Rainforest Automation RAVEn User manual

www.rainforestautomation.com
RAVEn™
Radio Adaptor for Viewing Energy
XML API Manual
Version 1.27
March 2013

Rainforest Automation,Inc.
RAVEn™ ™
XML API Manual
2
Copyright © 2013 by RAINFOREST AUTOMATION, INC (“RFA”). All rights reserved.
No part of this manual may be reproduced or transmitted in any from without the expressed, written
permission of RFA.
Under copyright law, this manual or the software described within, cannot be copied, in whole or part,
without the written consent of the manufacturer, except in the normal use of the software to make a
backup copy. The same proprietary and copyright notices must be affixed to any permitted copies as
were affixed to the original. This exception does not allow copies to be made for others, whether or not
sold, but all of the material purchased (with all backup copies) can be sold, given, or loaned to another
person. Under the law, copying includes translating into another language or format.
Rainforest Automation may have patents, patent applications, trademarks, copyrights, or other intellectual
property rights covering subject matter in this document. Except as expressly provided in any written
license agreement from Rainforest Automation, the furnishing of this document does not give you any
license to these patents, trademarks, copyrights, or other intellectual property.
Trademarks
Third-party brands and company Names mentioned herein may be trademarks and/or
registered trademarks of their respective companies and are the sole property of their
respective manufacturers.
Notice
The author(s) assumes no responsibility for any errors or omissions that may appear in this document nor
does it make a commitment to update the information contained herein.

Rainforest Automation,Inc.
RAVEn™
XML API Manual
3
RAVEn™ – Radio Adapter for Viewing Energy
RFA-Z106
Version 1.27
XML API Manual
Table of Contents
OVERVIEW...................................................................................................................... 5!
RAVEn™ XML API ...................................................................................................... 5!
Communications Model................................................................................................ 5!
Data Structures ............................................................................................................ 6!
Features ....................................................................................................................... 8!
FEATURES...................................................................................................................... 9!
RAVEn™ Feature ........................................................................................................ 9!
1.!Command: INITIALIZE ........................................................................ 9!
2.!Command: RESTART ......................................................................... 9!
3.!Command: FACTORY_RESET ........................................................... 9!
4.!Command: GET_CONNECTION_STATUS ...................................... 10!
5.!Notify: ConnectionStatus ................................................................... 10!
6.!Command: GET_DEVICE_INFO....................................................... 11!
7.!Notify: DeviceInfo............................................................................... 11!
8.!Command: GET_SCHEDULE ........................................................... 11!
9.!Notify: ScheduleInfo........................................................................... 12!
10.!Command: SET_SCHEDULE.......................................................... 12!
11.!Command: SET_SCHEDULE_DEFAULT ....................................... 13!
12.!Command: GET_METER_LIST....................................................... 13!
13.!Notify: MeterList............................................................................... 13!
Meter Feature............................................................................................................. 14!
1.!Command: GET_METER_INFO........................................................ 14!
2.!Notify: MeterInfo ................................................................................ 14!
3.!Command: GET_NETWORK_INFO.................................................. 15!
4.!Notify: NetworkInfo ............................................................................ 15!
5.!Command: SET_METER_INFO ........................................................ 16!
Time Feature .............................................................................................................. 17!
1.!Command: GET_TIME ...................................................................... 17!
2.!Notify: TimeCluster ............................................................................ 17!
Message Feature ....................................................................................................... 18!
1.!Command: GET_MESSAGE ............................................................. 18!
2.!Notify: MessageCluster...................................................................... 18!

