RAD Torque Systems MV-RAD 6 User manual

- INNOVATION DRIVEN PERFORMANC
E
USER MANUAL
MV-RAD ELECTRIC SERIES
65 - 8.000 Nm
User manual for:
• MV-RAD 6
• MV-RAD 14
• MV-RAD 21
• MV-RAD 34
• MV-RAD 45
• MV-RAD 60
• MV-RAD 80

Version 1.0 - June 2015
2
User manual MV-RAD
Table of contents
1. Generalinstrucons 3
2. Descriponofthefuncons 3
3. Sengdireconofrotaon 3
4. Sengthetorque 4
4.1 Setting the torque 4
4.2 Torque Check program (option) 4
4.3 User menu 5
5. Operaonofthetorquewrench 5
5.1 Rotating counter clockwise 5
5.2 Rotating clockwise 5
6. Movementofthereaconarm 6
6.1 Installing the reaction arm 6
6.2 Reaction arm height 6
6.3 Reaction arm foot 6
6.4 Reaction point 7
7. Safetyinstrucons 7
8. Errors 8
9. Warranty 8
9.1 New tool warranty 8
9.2 Repaired tool warranty 9
10. Contact 9

Version 1.0 - June 2015
3
User manual MV-RAD
1. Generalinstrucons
2. Descriponofthefuncons
NOTE: Do not use this torque wrench before reading these instructions. If the torque wrench does not
function properly, do not attempt to repair the torque wrench, but contact RAD Torque Systems B.V.
immediately
NOTE: The tool can be used with single-phase alternating current. It is grounded in accordance with
Class II VDE 0740 and CEE 20. The connection may also be provided by non-grounded electrical
outlets. The radio interference suppression meets EC Directive 82/499.
NOTE: Prior to use, check whether the supply voltage matches the operating voltage indicated.
RAD electric torque wrenches are torque-controlled. Correct operation requires the following:
• Impact sockets with locking pin and o-ring
• Proper reaction arm with retaining ring
• These torque wrenches contain metal components that can be dangerous in explosion hazardous
areas.
The torque wrench may only be operated, calibrated or repaired by qualied personnel. The torque
wrench contains rotating objects. The use of this tool by untrained persons may result in serious injuries.
After performing 20,000 joints, the tool must be maintained, including lubrication of the multiplier. You will
receive this message every time you start the tool after reaching 20,000 joints.
1. The torque wrenches of the MV-RAD series are high-capacity, clockwise and counter clockwise
rotating torque wrenches equipped with an automatic torque depending shutdown
2. The torque wrench is calibrated to a so-called medium-hard joint
3. The torque wrench responds to soft and hard joints. This also applies to mutual hard or soft joints
in different materials. Therefore, the torque wrench must be set to the proper value for each joint,
depending on the desired torque. The torque should be determined in advance, using a transducer.
4. To ensure that the tool reaches the pre-set torque, the relevant joint requires an angle of at least 90°
from the start of the tightening until reaching the torque. After reaching the set torque, the torque
wrench will switch off automatically.
5. For joints for which the tool is used to check the joint, the torque wrench will be loaded to maximum
capacity.
6. The torque wrench is not suitable for checking the torque. However, this is possible in combination
with our Smart Socket.
3. Sengdireconofrotaon
Only operate the rotational direction switch when the motor is at standstill, see Figure 1.
Upper position = Tightening
Lower position = Loosening
Centre position = Transportation position, on/off switch
Figure 1

Version 1.0 - June 2015
4
User manual MV-RAD
When the torque wrench is in operation, the reaction arm will move oppositely to the direction of rotation. It
is essential that the reaction arm can react off a solid surface (adjacent to the joint to be tightened).
WARNING: To prevent injury, always make sure that the hands of the user remain out of the range of the
reaction arm when the torque wrench is in operation.
NOTE: To return to the normal program plus angle, enter 09760 in the third step and activate the Norm-
Program by press the “M“ button and return to the torque ready mode.
4. Sengthetorque
4.1 Setting the torque
1. the torque is set via the keypad at the top of the torque wrench
2. the torque value is selected by pressing the centre key “M”
3. the torque can be set using the arrow keys
4. the torque value is conrmed by pressing the centre key “M” once more. This concludes setting the
torque. Now, the angle can be set, if this option is available
5. the angle is now selected. Repeat steps 3 and 4.
4.2 Torque Check program (option)
To select the Torque Check program follow the following steps:
1. press the centre key “M”
2. use the arrow keys to navigate to “password“ and press “M“
3. enter 02699 to enable the Torque Check program and press “M“
4. use the arrow keys to navigate to T-Check-Program and press “M“
5. the Torque Check program is now activated, press “Back” 3 times to get back in the torque ready
mode
When operating this torque wrench:
1. use only suitable and proper impact sockets
2. the handle can be rotated for ease of installation
3. there may be no clearance between the torque wrench and the reaction arm
4. the reaction arm is placed against the reaction point before the trigger is pulled in order to prevent
whipping movements of reaction arm
5. the trigger should be pressed until the torque wrench stops rotating.
340
0
Right
Nm
34
Degrees
Navigate (Down)
Menu key
Unit for angular degrees
Torque unit
Tool model indication
Navigate (Up)
Rotation direction indicator
Torque setting
Angle

