Recsea WHC-G12 User manual

Canon PowerShot G12 Waterproof Housing
Recsea WHC-G12
MANUAL
Please read this manual before use.
Seatool/Recsea
NTF CORPORATION UH Division
http://www.seatool.net

INTRODUCTION
CANON POWERSHOT G12 Waterproof Housing WHC-G12
※ Thank you for purchasing the WHC-G12 Waterproof Housing.
※ To ensure proper and safe use, please thoroughly read this manual.
※ Improper use may cause leakage causing irreparable damage to your digital camera.
※ Please check, and test the housing according to this manual prior to use.
※ Neither NTF Corporation, Resea nor their agents shall warrant or bear any responsibility
for any incident related to water leakage, damage or loss of data, unauthorized
modification, disassembly and repair; or any accident causing physical or material
damage while using this product.
※ This product is manufactured by machining methods. As a result, there may be minor
scratching or tool marks. These are a normal part of the manufacturing process, do not
effect operation of the housing or camera, and are not subject to warranty or any other
claims.
WARNING!
※ Do not store or leave housing in reach of infants or small children. The strap may cause
chocking and suffocation, or small parts may be swallowed causing injury.
※ Please remove digital camera from housing when not in use. Battery malfunction or
damage may cause fire.
※ The housing body is made of corrosion-resistant aluminum. However, saltwater can cause
rusting so be sure to rinse thoroughly using fresh water without fail.
※ Some parts of this product are made of polycarbonate which may be damaged by
chemicals or long periods direct sunlight.
CAUTION!
※ To prevent water leakage and damage, DO NOT disassemble or modify this housing.
※ Do not store the housing in areas of high humidity, high or low temperatures, or areas of
extreme temperature fluctuation. Doing so may cause deterioration of parts.
※ When diving, use a method of water entry that protects the housing from shock, which can
cause water leakage. If at all possible have housing handed to you after entering the
water.
※ This housing is designed to withstand depths of 60 meters (200 feet). Using the housing at
deeper depths may cause damage and water leakage. Use caution and monitor depth.
※ Remove O-Ring or leave housing slightly open when transporting by plane. Pressurization
of a sealed housing during transport may cause damage or make it difficult to open.
※ When opening and closing the housing be mindful of dust and other contaminants, which
may adhere to the to the O-Ring, possibly causing water leakage and damage.
※ Always check O-Rings prior to each use. Pay special attention to the grease condition and
that the O-Rings are seated uniformly in the O-Ring groove with no twists or bulges.
Neglecting to check the O-Rings prior to each use may result in water leakage and
damage.
※ The Port Lens is manufactured using hard coat acrylic. When cleaning please take care
not to scratch it.
FEATURES OF THIS PRODUCT
※ Compacted and durable, precision machined corrosion-resistant aluminum housing.
Lightweight designed to withstand depths of 60 meters (200 feet).
※ Original dial locking mechanism for easy opening and closing.
PACKAGE CONTENTS

Be sure all items listed here were included with your housing:
・ Main Housing Body
・ Diffuser
・ External Strobe Connection Mount
・ Lens Cover
・ Hand Strap
・ Reserve O-Rings (1 each for Back Cover and Port)
・ O-Ring Removal Pick
・ O-Ring Grease
OPTIONS
The following items are optional. Please contact Recsea or your local dealer if you wish to
purchase.
・ Original 2 and 3 piece Close Up Lens Set
・ Lens Mount adapter (for ST/M67/28AD)
・ Ball Joint Base
・ Wide Conversion Lens Port
・ Strobe Mask
・ Replacement O-Rings
・ Special Grease
・ Left Hand Grip Trey Assembly
・ W Grip Trey Assembly
GETTING TO KNOW YOUR HOUSING, NOMINCLATURE

ISO/Mode Double Dial
The ISO Dial is on the bottom with Mode Dial on top. When pressure is placed on the ISO
Dial and turned, both housing dials will turn but only the camera's ISO Dial setting will be
manipulated. When pressure is placed on the Mode Dial, only the Mode Dial will turn. If
due to underwater pressure the Mode Dial setting is manipulated when setting ISO:
① Apply pressure only to the ISO and turn to desired setting.
② While holding ISO portion of double dial stationary, turn Mode Dial to desired setting.
Telephoto/Wide Lock Screw
Use the Telephoto/Wide Lock Screw to lock Zoom Lever after setting wide focus when
using a dedicated optional wide port. Accidentally zooming in may cause damage to the

lens and port.
Strobe Mask/External Strobe Connection Mount Screw Hole
For External Strobe, use External Strobe Connection Mount.
Port Lock Button
Use when removing the port. While pressing the Port Lock Button, rotate Lens Port
clockwise until it stops.
※ Please refer to camera manual for explanation of button functions.
※ The housing Exposure Compensation Dial, ISO Speed Dial, and Mode Dial are designed to
turn the corresponding camera dials back and forth via friction from the o-ring that comes
in contact the camera dials inside the housing. Should the dials begin to slip, use a soft
dry cloth to wipe away any oil and other contaminates that may cause the loss of friction.
OPENING AND CLOSING THE BACK COVER
※ Please do the following operations in a clean area with low humidity and dust.
① To open, while pressing the Open & Close Lock Button, turn the Open & Close Dial to the
right (clockwise ). Due to pressurization, the back cover may be difficult to open, turn
strongly.
CAUTION! Due to pressurization, water on and around the closure by be sucked in at time of
opening. Please be sure to wipe excess water from housing before opening.
※ NOTE: Firmly press Lock Button while turning dial. Failing to do so may cause damage to
locking mechanisms.
② The back cover will open once the dial is turn completely to the right.
③ To close, seat back cover into place and press firmly (Note: Dial will turn to the left
(counterclockwise). While pressing the Open & Close Lock Button, turn the Open & Close
Dial completely to the left making sure the Open & Close Lock Button is engaged (Note: If
lock button is flush with dial base the lock is not engaged properly.)
CAUTION! Before using, please be sure the test the housing (without camera) in bucket or
aquarium if available. After use in salt water, rinse thoroughly in a bucket of fresh water

without fail, pressing all buttons several times to flush out salt deposits and other
contaminants. Allowing saltwater and contaminants to dry on housing can damage functions
and O-Ring. Clean with fresh water only, using a soft, dry cloth to wipe away water.
INSTALLING CAMERA
※ Please perform proper Housing and Port O-RING MAINTENANCE prior to installation.
※ Please conduct the following operations in a clean area with low humidity and dust.
※ Camera can be inserted with lens port attached.
1. Make sure the housing Exposure Compensation Dial, ISO Speed Dial, and Mode Dial are
pulled (or pushed) outward away from housing, and the Zoom Level is free (i.e., the
Telephoto/Wide Lock Screw is not engaged). If this is not done, the camera's dials and
will come in contact with the housing dials' internal part not allowing the camera to be
properly seated.
2. Check camera settings, and that battery charge and media storage capacity are
sufficient. Slowly and carefully install camera making sure camera does not hit housing's
internal controls. If the camera is not inserted correctly, buttons, dials, and levers may not
work properly.
3. Push housing Exposure Compensation Dial, ISO Speed Dial, and Mode Dial down and
into place.
4. After performing O-Ring Maintenance, carefully close back cover, then securely close
back cover making sure nothing is caught between the back cover and housing, and that
the Open & Close Dial is in the locked position. Double check to make sure the back
cover securely locked into place.
5. After conducting proper O-Ring Maintenance on the appropriate Port for the lens to be to
be used, attach Lens Port to Housing Port Mount.
6. Fill a bucket with water and perform Pre-Dive Check. Immerse Housing (with Port
attached) several times, starting with short intervals, gradually lengthening time, checking
for water leakage after each interval.
7. When entering water use a method of water entry that protects the housing from shock,
which can cause water leakage. If at all possible have Housing handed to you after
entering the water.
REMOVING CAMERA
CAUTION! After use in water, water will remain in gaps between housing, back cover and
Open & Close Dial. Wipe any water off housing with a soft dry towel to prevent water from
falling on camera.
1. Pull Exposure Compensation Dial, ISO Speed Dial, and Mode Dial outward away from
housing, and make sure the Zoom Level free (i.e., the Telephoto/Wide Lock Screw is not
engaged).
2. Open the back cover as instructed above.
3. Tip Housing backwards, gently sliding camera out of housing.
INSTALLING LENS PORT
※ Please perform proper Lens Port Inner Surface O-RING MAINTENANCE prior to
installation.
※ Please conduct the following operations in a clean area with low humidity and dust.
※ Recsea Housings can be used with various Lens Ports and Port Converters compatible
with a variety of lenses.
※ NOTE: Lens Port cannot be installed with External Strobe Connection Mount and Strobe

