Quest Engineering Atlantic E0014 User manual

Atlantic 3 Way chest fridge
Instruction manual
E0014: Atlantic 3 way chest fridge

www.questleisure.com
Correct Disposal
This marking indicates that this product should not be disposed
with other household wastes though out the EU. To prevent
possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote
sustainable reuse of material resources.
To return your used product, please use the return and collection
systems or contact the retailer from where the product was
purchased.
Specifications
Gross Capacity: 41 L.
Weight: 16 kg.
Size: 50  51  44cm.
DC Cooling: 85 Watts.
AC Cooling: 85 Watts.
Energy consumption (24h):
AC: 1.6 kWh/24h
DC: 169 Ah/24h
Gas: 100% Propane or 100% Butane is recommended
Category: I3+
Gas pressure: 28-30mbar (Butane) 37mbar (Propane)
Gas consumption (g/h): 12,6 g/h
The manufacturer reserves the right to change the products characteristics without prior
notice.
Atlantic 3 way chest fridge
Code: E0014
* All sizes and weights are approximate
RoHS
COMPLIANT

207.5911.86
Model: E0014
Type: JCB-1
Operating Instructions GB
0402
QUEST

2
Thank you for choosing our appliance. We are sure it will provide you with trouble-free use.
In the following, we would like to familiarise you with some symbols, which we bring to your attention to ensure
the safe and efficient operation of the appliance:
source of danger, in event of improper operation
suggested useful tips to read
information concerning environmental protection
The cooling box you have purchased is designed for operation from electrical mains, from a vehicle battery or
from bottled (LP) gas.
Please read these operating instructions carefully before putting the
refrigeration unit into operation. If you later sell or dispose of it, please ensure
that the new owner receives these operating instructions.
Attention!
Your portable Refrigerator - in gas operation - must only be used in a well-ventilated
place, above ground, where it is protected from rain or water splashes.
In electrical operation, the appliance can be used in an enclosed area. However
the appliance must still be protected from moisture.
The unit must not be used with gas operation in motor vehicles and boats
whilest the vehicle or boat is in motion!
Operation using liquid gas in enclosed spaces in not permitted!
THIS COOLING UNIT MAY ONLY BE USED WITH GAS OUT OF DOORS!
Outdoor use includes tents (awnings) which are well ventilated throughout unit
operation and flat garden terraces.
In this appliance the storage of any toxic or explosive substance is forbidden!
Only operate this appliance on one energy source at a time.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
It is important in the interests of efficiency, to give the back of the unit as much
ventilation as possible to allow the heat to escape. The hottest spot is in the vicinity
of the burner, and particularly when operating on gas, it is essential that this
place be kept clear of any obstruction or flammable materials.

3
C
CONTENT ONTENTS S
1. Unpacking
2. View of the appliance
3. Cleaning
4. Positioning the appliance
5. Using the appliance
5.1. From electrical mains
5.2. From vehicle battery
5.3. From bottled gas
6. Ice-making
7. Useful suggestions
8. Defrosting, cleaning and maintenance
9. Customer service
10. Putting into operation, technical data
10.1. Connecting to electrical mains
10.2. Connecting to vehicle battery
10.3. Connecting to as cylinder
10.4. Connection of gas supply
11. Environmental protection information
12. Recycling
ATTENTION!
Warranty arrangements are in accordance with EC Directive 44/19999/CE and the
normal conditions applicable in the country concerned.
For warranty or other servicing, such as spare-parts, please contact our Dometic
Service Network.
The warranty does not cover any damage due to improper use.
The warranty does not cover any modifications to the appliance or the use of non-
original Dometic spareparts.
The warranty does not apply if the installing and operating instructions are not adhered
to.
When contacting Dometic Service Network, please state the model, product number
and serial number.
You will find this information on the data plate on the rear cover of the refrigerator.

