RAYSTECH RT-5100S User manual

RT-5100S
Residential ESS Manual
About RT-5100S ESS
RT-5100S can be installed in Parallel, more attention should be paid for the DIP and
address selection following with part 5.3.2.
About this Manual
The Manual is intended for theRT-5100S Residential ESS, the hybrid inverter and any
other equipment is not included.
RAYSTECH (PTY) LTD.

Contents
1 Safety Instructions............................................................................................................................ - 1 -
1.1 Important Safety Instructions................................................................................................ - 1 -
1.2 Warnings in this Document................................................................................................... - 1 -
1.3 Battery handing guide.............................................................................................................- 1 -
1.4 Response to emergency situations......................................................................................- 1 -
1.4.1 Leaking batteries...............................................................................................................- 2 -
1.4.2 Fire ........................................................................................................................................ - 2 -
1.4.3 Wet battery.........................................................................................................................- 2 -
1.4.4 Damaged battery..............................................................................................................- 2 -
1.5 Installers.......................................................................................................................................- 3 -
1.6 Scrap battery..............................................................................................................................- 3 -
1.7 Customer careline.................................................................................................................... - 3 -
2 Product Introduction....................................................................................................................... - 3 -
2.1 Technical data............................................................................................................................- 3 -
2.2 Exploded views of battery......................................................................................................- 4 -
2.3 Indicator and ports...................................................................................................................- 4 -
2.4 Communication interface plat（DVC-A2 voltage）......................................................- 5 -
2.5 How it works.............................................................................................................................. - 5 -
2.6 Features.......................................................................................................................................- 6 -
3 Guidance for disconnection of batteries during shipment................................................... - 7 -
4 Installation Prerequisites................................................................................................................. - 7 -
4.1 Installation location.................................................................................................................. - 7 -
4.2 Installation process...................................................................................................................- 8 -
4.3 Installation materials................................................................................................................ - 8 -
4.4 Tools.............................................................................................................................................- 9 -
4.5 Safety instruments....................................................................................................................- 9 -
4.6 Network cable......................................................................................................................... - 10 -
4.7 Storage......................................................................................................................................- 10 -

5 Battery Installation..........................................................................................................................- 10 -
5.1 Package items......................................................................................................................... - 10 -
5.2 Checks before installation....................................................................................................- 11 -
5.3 Installation the battery.......................................................................................................... - 11 -
5.3.1 Connect with 51.2Vdc Inverter...................................................................................- 11 -
5.3.1.1 Wall mounting............................................................................................ - 11 -
5.3.1.2 Ground installation.................................................................................... - 12 -
5.3.2 Address selection of Master and Slave battery(ies) connection........................- 13 -
5.4 Cable connections..................................................................................................................- 15 -
5.4.1 Cable connection for Parallel connection............................................................... - 16 -
5.4.1.1 Ground installation.................................................................................... - 16 -
5.4.1.2 Wall mounting............................................................................................ - 16 -
6 Configuration.................................................................................................................................. - 17 -
6.1 Configure device WIFI...........................................................................................................- 17 -
6.2 Register your account...........................................................................................................- 17 -
6.3 Settings for CAN /485 bus pins..........................................................................................- 24 -
7 Commissioning............................................................................................................................... - 24 -
7.1 Commissioning battery.........................................................................................................- 24 -
7.2 Shutting down battery.......................................................................................................... - 25 -
8 Troubleshooting............................................................................................................................. - 25 -
9 Firmware Update............................................................................................................................- 26 -
10 RED Declaration of Conformity (DoC)................................................................................... - 31 -

- 1 -
1 Safety Instructions
1.1 Important Safety Instructions
This manual contains important instructions for:
RT-5100S Residential ESS product
This manual must be followed when installing and using this product.
The product is designed and tested in accordance with international safety
requirements IEC 60364, but as with all electrical and electronic equipment, certain
precautions must be observed when installing and/or operating the product. To
reduce the risk of personal injury and ensure the safe installation and operation of
the product, you must carefully read and follow all instructions, cautions and
warnings in this manual.
1.2 Warnings in this Document
A warning describes a hazard to equipment or personnel. It calls attention to a
procedure or practice, which, if not correctly performed or adhered to, could result
in damage to or destruction of part or all of the RAYSTECH equipment and/or
other equipment connected to the RAYSTECH equipment or personal injury.
Symbol
Description
Caution, risk of electric shock
Heavy enough may cause severe injure
Keep the battery away from open flame or ignition sources
Keep the battery away from children
Do not dispose of the product with household waste
Recycling
Read this manual before installation and operation
For safety reasons, installers are responsible for familiarizing themselves with the
contents of this manual and all warnings before performing installation.
1.3 Battery handing guide
Use the battery pack only as directed.
1.4 Response to emergency situations
The RAYSTECH Residential ESS is designed with multiple safety strategies to
prevent hazards resulting from failures. However, RAYSTECH cannot guarantee

