RCI RPTZ1080-18X+CTP18AH108 User manual

HD IR AHD Intelligent High Speed Dome
User Manual
Thank you for purchasing our products . Please do not hesitate to contact us if there is any question.
Please read this manual careful before installation or application
（Note：This manual is subject to change without notice）

HD IR AHD Intelligent High Speed Dome User Manual
1
Contents
Chapter 1 Introduction
1.1 Product Introduction ………………………………………………………………………………… 6
1.2 Appearance ……………………………………………………………………………………………6
1.3 Functions ………………………………………………………………………………………………6
1.4 Technical Data …………………………………………………………………………………………7
1.5 Short-cut Commands……………………………………………………………………………………8
1.6 Glossary ………………………………………………………………………………………………11
Chapter 2 Precautions to Installation
2.1 Preparation ………………………………………………………………………………………….15
2.2 Precautions to Installation …………………………………………………………………………….15
Chapter 3 Installation
3.1 Packing checking …………………………………………………………………………………….18
3.2 Installation…………………………………………………………………………………………….18
3.3 Dip Switches (DomeAddress, Protocol and Baud Rate) …………………………………………….21
Chapter 4 Installation of Different Brackets
4.1 Dimensions……………………………………………………………………………………………24
4.2 Wall Mount……………………………………………………………………………………………27
4.3 Pending Mount ……………………………………………………………………………………….29
4.4 Corner Adapter ……………………………………………………………………………………….31
4.5 Pole Mount Adapter …………………………………………………………………………………..34
4.6 Parapet Mount Adapter ……………………………………………………………………………… 37
Chapter 5 Operation Guidance
5.1 Wiring ………………………………………………………………………………………………..40
5.2 Protocol and Baud Rate Setting ……………………………………………………………………..40
5.3 Dome Address Setting………………………………………………………………………………..40
5.4 Connect to Power…………………………………………………………………………………….40
5.5 Controller Setting…………………………………………………………………………………….40
5.6 Testing ……………………………………………………………………………………………….40
5.7 Finish Testing………………………………………………………………………………………...41

HD IR AHD Intelligent High Speed Dome User Manual
2
Chapter 6 OSD Menu Operation
6.1 Operation in English OSD
6.1.1 Main Menu ………………………………………………………………………………………….43
6.1.2 Menu Tree (Submenu)……………………………………………………………………………….43
Appendix 1 Lightning and Surge Protection ……………………………………………………………………51
Appendix 2 RS485 BUS Connection ………………………………………………………………………….. 51
Appendix 3 Common Problems and Solutions ………………………………………………………………….53
Note 1: The key “IRIS+” mentioned in this manual is equal to “OPEN”, and “IRIS-“ is equal to “CLOSE”;
“PRESET” is equal to “SET” (i.e., to edit preshot, while” PREVIEW” is equal to “ACK” (i.e., call
preshot); “FOCUS-” is equal to “ FAR”.

HD IR AHD Intelligent High Speed Dome User Manual
3
Safeguards:
This is to assure the right application of this product and to avoid danger or property loss. The precaution measures
are divided into “Warnings” and “Cautions”, as shown in the following picture;
Warnings: Ignorance of Warnings may cause serious injury or death
Cautions: Ignorance of Cautions may cause injury or property loss.
Warning Follow this safe guard to
avoid serious injury or death
Caution Following this precaution to
avoid potential injury or property loss
Warning
1、All the national and regional electrical safety regulations must be strictly followed during the installation and
application of this product.
2、Please use standard power adapter AC24V/3A.
3、Do not connect several devices to one power adapter, as adapter overload may cause over-heat or fire hazard.
4、Please disconnect power during wiring and disassembling. Operation is not allowed when connected to
power.
5、When the product is installed on wall or ceiling, the devices should be firmly fixed.
6. If there is smoke, severe smell or noise in the dome, turn off the power and disconnect the cable immediately,
then contact our after-sales staff.
7. If the product does not work properly, please contact your dealer of our after-sale service center。Never
attempt to disassemble the camera yourself.
（We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.）
Cautions
1、Do not drop the dome or subject it to physical shock, and do not expose it to high electromagnetism radiation.
Avoid the equipment installation on vibrating surface or shocking places(ignorance can damage the
equipment).
2、Do not install the dome in extremely hot( over 60℃)or cold( below-40℃)or damp locations.
3、Indoor domes should be kept away from rain and moisture.
4、Avoid direct contact with the dome cover when opening it, as the acidic sweat of the fingers may erode the

HD IR AHD Intelligent High Speed Dome User Manual
4
surface coating of the dome cover. Scratch on dome cover by hard objects may cause unclear image.
5、Please use a soft and dry to clean inside and outside surfaces of the dome cover, do not use alkaline
detergents.

