Victory BX42S User manual

Wood Chipper Operator’s Manual
BX42S & BX72R
Please read this manual prior to operation

IMPORTANT
READ THESE INSTRUCTIONS BEFORE INSTALLING AND
USING THIS IMPLEMENT

1 INTRODUCTION
Congratulations on your choice of a
equipment has been designed and
landscaping industry.
3 Point Hitch Wood Chipper to compliment your operation. This
manufactured to meet the needs of a discerning timber or
Safe, efficient and trouble free operation of your Wood Chipper requires that you and anyone else who
will be using or maintaining the chipper, read and understand the Safety, Operation, Maintenance
Trouble Shooting information contained within the Operator's Manual.
BX32
BX42/4 0S Hopper BX62/620R Hopper
This manual covers the 3 Point Hitch Wood Chipper BX32, BX42, BX62 and BX92S/R. Use the Table of
Contents or Index as a guide to locate required information.
Keep this manual handy for frequent reference and to pass on to new operators or owners.
OPERATOR ORIENTATION - The directions left, right, front and rear, as mentioned throughout this
manual, are determined when sitting in the tractor driver's seat and facing in the direction of travel.

2 SAFETY
SAFETY ALERT SYMBOL
This Safety Alert symbol means The Safety Alert symbol identifies
ATTENTION! BECOME ALERT! important safety messages on the
YOUR SAFETY IS INVOLVED! TOWNSUNNY 3 Point Hitch Wood
Chipper and in the manual. When
you see this symbol, be alert to
the possibility of personal injury or
death. Follow the instructions in the
safety message.
Why is SAFETY important to you?
3 Big Reasons
SIGNAL WORDS:
Note the use of the signal words DANGER,
WARNING and CAUTION with the safety
messages. The appropriate signal word for
each message has been selected using the
following guide-lines:
Accidents Disable and Kill
Accidents Cost
Accidents Can Be Avoided
DANGER - Indicates an imminently hazardous
situation that, if not avoided, will result
in death or serious injury. This signal
word is to be limited to the most
extreme situations typically for
machine components which, for
functional purposes, cannot be
guarded.
WARNING -Indicates a potentially hazardous
situation that, if not avoided, could
result in death or serious injury, and
includes hazards that are exposed
when guards are removed. It may
also be used to alert against unsafe
practices.
CAUTION -Indicates a potentially hazardous
situation that, if not avoided, may
result in minor or moderate injury. It
may also be used to alert against
unsafe practices.

SAFETY
YOU are responsible for the SAFE operation and
maintenance of your TOWNSUNNY 3 Point Hitch
Wood Chipper. YOU must ensure that you and
anyone else who is going to use, maintain or work
around the 3 Point Hitch Wood Chipper be familiar
with the using and maintenance procedures and
related SAFETY information contained in this
manual. This manual will take you step-by- step
through your working day and alerts you to all
good safety practices that should be used while
using the 3 Point Hitch Wood Chipper.
Remember, YOU are the key to safety. Good safety
practices not only protect you but also the people
around you. Make these practices a working part of
your safety program. Be certain that EVERYONE
using this equipment is familiar with the
recommended using and maintenance procedures
and follows all the safety precautions. Most
accidents can be prevented. Do not risk injury or
death by ignoring good safety practices.
•3 Point Hitch Wood Chipper owners must give
operating instructions to operators or
employees before allowing them to operate
the machine, and at least annually thereafter.
•The most important safety device on this
equipment is a SAFE operator. It is the
operator’s responsibility to read and
understand ALL Safety and Operating
instructions in the manual and to follow these.
Most accidents can be avoided.
•A person who has not read and understood
all using and safety instructions is not
qualified to use the machine. An untrained
operator exposes himself and bystanders to
possible serious injury or death.
•Do not modify the equipment in any way.
Unauthorized modification may impair the
function and/or safety and could affect the
life of the equipment.
•Think SAFETY! Work SAFELY!
2.1 GENERAL SAFETY
1. Read and understand the
Operator’s Manual and
all safety signs before
using, maintaining,
adjusting or cleaning the
3 Point Hitch Wood Chipper.
2. Have a first-aid kit
available for use should the
need arise and know how
to use it.
3. Have a fire extinguisher
available for use should the
need arise and know how
to use it.
4. Do not allow riders.
5. Wear appropriate
protective gear. This
list includes but is
not limited to:
- A hard hat
- Protective
shoes with slip
resistant soles
- Protective glasses,
goggles or face shield
- Heavy gloves
- Wet weather gear
- Hearing Protection
- Respirator or filter mask
6. Install and secure all
guards before starting.
7. Wear suitable ear protection
for prolonged exposure to
excessive noise.
8. Turn machine off, stop and
disable engine, remove ignition key and
place in your pocket, set park brake and wait
for all moving parts to stop before servicing,
adjusting, repairing or unplugging.
9. Clear the area of people, especially small
children, before using the unit.
10. Review safety related items annually with all
personnel who will operating or maintaining
the 3 Point Hitch Wood Chipper.

