Recoda M602 User manual

M602 SD card MINI Mobile DVR
User manual
Ver. 1.2

Note:
·Put Mobile DVR on horizontal plane;
·Select appropriate installation position to provide good ventilation and
prevent overheating of the device.
·Do not put liquid stuff onto it
·Install the device in suitable humidity and temperature environment.
Statement:
· We strive to ensure the exactness and integrality of the manual in the
process of preparation, but still error or omission is inevitable.
· The copy, transmission, plagiary, storage in retrieval system, or
translation into any language without written authorization is prohibited.

Mini SD card mobile DVR M602 user manual
CONTENT
1.1.PRODUCT INTRODUCTION .............................................................................................................4
1.2 TECHNICAL PARAMETER ................................................................................................................4
2.THE PRODUCT STRUCTURE INTRODUCTION ........................................................................6
2.1 PRODUCT CONNECTION PORT INSTRUCTION ...............................................................................6
2.2 FRONT PANEL PORT INSTRUCTION ...............................................................................................7
2.4 REMOTE CONTROL DESCRIPTION ................................................................................................10
3 SYSTEM OPERATING INSTRUCTION .......................................................................................11
3.1 START SYSTEM ............................................................................................................................11
3.2 SHUTDOWN SYSTEM ...................................................................................................................11
3.3 BASIC OPERATION INSTRUCTION OF MENU ................................................................................11
3.3.1 ENTER MENU MODE ................................................................................................................11
3.3.2 MENU COMPONENT INSTRUCTION...........................................................................................12
3.3.3 EXIT MENU MODE ....................................................................................................................12
3.4 MAIN MENU .................................................................................................................................12
3.5 CHANNEL PREVIEW .....................................................................................................................13
3.6 PLAYBACK ....................................................................................................................................13
3.7 MANUAL RECORDING ..................................................................................................................15
3.8 MENU ...........................................................................................................................................15
3.8.1 TOOLS.......................................................................................................................................16
3.8.1.1 HDD MANAGEMENT .............................................................................................................16
3.8.1.2 USER MANAGEMENT.............................................................................................................17
3.8.3 PTZ Control.......................................................................................................................27
3.8.4 Log Information...............................................................................................................27
3.8.5 Shutdown System...........................................................................................................28
3.8.7 Bus Information...............................................................................................................29
3.8.8 Overlay Setting................................................................................................................29
4CLIENT SOFTWARE USER MANUAL .................................................................................................30
5 FREQUENTLY ASKED QUESTION ...............................................................................................8

Mini SD card mobile DVR M602 user manual
1.1.Product introduction
This device is specially designed for the mobile DVR. It adopts embedded processor and
embedded operating system, combines the latest technologies in the IT filed like audio and video
compression/decompression technology. Its structure adopts special anti-vibration technology.
Appearance
Front view:
Back view:
1.2 Technical Parameter

Mini SD card mobile DVR M602 user manual
Item Description
The main processor Hi3512
operating system Embedded Linux operating system
System resource 4 channel full real-time video at the same time
3G optional Built-in 3G wireless module optional. Such as EVDO,
HSPA, HSDPA, WCDMA…GPRS, EDGE, …
GPS optional Embedded GPS module Optional
Image compression H.264
Audio compression ADPCM
Video mode Manual, time, alarm, motion detection
Video search Time search, event search, channel search
backup mode USB backup
Video/Audio input 4 CH air connector
Video/Audio output 1 CH air connector
Recording Resolution PAL:720x576（D1） NTSC:720x480（D1）
playback Resolution PAL:352x288（CIF) NTSC:352x240（CIF),1channel D1
720x576
Image Control 6-speed adjustable
Motion Detection Can be set to 396 (22 × 18) detection areas, can be
set multi-level sensitivity
Screen display Single-screen, four screens
Recording speed PAL: 25 frames / s(adjustable) NTSC: 30 frames /
s(adjustable)
Recording storage SD Card
Local playback 1 ch or 4 ch playback
alarm input 4 switches
Memory interface 1 SD card interface
USB interface 1 USB 1.1 interface
Ignition signal ONE
Power Supply DC 5V- 36V power input
Power output the output voltage 12V/2A