- 2 -
their absolute safety for uncertain situations.
1.4.1 Leaking batteries
If the battery pack leaks electrolyte, avoid contact with the leaking liquid or gas.
Electrolyte is corrosive and contact may cause skin irritation and chemical burns. If
one is exposed to the leaked substance, do these actions:
Inhalation: Evacuate the contaminated area, and seek medical attention
immediately.
Eyes contact: Rinse eyes with flowing water for 15 minutes, and seek medical
attention immediately.
Skin contact: Wash the affected area thoroughly with soap and water, and seek
medical attention immediately.
Ingestion: Induce vomiting as soon as possible, and seek medical attention
immediately.
1.4.2 Fire
In case of a fire, make sure that an ABC or carbon dioxide extinguisher is nearby
and does not use water to extinguish the fire.
WARNING
The battery pack may catch fire when heated above 130°C.
If a fire breaks out where the battery is installed, do these actions:
1) Extinguish the fire before the battery catches fire.
2) If the battery has caught fire, do not try to extinguish the fire.
Evacuate people immediately
If the battery catches fire, it will produce poisonous gases. Do not
approach.
1.4.3 Wet battery
If the battery is wet or submerged in water, do not try to access it. Contact
RAYSTECH customer careline or your distributor for technical assistance.
1.4.4 Damaged battery
If the battery damaged, please contract RAYSTECH customer careline or your
distributor for help as soon as possible, because damaged battery is dangerous
and must be handled with extreme caution. Damaged battery is not suit for use
and may pose a danger to people or property. If the battery seems to be damaged,
return it to RAYSTECH or your distributor.
CAUTION
Damaged battery might export electrolyte or flammable gas, so
contact RAYSTECH for advice and information immediately. we will

- 3 -
deal with it within 48h
1.5 Installers
RAYSTECH Energy Storage battery is suggested to be installed by skilled worker or
electrician. A skilled worker is defined as a people who had been trained and
qualified electrician or had all of the following skills and experience:
Knowledge of the functional principles and operation of on-grid energy
Storage systems.
Knowledge of the dangers and risks associated with installing and using
electrical devices and acceptable mitigation methods.
Knowledge of the installation of electrical devices
Knowledge of and adherence to this manual and all safety precautions and
best practices.
1.6 Scrap battery
For scrap battery, please treat with local laws or regulations to recycle or scrap.
1.7 Customer careline
Use the contacts below for technical assistance. This phone numbers is available
only during business hours on weekdays.
Customer careline
[phone]
2 Product Introduction
2.1 Technical data
Model
RT-5100S
Total Energy*
5.1kWh
Usable Energy(d.c)*
4.8kWh
Nominal Charge/Discharge Power
5Kw
Voltage
48V-56Vd.c
Nominal Voltage
51.2Vd.c
Nominal Current
100A
Max. Charge Voltage
56V
Recommended DOD
90%
Operating Condition
Indoor
Operating Temperature（Charge）
0~50℃
Operating Temperature（Discharge）
-10~55℃
Dimensions(mm)
442*500*133

- 4 -
Weight
44±0.5 Kg
Relative Humidity(R H)
20~60%(No condensed water)
Cooling Type
Ambient cooling
Case Material
Metal
Color
White
Installation
Cabinet or Wall Mounting
IP Rating
IP20
Protective Class
I
Max. Number of Parallel
8
Warranty
10Years
Communication
CAN/RS485
Protection Mode
Triple Hardware Protection
Battery Protection
Over-Current/Over-Voltage/Short Circuit/
Under-Voltage/Over-Temperature
Safety Certificate
CE & TUV(IEC 62619, IEC 62040)
Hanrzd Class of Dangerous Goods
9
Transportation
UN38.3
Testing Conditions Based on Temperature 25℃ at The Beginning of Life.
Total Energy/Usable Energy Measured Under Specific Conditions From RAYSTECH 0.2C
CC/CV
2.2 Exploded views of battery
2.3 Indicator and ports

- 5 -
There are two LED indicators on the front of the battery to show its operating
status.
Table 2-1 Designations on the battery
Item
Designation
Definition
1
Running
Battery normally working without fault
2
Fault
Battery is in a warning state, see troubleshooting in Chapter 8
2.4 Communication interface plat（DVC-A2 voltage）
SW1
DIP switch select for CAN or RS485
SW2
Resistance for communication and DIP switch for parallel connection
SW3
Switch for battery’s Address select
SW4 & SW5
Communication interface for battery or master battery with Inverter
Reset
Reset the WIFI or GPPS/GPS module configuration
2.5 How it works

