Rabbit BL2600 User manual

SBC BL2600
C-Programmable Single-Board Computer with Ethernet
User’s Manual
019–0142_L

SBC BL2600
SBC BL2600 User’s Manual
©2011 Digi International® Inc.
All rights reserved.
Rabbit, Dynamic C, RabbitCore, RabbitNet, Digi, Digi International, Digi Interna-
tional Company, and the Digi and Rabbit logos are trademarks or registered trade-
marks of Digi International, Inc. in the United States and other countries worldwide.
All other trademarks are the property of their respective owners.
Information in this document is subject to change without notice and does not repre-
sent a commitment on the part of Digi International.
Digi provides this document "as is," without warranty of any kind, expressed or
implied, including, but not limited to, the implied warranties of fitness or merchant-
ability for a particular purpose. Digi may make improvements and/or changes in this
manual or in the product(s) and/or the program(s) described in this manual at any
time.
This product could include technical inaccuracies or typographical errors. Changes
are periodically made to the information herein; these changes may be incorporated in
new editions of the publication.
The latest revision of this manual is available at www.digi.com.

User’s Manual
TABLE OF CONTENTS
Chapter 1. Introduction 1
1.1 BL2600 Description..............................................................................................................................1
1.2 BL2600 Features...................................................................................................................................1
1.2.1 Connector Options ........................................................................................................................3
1.2.2 Memory and Clock Speed Options...............................................................................................3
1.3 Development and Evaluation Tools......................................................................................................4
1.3.1 Tool Kit.........................................................................................................................................4
1.3.2 Software........................................................................................................................................5
1.3.3 Additional Tools ...........................................................................................................................5
1.4 CE Compliance.....................................................................................................................................6
1.4.1 Design Guidelines.........................................................................................................................7
1.4.2 Interfacing the BL2600 to Other Devices.....................................................................................7
Chapter 2. Getting Started 9
2.1 Preparing the BL2600 for Development...............................................................................................9
2.2 BL2600 Connections ..........................................................................................................................10
2.2.1 Hardware Reset...........................................................................................................................11
2.3 Installing Dynamic C..........................................................................................................................12
2.4 Starting Dynamic C ............................................................................................................................13
2.5 PONG.C..............................................................................................................................................14
2.6 Where Do I Go From Here? ...............................................................................................................14
Chapter 3. Subsystems 15
3.1 BL2600 Pinouts ..................................................................................................................................16
3.1.1 Connector Options ......................................................................................................................18
3.2 Digital I/O...........................................................................................................................................19
3.2.1 Digital Inputs...............................................................................................................................19
3.2.2 PWM Outputs .............................................................................................................................20
3.2.3 High-Current Digital Outputs .....................................................................................................21
3.2.4 Configurable I/O .........................................................................................................................23
3.3 Serial Communication ........................................................................................................................25
3.3.1 RS-232 ........................................................................................................................................25
3.3.2 RS-485 ........................................................................................................................................25
3.3.3 Programming Port.......................................................................................................................27
3.3.4 Ethernet Port ...............................................................................................................................28
3.4 A/D Converter Inputs..........................................................................................................................29
3.4.1 A/D Converter Calibration..........................................................................................................30
3.5 D/A Converter Outputs.......................................................................................................................31
3.5.1 D/A Converter Calibration..........................................................................................................32
3.6 Analog Reference Voltage Circuit......................................................................................................33
3.7 Serial Programming Cable..................................................................................................................34
3.7.1 Changing Between Program Mode and Run Mode....................................................................34
3.8 Other Hardware...................................................................................................................................35
3.8.1 Clock Doubler.............................................................................................................................35
3.8.2 Spectrum Spreader......................................................................................................................35