HD IR AHD Intelligent High Speed Dome User Manual
5
Chapter 1 Introduction
1.1 Product Introduction
1.2 Appearance
1.3 Functions
1.4 Technical Data
1.5 Short-cut Commands
1.6 Glossary

HD IR AHD Intelligent High Speed Dome User Manual
6
1.1 Product Introduction
For this series of dome cameras, the 32-bit ARM processor, built-in zoom lens and the decoder controller are
used together. It’s driven by precise stepper motor, and thus responsive, stable, and trembling-free at any speed.
The excellent performance and complete functions has made it a high-tech security product.
1.2 Appearance
1.3 Functions
lAluminum-alloy housing, 6-inch dome cover, black rotating dome, integrated design
lCeiling-mount, wall mount, pending (indoor/outdoor) bracket available
lPrecise stepper motor driven, smooth and tremble-free rotation, noise-free
l32-bit ARM processor, large storage capacity, higher speed, better performance, higher integration, lower
consumption
lCan restore factory default settings
lSimultaneous zoom and speed limit
lColor/ B/W can be set to be Color, B/W, or Auto
l6 PTZ Pattern：can record all P/T/Z tour
Top external Housing
Infrared light
Side Cover
Connector
Bracket
Down external Housing
Camera module

HD IR AHD Intelligent High Speed Dome User Manual
7
lAutomatic changing of P/T speed: the P/T speed reduces proportionally according to zoom times.
l128 presets, accuracy less than 0.1º（the dome targets a specific location, can be set and changed
l16 presets in each tour: dwell time 1-99 seconds at each preset position settable in OSD menu
lPan 360°endless，Tilt 0---90°
lPan manual speed: 0.1°～1 8 0°/S, Tilt manual speed：0.1°～1 2 0°/ S
lVideo Transmitting Distance 400 m
lSupport coaxitron function
l3 degrees of lightning and surge protection
lWith IP66, CE, FCC and ROHS
1.4 Technical Data
Items Model Name
RPTZ1080-18X+CTP18AH108 RPTZ1080-18X+CTPU18AH108
Sensor IMX222-1/2.9”CMOS IMX322 -- 1/2. 9" CMOS
Effective Pixels 200k Pixels
Min. Illumination Color: 0.2 lux/F1.2 B/W:0.1 lux/F1.2
Optical Zoom
18X
，
f=4.7mm
～
84.6mm
Digital Zoom 12X NO
White Balance AUTO/Outdoor/Indoor/ATW/Manual
AUTO
Resolution 1080P/30 frame; 1080P/25 frame 1080P/30 frame; 1080P/25
frame;720P/30 frame;720P/25 frame
D/N ICR
Processor 32-bit ARM
Synchronous zoom IR lamp zoom in and out synchronously with zoom lens
IR light Source Varical focal IR-Ⅲgeneration
IR Wave Length 850nm
IR Control Auto/Manual
IR life more than 20,000 hours
IR angle 7°～40°and 60°
IR distance 150M
Address 0----255

HD IR AHD Intelligent High Speed Dome User Manual
8
Pan Range 360°Endless
Pan Speed 0.1°/S－180°/S（1-64 degree optional）
Tilt Range 0-----90°
Tilt Speed 0.1°/S－120°/S
OSD Menu English
PATTERN 6 Groups
Preset tour 7 Groups
2-Point Auto Scan Yes
Horizontal
360 °Scan Yes
Preshot 128
Preshot Speed 240°/S
Temperature -30℃-+60℃
Humidity ≤95% No condensation
Communication RS485 BUS ；Coaxitron control
Baud Rate 2400／4800／9600 /19200bps Optional
Input Power AC24V/3A
Consumption 36W
Video Out HD-AHD
Video Transmitting
Distance 400 m
Weight 6.5Kg
Installation Ceiling Mount, Pendant Mount, Bent Pipe etc. (Optional)
Certificates IP66，ROHS，CE，FCC
1.5 Short-cut Commands
PREVIEW
/
PRESET No Functions Remark
PREVIEW
65 Camera Power ON NO
PRESET Camera Power OFF NO

HD IR AHD Intelligent High Speed Dome User Manual
9
PREVIEW
66 BLC ON NO
PRESET BLC OFF NO
PREVIEW
67
PRESET ICR Color
PREVIEW
68 ICR B/W
PRESET Camera Reset NO
PREVIEW
69 Camera menu
PRESET Screen ON /OFF
PREVIEW
70 Digital Zoom ON
PRESET Digital Zoom OFF
PREVIEW
71 Auto Focus
PRESET Manual Focus
PREVIEW
72 Auto Iris NO
PRESET Manual Iris NO
PREVIEW
73 White Balance Auto
PRESET White Balance Manual
NO
PREVIEW
74 Indoor Mode NO
PRESET Outdoor Mode NO
PREVIEW
75 ATW
PRESET one push WB NO
PREVIEW
76 Image Freeze ON NO
PRESET Image Freeze OFF NO
PREVIEW
77 1080I/60 NO
PRESET 720P/60 NO
PREVIEW
78 1080I/50 NO
PRESET 720P/50 NO
PREVIEW
79 1080P/30
PRESET 720P/30
PREVIEW
80 1080P/25
PRESET 720P/25
PREVIEW
81 Home Position in 10
second

HD IR AHD Intelligent High Speed Dome User Manual
10
PRESET Home Position in 30
second
PREVIEW
82
Home Position in 60
second
PRESET Home Position in 120
second
PREVIEW
83
Home Position in 180
second
PRESET Home Position
OFF
PREVIEW
84 Run 2-Point Scan
PRESET
PREVIEW
85 1080P/60 frame Reserved
PRESET 1080P/50 frame Reserved
PREVIEW
86 Reserved
PRESET Reserved
PREVIEW
87
PRESET Set start position of
2-point scan
PREVIEW
88 Reserved
PRESET Reserved
PREVIEW
89 Reserved
PRESET Reserved
PREVIEW
90 2-point scan big circle
mode(﹥180°
PRESET 2-point scan big circle
mode(﹤180°)
PREVIEW
91 Reserved
PRESET Reserved
PREVIEW
92
Run Auto Scan
PRESET Dome information
display
PREVIEW
93 Run 16 preshots
PRESET Restart Press PRESET 93 three times continually
PREVIEW
95 Open OSD Menu

HD IR AHD Intelligent High Speed Dome User Manual
11
PRESET
PREVIEW
96
PRESET
PREVIEW
97 Run 1nd Pattern
PRESET
PREVIEW
98 Run 2rd Pattern
PRESET
PREVIEW
99
PRESET
PREVIEW
100
Run 1st Tour
PRESET Run 2nd Tour
PREVIEW
101
Run 3rd Tour
PRESET Run 4th Tour
PREVIEW
102
Run 5th Tour
PRESET Run 6th Tour
PREVIEW
103
IR light Auto
PRESET IR light ON
PREVIEW
104
IR light OFF
PRESET Reserved
PREVIEW
108
cruise time set
first call+(1---10) preset,and call+108(save standing
time),such as :call+2 one time,and call+108 one
time,so cruise standing time is 2S; call+10 one time,and
call+108 one time,so crusie standing time is 10S
PRESET
PREVIEW
109
Clear Memory Press PREVIEW 109 once，then press PRESET 109
twice，and press PREVIEW 109 once
PRESET
PREVIEW
110
Return to factory
setting
Press PREVIEW 110 once，then press PRESET 110
twice，and press PREVIEW 110 once
PRESET

HD IR AHD Intelligent High Speed Dome User Manual
12
1.6 Glossary
General Address
Address 0 is the general address, which means the controlling devices can control any dome in a system by this
address, no matter what the current dome address is.
Proportional Pan/Tilt Speed
Proportional pan/tilt automatically reduces or increases the pan and tilt speeds in proportion to the amount of
zoom. The dome slows down at a larger amount of zoom, and it speeds up at a small amount of zoom.
AUTO Pan SCAN
The dome rotates horizontally 360º continually at a set speed in the set direction. User can also set the starting
and ending position, between which the camera can move back and forth.
Two-point PAN SCAN
The domes moves horizontally from the starting point to the ending point at a set speed in the set direction.
PRESET (PRESHOT)
Each of the user-definable presets can be programmed to use pan, tilt, camera settings and other settings. When
preset is called, the dome will automatically move to the defined position. User is allowed to add, modify, delete
and call each preset.
PRESET TOUR (Vector Scan)
The dome will moves the continually from the 1st preset to the 16th. If one preset is not set, it skips and moves
directly to the next preset.
IR Cut Filter
The IR cut filter can be set to Auto, Day and Night. In auto mode, the camera is capable of automatically
switching Black & White mode (Night) and Color mode (Day) with regard to environment lightening conditions.
In manual switch mode, user can increase sensitivity in low light conditions by switching to Black & White mode,
while the Color mode is preferred in normal lighting conditions (depends on the camera).
Auto Focus
The auto focus enables the camera to focus automatically to maintain clear video images
User can also press FAR and NEAR to focus. It will resume auto focus when user does P/T/Z controlling.

HD IR AHD Intelligent High Speed Dome User Manual
13
Auto Iris
The auto iris enables the camera to iris automatically to maintain clear video images
User can also press OPEN and CLOSE to focus. It will resume auto iris when user do P/T/Z controlling.
Backlight Compensation
When there is bright light source in the background, the subject will be dark, like a black shadow. Backlight
compensation video gain done either manually or automatically to correct the exposure of subjects that are in front
of a bright light source, avoid unclearness of the target in bright background.

HD IR AHD Intelligent High Speed Dome User Manual
14
Chapter 2 Precautions to Installation
2.1 Preparation
2.2 Precautions to Installation

HD IR AHD Intelligent High Speed Dome User Manual
15
2.1 Preparation
1. Regulations
1）All electrical safety and fire regulations should be strictly followed.
2）Please check if your camera and accessories are all included in the product package, make sure the location is
suitable for installation and application of the dome, as specified in the manual.
2. Location checking
Make sure there is enough space for the dome and accessories in the chose location.
3. Check the supporting strength of the chose location
Make sure the ceiling or wall where the dome will be installed is strong enough to support 4 times of the weight
of domes and its accessories.
4. Preparing of cables
Select video cable according to required transmitting distance. Basic requirements of coaxial cable:
1）75Ω；
2）Brass cable；
3）95% copper braid, tinned
2.2 Precautions to Installation
1．Read this manual carefully before installation.
2．The power supply and the voltage should be the same as indicated on the cable. Standard voltage is AC24V,
the voltage should be within AC24V±10%.Long-time working of dome under too low or too high voltage
will cause abnormal working. Keep the power consumption above 40W, otherwise, the restart or controlling
of dome will be abnormal.
3．Continuing exposure of camera to strong light will damage CMOS and result in bad image or no display.
4．The outdoor dome is water-proof as well as moisture resistant (IP66). If the dome is wired improperly, the
rain will enter the dome along the cable, thus damaging the circuit board and even the camera. The right and
wrong wiring are shown in the following pictures:

HD IR AHD Intelligent High Speed Dome User Manual
16
Right Wiring
Wrong Wiring

HD IR AHD Intelligent High Speed Dome User Manual
17
Chapter 3 Installation
3.1 Package Checking
3.2 Installation
3.3 Dip Switches (DomeAddress, Protocol and Baud Rate)

HD IR AHD Intelligent High Speed Dome User Manual
18
3.1 Packing checking
Please check if your camera and accessories are all included in the product package:
Packing list of wall mount speed dome (indoor/outdoor):
1. Integrated Camera
2. Bracket Integrated Camera Bracket（Optional）
3. Power Supply
4. Screw Pack
5. User Manual
6. Quality Certificate
7. Warranty Card Power Supply（Optional）Screw Pack
User Manual
Note：Non-original packing material may cause damage in transportation and cost extra charge.
3.2 Installation
3.2.1 Install the bracket，run the BNC cable through the bracket (see following picture). Please refer to
Chapter 4 for installation of different brackets.
3.2.2 For wall mount bracket, get out the upper housing from the carton and install it with the bracket. Please
wrap the connecting part between the upper housing and the bracket with teflon tapes (see following picture) to
make it water proof if it’s an outdoor camera.

HD IR AHD Intelligent High Speed Dome User Manual
19
3.2.3 Wire of camera is shown as follows：
3.2.3.1 one-dome device connection
The one-dome device connection allows the user learn the wiring quickly, and also makes the installation,
adjusting, testing and exhibition easier. Read the below chart carefully for connection when you use the apparatus
for the first time. Any wrong wiring may cause permanent damage or damage to other equipments.
Following are 3 connection methods, for users’reference:
Caution: No operation is allowed when dome is powered-up.
3.2.3.2 Multi-dome device connection.
When connecting many dome devices together, the user can embed multi-device system with auxiliaries such
as arrester device, video matrix, DVR and alarm box for system integration.
AC24V: Power supply of dome device, which will convert AC 220V（50HZ）input to AC24V output and
supply to the dome device.
AC24V
