The SCOPIA Elite 5230 Platform Guide provides information on the
SCOPIA Elite 5230 platform and its components. For information and operating
procedures pertaining to a specific element board or application, refer to the
corresponding manual provided with the product.
RELATED
DOCUMENTATION The SCOPIA Elite 5230 platform documentation set is available on the
RADVISION Utilities and Documentation CD-ROM supplied with the product
and includes manuals in PDF format.
Note You require Adobe Acrobat Reader version 6.0 or later to open the PDF
files. You can download Acrobat Reader free of charge from www.adobe.com.
FEEDBACK The team at RADVISION constantly endeavors to provide accurate and
informative documentation. If you have comments or suggestions regarding
improvements to future publications, we would value your feedback.
We thank you for your contribution.
vi SCOPIA Elite 5230 Platform Guide
SCOPIA Elite 5230 Platform Overview 1
1
SCOPIA ELITE 5230 PLATFORM
OVERVIEW
The SCOPIA Elite 5230 platform is a high performance, multi-functional chassis
that supports mix-and-match functionality. This highly configurable and scalable
design provides maximum flexibility for configuring platforms to meet a wide
variety of functional and performance application requirements.
The SCOPIA Elite 5230 platform includes these components:
The SCOPIA Elite 5200 chassis
Two SCOPIA Elite 5000 Media Blades
A SCOPIA Elite Shelf Manager
We describe each component in these sections:
SCOPIA Elite 5200 Chassis on page 1
SCOPIA Elite 5000 Media Blade Panel Features on page 4
Shelf Manager on page 5
SCOPIA ELITE
5200 CHASSIS
SCOPIA Elite 5200 Chassis Main Features on page 2
Front and Rear Views of the of the SCOPIA Elite 5200 Chassis on page 3
1
2 SCOPIA Elite 5230 Platform Guide
SCOPIA Elite 5200 Chassis
SCOPIAELITE 5200
CHASSIS MAIN
FEATURES
The SCOPIA Elite 5200 chassis is a 3U chassis which can hold two RADVISION
SCOPIA Elite MCU Media Blades and a shelf manager.
The upper MCU functions as the master blade, providing the single management
interface and controlling both blades in the chassis. The LAN connection is via
the upper blade. The lower MCU functions as the slave.
Table 1-1 Chassis Main Features
Field replaceable units (FRUs) All boards, Power Supply Units and fan
drawers are field replaceable units
Hot swap All FRUs are hot-swappable—removing or
replacing an FRU (except a Power Supply
Unit) does not affect the operation of other
FRUs.
Grounding and electrostatic discharge The chassis includes an external
GND 4mm stud as per the TUV
requirement).
The chassis includes 4mm
banana jacks for a 4.5mm plug or
a standard 0.166" plug, as per the
PICMG 3.0 specification.
Cooling The chassis supports a single failed fan in
the fan tray.
Power supply Default AC power supply as the
default choice.
Universal 90-264 VAC power
ports.AC power entry includes
regular IEC320-C14 filtered AC
inlet and double pole switch
located in the rear.
Thermal shutdown if the unit
heats up beyond its limits.
SCOPIA Elite 5230 Platform Overview 3
SCOPIA Elite 5200 Chassis
FRONT AND REAR
VIEWS OF THE OF THE
SCOPIAELITE 5200
CHASSIS Figure 1-1 Chassis Front Panel
Figure 1-2 Chassis Rear Panel
STATUS
STATUS
RESET
HOT SWAP
RESET
HOT SWAP
PWR ALARM
STATUS
FAN ALARM-R
FAN ALARM-L
MEDIA BLADE
MEDIA BLADE
CONTROL BLADE
Elite 5200
4 SCOPIA Elite 5230 Platform Guide
SCOPIA Elite 5000 Media Blade Panel Features
SCOPIA ELITE
5000MEDIABLADE
PANEL FEATURES
Figure 1-3 Media Blade Front Panel
Table 1-2 Media Blade Panel Features
STATUS
RESET
HOT SWAP
MEDIA BLADE
521 6
4
3
Component Description
1 STATUS LED Lights green to indicate normal operation. Lights red to
indicate that an error has occurred and that the Media
Blade requires resetting.
