Cobra CHIP650L User manual

1
MODEL: CHIP650L / CHIP650LE (DR-GS-65H)
COBRA PETROL CHIPPER
OWNER’S MANUAL
IMPORTANT
Read safety rules and instructions carefully before operating equipment.
Cobra Garden Machinery
Henton and Chattell Ltd., London Road, Nottingham NG2 3HW UK
www.cobragarden.co.uk

Table of Contents
PART I: General Safety Rules.............................................................................................3
PART II: Familiar with the Wood Chipper............................................................................9
PART III: Operating the Wood Chipper..............................................................................10
PART IV: Maintaining the Wood Chipper...........................................................................12
PART V: Troubleshooting and Parts List ...........................................................................14
PART VI: Warranty & Environment ……………………………………………………………17
PART VII: Assmbly Instructions …………………………………………………………….…18
Conventions used in this manual
WARNING
This indicates a hazardous situation, which, if not avoided, could result in death or
serious injury.
CAUTION
This indicates a hazardous situation, which, if not avoided, could result in minor or
moderate injury.
NOTICE
This information is important in proper using of your machine. Failure to follow this
instruction could result in damage to your machine or property.
Additional Information and Potential Changes
We reserve the right to discontinue, change, and improve its products at any time
without notice or obligation to the purchaser. The descriptions and specifications
contained in this manual were in effect at printing. Equipment described within this
manual may be optional. Some illustrations may not be applicable to your machine.

Part I: General Safety Rules
2
PART I: General Safety Rules
Safety Labels Found on Your Unit

Part I: General Safety Rules
WARNING
Read this Safety & Operating Instructions manual before you use the Wood Chipper.
Become familiar with the operation and service recommendations to ensure the
best performance of your machine.
Intended Purpose:
CAUTION
This machine is designed solely to chip wood and must not be used for any other
purpose.
It should only be used by trained operators who are familiar with the content of this
manual. It is potentially hazardous to fit or use any parts other than your dealer
parts. The company disclaims all liability for the consequences of such use, which
in addition voids the machine warranty.

Part I: General Safety Rules
Before using the wood chipper
NOTICE
A．Operators must be fully trained before using this machine.
B．User Manual is read and understood.
C．Machine is positioned on level ground, all guards are fitted and in good
condition.
D．Blades are in good condition and secure. All blades are sharpened or replaced
in sets.
E．All fasteners are checked for tightness.
F．Only WOODEN materials free of nails etc. are fed into the machine.
G．Fire extinguisher is available on site.
When using the wood chipper
NOTICE
A. Always feed from the side.
B. It is better to have a second trained operator within easy reach of the machine.
C. Maintain strict discipline at all times and service machine at specified periods.
D. Note direction of discharge chute and if necessary note the wind direction to
prevent debris from being blown into highway or where it could affect members
of the public.
E. DO NOT put any part of your body into the in-feed chute while the machine is
running.
F. DO NOT operate the machine whilst under the influence of alcohol or drugs.
G. DO NOT operate inside a building or confined space or Climb on the in-feed
chute.
Protecting Yourself and Those Around You
WARNING
This is a high-powered machine, with moving parts operating with high energy. You
must operate the machine safely. Unsafe operation can create a number of hazards
for you, as well as anyone else in the nearby area. Always take the following
precautions when using this machine:
A. Keep in mind that the operator or user is responsible for accidents or hazards
occurring to other people, their property, and themselves.
B. Always wear protective goggles or safety glasses with side shields while using
the Wood Chipper to protect your eyes from possible thrown debris.
C. Avoid wearing loose clothing or jewelry, which can catch on moving parts.
D. We recommend wearing gloves while using the Wood Chipper. Be sure your
gloves fit properly and do not have loose cuffs or drawstrings.
E. Wear shoes with non-slip treads when using your Wood Chipper. If you have

Part I: General Safety Rules
safety shoes, we recommend wearing them. Do not use the machine while
barefoot or wearing open sandals.
F. Wear long trousers while operating the Wood Chipper.
G. Keep bystanders at least 50 feet away from your work area at all times. Stop the
engine when another person or pet approaches.
Safety for Children and Pets
WARNING
Tragic accidents can occur if the operator is not alert to the presence of children
and pets. Children are often attracted to the machine and the chipping activity.
Never assume that children will remain where you last saw them. Always follow
these precautions:
A. Keep children and pets at least 50 feet from the working area and ensure they
are under the watchful care of a responsible adult.
B. Be alert and turn the machine off if children or pets enter the work area.
C. Never allow children to operate the Wood Chipper.
Safety with Petrol Powered Machines
WARNING
Petrol is a highly flammable liquid. Petrol also gives off flammable vapor that can
be easily ignited and cause a fire or explosion. Never overlook the hazards of petrol.
Always follow these precautions:
A. Never run the engine in an enclosed area or without proper ventilation as the
exhaust from the engine contains carbon monoxide, which is an odorless,
tasteless, and a deadly poisonous gas.
B. Store all fuel and oil in containers specifically designed and approved for this
purpose and keep away from heat and open flame, and out of the reach of
children.
C. Replace rubber fuel lines and grommets when worn or damaged and after 5
years of use.
D. Fill the petrol tank outdoors with the engine off and allow the engine to cool
completely. Don't handle perol if you or anyone nearby is smoking, or if you're
near anything that could cause it to ignite or explode. Reinstall the fuel tank
cap and fuel container cap securely.
E. If you spill petrol, do not attempt to start the engine. Move the machine away
from the area of the spill and avoid creating any source of ignition until the gas
vapors have dissipated. Wipe up any spilled fuel to prevent a fire hazard and
properly dispose of the waste.
F. Allow the engine to cool completely before storing in any enclosure. Never
store a machine that has petrol in the tank, or a fuel container, near an open
flame or spark such as a water heater, space heater, clothes dryer or furnace.

Part I: General Safety Rules
G. Never make adjustments or repairs with the engine running. Shut down the
engine, disconnect the spark plug wire, keeping it away from the spark plug to
prevent accidental starting, wait 5 minutes before making adjustments or
repairs.
H. Never tamper with the engine’s governor setting. The governor controls the
maximum safe operation speed and protects the engine. Over-speeding the
engine is dangerous and will cause damage to the engine and to the other
moving parts of the machine. If required, see your authorized dealer for engine
governor adjustments.
I. Keep combustible substances away from the engine when it is hot.
J. Never cover the machine while the exhaust is still hot.
K. Do not operate the engine with the air cleaner or the carburetor air intake cover
removed. Removal of such parts could create a fire hazard. Do not use
flammable solutions to clean the air filter.
L. The exhaust and engine become very hot and can cause a severe burn; do not
touch.
General Safety
WARNING
Operating this Wood Chipper safely is necessary to prevent or minimize the risk of
death or serious injury. Unsafe operation can create a number of hazards for you.
Always take the following precautions when operating:
A. Your Wood Chipper is a powerful tool, not a plaything. Exercise extreme
caution at all times. The machine is designed to Chip Wood. Do not use it for
any other purpose.
B. Know how to stop the Wood Chipper quickly.
C. Never operate your unit on a slippery, wet, muddy, or icy surface. Exercise
caution to avoid slipping or falling.
D. See manufacturer’s instructions for proper operation and installation of
accessories.
E. Never use the machine without ensuring that all guards and shields are in
place.
F. Never, under any conditions, remove, bend, cut, fit, weld, or otherwise alter
standard parts on the Wood Chipper. This includes all shields and guards.
Modifications to your machine could cause personal injuries and property
damage and will invalid your warranty.
G. If the machine starts to make an unusual noise or vibrate, shut down the engine,
disconnect the spark plug wire, keeping it away from the spark plug to prevent
accidental starting, wait 5 minutes for engine to cool down, then inspect for
damage. Vibration is generally a warning of trouble. Check damaged parts and
clean, repair and/or replace as necessary.

Part I: General Safety Rules
H. Never tamper with safety devices. Check their proper operation regularly.
I. Before performing any maintenance or inspection procedure, shut down the
engine, disconnect the spark plug wire keeping it away from the spark plug to
prevent accidental starting, wait 5 minutes for machine to cool down.
J. Never allow people who are unfamiliar with these instructions to use the Wood
Chipper. Allow only responsible individuals who are familiar with these rules of
safe operation to use your machine.
K. Never overload or attempt to chip woods beyond the manufacturer’s
recommendation. It could result in personal injury or damage to the machine.
L. While using, don't hurry or take things for granted. When in doubt about the
equipment or your surroundings stop the machine and take time to look things
over.
M. Never operate the machine when under the influence of alcohol, drugs, or
medication.
N. Use the machine only in daylight.
O. Stay alert for hidden hazards or traffic.
P. Keep all nuts and bolts tight and keep the equipment in good operating
condition.
A Note to All Users
List of warnings and cautions cannot be all-inclusive. If situations occur that are
not covered by this manual, the operator must apply common sense and operate
this WOOD CHIPPER in a safe manner. Contact the dealers for assistance in your
area.

Part II: Familiar with the Wood Chipper
8
PART II: Familiar with the Wood
Chipper
It may be helpful to familiarize yourself with the controls and features of the Wood
Chipper. If you have any question, please contact the dealers in your area.
TECHNICAL SPECIFICATIONS
Start Recoil Start / Electric Start
Engine 6.5HP four strokes
Power Petrol
Chipper Capacity 3CBM/hour to 5CBM/hour
Wood Diameter Diameter 80mm
Chipper Blade twin reversible blades
Tire 4.10/3.5-4
Overall Height 870mm
Overall Length 555mm
Width 850mm
weight 100/85kgs
Roller Max RPM 2400rpm

Part III: Operating the Wood Chipper
9
PART III: Operating the Wood Chipper
It may be helpful to better familiarize yourself with the features of your Wood
Chipper before beginning the steps outlined in this chapter.
WARNING
A. Read and understand all instructions, safety precautions, and/or warnings
listed in “PART I: General Safety Rules” before operating the WOOD CHIPPER.
If any doubt or question arises about the correct or safe method of performing
anything found in this manual, please contact the dealers in your area.
B. When operating the Wood Chipper, make sure you are standing in the safe
operating area (OPERATOR ZONE). You must stay in the safe operating area at
all times when the ram is in motion (whether extending or retracting). Never
place any part of your body into a position that causes an unsafe operating
condition.
C. Before loading and operating the Wood Chipper, always wear protective gear,
including safety goggles, hearing protection, tight-fitting gloves without draw
strings or loose cuffs, and steel-toed shoes.
D. Knowing the correct and incorrect methods of Chipping woods. Never using an
incorrect or unsafe method.
Starting
1. Position your Wood Chipper on flat, dry ground, and then stop the front wheel
with brake, make sure the machine cannot be moved.
2. Make sure the fuel shut-off valve is in the “ON” position.
3. Move the choke control lever to the “CHOKE” position (should only be needed
if the engine is cold).
4. Move the throttle control lever to the “FAST” position.
5. Recoil Start: Turn the Ignition Switch to the “On” position. Grasp the recoil
starter handle and slowly pull until you feel resistance. Let the cord retract a
little bit then pull the cord rapidly to start the engine. One or two pulls usually
starts the engine.
6. Electric Start (where fitted): Turn and hold the Key in the start position until the
Engine starts then let the Key return to run position.
7. Move the choke control lever (if used for cold engine) slowly back to the “RUN”
position when the engine is running well.
8. If the Wood Chipper has not been running (cold engine), warm up the engine by
running the engine at half throttle for 3 to 4 minutes, then advance the engine
throttle control to the maximum speed.

Part III: Operating the Wood Chipper
Stopping
1. Move the Throttle Lever to IDLE.
2. Recoil Start: Turn the Ignition Switch to the OFF position.
3. Electric Start: Turn the Key to the OFF position.
Operator Zone
Wood Chipping
NOTICE
Woods’ and branches’ diameter should be no bigger than 80mm.
WARNING
Do not place your hands into the chute when loading. This is a very UNSAFE
method and could result in injury to your hands.
Do not reach or step across the rail while the Wood Chipper is running. This is a
very UNSAFE method which could cause personal injury, even death.
When Blocked
If the Roller stops while chipping woods or branches, the engine should be stopped,
and take out the woods which stuck the roller, and then restart the engine, and chip
again.

Part IV: Maintaining The Wood Chipper
11
PART IV: Maintaining the Wood Chipper
Regular maintenance is the way to ensure the best performance and long life of
your machine. Please refer to this manual and the engine manufacturer's user
manual for maintenance procedures.
WARNING
Before performing any maintenance procedure or inspection, stop the engine, wait
five minutes to allow all parts to cool. Disconnect the spark plug wire, keeping it
away from the spark plug. Disconnect the Battery Terminals (Electric start only).
Regular Maintenance Checklist
Procedure
Before Each
Use
Every 3
Hours
Every 25
Hours
Every
100
Hours
Check engine oil level
Δ
Check general equipment
condition
Δ
Check wedge for
sharpness
Δ
Grease surface of slide
rail
Δ
Check belts
Δ
Grease rack and pinion
Δ
Check tire pressure
Δ
Clean engine exterior and
cooling
Δ
Change Engine Oil First time
5hours
Δ
Replace air filter
Δ
Replace spark plug
Δ
Engine Service
Refer to the engine manufacturer’s user manual for engine maintenance.

Part IV: Maintaining The Wood Chipper
Lubrication
NOTICE
All Bearings of your Chipper are sealed units and should have sufficient lubricant
to last the life of your machine with normal use.
Greasing the rack and Pinion
NOTICE
All the rack and pinion should be greased before every use.

14
PART V: Troubleshooting and Parts List
Most problems are easy to fix. Consult the Troubleshooting Table below for
common problems and their solutions. If you continue to experience problems,
contact the dealers in your area.
WARNING
Before performing any maintenance procedure or inspection, stop the engine, wait
five minutes to allow all parts to cool. Disconnect the spark plug wire, keeping it
away from the spark plug.
Troubleshooting Table
SYMPTOM
POSSIBLE CAUSE
The engine won’t start.
(Please refer to the
engine user manual
for engine-specific
procedures.)
Is the ignition switch in the “ON” position?
Is the fuel shut-off valve on?
Are you using fresh, clean petrol? If the petrol is old, change
it. Use a fuel stabilizer if you keep petrol longer than 30 days.

Is the spark plug clean? If the spark plug is dirty or cracked,
change it. If it’s oily, leave it out, hold a rag over the plug hole
and pull the recoil cord several times to blow out any oil in the
cylinder, then wipe off the plug and reinsert it.
The engine lacks
power
or is not running
smoothly.
(Please refer to the
engine user manual
for engine-specific
procedures.)
Check that the Throttle Lever is in the “Run” position.
Is the air filter clean? If it’s dir
ty, change it following the
procedure in the engine manufacturer’s owner’s manual.
Is the spark plug clean? If it’s fouled or cracked, change it. If
it’s oily, leave it out, hold a rag over the plug hole and pull
your recoil cord several times to blow out
any oil in the
cylinder, then wipe off the plug and reinsert it.
Are you using fresh, clean unleaded petrol
? If it’s old,
change it. Use a fuel stabilizer if you keep petrol longer than
30 days.
Does your engine have the right amount of clean oil? If it’s
dirty, change it following the procedure in the engine
manufacturer’s owner’s manual.
Check the oil level and adjust as needed.
Engine smokes.
(Please refer to the
engine user manual
for engine-specific
Check the oil level and adjust as needed.
Check the air filter and clean or replace if needed.
You may be using the wrong oil—
too light for the
temperature. Refer to your Engine Owner’s Manual for
detailed information.

15
procedures.) Clean the cooling fins if they’re dirty.
Operator Lever
Snapping out of gear
or not staying in gear.

Lever not all the way forward when rack comes under full
load. Push lever quicker and more forcefully into the full
forward position.
Ram has been overloaded at lower part of face. Check gear
for straightness.
Machine does not
seem
to have full chipping
power.
The belts may be too loose and slipping. Adjust or replace
belts as needed.
Operator Lever not
engaging rack with
pinion gear.
Clean wood chips or other debris from under rack.
Clean accumulated dirt from frame where carriage assembly
rests against rubber bumpers.

16
Parts View
Ref.No Description Ref.No. Description
1
foundation
18
In-feed
2
Roller
19
Emergency stop fixation
3
Blade
20
Rubber fixation
4
Wheel axis
21
Emergency stop
5
Wheel
22
spring
6
Pulley
23
rubber
7
Belt
24
Switch
8
Belt cover
25
Switch cover
9
Clutch
26
Blade spacing
10
Belt inner cover
27
In-feed extension plate
11
Bearing
28
Handle
12
Bearing fixation plate
29
Switch extension pipe
13
Support foot
31
Limited block
14
Discharge chute
32
Shock pad
15
Chute adjust
33
Bearing cover
16
engine
34
Cotter
17
Engine fixation plate
35
Battery holder
（ELECTRIC
START ONLY)
36
Battery
（
ELECTRIC START
ONLY)
37
Battery box
（ELECTRIC START
ONLY)

17
PART VI: Warranty & Environment
This product is warranted in accordance with legal regulations for a 24 month period
effective from the date of purchase by the first user.
This product will not be covered if used in a commercial application.
This warranty covers all material or production failures, it does not include: defects from
normal wear and tear, parts such as, bearings, brushes, cables, air cleaning elements,
brake pad, clutch disc, tyre, wheel, recoil starter rope, belts, cutter blades, plugs, lubricant
oils and grease or accessories. Damage or defects resulting from abuse, accidents or
alterations, natural fading of painted or plated surfaces, sheet peeling and other natural
deterioration.
Any damage that occurs from the use of non-genuine Cobra parts will not be covered.
We reserve the right to reject any claim where the purchase cannot be verified or when it
is clear that the product was not maintained properly. (Clean ventilation slots, carbon
brushes and serviced regularly)
Expenses incidental to the warranty claim that are not covered;
-Compensation for loss of time, commercial loss or rental costs of substitute product.
-Costs incurred for transportation to and from the dealership.
Any damage that occurs from the following will not be covered; exposure of the product to
smoke and soot, chemical agents, bird droppings or other animal waste, seawater, sea
breeze, salt or other environmental phenomena.
Any damage resulting from operating methods other than those indicated in the owner’s
manual will not be covered.
Your purchase receipt must be kept as proof for date of purchase. Your un-dismantled
product must be returned to your dealer in an acceptably clean state, accompanied by
your proof of purchase.
ENVIRONMENT
Should your machine need replacement after extended use, do not put it in the domestic
waste but dispose of it in an environmentally safe way.

18
PART VII: Assembly Instructions
1. Remove from packing & fitting the wheel axle.
Use a block to support whilst securing and fitting the axle
for the transport wheels.
2. Wheel split pins fitting.
Fit with split pins just tight enough to get split pins in.
3. Fit the front support
Secure the front support frame with the bolts provided.
4. Fit the exit/discharge shoot
The shoot is fitted with 4 bolts – ensure these are fully
tightened and secure.

19
5. Fit the intake hopper
Fit the intake hopper and secure the bolts.
6. Attach the emergency stop wire.
Before operating fit the emergency stop wire. Check the
engine stops correctly before operating in every case.
7. Add oil as per the engine manual
Add engine oil as per the engine manufacturers
instructions. The engine is shipped without oil.

20
EC-DECLARATION OF CONFORMITY
EC Declaration of Conformity
We herewith declare, Cobra Garden Machinery
Hen
ton & Chattell Ltd, London Road, Nottingham
NG2 3HW United Kingdom
That the following machine complies with the appropriate basic safety and health
requirements of the EC Directive based on its design and type, as brought into circulation
by us.
In case of alteration of the machine, not agreed upon by us, this declaration will lose its
validity
Machine Description:
Petrol Wood Chipper
Machine Type:
CHIP650L/CHIP650LE (DR-GS-65H)
Displacement
196cm³
Max. Operating Width: 80mm
Measured sound power level: 108dB(A)
Guaranteed sound power level: 110dB(A)
Notified Body for EC Directive
2000/14/EC Annex V & 2005/88/EC
TÜV SÜD Industrie Service GmbH
Ridlerstraße 57 + 65 80339 München Deutschland
Applicable EC Directives: 2006/42/EC 2014/30/EU
2000/14/EC 97/68/EC
Applicable Harmonized Standards: EN ISO 12100:2010
EN 13683:2003+A2:2011+AC:2013
EN ISO 14120:2015
EN ISO 13857:2008
EN ISO 14982:2009
Authorized Signature/Date/ Place:
Peter J. Chaloner 08/6/2019
Title of Signatory:
Managing Director
Name and address of the person
authorised to compile the technical
file
Cobra Garden Machinery
Henton & Chattell Ltd, London Road, Nottingham
NG2 3HW United Kingdom
