Raytheon HSB L760 User guide

HSB Series
L755 and L760
Fishfinder
Owner’s
Handbook
Document number: 81169_3
Date: November 1st 2000

HSB Series L755 and L760 Fishfinder Owner’s Handbook iii
HSB Series L755 and L760 Fishfinder
Owner’s Handbook
November 2000
SAFETY NOTICES
This equipment must be installed and operated in accordance with the
instructions contained in this manual. Failure to do so can result in personal
injury and/or navigational inaccuracies. In particular:
1.HIGH VOLTAGE. The LCD display unit contains high voltages.
Adjustments require specialized service procedures and tools only available
to qualified service technicians – there are no user serviceable parts or
adjustments.The operator should never removethedisplayunit coveror
attempttoservicetheequipment.
2.NAVIGATIONAID.Thechartplotter unit is only anaid to navigation. Its
accuracycan be affected by many factors,including equipment failure or
defects,environmental conditions,and improper handling or use. It is the
user’s responsibility to exercise common prudence and navigational
judgements. This unitshould notbe relied upon as a substitute for such
prudence and judgement.
RAYTHEONMARINEproductsaresupportedbyanetworkofAuthorized
ServiceRepresentatives.ForinformationonRaytheonproductsandservices,
contact either of the following:
UNITED STATES Raytheon Marine Company
22 Cotton Road, Suite 280
Nashua,NH03063-4219
Telephone: [phone]
[phone]
Fax: [phone]
EUROPE Raytheon Marine Limited
Anchorage Park
Portsmouth
Hampshire PO3 5TD
England
Telephone: [phone]
Fax: [phone]
Copyright © Raytheon Marine Company2000

iv HSB Series L755 and L760 Fishfinder
The technical and graphicalinformation contained in this handbook,to the
bestofourknowledge,wascorrectasitwenttopress.However, theRaytheon
policyofcontinuousimprovementandupdatingmaychangeproduct
specifications without prior notice.Asa result, unavoidable differences
between theproduct and handbook mayoccur fromtime to time, for which
liability cannot be accepted by Raytheon.
Raytheonisaregisteredtrademark ofRaytheonCompany.
SeaTalk is a registered trademark ofRaytheon MarineEurope Limited.
HSB is atrademark ofRaytheon Marine Company.
Pathfinder is a trademark of Raytheon Marine Company.
ThisproductcontainstechnologyprovidedunderlicensebyAcornGroupplc.
The copyright of this intellectual property is acknowledged by Raytheon
MarineCompany,asareAcorn’strademarksandpatents.Acorn’sworldwide
webaddress is http://www.acorn.com.

Preface v
Preface
ThishandbookdescribestheRaytheonHSBSeries L755 andL760LCD
display units. The L755 and L760 are combined fishfinder and chartplotter
devicesintendedforrecreationalpurposes.Thechartplotterunitisintendedas
an aid to navigation and should not be relied upon asa substitute for official
navigationcharts.
Note:The Fishfinder/chartplotter display unit includes acartridge holder as-
sembly which contains two slots for C-MAP NT chart cards.
This handbookcontainsvery importantinformationon the installationand
operation ofyour new equipment. In order to obtainthe bestresults in
operationandperformance,please read thishandbook thoroughly.
Raytheon’s TechnicalServices representatives or your local dealer will be
available to answerany questions you may have.
TFT LCD Displays
The colors of the display may seem to vary when viewedagainst acolored
background or in colored light. This isa perfectly normaleffectthat will be
seen with all color LCD displays.
IncommonwithallThinFilmTransistor (TFT)LCDdisplays,thescreenmay
exhibit a few (less than 20) wrongly illuminated pixels. These may appear as
blackpixelsin alight portionof thescreen, oras colored pixels inblack areas.
CAUTION:
To provide protectionagainst the damaging effects of UV light, itis
advisabletoreplacethesuncoverprovidedwhenthecolorLCDdisplayis
notinuse.
Warranty
ToregisteryourHSBSeriesdisplayunitownership,pleasetakeafewminutes
tofilloutthewarrantyregistrationcardfoundattheendofthishandbook.Itis
veryimportantthatyou completetheownerinformationandreturnthecardto
the factory in order to receive fullwarranty benefits.

vi HSB Series L755 and L760 Fishfinder
EMC Conformance
All Raytheon equipmentand accessories are designed to the bestindustry
standardsfor use inthe recreationalmarine environment.
ThedesignandmanufactureofRaytheonequipmentandaccessoriesconform
to the appropriate Electromagnetic Compatibility (EMC) standards, but
correctinstallationisrequiredtoensurethatperformanceisnotcompromised.

Contents vii
