RCN SMART BASIC SMALL User manual

Via Marcatutto 7
20080 Albairate (MI) - ITALIA
www.rcnengineering.it - E-mail: [e-mail]
GLASS LAMINATING MACHINE
Mod. SMART
- HANDBOOK-
INSTALLATION - USE - MAINTENANCE
RCN-050508

MACHINE IDENTIFICATION :
•Manufacturer: R.C.N. Engineering S.R.L.
•Machine: glass laminating machine
•Machine N° : 05110
•Year of construction :
•Operating book no. : RCN-010704 ISSUE 01 of 01.07.2004 - Rev.00
ENCLOSED :
•"CE" declaration of conformity
•Electrical scheme N°. :
•Hydraulic-pneumatic set scheme N°.:
•List of working cycles set :
•Overall dimensions plan N°.:
CLIENT IDENTIFICATION DATA/PLACE OF INSTALLATION :
•Company name and address:
•Delivery place: see above
Note : In case of property transfer or leasing the manufacturer has to be informed in time.

CONTENTS
pag.
1. MAIN INFORMATION
Letter on delivery...............................................................................................................................................3
1.1. Contents and operating book .................................................................................................................4
1.2 Cooperation with the user........................................................................................................................5
1.3 Regulations..............................................................................................................................................6
1.4 Manufacturer’s responsibilities and guarantee........................................................................................6
1.5 Technical support.....................................................................................................................................6
2. MACHINE DESCRIPTION AND TECHNICAL SPECIFICATIONS
2.1 Glass laminating machine.......................................................................................................................7
2.1.1 Technical and construction features...............................................................................................7
2.1.2 Setting up – The parts of the machine............................................................................................7
2.1.3 Expected use – Appropriated use............................................................................................ ....11
2.2 Conditions of the service.................................................................................. .....................................11
2.2.1 Rules and dispositions applied in
construction...................................................................................................................................11
2.2.2 Electrical supply............................................................................................................................11
2.2.3 Identification plaque – conformity mark........................................................................................12
2.2.4 Environment conditions for use................................................. ...................................................12
2.2.5 Light..............................................................................................................................................14
2.2.6 Emissions in atmosphere during use............................................................................................14
2.2.7 Noise - Vibrations ........................................................................................ ................................14
2.2.8 Use limits, running conditions- Life..............................................................................................14
2.3 Expected use..........................................................................................................................................15
3. SAFETY AND SAFETY MEASURES
3.1 General safety dispositions............................................................................................................. ......15
3.2 The user.................................................................................................................................................15
3.2.1 Qualified staff.........................................................................................................................................16
4. LOGISTICS - INSTALLATION – SETTING UP
4.1 Despatch, transport and packaging........................................................................................................16
4.2 Manoeuvring, lifting, offloading..............................................................................................................16
4.2.1 Unpacking .....................................................................................................................................18
4.3 Preparation of the area of the installation ..............................................................................................18
4.4 Installation..................................................................................................................................... ........18
4.4.1 Positioning.....................................................................................................................................18
4.5 Setting up............................................................................................................................... ...............18
4.5.1 Connections to the electrical supply line……………...………………………………………………
18 4.5.2 Machine control........................................................................................................ ................19
5. MACHINE USE
5.1 In service................................................................................................................ ...............................21
5.1.1 Expected use – Measures and care.............................................................................................21
Unsuitable for.........................................................................................................................................33
5.7. To unable machine.................................................................................................................................34
6. MAINTENANCE
6.1 General information................................................................................................................................34
6.1.1 Safety measures ...........................................................................................................................35
6.2 Ordinary maintenance............................................................................................................................35
6.2.1 Operations prior to starting or change of shift .............................................................................35
6.2.2 Operations to stop on shift end or to change production..............................................................35
6.3 Periodic maintenance.............................................................................................................................35

6.3.1 Safety – general information.........................................................................................................35
6.3.2 Quarterly operations .....................................................................................................................36
7. ADDITIONAL INSTRUCTIONS
7.1 Instructions for emergency events .........................................................................................................37
7.2 Instructions for dismantling and wasting................................................................................................37
1. MAIN INFORMATION
Letter on delivery
Dear customer,
•Thank you for choosing R.C.N. Engineering S.R.L. This technical issue has the aim to help the customers
to obtain best output in total safety.
•We have carefully tested the machine, in all its functions, and it is ready to be installed at your works
•We advise you to check the integrity of the machine on arrival. Should any damage occur during
transport, please notify your reserves to the Forwarder.
•It is important to follow the instructions here contained for the best long-term machine use
•This document, whose the original text is in Italian, is written according to the following regulations: EN
292 – 1st part, passage 3.20 and 2nd part, passage 5. It has been written to comply with the
requirements number 1.7.4. Disposition 98/37 CE ex 89/392 CEE and subsequent amendments.
•Read the instructions carefully and get your working staff informed accordingly. Wish you all a good job.
•Should any doubt arise, please contact RCN immediately.
1.1 Content and operating book delivery