Mini SD card mobile DVR M602 user manual
2.The product structure introduction
2.1 Product Connection Port Instruction
LED1
LED2
LED3
LED4
LED5
LED6
LED7
J16
J7
98110
J6
1 3
2 4
J31
4 23
1
1
6
J27
10
5
51
J17
J13
J14
6
U20
J23
J28
115
16 2 11
12
J18
12
2
111
1
1 2
19 20
J30
J29
1
11
10 20
J19
1
1

Mini SD card mobile DVR M602 user manual
Code Number Function Discription
J6 Power input port 1: GND 2: GND 3: 5-32V input 4: Ignition singal
ACC
J7 USB1.1 port 1: +5V power supply 2: USB_D- 3: USB_D+ 4: GND
J13 HDD key port 1: GND 2: HDD lock signal
J14 USB2.0 port 1: GND 2: OTG_DP 3: OTG_DM 4: 5V power supply
5: +5V power supply 6: 3G reset signal
J16 Video output port
J17 RS232 extending port 1: +5V power supply 2: +3.3V power
su
pp
l
y
3: RS232_TXD2 4: RS232_RXD2
5: GND
J18 SD card extended
p
ort 1: GND 2: +12V power supply 3: SD_WP 4: SD_DATA2
5：SD_DATA0 6: GND 7: SD_DATA1 8: SD_DATA3
9: SD_DATA1 10: SD_CARDIN
11: SD
card3.3V power
su
pp
l
y
12: GND
J19 USB1.1 port 1: GND 2: USB_D+ 3: USB_D- 4: +5V power
su
pp
l
y
J23 SD card port
J27 User IO port 1: +12V power
su
pp
l
y
2: +12V power supply 3: RS485_B 4: RS485_A
5: GND 6: Alarm input 1 7: Alarm input
28: Alarm input 3
9: Alarm input 4 10: GND
J28 Front panel extended
port 1: Power indicator 2: Run indicator 3: Alarm indicator
4: Video loss
indicator
5: Recording
indicator 6: SD card indicator 7: NC 8: Infrared
9: GND 10: GND 11: GND 12: Video Output
13: +5V power
supply 14: +5V power supply 15: Single- chip machine
16: Single-chip
machine
J29 Video and audio
input output port 1: Audio output 2: GND 3: Audio A1 input 4: GND
5: Audio A2 input 6: GND 7: Audio A3
in
p
ut 8: GND
9: Audio A4 input 10: GND 11: Video
out
p
ut
12: +12V power
su
pp
l
y
13: Video V1 input 14: +12V power
su
pp
l
y
15: Video V2
in
p
ut
16: +12V power
su
pp
l
y
17: Video V3 input 18: +12V power
su
pp
l
y
19: Video V4
in
p
ut
20: +12V power
su
pp
l
y
J30 Video and audio
in
p
ut out
p
ut
p
ort 1: Audio output 2: Video output 3: GND 4: +12V power su
pp
l
y
5: Audio A1 input 6: Video V1 input 7: GND 8: +12V power
su
pp
l
y
Connection Port Definition
Note: either J29 or J30 is soldered only
either J7 or J19 is soldered only
J29: AV audio video output port definition
2.2 Front Panel Port Instruction

Mini SD card mobile DVR M602 user manual
⑥⑦
②③ ①④
⑤
①Status LED
②IR
③SD Card
④USB
⑤Video Out
⑥SD Card Lock
⑦SIM Card
2.2.1：Status LED
Indicator definition instruction:
Power: the power led will turn red when the power is connected; after soft-shutdown the
device, the power led will become green.
RUN: this led will flash when the device is working properly; after soft-shutdown the device, it
will turn off.
Alarm: when there is any channel alarm input, this led will turn on.
Video loss: where there is any channel video loss, this led will turn on.
Record: when the HDD is recording, this led will turn on.
SD: when the SD card is detected, the SD card led will turn on.