4
1. Unpacking
After removal from the cardboard packaging, make
sure the appliance is not damaged. If you find damage
to the appliance resulting from transport, report it
immediately to the transportation firm.
2. View of the appliance
1. insulated casing
2. insulated lid
3. control panel
4. evaporator panel
Figure 1.
2
4
3
1

5
Figure 2.
3. Cleaning
Clean both the inside and outside of the appliance
before putting it into use.
To do so, use a soft towel, lukewarm water and a non-
abrasive detergent. Ensure water does not enter the
rear cover grille or the control elements.
Afterwards, wipe the appliance with a clean towel and
cleanwater, and then wipe it dry.
To avoid damage, do not use soap, soda or abrasive
cleaners.
4. Positioning the appliance
During the refrigeration process, the appliance
gives off heat from the condenser (under the
upper part of the rear cover) into the surrounding air.
The more ventilated the condenser is, the more
effective the refrigeration will be.
The other condition for satisfactory operation is that
the appliance stands on a flat surface. This is best
seen by placing a glass of water on top of the
appliance.
It is important that the appliance is not directly
exposed to radiated heat (sunlight, radiator, near an
oven, etc.).
In gas operation following clearances should be
kept from the walls or other materials: from the back
side of the appliance minimum 10cms, from both
sidewalls 4cms each, from the top of the appliance
minimum 30 cms, from the bottom minimum 5 cms.
In the immediate vicinity of the appliance within the
specified distances no inflammable matters (paper,
wood, grass, textile etc.) should be met with.
5. Using the appliance
The cable for mains connection, the 12V connecting
cable and the connector for the gas hook-up are
located on the rear cover of the cooling box. (Figure
2).
5.1. Operating from electrical mains
Make sure the voltage shown on the data plate of the
appliance matches that of the mains voltage to which
you wish to connect the appliance. Pull out the mains
connecting cable and connect it to a receptacle
earthed socket for connection.
When connecting the appliance for the first time, set
the thermostat (Figure 4. A), to maximum; then, after
about five hours, set it back towards minimum
according to your need of cooling.
NB: Plug is provided according to specific
regulations in each country and may be different to
that shown.

6
Figure 3.
Figure 4.
5.2. Operating from vehicle battery
Make sure the voltage shown on the data plate of the
appliance matches the voltage of the vehicle battery
(12V or 24V).
12V DC voltage appliances are equipped with
connectors that can be plugged into cigarette lighters
(Figure 3.). For some types of vehicles, you may need
to remove the red plastic ring located on the end of
the connector. To do so, turn the plastic ring anti-
clockwise and pull it off. The appliance can then be
connected to the cigarette lighter. In 12V operation,
the appliance runs uninterrupted without temperature
control.
24V DC voltage appliances are shipped with bare wire
ends. The wire ends must be connected to a terminal
block, which is connected to the vehicle battery via a
5A fuse and 5A switch.
Whenever the engine is not running, the
appliance connector must be removed from the
cigarette lighter (12V appliance) or the switch turned
off (24V appliance). Otherwise, the appliance will
discharge the vehicle battery rapidly.
5.3. Operating from bottled gas
Connection to the gas cylinder is described in
sections 9.3. and 9.4.
After opening the valve of the gas cylinder and
checking for gas leaks turn thermostat to maximum
position (Figure 4. B), press down the gas safety valve
hold it down for about 10 seconds and then, press the
piezo-ignition button (marked with a star Figure 4. C)
several times in quick succession. If the flame does
not ignite, repeat the process. (Air in the appliance
gas line prior to connection to the gas cylinder must
be purged. Only then can the gas be lit.).
The control knob has 4 positions:
: high flame (MAX) = gas supply maximum
(high ambient temperature ~32 °C);
: medium flame (MID)= gas supply medium
(normal ambient temperature ~25°C);
: low flame (MIN) = gas supply minimum (low
ambient temperature ~16°C);
: off-position = gas supply to burner is shut off.
Ignition of the flame can be verified through the flameview
opening (Figure 5). After you have the flame alight keep the
safety gas valve pressed down for a further 20 seconds.
To stop the gas operation the valve of the gas cylinder (or
the pressure regulator) is to close.
Figure 5.
B
AC

7
6. Ice-making
Fill the ice-tray with drinking water to within 4/5 from the top and cover with lid. Wipe off any drops of water
which may be on the tray and lid to prevent freezing together and place in the cooler on the refrigerating unit.
Ice will be made more quickly when the thermostat knob (for electric operation) or regulating knob (for liquid
gas operation) is set to MAX for a short time. (When ice has formed, do not forget to return the knob to its
normal setting.)
To remove the ice, allow the ice-tray to defrost slightly for a while or run it under tap water at normal
temperature before removing the lid from the tray. The ice cubes can now be removed easily from the tray.
7. Useful suggestions
When setting out on a trip, run the appliance on 230 V (in thermostat setting between "min" and "max") for
24 hours prior to departure. Place food in a precooled condition into the appliance.
Frost forms on the evaporator panel when in operation. When opening the lid or putting in food, some of
this frost melts and collects in the form of water on the bottom of the appliance. Wipe the water off
occasionally using a sponge.
Avoid putting foods with fragile packaging (such as glass) into the cooling box. Movements and shaking of
the unit may cause these items to break.
Once the coolong box is in its permanent position, make sure foods do not come into contact with the
evaporator panel, as this can cause freezer-burn to the foods.
8. Defrosting, cleaning and maintenance
For defrosting, always unplug the appliance from an electrical power source to avoid the risk of shock.
Make sure no other power source is connected (gas or 12V/24V). Remove food from the refrigeration unit and
leave the lid open. Depending on the temperature, frost melts in a short time from the evaporator panel, with
water collecting at the bottom of the appliance.
Wipe it off using a towel. Afterwards, clean the appliance by following the instructions in section 3.
Leave the lid ajar to prevent any odours from forming.
The appliance does not require any further maintenance.

