R.V.R. Electronica PJ500C-LCD User manual

PJ500C-LCD &
PJ1000-LIGHT
User Manual
Volume 1
Manufactured by Italy

PJ500C-LCD & PJ1000-LIGHT - User Manual
Version 1.0
© Copyright 2005 - 2006
R.V.R. Elettronica SpA
Via del Fonditore 2/2c - 40138 - Bologna (Italia)
Telephone: [phone]
Fax: [phone]
Email: [e-mail]
Web: www.rvr.it
All rights reserved
Printed and bound in Italy. No part of this manual may be reproduced,
memorized or transmitted in any form or by any means, electronic
or mechanic, including photocopying, recording or by any informa-
tion storage and retrieval system, without written permission of the
copyright owner.
File Name: 03_PJ500C-LCD&PJ1000light_ING_1.0.indd
Version: 1.0
Date: 15/12/2006
Revision History











Document History
Date Version Reason Editor
15/12/06 1.0 First Edition J.H. Berti

PJ500C-LCD & PJ1000-LIGHT
iUser Manual Rev. 1.0 - 15/12/06
Table of Contents
1. Preliminary Instructions 1
2. Warranty 1
3. First Aid 1
3.1 Treatment of electrical shocks 1
3.2 Treatment of electrical Burns 2
4. Unpacking 3
4.1 General Description 3
5. Quick guide for installation and use 5
5.1 Preparation 5
5.2 First power-on and setup 8
5.3 Operation 11
5.4 Management Firmware 12
6. Front and Rear Panel Description 20
6.1 Front Panel 20
6.2 Rear Panel 21
6.3 Connectors description 22
 7. TechnicalSpecications 23
8. Operating principles 24
8.1 Power supply 24
8.2 Interface board (SL010IN3001) 26
8.3 Panel board - CPU (SL007PC2002) 26
8.4 PWR Input Measure Board (SLMPIPPJ1KC) 27
 8.5  Poweramplier 27
8.6 LPF Board (SLLPFTEX1KL) 27
8.7 BIAS board (SLBIAS1K3U-2) 28
8.8 External Telemetry Interface Board (SLTLMTXLCD03) 28
 9. IdenticationandAccesstotheModules 29
9.1 Top View (PJ500C-LCD) 29
9.2 Bottom View (PJ500C-LCD) 30
9.3 Top View (PJ500C-LCD) 31
9.4 Bottom View (PJ500C-LCD) 32

PJ500C-LCD & PJ1000-LIGHT
ii User ManualRev. 1.0 - 15/12/06
This page was intentionally left blank