SBC BL2600
3.9 Memory..............................................................................................................................................36
3.9.1 SRAM.........................................................................................................................................36
3.9.2 Flash Memory.............................................................................................................................36
3.9.3 Serial Flash.................................................................................................................................36
3.9.4 NAND Flash...............................................................................................................................37
Chapter 4. Software 39
4.1 Running Dynamic C...........................................................................................................................39
4.1.1 Upgrading Dynamic C................................................................................................................41
4.2 Sample Programs................................................................................................................................42
4.2.1 General BL2600 Sample Programs............................................................................................ 42
4.2.2 Digital I/O...................................................................................................................................42
4.2.3 Serial Communication................................................................................................................43
4.2.4 A/D Converter Inputs.................................................................................................................44
4.2.5 D/A Converter Outputs...............................................................................................................45
4.2.6 Use of BL2600 with SF1000 Serial Flash Card......................................................................... 46
4.2.7 Use of NAND Flash ...................................................................................................................46
4.2.8 Real-Time Clock ........................................................................................................................47
4.2.9 TCP/IP Sample Programs...........................................................................................................47
4.3 BL2600 Libraries ...............................................................................................................................47
4.4 BL2600 Function Calls ......................................................................................................................48
4.4.1 Board Initialization.....................................................................................................................48
4.4.2 Digital I/O...................................................................................................................................49
4.4.3 Serial Communication................................................................................................................57
4.4.4 A/D Converter Inputs.................................................................................................................59
4.4.5 D/A Converter Outputs...............................................................................................................66
4.4.6 SRAM Use..................................................................................................................................70
4.4.7 NAND Flash Drivers..................................................................................................................70
Chapter 5. Using the TCP/IP Features 71
5.1 TCP/IP Connections...........................................................................................................................71
5.2 TCP/IP Sample Programs...................................................................................................................73
5.2.1 How to Set IP Addresses in the Sample Programs.....................................................................73
5.2.2 How to Set Up your Computer’s IP Address for a Direct Connection ......................................74
5.2.3 Run the PINGME.C Demo......................................................................................................75
5.2.4 Running More Demo Programs With a Direct Connection .......................................................76
5.3 Where Do I Go From Here?...............................................................................................................76
Appendix A. Specifications 77
A.1 Electrical and Mechanical Specifications..........................................................................................78
A.1.1 Exclusion Zone..........................................................................................................................80
A.1.2 Headers......................................................................................................................................81
A.2 Conformal Coating............................................................................................................................82
A.3 Jumper Configurations......................................................................................................................83
A.4 Use of Rabbit 3000 Parallel Ports .....................................................................................................85
Appendix B. Power Supply 87
B.1 Power Supplies..................................................................................................................................87
B.1.1 Power for Analog Circuits.........................................................................................................88
B.2 Batteries and External Battery Connections......................................................................................88
B.2.1 Replacing the Backup Battery ...................................................................................................88
B.3 Power to Peripheral Boards...............................................................................................................89
Appendix C. Demonstration Board 91

User’s Manual
C.1 Connecting Demonstration Board......................................................................................................91
Appendix D. RabbitNet 95
D.1 General RabbitNet Description..........................................................................................................95
D.1.1 RabbitNet Connections ..............................................................................................................95
D.1.2 RabbitNet Peripheral Cards........................................................................................................96
D.2 Physical Implementation....................................................................................................................97
D.2.1 Control and Routing...................................................................................................................97
D.3 Function Calls....................................................................................................................................98
D.3.1 Status Byte ...............................................................................................................................104
Schematics 105
Index 107

SBC BL2600

User’s Manual 1
1. INTRODUCTION
The BL2600 is a high-performance, C-programmable single-
board computer that offers built-in digital and analog I/O com-
bined with Ethernet connectivity in a compact form factor. The
BL2600 is ideal for both discrete manufacturing and process-
control applications.
A Rabbit®3000 microprocessor operating at up to 44.2 MHz
provides fast data processing with 10/100Base-T Ethernet con-
nectivity. Serial flash options support a full directory file struc-
tures to maximize remote access control and programmability.
The I/O can be expanded with RabbitNet peripheral cards.
1.1 BL2600 Description
Throughout this manual, the term BL2600 refers to the complete series of BL2600 single-
board computers unless other production models are referred to specifically.
The BL2600 is an advanced single-board computer that incorporates the powerful Rabbit
3000 microprocessor, flash memory, serial flash options, static RAM, digital I/O ports,
A/D converter inputs, D/A converter outputs, RS-232/RS-485 serial ports, and a
10/100Base-T Ethernet port.
1.2 BL2600 Features
•Rabbit®3000 microprocessor operating at 29.4 MHz or 44.2 MHz.
•Dual-entry IDC through-hole I/O header sockets allow header mounting on either side
of the BL2600 board
•Industry-standard friction-lock connectors for power-supply wiring harness.
•512K static RAM and 512K flash memory standard.
•36 digital I/O: 16 protected digital inputs, 4 high-current digital outputs software-
configurable as sinking or sourcing, and 16 I/O individually software-configurable as
inputs or sinking outputs.
•12 analog channels: eight 11-bit A/D converter inputs, four 12-bit D/A converter 0–10 V
or ±10 V buffered outputs.