Mini SD card mobile DVR M602 user manual
2.3 Back Panel Port Instruction
2.3.1 : Power Supply Interface
2.3.2:Debug Serial
GND RS232_RXD
GND RS232_TXD
2.3.3: I/O Signal Interface Unit
2.3.4:Video- Audio Input And Output Interface

Mini SD card mobile DVR M602 user manual
Video-Audio
output
1CH
Video-Audio
input
2CH
Video-Audio
input
3CH
Video-Audio
input
4CH
Video-Audio
input
2.4 Remote control description
1. Power key: used to close the system, press and hold 5 seconds
2. FN key:
In the video file list, select the specified file and used to backup
used to switch the soft keyboard input.
Change the selected or not for Motion detection area setting and Cover area setting
3. MENU Key:

Mini SD card mobile DVR M602 user manual
Bring up the main menu
exit the soft keyboard
clear out all the regional settings
4. MULTI key:
Set up to 4 pictures.
5. SHIFT key: playback, used to show / hide the control bar
6. ESC key: Exit the menu.
7. ●key: enter the settings manually recording interface for manual recording.
8. The play button: play the video files.
9. VOIP key: Backspace’s shortcuts for the soft keyboard of edit box of; set the motion
detection zone set all selected.
10. MUTE button: when file playbacking, the sound / mute settings.
11. OK button: the case without the menu, press the OK button to display the system
information
3 System Operating Instruction
3.1 Start System
When connect 12V DC power supply to the device, the system starts. After the system
start-up completely, the 【POWER】indicator will become green, and the RUN indicator will
be flashing continually. There are three ways of starting the system: 1. long-press the
【POWER】button on the remote control for 5 seconds; 2. the ignition signal of the vehicle; 3.
system sets timing starting system. Note: the system will auto shutdown when unplug the lock
of the HDD.
3.2 Shutdown System
There are three ways of soft-shutdown system: 1. long-press the 【POWER】button on
the remote control for 5 seconds; 2. the ignition signal of the vehicle; 3. system sets timing
shutdown system. Through necessary processing, after about 5 seconds, the system will
shutdown and the power led will turn off and the run led will turn on.
Shutdown system by power disconnection: unplug the 12V power input, the system will
stop working. As unplug power directly may affect the HDD and SD card, we suggest you
soft-shutdown the system before unplugging the power.
3.3 Basic Operation Instruction of Menu
3.3.1 Enter Menu Mode
Enter the system menu by pressing the 【MENU】button on the remote control or clicking
the right mouse button.

Mini SD card mobile DVR M602 user manual
3.3.2 Menu Component Instruction
Menu component units mainly include:
(1) Check box: “√” means valid, blank means shield. There are two operating modes: 1.
use the 【OK】button or the 【↑】, 【↓】button on the remote control; 2. click the left mouse
button to operate.
(2) Selection box: provide two or more than 2 options, but only one option can be selected.
Press the【↑】, 【↓】button on the remote control or click the left mouse button to switch.
(3) List box: display the search result information in the list. You can select one item from
list. If you press the 【OK】button or click the left mouse button, the recording file will play; if
press the number “0” or the 【FN】key or the right mouse button, you can select/cancel the
recording file in order to backup the recording file.
(4) Edit box
a) You can switch the input character including number, uppercase and lowercase letters
and mark by the 【FN】key on the remote control.
b) You can move the cursor position by the 【←】, 【→】key on the remote control.
c) You can delete the character before the cursor by the 【viop】key on the remote
control.
d) After completing the input, press the 【MENU】key on the remote control, you can exit
the edit status.
(5) Button: used to conduct a specific function or enter the submenu. Press the 【OK】key
on the remote control or click the left mouse button to enter the submenu.
3.3.3 Exit Menu Mode
Press the 【ESC】key on the remote control or click the right mouse button, you can exit
the menu mode and switch to preview mode.
3.4 Main Menu
The menu box will pop-up when press the 【MENU】key or click the right mouse button.
This menu includes three parts.
Channel preview: single-picture switch, four-picture preview.
Shortcut operation bar: video playback, manual recording.
Menu bar: click and enter the submenu which includes Tools, Setup, PTZ, Log,
ShutDown, timing, BusInfo and Overlay.