8
9. Customer service
Before notifying customer service, please check the
following:
Are location and ventilation satisfactory?
Is the appliance level?
Is there a current in the wall socket and is the
connection suitable for the appliance?
Is the mains power cable damaged?
For mains operation, is the electric thermostat swiched
on?
For gas operation, was the safety valve knob pressed
down long enough?
Is the thermostat knob set towards the maximum
position?
Is the gas cylinder or the pressure regulator valve open?
Is there any gas in the cylinder? (If by shaking, no liquid
movement can be detected, then the cylinder is empty.)
Are by any chance two different power sources
connected (such as gas or electricity)?
Was warm food placed in the unit?
Was a large quantity of food put in at one time?
If after checking the above, the appliance still does not
operate properly, contact customer service.
When reporting the problem, state the type of problem, the
type of appliance, and the product number and serial
number from the data plate.
We assume the warranty in accordance with our warranty
assumptions for the appliance.
www.dometic.com
10. Putting into operation
You must, in all instances, operate the
appliance from a single energy source only.
Connecting several energy sources at the same time
will cause failure of the appliance.
Technical data:
10.1. Connecting to electrical mains
Make sure no other energy source is connected (gas,
12V).
The appliance may only be operated from
nominal voltage mains as shown on the data
plate. The appliance mains plug may be connected to a
mains socket earthed in accordance with regulations.
Any electrical work required to install this appliance
should be carried out by a qualified electrician or
competent person.
The manufacturer declines any liability should
these safety measures not be observed.
Electrical Requirements
Before switching on, make sure the electricity supply
voltage is the same as that indicated on the appliance
data plate.
Only for UK:
The appliance is supplied with a 3 amp plug fitted. In the
event of having to change the fuse in the plug supplied,
a 3 amp ASTA approved (BS 1362) fuse must be used.
Should the plug need to be replaced for any reason, the
wires in the mains lead are coloured in accordance with
the following code:
Green and Yellow: Earth
Blue: Neutral
Brown: Live
The wire coloured green and yellow must be connected
to the terminal marked with the letter „E“ or by the earth
symbol or coloured green and yellow.
The wire coloured blue must be connected to the
terminal „N“ or coloured black.
The wire coloured brown must be connected to the
terminal marked „L“ or coloured red.
Upon completion there must be no cut, or stray strands
of wire present and the cord clamp must be secure over
the outer sheath.
Model E0014
Type JCB - 1
Gross volume 41 litre
Mains operation 220 - 240V (AC)
Input 85W
Energy consumption 1.38 kWh/24h
Battery operation 12V (DC)
Input 85W
Energy consumption 170Ah/24h
Gas pressure (p) 28-30/37 mbar
Gas classification I3+
Jet size 2
Rated thermal loading: butane 161W -- 11,7 g/h
(propane) (138W - 9,8g/h)
Min.thermal loading: butane 127W - 9,1g/h
(propane) (102W - 7,2g/h)
Climate class N
Refrigerant 159g H2O + 86g NH3