2 Serial connector A DB-9 connector that allows you to connect a PC
terminal for local configuration, maintenance and
debugging.
3 100/1000 BASE-T
Ethernet connectors RJ-45 connectors that provide the primary LAN
connection for the IP network port.
4 Ethernet connector
Link/Activity LEDs The top part of each Ethernet connector contains two LED
indicators. The right LED lights green when the local IP
network link is active. The left LED lights green if the
connection speed reaches 1000 Mbps, and lights orange if
the connection speed reaches 100 Mbps.
5 RESET button Allows you to reset the Media Blade manually.
6 HOT SWAP LED Lights blue when the latches of the board are unlocked and
it is safe to remove the board from the chassis, and during
reset. Goes off when the board is completely detached.
SCOPIA Elite 5230 Platform Overview 5
Shelf Manager
SHELF MANAGER Shelf Manager Main Features on page 5
Shelf Manager Panel Features on page 5
SHELF MANAGER
MAIN FEATURES The shelf manager administers the chassis and its component power supply units,
fans and boards.
Shelf manager functionality includes:
Monitoring chassis temperature
Controlling fan speed
Providing alarm indications to the upper Media Blade over the Ethernet
via the SCOPIA Elite 5230 chassis backplane
SHELF MANAGER
PANEL FEATURES
Figure 1-4 Shelf Manager Front Panel
Table 1-3 Shelf Manager Panel Features
PWR ALARM
STATUS
FAN ALARM-R
FAN ALARM-L CONTROL BLADE
Component Description
STATUS LED Lights green to indicate normal operation.
FAN ALARM - L LED Lights red if the tacho-speed in one or more
fans in the left fan tray falls below
900 rpm.
FAN ALARM - R LED Lights red if the tacho-speed in one or more
fans in the right fan tray falls below
900 rpm.
PWR ALARM LED Lights red if there is a failure in one of the
AC power supplies.
6 SCOPIA Elite 5230 Platform Guide
Shelf Manager
Cable Connections and Pin-outs 7
2
CABLE CONNECTIONS AND PIN-OUTS
9-Pin Serial Port Terminal Cable on page 7
RJ-45 8-Pin IP Network Port on page 8
9-PIN SERIAL PORT
TERMINAL CABLE Table 2-1 describes the pin-to-pin configuration of the RS-232 terminal cable
provided with the SCOPIA Elite 5230.
Table 2-1 RS-232 9-pin D-Type Serial Port Pin-out
Pin Function I/O
1NC
2 RXD Input
3 TXD Output
4NC
5 GND
6NC
7NC
8NC
9NC
2
8 SCOPIA Elite 5230 Platform Guide
RJ-45 8-Pin IP Network Port
RJ-45 8-PIN IP
NETWORK PORT
100 Mbps Ethernet on page 8
1 Gbps Ethernet on page 8
100 MBPS ETHERNET Table 2-2 describes the pin-out configuration of the 100 Mbps RJ-45 Ethernet
connector.
Table 2-2 Pin-out Configuration of the 100 Mbps RJ-45 IP Ethernet
Connector
1 GBPS ETHERNET Table 2-2 describes the pin-out configuration of the 1 Gbps RJ-45 Ethernet
connector.
Table 2-3 Pin-out Configuration of the 1 Gbps RJ-45 IP Ethernet
Connector
Pin Function I/O
1 TXD+ Output
2 TXD+ Output
3 RXD+ Input
4NC
5NC
6 RXD- Input
7NC
8NC
Pin Name Function I/O
1 BI_DA+ Bi-directional pair A + I/O
2 BI_DA- Bi-directional pair A - I/O
3 BI_DB+ Bi-directional pair B + I/O
4 BI_DC+ Bi-directional pair C + I/O
Cable Connections and Pin-outs 9
RJ-45 8-Pin IP Network Port
5 BI_DC- Bi-directional pair C - I/O
6 BI_DB- Bi-directional pair B - I/O
7 BI_DD+ Bi-directional pair D + I/O
8 BI_DD- Bi-directional pair D - I/O
Pin Name Function I/O
10 SCOPIA Elite 5230 Platform Guide
RJ-45 8-Pin IP Network Port
Safety 11
1
SAFETY
This section describes safety procedures and requirements for operating the
SCOPIA Elite 5230 platform.