1 / 32User Manual Rev. 1.0- 15/12/06
PJ500C-LCD & PJ1000-LIGHT
1. Preliminary Instructions
This manual is written as a general guide for those having previous
knowledge and experience with this kind of equipment, well
conscious of the risks connected with the operation of electrical
equipment.
It is not intended to contain a complete statement of all safety
rules which should be observed by personnel in using this
or other electronic equipment.
The installation, use and maintenance of this piece of
equipment involve risks both for the personnel performing
them and for the device itself, that shall be used only by
trained personnel.
R.V.R. Elettronica SpA doesn’t assume responsibility for
injury or damage resulting from improper procedures or
practicesbyuntrained/unqualiedpersonnelinthehandling
of this unit.
Pleaseobservealllocalcodesandreprotectionstandards
in the operations of this unit.
WARNING: always disconnect power before
opening covers or removing any part of this unit.
Pleaseobservealllocalcodesandreprotectionstandards
in the operations of this unit.
WARNING: this device can irradiate radio
frequency waves, and if it’s not installed following
the instructions contained in the manual and local
regulations it could generate interferences in radio
communications.
This is a “CLASS A” equipment. In a residential place this
equipment can cause hash. In this case can be requested
to user to take the necessary measures.
R.V.R. Elettronica SpA reserves the right to modify the
design and/or the technical specications of the product
and this manual without notice.
2. Warranty
Any product of R.V.R. Elettronica is covered by a 24
(twenty-four) month warranty.
Forcomponentsliketubesforpowerampliers,the
original manufacturer’s warranty applies.
R.V.R. Elettronica SpA extends to the original end-
user purchaser all manufacturers warranties which are
transferrable and all claims are to be made directly to
R.V.R. per indicated procedures.
Warranty shall not include:
1 Re-shipment of the unit to R.V.R. for repair
purposes;
2 Anyunauthorizedrepair/modication;
3 Incidental/consequential damages as a result
of any defect;
4 Nominal non-incidental defects;
5 Re-shipment costs or insurance of the unit or
replacement units/parts.
Any damage to the goods must be reported to the carrier in
writing on the shipment receipt.
Any discrepancy or damage discovered subsequent to
delivery, shall be reported to R.V.R. Elettronica within 5
(ve)daysfromdeliverydate.
To claim your rights under this warranty, you shold follow
this procedure:
1 Contact the dealer or distributor where you
purchased the unit. Describe the problem
and, so that a possible easy solution can be
detected.
Dealers and Distributors are supplied with all the information
about problems that may occur and usually they can repair
the unit quicker than what the manufacturer could do. Very
often installing errors are discovered by dealers.
2 If your dealer cannot help you, contact R.V.R.
Elettronica and explain the problem. If it
is decided to return the unit to the factory,
R.V.R. Elettronica will mail you a regular
authorization with all the necessary instructions
to send back the goods;
3 When you receive the authorization, you can
return the unit. Pack it carefully for
the shipment, preferably using the original
packing and seal the package perfectly. The
customer always assumes the risks of loss
(i.e., R.V.R. is never responsible for damage
or loss), until the package reaches R.V.R.
premises. For this reason, we suggest you to
insure the goods for the whole value. Shipment
must be effected C.I.F. (PREPAID) to the
addressspeciedbyR.V.R.’sservicemanager
on the authorization
DO NOT RETURN UNITS WITHOUT OUR
AUTHORIZATION AS THEY WILL BE REFUSED
4 Be sure to enclose a written technical report
where mention all the problems found and a
copy of your original invoice establishing the
starting date of the warranty.
Replacement and warranty parts may be ordered from
the following address. Be sure to include the equipment
model and serial number as well as part description and
part number.
R.V.R. Elettronica SpA
Via del Fonditore, 2/2c
40138 BOLOGNA
ITALY
Tel. [phone]
3. First Aid
The personnel employed in the installation, use and
maintenance of the device, shall be familiar with theory and
practiceofrstaid.
3.1 Treatment of electrical shocks
3.1.1 If the victim is not responsive
Follow the A-B-C’s of basic life support.
• Place victim flat on his backon a hard
surface.
• Open airway: lift up neck, push forehead back
(Figure 1).
Figure 1

2 / 32 User ManualRev. 1.0 - 15/12/06
PJ500C-LCD & PJ1000-LIGHT
• clear out mouth if necessary and observe for
breathing
• if not breathing, begin artificial breathing
(Figure 2): tilt head, pinch nostrils, make airtight
seal, four quick full breaths. Remember mouth
to mouth resuscitation must be commenced as
soon as possible.
Figure 2
• Check carotid pulse (Figure 3); if pulse is
absent, begin articial circulation (Figure 4)
depressing sternum (Figure 5).
Figure 3 Figure 4
Figure 5
• In case of only one rescuer, 15 compressions
alternated to two breaths.
• If there are two rescuers, the rythm shall be of
one brath each 5 compressions.
• Do not interrupt the rythm of compressions
when the second person is giving breath.
• Call for medical assistance as soon as
possible.
3.1.2 If victim is responsive
• Keep them warm.
• Keep them as quiet as possible.
• Loosen their clothing (a reclining position is
recommended).
• Call for medical help as soon as possible.
3.2 Treatment of electrical Burns
3.2.1 Extensive burned and broken skin
• Cover area with clean sheet or cloth.
• Do not break blisters, remove tissue, remove
adhered particles of clothing, or apply any salve
or ointment.
• Treat victim for shock as required.
• Arrange transportation to a hospital as quickly
as possible.
• If arms or legs are affected keep them
elevated.
If medical help will not be available within an hour and
the victim is conscious and not vomiting, give him a weak
solution of salt and soda: 1 level teaspoonful of salt and
1/2 level teaspoonful of baking soda to each quart of water
(neither hot or cold).
Allow victim to sip slowly about 4 ounces (half a glass) over
a period of 15 minutes.
Discontinueuidifvomitingoccurs.
DO NOT give alcohol.
3.2.2 Less severe burns
• Apply cool (not ice cold) compresses using the
cleansed available cloth article.
• Do not break blisters, remove tissue, remove
adhered particles of clothing, or apply salve or
ointment.
• Apply clean dry dressing if necessary.
• Treat victim for shock as required.
• Arrange transportation to a hospital as quickly
as possible.
• If arms or legs are affected keep them
elevated.