- 6 -
Morning
Afternoon
Optimized self consumption will be
achieved. ESS are used to store the
excess energy produced by PV system.
Extra energy will be fed into the grid
when ESS are fully charged and system
has already meet its load requirement.
Evening
Night
ESS will power the AC load when the
sun sets.
If the ESS capacity is insufficient to meet
self consumption requirement, electricity
will be obtained from the grid.
2.6 Features
The RAYSTECH Residential ESS has following features:
Energy storage unit: This battery is suit for PV solar system compatibility.
Battery management system (BMS): The battery built-in BMS monitor. It
prevents the battery from running outside of the design, limitations. See
Troubleshooting on Chapter 8.
Monitor: The battery BMS built-in with WIFI module, the battery running
information could be seen in mobile phone and computer.

- 7 -
Easy firmware update: The BMS firmware can be updated to the latest version.
See Chapter 9 Firmware Update.
Expandability: The battery capacity can be increased by adding other batteries.
See part 5.4 cable connections.
3 Guidance for disconnection of batteries during shipment
1) Cartons that have been crushed, punctured, or torn in such a way that contents
are revealed shall be set aside in an isolated area and inspected by a skilled
person. If the package is deemed to be not shippable, the contents shall be
promptly collected, segregated, and either the consignor or consignee
contacted.
2) The DC circuit of RAYSTECH Residential ESS has been disconnected before
outgoing.
3) A precautionary label had been affixed to the shipping carton to alert
individuals as to the battery within the package have been disconnected;
otherwise, the battery should not be transported.
4) We have conducted comprehensive tests to ensure the equipment they
distribute around the world is safe for shipping transport. These products shall
be handled with care and immediately inspected if visibly damaged. lf the
cartoon visibly damaged,please contract with RAYSTECH customer careline to
confirm whether the battery could be used safely or not.
4 Installation Prerequisites
4.1 Installation location
Make sure that the installation location meets the following conditions:
The building is designed to withstand earthquakes.
Far away from the sea to avoid salt water and humidity.
The floor is flat and level.
No flammable or explosive materials nearby.
Optimal ambient temperature is between 15℃ and 30°C.

- 8 -
Temperature and humidity stays at a constant level.
Minimal dust and dirt in the area.
No corrosive gases present, including ammonia and acid vapor.
The RAYSTECH Residential ESS is rated at IP20, so the battery could be installed
indoor.
If the ambient temperature is outside the operating range, battery will protect itself
by shutting down. The battery optimal operate temperature is 15°C to 30°C.
Frequent exposure to severe operating condition would exacerbate the
performance and lifetime of the battery.
4.2 Installation process
The battery should be installed according to the following flow chart.
4.3 Installation materials
Following installation materials should be prepared by installers.
Power cable

- 9 -
Data cable
Ground wire
Bipolar external isolator, when two or more battery systems in parallel, each of
them shall have a bipolar isolator.
NOTICE
Make sure that the cross-sectional area of charging cables is 25 to 35
mm2.
A breaker between RAYSTECH battery and inverter was recommended
to install, and the breaker’s min. current should be over 150A or
following with local regulations.
4.4 Tools
To install the battery pack, those following tools are probably required:
Phillips screwdriver
Torque wrench
Cable crimper
Wire clamp
Voltmeter
Tape measure
Drill
Flat-head screwdriver
In order to protect operator and installer’s safety, please select and use suitable
tools and measuring instruments that are certified for precision and accuracy.
4.5 Safety instruments
When dealing with the battery, following safety gears should be equipped. Installers
must meet the relevant requirements of IEC 60364 or the domestic legislation and
other relevant international standards.
Insulated glove
Safety goggles
Safety shoes

- 10 -
4.6 Network cable
If needed, the network cable should be made like this diagram. But the network
cable between battery and Inverter should be made following the definition of
Inverter. If available, use a LAN cable tester to check whether the cable is faulty.
4.7 Storage
If the battery is not to be installed immediately, or removed from operation and
needs to be stored for a long period, please choose an appropriate location to
store it. Instructions for storage are:
Do not stack more than 8 battery boxes.
The temperature of battery stored recommended in the range of -20°C to 25°
C.
Do not expose to water
The ESS box should be upright and not stacked upside down when storing the ESS
box.
If the ESS needs to be stored over 3 months, the DC circuit of battery suggests to
be disconnected. Otherwise, the battery would discharge at a minimum rate and
capacity degrades depended on storage time, the battery self-consumption is less
than 5w. And, if the battery stored over 6 months, it is suggested to connect the
battery with inverter and commission the system.
5 Battery Installation
5.1 Package items
These items are included in the package.

- 11 -
Battery*1
Cardboard*1
User Manual
5.2 Checks before installation
There are a few things to check before installing the battery to ensure that it has no
defects.
Check item 1: Check the battery voltage.
WARNING
If this checking process is executed for any reason
after the battery is fully installed, make sure that the
inverter is turned off or break the connection
between battery and inverter while checking the
battery.
Press and hold the panel button for about 4s and then
release it after the two LED lights on, measure the voltage at
the terminal interface with a voltmeter. If the voltage is lower
than 48 V, do not use the battery and contact RAYSTECH
customer careline or your distributor.
5.3 Installation the battery
NOTICE
The symbol located on the front of battery, For Parallel connection, the
earth wire was recommended to be installed.
5.3.1 Connect with 51.2Vdc Inverter
To prevent the battery from moving, make sure the battery fixed to a wall.
NOTICE
If the battery is installed above the floor or on a platform, make sure
that the wall or platform is capable of supporting the battery’s weight.
5.3.1.1 Wall mounting

- 12 -
1. Determine bracket mounting place
to be fixed using this Positioning
cardboard.
2. Drill holes in the wall for the M8
expansion screw anchors, which
depth should be at least 50 mm.
Tighten the screws to a torque
around 2.5 N∙m.
3. Fasten the battery to bracket, fasten
the holes with M6 screws with
2.0N∙m roughly.
4. Meanwhile, two or four batteries
could be installed by theses brackets.
Note: if more than 4 batteries installed, a cabinet recommended to be selected for
the battery’s stable.
5.3.1.2 Ground installation
Meanwhile, RT-5100S battery also could be installed on floor, the installation step
as following:
1. Fix the bracket to battery’s mounting
holes one by one.

- 13 -
2. If more power and energy needed, 2
to 4 batteries could be installed in
one stack.
3. If the number of batteries at the
range of 5 to 8, a cabinet is
recommended to be selected.
5.3.2 Address selection of Master and Slave battery(ies) connection

- 14 -
WARNING
Please make sure the SW2 DIP switch selected correctly, if the battery
connected in Parallel mode, but select SW2 DIP8 at ON position,
probably lead serious fault even dangerous.
Connected
battery
number
Group
Set of SW2
Address Set
(SW3)
Parallel connect
1
—
13
1
2
Master
13
2
Slave
1
1
3
Master
13
3
Slave 1
0
1
Slave 2
1
2
4
Master
13
4
Slave 1
0
1
Slave 2
0
2
Slave 3
1
3
5
Master
13
5
Slave 1
0
1
Slave 2
0
2
Slave 3
0
3
Slave 4
1
4
6
Master
13
6
Slave 1
0
1

- 15 -
Slave 2
0
2
Slave 3
0
3
Slave 4
0
4
Slave 5
1
5
7
Master
13
7
Slave 1
0
1
Slave 2
0
2
Slave 3
0
3
Slave 4
0
4
Slave 5
0
5
Slave 6
1
6
8
Master
13
8
Slave 1
0
1
Slave 2
0
2
Slave 3
0
3
Slave 4
0
4
Slave 5
0
5
Slave 6
0
6
Slave 7
1
7
5.4 Cable connections
WARNING
Before connecting battery with inverter, please make sure that no

- 16 -
inverter connected or the inverter is turned off.
NOTICE
5.4.1 Cable connection for Parallel connection
5.4.1.1 Ground installation
For parallel installation, please pay
attention on Cable connection, and the
DIP8 of SW2 no need to be changed
and stayed on Initial Factory state.
5.4.1.2 Wall mounting
For wall mounting, the battery
connection number should be less than
4, if more batteries installed, a cabinet is
recommended.

- 17 -
NOTICE
Before two or more batteries installed in parallel, please check the
voltage of each battery and make sure the differences is less than
2.0V.
6 Configuration
DIP switch should be set correctly for proper communication between inverter and
battery.
If parallel connecting multiple batteries, please set the DIP switches as following:
6.1 Configure device WIFI
The RAYSTECH Residential ESS has a built-in WIFI module to use with the
RAYSTECH APP.
The WIFI setting of battery should be as following
6.2 Register your account
6.2.1 Software Overview
6.2.1.1 Summarize
Smart BESS is a data information system
made for users to apply battery
management. It can query the data update
battery configuration key network, fault