2.2 EQUIPMENT SAFETY GUIDELINES
1. Safety of the operator and bystanders is one
of the main concerns in designing and
developing equipment. However, every year
many accidents occur which could have been
avoided by a few seconds of thought and a
more careful approach to handling
equipment. You, the operator, can avoid
many accidents by observing the following
precautions in this section. To avoid personal
injury or death, study the following
precautions and insist those working with you,
or for you to follow them.
2. In order to provide a better view, certain
photographs or illustrations in this manual
may show an assembly with a safety shield
removed. However, equipment should never
be used in this condition. Keep all shields in
place. If shield removal becomes necessary
for repairs, replace the shield prior to use.
3. Replace any safety sign or instruction sign
that is not readable or is missing. Location of
such safety signs is indicated in this manual.
4. Never use alcoholic beverages or drugs which
can hinder alertness or coordination while
using this equipment. Consult your doctor
about using this machine while taking
prescription medications.
5. Under no circumstances should young
children be allowed to work with this
equipment. Do not allow persons to use or
assemble this unit until they have read this
manual and have developed a thorough
understanding of the safety precautions
and of how it works. Review the safety
instructions with all users annually.
6. This equipment is dangerous to children and
persons unfamiliar with its operation. The
operator should be a responsible, properly
trained and physically able person familiar
with machinery and trained in this equipment's
operations. If the elderly are assisting with
work, their physical limitations need to be
recognized and accommodated.
7. Never exceed the limits of a piece of
machinery. If its ability to do a job, or to do so
safely, is in question - DON'T TRY IT.
8. Do not modify the equipment in any way. Un-
authorized modification may result in serious
injury or death and may impair the function
and life of the equipment.
9. In addition to the design and configuration of this
implement, including Safety Signs and Safety
Equipment, hazard control and accident
prevention are dependent upon the awareness,
concern, prudence, and proper training of
personnel involved in the operation, transport,
maintenance, and storage of the machine. Refer
also to Safety Messages and operation
instruction in each of the appropriate sections of
the tractor and machine manuals. Pay close
attention to the Safety Signs affixed to the tractor
and the machine.

2.3 SAFETY TRAINING
1. Safety is a primary concern in the design
and manufacture of our products.
Unfortunately, our efforts to provide safe
equipment can be wiped out by a single
careless act of an operator or bystander.
2. In addition to the design and configuration of
equipment, hazard control and accident
prevention are dependent upon the
awareness, concern, prudence and proper
training of personnel involved in the operation,
transport, maintenance and storage of this
equipment.
3. It has been said, "The best
safety feature is an
informed, careful operator."
We ask you to be that kind
of an operator. It is the
operator's responsibility to read and under-
stand ALL Safety and Using instructions in the
manual and to follow these. Accidents can be
avoided.
4. Working with unfamiliar equipment can
lead to careless injuries. Read this manual
before assembly or using, to acquaint
yourself with the machine. If this machine
is used by any person other than yourself,
or is loaned or rented, it is the machine
owner's responsibility to make certain that
the operator, prior to using:
a. Reads and understands the
operator's manuals.
b. Is instructed in safe and proper use.
5. Know your controls and how to stop tractor and
machine quickly in an emergency. Read this
manual and the one provided with tractor.
6. Train all new personnel and review
instructions frequently with existing workers.
Be certain only a properly trained and
physically able person will use the machinery.
A person who has not read and understood
all using and safety instructions is not
qualified to use the machine. An untrained
operator exposes himself and bystanders to
possible serious in- jury or death. If the elderly
are assisting with the work, their physical
limitations need to be recognized and
accommodated.
2.4 SAFETY SIGNS
1. Keep safety signs clean and legible at
all times.
2. Replace safety signs that are missing or have
become illegible.
3. Replaced parts that displayed a safety
sign should also display the current sign.
4. Safety signs displayed in Section 3 each
have a part number in the lower right hand
corner. Use this part number when ordering
replacement parts.
5. Safety signs are available from your
authorized Distributor or Dealer
Parts Department or the factory.
How to Install Safety Signs:
•Be sure that the installation area is clean
and dry.
•Be sure temperature is above 50°F (10°C).
•Determine exact position before you
remove the backing paper.
•Remove the smallest portion of the
split backing paper.
•Align the sign over the specified area and
carefully press the small portion with the
ex-posed sticky backing in place.
•Slowly peel back the remaining paper and
carefully smooth the remaining portion of
the sign in place.
•Small air pockets can be pierced with a
pin and smoothed out using the piece of
sign backing paper.