Mini SD card mobile DVR M602 user manual
3.5 Channel Preview
Single-channel Preview: single-click the left mouse button, you can single-picture
preview; press number 1-4 on the remote control, you can single preview the corresponding
channel.
Four-channel preview: press the 【Multi】key on the remote control or single-click the
left mouse button, it can return to four-picture preview status.
3.6 Playback
1. Enter the playback operation interface
For four-channel preview interface, press the 【PLAY】key on the remote control; for
the main menu interface, press the 【OK】key on the remote control or click the left mouse
button on “Playback” can enter the playback operation interface directly.
2. File search interface instruction:
System supports searching recording file by channel number, recording type and start and
end time.
File search:
Search the recording files which meet the search conditions and they will display in
the structure list.
Note: if the recording files which meet the search conditions are more than
4000 items, the system will only display the first 4000 items. To search the
update file, please modify the search condition.
Play by time: to playback all the files within a specified time period, you can select
single channel or multi-channel. You can playback 4 channels using this button.
Backup by time: backup all the files within a specified time period to the specified
device.
3. File search results interface instruction:
Playback the specified file: left click the left mouse button on the specified file or
click the 【OK】button on the remote control, you can playback the specified file.
Select All: used to fast select all the recording files on the current page (“√” will be

Mini SD card mobile DVR M602 user manual
shown after selection) in order to backup files.
Prev: jump to the previous page
Next: jump to the next page
Goto: go to the specific page
Backup: you can use the 【FN】key on the remote control or the number “0” or the
right mouse button to make a backup mark, backup the selected recording file in
the current list box to the corresponding device (USB disk).
Cancel: return to the previous page.
4. Playback operation instruction
The buttons on the information bar below the playback screen respectively
represent: exit, pause, frame forward, slow forward, fast forward, go to the last section,
go to the next section, sound; the other information represents: play speed, real play
time, the total time of the recording file.
Cancel/display the information tip bar: press the 【shift】key on the remote control
or click the right mouse button will display/cancel the information tip bar.
Exit play: press the 【ESC】key on the remote control or click exit by mouse can
exit the play screen at any time; it will auto exit the play screen when the file is
finished.
Pause/continue play: press the 【Pause】button on the remote control can
pause/continue play.
Frame forward: under the pause mode, each click the frame forward button, it will
play 1 frame forward, namely single frame mode play.
Adjust the play speed: press the 【Slow Play】button will reduce the play
speed. There are 1/2, 1/4, 1/8 time speed for selection; 【Fast Play】will
increase the play speed, there are 2, 4, 8 time speed for selection.
Last section: when play by time, press 【Last Section】, the system will play
the last file directly.
When playback by selecting file, press 【Last Section】, the file will backward
10% and play.
Next section: when playback by time, press 【Next Section】, the system will
play the next section directly.
When playback by selecting file, press 【Next Section】, the file will forward
10% and play.
Turn off/on sound: press 【MUTE】can switch between sound and mute and
there will be corresponding sound icon displaying.
Playback by time: the operation is similar to “Playback by file” except the playback
content is the recording file within the specified time period.

Mini SD card mobile DVR M602 user manual
3.7 Manual Recording
Enter manual record interface
Press【Record/●】on the remote control or click “Manual Record” by mouse can enter the
manual record interface directly.
Manual record interface instruction
The manual record operation interface is consists of the following components: channel,
status, start/stop icon mark, Start All, Stop All and Exit.
Note: for the recording started manually, it can only be stopped manually, otherwise, it
will be recording continuously.
Remind: for manual record operation, the user is required to have “Record” operation
authority. Before carrying out this operation, please confirm with the
administrator that the DVR has been installed a HDD which has been formatted
correctly.
3.8 Menu
The menu includes Tools (management tools), Setup (system setup), PTZ (PTZ control), Log
(log search), ShutDown (shutdown system), Timing (timing switch), BusInfo (bus information)
etc..

Mini SD card mobile DVR M602 user manual
3.8.1 Tools
Including HDD (HDD management), User (user management), Default (restore to default),
Clear (clear alarm), Update (software update), Time (date and time), Export(import and export
configuration) and Info (system information).
3.8.1.1 HDD Management
Check the current status, capacity and the remaining space of the specified HDD and if
the HDD was formatted.
Format: used to format the specified HDD or the SD card.
Unplug the SD card: before unplugging the SD card, uninstall the software in order to
avoid damage to the SD card or SD data; clicking for unplugging the SD card, it has to be
unplugged within 10S, otherwise, the SD card will be auto mounted after 10S. Note: the
system will restart when the SD card is unplugged illegally.
Note: 1. the new HDD or SD card installed can only be used after being formatted; 2.
the recording has to be stopped before the HDD formatted.

