RCA F20625 User manual

TELEVISION
F20625
20"Stereo
Monitor-Receiver
• High-Performance Video System
➤Dark-Tint, High-Contrast Picture Tube
➤GUIDE Plus+ GOLD1On-Screen
Program Guide
➤Master Touch®Universal Glo-In-The-Dark
Remote
➤Audio/Video Input
• Sound Logic™Audio Leveler
diagonal
1

• Broadcast Stereo with dbx3
Noise Reduction
Improves the clarity and fidelity
of stereo broadcasts by restoring
dynamic range and suppressing
unwanted noise.
• Low-Noise Audio System
Delivers a 60dB signal-to-noise
ratio for spectacular quality sound.
• Second Audio Program
(SAP)
Decodes the second audio
program available on some
broadcasts.
• Separate Bass/Treble
Control
Customize audio sound output
to specific room environment or
personal preference via on-screen
menu adjustment.
• Front-Fired Speaker System
Front-fired full-range frequency
drivers provide excellent imaging
while localizing voices at the
screen.
• Sound Logic™Audio Leveler
When turned on, eliminates the
annoying “blast” of sound during
commercial breaks. Additionally,
soft sounds are amplified, main-
taining a constant volume level.
Picture Remote
Sound
➤Master Touch®Universal
Glo-In-The-Dark Remote
CRK76TE1
Ergonomic design with glo-in-the-
dark buttons provides complete
TV operation plus control of the
primary functions of virtually every
brand of remote-controllable
VCRs and cable boxes, and RCA
Satellite Systems. Also controls
most functions of RCA DVD
Players and select functions of
some brands of audio com-
ponents. Frequently used buttons
glow in the dark, making it easy
to find the correct functions even
at night.
• Adjustable Picture Control
Custom picture settings are just
a button-press away. Adjust and
store Contrast, Color, Tint, Black
Level, and Sharpness settings for
personal picture performance
depending on your own
individual tastes.
➤Dark-Tint, High-Contrast
Picture Tube
Dark glass picture tube delivers
outstanding picture contrast for
blacker blacks, brilliant whites,
and deep rich colors even in
bright room conditions.
• Preferred Picture Presets
Optimize the picture by selecting
the correct setting depending on
the lighting conditions of the
room. Choose between four set-
tings for bright lighting, normal
lighting, dim (soft) lighting, and a
customer-selectable and savable
“personal” setting.
• Deluxe Shielded Tuner
with 181-Channel Tuning
Capability2
Special shielding dramatically
reduces ghosting caused from
off-air pick-up when watching
cable channels. Digitally-controlled
frequency synthesis tuning
system “locks on” to cable and
standard signals with unsurpassed
accuracy.
• High Performance Video
Amplifier
Delivers high resolution and clarity
by extending the video frequency
response. Optimizes performance
from high-resolution sources
such as the RCA Satellite System
and DVD players.
• Dynamic BlackStretch
Circuitry
Extends black levels in bright
scenes to enhance contrast
and detail.
•
Automatically maintains natural
flesh tones and color fidelity
from channel to channel and
scene to scene.
• Adjustable Color Warmth
Customer-selectable color
temperature system allows
for background color balance
adjustment of the picture to
personal preference. Setting
choices are Cool, Warm, or
Normal.
• Contrast/Color Tracking
System
Synchronizes contrast
and color settings to maintain
vibrant images.
High-Performance Video System
Advanced circuitry delivers outstanding picture performance.
F20625

•
Countdown timer returns TV
to original channel, so other
channels can be browsed during
program breaks.
• Auto Tune
After initial setup, just pressing one
component button on the TV’s
remote (either VCR, RCA Satellite
System, cable, or DVD) turns on
both the TV and the component
and also automatically tunes the
TV to the correct viewing channel.
Just one press!
• Picture Memory for Video
Inputs
Custom picture settings are
activated whenever direct video
inputs are selected. Allows tailored
picture performance with each
video source.
• Picture Reset
Instantly returns picture to factory
settings for Color, Tint, Contrast,
Brightness, and Sharpness.
• Advanced Auto Channel
Search
Auto Cable/Air Switch sets tuner
to cable or “off-air” frequencies
during initial setup. Then system
automatically scans for and locks
active channels into channel
memory.
• On-Screen Menu System
On-screen displays make it easy
to adjust more picture, sound, and
convenience features from either
the remote control or the TV front
panel buttons.
• Interactive Setup Menu
Convenient on-screen menu system
automatically steps user through
the initial setup procedures.
• Trilingual On-Screen Display
Allows the on-screen menu system
to be displayed in one of three
languages (English, French, or
Spanish).
• On-Screen Time and
Channel Display
Displays time and channel number
during channel change or at the
press of a button.
• Programmable Timer
System
Convenient scheduling system can
be used in a variety of ways:
–Sleep Timer
Automatically turns off the TV
after a preset time period — for
those times when you drift off to
sleep in front of the television.
–Alarm Timer
Wake up to your favorite morning
show or turn on your television
automatically to catch your
favorite program.
–Scheduling Timer
Since the alarm setting remains in
the TV memory indefinitely, the
TV can be scheduled to turn on
at the same time every day.
•
Assign on-screen characters to easily
identify channels (e.g. NBC, HBO,
ESPN, VH-1).
• Front Panel Lockout
Completely disables front panel
controls to prevent toddlers from
altering settings.
• V-Chip Parental Control
Puts control back into the hands
of the viewer by blocking
unwanted television broadcasts
with NEW U.S. Government
required circuitry. Blocks three
types of programs: regular
television programs, broadcast
movies and unrated programs.
Program rating information is
sent by the broadcaster before
the beginning of each program.
The television will match program
rating to user preference and
block the entire program. User
preference is secured using
a four-digit password.
• Non-Volatile Memory
In case of most power outages,
the picture adjustments and
channel selections are stored in
electronic memory.
• Caption Vision Closed
Caption Capability4
Assists the hearing impaired, helps
children learn to read, and aids in
the teaching of English as a second
language. Built-in Closed Caption
Decoder displays the audio portion
of a program as text on the TV
screen (when program is aired
with the encoded signal).
CC
:30
Convenience
“Command” Buttons
Information
Window
Promotional
Windows
TV
On-Screen
Networks
Guide
Selector
Program
Grids
The Program Guide appears
on your television.
Program Listings and One-Touch
Record...Right through your
remote control!
2 ways to find your programs
➁
GUIDE Plus+ GOLD
1
Interactive Program Guide
Find out what’s on! GUIDE Plus+ GOLD1is a built-in
feature that provides an instant summary of your favorite TV
shows at the touch of a button—yet requires no monthly
fee! The two-day Guide also allows you to view listings up to
48 hours in advance and delivers the capability for One-Touch
Tuning and VCR recording with the press of a button.
Press
Here.
➀And The Benefit
of One-Touch Record
Even if your VCR is flashing 12:00,
GUIDE Plus+ GOLD1can record your favorite
show. Simply highlight the program you
would like to record and press the Record
button on the remote. In the Schedule Menu,
you can choose to record shows once, daily,
or weekly.
Using the directional arrow pads on your remote,
you may scroll through TV listings, or scroll to
future programs. As each channel grid is high-
lighted, the current program appears in the
preview window, and a description is shown to
the right of the window.
The Grid Guide
Want to relax and watch a movie? SORT lists
movies by theme that are on for the next
seven days. SORT can also help you find your
favorite game or sports or children’s programs.
The Sort Guide

TELEVISION
➤Audio/Video Monitor Panel
Color-coded monitor panel
provides direct audio and video
connections for optimum
performance and system flexibility.
Includes audio/video input.
• Back Panel
1 GUIDE Plus+ GOLD is a trademark of Gemstar Development Corporation.
2 Check your cable company’s compatibility requirements.
3 dbx is a registered trademark of Carillon Electronics Corporation.
4 This television receiver provides display of television closed captioning in accordance
with §15.119 of the FCC rules. This television receiver does not support color attributes
of television closed captioning.
VIDEO RL / MONO
AUDIO
CABLE/
ANTENNA
G-LINK
IN
• Limited Warranty
– 90 days for labor charges.
– One year for parts.
– Two years for picture tube.
– See RCA dealer for complete details.
Get more information on
RCA Consumer Electronics Products at www.rca.com
Connections
Specifications
F20625
Screen Size (diagonal) 20"
Finish Black Texture
Cabinet Dimensions 191⁄8" H, 201⁄4" W, 18 7⁄8" D
Approx. Shipping Weight 54 Lbs.
©2000 Thomson Consumer Electronics, Inc.
Form S-F20625
Trademark(s) ® Registered
Marca(s) Registrada(s)
Photos and features subject to change
without notice. Illustration of product finish
may vary from actual color. Screen sizes
measured diagonally.
PC13771