Rainforest Automation,Inc.
RAVEn™
XML API Manual
4
3.!Command: CONFIRM_MESSAGE.................................................... 19!
Price Feature.............................................................................................................. 20!
1.!Command: GET_CURRENT_PRICE ................................................ 20!
2.!Command: SET_CURRENT_PRICE................................................. 20!
3.!Notify: PriceCluster ............................................................................ 21!
Simple Metering Feature ............................................................................................ 22!
1.!Command: GET_INSTANTANEOUS_DEMAND............................... 23!
2.!Notify: InstantaneousDemand ........................................................... 23!
3.!Command: GET_CURRENT_SUMMATION_DELIVERED............... 24!
4.!Notify: CurrentSummationDelivered .................................................. 24!
5.!Command: GET_CURRENT_PERIOD_USAGE............................... 25!
6.!Notify: CurrentPeriodUsage............................................................... 25!
7.!Command: GET_LAST_PERIOD_USAGE ....................................... 26!
8.!Notify: LastPeriodUsage .................................................................... 27!
9.!Command: CLOSE_CURRENT_PERIOD......................................... 27!
10.!Command: SET_FAST_POLL......................................................... 28!
11.!Command: GET_PROFILE_DATA.................................................. 28!
12.!Notify: ProfileData............................................................................ 29!

Rainforest Automation,Inc.
RAVEn™
XML API Manual
5
OVERVIEW
RAVEn™ XML API
The RAVEn™ is a USB device that communicates with a smart meter over a secured ZigBee
wireless network. The RAVEn™ is an endpoint on the network that is authorized and
authenticated to communicate with the smart meter. The XML (eXtensible Markup Language)
API (Application Programming Interface) described in this document provides a mechanism to
allow external applications to receive smart meter data from the RAVEn™.
Communications Model
The RAVEn™ is a USB device; the USB port is mapped to a virtual serial port, which shows up
as a standard COM port. Applications that can connect to a COM port can also connect to the
RAVEn™. The RAVEn™ sends and receives data as a serial stream. The RAVEn™ uses an 8
bit Extended ASCII character set (code page 1252) to encode the data. This may change in the
future in order to support UTF-8.
Settings for the virtual serial COM port:
•PORT NAME: determined by OS
•BAUD RATE: 115,200
•DATA BITS: 8
•PARITY: N
•STOP BITS: 1
The RAVEn™ uses an asynchronous serial communications model. This means that the
transmit and receive data streams are independent; the RAVEn™ can be sending and receiving
data at the same time. The RAVEn™ does not use hand shaking, acknowledgements, or time
synchronization.
The RAVEn™ is also a ZigBee device. It is ZigBee Smart Energy 1.0 compliant, and is certified
by the ZigBee Alliance to operate according to that standard. Therefore, the XML API options
are restricted to what is allowed by the ZigBee Smart Energy 1.0 standard. The RAVEn™ must
be authorized and authenticated by the ZigBee Coordinator before the RAVEn™ can
communicate with the smart meter. Generally, the smart meter is also the ZigBee Coordinator.
The RAVEn™ is authorized by the owner of the smart meter (i.e. the electric utility); the owner
needs the MAC ID and Install Code for the RAVEn™ in order to set up the authorization.

Rainforest Automation,Inc.
RAVEn™
XML API Manual
6
Data Structures
The RAVEn™ sends and receives data as a serial stream. The data is structured as XML
Fragments. An XML Fragment is a stripped down XML Element. The RAVEn™ uses XML
Fragments to simplify the parsing of the data stream, while providing a data structure that is
flexible and human readable.
The rules for XML Fragments are:
1. XML Fragments are transmitted as a stream; there are no BOF or EOF markers.
2. An XML Fragment is a well formed XML Element.
3. XML Elements do not have XML Attributes.
4. Only the root XML Element has child XML Elements.
5. There is no XML Declaration Section.
6. There are no XML Name spaces.
The RAVEn™ receives commands and sends notifications. A command is a request to the
RAVEn™ to do something. The RAVEn™ will execute the command, which will trigger an
event. RAVEn™ events send out notifications that contain information about the event.
For example:
1. Send a GET_CURRENT_PRICE command, which causes the RAVEn™ to request the
current price stored in the meter;
2. RAVEn™ returns a PriceCluster notification with the current price received from the
meter.
The RAVEn™ will also send notifications when events are triggered by something other than a
command. For instance, when the RAVEn™ receives a new text message from the smart
meter, the RAVEn™ will send a MessageCluster notification. This is why the communications
model is asynchronous; the RAVEn™ sends notifications whenever an event occurs, in addition
to when a command is received.
The format of an XML Fragment is
<tag>
[<string>text</string>]
[<hex>0xFFEEDDCCBBAA99887766554433221100</hex>]
[<int>-987654321</int>]
[<decimal>-7654321.12345</decimal>]
[<![CDATA[binary]]>]
[<enumeration>{A|B|C}</enumeration>]
</tag>
Where:
- <tag> is the tag for the root XML Element
- <string>is the start tag for an element with Extended ASCII string
- <hex> is the start tag for an element with a hexadecimal data
- <int> is the start tag for an element with a signed 32bit integer