Mini SD card mobile DVR M602 user manual
3.8.1.2 User Management
Add user, delete user and modify user. (Other users except the Admin user don’t have the
authority to set the authorities of the other users)
Add User
Enter “User” operation interface.
1. Input New User Name
On the “User” interface, click “Add”, enter “Add/Modify User” interface, input a new user
name (like user), input type supports number, uppercase and lowercase letters and Chinese.
2. Setup Password for the New User
On the “Add/Modify User” interface, click “Password” button, enter the password setup
interface, input new password directly (password is 6 or less than 6 digits), then confirm
password. The password will become valid after confirmation.
3. Setup Rights for New User
On the “Add/Modify User” interface, mark “√” means that the user can use this right while
blank means that the user cannot use this right.
4. Save the Setup Information of the New User
After confirmation, the setup information of the new user will be saved; cancel means give
up modification.
Modify User
Enter the “User” operation interface, click left mouse button or press the 【↑】【↓】【OK】
button on the remote control to select the user which needs to be modified in the user
selection box, click the “Modify” button, enter the user modification interface, you can
modify user password and operation authority.
Note: admin administrator can modify the rights of the other users, while the
non-admin users can only modify their own login password but cannot add,
modify or delete user right.
Delete User
Enter the “User” operation interface, click left mouse button or press the 【↑】【↓】【OK】
button on the remote control to select the user which needs to be deleted in the user

Mini SD card mobile DVR M602 user manual
selection box, click the “Delete” button to delete the specified user.
3.8.1.3 Restore to Default
Restore the system configuration parameter to factory configuration, the system will auto
restart when the restore is complete.
Note: the vehicle information will not be restored to factory configuration after restoring to
default, facilitating the user to save the vehicle information.
3.8.1.4 Clear Alarm
Manually clear all the alarm output. When the alarm is cleared successfully, the system will
prompt “Alarm has been cleared successfully”, confirm and return to the page of
management tools.
3.8.1.5 Software Update
Manual update: system supports USB update: copy the update file to the root directory
of the USB disk, insert the USB disk, then click “OK” to upgrade the system manually.
Auto update: insert the USB disk with upgrade file first, when the system restarts, it will
detect the update program. If the version number of the update program is different
from the one in the system, the system will auto update. After successful update, the
buzzer will prompt and system will auto restart; if the version number of the update
program is the same as the one in the system, it will not update.
MCU update: can only adopt auto upgrade.
Note: the name of the system upgrade file is “MDVRB_v version. Bin”; the name of
the single chip upgrade file is “mpanel version. Bin”. When upgrade is complete, the

Mini SD card mobile DVR M602 user manual
system will auto restart.
3.8.1.6 Date and Time
Enter the time page of the system, you can modify the time of the system and the time
format. Note: the time can be modified when recording is stopped.
3.8.1.7 System Information
Display system related information, mainly include device name, model number, MCU model
number and software version.
Note: under preview mode, press 【OK】button on the remote control can display this
interface directly.

Mini SD card mobile DVR M602 user manual
3.8.1.8 Import and Export
Used to export the system configuration to the USB disk, or import the system configuration
from the USB disk, in order to facilitate configuring multiple devices in batch.
There are two ways of import: ①manual import: insert the USB disk with configuration file,
click OK, after successful import, the system will restart. There will be sound prompting after
successful import. ②Auto import configuration file: insert the USB disk with configuration file,
when the system starts, it will auto import the configuration file. There will be sound prompting
after successful import and the system will restart. You should unplug the USB disk
immediately.
3.8.2 System Setup
System setup includes Setup (system parameter), Record (recording setup), Image (image
setup), Alarmin (alarm input), Schedule (schedule setup), Expection (expection handling),
MTD (motion detection), PTZ (PTZ configuration) and Network.