Installation Safety on page 11
Electrical Safety on page 12
Operation Safety on page 13
INSTALLATION
SAFETY Read the installation instructions before connecting the system to the power
source.
To avoid an electric shock or damage to the SCOPIA Elite 5230 platform,
servicing should be performed by qualified service personnel only.
Do not operate without covers. To avoid electric shock or fire hazard, do not
operate this product with any removed enclosure covers or panels.
To avoid the risk of electric shock do not operate in wet, damp, or condensing
conditions.
To avoid electrical hazards (heat shock and/or fire hazard), do not make
connections to terminals outside the range specified for that terminal. See the
Cable Connections and Pin-outs chapter for correct connections.
To avoid the risk of electric shock, always make connections to a grounded main
when supplying power to the system. Do not operate in wet, damp, or condensing
conditions.
1
12 SCOPIA Elite 5230 Platform Guide
Electrical Safety
ELECTRICAL
SAFETY To reduce the risk of damaging power surges, RADVISION recommends installing
an AC surge arrestor in the AC outlet from which the SCOPIA Elite 5230
platform is powered.
A readily accessible listed branch circuit over current protective device rated
20 A must be incorporated in the building wiring.
Grounding on page 12
Power Supply on page 13
ESD Procedures on page 13
GROUNDING This SCOPIA Elite 5230 platform must be grounded. Contact the appropriate
electrical inspection authority or an electrician if you are uncertain that suitable
grounding is available.
The SCOPIA Elite 5230 platform can become dangerous if you interrupt any of
the protective conductors (grounding) or disconnect any of the protective earth
terminals.
The SCOPIA Elite 5230 platform must be installed according to the latest
version of the country national electrical codes. For North America, equipment
must be installed in accordance to the applicable requirements in the US National
Electrical Code and the Canadian Electrical Code.
The power cable of the SCOPIA Elite 5230 platform should only be connected to
a power outlet that has a protective earth contact. Do not use an extension cord
that does not have a protective conductor (ground).
Caution For North American installations, select a 3-conductor (18 AWG)
power supply cord that is UL listed and CSA certified. The cord must be
terminated in a molded-on plug cap rated 125V/5A, with a minimum length of
1.5m (6 feet) and no longer than 4.5m (approximately 14 feet).
Caution This is a class I unit. In Denmark, use this unit with an AC cord suited
to Danish specifications. The cord should include an earthing conductor. Plug the
unit into a wall socket outlet which is connected to the protective earth contact. Do
not use socket outlets which are not connected to a protective earth contact!
Varoitus Laite on liitettävä suojamaadoituskoskettimilla varustettuun
pistorasiaan.
Safety 13
Operation Safety
Advarsel Apparatet må tilkoples jordet stikkontakt.
Varning Apparaten skall anslutas till jordat uttag.
POWER SUPPLY Caution Risk of electric shock and energy hazard. This unit might have more
than one power supply connection. All connections must be removed to
de-energize the unit.
ESD PROCEDURES To prevent damage to RADVISION element boards by random electrostatic
discharge (ESD), the use of wrist straps is highly recommended.
OPERATION
SAFETY Warning To prevent the SCOPIA Elite 5230 platform from overheating, do not
operate it in an area that exceeds the maximum recommended ambient
temperature of 113°F (45°C). To prevent airflow restriction, allow at least
3 inches (7.6 cm) of clearance around the ventilation openings.
Microprocessor heatsinks may become hot during normal operation. To avoid
burns, do not allow anything to touch processor heatsinks.
When removing the fan tray, keep your hands and fingers away from the
spinning fan blades. Let the fan blades completely stop before you remove the
fan tray.
Warning There is a danger of explosion if the ATCA board battery is incorrectly
replaced. Replace with the same type, or an equivalent type recommended by the
manufacturer. Dispose of used batteries only according to manufacturer
instructions.
Ultimate disposal of this product should be handled according to all national laws
and regulations.
Cables for connecting to the unit RS-232 and Ethernet interfaces must be UL
certified type DP-1 or DP-2 (when residing in a non-LPS circuit).
14 SCOPIA Elite 5230 Platform Guide
Operation Safety
This manual suits for next models
2
Table of contents