Rainforest Automation,Inc.
RAVEn™
XML API Manual
7
- <decimal> is the start tag for an element with a signed decimal(12.5)
- <base64>is the start tag for an element with Base64 data
- <![CDATA[binary]]> is the tag for a CDATA section
- binary is the binary content of the CDATA section
- [ ] brackets indicate optional elements
- <enumeration>is the start tag for an element that can have a specific list of
values.
- {A|B|C} are the different options for the element value
- [<Element> | <Element>] are the different optional elements
- Element names are case insensitive; the case is used strictly for legibility
RAVEN™ receives commands with the following XML Fragment structure:
<Command>
<Name>text</Name>
…
</Command>
Where:
- <Command> is the start tag for the command XML Fragment
- <Name> is the start tag for the name of the command
- …indicates the variable number of command specific parameters
RAVEN™ sends notifications with the following XML Fragment structure:
<tag>
<element>value</element>
…
</tag>
Where:
- <tag> is the start tag for the XML Fragment; each notification will have a unique
tag name;
- <element> is the start tag for an element; there will be one or more child
elements in the fragment; each notification element will have a unique element
name.
- …indicates the variable number of notification specific elements
The first element of every notification is always the MAC ID of the RAVEn™ that generated the
notification.
Note: the RAVEn™ does not send or require the MAC ID of the meter when in single meter
operation. This may change in the future. For multiple meters, the meter MAC ID will always be
required.

Rainforest Automation,Inc.
RAVEn™
XML API Manual
8
Features
RAVEN™ XML Fragments are loosely organized as Features, where each Feature is a logical
grouping of notifications and commands.
The API is organized into these Features:
Feature
Description
RAVEn™
RAVEn™ device specific information
Meter
Meter specific information
Time
Time and Date information
Message
Text Message information
Price
Price information
Simple Metering
Metering data information
Firmware Update
Firmware upgrade procedure

Rainforest Automation,Inc.
RAVEn™
XML API Manual
9
FEATURES
RAVEn™ Feature
The RAVEn™ Feature provides the commands and notifications for managing the configuration
of the RAVEn™ and diagnosing the communications to the smart meter.
Key commands and notifications include:
•Start up, joining, and connectivity status notifications
•Restarting the RAVEn™ (Soft Reboot)
•Resetting the RAVEn™ (Factory Reset, will Decommission device)
•Get revision information for RAVEn™
•Configuring the scheduler on the RAVEn™
1. Command: INITIALIZE
Send the INITIALIZE command to have the RAVEn™ reinitialize the XML parser. Use this
command when first connecting to the RAVEn™ prior to sending any other commands. While
initialization is not required, it will speed up the initial connection.
<Command>
<Name>initialize</Name>
</Command>
2. Command: RESTART
Send the RESTART command to have the RAVEn™ go through the start-up sequence. This
command is useful for capturing any diagnostic information sent during the start-up sequence.
<Command>
<Name>restart</Name>
</Command>
3. Command: FACTORY_RESET
Send the FACTORY_RESET command to decommission the RAVEn™. This command erases
the commissioning data and forces a restart. On restart, the RAVEn™ will begin the
commissioning cycle.
<Command>
<Name>factory_reset</Name>
</Command>