3 / 32User Manual Rev. 1.0- 15/12/06
PJ500C-LCD & PJ1000-LIGHT
4. Unpacking
The package contains:
1 PJ500C-LCD & PJ1000-LIGHT
1 User Manual
1 Mains power cable
The following accessories are also available from Your R.V.R. Dealer:
• Accessories, spare parts and cables
4.1 General Description
PJ500C-LCD ePJ1000-LIGHT are compact radio broadcasting amplier
manufactured by R.V.R. Elettronica SpA featuring adjustable RF power output
up to 500W and 1000 W, respectively, under 50 Ohm standard load and less than
20W drive power requirement.
PJ500C-LCD and PJ1000-LIGHT have been designed for installation in a 19”x3HE
box for rack.
Theseampliersincorporatesalow-passltertokeepharmonicsbelowthelimits
provided for by international standards (CCIR, FCC or ETSI).
Two major features of PJ500C-LCD e PJ1000-LIGHT are compact design and
user-friendliness. Another key feature is its modular-concept design: the different
functions are performed by modules with most connections achieved through
maleandfemaleconnectorsorthroughatcablesterminatedbyconnectors.This
design facilitates maintenance and module replacement.
The RF power section of PJ500C-LCD uses two MOSFET modules delivering
up to 300W output power each, whereas PJ1000-light features three MOSFET
modules with up to 350 W output power each.
An LCD on the front panel and a push-button panel provide for user interfacing with
the microprocessor control system, which implements the following features:
• Output power setup
• Power output enable/disable
• User-selectable threshold settings for output power alarm (Power Good
feature)
• Measurementanddisplayofamplieroperatingparameters
• Communication with external devices, as programming systems or telemetry
systems through RS232 or I2C serial interface

4 / 32 User ManualRev. 1.0 - 15/12/06
PJ500C-LCD & PJ1000-LIGHT
Four LEDs on the front panel provide for machine status indication (ON, FAULT/
LOCK, FOLDBACK, RF MUTE) and two yellow LEDs provide Power Supply fault
indication.
Theampliermanagementsoftwareisbasedonamenusystem.Userhasfour
navigation buttons available to browse submenus: ESC, , , and ENTER.
The rear panel features the mains input connectors with a mains voltage switch
(chap. 6.2) to select the appropriate mains input voltage, RF input and output
connectors, telemetry connector, protection fuses, interlock input and output
connectors and a BNC connector that provides an RF test point with level being
-60 dB lower than power ouput.

5 / 32User Manual Rev. 1.0- 15/12/06
PJ500C-LCD & PJ1000-LIGHT
5. Quick guide for installation and use
This section provides a step-by-step description of the machine installation and
conguration procedure. Follow these procedures closely upon rst power-on
andeachtimeanychangeismadetogeneralconguration,suchaswhenanew
transmission station is added or the exciter is replaced.
Oncethedesiredcongurationhasbeensetup,nomoresettingsarerequired
for normal operation; at each power-up (even after an accidental shutdown),
the amplifier defaults to the parameters set during the initial configuration
procedure.
The topics covered in this section are discussed at greater length in the next
sections, with detailed descriptions of all hardware and rmware features and
capabilities. Please see the relevant sections for additional details.
IMPORTANT: When conguring and testing the transmitter in which the amplier
is integrated, be sure to have the Final Test Table supplied with the machine ready
at hand throughout the whole procedure; the Final Test Table lists all operating
parameters as set and tested at the factory.
5.1 Preparation
5.1.1 Preliminary checks
Unpacktheamplierandimmediatelyinspectitfortransportdamage.Ensurethat
all connectors are in perfect condition.
Provide for the following (applicable to operating tests and putting into service):
√ Single-phase 230 VAC or 115 VAC (-15% / +10%) mains power supply with
adequate ground connection
√ FM exciter with adjustable output power up to 20W (as a minimum), like RVR
Elettronica PTX30-LCD
√ For operating tests only: dummy load with 50 Ohm impedance and adequate
capacity (500w for PJ500C-LCD or 1000 W for PJ1000-light as a minimum)
√ Connection cable kit including:
• Mains power cable