The glass laminating kiln, hereafter called “machine”, this publication refers to, has been designed,
manufactured and introduced to the market by
Via Marcatutto 7, 20080 Albairate (Mi)
tel [phone] fax [phone]
www.rcnengineering.it - E-mail: [e-mail]
The operating book, for the “intended use – expected use" of the machine, contains the technical
specifications and performance features of the machine itself as well as the instructions for installation, use
and maintenance. It is intended for :
•the person responsible for the plant, works or third part who purchased the machine
•people employed in transport, in manoeuvring and installation
•people employed in installation and first starting up
•people employed in use and maintenance.
This document have to be kept by one person in charge, in a suitable place, in such a way to have it always
available for reading.
In case of lost or deterioration, a new document can be required by letter indicating the code of this book.
The manufacturer is responsible for the contain of this publication. Disclosure, duplication, or
partial duplication, are forbidden without written consent by RCN.
The original text of this publication, written in Italian language, is the only reference in matter of
decision in case of disagreement or interpretation related to any translation into the EC languages.
This publication is part of the machine and has to be kept for future references until dismantling and
wasting of the machine
1.2 Cooperation with the user
The operating book reflects the state of the machine in the right moment it is introduced on the market. It is
part of the machine itself.
Any future integrations of this book, made and sent to every user by the manufacturer, are intended to be
kept with the operating book.
The manufacturer is at disposal for further information and to collect proposals to improve the content in
order to meet all those purposes this book has been written for.
In case of property transfer, the main user is requested to inform the manufacturer about the new user’s
address to send him the necessary communications and/or updating

1.3 Conformity regulations
The machine has been studied and manufactured in accordance with “the basic safety systems” of the 1st
Attachment of the European Community Regulations 98/37 CE ex 89/392 CEE and subsequent
amendments 91/368/CEE, 93/44/CEE and 93/68/CEE, called Machines Dispositions, transferred into the
National Italian legislation system as DPR N° 459 del 24.07.96.
In accordance with the content of the 2nd Enclosed of the Disposition 98/37, the machine is introduced on
market as follows:
-Complete, i.e. able to self-running , with CE brand and Declaration of CE Conformity – 2
nd
A -Enclosed.
The machine applies to the following dispositions as well:
•Low Tension (DBT) 73/23/CEE, transferred into the Italian legislation system with the Law N° 791/77
modified with D.Lgs N° 626/96 and with D.Lgs. N° 277/97.
•Electro-magnetic disposition (EMC) 89/336/CEE transferred into the Italian system with D.Lgs. N°
476/92 modified with D.Lgs. N° 615/96.
The machine has also been studied and manufactured in accordance with the dispositions in matter of
industrial safety equipment in force at the date of introducing on market of this machine. It is particularly in
accordance with
•DPR 547/55; 302/56; 303/56: accident in working
•D.Lgs. 626/94 relating to the Disposition table 89/391/CEE: safety in the working areas and other
particular Dispositions related to.
1.4 Manufacturer’s responsibilities and guarantee.
With reference to the content of this handbook, R.C.N. S.R.L., declines any responsibility in case of:
•Different use of the machine from the norms contained in the national laws in matter of safety
and accident events.
•defects in tension and in electrical supply and/or in other supplying sources.
•neglected or wrong compliance of the instructions supplied in this handbook.
•no allowed or unauthorized modifications on the machine
•bad issues derived from not trained or unsuitable staff.
To benefit of the guarantee the buyer must follows the instructions contained in this handbook carefully,
especially:
•always operate within the machine limits of use
•always make a constant and careful maintenance
•allow the use of the machine to those operators who can prove ability and skill.
•use original spare parts only, those indicated by the manufacturer.
•The intended use and the setting up the of machine here contained are the only allowed.
•Do not try to use the machine for different purposes, in disagreement with the instructions
•The instructions here contained are, in no case, intended as a replacement of the obligations to
respect the present dispositions in matter of safety and accident events.
This handbook reflects the state of the machine in the right moment the machine is introduced on the
market. Any modifications, adjusting, improvements, etc. made in the future by RCN S.R.L do not oblige the
latter to apply to the former orders, nor the machine could be considered lacking and/or unsuitable in
performance.