Rainforest Automation,Inc.
RAVEn™
XML API Manual
10
4. Command: GET_CONNECTION_STATUS
Send the GET_CONNECTION_STATUS command to get the RAVEn™ connection information.
The RAVEn™ will send a ConnectionStatus notification in response.
<Command>
<Name>get_connection_status</Name>
</Command>
5. Notify: ConnectionStatus
The RAVEn™ will send notifications during the start-up sequence and during the join/re-join
sequence. These notifications are useful for diagnostic purposes.
<ConnectionStatus>
<DeviceMacId>0xFFFFFFFFFFFFFFFF</DeviceMacId>
<MeterMacId>0xFFFFFFFFFFFFFFFF</MeterMacId>
<Status>{enumeration}</Status>
[<Description>{string}</Description>]
[<StatusCode>0xFF</StatusCode>]
[<ExtPanId>0xFFFFFFFFFFFFFFFF</ExtPanId>]
[<Channel>00</Channel>]
[<ShortAddr>0xFFFF</ShortAddr>]
<LinkStrength>0xFF</LinkStrength>
</ConnectionStatus>
Element
Range
Description
DeviceMacId
0xFFFFFFFFFFFFFFFF
Unique MAC Address of the RAVEn™
MeterMacId
0xFFFFFFFFFFFFFFFF
Unique MAC Address of meter
Status
Initializing | Network
Discovery | Joining | Join:
Fail | Join: Success |
Authenticating |
Authenticating: Success |
Authenticating: Fail |
Connected | Disconnected |
Rejoining
Indicates the current state of the device
Description
Text; Optional
Gives a description of the device state
StatusCode
0x00 – 0xFF; Optional
If available, provides a status code for the
current state
ExtPanId
0x0 -
0xFFFFFFFFFFFFFFFF;
Optional
Provides the extended PAN ID of the
network the device is trying to join or has
joined
Channel
11 – 26; Optional
Indicates the channel on which the device is
operating
ShortAddr
0x0000 – 0xFFFF; Optional
The short address assigned to the
RAVEn™ by the network coordinator
LinkStrength
0x00 – 0x64
Indicates the strength of the link

Rainforest Automation,Inc.
RAVEn™
XML API Manual
11
6. Command: GET_DEVICE_INFO
Send the GET_DEVICE_INFO command to get the RAVEn™ configuration information. The
RAVEn™ will send a DeviceInfo notification in response.
<Command>
<Name>get_device_info</Name>
</Command>
7. Notify: DeviceInfo
DeviceInfo notifications provide some basic information about the RAVEn™.
<DeviceInfo>
<DeviceMacId>0xFFFFFFFFFFFFFFFF</DeviceMacId>
<InstallCode>0xFFFFFFFFFFFFFFFF</InstallCode>
<LinkKey>0xFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF</LinkKey>
<FWVersion>{string}</FWVersion>
<HWVersion>{string}</HWVersion>
<ImageType>{string}</ImageType>
<Manufacturer>{string}</Manufacturer>
<ModelId>{string}</ModelId>
<DateCode>{string}</DateCode>
</DeviceInfo>
Element
Range
Description
DeviceMacId
0xFFFFFFFFFFFFFFFF
Unique MAC Address of
the RAVEn™
InstallCode
0xFFFFFFFFFFFFFFFF
Install Code
LinkKey
0xFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF
Link Key
FWVersion
Text
Firmware Version
HWVersion
Text
Hardware Version
ImageType
Text
Firmware Image Detail
Manufacturer
Text
“Rainforest Automation”
ModelId
Text
“RFA-Z106”
DateCode
YYYYMMDDZZZZZZZZ
Manufacturer’s date code
and lot number
8. Command: GET_SCHEDULE
Send the GET_SCHEDULE command to get the RAVEn™ scheduler information. The
RAVEn™ will send the ScheduleInfo notification in response; or, RAVEn™ will send a series of
ScheduleInfo notifications if the Event field is omitted.
<Command>
<Name>get_schedule</Name>
[<MeterMacId>0xFFFFFFFFFFFFFFFF</MeterMacId>]
[<Event>{enumeration}</Event>]
</Command>
Element
Range
Description

