RADLEY 1239-306 User manual

3042597
OWNER’S MANUAL
3 Year Limited Warranty on tool
2 Year Limited warranty on battery and charger.
JD508320

1
Variable Speed 0–3,000 RPM (no load)
Impact Speed 0–3,000 BPM
Torque 1,400 in/lbs (158 Nm) maximum
Hex Drive Quick release 1/4" (6.35 mm)
Weight 3lbs (1.5kg)
BATTERY AND CHARGER
Battery 20V Max* Li-ion (Maximum charged battery voltage,
measured without load, is 20V with a nominal value
of 18V), 1.5 Ah
Charger Approximately 1 hour, Class 2
Replacement Battery 5350-547 (2Ah)
Replacement Charger
Assembly
5350-013
NEED ASSISTANCE?
Call us on our toll- free customer support line:
1-866-349-8665 (Monday through Friday 9am – 5pm Eastern Standard Time)
•Technical questions
•Replacement parts
•Parts missing from package

1239-306
20V MAX IMPACT DRIVER
2
TBE F CNET
1
 
 
 
 
 
 
 10
 11



 

3
GNRL SFT ANNS
WARNING:




EYE, EAR & LUNG PROTECTION
SYMBOL MEANING
ALWAYS WEAR EYE PROTECTION THAT CONFORMS WITH
CSA Z94.3 or ANSI SAFETY STANDARD Z87.1


Non-compliant eyewear can cause serious injury if broken
during the operation of a power tool.
Use hearing protection, particularly during extended periods of
operation of the tool, or if the operation is noisy.
WEAR A DUST MASK THAT IS DESIGNED TO BE USED WHEN
OPERATING A POWER TOOL IN A DUSTY ENVIRONMENT.




•
•
•





To avoid electrical hazards, fire hazards or damage to the tool,
use proper circuit protection.






1239-306
20V MAX IMPACT DRIVER
4
PWR TO SFT
WORK AREA SAFETY






ELECTRICAL SAFETY















PERSONAL SAFETY
Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the influence of drugs,
alcohol or medication.

Use personal protective equipment. Always wear eye protection. 


Prevent unintentional starting. Ensure the switch is in the o position before
connecting to power source and/or battery pack, picking up or carrying the tool.


Remove any adjusting key or wrench before turning the power tool on. 

Do not overreach. Keep proper footing and balance at all times.


5
Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from moving parts.

If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used.

POWER TOOL USE AND CARE
Do not force the power tool. Use the correct power tool for your application.


Do not use the power tool if the switch does not turn it on and o. 

Disconnect the plug from the power source and/or the battery pack from the power
tool before making any adjustments, changing accessories, or storing power tools.

Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instructions to operate the power tool.

Maintain power tools. Check for misalignment or binding of moving parts, breakage
of parts and any other condition that may aect the power tool’s operation. If damaged,
have the power tool repaired before use. 

Keep cutting tools sharp and clean. 

Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be performed.


Hold power tool by insulated gripping surfaces, because the blade may contact its own
cord. Cutting a "live" wire may make exposed metal parts of the tool "live" and could
give the operator an electric shock.
BATTERY TOOL USE AND CARE
Recharge only with the charger specified by the manufacturer. A charger used
that is suitable for one type of battery pack may create a risk of fire when another
battery pack.
Use power tools only with specifically designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
When battery pack is not in use, keep it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small metal objects that can make a connection
from one terminal to another. 


1239-306
20V MAX IMPACT DRIVER
6
Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, also seek medical
help. 
SERVICE
Have your power tool serviced by a qualified repair person using only identical
replacement parts. 
SEFC SFT US
WARNING: Know your cordless impact driver. Do not plug in the charger or install
the battery in the tool until you have read and understand this Owner's Manual. Learn
the tool’s application and limitations as well as the specific potential hazards related to
this tool. Following this rule will reduce the risk of electric shock, fire, or serious injury.





WARNING: Glasses or goggles not in compliance with ANSI Z87.1
could cause serious injury when they break.



WARNING: 

WARNING: 

WARNING: 


WARNING: 













7















BTE & CAGR SFT
WARNING:












 



NOTE: 





1239-306
20V MAX IMPACT DRIVER
8












BTE PC RCCIG
To preserve our natural resources, please recycle or dispose of
batteries properly.




9
3042597
JD508320
This symbol designates that this tool is listed with Canadian and U.S. requirements
by ETL Testing Laboratories, Inc. Conforms to UL Std. 60745-1, 60745-2-2.
WARNING: Some of the following symbols may appear on the impact driver. Study
these symbols and learn their meaning. Proper interpretation of these symbols will allow for
V Volts 3n
~
Three-phase alternating
current with neutral
A Amperes Direct current
Hz Hertz noNo load speed
W Watts Alternating or direct current
kW Kilowatts Class II construction
Microfarads Splash-proof construction
L Litres Watertight construction
kg Kilograms Protective grounding at
terminal, Class I tools
H Hours .../min Revolutions or reciprocations
per minute
N/cm² Newtons per square
centimetre Diameter
Pa Pascals 0
OPM Oscillation per minute Directional Arrow
Min Minutes Warning symbol
S Seconds Wear your safety glasses
~or AC Alternating current Wear a dust mask
3 ~
Three-phase alternating
current Wear hearing protection