2SBC BL2600
•One RJ-45 Ethernet port compliant with IEEE 802.3 standard for 10/100Base-T
Ethernet protocol.
•Up to 5 serial ports:
Three serial ports (2 RS-232 or 1 RS-232 with RTS/CTS, 1 RS-485 or RS-232).
Two RabbitNet™ expansion ports multiplexed from one serial port.
One serial port dedicated to programming/debugging.
•Provision to install optional SF1000 serial flash, other memory options have provision
for removable memory cards.
•Battery-backed real-time clock.
•Watchdog supervisor.
Two BL2600 models are available. Their standard features are summarized in Table 1.
Additional memory and clock speed options are available, and are described in
Section 1.2.2.
The BL2600 consists of a main board with a RabbitCore module. Refer to the RabbitCore
module manuals, available on the Web site, for more information on the RabbitCore mod-
ules, including their schematics.
The BL2600 is programmed over a standard PC serial port through a programming cable
supplied with the Tool Kit, and can also be programed through a USB port with an
RS-232/USB converter, or over an Ethernet with the RabbitLink (both available from Rabbit).
Appendix A provides detailed specifications.
Table 1. BL2600 Models
Feature BL2600 BL2610
Microprocessor Rabbit®3000 running at
44.2 MHz Rabbit®3000 running at 29.4 MHz
Program Execution SRAM 512K —
Data SRAM 256K 512K
Flash Memory 512K
Ethernet Port 10/100Base-T, 3 LEDs —
RabbitCore Module Used RCM3200 RCM3100
Visit the Web site for up-to-date information about additional add-ons and features as
they become available. The Web site also has the latest revision of this user’s manual.

User’s Manual 3
1.2.1 Connector Options
In addition to the standard polarized friction-lock connectors supplied on BL2600 boards,
dual-entry 0.1" IDC sockets can be used to connect to the BL2600 either from the top or
the bottom.
1.2.2 Memory and Clock Speed Options
In addition to the two standard production models of the BL2600, the concept of pairing a
RabbitCore module with the BL2600 “motherboard” allows for additional versions of the
BL2600 to be offered for custom orders involving nominal lead times. These additional
versions and their part numbers are listed below.
Check the Web site or contact your Digi sales representative or authorized distributor for
more information.
Standard polarized friction-lock
terminals, 0.1" pitch
0.1" IDC sockets can accept
header pins from either top or
bottom
Table 2. Additional BL2600 Memory, Clock Speed, and Ethernet Options
Feature 101-0906 101-0907 101-0908 101-1095 101-1096
Clock Speed 29.4 MHz 29.4 MHz 29.4 MHz 44.2 MHz 44.2 MHz
Program Execution SRAM — — — 512K 512K
DataSRAM 512K128K128K512K512K
Flash Memory (program) 512K 256K 256K 512K 512K
NAND Flash Memory
(mass data storage, fixed) — — — 16 Mbytes —
NAND Flash Memory
(mass data storage, removable
memory card) up to 128 Mbytes
Ethernet Port 10/100-compatible
10Base-T interface — 10/100Base-T
RabbitCore Module Used RCM3000 RCM3010 RCM3110 RCM3365 RCM3375

4SBC BL2600
1.3 Development and Evaluation Tools
1.3.1 Tool Kit
A Tool Kit contains the hardware essentials you will need to use your own BL2600 single-
board computer. The items in the Tool Kit and their use are as follows.
•Getting Started instructions.
•Dynamic C CD-ROM, with complete product documentation on disk.
•Programming cable, used to connect your PC serial port to the BL2600.
•Universal AC adapter, 12 V DC, 1 A (includes Canada/Japan/U.S., Australia/N.Z.,
U.K., and European style plugs). If you are using another power supply, it must provide
9 to 36 V DC at 12 W .
•Stand-offs to serve as legs for the BL2600 board during development.
•Demonstration Board with pushbutton switches and LEDs. The Demonstration Board
can be hooked up to the BL2600 to demonstrate the I/O and the TCP/IP capabilities of
the BL2600.
•Wire assembly to connect Demonstration Board to BL2600.
•Connector pins and parts to build your own wire assemblies: 0.1" crimp terminals;
0.156" crimp terminals; 1 × 4, 1 × 10, and 1 × 13 friction-lock connectors.
•Rabbit 3000 Processor Easy Reference poster.
•Registration card.