Rainforest Automation,Inc.
RAVEn™
XML API Manual
12
MeterMacId
0xFFFFFFFFFFFFFFFF;
Optional if only one meter
Unique MAC Address of meter
Event
time | price | demand |
summation | message
The type of event being scheduled
9. Notify: ScheduleInfo
ScheduleInfo notifications provide the frequency at which a certain event is read and if it is at
present enabled or disabled.
<ScheduleInfo>
<DeviceMacId>0xFFFFFFFFFFFFFFFF</DeviceMacId>
[<MeterMacId>0xFFFFFFFFFFFFFFFF</MeterMacId>]
<Event>{enumeration}</Event>
<Frequency>0x00000000</Frequency>
<Enabled>{enumeration}</Enabled>
</ScheduleInfo>
Element
Range
Description
DeviceMacId
0xFFFFFFFFFFFFFFFF
Unique MAC Address of the RAVEn™
MeterMacId
0xFFFFFFFFFFFFFFFF;
Optional if only one meter
Unique MAC Address of meter
Event
time | price | demand |
summation | message
The type of event being scheduled
Frequency
0x0 - 0xFFFFFFFE
The frequency in seconds the event will be
executed
Enabled
Y | N
Y: the scheduled event will execute;
N: the scheduled event will not execute.
10.Command: SET_SCHEDULE
Send the SET_SCHEDULE command to update the RAVEn™ scheduler. The command
options include setting the frequency of the command in seconds, and disabling the event. If the
event is disabled the frequency is set to 0xFFFFFFFF.
<Command>
<Name>set_schedule</Name>
[<MeterMacId>0xFFFFFFFFFFFFFFFF</MeterMacId>]
<Event>{enumeration}</Event>
<Frequency>0x00000000</Frequency>
<Enabled>{enumeration}</Enabled>
</Command>
Element
Range
Description
MeterMacId
0xFFFFFFFFFFFFFFFF;
Optional if only one meter
Unique MAC Address of meter
Event
time | price | demand |
summation | message
The type of event being scheduled
Frequency
0x0 - 0xFFFFFFFE
The frequency in seconds the event will be
executed

Rainforest Automation,Inc.
RAVEn™
XML API Manual
13
Enabled
Y | N
Y: the scheduled event will execute (default);
N: the scheduled event will not execute.
11.Command: SET_SCHEDULE_DEFAULT
Send the SET_SCHEDULE_DEFAULT command to reset the RAVEn™ scheduler to default
settings. If the Event field is set, only that schedule item is reset to default values; otherwise all
schedule items are reset to their default values.
<Command>
<Name>set_schedule_default</Name>
[<MeterMacId>0xFFFFFFFFFFFFFFFF</MeterMacId>]
[<Event>{enumeration}</Event>]
</Command>
Element
Range
Description
MeterMacId
0xFFFFFFFFFFFFFFFF;
Optional if only one meter
Unique MAC Address of meter
Event
time | price | demand |
summation | message
The type of event being scheduled; if omitted,
command applies to all scheduled items.
12.Command: GET_METER_LIST
Send the GET_METER_LIST command to get the list of meters the RAVEn™ is connected to.
The RAVEn™ will send a MeterList notification in response.
<Command>
<Name>get_meter_list</Name>
</Command>
13.Notify: MeterList
MeterList notifications provide a list of meters the RAVEn™ is connected to.
<MeterList>
<DeviceMacId>0xFFFFFFFFFFFFFFFF</DeviceMacId>
[<MeterMacId>0xFFFFFFFFFFFFFFFF</MeterMacId>]
[ … ]
</MeterList>
Element
Range
Description
DeviceMacId
0xFFFFFFFFFFFFFFFF
Unique MAC Address of the RAVEn™
MeterMacId
0xFFFFFFFFFFFFFFFF;
Optional
MAC Address of Meter; there can any number
of MeterMacId tags in the MeterList fragment

Rainforest Automation,Inc.
RAVEn™
XML API Manual
14
Meter Feature
The Meter Feature provides the commands and notifications for getting information about the
meter and the network the device is on.
Key commands and notifications include:
•Getting information about the type of meter and its identifiers
•Finding the status of the network connection and the quality of the link
1. Command: GET_METER_INFO
Send the GET_METER_INFO Command to get the meter information. The RAVEn™ will send
a MeterInfo notification in response.
<Command>
<Name>get_meter_info</Name>
[<MeterMacId>0xFFFFFFFFFFFFFFFF</MeterMacId>]
</Command>
Element
Range
Description
MeterMacId
0xFFFFFFFFFFFFFFFF;
Optional if only one meter
Unique MAC Address of meter
2. Notify: MeterInfo
MeterInfo notifications provide information about meters that are on the network.
<MeterInfo>
<DeviceMacId>0xFFFFFFFFFFFFFFFF</DeviceMacId>
<MeterMacId>0xFFFFFFFFFFFFFFFF</MeterMacId>
<MeterType>{enumeration}</MeterType>
<NickName>{string}</NickName>
[<Account>{string}</Account>]
[<Auth>{string}</Auth>]
[<Host>{string}</Host>]
[<Enabled>{enumeration}</Enabled>]
</MeterInfo>
Element
Range
Description
DeviceMacId
0xFFFFFFFFFFFFFFFF
Unique MAC Address of the RAVEn™
MeterMacId
0xFFFFFFFFFFFFFFFF
Unique MAC Address of meter
Meter Type
electric | gas | water |
other
Type of meter
Nickname
Text
Nickname set for the meter
Account
Text; Optional
Account Identification
Auth
Text; Optional
Authentication code
Host
Text; Optional
Hosting Provider

Rainforest Automation,Inc.
RAVEn™
XML API Manual
15
Enabled
Y | N; Optional
Y: to start transmitting data to host
N: to stop transmitting data to host
3. Command: GET_NETWORK_INFO
Send the GET_NETWORK_STATUS Command to get the status of device on the network. The
RAVEn™ will send a NetworkInfo notification in response.
<Command>
<Name>get_network_info</Name>
</Command>
4. Notify: NetworkInfo
NetworkInfo notifications provide information about the network that the device is on.
<NetworkInfo>
<DeviceMacId>0xFFFFFFFFFFFFFFFF</DeviceMacId>
<CoordMacId>0xFFFFFFFFFFFFFFFF</CoordMacId>
<Status>{enumeration}</Status>
<Description>{string}</Description>
<StatusCode>[0xFF]</StatusCode>
<ExtPanId>0xFFFFFFFFFFFFFFFF</ExtPanId>
<Channel>00</Channel>
<ShortAddr>0xFFFF</ShortAddr>
<LinkStrength>0xFF</LinkStrength>
</NetworkInfo>
Element
Range
Description
DeviceMacId
0xFFFFFFFFFFFFFFFF
Unique MAC Address of the RAVEn™
CoordMacId
0xFFFFFFFFFFFFFFFF
MAC Address of the network coordinator
(normally the meter)
Status
Initializing | Network
Discovery | Joining | Join:
Fail | Join: Success |
Authenticating |
Authenticating: Success |
Authenticating: Fail|
Connected| Disconnected|
Rejoining
Indicates the current state of the device
Description
Text
Gives a description of the device state
StatusCode
0x00 – 0xFF
If available, provides a status code for the
current state; if not available, then null
ExtPanId
0x0 -
0xFFFFFFFFFFFFFFFF
Provides the extended PAN ID of the network
the device is trying to join or has joined
Channel
11 – 26
Indicates the channel on which the device is
operating
ShortAddr
0x0000 – 0xFFFF
The short address assigned to the RAVEn™