2.5 PREPARATION
1. Never use the machine until you have read
and completely understand this manual, the
tractor Operator's Manual and each of the
Safety Messages found on the safety signs on
the tractor and machine.
2. Personal pro-
tection equip-
ment including
hard hat, safety
glasses, safety
shoes, and
gloves are rec-
ommended dur-
ing assembly,
installation, operation, adjustment, maintain-
ing, repairing, removal, cleaning, or moving the
unit. Do not allow long hair, loose fitting
clothing or jewellery to be around equipment.
3. PROLONGED EXPOSURE
TO LOUD NOISE MAY
CAUSE PERMANENT
HEARING LOSS!
Power equipment with or
without equipment attached
can often be noisy enough
to cause permanent, partial
hearing loss. We recommend that you wear
hearing protection on a full-time basis if the
noise in the Operator's position exceeds 80db.
Noise over 85db on a long-term basis can cause
severe hearing loss. Noise over 90db adjacent
to the Operator over a long-term ba-sis may
cause permanent, total hearing loss. NOTE:
Hearing loss from loud noise (from tractors,
chain saws, radios, and other such sources
close to the ear) is cumulative over a lifetime
without hope of natural recovery.
4. Clear working area of stones, branches or
hidden obstacles that might be hooked or
snagged, causing injury or damage.
5. Use only in daylight or good artificial light.
6. Be sure machine is properly mounted,
adjust-ed and in good operating condition.
7. Ensure that all safety shielding and safety
signs are properly installed and in good
condi-tion.
2.6 MAINTENANCE SAFETY
1. Good maintenance is your responsibility.
Poor maintenance is an invitation to trouble.
2. Follow good shop practices.
- Keep service
area clean
and dry.
- Be sure electrical
outlets and tools
are properly
grounded.
- Use adequate
light for the job
at hand.
3. Make sure there is
plenty of ventilation. Never operate the en-
gine of the towing vehicle in a closed building.
The exhaust fumes may cause asphyxiation.
4. Before working on this machine, shut off the
engine, set the brake, and turn fuel valve off.
5. Never work under equipment unless it is
blocked securely.
6. Always use personal protection devices such
as eye, hand and hearing protectors, when
performing any service or maintenance
work. Use heavy or leather gloves when
handling blades.
7. Where replacement parts are necessary for
periodic maintenance and servicing, genuine
factory replacement parts must be used to
restore your equipment to original specifica-
tions. The manufacturer will not be responsi-
ble for injuries or damages caused by use of
unapproved parts and/or accessories.
8. A fire extinguisher and first aid kit should be
kept readily
accessible while
performing
main-tenance on
this equipment.
9. Periodically tighten all bolts,
nuts and screws and check that all electrical
and fuel connections are properly secured to
ensure unit is in a safe condition.
10. When completing a maintenance or service
function, make sure all safety shields and
devices are installed before placing unit in
service.

2.7 OPERATING SAFETY
1. Please remember it is important that you read
and heed the safety signs on the 3 Point Hitch
Wood Chipper. Clean or replace all safety signs
if they cannot be clearly read and under-stood.
They are there for your safety, as well as the
safety of others. The safe use of this machine is
strictly up to you, the operator.
2. All things with moving parts are potentially
hazardous. There is no substitute for a cau-
tious, safe-minded operator who recognizes
potential hazards and follows reasonable
safety practices. The manufacturer has
designed this 3 Point Hitch Wood Chipper to
be used with all its safety equipment properly
attached, to minimize the chance of
accidents. Study this manual to make sure
you have all safety equipment attached.
3. Close and secure rotor cover before operat-
ing.
4. Close and secure all guards, deflectors
and shields before starting and operating.
5. Read and understand operator's manual
before starting. Review safety instructions
annually.
6. Personal protection equipment including hear-
ing protection, hard hat, safety glasses, safety
shoes, and gloves are recommended during
assembly, installation, operation, adjustment,
maintaining, repairing, removal, or moving. Do
not allow long hair, loose-fitting clothing, or
jewellery to be around moving parts.
7. Keep hydraulic lines and fittings tight, in good
condition and free of leaks.
8. Never place any part of your body where it
would be in danger if movement should occur
during assembly, installation, operation, main-
tenance, repairing, unplugging or moving.
9. Turn machine off, stop and disable engine,
remove ignition key and place in your pocket,
set park brake and wait for all moving parts
to stop before servicing, adjusting, repairing
or unplugging.
10. Do not run machine inside a closed building
to prevent asphyxiation from engine exhaust.
11. Use care when feeding material into chipper.
Do not send metal, bottles, cans, rocks, glass
or other foreign material into wood chipper. If
foreign material enters chipper, stop
machine, turn engine off and place ignition
key in your pocket and wait for all moving
parts to stop before removing material and/or
unplugging. Inspect machine for damaged or
loose parts before resuming work.
12. Never use alcoholic beverages or drugs
which can hinder alertness or coordination
while operating this equipment. Consult your
doc-tor about operating this machine while
taking prescription medications.
13. Do not allow riders on this machine at any
time. There is no safe place for any riders.
14. Never allow children or unauthorized people
to operate or be around this machine.
15. Do not reach into rotor or feed hopper open-
ings when the engine is running. Install and
secure access covers before starting engine.
16 Keep the working area clean and free of de-
bris to prevent tripping. Operate only on level
ground.
17 Do not point discharge at people, animals or
buildings. Rotor can expel wood chips fast
enough to cause injury.
18. Do not move or transport chipper when
the rotor is turning.
19. Do not exceed a safe travel speed
when transporting.

2.8 HYDRAULIC SAFETY
1. Make sure that all the components in the hy-
draulic system are kept in good condition and
are clean.
2. Before applying pressure to the system,
make sure all components are tight, and that
lines, hoses and couplings are not damaged.
3. Do not attempt any makeshift repairs to the
hydraulic lines, fittings or hoses by using
tapes, clamps or cements. The hydraulic sys-
tem operates under extremely high pressure.
Such repairs will fail suddenly and create a
hazardous and unsafe condition.
4. Wear proper hand and eye
protection when searching
for a high pressure hy-
draulic leak. Use a piece
of wood or cardboard as a
backstop instead of hands
to isolate and identify a
leak.
5. If injured by a concentrated high-pressure
stream of hydraulic fluid, seek medical atten-
tion immediately. Serious infection or toxic
reaction can develop from hydraulic fluid
piercing the skin surface.
6. Relieve pressure on hydraulic system before
maintaining or working on system.
2.9 STORAGE SAFETY
1. Store the unit in an area away from human
activity.
2. Do not children to play on or around the
stored machine.
3. Store the unit in a dry, level area. Support the
frame with planks if required.
2.10 TRANSPORT SAFETY
1. Comply with state and local laws governing
safety and transporting of machinery on
public roads.
2. Check that all the lights, reflectors and other
lighting requirements are installed and in
good working condition.
3. Do not exceed a safe travel speed. Slow
down for rough terrain and cornering.
4. Fold up and secure feed hopper before mov-
ing or transporting.
5. Be sure the machine is hitched positively to
the tractor and a retainer is used through
the mounting pins.
6. Do not drink and drive.
7. Be a safe and courteous driver. Always yield
to oncoming traffic in all situations, including
narrow bridges, intersections, etc. Watch for
traffic when operating near or crossing road-
ways.
8. Never allow riders on the machine.

3 SAFETY SIGN LOCATIONS
The types of safety signs and locations on the equipment are shown in the illustrations that follow. Good
safety requires that you familiarize yourself with the various safety signs, the type of warning and the
area, or particular function related to that area, that requires your SAFETY AWARENESS.
•Think SAFETY! Work SAFELY!
D
AF
B
A
B
Z9400
Z94006
REMEMBER - If safety signs have been damaged, removed, become illegible or parts replaced without
safety signs, new signs must be applied. New safety signs are available from your authorized dealer.

The types of safety signs and locations on the equipment are shown in the illustrations that follow. Good
safety requires that you familiarize yourself with the various safety signs, the type of warning and the
area, or particular function related to that area, that requires your SAFETY AWARENESS.
•Think SAFETY! Work SAFELY!
B
C
DC
H
C
WARNING
HIGH PRESSURE FLUID HAZARD
To prevent serious injury or death from
high-pressure fluid:
•Relieve pressure on system
before repairing or adjusting.
•Wear proper hand and eye protection
when searching for leaks. Use wood
or cardboard instead of hands.
•Keep all components in good repair.
Z9400
REMEMBER - If safety signs have been damaged, removed, become illegible or parts replaced without
safety signs, new signs must be applied. New safety signs are available from your authorized dealer.

The types of safety signs and locations on the equipment are shown in the illustrations that follow. Good
safety requires that you familiarize yourself with the various safety signs, the type of warning and the
area, or particular function related to that area, that requires your SAFETY AWARENESS.
B
B
DD
D
DANGER
E
THROWN OBJECT HAZARD
To prevent serious injury or death from
thrown objects:
• Turn machine off, stop and disable en-
Z940 3
gine, remove ignition key and place in
your pocket, set park brake and wait for
all moving parts to stop before adjusting,
servicing, maintaining, repairin g or un-
plugging.
•Do not direct discharge duct towards
people, animals or prop erty. Always
wear appropriate safety gear. Keep hands
and feet out of discharge openings.
• Keep others away.
Z9400
REMEMBER - If safety signs have been damaged, removed, become illegible or parts replaced without
safety signs, new signs must be applied. New safety signs are available from your authorized dealer.

The types of safety signs and locations on the equipment are shown in the illustrations that follow. Good
safety requires that you familiarize yourself with the various safety signs, the type of warning and the
area, or particular function related to that area, that requires your SAFETY AWARENESS.
D D
B
A
BF
BH
F
REMEMBER - If safety signs have been damaged, removed, become illegible or parts replaced without
safety signs, new signs must be applied. New safety signs are available from your authorized dealer.

The types of safety signs and locations on the equipment are shown in the illustrations that follow. Good
safety requires that you familiarize yourself with the various safety signs, the type of warning and the
area, or particular function related to that area, that requires your SAFETY AWARENESS.
D
A
G
F
H
D
A
E
G
HF
D
AB
H
G
REMEMBER - If safety signs have been damaged, removed, become illegible or parts replaced without
safety signs, new signs must be applied. New safety signs are available from your authorized dealer.

The types of safety signs and locations on the equipment are shown in the illustrations that follow. Good
safety requires that you familiarize yourself with the various safety signs, the type of warning and the
area, or particular function related to that area, that requires your SAFETY AWARENESS.
H
J
H
DANGER
J
DANGER
ROTATING DRIVELINE HAZARD
GUARDS MISSING
CONTACT CAN CAUSE DEATH
DO NOT OPERATE
KEEP AWAY!
DANGER
DO NOT OPERATE WITHOUT:
• ALL DRIVELINE, TRACTOR AND
EQUIPMENT SHIELDS IN PLACE.
• DRIVELINES SECURELY AT-
GUARDS MISSING
TACHED AT BOTH ENDS.
• DRIVELINE SHIELDS THAT TURN
DO NOT OPERATE Z940 3
FREELY ON DRIVELINE.
Z940 0
DANGER
REMEMBER - If safety signs have been damaged, removed, become illegible or parts replaced without
safety signs, new signs must be applied. New safety signs are available from your authorized dealer.

4 ASSEMBLING
The machine comes from the factory in a
shipping configuration. Always use tools
equipment and forklifts of appropriate size and
capacity for the job. Always use 2 men when
lifting, moving and assembling the machine.
When the machine is shipped, follow this proce-
dure when preparing for the customer:
1. Clear the area of bystanders especially small
children before starting.
2. Use a forklift to lift the pallet/machine from the
truck. Carry the load close to the ground.
3. Move the machine to the assembly area. Be
sure there is sufficient clearance to access
the machine from all sides.
BX32
BX42
BX62
Fig. 1 SHIPPING

4. Cut the tie-down straps.
Fig. 2 TIE-DOWNS
5. Lay-out components next to machine.
BX32
BX62
Fig. 3 LAY-OUT

6. Use a forklift to raise and lift the frame.
7. Or alternatively attach a lifting device to
the lifting bracket on top of the frame.
8. Remove pallet and place machine on
the ground.
Forklift
Bracket
Fig. 4 LIFTING
Fig. 5 PALLET REMOVED

9. Release feed hopper transport latch and lower
hopper into the working position. Stow anchor
latch.
Fig. 6 HOPPER TRANSPORT LATCH
10. Tighten anchor bolts to their specified torque.
Fig. 7 ANCHOR BOLTS (TYPICAL)
