RAMSET CHDDR18 User manual

TO REDUCE THE RISK OF INJURY, USER MUST READ OPERATOR’S MANUAL.
CHDDR18
18V Hammer Drill/Driver
Operator’s Manual

13
12
6
5
8
1
11
10 2

2
Remove the battery pack before starting any work on the
machine.
2 1 9
7
STOP
14
3
START

Remove the battery pack before
starting any work on the machine.
3
1
2
1
2
click

4
78-100 %
55-77 %
3-54 %
10-2 %%
< 10 %

5
1
1
2
3
4
5

6
1
2
1
2

7
START
STOP

8

9
LOCK

10

11

12

13
1
2

14
1
2

15
TECHNICAL DATA
Drilling capacity in steel ...........................................................
Drilling capacity in wood ..........................................................
Drilling capacity in brick and tile ..............................................
Wood screws (without pre-drilling) ..........................................
No-load speed 1st gear ...........................................................
No-load speed 2nd gear ..........................................................
Torque max *1 .........................................................................
Battery voltage ........................................................................
Drill opening range ..................................................................
Weight with battery (1.5 Ah) ....................................................
CHDDR18
........................13 mm
........................55 mm
........................16 mm
..........................8 mm
......................0-450 min-1
....................0-1800 min-1
..........................85 Nm
...........................18V
SAFETY INSTRUCTIONS
SPECIFIED CONDITIONS OF USE
The electronic battery hammer drill/ screwdriver is
designed for drilling, percussion drilling, as well as
screwdriving for independent use away from mains
supply.
Do not use this product in any other way as stated for
normal use.
Noise/vibration information
Measured values determined according to EN 60 745.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level (K = 3dB(A)) .......................................
Sound power level (K = 3dB(A)) ............................................
Wear ear protectors!
Total vibration values (vector sum in the three axes)
determined according to EN 60745. Vibration emission
value ah
Percussion drilling into concrete ...........................................
Uncertainty K= ......................................................................
Drilling into metal ..................................................................
Uncertainty K= ......................................................................
Screwing ...............................................................................
Uncertainty K= ......................................................................
.....................1.5-13 mm
..........................2.5 kg
........................86.5 dB (A)
........................97.5 dB (A)
.......................11.6 m/s2
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given
in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained, the vibration emission may differ. This may signicantly
increase the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may signicantly reduce the exposure level over the total working
period. Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool
and the accessories, keep the hands warm, organisation of work patterns.
WARNING! Read all safety warnings and all instruc-
tions, including those given in the accompanying bro-
chure. Failure to follow the warnings and instructions may
result in electric shock, re and/or serious injury. Save all
warnings and instructions for future reference.
Wear ear protectors. Exposure to noise can cause hearing
loss.
Use auxiliary handles supplied with the tool. Loss of
control can cause personal injury.
Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory
may contact hidden wiring. Cutting accessory contacting
a “live” wire may make exposed metal parts of the power
tool “live” and shock the operator.
Sawdust and splinters must not be removed while the
machine is running.
When working in walls ceiling, or oor, take care to avoid
electric cables and gas or waterpipes.
Remove the battery pack before starting any work on the
machine.
Do not dispose of used battery packs in the household
refuse or by burning them.
Do not store the battery pack together with metal objects
(short circuit risk).
Use only CCR18 chargers for charging R18 battery packs.
Do not use battery packs from other systems. Battery acid
may leak from damaged batteries under extreme load or
extreme temperatures. In case of contact with battery acid
wash it off immediately with soap and water. In case of
eye contact rinse thoroughly for at least 10 minutes and
immediately seek medical attention.
.......................< 2.5 m/s2
.......................1.5 m/s2
.......................< 2.5 m/s2
.......................1.5 m/s2
.......................1.5 m/s2

16
EC-DECLARATION OF CONFORMITY
We declare under our sole responsibility that this product is
in conformity with the following standards or standardized
documents. EN 60745, EN 55014-1, EN 55014-2, in
accordance with the regulations 98/7/EC, 2004/108/ECC
BATTERIES
New battery packs reach full loading capacity after 4 - 5
chargings and dischargings. Battery packs which have
not been used for some time should be recharged before
use. Temperatures in excess of 50°C (122°F) reduce the
performance of the battery pack. Avoid extended exposure
to heat or sunshine (risk of overheating).
The contacts of chargers and battery packs must be kept
clean.
BATTERY PACK PROTECTION
In extremely high torque, binding, stalling and short circuit
situations that cause high current draw, the tool will vibrate
for about 2 seconds and then the tool will turn OFF.
To reset, release the trigger.
Under extreme circumstances, the internal temperature of
the battery could become to high. If this happens, the
battery will shut down.
Place the battery on the charger to charge and reset it.
INTENANCE
Use only Ramset accessories and spare parts. Should
components need to be replaced which have not been
described, please contact our Ramset National Service
Centre.
SYMBOLS
Please read the instructions carefully before
starting the machine.
Remove the battery pack before starting any
work on the machine.
Do not dispose of electric tools together with
household waste material! In observance
of European Directive 2002/96/EC on waste
electrical and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their
life must be collected separately and returned to
an environmentally compatible recycling facility.

TWO YEAR WARRANTY
Every RamsetTM 18 Volt Lithium-Ion power tool (including battery charger) is warranted to
the original purchaser only to be free from defects in material and workmanship. Subject
to certain exceptions, RamsetTM will repair or replace any part on a 18 Volt Lithium-Ion
power tool which, after examination, is determined by RamsetTM to be defective in
material or workmanship for a period of two (2) years* after the date of purchase. Return
the 18 Volt Lithium-Ion power tool and a copy of proof of purchase to the RamsetTM
National Service Centre, freight prepaid and insured, as requested for this warranty to
be effective. This warranty does not apply to damage that RamsetTM determines to be
from repairs made or attempted by anyone other than RamsetTM authorized personnel,
misuse, alterations, abuse, normal wear and tear, lack of maintenance, or accidents.
*The warranty period for Li-Ion battery packs is two (2) years from the date of purchase.
ACCEPTANCE OF THE EXCLUSIVE REPAIR AND REPLACEMENT REMEDIES
DESCRIBED HEREIN IS A CONDITION OF THE CONTRACT FOR THE PURCHASE
OF EVERY RamsetTM PRODUCT. IF YOU DO NOT AGREE TO THIS CONDITION,
YOU SHOULD NOT PURCHASE THE PRODUCT. IN NO EVENT SHALL RamsetTM
BE LIABLE FOR ANY INCIDENTAL, SPECIAL, CONSEQUENTIAL OR PUNITIVE
DAMAGES, OR FOR ANY COSTS, ATTORNEY FEES, EXPENSES, LOSSES OR
DELAYS ALLEGED TO BE AS A CONSEQUENCE OF ANY DAMAGE TO, FAILURE
OF, OR DEFECT IN ANY PRODUCT INCLUDING, BUT NOT LIMITED TO, ANY
CLAIMS FOR LOSS OF PROFITS. THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF
ALL OTHER WARRANTIES OR CONDITIONS, WRITTEN OR ORAL, EXPRESSED
OR IMPLIED. WITHOUT LIMITING THE GENERALITY OF THE FOREGOING,
RamsetTM DISCLAIMS ANY IMPLIED WARRANTY OF MERCHANT-ABILITY OR
FITNESS FOR A PARTICULAR USE OR PURPOSE, AND ALL OTHER WARRANTIES.
RamsetTM A division of ITW Australia Pty Ltd
RAMCHDDR18/OM1911