1.5 Technical support
For assistance or technical help ask the manufacturer at the following address, always indicating machine
Model and Number:
R.C.N. Enginering S.R.L.
Via Marcatutto, 7 – 20080 ALBAIRATE (MI) - Italia
Tel. [phone] – Fax [phone]
www.rcnengineering.it - E-mail: [e-mail]
2. MACHINE DESCRIPTION AND TECHNICAL SPECIFICATIONS
2.1 The Glass Laminating Kiln.
2.1.1 technical and manufacturing features.
-Structure: welded and bolted metallic structure.
-Insulating system: one layer of 50 mm. glass wool, high density
-Heating: armoured special steel heating elements and checking thermocouples type k ; specific
thermocouple for the automatic interruption of the electrical supply in case of damage of the thermo
controllers.
-Shelf:, Drower-opening extractible shelf for Medium and Large model. Fixed shelf for Small model.
It is provided with a silicon mantle to create vacuum in lamination
-Top of the kiln: open top for Basic Small. Fixed for Medium and Large.
Mod. BASIC SMALL Mod. BASIC MEDIUM
-Height x Length x Width: 1210x2240x1240 mm 1250x2950x2140 mm
-Internal height: 540 mm 530 mm
-Shelf height:: 760 mm 825 mm
-Open wide: 2000 mm 2770 mm
-Weight: 500 kg 750 kg
-Electrical supply: 400 V – 50/60 Hz 400 V – 50/60 Hz
-Installed power: 13kW 16kW
Mod. BASIC LARGE Mod. ---------------------
-Height x Lenght x Width: 1250x3450x2240 mm -
-Internal height: 530 mm -
-Shelf height: 825 mm -
-Open wide: 3265 mm -
-Weight: 1000 kg -
-Electrical supply: 400V -50/60Hz -
-Istalled power: 20KW -
2.1.2 Setting up – machine’s parts
The machine appearance and structure is the same of picture. 2-1.

Note: though keeping features and setting up unchanged, machines can be manufactured with different
dimensional features and productive potentialities .
Refer to a possible enclosed added documentation.
In picture 2-1 the main machine components are shown together with a list of words the operator has to
know for a safe and lasting use of the machines.
Note: electrical schemes are enclosed to this publication or placed in a pocket inside the electrical box.
9
13
10
11
12
13
1. Structure
2. Supports and kiln level
3. Electrical box
4. Keybord
5. Upper side
6. Shelf

7. Opening pin supports
8. Vaccum pum
10. Vacuum bag
11. Vacuum valve
12. Metal strip to fix vacuum bag
13. Fixing Clamps
Fig. 2-1
9
13
10
11
12
13
1. Structure
2. Supports and kiln level

3. Electrical box
4. Keybord
5. Upper side
6. Extractible shelf
7. Opening pin supports
8. Vaccum pump
10. Vacuum bag
11. Vacuum valve
12. Metal strip to fix vacuum bag
13. Fixing Clamps
14. Closing door and extractible shelf support
Fig. 2-1
9
13
10
11
12
13

1. Structure
2. Supports and kiln level
3. Electrical box
4. Keybord
5. Upper side
8. Extractible shelf
9. Opening pin supports
8. Vaccum pump
10. Vacuum bag
11. Vacuum valve
12. Metal strip to fix vacuum bag
13. Fixing Clamps
14. Closing door and extractible shelf support
Fig. 2-1
2.1.3 Expected use – Appropriate use
The kiln has been studied for glass laminating process only. The system mainly consists of a heating of the
assembled glass, fully described in the following paragraphs, kept into the silicon bag on the shelf. Time for
vacuum is contained in the procedures pre-set in the laminating cycles, according to the logic of the
electronic checking controller of the machine.
The glass assembling, (one or more sandwiches: glass, thermo-adhesive interlayer, glass), within the size
limits of the manufacturing features of the machine and the laminating cycles, must be performed only using
the Ethilene Vynil Acetate films: “Evasafe”, manufactured by Bridgestone, or “EN S-LEC” manufactured by
Sekisui. Follow the instructions carefully in matter of using and storage. To seal the sandwiches on the
edges, use silicon-based tape only.
The silicon rubber for vacuum comes together with the machine and must be used with flat glass only. To
laminate curved glass the client needs to buy a zipped bag.
The use and the set up of the machine, as picture no. 2-1, are the only allowed by the manufacturer.
A different, having one purpose use only is allowed just on specific instructions, to be find here
enclosed, if the case.
2.2 C onditions
2.2.1 Rules and dispositions applied in constructiuon
In planning and manufacturing the machine the following regulations have been taken into consideration:
•CE Dispositions :
•Machines 98/37 CE.
•73/23 CEE: " low-tension electrical components".
•89/336 CEE " electro-magnetic compatibility".

2.2.2 Electrical Supply
The machine is set for the following:
•Electrical voltage: alternating with 400 V +/- 10% - 50Hz. mono-phase tension, according to
IEC 38-1
2.2.3 Identification plaque – Mark Accordance
All the entire parts of the machine are in accordance with the Dispositions, and the CE mark give evidence to
the conformity.
A plaque indicates manufacturer’s identification details, technical data about the electrical supply and CE
mark, see A, fig. 2-2.
An adhesive plaque is stuck on the electrical box and on the control panel informing about the risks related
to electrical supply.
A sticker is stuck inside the electrical box indicating technical specifications about the electrical supply.
Every plaque or stick has to be carefully kept and data are to be always legible. Clean them
periodically.
Should a plaque or a stick be damaged and data illegible, even for one data only, ask the
manufacturer for another one and provide for replacing.
For any communication to the manufacturer, always quote data the plaque or the stick contain and
the identification details.
Other plaques or stickers different from those affixed by the manufacturer are forbidden without
written confirmation.
2.2.4 Environment conditions for use
•Temperature for running: minimum + 5 °C; maximum + 40 °C
•Max humidity: 80 %
•The machine must be placed in a sheltered space having all the safety references required by the
regulations in force, to guarantee specialists best operating conditions.
The machine cannot operate in open space and/or under atmospheric agents and in places having vapours,
corrosive and/or abrasive powders, or other places with risk of firing or explosion and in all those places
where the use of anti-explosion components is required.
Besides, it is necessary to provide for a working place suitable enough to guarantee the operator and
other staff safety conditions.
Attention: if during installation the environment conditions should be find different from those
determined, or should them be modified in the future, the manufacturer is to be informed before the
machine starting up.
-

Detail ‘A’
Detail ‘B’

Fig. 2-2
2.2.5 Light
The machine has not light system.
The light where the machine operates has to be such to avoid shadows (roughly 300-600 lux) and guarantee
the maximum safety conditions.
In case of maintenance or operations in scarcely lightened place, the use of portable lights is compulsory to
avoid shadows reducing or prevent visibility in the working area or thereabout.
2.2.6. Emissions in atmosphere during use
The machine does not give any vapours, powders, etc. off. It is up to the user to ensure that the use
conditions in his own premises do not generate situations of danger for the operators’ health (few ventilation,
high humidity, etc.) He has to verify self-protections are being used according to law dispositions.
2.2.7 Noise - Vibrations
The acoustic tests performed during the installation at the manufacturer’s works shown that in the worst
operating situation, the result is lower than 85dB (A), with no reverberation,, measured from 1 m distance
from the machine, and 1,6 m from the floor .
The vibrations generated by the machine are not dangerous for people operating near the machine
A great vibration can be provoked by breakdown. Immediately inform, stop the signal to avoid compromising
the machine reliability.
In conformity to the law dispositions in force, the buyer has the obligation to make acoustic pressure
measurements at his premises after the installation, and in any case before the machine running.
Other measurements are to be made during machine functioning in worst conditions operations to
be sure that during normal running the reverberations do not generate dangerous events for the
operator and providing self-protections remedies, if necessary.
2.2.8 Limits of use, conditions of running - Durability
The machines have been studied for a continuous use. To keep a constant safety level, the user should ask
the manufacturer or an authorized works for a full revision after ten years running.
Do not try to re-use the machine or some of its parts or components, even in good state of
appearance, if they are declared unsuitable by specialists or by the manufacturer, after the
inspection.

2.3 Expected use
Refer to the specific paragraphs 'Machine use'.
A different and sole use is allowed if only enclosed to this book as instructions
The main technical manufacturing features of the machine are written in paragraph. 2.1.1
2.2.8 Limits of use, conditions of running - Durability
The machines have been studied for a continuous use. To keep a constant safety level, the user should ask
the manufacturer or an authorized works for a full revision after ten years running.
Do not try to re-use the machine or some of its parts or components, even in good state of
appearance, if they are declared unsuitable by specialists or by the manufacturer, after the
inspection.
3. SAFETY AND ANTI-ACCIDENT MEASURES.
3.1 General Safety Disposition
The machine has been studied according to the most modern technological know-how and can be safely
used.
Dangerous events can be fully avoided and/or reduced with a correct use of the machine by trained staff and
according to the instructions contained in this hand-book,
The staff is responsible for the following operations:
First running of the machine and normal running.
Operations of different nature on the machine particularly related to the first the installation, loadings, checks
cleanings; maintenance, repairs of any components prior to the machine setting up, during operating or after
machine stop. The operators has to be informed about the possible dangers they can meet while
accomplishing their duties, and about the functioning and the use of the safety devices of the machine itself.
The staff in charge has to observe the following safety rules to avoid dangerous situations.
3.2 The Operator
The company’s person in charge and responsible for the safety has to choose the operator
according to the disposition in matter of labour fitness. But other components are important in the
choice of the subject: the aspect, no disablement; the psychological appearance, balance of mind,
sense of responsibility as well as personal education, training, experience, good knowledge in matter
of regulations, prescriptions and measures to prevent accidents.
After having tested and considered skill, the operator designed shall be instructed and trained for the
machine functioning and for products to be laminated. He must also to be informed about the
content of this book.

3.2.1. Qualified staff
-Operator working on the machine:
The operator must follows all the information he had got to obtain the maximum safety for himself and for
other people. He must observe the instructions given in this book for the executions of all the operations.
Common operations expected:
- use of the machine in normal functioning and in starting up after a stop;
- assuming necessary measures to keep the quality of the machine performance;
- cleaning of the machine (paragraph ‘Ordinary maintenance’);
- cooperation with the appointed staff for the extraordinary maintenance.
Operator place:
- The machine needs just one operator; he is not asked to stay in a particular place during operating.
-Operator in charge and authorized to various actions (moving and connections to electrical
equipment of the area, adjustments, extraordinary maintenance, repairs):
these persons are to be chosen by the user among the professional figures of the department having tested
skill and experience; having technical knowledge about the specific activity they will perform.
R.C.N. Engineering S.R.L. will not be responsible for damages on persons or things accomplished
by the user neglecting the instructions of this chapter.
Some activities to be made on machine in function can expose operators to conditions of serious danger, it is
therefore important to respect the following instructions, carefully:
- The staff must be authorized and instructed about the instructions to follow, about the dangerous situations
that could arise and measures to avoid them.
They have to operate with the utmost care and caution.
-In the exceptional event of technical intervention for maintenance, inspection or repairs requiring complete
or partial stop or repairs removal, the staff in charge must restore the parts as soon as the operations end.
The staff in charge must also check some tools or checking devices are not to be forgotten inside the
machine provoking damages of bad functioning on starting up.
- The staff in charge for maintenance, inspection and repairs has to cut the machine electrical supply off and
to take all due measures before starting the operations to insure his own safety
-Verify that all the preventive measures have been assumed (signs, blocking devices) to avoid sudden total
or partial start on intervening.
-Should a technical operation take place on an electrical device without cutting tension off, the utmost care
and caution must be paid.
4. MOVING- INSTALLATION – STARTING UP
The glass laminating machine is generally delivered fully assembled. However its functioning could
only take place after the following operations, put under the care of the staff charged for transport,
moving, installation and starting up in force to the buyer’s or designed by him.
-All the operation here described, owing to their care and importance, can involve, if wrongly executed, the
safety of the persons exposed during the fist installation and other operations.
-The operations have to be performed by a qualified professional staff, specialized in industrial plant, with
competence in matter of electro-mechanic systems, equipped with labour fittings and self-protections in
accordance with the laws related to anti-accident and safety in labour.

4.1 Despatch and packaging
Transport, when not differently specified, is to be made by truck with canvas to protect machine from weather
agents until destination.
The machine transport or of some of its parts or components has to be made by qualified carriers able to
guarantee adequate moving of the items transported.
R.C.N. Engineering S.R.L. is not responsible for transports made carriers chosen by the client.
The standard package, if supplied and not differently expected, is not waterproof and suitable for ground not
for sea transports, and for sheltered and not humid space.
The materials, duly preserved, can be stocked for about one year in sheltered place with temperature range
of + 5° C and + 40° C, with humidity not over 80%.
For different environment a specific package has to be arranged.
4.2 Moving, lifting and offloading
The staff entrusted for the operations listed here under has to be instructed and authorized to make
these activities to avoid wrong manoeuvring causing possible danger and/or damaging the machine.
Make some visual check before moving the machine and/or its parts to detect possible breakages or
damages, please proceed as follows:
Using a suitable lift equipment and avoid wavering.
The packaging supplied has to be found intact on receiving, it means:
- no marks of crash or breakages;
- no marks giving suspect it was exposed to weather agents such as heat, cold, water, etc.;
- no marks of tampering.
-The lifting capacity of the equipment has to be suitable to the mass to be moved, consider some
reasonable margin of safety.
Never use lifting equipment not in accordance with the safety regulations.
- R.C.N. Engineering S.R.L. is not responsible of possible damages to people or things generated by
wrong manoeuvrings of the load or manoeuvrings made by unsuitable operators and/or using
unsuitable lifting equipment.

4.2.1 Unpack
Free the machine from any package.
-For every material used in packaging, the client has to arrange for wasting according the law of his
country.
-Do not waste the package into the environment
4.3 Place of installation
To allow a regular and correct installation of the machine, the client has to follow the instructions
listed here under:
•Verify the suitability of the shelf/shelves and the bearing structures on kiln positioning.
It is important to check the suitability, the resistance and evenness of the floor, the solidity of some
foundations in connection with the static actions/reactions and movements caused in placing, the use and
weight of the machine itself.
•Check the suitability of the space for manoeuvring, the ways, the aisles, the escape lines and the exits
close to the machine.
•Verify the appropriateness and the due functioning of the electrical supply : line of supply, sockets ,
electrical panel, the switch off system to interrupt electricity, section, power and length of the cable/cables
and earth device according to the EN 60204 –1 regulations.
•Arrange for a the place of installation fulfilling the anti-accident regulations in matter of safety of the
equipment for electrical supply source; of the products/materials and equipment given for installation. The
buyer must pay particularly care in guarantee the suitability of the earth connection for the metallic parts
and electrical equipment that have to be duly connected to the earth.
•Place suitable signals, according to the ISO 7000 regulations, to inform operations and manoeuvrings are
being carried out.
4.4 Installation
4.4.1 Positioning
Verify the aisle to reach the place of installation is free from any obstructions. Provide for protections if
needed.
Reach the designated place of installation .
If the kiln is placed near to one or more walls, leave a space large enough to allow people for an escape line.
4.5 Setting up
4.5.1 Connection to the electrical supply line.
The user is responsible to provide for a suitable electrical supply: box, socket, earth connection.
The supply source fits the machine and respectful of the regulations margins.
The R.C.N. Engineering S.R.L. electric machines are manufactured according to CEI-EN 60204-1
regulations and the electrical supply has to get a max margin of 10% on the value of the tension and a max
continuous margin of 1%p and of 2% for a short time on the value of the frequency.

The supply must have an automatic device for release with an differential magneto-thermal switcher
and earth connection to guarantee the respect of the regulations applied in the country machine is
going to be installed.
We strongly advise the use of a differential switcher having limit of effect at 0,03A.
The connection of the machine to the electrical supply, to be effected by a qualified specialists, has to be
made directly to the clamps of the main switcher by means of the cable glands of the machine electrical
panel. Check on the electrical scheme here enclosed. (6, fig. 2-1)
•Before connecting, verify your electrical line has the same features of those indicated on the
machine plaque and in accordance with the information written on the electrical scheme here
enclosed.
•Check the main switcher is on '0' position .
•Do not execute connection with temporary cable and/or extensions .
•Signal the presence of cable/s on the floor if no other solutions could be undertaken in the area of
the installation and people have to walk across.
•Do not leave cables on the floor in the area where means of transport drive across.
4.5.2. Machine control
Check fig. 4-1
MAIN SWITCHER (on the opening of the electrical box)
If turned on selection (I) it connects the machine and the controller to the electrical supply of the department.
1. ANCILLARY BUTTONS
When the button is pressed, the related light turns on and the machine is ready to run and all the ancillary
circuits are activated.
The button has to be activated at first starting up of the machine and every time the machine is stopped by
pressing the emergency button, (2).
2. 'EMERGENCY STOP' BUTTON
When fully pressed, the red “mushroom shaped” button stops cycle and functions accordingly.
The button keeps its position when pressed (self-hold); to re-start the machine turn the button clockwise in
the original 'lifted' position for running and make machine work pressing the ancillary buttons (1).
