RC6D

25 & 35h p Wo o d Ch i p p e r

Op e r a t i O n Ma n u a l

800-610-4101 • ActionRental.com

Printed in U.S.A.

Contents

Printed in U.S.A.

Contents 3

This manual is published by Rayco

Manufacturing, Inc. for the benet of

the users of Rayco products. Rayco

Manufacturing, Inc. has made every

effort to ensure that this manual is

correct and up to date at the time of

publication. However, due to continuous

improvements, Rayco Manufacturing,

Inc. reserves the right to make changes

in the contents, at any time, without

notice or obligation.

Each machine shipped contains

operation, maintenance & parts manuals

to familiarize the operator with the proper

operating, lubricating and maintenance

instructions. This helps to ensure the best

possible performance and service from

the machine. Read and understand all

instructions before attempting to operate

this machine. This manual should be

readily available for reference at all times.

Additional copies of this manual may be

purchased from Rayco.

This Rayco machine was designed and

manufactured by Rayco Manufacturing,

Inc., Wooster, Ohio. Due to continuous

improvements, Rayco reserves the

right to make changes in engineering,

design and specications, or discontinue

manufacture, at any time, without notice

or obligation.

Always have a record of the model

numbers and serial numbers for your

machine to specify when ordering

parts. Record your machine model and

serial numbers below for your personal

records.

IDENTIFICATION NUMBERS

MODEL NUMBER SERIAL NUMBER

MACHINE

ENGINE

NOTICE:

MAINTENANCE AND REPAIRS SHOULD ONLY BE PERFORMED BY A TRAINED

SPECIALISTS OR QUALIFIED PERSON.

PLEASE CONTACT RAYCO MFG FOR A LISTING OF APPROVED

MAINTENANCE FACILITIES IN YOUR AREA.

DEALER INFORMATION

NAME

ADDRESS

DEALER CONTACT PHONE NUMBER HOURS

SALES

PARTS

SERVICE

800-610-4101 • ActionRental.com

Printed in U.S.A.

Contents

Printed in U.S.A.

Contents 3

Table of Contents

In f o r m a t I o n a l Se c t I o n

Literature ............................................................4

Machine Description...........................................5

Serial Number Locations ....................................5

Sa f e t y Se c t I o n

California proposition 65 Warning ......................6

Certied engine Maintenance.............................6

Important Safety Information ..............................7

Warning Signs ....................................................7

General Hazard Information ...............................8

Personal Protection Equipment (PPE) ...............9

Flying Debris.......................................................9

Pressurized Air and Water..................................9

Trapped Pressure...............................................9

Fluid Penetration ................................................9

Containing Fluid Spillage..................................10

Asbestos Information........................................10

Dispose of Waste Properly ...............................10

Crusing Prevention and Cutting Prevention .....10

Burn Prevention................................................ 11

Coolant & Oils................................................... 11

Battery & Tires..................................................12

Fire Prevention and Explosion Prevention .......12

Ether Starting Fluid...........................................13

Lines, Tubes and Hoses ...................................13

Fire Extinguisher & Location.............................13

Electrical Storm Injury prevention.....................14

While Operating the Machine ...........................14

While Servicing and Maintenance ....................14

Before Starting Engine .....................................15

Visibility Information..........................................15

Engine Starting.................................................15

Operation..........................................................16

Parking .............................................................16

Slope Operation................................................17

Equipment Lowering with Engine Stopped.......17

Work Tool Options / Attachments .....................17

Sound Level Information...................................18

Vibration Information ........................................18

Guidelines for Reducing Vibration Levels.........18

Guards (Operator Protection)...........................18

Roll Over Protection .........................................19

Other Guards....................................................19

Precautions for Welding with ECU ..................19

Safety Decals ...................................................19

Lock-Out / Tag-Out Guidelines .........................20

Pre-Transportation Checks...............................21

Important Towing Information ...........................21

Loading Your Combination ...............................21

Slow Down When Towing .................................21

Before Towing and on the Road .......................22

Your Tow Vehicle ..............................................22

Towing Equipment Requirements.....................22

Tire Pressure ....................................................22

Connecting Your Trailer ....................................22

Safety Chains ...................................................22

Emergency Brake Chain / Cable ......................23

Lighting connections.........................................23

Loading.............................................................23

Secure the Load ...............................................23

Towing Checklist...............................................23

OSHA- Hazards of Wood Chippers..................24

op e r a t I o n Se c t I o n

Know YourMachine...........................................28

Operators Controls ...........................................29

Machine Operation ...........................................29

Discharge Chute Adjustment..........................29

PreStart Inspection.........................................29

Starting the Machine.......................................29

Stopping the Machine.....................................30

Hitching / Height Adjustment ..........................31

Optional Safety Bump Bar (Panic Bar)...........31

Work Site Preparation ......................................32

While Operating the Machine ...........................32

Feed Brush into the Chipper.............................33

Changing the Chip Size....................................34

Versa-Feed System ..........................................34

Clearing Obstructions.......................................34

Clearing out the Discharge Chute ....................34

Walk Around Inspection....................................35

Storing the Chipper...........................................35

Starting with Jumper Cables.............................36

ma I n t e n a n c e Se c t I o n

Torque Specications .......................................37

Fluid Specications...........................................38

Maintenance Intervals ......................................39

tr o u b l e Sh o o t I n g Se c t I o n ��54

ma c h I n e Sp e c I f I c a t I o n S ��56

Se r v I c e pa r t S - Qu I c k re f e r e n c e��57

Wa r r a n t y .........................................................58

800-610-4101 • ActionRental.com

Printed in U.S.A.

Contents

Printed in U.S.A.

Contents 5

Printed in U.S.A.

Contents

Printed in U.S.A.

Contents 5

FOREWORD

LITERATURE INFORMATION

The operators manual should be stored in the

operator’s compartment in the literature holder

storage area. Rayco provides a binder to hold

the Operator Service Manual, Parts Manual,

Engine Manual along with other component

manuals.

These manuals contain safety information,

operation instruction, transportation informa-

tion, lubrication information and maintenance

information.

Some photographs or illustrations in the pub-

lication show details of attachments that can

be different from your machine. Guards and

covers might have been removed for illustrative

purposes. Continuing improvement may have

caused changes to your machine which may not

be included in this publication.

Continuing improvement and advancement of

product design might have caused changes

to your machine which are not included in this

publication. Read, study and keep this manual

with the machine.

Whenever a question arises regarding your

machine, of this publication, please consult your

Rayco dealer for the latest available information.

SAFETY

The safety section lists basic safety precautions.

In addition, this section may include text and

locations of warning signs and labels used on

the machine.

Read and understand the basic precautions

listed in the safety section before operating or

performing lubrication, maintenance and repair

on this machine.

PARTS (see Parts Manual)

Parts are readily found through illustrations

with accompanying Rayco part numbers. The

machine assembly is listed by basic groups to

enable ease of nding parts.

Please consult your local Rayco Dealer or local

Engine Manufacturer Dealer for obtaining engine

parts and service.

OPERATION

The operation section is a reference for the new

operator and a refresher for the experienced

operator. This section includes a discussion of

gauges, switches, machine controls, attachment

controls, transportation and towing information.

Photographs and illustrations guide the operator

through correct procedures of checking, starting,

operating and stopping the machine.