1239-306
20V MAX IMPACT DRIVER
10
1. Quick Release Chuck
2. LED Work Light
3. Trigger Switch
4. Battery Release Button
5. Battery 5350-547
6. Forward/Reverse Switch
7 Air Vents
8. Battery Charger DL125418
9. Air Vents
10. Air Vents
11. Red LED
12. Green LED
8
12 11 10
9
1
2
3
4
5
6
7

11
ASML AD ETO
CHECKING THE BATTERY CHARGER STATUS


NOTE: The battery charge remaining may be checked while the battery is installed
in the tool with the ON/OFF switch turned OFF. It may also be checked while the
battery is removed from the tool. DO NOT check the battery charge remaining while
the battery is in the charger. You will get a false reading and you may also damage
the battery status system.
 





    
 
CHARGING THE BATTERY PACK
 


NOTE: 



NOTE:


1239-306
20V MAX IMPACT DRIVER
12
NOTES:
1. When the charger is plugged into the wall receptacle and NO battery is on the
charger, the green indicator light (5) will turn ON indicating the charger is “live”.
2. When a discharged battery is installed on the charger, the green indicator light will
turn OFF and the red indicator light (6) will turn ON. The red indicator light indicates
the battery is being charged.
3. If the red indicator light does not come ON, check to make sure battery pack is slid
fully onto the charger and the electrical outlet is working properly.
4. See Fig. 2 below for other indicator light functions.
5. A discharged battery pack should be fully charged in 60 minutes.
6. It is normal for the battery charger to hum and be warm to the touch during operation.
7. If the battery pack does not charge properly, check to make sure the electrical outlet
is “live”.
8. Do NOT charge batteries when the work area or the battery temperature is at or below
41°F/5°C or above 105°F / 40.5° C.
GREEN
LIGHT
RED
LIGHT
BATTERY
INSERTED
INTO
CHARGER
CHARGING STATUS
ON OFF NO Charger connected
to power supply
OFF ON YES Battery being charged
ON OFF YES Battery fully charged
OFF ON YES Battery is charged
but not operational
on tool. This may
indicate defective /
bad contact on battery
or charging conditions
are either too hot or
too cold.
Fig. 1 Fig. 2

13
INSTALLING A BATTERY IN THE IMPACT DRIVER





NOTE:

1




WARNING:

INSTALLING SCREWDRIVER BITS AND SOCKETS
WARNING:


WARNING:



WARNING:





1239-306
20V MAX IMPACT DRIVER
14
NOTES:








FORWARD/REVERSE SWITCH




NOTES:



VARIABLE SPEED TRIGGER SWITCH






NOTE:


1





15
LED WORK LIGHT




WARNING: For safety reasons, the operator must read the sections of this
Owner’s Manual entitled "GENERAL SAFETY WARNINGS", "POWER TOOL SAFETY",
"SPECIFIC SAFETY RULES", "BATTERY & CHARGER SAFETY" and "SYMBOLS"
before using this impact driver.
Verify the following every time the cordless driver is used:
1. Safety glasses, safety goggles, or face shield is being worn.
2. Hearing protection is being worn.
3. The screwdriver bit is single ended and has the ANSI groove on one end.
4. The screwdriver bit is correctly installed and locked into the collet.
5. The bit is in good condition, and is fully inserted into the bit holder.
Failure to observe these safety rules will significantly increase the risk of injury.
PREPARING SCREW HOLES







1239-306
20V MAX IMPACT DRIVER
16


NOTE: 






DRIVING SCREWS












NOTE:






NOTE:

17



NOTE: 
This impact driver may be used with nut drivers and impact sockets. Although these
accessories are NOT included with this tool, they may be purchased separately.
WARNING: Nut drivers, socket adaptor and sockets MUST be impact rated and
include the ANSI locking groove.
INSTALLING NUT DRIVERS FOR 3/16" TO 3/8" NUTS


NOTE:
 
1
INSTALLING IMPACT SOCKETS FOR 7/16" TO 3/4" NUTS



NOTE:
1



1239-306
20V MAX IMPACT DRIVER
18
REMOVING NUTS





NOTE: 




WARNING: 


MITNNE
GENERAL
WARNING: 




WARNING: 






LUBRICATION



LITHIUMION BATTERY PERFORMANCE


• 
• 
• 
• 



19



LITHIUMION BATTERY MAINTENANCE





NOTE:
BATTERY PACK REMOVAL AND PREPARATION FOR RECYCLING






WARNING: If the battery pack has been removed from the tool, cover the terminals
of the battery pack with electrical tape or heavy-duty adhesive tape. Never touch
both terminals with metal objects or body parts, because a short circuit may result.
Keep away from children. Do not attempt to destroy or disassemble battery pack or
remove any of its components. Rechargeable batteries must be recycled or disposed of
properly. Failure to comply with these warnings could result in fire and serious injury.
WARNING: When servicing, use only original equipment replacement parts. The use
of any other parts may create a safety hazard or cause damage to the tool. Any attempt
to repair or replace electrical parts on this tool may create a safety hazard unless repairs
are performed by a qualified technician. For more information, call the Toll-free helpline
at 18663498665. Always order by part number, not by key number.