6 / 32 User ManualRev. 1.0 - 15/12/06
PJ500C-LCD & PJ1000-LIGHT
5.1.2 Mains power supply
WARNING: Disconnect mains power supply before beginning these
procedures.
Both power supply units (please see chapter 8.1 for a detailed description) are
equipped with fuses and voltage selection blocks: check all fuses and voltage
selection blocks to ensure they are properly rated for the power mains and
change them as required to match mains voltage.
All mains power supply protection fuses are conveniently located on the rear panel
andareeasilyaccessed(seegure6.2):tocheckorreplaceafuse,disconnect
machine from power mains, unscrew fuse cover and pull fuse out of socket.
The following fuses are used:
PJ500C-LCD
@ 230 Vac/115 Vac
PJ1000-light
@ 230 Vac/115 Vac
Main Power Supply
(g. 6.2 – item [7] e [20]) (2x) 25A type 10x38 (2x) 25A type 10x38
Service power supply
( g. 6.2 – item [19]) (1x) 1A type 5x20 (1x) 2A type 5x20
Table 5.1: Fuses
Ensure that machine is appropriately set for available mains voltage (supply voltage
rating is reported in the Final Test Table) as follows: disconnect machine from
mains and ensure that the voltage selection block of the power supply located on
therearpanel(seeg.6.2)issettotheappropriatevoltage;changesettingas
required.
The main power supply unit is the full-range type and requires no voltage setup.
When supply voltage is other than 230 Vac and might cause erratic operation (say,
less than 200 Vac), it may help to move jumper JP3 on the PFC controller board
fromposition2-3to1-2(seePFCPSL1000diagram,ingure 9.1 and detail in
gure5.1below).

7 / 32User Manual Rev. 1.0- 15/12/06
PJ500C-LCD & PJ1000-LIGHT
Figure 5.1: Voltage selection jumper on PFC
5.1.3 Connections
Connect the output of a suitable FM exciter (for instance, PTX30-LCD exciter
availablefromR.V.R.Elettronica)totheRFinput(seegure6.2)usinga50-Ohm
coaxial cable with suitable connectors. To begin with, set exciter to minimum output
power and switch if off.
Connect the amplier INTERLOCK OUT output (gure 6.2) to the matching
INTERLOCKINinputttedonallR.V.R.Elettronicaexcitersasstandard;ifyour
exciter is a different brand, identify an equivalent input.
ConnecttheRFoutput(seegure6.2)toanadequatelyrateddummyloadorto
the antenna.
WARNING: Electric shock hazard. Never handle the RF output connector
when the machine is powered on and no load is connected. Injury or death
may result.
Ensure that the POWER switch on the front panel (see gure 6.1) is set to
“OFF”.
Connect the mains power cable to the MAINS terminal board on the rear panel
(seegure6.2).
Note : The mains must be equipped with adequate ground connection properly
connected to the machine. This is a pre-requisite for ensuring operator safety and
correct operation.
WARNING: The power supply connector is a terminal board. Ensure the wire
is not live before performing the connection.
Pleaseseegure5.2forahook-updiagramshowingRFconnectionbetween
amplierandexciterandloadconnection.

8 / 32 User ManualRev. 1.0 - 15/12/06
PJ500C-LCD & PJ1000-LIGHT
Figure 5.2: Connection to exciter
5.2 First power-on and setup
Follow this procedure upon rst power-on and after making changes to the
congurationofthetransmitterinwhichtheamplierisintegrated.
Note : Standard factory settings are RF power output Off (Pwr OFF) and output
power set to upper limit (unless otherwise specied by customer).
5.1.2 Pilot exciter setup
Set up the pilot exciter so that the output power it delivers to a matched load equals
themaximuminputpowerindicatedintheampliernaltesttable, switch off the
exciterandconnectittotheamplier.
5.2.2 Power-on
When you have performed all of the connections described in the previous
paragraph,poweron the amplier usingthesuitablepowerswitch on the front
panel(gure6.1).Poweronthepilotexciter.