Version 1.0 - June 2015
5
User manual MV-RAD
4.3 User menu
Pressing the menu button for more than three seconds will display the user menu. In this menu, the menu
options can be selected using the arrow keys and conrmed with the menu key.
1. Voorselectie (Preset / Vorwahl)
This menu option allows you to select and save up to four torques and/or angles as a shortcut. This
menu option can be selected using the “M” key. The following sub-menu allows you to select or save
a preset. The following sub-menu shows the available settings. The different settings can be selected
using the arrow keys. The selection is conrmed by pressing the menu key. When saving the setting,
the selected value will be overwritten.
2. Onderhoudsteller (Maintenance counter / Wartungszähler)
This option allows you to view the number of joints after the last service interval and schedule the next
service interval.
3. Totaalteller (Cycle counter / Gesamtzähler)
This option displays the total number of joints since the delivery of the tool.
4. Informatie (Information / Informationen)
This option displays the tool information. This information is required for the telephone detection of
errors by RAD Torque Systems B.V.
5. Wachtwoord (Password / Kennwort)
When entering a password, you will enter the following sub-menu. Here, the following options are
available:
• Reset the maintenance counter
• Change the menu language (English or German)
• Change the torque setting unit (Nm or ft/lbs)
• Password: 02699
6. Terug (Back / Zurück)
With this function, you will return to the main menu and one step back in the menu navigation.
5. Operaonofthetorquewrench
5.1 Rotating counter clockwise
1. Connect the tool to the supply voltage. Observe the voltage indicated on the rating plate
2. Fix the reaction arm to the jagged side of the unit and secure it
3. Install the impact socket onto the square drive of the tool and secure it with the lock pin and the o-ring.
Only use proper impact sockets to this end.
4. Place the torque wrench and impact socket onto the nut
5. Preset the counter clockwise direction of rotation on the reverse lever
6. Rotate the reaction arm against a solid reaction point
7. Press the ON-button until the joint is loosened.
5.2 Rotating clockwise
1. Connect the tool to the supply voltage. Observe the voltage indicated on the rating plate
2. Fix the reaction arm to the jagged side of the unit and secure it
3. Install the impact socket onto the square drive of the tool and secure it with the lock pin and the o-ring.
Only use proper impact sockets to this end.
4. Place the torque wrench and impact socket onto the nut
5. Preset the clockwise direction of rotation on the reverse lever
6. Set the torque as specied
7. Rest the reaction arm against a solid reaction point
8. Press the ON-button until the tool switches off automatically.

Version 1.0 - June 2015
6
User manual MV-RAD
Figure 2
Reaction point
Clockwise operation Counter clockwise
operation
6. Movementofthereaconarm
WARNING: In use, this tool must be supported at all times in order to prevent unexpected release in the
event of a fastener or component failure!
6.1 Installing the reaction arm
Ensure the reaction arm and retaining ring are installed securely to hold the reaction arm in place. Make
sure the reaction arm is in contact with a solid reaction point before you operate the tool. When the tool
is in operation the reaction arm rotates in the opposite direction to the output square drive and must be
allowed to rest squarely against a solid object or surface adjacent to the bolt to be tightened, see Figure 2.
NOTE: Improper reaction will void warranty and can cause premature tool failure.
6.2 Reaction arm height
Ensure the height of the socket is even with the height of the reaction arm as seen below in Figure 3A.
The height of the socket cannot be shorter or higher than the height of the reaction arm as seen below in
Figure 3B and 3C.
6.3 Reaction arm foot
Ensure the foot of the reaction arm aligns with the length of the nut as seen in Figure 4A. The length of the
foot cannot be shorter or longer than the nut as seen in Figure 4B and 4C.
Figure 3A Figure 3B Figure 3C
✔✘ ✘
Figure 4A Figure 4B Figure 4C
✔✘ ✘

