RAMTONS RM 396 User manual

Microwave Oven
Instructions
Model: RM 396
Please read these instructions carefully before installing and operating the oven.
Record in the space below the SERIAL NO. found on the nameplate on your
oven and retain this information for future reference.
SERIAL NO.

1
Content
Precautions to Avoid Possible Exposure to Excessive Microwave Energy.................................2
Important Safety Instructions........................................................................................................2
Specifications................................................................................................................................4
Installation Guide..........................................................................................................................5
Grounding Instructions.................................................................................................................5
Radio Interference........................................................................................................................6
Before Calling For Service ...........................................................................................................6
Cooking Techniques.....................................................................................................................6
Cooking Utensils Guide................................................................................................................7
Product Diagram ..........................................................................................................................8
Control Panel................................................................................................................................9
Power/Action Selector...........................................................................................................9
Timer Knob............................................................................................................................9
Microwave Cooking...............................................................................................................9
Operation Instructions................................................................................................................10
Cleaning and Care .....................................................................................................................11

2
Precautions to Avoid Possible Exposure to
Excessive Microwave Energy
1. Do not attempt to operate this oven with the door open since open-door operation can
result in harmful exposure to microwave energy. It is important not to defeat or tamper with
the safety interlocks.
2. Do not place any object between the oven front face and the door or allow soil or cleaner
residue to accumulate on sealing surfaces.
3. Do not operate the oven if it is damaged. It is very important that the oven door close
properly and that there is no damage to the
a)Door (including any dents),
b)Hinges and latches (broken or loosened),
c)Door seals and sealing surfaces.
4. The oven should not be adjusted or repaired by anyone except qualified service personnel.
Important Safety Instructions
When using electrical appliance basic safety precautions should be followed, including the
following:
WARNING!--To reduce the risk of burns, electric shock, fire, injury to persons or exposure to
excessive microwave energy:
1. Read all instructions before using the appliance.
2. Use this appliance only for its intended use as described in the manual. Do not use corrosive
chemicals or vapors in this appliance. This type of oven is specifically designed to heat, cook
or dry food. It is not designed for industrial or laboratory use.
3. Do not operate the oven when empty.
4. Do not operate this appliance if it has a damaged cord or plug, if it is not working properly, or
if it has been damaged or dropped. If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.
5. WARNING: Only allow children to use the oven without supervision when adequate
instructions have been given so that the child is able to use the oven in a safe way and
understands the hazards of improper use.
6. To reduce the risk of fire in the oven cavity:
When heating food in plastic or paper container, check the oven frequently to the possibility
of ignition.
Remove wire twist-ties from paper or plastic bags before placing bag in oven.
If smoke is observed, switch off or unplug the appliance and keep the door closed in order
to stifle any flames.
Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils,
or food in the cavity when not in use.

3
7. WARNING: Liquid or other food must not be heated in sealed containers since they are liable
to explode.
8. Microwave heating of beverage can result in delayed eruptive boiling, therefore care has to
be taken when handle the container.
9. Do not fry food in the oven. Hot oil can damage oven parts and utensils and even result in
skin burns.
10. Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens
since they may explode even after microwave heating has ended.
11. Pierce foods with heavy skins such as potatoes, whole squashes, apples and chestnuts
before cooking.
12. The contents of feeding bottles and baby jars should be stirred or shaken and the
temperature should be checked before serving in order to avoid burns.
13. Cooking utensils may become hot because of heat transferred from the heated food.
Potholders may be needed to handle the utensil.
14. Utensils should be checked to ensure that they are suitable for use in microwave oven.
15. WARNING: It is hazardous for anyone other than a trained person to carry out any service or
repair operation which involves the removal of any cover which gives protection against
exposure to microwave energy.
16. This product is a Group 2 Class B ISM equipment. The definition of Group 2 which contains
all ISM (Industrial, Scientific and Medical) equipment in which radio-frequency energy is
intentionally generated and/or used in the form of electromagnetic radiation for the treatment
of material, and spark erosion equipment. For Class B equipment is equipment suitable for
use in domestic establishments and in establishments directly connected to a low voltage
power supply network which supplies buildings used for domestic purpose.
17. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
18. Children should be supervised to ensure that they do not play with the appliance.
19. The microwave oven is only used in freestanding.
20. WARNING: Do not install oven over a range cooktop or other heat-producing appliance. if
installed could be damaged and the warranty would be avoid .
21. The accessible surface may be hot during operation.
22. The microwave oven shall not be placed in a cabinet.
23. The door or the outer surface may get hot when the appliance is operating.
24. The temperature of accessible surfaces may be high when the appliance is operating.
25. The appliance shall be placed against a wall.
26. Appliance is not to be used by children or persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction.
27. Children being supervised not to play with appliance.
28. WARNING: If the door or door seals are damaged, the oven must not be operated until it has
been repaired by a competent person.

4
29. The instructions shall state that appliances are not intended to be operated by means of an
external timer or separate remote-control system.
30. The microwave oven is for household use only and not for commercial use.
31. Never remove the distance holder in the back or on the sides, as it ensures a minimum
distance from the wall for air circulation.
32. Please secure the turn table before you move the appliance to avoid damages.
33. Caution: It is dangerous to repair or maintain the appliance by no other than a specialist
because under these circumstances the cover have to be removed which assures protection
against microwave radiation. This applies to changing the power cord or the lighting as well.
Send the appliance in these cases to our service centre.
34. The microwave oven is intended for defrosting, cooking and steaming of food only.
35. Use gloves if you remove any heated food.
36. Caution! Steam will escape, when opening lids or wrapping foil.
37. This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children unless they are aged from 8 years and
above and supervised.
38. If smoke is emitted, switch off or unplug the appliance and keep the door closed in order to
stifle.
Specifications
Power Consumption
230V~50Hz, 1100W(microwave)
Output
700W
Operation Frequency
2450MHz
Outside Dimensions
262mm(H)×452mm(W)×365mm(D)
Oven Cavity Dimensions
220mm(H)×315mm(W)×294mm(D)
Oven Capacity
Compact 20Litres
Cooking Uniformity
Turntable System
Net Weight
Approx.10.5kg

5
Installation Guide
1. Make sure that all the packing materials are removed from the inside of the door.
2. WARNING: Check the oven for any damage, such as misaligned or bent door, damaged
door seals and sealing surface, broken or loose door hinges and latches and dents inside the
cavity or on the door. If there is any damage, do not operate the oven and contact qualified
service personnel.
3. This microwave oven must be placed on a flat, stable surface to hold its weight and the
heaviest food likely to be cooked in the oven.
4. Do not place the oven where heat, moisture, or high humidity are generated, or near
combustible materials.
5. For correct operation, the oven must have sufficient airflow. Allow 20cm of space above the
oven, 10cm at back and 5cm at both sides. Do not cover or block any openings on the
appliance. Do not remove feet.
6. Do not operate the oven without glass tray, roller support, and shaft in their proper positions.
7. Make sure that the power supply cord is undamaged and does not run under the oven or
over any hot or sharp surface.
8. The socket must be readily accessible so that it can be easily unplugged in an emergency.
9. Do not use the oven outdoors.
Grounding Instructions
This appliance must be grounded. This oven is equipped with a cord having a grounding wire
with a grounding plug. It must be plugged into a wall receptacle that is properly installed and
grounded. In the event of an electrical short circuit, grounding reduces risk of electric shock by
providing an escape wire for the electric current. It is recommended that a separate circuit
serving only the oven be provided. Using a high voltage is dangerous and may result in a fire or
other accident causing oven damage.
WARNING--- Improper use of the grounding plug can result in a risk of electric shock.
Note:
1. If you have any questions about the grounding or electrical instructions, consult a qualified
electrician or service person.
2. Neither the manufacturer nor the dealer can accept any liability for damage to the oven or
personal injury resulting from failure to observe the electrical connection procedures.
The wires in this cable main are colored in accordance with the following code:
Green and Yellow = EARTH
Blue = NEUTRAL
Brown = LIVE

6
Radio Interference
Operation of the microwave oven can cause interference to your radio, TV, or similar
equipment.
When there is interference, it may be reduced or eliminated by taking the following measures:
1. Clean door and sealing surface of the oven.
2. Reorient the receiving antenna of radio or television.
3. Relocate the microwave oven with respect to the receiver.
4. Move the microwave oven away from the receiver.
5. Plug the microwave oven into a different outlet so that microwave oven and receiver are on
different branch circuits.
Before Calling For Service
Before asking for service, please check each item below:
Check to ensure the oven is plugged in securely. If not, remove the plug from the outlet,
wait 10 seconds, and plug it in again securely.
Check for a blown circuit fuse or a tripped main circuit breaker. If these seem to be
operating properly, test the outlet with another appliance.
Check to ensure the control panel is programmed correctly and the timer is set.
Check to ensure the door is securely closed, engaging the door lock system. If the door is
not properly closed, the microwave energy will not flow inside.
IF NONE OF THE ABOVE RECTIFIES THE SITUATION, THEN CONTACT A QUALIFIED
TECHNICIAN. DO NOT TRYTOADJUST OR REPAIR THE OVEN YOURSELF.
Cooking Techniques
1. Arrange food carefully. Place thickest areas towards outside of dish.
2. Watch cooking time. Cook for the shortest amount of time indicated and add more as needed.
Food severely overcooked can smoke or ignite.
3. Cover foods while cooking. Covers prevent spattering and help foods to cook evenly.
4. Turn foods over once during microwave cooking to speed cooking of such foods as chicken
and hamburgers. Large items like roasts must be turned over at least once.
5. Rearrange foods such as meatballs halfway through cooking both from top to bottom and
from the center of the dish to the outside.

7
Cooking Utensils Guide
1. The ideal material for a microwave utensil is transparent to microwave, it allows energy to
pass through the container and heat the food.
2. Microwave cannot penetrate metal, so metal utensils or dishes with metallic trim should not
be used.
3. Do not use recycled paper products when microwave cooking, as they may contain small
metal fragments which may cause sparks and/or fires.
4. Round /oval dishes rather than square/oblong ones are recommend, as food in corners
tends to overcook.
5. Narrow strips of aluminum foil may be used to prevent overcooking of exposed areas. But be
careful don’t use too much and keep a distance of 1 inch (2.54cm) between foil and cavity.
The list below is a general guide to help you select the correct utensils.
Cookware
Microwave Cooking
Heat–Resistant Glass
Yes
Non Heat–Resistant Glass
No
Heat–Resistant Ceramics
Yes
Microwave–Safe Plastic Dish
Yes
Kitchen Paper
Yes
Metal Tray
No
Metal Rack
No
Aluminum Foil & Foil Containers
No

8
Product Diagram
○
1 Door Safety Lock System
○
2 Oven Window
○
3 Turntable Support
○
4 Door Release Button
○
5 Control Panel
○
6 Wave Guide (Please do not remove the mica plate covering the wave guide)
○
7 Glass Tray

9
Control Panel
The control panel consists of two function
operators. One is a time knob, and the other a
power knob.
Power/Action Selector
You use this operator knob to choose a cooking
power level. It is the first step to start a cooking
session.
Timer Knob
Offer visual timing settings at easy turn of your
thumb to select a desired cooking time up to 30
minutes per cooking session.
Microwave Cooking
For pure microwave cooking, there are six power
levels from which to choose one as best fit to do
the job at hand.
Power level increases with the knob turning
clockwise. The power levels can be classified as
the following:
Power Output
Description
100%
High
85%
M.High
66%
Med
48%
M.Low
40%
Defrost
17%
Low

10
Operation Instructions
To start a cooking session,
1. Place food into oven and close the door.
2. Turn Power Selector to select a power level.
3. Turn Timer knob to set a cooking time.
NOTE: As soon as the timer is turned, oven starts cooking. When selecting time for less than 2
minutes, turn timer past 2 minutes and then return to the correct time.
CAUTION: ALWAYS RETURN TIMER BACK TO ZERO POSITION if food is removed from
oven before the set cooking time is complete or when oven is not in use. To stop oven during
cooking process, push the door release button or open the door by the handle.

11
Cleaning and Care
1. Turn off the oven and unplug the power cord from the wall when cleaning.
2. Keep the inside of the oven clean.When food splatters or spilled liquids adhere to oven walls,
wipe with a damp cloth. Mild detergents may be used if the oven gets very dirty. Avoid using
spray or other harsh cleaners. They may stain, streak or dull the door surface.
3. The outside of the oven should be cleaned with a damp cloth. To prevent damage to the
operating parts inside the oven, water should not be allowed to seep into the ventilation
openings.
4. Wipe the door and window on both sides, the door seals and adjacent parts frequently with a
damp cloth to remove any spills or spatters. Do not use abrasive cleaner.
5. Do not allow the control panel to become wet. Clean with a soft, damp cloth. When cleaning
the control panel, leave oven door open to prevent oven from accidentally turning on.
6. If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth.
This may occur when the microwave oven is operated under high humidity condition. And it
is normal.
7. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm
sudsy water or in a dishwasher.
8. The roller ring and oven floor should be cleaned regularly to avoid excessive noise. Simply
wipe the bottom surface of the oven with mild detergent. The roller ring may be washed in
mild, soapy water or in a dishwasher. When removing the roller ring, be sure to replace it in
the proper position.
9. Remove odors from your oven by combining a cup of water with the juice and skin of one
lemon in a microwaveable bowl. Microwave for 5 minutes. Wipe thoroughly and dry with a
soft cloth.
10. If the light bulb burns out, please contact customer service to have it replaced.
11. The oven should be cleaned regularly and any food deposits should be removed. Failure to
maintain the oven in a clean condition could lead to deterioration of surface that could
adversely affect the life of the unit and could possibly result in a hazardous situation.
12. Please do not dispose of this appliance into the domestic rubbish bin; it should be disposed
to the particular disposal center provided by the municipalities.