9 / 32User Manual Rev. 1.0- 15/12/06
PJ500C-LCD & PJ1000-LIGHT
5.2.3 Power check
Ensure that the ONlightturnson(seegure6.1).Machinenameshouldappear
brieyonthedisplay,quicklyfollowedbyforwardandreectedpowerreadings
(gure5.2-menu1).IfRFoutputisdisabled,thesereadingswillbezero.
5.2.4 How to enable Local mode and RF output
Check current mode setting and enable Local mode (if not already enabled)
following menu path Fnc ⇒Loc ⇒Local(gure5.2-menu4):ifleftdisabled,
the machine will not accept the next commands.
Check current RF output setting and enable output (if not already enabled) following
menu path Fnc ⇒Pwr ⇒ON(gure5.2-menu4)
Check output power level and set to maximum level (if not already set to maximum)
from the Power Setup Menu, which you can call up by pressing these keys in the
order: ESC (opens Default Menu) ⇒ENTER (hold down for 2 seconds) ⇒SET
⇒usekeytosetbartomaximumlimit(gure5.2-menu2).
5.2.5 Input power check and setup
Go to Pwrmenu(gure5.2-menu5)andlookupforwardoutputpowerFwd,
reectedpowerR and input power Inp readings.
WithdrivepowersetasspeciedintheFinal Test Table,amplieroutputpower
should be 500W (for model PJ500C-LCD) or 1000W (for model PJ1000-light) or
higher:ifneeded,netunedrivepoweruntilachievingratedoutputpower.Never
exceed 550W (for model PJ500C-LCD) or 1100W (for model PJ1000-light) output
power.
Note : Normally, drive power should not exceed 20W (typically 18W): higher drive
power requirements are a symptom of abnormal operation.
WARNING:Drivepowerlevelsabove20W(typically25W),resultinexceeding
inputpower,whichcausesatemporaryamplierlock-out(seesection5.3.4.1
- Alarms and Faults for more details).
5.2.6 RF output power level control
IMPORTANT: The amplier incorporates Automatic Gain Control and output
power is modulated based on the power level set by the user and actual operating
conditions, such as temperature, reected power and other parameters. Drive
power must be kept steady at maximum output power capacity. Please read section
5.3 for more details of RF power modulation.

10 / 32 User ManualRev. 1.0 - 15/12/06
PJ500C-LCD & PJ1000-LIGHT
Open the Power setup menu(gure5.2-menu2)pressingthefollowingkeys
in the order:
ESC (opens Default Menu) ⇒ENTER (hold down for 2 seconds)
Use SET menu and keystosetthedesiredamplieroutputpower;theSET
bar at the side provides a graphic display of set power, whereas the forward power
value shown on the display (Fwd:xxxxW) gives actual output power reading,
and may be lower than set power if an Automatic Gain Control is in limited-
power mode (please read section 5.3 concerning RF power modulation for more
details”.
Note : Output power can also be set in a Pwr OFF condition; in this condition,
(Fwd) output power reading on the display will be 0 (zero), whereas the SET bar,
which you can control using the keys, provides a graphic display of the amount of
power that will be delivered the moment you switch back to Pwr ON state.
5.2.7 Changing the Power Good alarm threshold
Change Forward Power Good alarm setting PgD from the Fnc menu as required
(factory setting is 50%).
Please read section 5.3.1 for more details.
5.2.8 Changing machine I2C address
Change the IIC address in the Mix menu as required (factory setting is 01).
Please read section 5.3.5 for more details.
5.2.9 How to enable Remote mode
If you wish to use the telemetry control feature, enable Remote control in the Fnc
menu (see section 5.3.1 for details).
Note : In the Remote mode, all local push-button controls except Remote/Local
(for switching back to Local mode) are disabled . Operating parameter readings
are available.