Operating techniques outlined in this publication

are basic. Skill and techniques develop as the

operator gains knowledge of the machine and its

capabilities.

MAINTENANCE

The maintenance section is a guide to equip-

ment care. The Maintenance Interval Schedule

lists the items to be maintained at a specic

service interval. The Maintenance Interval

Schedule lists the page number for the step-

by-step instructions required to accomplish the

scheduled maintenance procedure.

MAINTENANCE INTERVALS

Use the service hour meter to determine servic-

ing intervals. Calendar intervals shown (daily,

weekly, monthly, etc.) can be used instead of

service hour meter intervals if they provide more

convenient servicing schedules and approximate

the indicated service hour meter reading. Rec-

ommended service should always be performed

at the interval that occurs rst.

Under extremely severe, dusty or wet operat-

ing conditions, more frequent lubrication than

is specied in the maintenance intervals chart

might be necessary.

Perform service on items at multiples of the

original requirement. For example, at every 100

service hours, also service those items listed un-

der every 50 service hours and every 10 service

hours or daily.

800-610-4101 • ActionRental.com

Printed in U.S.A.

Contents

Printed in U.S.A.

Contents 5

Printed in U.S.A.

Contents

Printed in U.S.A.

Contents 5

A Description of the

Machine

Design

The Rayco RC6D Wood Chipper was designed

with both the operator and service technician

in mind. The RC6D Chipper will quickly reduce

brush and tree limbs into usable and consistently

sized chips or mulch.

The RC6D wood chipper is equipped with your

choice of either a 25hp Kohler or 35hp Briggs &

Stratton Vanguard engine that can be easily ser-

viced. The new design allows room to perform

most service tasks with ease and efciency.

The Newly designed chipping disc contains (2)

double edged knives. The knives cut against an

adjustable bed knife which allows the owner to

preset the gap to provide just the right size of

discharged chips or mulch. The disc is mounted

on heavy-duty bearings for longevity and ease of

maintenance.

The chipping disc is driven by a manually

engaged belt clutch through a simplied V-belt

system.

The In-Feed wheel is driven hydraulically and

monitored by the “Versa-Feed System” which

self-adjusts the material infeed rate accord-

ing to engine speed. This allows the operator

to concentrate on loading material rather that

continually monitoring the machine feeding rate

to prevent the engine from stalling.

Another feature to the Rayco RC6D machine

line is the externally mounted “High-Velocity

Discharge System” that keeps a constant air ve-

locity ow through the discharge chute allowing

a more consistent pile formation. The discharge

chute can be rotated 360 degrees and locked at

every 7.5 degree increment as well as elevated

or lowered for improved byproduct manage-

ment. The chute also has an adjustable locking

deector at the end of the discharge chute to

provide just the right amount of deection angle

you need.

The In-Feed Chute can accommodate material

up to 6 inches tall by 6 inches wide. The frame

consists of All-Steel channel and tubing with a

reinforced steel cutter housing to provide years

of service.

Features:

• A convenient all-steel lockable tool box.

• The Feed table folds up for reduced

storage space.

• High-Velocity Discharge fan

• Infeed wheel system provides a constant

material feed to the chipper disc.

• Electronic Versa-Feed system maintains

engine efciency when chipping large

materials thus saving the owner time

and fuel.

Operator Safety:

• Specially equipped with a Feed Control

Emergency Stop Bar (ANSI Z133.1)

• Fold Down Feed Table extends the distance

between operator and feed roller.

• Discharge Chute Deector Guard reduces

the risk of being struck by ying debris.

Serial Numbers

Whenever communicating with Rayco or your

Rayco dealer, have your machine serial num-

ber handy, as it can help pinpoint most exactly

what information is needed in caring for your

machine.

It is attached to the machine at the location

shown. For ready reference, record it in the

boxes provided on the inside front cover of this

manual.

For reference on communication regarding the

engine, record its model and serial numbers also

in the boxes provided on the inside front cover

of this manual. See the Engine Operator Manual

for assistance in locating the numbers on the

engine.

800-610-4101 • ActionRental.com

Safety Section

Safety Section 7

Printed in U.S.A.

Safety Section

Safety Section 7

Printed in U.S.A.

CALIFORNIA PROPOSITION 65 WARNING

Diesel engine exhaust and some of its con-

stituents are known to the State of California to

cause cancer, birth defects, and other reproduc-

tive harm.

Battery posts, terminals and related accessories

contain lead and lead compounds. Wash hands

after handling.

CERTIFIED ENGINE MAINTENANCE

Proper maintenance and repair is essential to

keep the engine and machine systems operat-

ing correctly. As the heavy duty off-road engine

owner, you are responsible for the required

maintenance listed in the Engine Owner Manual

& Machine Operator, Maintenance & Service

Manual.

Attach a “Do Not Operate” warning tag or a

similar warning tag to the start switch or to the

controls before you service the equipment or

before you repair the equipment.

Know the width of your equipment in order to

maintain proper clearance with you operate

the equipment near fences or near boundary

obstacles.

Be aware of high voltage power lines and power

cables that are buried. If the machine comes

in contact with these hazards, serious injury or

death may occur from electrocution.

Wear a hard hat, protective glasses, and other

protective equipment, as required.

Do not wear loose clothing or jewelry that can

snag on controls or on other parts of the equip-

ment.

Make sure that all protective guards and all cov-

ers are secured in place on the equipment.

Keep the equipment free from foreign material.

Remove debris, oil, tools, and other items from

the deck, from walkways, and from steps.

Secure all loose items such as lunch boxes,

tools, and other items that are not a part of the

equipment.

Know the appropriate work site hand signals

and the personnel that are authorized to give

the hand signals. Accept hand signals from one

person only.

Do not smoke when you service an air condi-

tioner. Also, do not smoke if refrigerant gas may

be present. Inhaling the fumes that are released

from a ame that contact air conditioner refriger-

ant can cause bodily harm or death. Inhaling

gas from air conditioner refrigerant through a

lighted cigarette can cause bodily harm or death.

Never put maintenance uids into glass contain-

ers. Drain all liquids into a suitable container.

Obey all local regulations for the disposal of

liquids.

Use all cleaning solutions with care. Report all

necessary repairs.

Do not allow unauthorized personnel on the

equipment.

Unless you are instructed otherwise, perform

maintenance with the equipment in the servicing

position. Refer to Operation and Maintenance

Manual for the procedure for placing the equip-

ment in the servicing position.

When you perform maintenance above ground

level, use appropriate devices such as ladders or

man lift machines. If equipped, use the machine

anchorage points and use approved fall arrest

harnesses and lanyards.

800-610-4101 • ActionRental.com

Safety Section

Safety Section 7

Printed in U.S.A.

Safety Section

Safety Section 7

Printed in U.S.A.

IMPORTANT SAFETY

INFORMATION

Most accidents that involve product operation,

maintenance and repair are caused by failure

to observe basic safety rules or precautions.

An accident can often be avoided by recogniz-

ing potentially hazardous situations before an

accident occurs. A person must be alert to

potential hazards. This person should also have

the necessary training, skills and tools to perform

these functions properly.

Improper operation, lubrication, maintenance

or repair of this product can be dangerous and

could result in injury or death.

Do not operate or perform any lubrication, main-

tenance or repair on this product, until you have

read and understood the operation, lubrication,

maintenance and repair information.

Safety precautions and warnings are provided in

this manual and on the product. If these hazard

warnings are not heeded, bodily injury or death

could occur to you or to other persons.

The hazards are identied by the “Safety Alert

Symbol” and followed by a “Signal Word” such

as “DANGER”, “WARNING” or “CAU-

TION”. The Safety Alert “WARNING” label is

shown below.

SAFETY

To highlight specic safety information the

following designations are provided to assist

the reader.

This is the “Safety Alert” symbol. It is used

to ALERT you to the potential personal injury

hazards. Obey all safety messages that fol-

low this symbol to avoid possible injury or

death.

Indicates an imminently hazardous situation

which, if not avoided, could result in death or

serious injury.

WARNING

Indicates a potentially hazardous situation

which, if not avoided, will result in death or

serious injury.

CAUTION

Indicates a potentially hazardous situation

which, if not avoided, may result in minor or

moderate injury.

A message, either written or pictorial, follows

to explain the hazard. Rayco cannot anticipate

every possible circumstance that might involve a

potential hazard. The warnings in this publica-

tion and on the product are therefore not all

inclusive. If you desire to make use of a tool,

procedure, work method, or operating technique

not specically recommended by Rayco, you

must use it only if you have accurately evaluated

it and found that it threatens no one’s safety.

You should also ensure that the product will not

be damaged or made unsafe by the operation,

lubrication, maintenance, or repair procedures

that you choose.

The procedures described in this “Safety” sec-

tion may not be fully explained here, but a more

complete explanation is given in the “Operation”,

or in the “Maintenance” section.

The information, specications, and illustrations

in this publication are on the basis of information

that was available at the time that the publication

was written. The specications, torques, pres-

sures, measurements, adjustments, illustrations,

and other items can change at any time. These

changes can affect the service that is given to

the product. Obtain the complete and most

current information before you start any job.

Rayco dealers have the most current information

available.

This is the safety alert symbol. It is used to alert

you to the potential personal injury hazards. Obey all

safety messages that follow this symbol to avoid

possible injury or death.

800-610-4101 • ActionRental.com

Safety Section

Safety Section 9

Printed in U.S.A.

Safety Section

Safety Section 9

Printed in U.S.A.

Rayco Manufacturing, Inc. is greatly con-

cerned with the safety of the operator, as well

as all in the vicinity of his work.

Rayco has provided shields, guards, safety

decals and other important safety features to aid

in using the machine properly. In order to further

ensure your safety we ask that you properly

operate and service your machine.

WARNING

This machine is capable of amputating hands

and feet and throwing objects. Failure to ob-

serve safety instructions, improper opera-

tion, lubrication, maintenance, or repair of

this product could result in severe injury or

death.

Do not operate or perform any lubrication,

maintenance, or repair on this product, until

you have read, you understand, and you

decide to do so in compliance with all of the

operation, lubrication, maintenance, and

troubleshooting information contained in

these Operator and Parts Manuals and that

contained in the Engine Operator Manual,

which are included with this machine. Additional

manuals are available from Rayco or your Rayco

dealer.

When replacement parts are required for this

product Rayco recommends using Rayco

replacement parts or parts with equivalent speci-

cations including, but not limited to, physical

dimensions, type, strength and material.

Failure to heed this warning can lead to pre-

mature failures, product damage, personal

injury of death.

GENERAL HAZARD INFORMATION

· Read, understand and follow all instructions on

the machine and in the manuals before attempt-

ing to operate. Keep all manuals in a safe place

for future reference and for ordering replacement

parts.

· Familiarize yourself with all controls in a safe

environment before operation. Know how to stop

the machine and disengage the controls quickly.

· Never allow minors to operate this machine.

· Never allow anyone who has not had proper

instruction to operate this machine.

· Keep bystanders, children and pets away from

the machine and work area.

·Never allow anyone to ride on this machine.

· Never transport cargo, tools or wood on this

machine.

· Keep the operator zone and adjacent area clear

for safe, secure footing.

· Use the machine in daylight or under good

articial lighting.

· Use this machine for its intended purpose only,

deviation from the machines capabilities could

damage the equipment and cause injury or

death.

· Engine exhaust contains products of combus-

tion which can be harmful to your health. Always

start and operate the engine in a well ventilated

area. If you are in an enclosed area, vent the

exhaust to the outside.

800-610-4101 • ActionRental.com

Safety Section

Safety Section 9

Printed in U.S.A.

Safety Section

Safety Section 9

Printed in U.S.A.

PERSONAL PROTECTIVE EQUIPMENT (PPE)

Head protection must conform to ANSI Z89.1

and DO NOT wear under chin strapping while

operating or within the operation area of the

Horizontal Grinder.

Eye protection must conform to ANSI Z87.1 and

be the wrap around style. Always wear the eye

protection when operating or working within the

operational area of the machine.

Hearing Protection- Plug type ear protection

or full ear coverage devices (muff type) shall be

worn at all times when operating or within the

operational area of the machine.

Gloves- When operating or handling brush

within the operational area of the Horizontal

Grinder, loose tting gloves are the only gloves

that should be worn. DO NOT wear gauntlet or

strapped gloves.

Clothing Protection- Clothes must be close

tting, but not restrictive of movement. DO NOT

wear loose tting clothes, jewelry or long dan-

gling clothing; i.e. neckties, long belts or chains.

Hooded sweat shirts may be worn only if the

hood is tightly drawn around the face with

drawstrings tucked into the outer garment when

not in use. If working near trafc, wear reective

clothing.

Shoes- (Foot Protection)- Always over the ankle

work boots with skid resistant soles.

Breathing Protection- When breathing protec-

tion is required the use of paper masks that can

tear away if caught or entangled in material or

machine must be worn.

FLYING DEBRIS

Do not allow anyone to stand in front or directly

behind the machine. Flying debris could be

thrown past guards and injure bystanders if

they are in these areas.

PRESSURIZED AIR AND WATER

Pressurized air and/or water can cause

debris and/or hot water to be blown out. This

could result in personal injury.

When pressurized air and/or pressurized water is

used for cleaning, wear protective clothing, pro-

tective shoes, and eye protection. Eye protec-

tion includes goggles or a protective face shield.

The maximum air pressure for cleaning purposes

must be reduced to 205 kPa (30 psi) when the

nozzle is deadheaded and the nozzle is used

with an effective chip deector and personal

protective equipment. The maximum water

pressure for cleaning purposes must be below

275kPa (40 psi).

TRAPPED PRESSURE

Pressure can be trapped in a hydraulic system.

Releasing trapped pressure can cause sudden

machine movement or attachment movement.

Use caution if you disconnect hydraulic lines of

ttings. High pressure oil that is released can

cause a hose to whip. High pressure oil that is

released can cause oil to spray. Fluid penetra-

tion can cause serious injury and possible

death.

FLUID PENETRATION

Pressure can be trapped in the hydraulic circuit

long after the engine has been stopped. The

pressure can cause hydraulic uid or items such

as pipe plugs to escape rapidly if the pressure is

not relieved correctly.

Do not remove any hydraulic components

or parts until pressure has been relieved or

personal injury may occur. Do not disas-

semble any hydraulic components or parts

until pressure has been relieved or personal

800-610-4101 • ActionRental.com

Safety Section

Safety Section 11

Printed in U.S.A.

Safety Section

Safety Section 11

Printed in U.S.A.

injury may occur. Refer to the Service Manual

for any procedures that are required to relieve

the hydraulic pressure

Always use a board or cardboard when you

check for a leak. Leaking uid that is under

pressure can penetrate body tissue. Fluid

penetration can cause serious injury and

possible death. A pin hole leak can cause

sever injury. If uid is injected into your skin you

must get treatment immediately. Seek treatment

from a doctor that is familiar with this type of

injury.

CONTAINING FLUID SPILLAGE

Care must be taken in order to ensure the uids

are contained during performance of inspection,

maintenance, testing, adjusting and repair of the

equipment. Prepare to collect the uid with suit-

able containers before opening any compartment

or disassembling any component that contains

uids.

· Tools that are suitable for collecting uids and

equipment that is suitable for collecting uids

· Tools that are suitable for containing uids and

equipment that is suitable for containing uids

Obey all local regulations for the disposal of

liquids.

ASBESTOS INFORMATION

Rayco recommends the use of only genuine

Rayco replacement parts. Use the following

guidelines when you handle any replacement

parts that contain asbestos or when you handle

asbestos debris.

Use caution. Avoid inhaling dust that might be

generated when you handle components that

contain asbestos bers.

Inhaling this dust can be hazardous to your

health.

The components that may contain asbestos

bers are brake pads, brake bands, lining materi-

al, clutch plates, and some gaskets. The asbes-

tos that is used in these components is usually

bound in a resin or sealed in some way. Normal

handling is not hazardous unless airborne dust

that contains asbestos is generated.

If dust that may contain asbestos is present,

there are several guidelines that should be fol-

lowed:

· Never use compressed air for cleaning.

· Avoid brushing materials that contain asbestos.

· Avoid grinding materials that contain asbestos.

· Use a wet method in order to clean up asbes-

tos material.

· A vacuum cleaner that is equipped with a high

efciency particulate air lter (HEPA) can also

be used.

· Use exhaust ventilation on permanent machin-

ing jobs.

· Wear an approved respirator if there is no

other way to control the dust.

· Comply with applicable rules and regulations

for the work place, In the United States, refer to

Occupational Safety and Health Administration

(OSHA) requirements.

· Obey environmental regulations for the dis-

posal of asbestos.

· Stay away from areas that might have asbes-

tos particles in the air

DISPOSE OF WASTE PROPERLY

Improperly disposing of waste can threaten the

environment. Potentially harmful uids should

be disposed of according to local regulations.

Always use leak proof containers when you drain

uids. Do not pour waste onto the ground, down

a drain, or into any source of water.

CRUSHING PREVENTION AND CUTTING

PREVENTION

Support the equipment properly before you

perform any work or maintenance beneath that

equipment. Do not depend on the hydraulic

cylinders to hold up the equipment. Equipment

can fall if a control is moved, or if a hydraulic line

breaks.

Do not perform any work until you have read

and followed the proper “Lock-Out / Tag-Out”

procedures.

Do not work beneath the cab of the machine un-

less the cab is properly supported.

Unless you are instructed otherwise, never at-

tempt adjustments while the machine is moving

or while the engine is running.

Never jump across the starter solenoid termi-

nals in order to start the engine. Unexpected

machine movement could result.

800-610-4101 • ActionRental.com

Safety Section

Safety Section 11

Printed in U.S.A.

Safety Section

Safety Section 11

Printed in U.S.A.

Whenever there are equipment control linkages,

the clearance in the linkage area will change with

the movement of the equipment or the machine.

Stay clear of areas that may have a sudden

change in clearance with machine movement or

equipment movement.

Avoid contact with the rotating feed wheel, cutter

wheel and rotor.

Always shut-off the engine and wait for all

moving parts, belts, fans, rotors, discs, cutting

wheels (etc.) to come to a complete stop before

opening access covers and/or guards.

Stay clear of all rotating and moving parts. A

moving belt, pulley, sprocket and chain can

suddenly pull a limb into them causing loss or

severe injury.

If it is necessary to remove guards in order to

perform maintenance, always install the guards

after the maintenance is performed.

Keep objects away from moving fan blades. The

fan blade will throw or cut objects.

Do not use a kinked wire cable or a frayed wire

cable. Wear gloves when you handle wire cable.

When you strike a retainer pin with force, the

retainer pin can y out. The loose retainer pin

can injure personnel. Make sure that the area

is clear of people when you strike a retainer pin.

To avoid injury to your eyes, wear protective

glasses when you strike a retainer pin.

If equipment is unhitched from the tow vehicle for

operation, always block the wheels and support

the tongue weight with blocking to prevent unin-

tended movement. Do not use only the jackstand

to support the tongue while in operation.

BURN PREVENTION

Do not touch any part of an operating engine.

Allow the engine, radiator, exhaust and hydrau-

lic reservoir to cool before any maintenance is

performed. Relieve all pressure in the air system,

oil system, lubrication system, fuel system, and/

or in the cooling system before any lines, ttings

or related items are disconnected.

In addition, avoid contact with other related hot

engine parts such as exhaust manifolds, turbo-

chargers and mufers.

External exhaust parts become very hot during

operation. Paper, cloth, and wooden materials

could ignite if they come in contact with these

parts.

COOLANT

When the engine is at operating temperature, the

engine coolant is hot. The coolant is also under

pressure. The radiator and all lines to the heat-

ers or to the engine contain hot coolant.

Any contact with hot coolant or with steam

can cause severe burns. Allow cooling system

components to cool before the cooling system is

drained.

800-610-4101 • ActionRental.com

Safety Section

Safety Section 13

Printed in U.S.A.

Safety Section

Safety Section 13

Printed in U.S.A.

Check the coolant level only after the engine has

been stopped.

Ensure that the ller cap is cool before removing

the ller cap. The ller cap must be cool enough

to touch with a bare hand. Remove the ller cap

slowly in order to relieve pressure.

Cooling system conditioner contains alkali. Alkali

can cause personal injury. Do not allow alkali

to contact the skin, the eyes or the mouth.

OILS

Hot oil and hot components can cause personal

injury. Do not allow hot oil to contact the skin.

Also, do not allow hot components to contact

the skin.

Remove the hydraulic tank ller cap only after

the engine has been stopped. The ller cap

must be cool enough to touch with a bare hand.

Follow the standard procedure in this manual in

order to remove the hydraulic tank ller cap.

BATTERIES

Electrolyte is an acid. Electrolyte can cause

personal injury. Do not allow electrolyte to

contact the skin or the eyes. Always wear

protective glasses for servicing batteries. Wash

hands after touching the batteries and connec-

tors. Use of gloves is recommended.

TIRES

Tire explosion can result if the following proce-

dures are not followed:

• Check for and maintain correct tire pressure.

Do not inate the tires above the recommended

pressure.

• Replace any wheel with cuts, bubbles, or dam-

aged rims.

• Do not weld or heat the wheel assembly. Heat-

ing will increase tire pressure.

FIRE PREVENTION AND EXPLOSION

PREVENTION

All fuels, most lubricants, and some coolant

mixtures are ammable.

Flammable uids that are leaking or spilled onto

hot surfaces or onto electrical components can

cause a re. Fire may cause personal injury and

property damage.

Remove all ammable materials such as fuel,

oil, and debris from the machine. Do not allow

any ammable materials to accumulate on the

machine. Serious personal injury can occur

when fuel or oil is spilled on yourself or your

clothes, which can ignite.

Store fuels and lubricants in properly marked

containers away from unauthorized persons.

Store oily rags and any ammable materials in

protective containers. Do not smoke in areas

that are used for storing ammable materials.

Do not operate the machine near any ame.

Extinguish all cigarettes, cigars, pipes and other

sources of ignition.

Exhaust shields (if equipped) protect hot exhaust

components from oil spray or fuel spray in case

of a break in a line, in a hose, or in a seal. Ex-

haust shields must be installed correctly.

Do not weld on lines or on tanks that contain

ammable uids. Do not ame cut lines or

tanks that contain ammable uid. Clean any

such lines or tanks thoroughly with a nonam-

mable solvent prior to welding or ame cutting.

Check all electrical wires daily. Repair any wires

that are loose or frayed before you operate the

machine. Clean all electrical connections and

tighten all electrical connections.

Dust that is generated from repairing nonmetallic

hoods or non metallic fenders can be ammable

and/or explosive. Repair such components in a

well ventilated area away from open ames or

sparks.

Inspect all lines and hoses for wear or for dete-

rioration. The hoses must be properly routed.

The lines and the hoses must have adequate

800-610-4101 • ActionRental.com

Safety Section

Safety Section 13

Printed in U.S.A.

Safety Section

Safety Section 13

Printed in U.S.A.

support and secure clamps. Tighten all connec-

tions to the recommended torque. Leaks can

cause res.

Use caution when you are refueling a machine.

Do not smoke while you are refueling a

machine. Do not refuel a machine near open

ames or sparks. Always stop the engine

before refueling. Fill the fuel tank outdoors.

Gases from a battery can explode. Keep any

open ames or sparks away from the top of

a battery. Do not smoke in battery charging

areas.

Never check the battery charge by placing a

metal object across the terminal posts. Use a

voltmeter or a hydrometer.

Improper jumper cable connections can cause

an explosion that can result in injury. Refer to

the Operation Section of this manual for specic

instructions.

Do not charge a frozen battery. This may

cause an explosion.

ETHER STARTING FLUID

Ether is ammable and poisonous.

Use ether in well ventilated areas. Do not

smoke while you are replacing an ether cylin-

der or while you are using an ether spray.

Do not store ether cylinders in living areas or

in the operator compartment of a machine. Do

not store ether cylinders in direct sunlight or in

temperatures above 49 °C (120 °F). Keep ether

cylinders away from open ames or sparks.

Dispose of used ether cylinders properly. Do not

puncture an ether cylinder. Keep ether cylinders

away from unauthorized personnel.

Do not spray ether into an engine if the ma-

chine is equipped with a thermal starting aid

for cold weather starting.

LINES, TUBES AND HOSES

Do not bend high pressure lines. Do not strike

high pressure lines. Do not install any lines that

are bent or damaged.

Repair any lines that are loose or damaged.

Leaks can cause res. Consult your Rayco

dealer for repair or for replacement parts.

Check lines, tubes and hoses carefully. Do not

use your bare hand to check for leaks. Use a

board or cardboard to check for leaks. Tighten

all connections to the recommended torque.

Replace the parts if any of the following condi-

tions are present:

• End ttings are damaged or leaking

• Outer coverings are chafed or cut.

• Wires are exposed.

• Outer coverings are ballooning.

• Flexible part of the hoses are kinked.

• Outer covers have embedded armoring.

• End ttings are displaced. Make sure that all

clamps, guards, and heat shields are installed

correctly. During machine operation, this will

help to prevent vibration, rubbing against other

parts, and excessive hear.

FIRE EXTINGUISHER

Make sure that a re extinguisher is available.

Be familiar with the operation of the re extin-

guisher. Inspect the re extinguisher and service

the re extinguisher regularly. Obey the recom-

mendations on the instruction plate.

FIRE EXTINGUISHER LOCATION

Make sure that a re extinguisher is on the

machine. Make sure that you are familiar with

the operation of the re extinguisher. Inspect the

re extinguisher and service the re extinguisher.

Obey the recommendations on the instruction

plate.

Mount the re extinguisher in an easily accessi-

ble place on the machine, for crawlers mount on

the left side of the cab behind the seat. Consult

your Rayco dealer for the proper procedure of

mounting the re extinguisher.

800-610-4101 • ActionRental.com

Safety Section

Safety Section 15

Printed in U.S.A.

Safety Section

Safety Section 15

Printed in U.S.A.

ELECTRICAL STORM INJURY

PREVENTION

When lightning is striking in the vicinity of the

machine, the operator should never attempt the

following procedures:

• Mount the machine.

• Dismount the machine.

If you are in the operator’s CAB during an electri-

cal storm, stay in the operator’s CAB. If you are

on the ground during an electrical storm, stay

away from the vicinity of the machine!

WHILE OPERATING THE MACHINE

All personnel using this Machine must be trained

in the operation, safety and maintenance repair

procedures. Careless use of this Equipment

could result in serious injury or even death.

ALL PROCEDURES IN THE SAFETY AND

OPERATION SECTIONS OF THIS MANUAL

MUST BE READ AND UNDERSTOOD BEFORE

STARTING THIS MACHINE.

• All operators must be wearing the proper Per-

sonal Protective Equipment before attempting to

start and operate this machine.

• Do not allow children or other spectators to

standby and watch the machine in operation.

• Familiarize yourself with all of the controls in a

safe environment before starting to work with this

machine.

• Always have more than one person at the job

site. If an accident occurs, someone is there to

assist or obtain help.

• Never operate or allow someone to operate

the machine while under the inuence of alcohol,

drugs, or any medication that could affect the

operator’s performance and concentration. Main-

tain a drug-free work place.

• Always operate this machine with all safety

equipment in place and working. Make sure all

controls are properly adjusted for safe operation.

• Do not change the engine governor settings or

overspeed the engine. The governor controls the

maximum safe operating speed of the engine

• Never leave this machine unattended with the

engine running.

• Use only your hand to operate the controls.

Never use a foot, knee, rope or any extension

device.

• Never hand-feed this machine for any reason.

• Contact with moving parts, belts or rotating

cutter wheels can kill, injure or dismember.

• Turn off engine and wait for all movement to

stop before working on this machine. Lock-out/

Tag Out all controls.

• If equipped, the Emergency Stop buttons must

be operating properly. These should each be

checked and veried to shut down the engine by

the operator prior to performing any work.

CAUTION! FLYING DEBRIS! NEVER stand or

allow anyone else to be directly in front of the In-

Feed conveyor or directly behind the discharge

conveyor!

• Stay away from the discharge chute while the

rotor is turning. Material being discharged can

cause severe injury, blindness or death.

• Always operate this machine from the operator

area. Never stand directly in front or in back of

machine as ying objects could be thrown during

operation.

• Never move this machine, or make adjust-

ments or repairs, while the engine is running.

WHILE SERVICING AND PERFORMING

MAINTENANCE ON THE MACHINE

• ALWAYS Block the wheels to prevent unin-

tended movement.

• Adhere to your LOCK-OUT/TAG-OUT proce-

dure when performing maintenance or repairs to

this machine. Locking and tagging out equipment

safeguards those working on equipment from

being injured by its unexpected energized or

releasing stored energy.

• To prevent res, clean debris and chaff from

the engine and mufer areas.

• Periodically check that all nuts and bolts, hose

clamps, and hydraulic ttings are tight.

• When removing the fuel cap, unscrew it slowly,

and hold it rmly. The cap may otherwise be

thrown due to pressure buildup caused by an

increase in temperature.

• For your safety, repair or replace all damaged

or worn parts immediately. Replacement parts

which are authorized by Rayco are the only parts

which should be used for repair or replacement

on this machine.

Altering this equipment, or using this equipment

in such a way as to circumvent its design capa-

bilities and capacities, could result in serious in-

jury or fatality and WILL VOID THE WARRANTY.

800-610-4101 • ActionRental.com

Safety Section

Safety Section 15

Printed in U.S.A.

Safety Section

Safety Section 15

Printed in U.S.A.

• Do not alter this machine in any manner. Al-

terations such as attaching a rope to the control

bar may result in personal injury or death.

NEVER remove the cap from the hydraulic tank

or reservoir while the Horizontal Grinder is run-

ning. Hot oil under pressure will cause injury.

• Relieve hydraulic system pressure before

repairing or adjusting ttings, hoses, tubing, or

other system components.

BEFORE STARTING ENGINE

Start the engine only from the operator compart-

ment. Never short across the starter terminate

or across the batteries. Shorting could damage

the electrical system by bypassing the engine

neutral start system.

Inspect the condition of the seat belt (if

equipped) and of the mounting hardware.

Replace any parts that are worn or damaged.

Regardless of appearance, replace the seat belt

after three years of use. Do not use a seat belt

extension on a retractable seat belt.

Adjust the seat so that full pedal travel can be

achieved with the operator’s back against the

back of the seat.

Make sure that the machine is equipped with

a lighting system that is adequate for the job

conditions. Make sure that all machine lights are

working properly.

Before you start the engine and before you move

the machine, make sure that no one is under-

neath the machine, around the machine, or on

the machine. Make sure that the area is free of

personnel.

VISIBILITY INFORMATION

Before you start the machine, perform a walk-

around inspection in order to ensure that there

are no hazards around the machine.

While the machine is in operation, constantly

survey the area around the machine in order to

identify potential hazards as hazards become

visible around the machine.

Your machine may be equipped with visual

aids. Some examples of visual aids are Closed

Circuit Television and mirrors. Before operat-

ing the machine, ensure that the visual aids are

in proper working condition and that the visual

aids are clean. Adjust the visual aids using the

procedures that are located in this Operation and

Maintenance manual.

It may not be possible to provide direct visibil-

ity on large machines to all areas around the

machine. Appropriate job site organization is

required in order to minimize hazards that are

caused by restricted visibility. Job site organiza-

tion is a collection of rules and procedures that

coordinates machines and people that work

together in the same area. Examples of job site

organization include the following:

• Safety instructions

• Controlled patterns of machine movement and

vehicle movement

• Workers that direct trafc to move when it is

safe

• Restricted areas

• Operator training

• Warning symbols or warning signs on machines

or on vehicles

• A system of communication

• Communication between workers and opera-

tors prior to approaching the machine

Modications of the machine conguration by the

user that result in a restriction of visibility shall be

evaluated.

ENGINE STARTING

If a warning tag is attached to the start switch or

to the controls, do not start the engine. Also, do

not move any controls.

Move all hydraulic controls to the NEUTRAL

position before you start the engine.

Diesel engine exhaust contains products of

combustion which can be harmful to your health.

Always start the engine in a well ventilated area.

Always operate the engine in a well ventilated

area. If you are in an enclosed area, vent the

exhaust to the outside.

800-610-4101 • ActionRental.com

Safety Section

Safety Section 17

Printed in U.S.A.

Safety Section

Safety Section 17

Printed in U.S.A.

BEFORE OPERATION

Video tapes and safety information are avail-

able in English for this machine. A list of some

of the material is available in the Operation and

Maintenance Manual, “Reference Material”.

Consult your Rayco dealer in order to obtain

copies of the material. The information should

be reviewed by every person that operates the

machine.

Clear all personnel from the machine and from

the area.

Clear all obstacles from the path of the machine.

Beware of hazards such as wires, ditches, etc.

Make sure that all windows are clean. Secure

all doors in the closed position. Secure the win-

dows in the open position or in the shut position.

Make sure that the machine horn, the backup

alarm and all other warning devices are working

properly.

Fasten the seat belt securely (if equipped).

Lower the armrest.

OPERATION

Only operate the machine controls when the

engine is running. Do not leave the operators

station while machine is running.

Before you move the machine, you must be

certain that no one will be endangered.

While you operate the machine and the work tool

slowly in an open area, check for proper opera-

tion of all controls and all protective devices.

Do not allow riders on the machine.

Note any needed repairs during machine opera-

tion. Report any needed repairs.

Use only Rayco Approved Work Tools on this

machine. Obey all the lift restrictions. Refer to

Operation and Maintenance Manual, “Rayco Ap-

proved Work Tools” for the approved work tools

and the lift restriction information.

If equipped, carry work tools low. Lower the

lift arms fully. Tilt back the work tool in order to

keep the work tool off of the ground. Do not go

close to the edge of a cliff, an excavation, or an

overhang.

If the machine begins to sideslip downward on a

grade, immediately remove the load and turn the

machine downhill.

Avoid any conditions that can lead to tipping

the machine. The machine can tip when you

work on hills, on banks and on slopes. Also, the

machine can tip when you cross ditches, ridges

or other unexpected obstacles.

Avoid operating the machine across the slope.

When possible, operate the machine up the

slopes and down the slopes.

Maintain control of the machine. Do not over-

load the machine beyond the machine capacity.

Never straddle a wire cable. Never allow per-

sonnel to straddle a wire cable.

Know the maximum dimensions of your machine.

If equipped with a Rollover Protection Structure

(ROPS), always keep the ROPS installed during

machine operation.

Observe all applicable local government regula-

tions when you use this machine.

PARKING

Park on a level surface. If you must park on a

grade, chock the machine.

1. Move the joystick control slowly to the

NEUTRAL position in order to stop the machine.

2. Move the throttle control lever to the LOW

IDLE position.

3. Lower all implements (if equipped) so that the

work tool implement rests rmly on the ground.

4. Move the hydraulic controls to the NEUTRAL

position.

5. Turn the engine start switch key to OFF posi-

tion and remove the key.

6. Disconnect the operator restraint devices (if

equipped) and exit the machine.

7. Block the wheels (if equipped), and set manu-

al brake (if equipped) to prevent movement.

SLOPE OPERATION

Machines that are operating safely in various ap-

plications depend on these criteria: the machine

model, conguration, machine maintenance, op-

erating speed of the machine, conditions of the

terrain, uid levels, and tire ination pressures.

The most important criteria are the skill and judg-

ment of the operation.

A well trained operator that follows the instruc-

tions in the Operation and Maintenance Manual

has the greatest impact on stability. Operator

training provides a person with the following

abilities: observation of working and environmen-

tal conditions, feel for the machine, identication

800-610-4101 • ActionRental.com

Safety Section

Safety Section 17

Printed in U.S.A.

Safety Section

Safety Section 17

Printed in U.S.A.

of potential hazards, and operating the machine

safely by making appropriate decisions.

When you work on side hills and when you work

on slopes, consider the following important

points:

· Speed of travel – At higher speeds, forces of

inertia tend to make the machine less stable.

· Roughness of terrain or surface – The machine

may be less stable with uneven terrain.

· Direction of travel – Avoid operation the

machine across the slope. When possible, oper-

ate the machine up the slopes and operate the

machine down the slopes.

- Place the heaviest end of the machine uphill

when you are working on an incline.

· Mounted equipment – Balance of the machine

may be impeded by the following components:

equipment that is mounted on the machine,

machine conguration, weights, and counter-

weights.

· Nature of surface – Ground that has been

newly lled with earth may collapse from the

weight of the machine.

· Surface material – Rocks and moisture of

the surface material may drastically affect the

machine’s traction and machine’s stability.

Rocky surfaces may promote side slipping of the

machine.

· Slippage due to excessive loads – This may

cause downhill tracks or downhill tires to dig into

the ground, which will increase the angle of the

machine.

· Width of tracks or tires – Narrower tracks or

narrower tires further increase the digging into

the ground which causes the machine to be less

stable.

· Implements attached to the machine hitch or

drawbar – This may decrease the weight on the

uphill tracks. This may also decrease the weight

on the uphill tires. The decreased weight will

cause the machine to be less stable.

· Height of the working load of the machine –

When the working loads are in higher positions,

the stability of the machine is reduced.

· Operated equipment – Be aware of perfor-

mance features of the equipment in operation

and the effects on machine stability.

· Operating techniques – Keep all attachments

or pulled loads low to the ground for optimum

stability.

· Machine systems have limitations on slopes

– Slopes can affect the proper function and

operation of the various machine systems.

These machine systems are needed for machine

control on slopes.

· Note: Safe operation on steep slopes may

require special machine maintenance. Excellent

skill of the operator and proper equipment for

specic applications are also required. Consult

the Operation and Maintenance Manual sec-

tions for the proper uid level requirements and

intended machine use.

WORK TOOL OPTIONS- ATTACHMENTS

Only use work tools that are approved by Rayco

for use on Rayco machines. Refer to the Opera-

tion and Maintenance Manual, Rayco options”.

If you are in doubt about the compatibility of a

particular work tool with your machine, consult

your Rayco dealer.

Make sure that all necessary guarding is in place

on the host machine and on the work tool.

If equipped, keep all windows and doors closed

on the machine.

Always wear protective glasses. Always wear

the protective equipment that is recommended

in the work tool’s operation manual. Wear any

other protective equipment that is required for

the operating environment.

To prevent personnel from being struck by ying

objects, ensure that all personnel are out of the

work area.

While you are performing any maintenance, any

testing, or any adjustments to the machine, stay

clear of the following areas: cutting edges, pinch-

ing surfaces, and crushing surfaces.

EQUIPMENT LOWERING WITH ENGINE

STOPPED

Before lowering any equipment with the engine

stopped, clear the area around the equipment

of all personnel. The procedure to use will vary

with the type of equipment to be lowered. Keep

in mind this system use a high pressure uid to

raise or lower equipment. The procedure will

cause high pressure hydraulic oil to be released

in order to lower the equipment. Wear appropri-

ate personal protective equipment and follow

the established procedure in the Operation and

Maintenance Manual,

800-610-4101 • ActionRental.com

Safety Section

Safety Section 19

Printed in U.S.A.

Safety Section

Safety Section 19

Printed in U.S.A.

SOUND LEVEL INFORMATION

The operator Equivalent Sound Pressure Level

is used to measure a work cycle sound exposure

level

Hearing protection may be needed when the

machine is operated with an open operator

station for extended periods in a noisy environ-

ment. Hearing protection may be needed when

the machine is operated with a cab that is not

properly maintained or when the doors and

windows are open for extended periods or in a

noisy environment.

VIBRATION DATA INFORMATION CONCERN-

ING HAND/ARM VIBRATION LEVEL

When the machine is operated according to the

intended use, the hand/arm vibration of this ma-

chine is rated by meter per second squared.

Note: Vibration levels are inuenced by many

different parameters listed below.

• Operator training, behavior, mode, and stress

• Job site organization, preparation, environment,

weather and material

• Machine type, quality of the seat, quality of the

suspension system, attachments, and condition

of the equipment.

GUIDELINES FOR REDUCING VIBRATION

LEVELS ON EQUIPMENT

Properly adjust machines. Properly maintain

machines. Operate machines smoothly. Main-

tain the conditions of the terrain. The following

guidelines can help reduce the whole body

vibration level:

1. Use the right type and size of machine, equip-

ment, and attachments.

2. Maintain machines according to the manufac-

turer’s recommendations.

a. Tire pressures

b. Brake and steering systems

c. Controls, hydraulic system and linkages

3. Keep the terrain in good condition.

a. Remove any large rocks or obstacles.

b. Fill any ditches and holes.

c. Provide machines and schedule time in order

to maintain the conditions of the terrain.

4. Use a seat that meets “ISO 7096”. Keep the

seat maintained and adjusted.

a. Adjust the seat and suspension for the

weight and the size of the operator.

b. Inspect and maintain the seat suspension

and adjustment mechanisms.

5. Perform the following operations smoothly.

a. Steer

b. Brake

c. Accelerate

d. Shift the gears

6. Move the attachments smoothly.

7. Adjust the machine speed and the route in

order to minimize the vibration level.

a. Drive around obstacles and rough terrain.

b. Slow down when it is necessary to go over

rough terrain.

8. Minimize vibrations for a long work cycle or a

long travel distance.

a. Haul the machines between workplaces.

9. Less operator comfort may be caused by

other risk factors. The following guidelines can

be effective in order to provide better operator

comfort:

a. Adjust the seat and adjust the controls in order

to achieve good posture.

b. Adjust the mirrors in order to minimize

twisted posture.

c. Provide breaks in order to reduce long

periods of sitting.

d. Avoid jumping from the cab.

e. Minimize repeated handling of loads and

lifting of loads.

f. Minimize any shocks and impacts during

sports and leisure activities.

GUARDS (OPERATOR PROTECTION)

There are different types of guards that are

used to protect the operator. The machine and

the machine application determines the type of

guard that should be used.

A daily inspection of the guards is required

in order to check for structures that are bent,

cracked or loose. Never operate a machine with

a damaged structure.

The operator becomes exposed to a hazard-

ous situation if the machine is used improperly

or if poor operating techniques are used. This

situation can occur even though a machine is

800-610-4101 • ActionRental.com

Safety Section

Safety Section 19

Printed in U.S.A.

Safety Section

Safety Section 19

Printed in U.S.A.

equipment with an appropriate protective guard.

Follow the established operating procedures that

are recommended for your machine.

PRECAUTIONS FOR WELDING ON FRAME

WITH ENGINE/MACHINE ELECTRONIC

CONTROL UNIT (ECU)

Important: ALWAYS disconnect Electronic Con-

trol Unit (ECU) connectors and engine control

system-to-machine ground before welding on

engine or machine.

High currents or electro-static discharge in

electronic components from welding may cause

permanent damage.

SAFETY DECALS

The safety decals located on this machine

contain useful and important information which

will help you to operate your machine safely. The

complete decal kit and location of each decal

is given in the “Parts” manual. For your protec-

tion, familiarize yourself with each label until you

completely understand the warning intended. Do

not violate any such warnings!

Keep all decals in place and in good condition:

• Use soap and water to keep decals clean. DO

NOT use mineral spirits, abrasive cleaners or

other similar cleaners which will damage the

decals.

• Replace any damaged or missing decals. Be-

fore attaching decals, the surface temperature of

the metal must be at least 40 degrees. The metal

should also be clean and dry before attaching

the decal.

• If a machine component to which a decal is at-

tached is replaced, be sure to replace the decal

as well.

• Replacement decals may be purchased from

Rayco Mfg or your Rayco dealer.

ROLLOVER PROTECTIVE STRUCTURE

(ROPS), FALLING OBJECT PROJEC-

TIVE STRUCTURE (FOPS) OR TIP OVER

PROTECTION STRUCTURE (TOPS)

The TOPS/FOPS Structure (if equipped) on your

machine is specically designed, tested and

certied for that machine. Any alteration or any

modication to the ROPS/FOPS Structure could

weaken the structure. This places the operator

into an unprotected environment. Modica-

tions or attachments that cause the machine

to exceed the weight that is stamped on the

certication plate also place the operator into

an unprotected environment. Excessive weight

may inhibit the brake performance, the steering

performance and the ROPS. The protection

that is offered by the ROPS/FOPS Structure will

be impaired if the ROPS/FOPS Structure has

structural damage. Damage to the structure

can be caused by an overturn, a falling object, a

collision, etc.

Do not mount items (re extinguishers, rst aid

kits, work lights, etc.) by welding brackets to the

ROPS/FOPS Structure or by drilling holes in the

ROPS/FOPS Structure.

Welding brackets or drilling holes in the ROPS/

FOPS Structures can weaken the structures.

Consult your Rayco dealer for mounting guide-

lines.

The Top Over Protection Structure (TOPS) is

another type of guard that is used on crawl-

ers. This structure protects the operator in the

even of a tip over. The same guidelines for the

inspection, the maintenance and the modication

of the ROPS/FOPS Structure are required for the

Top Over Protection Structure.

OTHER GUARDS (IF EQUIPPED)

Protection from ying object and/or falling

objects is required for special applications. Log-

ging applications and demolition applications are

two examples that require special protection.

A front guard needs to be installed when a work

tool that creates ying objects is used. Mesh

front guards that are approved by Rayco or

polycarbonate front guards that are approved

by Rayco are available for machines with a

cab or an open canopy. On machines that are

equipped with cabs, the windshield should also

be closed. Safety glasses are recommended

when ying hazards exist for machines with cabs

and machines with open canopies.

If the work material extends above the cab, top

guards and front guards should be used.

Additional guards may be required for specic

applications or work tools. The Operation and

Maintenance Manual for your machine or your

work tool will provide specic requirements for

the guards. Consult your Rayco dealer for ad-

ditional information.

800-610-4101 • ActionRental.com

Safety Section

Safety Section 21

Printed in U.S.A.

Safety Section

Safety Section 21

Printed in U.S.A.

LOCK-OUT / TAG-OUT GUIDELINES

Always practice lock out tag out procedures when working on this machine.

Locking and tagging out equipment safeguards those working on the equipment from being injured by

its unexpected energized or releasing stored energy. This section summarizes the applicable require-

ments for lockout/ tag out procedures, and its intent to comply with OSHA regulations.

LOCK OUT PROCEDURE

a. All affected persons are to be notied that the

equipment will be off and locked out.

b. All energy sources for the equipment should

be identied.

c. The equipment shall be shut off or otherwise

deenergized, being careful to de-energize all en-

ergy sources. This includes all valves, switches,

breakers, or other controls that supplies energy

to the equipment. In case of mechanical energy,

a block may be used to stop the release of

stored energy.

d. A lock is to be placed on each energy source

disconnect or energy release block.

1. The lock is to be placed directly on the equip-

ment if provided with an integral locking device.

2. If there is no integral lockout device on the

equipment, securely attach an independently

manufactured lockout device on the equipment

and then place the lock on the lockout device.

3. If none of the above are possible, use the tag

out procedure.

e. A tag to be secured to the lock indicating that

the equipment is not to be energized and who

owns the lock.

f. It should be safely tested and veried that the

lockout does prevent the release of energy.

TAG OUT PROCEDURE

a. This procedure is to be used only if it is not

reasonable to use the lockout procedure.

b. All affected persons are to be notied that the

equipment will be shut off and tagged out.

c. All energy sources for the equipment should

be identied.

d. The equipment shall be shut off or otherwise

de-energized, being careful to de-energize all en-

ergy sources. This includes all valves, switches,

breakers, or other controls that supplies energy

to the equipment. incase of mechanical energy, a

block may be used to stop the release of stored

energy.

e. Securely place a tag on each energy source

disconnect or energy release block.

REMOVAL PROCEDURE

a. Lockout/tag out equipment must be removed

by the worker who placed it.

b. Before the removal of a lockout/tag out the

following must be completed:

1. Removal of all non essential items.

2. Check to see that all workers and bystanders

are located in a safe position.

3. Inform all affected personnel.

c. If a worker who applied the lockout/tag out is

not present, and his supervisor deems it neces-

sary to energize the equipment, the following

must be done by the supervisor.

1. Make all reasonable effort to contact the

worker who placed the tag.

2. Determine the purpose of the lockout/tag out,

and whether it is safe to operate the equipment

in its current condition.

3. Remove all non essential items.

4. Inform all affected personnel.

5. Check to see that all affected persons are

located in a safe position.

6. Inform the worker of the lockout/tag out

removal before the worker starts to work for his/

her next shift.

7. When more than one person works on the

same equipment, multiple lock/tag outs must be

used. Only when all locks are removed can the

equipment be energized.

800-610-4101 • ActionRental.com

Table of contents

Popular Chipper manuals by other brands

Stiga

Stiga BIO MASTER 2200 Operator's manual

Hansa

Hansa C16C Operation, maintenance and safety manual

Hansa

Hansa C40 Operation, maintenance and safety manual

Hyundai

Hyundai HYCH7070-2 user manual

JUN KARRI

JUN KARRI HJ M 10 operating instructions

Wallenstein

Wallenstein BXR Series Operator's manual

SAKAWA

SAKAWA AS15TG manual

AGRI EASE

AGRI EASE BE-WCGF4 Series Operations & parts manual

Victory

Victory BX42S Operator's manual

W-W Grinder

W-W Grinder renegade 250 owner's manual

Farmi Forest

Farmi Forest CH 160 Operation, maintenance and spare parts

Cobra

Cobra CHIP650L owner's manual

Sears

Sears 247.79585 owner's manual

Hansa

Hansa C65RX Operation, maintenance and safety manual

Baker

Baker 1692371 parts manual

Timberwolf

Timberwolf TW 190TFTR manual

Vermeer

Vermeer BC190XL OPERATING STEPS - INSTALLATION MANUAL

Billy Goat

Billy Goat Termite KD512SP Operator owner's manual

Rayco RC6D User manual

Popular Chipper manuals by other brands