Rainforest Automation,Inc.
RAVEn™
XML API Manual
16
by the network coordinator
LinkStrength
0x00 – 0x64
Indicates the strength of the link
5. Command: SET_METER_INFO
Send the SET_METER_INFO Command to set the meter information.
<Command>
<Name>set_meter_info</Name>
[<MeterMacId>0xFFFFFFFFFFFFFFFF</MeterMacId>]
[<NickName>{string}</NickName>]
[<Account>{string}</Account>]
[<Auth>{string}</Auth>]
[<host>{string}</host>]
[<enabled>{enumeration}</enabled>]
</Command>
Element
Range
Description
MeterMacId
0xFFFFFFFFFFFFFFFF;
Optional if only one meter
Unique MAC Address of meter
NickName
Text; Optional
Meter nick name
Account
Text; Optional
Account Identification
Auth
Text; Optional
Authentication code
Host
Text; Optional
Hosting Provider
Enabled
Y | N; Optional
Y: to start transmitting data to host
N: to stop transmitting data to host

Rainforest Automation,Inc.
RAVEn™
XML API Manual
17
Time Feature
The Time Feature provides the commands and notifications for getting the time from the smart
meter.
Key commands and notifications include:
•Notify what the time is on a smart meter
•Ask for the latest time from a smart meter
1. Command: GET_TIME
Send the GET_TIME command to get the current time. The RAVEn™ will send a TimeCluster
notification in response.
<Command>
<Name>get_time</Name>
[<MeterMacId>0xFFFFFFFFFFFFFFFF</MeterMacId>]
[<Refresh>{enumeration}</Refresh>]
</Command>
Element
Range
Description
MeterMacId
0xFFFFFFFFFFFFFFFF;
Optional if only one meter
Unique MAC Address of meter
Refresh
Y | N; Optional
Y: Get current time from meter
N: Get time from RAVEn™ cache (default)
2. Notify: TimeCluster
TimeCluster notifications provide the current time reported on the meter in both UTC and Local
time. The time values are the number of seconds since 1-Jan-2000 UTC.
<TimeCluster>
<DeviceMacId>0xFFFFFFFFFFFFFFFF</DeviceMacId>
<MeterMacId>0xFFFFFFFFFFFFFFFF</MeterMacId>
<UTCTime>0xFFFFFFFF</UTCTime>
<LocalTime>0xFFFFFFFF</LocalTime>
</TimeCluster>
Element
Range
Description
DeviceMacId
0xFFFFFFFFFFFFFFFF
Unique MAC Address of the RAVEn™
MeterMacId
0xFFFFFFFFFFFFFFFF
Unique MAC Address of meter
UTCTime
0x0 – 0xFFFFFFFF
UTC Time as reported by meter
LocalTime
0x0 – 0xFFFFFFFF
Local Time as reported by meter

Rainforest Automation,Inc.
RAVEn™
XML API Manual
18
Message Feature
The Message Feature provides the commands and notifications for managing messages routed
through the smart meters.
Key commands and notifications include:
•Message notifications when a smart meter receives a message
•Message confirmation by the User
1. Command: GET_MESSAGE
Send the GET_MESSAGE command to have the RAVEn™ get the current text message. The
RAVEn™ will send a MessageCluster notification in response.
<Command>
<Name>get_message</Name>
[<MeterMacId>0xFFFFFFFFFFFFFFFF</MeterMacId>]
[<Refresh>{text}</Refresh>]
</Command>
Element
Range
Description
MeterMacId
0xFFFFFFFFFFFFFFFF;
Optional if only one meter
Unique MAC Address of meter
Refresh
Y | N; Optional
Y: Get current message from meter
N: Get message from RAVEn™ cache
(default)
2. Notify: MessageCluster
MessageCluster notifications provide the current text message from the meter. If a confirmation
is required, the ConfirmationRequired flag is set. If the user has already confirmed the message,
then the Confirmed flag is set to Y. The ID is the reference to a particular message. The
message text is HTML escape encoded.
<MessageCluster>
<DeviceMacId>0xFFFFFFFFFFFFFFFF</DeviceMacId>
<MeterMacId>0xFFFFFFFFFFFFFFFF</MeterMacId>
<TimeStamp>0xFFFFFFFF</TimeStamp>
<Id>0xFFFFFFFF</Id>
<Text>{string}</Text>
<ConfirmationRequired>{enumeration}</ConfirmationRequired>
<Confirmed>{enumeration}</Confirmed>
<Queue>{enumeration}</Queue>
</MessageCluster>

Rainforest Automation,Inc.
RAVEn™
XML API Manual
19
Element
Range
Description
DeviceMacId
0xFFFFFFFFFFFFFFFF
Unique MAC Address of the RAVEn™
MeterMacId
0xFFFFFFFFFFFFFFFF
Unique MAC Address of meter
TimeStamp
0xFFFFFFFF
UTC Time when message cluster data was
received from meter
Id
0x0 – 0xFFFFFFFF
Message ID from meter
Text
Text
Contents of message HTML encoded:
&gt; replaces the > character
&lt; replaces the < character
&amp; replaces the & character
&quot; replaces the " character
Confirmation
Required
Y | N
Y: a user confirmation is required;
N: a user confirmation is not required (default)
Confirmed
Y | N
Y: the user confirmation has been sent;
N: the user confirmation has not been sent
(default)
Queue
Active | Cancel Pending
Active: Indicates message is in active queue
Cancel Pending: Indicates message is in
cancel pending queue
3. Command: CONFIRM_MESSAGE
Send the CONFIRM_MESSAGE command to have the RAVEn™ confirm the message as
indicated by the ID. To verify that the message confirmation was sent, use a GET_MESSAGE
command with Refresh=Y. The resulting MessageCluster notification should show
Confirmed=Y.
<Command>
<Name>confirm_message</Name>
[<MeterMacId>0xFFFFFFFFFFFFFFFF</MeterMacId>]
<Id>0xFFFFFFFF</Id>
</Command>
Element
Range
Description
MeterMacId
0xFFFFFFFFFFFFFFFF;
Optional if only one meter
Unique MAC Address of meter
ID
0x0 – 0xFFFFFFFF
Message ID to confirm

Rainforest Automation,Inc.
RAVEn™
XML API Manual
20
Price Feature
The Price Feature provides the commands and notifications for managing prices from the smart
meters.
Key commands and notifications include:
•Price notifications from a smart meter
•Price Tier notifications from a smart meter
•Set a user-defined Price when the smart meter does not provide a price
1. Command: GET_CURRENT_PRICE
Send the GET_CURRENT_PRICE command to get the price information. Set the Refresh
element to Y to force the RAVEn™ to get the information from the meter, not from cache.
The RAVEn™ will send a PriceCluster notification in response.
<Command>
<Name>get_current_price</Name>
[<MeterMacId>0xFFFFFFFFFFFFFFFF</MeterMacId>]
[<Refresh>{enumeration}</Refresh>]
</Command>
Element
Range
Description
MeterMacId
0xFFFFFFFFFFFFFFFF;
Optional if only one meter
Unique MAC Address of meter
Refresh
Y | N; Optional
If user price is set, this is ignored; price is
always from RAVEn™ cache.
If user price is not set:
Y: Get current price from meter
N: Get price from RAVEn™ cache (default)
2. Command: SET_CURRENT_PRICE
Send the SET_CURRENT_PRICE command to set the user-defined price on the RAVEn™.
The Price field is an integer; the Trailing Digits field indicates where the decimal place goes (i.e.,
the divisor). The user-defined price will override the meter price. Setting the user-defined price
to zero will clear the user entered price in the RAVEn™, and the meter price will be used, if
available.
<Command>
<Name>set_current_price</Name>
[<MeterMacId>0xFFFFFFFFFFFFFFFF</MeterMacId>]
<Price>0x000000</Price>
<TrailingDigits>0x00</TrailingDigits>
</Command>