9
10.2. Connecting to vehicle power
source
Make sure no other energy source is connected (gas,
230V).
A safety fuse must be installed in the electricity supply
between battery and the cooling box in a duct.
12V appliances must be connected to a vehicle
cigarette lighter, which is protected with a 10A fuse.
24V appliances must be connected by inserting a
terminal block and switch and protected with a 5A
fuse. The switch must be suitable for switching a 5A
current.
It is not necessary to consider the polarity when
connecting the unit.
In case you need a longer cable, please refer to the
table below:
max. cable lengths
Cable cross section 12 V 24 V
2.5 mm2until 2.5 m 5 m
4.0 mm2until 4.0 m 8 m
6.0 mm2until 6.0 m 12 m
Do not connect a cable thicker than 2.5 mm2into the
cigarette lighter plug! Please build a terminal block
connection.
10.3. Connecting to gas cylinder
Make sure no other energy source is connected
(230V, 12V).
The unit must not be connected to town or natural
gas pipelines. It is only suitable for use with
propane/butane gas (e.g. Calor Gas, Camping Gaz,
Caravangas, etc.).
The cooling box is equipped for a specific gas-
pressure, corresponding to the standard pressure of
the country in which it is sold. The data plate states
the pressure that is correct. It is important that a non-
adjustable pressure-regulator must be used to reduce
the pressure in the gas cylinder to the operating
pressure specified on the data plate. No other
pressure may be used.
Needle valve-operated gas valves are NOT suitable
for use with this appliance and must not be used as a
substitute for a pressure regulator.
10.4. Connection of gas supply
The correct connection of the fridge has to be
carried out by a skilled specialist. Note the
particularly valid national rules for usage of
liqiud gas driven appliances.
(The following instructions refer in the main to
coolers manufactured in the United Kingdom. For
other countries please refer to your supplier.)
Always connect in the following sequence:
GAS BOTTLE →PRESSURE-REGULATOR →
→ APPLIANCE.
To connect the appliance to the pressure-regulator
an APPROVED FLEIBLE GAS TUBE must be used.
This must not be longer than 1,5 m - and should
have an inside dimension of 8 mm and be marked
BS3212/2/8. The flexible gas tube must not be
twisted! It must be regularly changed if it is
determinated in the standard of your country.
The pressure-regulator must be compatible for
Butane 11 in (28 mbar) or for Propane 14 in (37
mbar).
To connect the pressure-regulator to the gas bottle,
the valve of the gas bottle must be closed. After
connecting the pressure regulator to the bottle by
screwing, connect the two ends of the tubing to the
nipples and secure them with the two hose clipse.
(Figure 6).
When fitting the connection to the gas inlet of the
appliance (Figure 6 D), hold the counterpart to
avoid straining and possibly damaging.
The gas bottle (Butane, blue bottle) may only be
used in an upright position and particular care must
be taken every time the appliance is connected to
the gas bottle to ensure that there are no leaks, that
the tubing (rubber hose) is not under tension or
kinked, and that it is not in contact with hot
surfaces.
The tubing and the gas bottle should always be
located in positions where they will not be tripped
over or otherwise inadvertently disturbed.
Before attempting to light the burner, every time
after connection, turn on the gas at the bottle and
check the gas connections for leaks by applying a
soap and water solution over them and watching for
bubbles, which would indicate a leak.
After testing dry off traces of detergent.

10
For your safety:
Do not check for leaks with a naked flame! Do not smoke while checking for leaks!
Figure 6.
seal
This appliance complies with the following EEC
directives:
LVD-Directive 2006/95/EC
EMC-Directive 2004/108/EC
Gas-Directive 90/396/EEC
CE-Directive 93/68/EEC
RoHS-Directive 2002/95/EC
WEEE-Directive 2002/96/EC.
11. Environmental protection
information
Ammonia (natural hydrogen and nitrogen compound)
is used as refrigerant agent in the cooling unit.
The ozone-friendly cyclopentane is used as a blowing
agent for the PU foam insulation.
Sodium chromate is used for corrosion protection
(less than 2 weight % of the coolant).
12. Recycling
After unpacking the appliance, the packing materials
should be delivered to a local collection site. At the
end of its useful lifetime, the appliance should be
delivered to a specialised recycling firm, which
reclaims the usable materials. The rest is properly
destroyed.
Appliances bearing this symbol must be
deposited at the designated local
reception point for the disposal of
electrical and electronic equipment.
It is not permitted that this product be disposed of by
way of the normal household refuse collection system.
Dometic refrigerators bear this symbol on the
specifications plate (data plate) to be found on the rear
cover of the unit.

11

Printed by Canon Hungária Kft. Rev.: 2015. 12. 02.

Quest Leisure
Page 1
Atlantic
3 Way chest fridge
Product Code: E0014
Instruction Version: 3
Warranty Form
• Please fill out this warranty form before you return to your dealer. If you do not then you will be
required to fill this form out at your dealer.
Your name:
Your contact:
(Email, phone or address)
Date of purchase:
Place of purchase:
Serial number of fridge:
(Found on silver sticker/
plate on the back of the
fridge)
Details of fault:
