Recordex iMMCam AFX-150 Instruction Manual Page 3
Table of Contents
PACKAGE CONTENTS.............................................................................................................4
GETTING TO KNOW YOUR iMMCam AFX-150......................................................................5
THE INPUT/OUTPUT PANELS.................................................................................................6
CONTROL PANEL.....................................................................................................................7
REMOTE CONTROL.................................................................................................................8
SPECIAL FUNCTIONS..............................................................................................................8
TECHNICAL SPECIFICATIONS.................................................................................................9
DEVICE DRIVER INSTALLATION...........................................................................................10
VIDEOGLIDE FOR MAC OSX.................................................................................................11
XSIGHT HD VIEWER INSTALLATION....................................................................................12
MAKING THE CONNECTIONS...............................................................................................13
TROUBLESHOOTING.............................................................................................................14
RECORD PRODUCT INFORMATION.....................................................................................15
WARRANTY STATEMENT......................................................................................................16

Recordex iMMCam AFX-150 Instruction Manual Page 4
PACKAGE CONTENTS
Take a moment to confirm that you received all the items listed below:
Recordex iMMCam AFX-150
Power Adapter & Cord
Anti-Glare Sheet
Remote
QuickStart Guide
(with XSight License)
VGA D-Sub Cable
USB Cable
Optional Microscope
Adapter (28 mm)
HDMI - DVI Cable
HDMI - HDMI Cable
Carrying Case

Recordex iMMCam AFX-150 Instruction Manual Page 5
GETTING TO KNOW YOUR iMMCam AFX-150
Use the illustrations below to familiarize yourself with the Recordex iMMCam AFX-150.
Gooseneck
Pivot Point
Camera Head
LED Lamps and
Camera Lens
Control Panel
AFX-150: Rear Side View
Rear Ports
Flexible Gooseneck
Head Pivot Joints
Side Ports

Recordex iMMCam AFX-150 Instruction Manual Page 6
THE INPUT/OUTPUT PANELS
Use the illustrations below to familiarize yourself with the various ports found on the rear
and side panel of the camera.
4
6
Rear I/O Panel
# Label Description
1 DC12V:2A Power Supply Port (DC 12V)
2 ON/OFF Power Switch
3 VGA-IN D-Sub RGB Port (VGA Input) - Used for VGA Passthrough
4 VGA-OUT D-Sub RGB Port (VGA Output) - Connect to Projector/Display
1 2 3
# Label Description
5 LOCK Kensington Lock
6 HDMI HDMI Port (OUTPUT to Display) - Connect to HDMI or DVI port.
7 USB USB 2.0 Port (OUTPUT to Computer), 12 X Optical Zoom, SXGA
Resolution.
5
Right Side I/O Panel
VGA-IN VGA-OUT
USB
HDMI
7

Recordex iMMCam AFX-150 Instruction Manual Page 7
CONTROL PANEL
Refer to the illustration below and the summary table for a description of the control panel
function buttons.
Label Description
TELE Zoom in
WIDE Zoom out
UP Navigate saved images
DOWN Navigate saved images
LEFT Navigate saved images
RIGHT Navigate saved images
BRI- Reduce image brightness
BRI+ Increase image brightness
SAVE Capture current view to internal memory
DELETE Delete saved images (hold down for 3 seconds when selected in thumbnail view)
VIEW Bring up catalog of saved images, press to cycle through pages of images
ENTER Select saved image for full screen viewing
REPLAY View saved images in slideshow
SPLIT Divide display: ½ screen is frozen, ½ screen is live image
RGB Switch to VGA Passthrough (RGB-IN passed through to VGA-OUT)
FREEZE Toggle on/off image freeze mode (press again for normal view)
AUTO Automatically optimize image focus, brightness, and white balance
LED Toggle on/off the LED lamps
LIGHTS Description
RGB Lit when VGA Passthrough is active
POWER Lit when camera is powered on

Recordex iMMCam AFX-150 Instruction Manual Page 8
REMOTE CONTROL
Refer to the illustration below and the summary table for a description of the remote con-
trol function buttons.
Label Description
NOTE: most buttons are defined in the table on page 8. This table de-
fines function buttons that only appear on the remote control.
B.W/C Switch between black and white or color viewing
MIRROR Displays mirror image of current presenter view
NEAR Small nudge adjustment to AutoFocus
FAR Small nudge adjustment to AutoFocus
SHARP+ Increase edge sharpness
SHARP- Decrease edge sharpness
TEXT Increase text sharpness (toggle text/graphic
mode)
AWB Auto white balance the image
RESET Reset image settings
BLUE+ Increase blue color level (manual white balance,
remote control function only)
BLUE- Decrease blue color level (manual white balance,
remote control function only)
RED+ Increase red color level (manual white balance,
remote control function only)
RED- Decrease red color level (manual white balance,
remote control function only)
SPECIAL FUNCTIONS
Changing Output Resolution. The default output resolution of the camera is SXGA
(1280x1024 @60Hz). The VGA/HDMI output resolution can be changed to XGA (1024x768
@60Hz), SXGA (1280x1024 @60Hz), WXGA (1280x800 @60Hz) or HD (1920x1080 @ 60Hz).
To do this press the AUTO button on base control panel and hold it down for three sec-
onds. Doing so will cycle the camera through the three output resolutions 1024x768,
1280x800, 1280x1024, 1920x1080. NOTE: Not all display devices will be able to accept all
resolutions.
Deleting Saved Images. To delete the images stored to the internal memory follow
these steps:
ŸPress VIEW/ENTER and then select the image you wish to delete by using the UP,
DOWN, LEFT and RIGHT buttons.
ŸAfter the image is highlighted press the SAVE/DEL button and hold it down for three
seconds.
ŸNOTE: The images can only be deleted while in thumbnail view. Do not
enlarge/view and then try to delete. Highlight the image in the thumbnail view and
then hold down the ENTER/DEL button for three seconds.

Recordex iMMCam AFX-150 Instruction Manual Page 9
TECHNICAL SPECIFICATIONS
Feature/Specification Model: AFX-150 // Portable Gooseneck
Image Sensor 1/3” CMOS
Pixels 3.2 Mega Pixel
Zoom 12x Optical, 13x Digital (156x Total)
Lens Glass
Frame Rate 25 fps (max)
Focus Auto Focus
Image Effect Mirror/Freeze/B&W/Negative/Split
Head Rotation 270 degrees/ 45 d. pivot
White Balance Auto/Manual
Exposure Auto
Flicker Level 2 levels
Horizontal Resolution 1000TV
Shooting Area 12”x14”
VGA/RGB Output WUXGA/HD (1920x1080 @ 60Hz
SXGA (1280x1024 @ 60Hz)
WXGA (1280x800 @ 60Hz)
XGA (1024 x 768 @60Hz)
Video Input Switching VGA Passthrough Switch
RGB/VGA Pass-through Passive & Active Pass-through (power on or off)
USB 2. 0 Output (Hi-Res) USB Video Device (1280x1024)
12x Optical Zoom (12x total Zoom) with additional
Zoom through XSight HD Viewer software.
Save Images 64-JPEG to Internal Memory
Unlimited capture by USB 2.0
(Video and still capture)
Software XSight HD Viewer for Windows
VidoeGlide Video Capture for MAC
Video Input 1 VGA Passthrough
Audio Input N/A
Video Output 1 x VGA Out (XGA, SXGA, WXGA, HD/WUXGA)
1 x HDMI/DVI Out (XGA, SXGA, WXGA, HD/WUXGA)
1 x USB 2.0 (SXGA, XGA, VGA)
Audio Output N/A
Power (brick) DC 12V/2A (100-240v 50/60 Hz)
Light Source LED Lamp (adjustable: on/off)
IR Remote Yes
Carrying Case Yes
Microscope Adapter Optional
Physical Dimensions
Weight Folded: 15.25 x 8 x 2.5 (in) Open: 7.25 x 7.7x 24 (in)
Weight: 4.5 lbs
Shipping Weight: 10 lbs

Recordex iMMCam AFX-150 Instruction Manual Page 10
DEVICE DRIVER INSTALLATION
Your iMMCam AFX-150 document camera can be used as a visualizer without installing any
device drivers or additional software. However, if you wish to capture video or image stills
from your iMMCam then you will need to install USB capture software.
Hi-Resolution USB Port (Labeled : USB) (Location: Side panel)
This port is designed for hi-resolution image capture. It will support up to 1280x1024 image cap-
turedth.
TYPICAL USE Capturing hi-resolution image stills and video using XSight HD Viewer
(Windows) or VideoGlide (MAC)
MAX ZOOM Up to 12x Zoom plus 8X XSight Zoom = 96X total
DRIVER No driver pre-installation required for Windows or Mac OS X.
Simply connect camera with supplied USB cable and the OS will auto-
matically install the proper device driver and the device will be installed
as a USB Video Device.
INSTALLATION No special driver installation required. Simply plug in device, connect
the USB cable to your computer and allow the operating system to de-
tect the hardware and install the appropriate driver. This device will ap-
pear as a USB Video Device under Windows and Mac OS X.

Recordex iMMCam AFX-150 Instruction Manual Page 11
VIDEOGLIDE FOR MAC OSX
If you are running MAC OSX you will use VideoGlide to capture still images and video with
your AFX.
To Install VideoGlide go to www.recordexusa.com/myAFX.html to register your camera
and download the software. Then install the software on your computer.
Next to connect your AFX to your computer by following these steps:
1. Plug in your AFX
2. Make sure it is powered on.
3. Connect the AFX to your MAC using the supplied USB cable. Use any open USB 2.0
port on your computer.
4. The MAC OS will auto-detect the camera.
5. Next, launch VideoGlide and then select USB Video Device from digitizers on the main
menu bar.
6. Use the Snapshot or Record menu to capture still images or video from the camera.

Recordex iMMCam AFX-150 Instruction Manual Page 12
XSIGHT HD VIEWER INSTALLATION
If you are running Windows you will use XSight HD Viewer to capture still images and vid-
eo with your AFX.
Go to www.recordexusa.com/myAFX.html for instructions on downloading and installing
XSight HD Viewer. Also you will find several videos showing how to use the software.

Recordex iMMCam AFX-150 Instruction Manual Page 13
MAKING THE CONNECTIONS
The diagram below demonstrates the input and output connections the AFX supports.
USB
Capture Images & Video To Computer (optional)
To capture images and video to your computer
you will need to connect the AFX to your
computer with the supplied USB Cable, and then
go to www.recordexusa.com/myAFX.html and
download the image capture software for your
PC or Mac computer.
Use Supplied
USB Cable.
Use Supplied
Power Adapter.
Use Supplied VGA Cable.
Connect to Projector or Display Panel
Steps
For Standalone Use (with Projector)
1. Plug in power to camera.
2. Connect camera to display.
3. Turn on camera.
For Use with Computer (capture images)
4. Connect camera to computer with
USB cable.
5. Install Video Capture Software.
Connect for VGA Passthrough
6. Connect camera to computer with VGA
cable.
For more information go to:
www.recordexusa.com/myAFX.html
1
2
34
5
6
Side ports.
Rear ports.
HDMI
VGA-IN VGA-OUT
Connect the AFX to your video projector
or display panel using the VGA-OUT port
or the HDMI Port* on the camera. Use the
supplied cables or the cables that came
with your projector or display panel.
* Note regarding HDMI connectivity: Not all display devices are designed to support PC Devices. The AFX camera is designed as a PC
Device and the HDMI signal will only work on display devices equipped to handle PC Devices. If your display device will not accept the
HDMI signal from the AFX then please use the VGA cable for connectivity.
Easy VGA Passthrough Mode (Optional)
Use the supplied VGA Cable to connect your computer to your document camera. The cable will
plug into the VGA port on your computer and the VGA port on the camera labeled VGA-IN.
Press the RGB button on the camera and your computer desktop will be presented on the projector
screen. The signal is passed from your computer through to the video projector that is connected
to the document camera.
* Note regarding HDMI connectivity: Not all display devices are designed to sup-
port PC Devices. The AFX camera is designed as a PC Device and the HDMI signal
will only work on display devices equipped to handle PC Devices. If your display
device will not accept the HDMI signal from the AFX then please use the VGA ca-
ble for connectivity.

Recordex iMMCam AFX-150 Instruction Manual Page 14
TROUBLESHOOTING
Problem/Observation Solution
No image is displayed or image is
totally black or totally white.
ŸCheck that the unit is plugged in and powered
on. Press the LED button to cycle through the
lighting options to confirm the unit is on.
ŸCheck that the VGA cable is tightly connected
to the document camera and the projector.
ŸThe camera is zoomed too far in and is display-
ing only a blank portion of the document or
object. Zoom out or move object.
USB capture is not working ŸMake sure the USB cable is plugged into the
camera and the computer.
ŸUse a rear USB Port on your computer. Some
front USB ports do not have adequate band-
width and power to allow for quality image
capture.
ŸTry using the capture software provided with
the camera to rule out any issues with third par-
ty software.
ŸUnplug USB cable, restart your computer and
camera. Make connection after computer has
been logged into Windows. (resets USB ports)
Image is out of focus
ŸPress the AutoFocus button.
ŸPress the reset button
ŸTry zooming in or out a little (press Tele / Wide)
ŸUse the near/far button on the remote to man-
ually tweak the focus.
Refer to the “Quick Setup Guide” for opti-
mum camera head placement. 15-18” above
document
Image is dark or washed out ŸPress the Auto White Balance button (AWB)
ŸTry changing the lighting
ŸManually change the brightness (BRI+/BRI-)
ŸPower off camera and try again.
Image is stuck ŸPress the Freeze button to resume normal
viewing
ŸPower off the unit. Power on and try again.
VGA pass-through is not working ŸIf using a laptop/notebook make sure to switch
the display settings of the notebook to use an
external monitor.
ŸMake sure computer has not gone into sleep
mode.
Video projector is unable to project
image from camera.
ŸMake sure VGA connection is tight.
ŸTry changing the output resolution by pressing
and holding the AUTO button for 3 seconds.

Recordex iMMCam AFX-150 Instruction Manual Page 15
RECORD PRODUCT INFORMATION
We strongly recommend you fill out the information below:
MODEL NUMBER:
SERIAL NUMBER:
SOFTWARE KEY:
PURCHASED FROM:
PURCHASE DATE:
(staple copy of invoice to this manual)
SUPPORT CONTACTS
PHONE: [phone] Ext. 2
EMAIL: [email protected]

WARRANTY STATEMENT
LIMITED 5-YEAR WARRANTY RECORDEX USA AFX Document Camera (“Product”)
What is my warranty? Recordex warrants to the original purchaser only that the Product
will be free from defects in material and workmanship under normal use for a period of five
(5) years from the date of original purchase.
How long does this warranty last? Five (5) years from the date of the original purchase.
Who is responsible for Shipping? You are responsible for shipping the Product to our
Warranty Service Depot. Recordex will pay for return shipment of the repaired Product
under warranty. Return shipment will be by ground service to the 48 contiguous US states.
You are responsible for shipping to Alaska, Hawaii and any address outside of the United
States. If the Product is repaired out of warranty then you are responsible for shipping both
ways. Recordex is not responsible for any shipping damage that may occur in transit to
the service depot.
Is There A Special Warranty for Educators?
Yes, Product used in a classroom or education setting is eligible for our Replacement War-
ranty Service. Make sure our customer service representative knows that the Product is in
and educational setting and we will replace the product should a defect arise. Product will
be replaced with new or refurbished product at Recordex’s discretion. This process elimi-
nates the wait time associated with sending in the Product for repair. This warranty is of-
ten referred to as a 'hot swap' warranty.
What must I do to obtain warranty service? To obtain warranty service please contact
Recordex's Customer Service Center at 1-718-392-5380 x2 or contact your authorized Re-
cordex Dealer for assistance in filing a warranty claim. You will receive instructions on how
to properly return your product for authorized warranty repair. In order to receive warranty
service you must be able to provide an original receipt or invoice for the purchase of your
Product.
What are the limitations? Recordex's warranty shall not apply: (i) to any Product subject-
ed to accident, misuse, neglect, alteration, acts of God, improper handling, improper trans-
port, improper storage, improper use or application, improper installation, industrial or
commercial use, improper testing or unauthorized repair; or (ii) to cosmetic problems or
defects that result from normal wear and tear under ordinary use, and do not affect the
performance or use of the product. If the Product develops a covered defect within the war-
ranty period, Recordex will, at its option, either repair or replace the Product at no charge,
provided that the Product is returned during the warranty period and this is your exclusive
remedy and the entire liability of Recordex under this warranty. No warranty is made or
implied as to the effectiveness or suitability of this product for your purposes.
THE ABOVE STATED WARRANTY IS EXCLUSIVE AND REPLACES ALL OTHER WAR-
RANTIES EXPRESSED OR IMPLIED INCLUDING THOSE OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. RECORDEX WILL NOT BE HELD LIABLE
FOR ANY OTHER DAMAGES OR LOSS INCLUDING INCIDENTAL OR CONSEQUEN-
TIAL DAMAGES AND LOSS OF PROFITS OR REVENUES FROM WHATEVER CAUSE,
INCLUDING BREACH OF WARRANTY OR NEGLIGENCE.
// www.recordexusa.com // 718-392-5380 // 10-50 46th Avenue, L.I.C., NY 11101 //