Version 1.0 - June 2015
7
User manual MV-RAD
6.4 Reaction point
Ensure the reaction arm reacts off the middle of the foot as seen in Figure 5A. Do not react off the heel of
the reaction foot as seen in Figure 5B.
Please contact RAD Torque Systems B.V. or your local RAD authorised distributor for custom reaction
arms.
WARNING: Always keep your hands and other body parts away from the reaction arm when the torque
wrench is in operation, see Figure 5C.
Figure 5A Figure 5B Figure 5C
✔✘ ✘
7. Safetyinstrucons
RAD tools are developed for tightening and loosening threaded fasteners using very large forces. For
your safety and that of others, warning labels and attention labels are prominently attached to the torque
wrench and its accessories.
NOTE: Make sure you observe the directions on the warning labels at all times.
RAD tools have been designed with safety in mind however, as with all tools you must observe all general
workshop safety practices, and specically the following:
1. Before using your new tool, get familiar with all its accessories and how they work
2. Always wear safety goggles when the tool is in operation
3. Make sure the reaction arm is in contact with a solid contact point before you operate the tool
4. Make sure the reaction arm snap ring is securely in place to hold the reaction arm in place.
RAD tools are safe and reliable. Not following precautions and instructions outlined here can result in
injury to you and your fellow workers. RAD Torque Systems B.V. incorporated is not responsible for any
such injury.

Version 1.0 - June 2015
8
User manual MV-RAD
8. Errors
In the case of a malfunction or a message for the user, different messages can be shown on the display.
These messages can be conrmed by pressing the “M” key. If certain errors appear on a regular basis,
please contact RAD Torque Systems, tel. [phone].
ERRORS MEANING SOLUTION
Maintenance schedule / Wartung planen
/ Plan Maint
More than 20,000 joints have been
performed. Carry out the maintenance.
This indication can be conrmed by
pressing the “M” key. After this, the torque
wrench can be used again. If the service
interval is performed by RAD Torque
Systems B.V., the counter will be reset
and the message will not appear until
20,000 joints have been performed.
Fout toerental / Fehler Drehzahl / Impuls
Sensor
The impulse sensor is defect. Contact RAD Torque Systems B.V., tel.
[phone].
Fout Spanning / Fehler Spannung /
Error Voltage
The supply voltage does not correspond
to the specications of the tool.
Check the supply voltage to which the
tool is connected.
The settings in the main menu are
displayed in red after a joint.
The last performed joint was not
tightened according to the setting.
Loosen the joint and repeat the tightening
process. Press the switch of the torque
wrench until it switches off automatically.
The message “Links / Left / Linksauf” is
displayed in red.
Loosening is not possible. The joint that needs to be loosened is
tightened too much. To prevent damage
to the drive mechanism, the tool will
automatically switch off.
9. Warranty
9.1 New tool warranty
Any new tool branded with the RAD name and purchased from RAD Torque Systems B.V., or through one
of its authorized distributors or agents, is warranted to the original purchaser against defects in materials
and workmanship for a period of twelve (12) month from the date of delivery to the end user. This
guarantee is valid until fteen (15) months after the original calibration date.
Furthermore, the warranty conditions determine that no warranty applies if:
1. The defect, wholly or partly, is due to unusual, inappropriate, improper or careless use of the product;
2. The defect, wholly or partly, is due to normal wear and tear or lack of proper maintenance;
3. The defect, wholly or partly, is due to unusual, is due to installation, assembly, modication and / or
repair by the customer or by third parties;
4. The product altered, modied, used or processed is;
5. The product is transferred to a third party;
6. RAD Torque Systems B.V. has obtained the product, wholly or partly, from a third party, and RAD
Torque Systems B.V. cannot claim compensation under warranty;
7. RAD Torque Systems B.V., in manufacturing of the product, has used raw materials, and suchlike on
the instructions of the customer;
8. The product has a small deviation in its quality, nishing, size, composition and suchlike, which is not
unusual in the industry or if the defect was technically unavoidable;
9. The customer has not fullled all obligations under the agreement promptly and correctly towards RAD
Torque Systems B.V.

Version 1.0 - June 2015
9
User manual MV-RAD
9.2 Repaired tool warranty
After the warranty has expired, a three (3) month warranty applies to the original purchaser against
defective in material or workmanship or both from the date of repair.
To qualify for the above mentioned warranties, written notice to RAD Torque Systems B.V. must be
given immediately upon discovery of such defect, at which time, RAD Torque Systems B.V. will issue an
authorisation to return the tool. Freight costs must be paid in advance. When returning a tool, the reaction
arm/s being used with the tool must also be returned.
For the latest warranty terms, please see our sales conditions on our website www.radtorque.nl.
10. Contact
RAD Torque Systems B.V.
Zuidergracht 19
3763 LS Soest
Phone: [phone]
E-mail: [email protected]
Website: www.radtorque.nl

Version 1.0 - June 2015
10
User manual MV-RAD
STEEL CONSTRUCTION
OIL & GAS
WINDPOWER
AEROSPACE
PETROCHEMICAL
COMMERCIAL VEHICLES
OFFSHORE
OFFICIAL RAD DISTRIBUTOR FOR THE BENELUX:
RAD TORQUE SYSTEMS B.V.
ZUIDERGRACHT 19
3763 LS SOEST
THE NETHERLANDS
PHONE: +31 (0)35 - 5882450
E-MAIL: [e-mail]
[e-mail]
[e-mail]
WWW.RADTORQUE.NL
