RDT RSC-900 Series User manual

RSC-900 System Components
(included in all kits):
1 – Communication hub
(Ethernet or Wi-Fi)
2 – AA batteries (hub)
1 – Ethernet cable
(Ethernet models only)
1 – 110V plug (hub)
2 – Water ood sensors
4 – AAA batteries (sensors)
RSC-900-AW kits:
1 – Valve
1 – Actuator
4 – CR123A (3V) batteries
(actuator)
1 – Long parallel mounting
adaptor (valve/actuator)
1 – Short perpendicular
mounting adaptor
(valve/actuator)
1 – Emergency key
(valve/actuator)
RSC-900 Series
Quick-Start Guide
NEED INSTALLATION OR SETUP ASSISTANCE?
Call toll-free: 888-771-4929
Or visit www.RelianceDetection.com/support/RSC-900
RSC-900 leak detection systems with shut-off valves
should be installed by an authorized plumber. Hub and
sensors are for interior use only. The valve/actuator may be
installed on the exterior of the building, if necessary and as the local
climate allows. When considering exterior installation, be sure the
actuator would not be immersed in water for more than 30 minutes and
immersed in water deeper than 3’. Do not install any components inside
a metal cabinet.
RSC-900 Wireless System FCC & Industry Canada Information
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Communication hub: IP Rating IEC60529
Valve/actuator: IP Rating IEC60529; IP68, ANSI61, Annex G (valve)
Certications: FCC IC
Flood Sensor RSC-900-W-001 2AFOICLMFLD10 20798-CLMFLD10
Hub RSC-900-X-650 2AFOICLMCTRL10 20798-CLMCTRL10
Hub RSC-900-X-800 2AFOICLMCTRL10 20798-CLMCTRL10
Actuator RSC-900-W-310 2AFOICLMASOU20 20798-CLMASOU20

1Download the RSC-900 System Management App
Download the “RSC-900 by RDT” app onto the designated smartphone from the
Apple App Store or Google Play.
Component Indicator Light Guide
Green .......................... OK
Blue ............................ Communication problem
Slow Red Flash ............ Low battery
Quick Red Flash ........... Water leak detected (sensor only)
2Set Up the Communication Hub
FOR WI-FI HUB SYSTEMS: You will be registering the RSC-900 to your designated Wi-Fi network;
conrm that your mobile phone is connected to the same before proceeding. From the phone settings,
select the system hub from the list to join it to the network. Follow the prompts on the app to complete
system set up. Reference steps 4 –8 for hardware installation, set-up conrmation and system testing.
FOR ETHERNET HUB SYSTEMS:
Flat Surface Install
Wall Mount Install
(screws not included)
A
D
E
B
C
2 - Install batteries 3 - Plug into wall outlet
1 - Connect Ethernet cable to 2.4 GHz band Internet router
A. LED status light
B. Upper cover
C. Lower cover
D. Power / Ethernet inputs
(bottom of lower cover)
E. Table stand (detachable –
Ethernet hub only)
DO NOT proceed to next step until the LED on top of the Hub is ashing green (Internet communication has
been established). Check the Internet rewall settings on your router or consult your Internet provider if you
see a blue LED on the Hub.
3Set Up Account & System
1 - Once Internet communication has been
established with the hub (as indicated by ashing
green LED status light) create a New Account and
System in the app.
IMPORTANT! Visit our website for detailed video
instructions for account and system set up:
www.RelianceDetection.com/support/RSC-900
2 - After your
account has been
set up on the app,
scan the Kit Master
QR Code found
on the outside
of the master kit box (see above) to add the
basic kit components to your system. Wait until
“Installation Successful” appears on the app and
then tap “OK.”

4Set Up the Valve and Actuator
(Skip to step 5 if your install does not include water shut-off)
NOTE: Be sure to turn off the water
supply before installation.
NOTE: Valves can be installed in any
direction or orientation.*
H
I
JK
AE
F
B C
G
D
1-Install the CR123A (3V) batteries with positive side “in” and negative side “out,”
facing you.
2-Install the stem and adaptor as shown, using
the provided screws.
3-Install the valve into the water line after the
manual shut-off; after any re suppression systems;
and according to all local plumbing codes.
4-Record the actuator name, location and photo
in the app.
5 - Turn on the water supply. Check for leaks.
6-Hang the emergency key and tag on the
actuator lock (G).
A. Shut-off valve motor
B. Motor stem position indicator
C. LED status light
D. Multipurpose button
E. Battery housing cover
F. Mounting adapter
G. Lock
H. Short mounting adaptor and stem
(for actuator install perpendicular to pipe)
I. Long mounting adaptor and stem
(for actuator install parallel to pipe)
J. Emergency turn key
K. Valve
* Please visit our website for detailed video
instructions for hardware component set up:
www.RelianceDetection.com/support/RSC-900
Manual/Emergency Operation
For information on how to manually open and close the valve, please refer to the included tag.
1
2
–
+
NEED INSTALLATION OR SETUP ASSISTANCE?
Call toll-free: 888-771-4929
Or visit www.RelianceDetection.com/support/RSC-900

© Copyright 2021 Reliance Detection Technologies, LLC – A Madison Company – All specications subject to change without notice.
ECN # 12003, 01/2021, MF165, REV F
203-488-2684 or 888-771-4929
[email protected]
www.RelianceDetection.com
Reliance Detection Technologies, LLC
27 Business Park Drive
Branford, CT 06405
Set Up the Master Kit
Water Flood Sensors
1-Install AAA batteries.
2-Record the sensor name and
location in the app (conrm the
correct device via the unique serial
number on the app and sensor QR code).
3-Repeat for each sensor.
4-Place the sensors in their desired locations.
Conrm Set Up
Once all devices have been deployed, conrm your
system is properly set up and devices are within
wireless signal range of the Hub.
1 -
From the RSC-900 app menu in the upper-left corner
of the screen (see icon at right), click on “Settings.”
2 - Tap “Add/Remove Devices.”
3 - Tap “Congure” next to the appropriate system
(if you have multiple systems).
4 -
Tap “Accept” at the bottom of the screen. The
system will now conrm wireless signal strength of
all devices. Devices will be momentarily greyed out
on the screen while this occurs.
5-Observe the devices come back on-line (borders
around all device icons), along with their “Wireless
Signal” strength indication.
6 -
Look for any warning symbols along the right-hand
side of the screen. indicates that the use of a
repeater is needed for indicated device(s). Follow
installation instructions for RSC-900-X-200 Wireless
Signal Repeater to overcome wireless signal issues.
Adding Accessory Sensors & Actuators
1-Install the new device in its permanent
location.
2-From the App, tap on Menu – Settings – Add/
Remove Devices – Congure – Add Devices.
Scan the device QR code (see right).
3 - Tap the new device on the
app screen.
4 - Scroll down and tap “Edit.”
5-Add name, location, and photo of installation
location (optional).
Test the System
1-Apply a wet paper towel to a
sensor’s electrodes until its
LED ashes red and its alarm/
beep sounds.
2-A “Leak!” indicator message will
appear on the home screen of
the app.
3-If you have a valve and actuator
shut-off installed, conrm that
there is no water ow.
In the app, tap the water shut-off
icon, and then tap “Open” on the
screen to open the valve. Verify
that water is owing at the faucet.
5-Repeat for each sensor in
the system.
D
C
A
B
5
7
6
8
Slide to open
A. LED status light
B. Water detection electrodes
C. Battery housing cover
D. Double-sided tape