11 / 32User Manual Rev. 1.0- 15/12/06
PJ500C-LCD & PJ1000-LIGHT
5.3 Operation
NOTE: For better clarity, only the typical screens of PJ1000-LIGHT are reported
below. PJ500C-LCD screens look the same except that full scale values are
different.
1) Powerontheamplier(chap.6.1)andensurethattheON light turns on (chap.
6.1).Machinenameshouldappearbrieyonthedisplay,quicklyfollowedby
forwardandreectedpowerreadings(Menu1),providedthattheamplieris
delivering output power.
Menu 1
1b) To modify power level setting, hold down the ENTER button until opening
the power setup menu.
The edit screen will look like this:
Menu 2
Next to SET indication, a bar provides a graphic display of preset output power.
Thelledportionofthebarisproportionaltosetpowerlevel.
Example
100% output power Full bar
≅1000W in output
(mod.PJ1000-LIGHT)
≅500W output
(mod.PJ500C-LCD)
50% output power Half bar
≅500W in output (mod.
PJ1000-LIGHT)
≅250W output
(mod.PJ500C-LCD)
25% output power 1/4 bar
≅250W in output (mod.
PJ1000-LIGHT)
≅125W output
(mod.PJ500C-LCD)
The bottom line provides instantaneous power reading (997W in this instance);
press button to increase level, press to decrease it. When you have achieved
the desired level, press ENTERtoconrmandexitthedefaultmenu.Pleasenote
that the setting is stored automatically; in other words, if you press ESC or do not
press any keys before the preset time times out, the latest power level set will be
retained.

12 / 32 User ManualRev. 1.0 - 15/12/06
PJ500C-LCD & PJ1000-LIGHT
NOTE: This feature prevents the machine from delivering maximum power as
soon as output is enabled from menu 4, or in the event the machine is already
set to ON and energised.
2) Ensure that machine is not in a locked-out state. Press the ESC key (chap.
6.1) to call up the selection screen (Menu 3). Highlight Fnc and press ENTER
toconrm(chap.6.1)andaccesstheappropriatemenu(menu4).
If LOC is set to REMOTE (machine remote control), move cursor to LOC and
press ENTER (chap. 6.1); label will change to LOCAL, i.e. local control operation
mode.
In the same menu, ensure that power limiting is disabled: if PWR is set to OFF,
i.e. power output is disabled, move cursor to PWR. Press ENTER (chap. 6.1)
and label will switch to ON, i.e. power output enabled.
Press ESC (chap. 6.1) twice to go back to the default menu (menu 1).
3) Fine tune power setting from menu 2 (see description of item 1b) until achieving
the desired value.
WARNING:Equipment is capable of delivering more than rated output power
(500W for PJ500C-LCD or 1000 W for PJ1000-LIGHT); however, never exceed
thespeciedpowerrating.
NOTE: Exciter drive power setting should never exceed 20W, or it will trigger an
Overdrive Alarm.
NOTE: If power is set to 0 W in the edit mode, the INTERLOCK OUT contact
(chap. 6.2) trips and external exciter power is immediately inhibited.
Next, you can review all operating parameters of the machine through the
managementrmware.
Normally, the machine can run unattended. Any alarm condition is handled
automatically by the safety system or is signalled by the LED indicators on the
panel or by display messages.
NOTE: Standard factory settings are: output power set to upper limit (unless
otherwisespeciedbycustomer)andOFF.
5.4 Management Firmware
The machine features an LCD with two lines by 16 characters that displays a set
of menus. Figure 5.2 below provides an overview of machine menus.
The symbols listed below appear in the left portion of the display as appropriate:
(Cursor) - Highlights selected (i.e. accessible) menu.
(Filled arrow) - Editable parameter marker. This symbol appears in menus that
take up more than two lines to aid browsing.
(Three empty arrows) - Parameter is being edited.
(Empty arrow) - Current line marker; the parameter in this line cannot be
edited. This symbol appears in menus that take up more than two lines to aid
browsing.

13 / 32User Manual Rev. 1.0- 15/12/06
PJ500C-LCD & PJ1000-LIGHT
Menu 1
Menu 1
Operation Menu
Power Menu
P.A. Menu
Alarm Menu
Version Menu
Miscellaneous menu
Menu 3
Menu 3
Menu 2
Menu 2
Menu 4
Menu 4
Menu 5
Menu 5
Menu 6
Menu 6
Menu 7
Menu 7
Menu 8
Menu 8
Menu 9
Menu 9
Selection Screen
Power Setup Menu
Default Menu
Figure 5.2
When the display is off, touching any key will turn on backlighting.
When the display is on, pressing the ESC button (chap. 6.1) from the default
menu (menu 1) calls up the selection screen (menu 3), which gives access to
all other menus:
Menu 3
To gain access to a submenu, select menu name (name is highlighted by cursor)
using button or and press the ENTER button (chap. 6.1).
Press ESC again (chap. 6.1) to return to the default menu (menu 1).

14 / 32 User ManualRev. 1.0 - 15/12/06
PJ500C-LCD & PJ1000-LIGHT
5.4.1 Operation Menu (Fnc)
In this menu, you can set power output On/Off, toggle between “Local” or “Remote”
control mode and set the Forward Power Good (PgD) threshold rate.
To edit an item, highlight the appropriate line using the UP and DOWN buttons and
then press and hold the ENTER button (chap. 6.1) until the command is accepted.
This way, Pwr setting is toggled between On and Off and Mod setting is toggled
between “x1” and “x10”. To edit the Power Good rate, simply select item “PgD”
and edit its value using buttons and ;nally,pressENTER toconrm(chap.
6.1).
Menu 4
Pwr Enables(ON)ordisables(OFF)amplierpoweroutput.
Loc Modiesmachineoperation.IntheLOCALmode,themachinecanread
and modify its operating parameters through the navigation keys and the
managementrmware,whereasallothersourcesarelockedout.Inthe
REMOTE mode, the machine can only read its operating parameters;
parametersaremodiedbasedonthecommandsreceivedfromother
connected telemetry systems.
PgD ModiesPowerGoodthresholdforforwardpower.ThePowerGood
rate is a percent of equipment rated power (500W for PJ500C-LCD and
1000 W for PJ1000-LIGHT), not of forward output power. This means
that this threshold set at 50% will give 250 W and 500 W, respectively,
regardless of set power level. The Power Good feature enables output
power control and reporting. When output power drops below set Power
Good threshold, the equipment changes the state of pin [7] of the DB15
“Remote”connectorlocatedontherearpanel(gure6.2-[16]).

15 / 32User Manual Rev. 1.0- 15/12/06
PJ500C-LCD & PJ1000-LIGHT
5.4.2 Power Menu (Pwr)
This screen holds all readings related to machine output power:
Menu 5
Fwd Forward power reading.
R Reectedpowerreading.
Inp Input power reading.
Note that these are readings, rather than settings, and cannot be edited (note
the empty arrow). To change power setting, go to the default menu (menu 1) as
outlined earlier.
 5.4.3 PowerAmplier(P.A)Menu
This screen is made up of four lines that can be scrolled using the buttons and
,showsthereadingsrelatingtonalpowerstage:
Menu 6
Note that these are readings, rather than settings, and cannot be edited (note the
empty arrow).
VPA Voltagesuppliedtoampliermodule.
IPA Currentabsorbedtoampliermodule.
Eff Efciencybasedonratioofforwardpowertoampliermodulepower
in percent ( FWD PWR/(Vpa x Ipa) % ).
Tmp Machine internal temperature.

16 / 32 User ManualRev. 1.0 - 15/12/06
PJ500C-LCD & PJ1000-LIGHT
5.4.4 Alarm Menu (Alm)
This menu shows any alarm conditions occurring during machine operation. Alarm
thresholds are preset at the factory.
Menu 7
FWD Counter of alarm conditions triggered by forward power.
RFL  Counterofalarmconditionstriggeredbyreectedpower.
INP Counter of alarm conditions triggered by input power.
Reset Alm Alarm counter reset.
Alarmconditionsarenumberedfrom1to10andreectthefollowingsituations:
forwardoutputpowertoohigh,reectedoutputpowertoohighandinputpower
too high.
Alarm monitoring cycle is as follows: when an alarm condition is detected, alarm
counter increases by 1 unit, machine goes into lock-out state and the display shows
the cause for the stop (chap. 5.3.4.1). After 15 seconds, the machine attempts
to re-start; if a new alarm condition is detected, cycle is repeated over and over
again up to 10 times maximum.
If machine re-starts successfully, all alarm counters are reset after 30 minutes’
regular operation. After 10 alarm conditions triggered by the same cause, the
machine goes into fault lock-out mode, a lock-out mode warning appears on the
display and the “FAULT” LED turns on (chap. 6.1).
Afterthealarmconditionhasbeenrectied,thecountercanberesetbyhighlighting
“Reset Alm” and holding down the ENTER key for some time (chap. 6.1).
5.4.4.1 Alarms and Faults
There are three types of alarms that can cause a machine lock-out and trigger a
“FAULT” indication. Whenanyoneofthethreealarmthresholdsisexceeded,
the system will automatically switch to the warning screen (even though
the user is browsing system menus) and the following messages are
displayed:
