RCA Scenium PHD50300 User manual

General
Panel Reso
Screen Asp
Capsulated
Contrast Ra
Frequency
H-sync (kHz
V-sync (Hz)-
Video Sign
Video - - - -
Digital TV -
RGB-VGA,
XGA, UXGA
On-Screen
English/Spa
Inputs
Componen
Componen
Componen
DTV/HDTV/
S-Video- - -
Audio - - -
Audio Powe
Communica
Power
120V AC 50
Power Co
595 Watt Ty
Weight
101.3 lbs/4
Regulatory
FCC Class
Warranty
1 Year Limit
Environme
Operating T
Humidity- -
Storage Tem
Storage Hu
Accessorie
Tabletop St
Fixed Wall
Speakers- -
Universal R
Digital Plasma Monitor 50”
50”
PHD50300
Diagonal CinemaScreen
™

PHD50300
SPK50 PLB50
Digital Video Resolution (1365 x 768)
500:1 Typical Panel Contrast Ratio
Plasma Screen CCF Technology
(Capsulated Color Filter1)
160-Degree Viewing Angle
3D-Y/C Digital Comb Filter
Digital TV Mode 720p/1080i
External Speaker Terminals
General
Panel Resolution (Pixels) - - - - - 1365 x 768
Screen Aspect Ratio - - - - - - - - 16:9
Capsulated Color Filter1- - - - - Yes
Contrast Ratio - - - - - - - - - - - - 580 to 1
Frequency
H-sync (kHz)- - - - - - - - - - - - - - 15.6 - 92 Auto,
Step Scan
V-sync (Hz)- - - - - - - - - - - - - - - 50 - 120 Auto,
Step Scan
Video Signal Compatibility
Video - - - - - - - - - - - - - - - - - - NTSC Composite/
S-Video
Digital TV - - - - - - - - - - - - - - - 480i - 480p -
720p - 1080i
RGB-VGA, SVGA,
XGA, UXGA, MAC
On-Screen Display
English/Spanish/French
Inputs
Component Video (Analog) - - - 1 Set RCA/
1 Set BNC
Component Video (Analog) - - - BNC (R,G,B,H/V
sync)/D-Sub 15-Pin
Component Video (Digital) DVI - I 29-Pin
DTV/HDTV/DVD - - - - - - - - - - 1 Set RCA
YPbPr/YCrCb
S-Video- - - - - - - - - - - - - - - - - Mini DIN 4-Pin
Audio - - - - - - - - - - - - - - - - - 3 Pair RCA
(Selectable)
Audio Power - - - - - - - - - - - - - 7W + 7W at 6 ohm
Communication - - - - - - - - - - - RS232 (D-Sub 9-Pin)
Power
120V AC 50/60 Hz
Power Consumption
595 Watt Typical
Weight
101.3 lbs/46.0 kg
Regulatory Compliance
FCC Class B3
Warranty
1 Year Limited
Environmental Considerations
Operating Temperature- - - - - - 0°C to 35°C
Humidity- - - - - - - - - - - - - - - - 20 to 80%
Storage Temperature - - - - - - - Minus 10°C to 50°C
Storage Humidity - - - - - - - - - - 10 to 90%
Accessories
Tabletop Stand - - - - - - - - - - - Optional (PLB50)
Fixed Wall Mount- - - - - - - - - - Included Separate
(PWM42)
Speakers- - - - - - - - - - - - - - - - Optional (SPK50)
Universal Remote - - - - - - - - - - CRK76TUL1
Digital Plasma Monitor 50”
50”
PHD50300
Diagonal CinemaScreen
™
The RCA HD/Digital Receiver adds to the
superior picture quality of plasma.
The optional RCA HD/Digital Receiver has a built-in DIRECTV receiver and is an essential
part of the plasma entertainment experience, providing a wide variety of digital programming
options. Specifically, the DTC100 accepts all local digital programming, as well as local
analog broadcasts and analog cable. When combined with a DSA8900E multi-satellite dish
antenna (sold separately), you’ll have access to over 225 channels of digital-quality entertainment
from DIRECTV and access to DIRECTV®high-definition programming (DIRECTV® programming
sold separately). The DTC100 digital receiver not only puts digital entertainment possibilities
into the plasma picture—it also makes an impact with digital sound capability. The receiver offers
5.1-channel Dolby Digital2Surround Sound capability with up to five full channels and a sixth
low-frequency-effects (subwoofer) channel.
1 Capsulated Color Filter technology is a development
of the NEC Corporation.
2 Dolby Digital is a registered trademark of Dolby Laboratories
Licensing Corp.
3 This model is rated as Class B—it has low EMI radiation
and is suitable for either industrial or consumer use.
Class A models cannot be used for consumer use.
DIRECTV and the Cyclone Design logo are trademarks
of DIRECTV, Inc., a unit of Hughes Electronics Corp.,
and are used with permission.
RCA Multi-Satellite Dish Antenna
(sold separately)
RCA Model DTC100
High-Definition Digital Receiver
(sold separately)
Form S-PHD50300
©2001 Thomson multimedia Inc. Trademark(s) ® Registered Marca(s) Registrada(s)
Photos and features subject to change without notice. Illustration of product finish may vary from actual color.
Screen sizes measured diagonally. Printed in the U.S.A. 3/01 PC15939
rcascenium.com

The Picture
3D Y/C Digital Frame Comb Filter
The ultimate in color separation—this three-
dimensional filter evaluates both current
and future video information, eliminating
dot and edge crawl while providing for
better transitions between scene changes—
resulting in a dramatically enhanced picture.
RCA Scenium PHD50300 Monitor
The monitor is a high-performance
XGA-compatible 50" plasma monitor
ideal for corporate applications
including conference room meeting
support, boardroom presentations, video
conferencing and dynamic signage in
building lobbies and shared areas.
Capsulated Color Filter1Technology
Provides Realistic Color
Capsulated Color Filter1(CCF) technology
improves color response to provide the
most realistic color rendering available in
plasma monitors. CCF technology is a
series of red, green and blue filters bonded
within the panel’s front glass substrate.
CCF optimizes the color spectrum of visible
light emitted from the panel by attenuating
unwanted spectral emissions associated
with the ionization of gas within the
individual pixels. CCF also incorporates
a black matrix that helps the panel absorb
external light, cuts down on reflections
and improves the reproduction of black.
The result is color that is more true to life,
enhanced contrast and an exceptional
screen image.
Professional Color Management Control
The control system complements the
Capsulated Color Filter1technology by
allowing simple and accurate adjustment
of on-screen color temperature settings
through the monitor’s on-screen user
menus. Select one of three preset color
temperatures or “Pro Mode.” Select PM
to set a customized color temperature to
suit your specific application requirements
or personal preferences.
SYNCROSCAN™Conversion Technology
Delivers High-Resolution Image Quality
The SYNCROSCAN™system automatically
delivers high-resolution pixel mapping
from sources up to SXGA resolution.
This high-performance system displays
computer graphics with superior accuracy
and stability. This results in a screen image
with excellent clarity from the highest
resolution sources.
The Sound
Stereo Amplifier
Built-in amplifier enhances stereo
performance and can power optional
left/right or surround speakers.
The Convenience
Advanced On-Screen Menu System
On-screen displays make it easy to adjust
most picture, sound, and convenience
features from either the remote control
or the TV front-panel buttons.
The Remote
Universal Remote Control CRK76TUL1
New ergonomic design and
color-coded buttons provide
complete TV operation plus
control of the primary functions
of virtually every brand of remote-
controllable VCR, satellite system,
and cable box. Also controls
most functions of RCA DVD
players. Frequently-used buttons
illuminate for easier nighttime use.
The Connections
• A/V Inputs Composite/S-Video
• Component Video Input: YPrPb
• HD/PC/RGB Input: Mini D-Sub 15 pin/BNC
• PC Compatibility: VGA, SVGA, XGA, SXGA
The Limited Warranty
• One year for labor charges.
• One year for parts.
• See RCA Scenium dealer for
complete details.
The Dimensions
Understanding Plasma Technology
This RCA Scenium™television monitor is equipped with the ultimate in plasma technology.
The use of plasma, a mixture of rare gases that emulate the energy of the sun, makes it
possible to achieve an image that is infinite in surface and quality.
Trapped between two glass plates and electronically activated, the plasma produces a
controlled energy that is instantaneously transformed into color images by red, green and
blue phosphors. The technique is all the more astonishing when you consider that the layer
of gas is only 100 microns thick—one-tenth of a millimeter!
This RCA Scenium television monitor combines this technology with the unique Capsulated Color
Filter1 process: a grid of colored micro-filters positioned on the screen. The fidelity of the colors is
so high, they are virtually identical to the colors in nature. In fact, they are virtually indistinguishable.
5"
Shown with optional base and speakers.
Screen Dimensions
441⁄2"
331⁄2"
The Accessories
The Ventilation Requirements
The TV can be easily hung on a wall
with the included mounting bracket.*
The ultra-thin design allows big-screen
entertainment in almost any room. The
bracket is designed to allow necessary
ventilation behind the TV.
If an enclosed mounting is desired
(recessed into the wall), please allow
1.5" clearance on each side and
2" clearance on the top and bottom
for proper ventilation.
484⁄5"
11⁄2"
clearance
2" clearance
Wall
Wall
11⁄2"
clearance
301⁄8"
251⁄2"
27⁄8"
303⁄16"
321⁄2"
26.31"
42.63"
484⁄5"
301⁄8"
*Bracket must be securely mounted
to wall studs.
321⁄2"
153⁄4"
41⁄5"
Optional Speakers including matching stands.
Speaker Specifications (Model SPK50):
• Passive radiator design
• 2 - 92 mm diameter
• Impedance 6 ohms
• Maximum input rating 10 watts
33
1
⁄
2
"
153⁄4"

The Picture
3D Y/C Digital Frame Comb Filter
The ultimate in color separation—this three-
dimensional filter evaluates both current
and future video information, eliminating
dot and edge crawl while providing for
better transitions between scene changes—
resulting in a dramatically enhanced picture.
RCA Scenium PHD50300 Monitor
The monitor is a high-performance
XGA-compatible 50" plasma monitor
ideal for corporate applications
including conference room meeting
support, boardroom presentations, video
conferencing and dynamic signage in
building lobbies and shared areas.
Capsulated Color Filter1Technology
Provides Realistic Color
Capsulated Color Filter1(CCF) technology
improves color response to provide the
most realistic color rendering available in
plasma monitors. CCF technology is a
series of red, green and blue filters bonded
within the panel’s front glass substrate.
CCF optimizes the color spectrum of visible
light emitted from the panel by attenuating
unwanted spectral emissions associated
with the ionization of gas within the
individual pixels. CCF also incorporates
a black matrix that helps the panel absorb
external light, cuts down on reflections
and improves the reproduction of black.
The result is color that is more true to life,
enhanced contrast and an exceptional
screen image.
Professional Color Management Control
The control system complements the
Capsulated Color Filter1technology by
allowing simple and accurate adjustment
of on-screen color temperature settings
through the monitor’s on-screen user
menus. Select one of three preset color
temperatures or “Pro Mode.” Select PM
to set a customized color temperature to
suit your specific application requirements
or personal preferences.
SYNCROSCAN™Conversion Technology
Delivers High-Resolution Image Quality
The SYNCROSCAN™system automatically
delivers high-resolution pixel mapping
from sources up to SXGA resolution.
This high-performance system displays
computer graphics with superior accuracy
and stability. This results in a screen image
with excellent clarity from the highest
resolution sources.
The Sound
Stereo Amplifier
Built-in amplifier enhances stereo
performance and can power optional
left/right or surround speakers.
The Convenience
Advanced On-Screen Menu System
On-screen displays make it easy to adjust
most picture, sound, and convenience
features from either the remote control
or the TV front-panel buttons.
The Remote
Universal Remote Control CRK76TUL1
New ergonomic design and
color-coded buttons provide
complete TV operation plus
control of the primary functions
of virtually every brand of remote-
controllable VCR, satellite system,
and cable box. Also controls
most functions of RCA DVD
players. Frequently-used buttons
illuminate for easier nighttime use.
The Connections
• A/V Inputs Composite/S-Video
• Component Video Input: YPrPb
• HD/PC/RGB Input: Mini D-Sub 15 pin/BNC
• PC Compatibility: VGA, SVGA, XGA, SXGA
The Limited Warranty
• One year for labor charges.
• One year for parts.
• See RCA Scenium dealer for
complete details.
The Dimensions
Understanding Plasma Technology
This RCA Scenium™television monitor is equipped with the ultimate in plasma technology.
The use of plasma, a mixture of rare gases that emulate the energy of the sun, makes it
possible to achieve an image that is infinite in surface and quality.
Trapped between two glass plates and electronically activated, the plasma produces a
controlled energy that is instantaneously transformed into color images by red, green and
blue phosphors. The technique is all the more astonishing when you consider that the layer
of gas is only 100 microns thick—one-tenth of a millimeter!
This RCA Scenium television monitor combines this technology with the unique Capsulated Color
Filter1 process: a grid of colored micro-filters positioned on the screen. The fidelity of the colors is
so high, they are virtually identical to the colors in nature. In fact, they are virtually indistinguishable.
5"
Shown with optional base and speakers.
Screen Dimensions
441⁄2"
331⁄2"
The Accessories
The Ventilation Requirements
The TV can be easily hung on a wall
with the included mounting bracket.*
The ultra-thin design allows big-screen
entertainment in almost any room. The
bracket is designed to allow necessary
ventilation behind the TV.
If an enclosed mounting is desired
(recessed into the wall), please allow
1.5" clearance on each side and
2" clearance on the top and bottom
for proper ventilation.
484⁄5"
11⁄2"
clearance
2" clearance
Wall
Wall
11⁄2"
clearance
301⁄8"
251⁄2"
27⁄8"
303⁄16"
321⁄2"
26.31"
42.63"
484⁄5"
301⁄8"
*Bracket must be securely mounted
to wall studs.
321⁄2"
153⁄4"
41⁄5"
Optional Speakers including matching stands.
Speaker Specifications (Model SPK50):
• Passive radiator design
• 2 - 92 mm diameter
• Impedance 6 ohms
• Maximum input rating 10 watts
33
1
⁄
2
"
153⁄4"

The Picture
3D Y/C Digital Frame Comb Filter
The ultimate in color separation—this three-
dimensional filter evaluates both current
and future video information, eliminating
dot and edge crawl while providing for
better transitions between scene changes—
resulting in a dramatically enhanced picture.
RCA Scenium PHD50300 Monitor
The monitor is a high-performance
XGA-compatible 50" plasma monitor
ideal for corporate applications
including conference room meeting
support, boardroom presentations, video
conferencing and dynamic signage in
building lobbies and shared areas.
Capsulated Color Filter1Technology
Provides Realistic Color
Capsulated Color Filter1(CCF) technology
improves color response to provide the
most realistic color rendering available in
plasma monitors. CCF technology is a
series of red, green and blue filters bonded
within the panel’s front glass substrate.
CCF optimizes the color spectrum of visible
light emitted from the panel by attenuating
unwanted spectral emissions associated
with the ionization of gas within the
individual pixels. CCF also incorporates
a black matrix that helps the panel absorb
external light, cuts down on reflections
and improves the reproduction of black.
The result is color that is more true to life,
enhanced contrast and an exceptional
screen image.
Professional Color Management Control
The control system complements the
Capsulated Color Filter1technology by
allowing simple and accurate adjustment
of on-screen color temperature settings
through the monitor’s on-screen user
menus. Select one of three preset color
temperatures or “Pro Mode.” Select PM
to set a customized color temperature to
suit your specific application requirements
or personal preferences.
SYNCROSCAN™Conversion Technology
Delivers High-Resolution Image Quality
The SYNCROSCAN™system automatically
delivers high-resolution pixel mapping
from sources up to SXGA resolution.
This high-performance system displays
computer graphics with superior accuracy
and stability. This results in a screen image
with excellent clarity from the highest
resolution sources.
The Sound
Stereo Amplifier
Built-in amplifier enhances stereo
performance and can power optional
left/right or surround speakers.
The Convenience
Advanced On-Screen Menu System
On-screen displays make it easy to adjust
most picture, sound, and convenience
features from either the remote control
or the TV front-panel buttons.
The Remote
Universal Remote Control CRK76TUL1
New ergonomic design and
color-coded buttons provide
complete TV operation plus
control of the primary functions
of virtually every brand of remote-
controllable VCR, satellite system,
and cable box. Also controls
most functions of RCA DVD
players. Frequently-used buttons
illuminate for easier nighttime use.
The Connections
• A/V Inputs Composite/S-Video
• Component Video Input: YPrPb
• HD/PC/RGB Input: Mini D-Sub 15 pin/BNC
• PC Compatibility: VGA, SVGA, XGA, SXGA
The Limited Warranty
• One year for labor charges.
• One year for parts.
• See RCA Scenium dealer for
complete details.
The Dimensions
Understanding Plasma Technology
This RCA Scenium™television monitor is equipped with the ultimate in plasma technology.
The use of plasma, a mixture of rare gases that emulate the energy of the sun, makes it
possible to achieve an image that is infinite in surface and quality.
Trapped between two glass plates and electronically activated, the plasma produces a
controlled energy that is instantaneously transformed into color images by red, green and
blue phosphors. The technique is all the more astonishing when you consider that the layer
of gas is only 100 microns thick—one-tenth of a millimeter!
This RCA Scenium television monitor combines this technology with the unique Capsulated Color
Filter1 process: a grid of colored micro-filters positioned on the screen. The fidelity of the colors is
so high, they are virtually identical to the colors in nature. In fact, they are virtually indistinguishable.
5"
Shown with optional base and speakers.
Screen Dimensions
441⁄2"
331⁄2"
The Accessories
The Ventilation Requirements
The TV can be easily hung on a wall
with the included mounting bracket.*
The ultra-thin design allows big-screen
entertainment in almost any room. The
bracket is designed to allow necessary
ventilation behind the TV.
If an enclosed mounting is desired
(recessed into the wall), please allow
1.5" clearance on each side and
2" clearance on the top and bottom
for proper ventilation.
484⁄5"
11⁄2"
clearance
2" clearance
Wall
Wall
11⁄2"
clearance
301⁄8"
251⁄2"
27⁄8"
303⁄16"
321⁄2"
26.31"
42.63"
484⁄5"
301⁄8"
*Bracket must be securely mounted
to wall studs.
321⁄2"
153⁄4"
41⁄5"
Optional Speakers including matching stands.
Speaker Specifications (Model SPK50):
• Passive radiator design
• 2 - 92 mm diameter
• Impedance 6 ohms
• Maximum input rating 10 watts
33
1
⁄
2
"
153⁄4"

PHD50300
SPK50 PLB50
Digital Video Resolution (1365 x 768)
500:1 Typical Panel Contrast Ratio
Plasma Screen CCF Technology
(Capsulated Color Filter1)
160-Degree Viewing Angle
3D-Y/C Digital Comb Filter
Digital TV Mode 720p/1080i
External Speaker Terminals
General
Panel Resolution (Pixels) - - - - - 1365 x 768
Screen Aspect Ratio - - - - - - - - 16:9
Capsulated Color Filter1- - - - - Yes
Contrast Ratio - - - - - - - - - - - - 580 to 1
Frequency
H-sync (kHz)- - - - - - - - - - - - - - 15.6 - 92 Auto,
Step Scan
V-sync (Hz)- - - - - - - - - - - - - - - 50 - 120 Auto,
Step Scan
Video Signal Compatibility
Video - - - - - - - - - - - - - - - - - - NTSC Composite/
S-Video
Digital TV - - - - - - - - - - - - - - - 480i - 480p -
720p - 1080i
RGB-VGA, SVGA,
XGA, UXGA, MAC
On-Screen Display
English/Spanish/French
Inputs
Component Video (Analog) - - - 1 Set RCA/
1 Set BNC
Component Video (Analog) - - - BNC (R,G,B,H/V
sync)/D-Sub 15-Pin
Component Video (Digital) DVI - I 29-Pin
DTV/HDTV/DVD - - - - - - - - - - 1 Set RCA
YPbPr/YCrCb
S-Video- - - - - - - - - - - - - - - - - Mini DIN 4-Pin
Audio - - - - - - - - - - - - - - - - - 3 Pair RCA
(Selectable)
Audio Power - - - - - - - - - - - - - 7W + 7W at 6 ohm
Communication - - - - - - - - - - - RS232 (D-Sub 9-Pin)
Power
120V AC 50/60 Hz
Power Consumption
595 Watt Typical
Weight
101.3 lbs/46.0 kg
Regulatory Compliance
FCC Class B3
Warranty
1 Year Limited
Environmental Considerations
Operating Temperature- - - - - - 0°C to 35°C
Humidity- - - - - - - - - - - - - - - - 20 to 80%
Storage Temperature - - - - - - - Minus 10°C to 50°C
Storage Humidity - - - - - - - - - - 10 to 90%
Accessories
Tabletop Stand - - - - - - - - - - - Optional (PLB50)
Fixed Wall Mount- - - - - - - - - - Included Separate
(PWM42)
Speakers- - - - - - - - - - - - - - - - Optional (SPK50)
Universal Remote - - - - - - - - - - CRK76TUL1
Digital Plasma Monitor 50”
50”
PHD50300
Diagonal CinemaScreen
™
The RCA HD/Digital Receiver adds to the
superior picture quality of plasma.
The optional RCA HD/Digital Receiver has a built-in DIRECTV receiver and is an essential
part of the plasma entertainment experience, providing a wide variety of digital programming
options. Specifically, the DTC100 accepts all local digital programming, as well as local
analog broadcasts and analog cable. When combined with a DSA8900E multi-satellite dish
antenna (sold separately), you’ll have access to over 225 channels of digital-quality entertainment
from DIRECTV and access to DIRECTV®high-definition programming (DIRECTV® programming
sold separately). The DTC100 digital receiver not only puts digital entertainment possibilities
into the plasma picture—it also makes an impact with digital sound capability. The receiver offers
5.1-channel Dolby Digital2Surround Sound capability with up to five full channels and a sixth
low-frequency-effects (subwoofer) channel.
1 Capsulated Color Filter technology is a development
of the NEC Corporation.
2 Dolby Digital is a registered trademark of Dolby Laboratories
Licensing Corp.
3 This model is rated as Class B—it has low EMI radiation
and is suitable for either industrial or consumer use.
Class A models cannot be used for consumer use.
DIRECTV and the Cyclone Design logo are trademarks
of DIRECTV, Inc., a unit of Hughes Electronics Corp.,
and are used with permission.
RCA Multi-Satellite Dish Antenna
(sold separately)
RCA Model DTC100
High-Definition Digital Receiver
(sold separately)
Form S-PHD50300
©2001 Thomson multimedia Inc. Trademark(s) ® Registered Marca(s) Registrada(s)
Photos and features subject to change without notice. Illustration of product finish may vary from actual color.
Screen sizes measured diagonally. Printed in the U.S.A. 3/01 PC15939
rcascenium.com