Mask attached. Please remover first.
CAUTION! Only use the proper Lens Port intended for each lens. Failure to use the proper
Lens Port could result in image vignetting and distortion, as well as possible water leakage.
1. Prepare the appropriate Lens Port for the lens to be used.
2. Lightly grease-up Lens Port's inner surface.
3. Place Lens Port over Housing Port Mount with Lens Port Lock Tab aligned with Housing's
lower right Port Mount Lens Port groove, below the Port Lock Release Button.
4. Make sure the Lens Port is resting evenly on the Port Mount and then push down onto
Port Mount.
5. With Lens Port evenly pushed down onto Port Mount, rotate Lens Port counterclockwise
until the Port Lock Button engages with an audible click.
REMOVING LENS PORT
CAUTION! After use in water, before removing Lens Port wipe any water off Housing and
Lens Port with a soft dry towel to prevent water from falling into the Housing and onto
camera.
※ NOTE: Lens Port cannot be removed with External Strobe Connection Mount and Strobe
Mask attached. Please remover first.
1. While pressing the Port Lock Button, rotate Lens Port clockwise until it stops.
2. Pull Lens Port outwards away from Housing to remove.
INTERNAL AND EXTERNAL STROBE
※ While in the Housing, the camera's on-board strobe can be used.
※ Use the Strobe Mask and External Strobe Connection Mount to connect external strobe
fiber optic cable.
Connecting fiber optic cable for external strobe use:
CAUTION! Store External Strobe Connection Mount and Strobe Mask in a secure place so as
not to lose them.
1. Using the External Strobe Connection Mount, attach the Strobe Mask by screwing the
connection mount into the connection mount Screw Hole.
2. Insert bare fiber optic end into Fiber Optic Socket.
HANDLING PRECAUTIONS
※ The port is made of polycarbonate resin (POM). Excessive vibration or impact from

dropping or striking can damage the port . Such damage is not covered by warranty.
※ The Lens is manufactured using hard coat acrylic. When cleaning please take care not to
scratch it. Should the Lens become scratched please send port to Seatool/Recsea for
replacement. (Repair fee and return shipping will be charged at normal rates)
MAINTENANCE
CAUTION! Allowing saltwater and contaminants to dry on housing can damage functions and
O-Rings possibly causing water leakage. Clean with fresh water only, using a soft, dry cloth
to wipe away water.
※ We recommend a complete Housing overhaul once every year.
1. After use in salt water, wash off salt and other contaminants by soaking empty Housing,
with Lens Port attached, thoroughly in a bucket of fresh water (lukewarm) for 10 to 20
minutes.
2. Manipulate all buttons and dials several times to flush out salt deposits and other
contaminants.
3. Wipe any water off Housing with a soft dry cloth.
4. Remove Lens Port and open Back Cover.
5. Using the O-Ring Removal Pick, remove O-Rings.
6. Clean O-Ring grooves and contact surfaces using a clean cotton swab. DO NOT clean
Housing or optional Lens Ports with volatile organic solvents or chemical cleaning agents
such as thinner, gasoline, and benzine, etc.
7. Perform O-RING GREASING & MAINTENANCE as instructed below before re-installing.
※ O-RING GREASING & MAINTENANCE ( 1)
※ Before conducting grease-up of the housing Back Cover and Port O-Rings, thoroughly
clean O-Ring grooves (cover and port), and O-Ring contact surfaces (cover and port). Be
sure to also apply a very thin layer of grease to contact surfaces.
1. Using the O-Ring Removal Pick, remove O-Rings.
2. Clean sand, salt, other contaminants and old grease from O-Rings.
3. Clean O-Ring grooves and O-Ring contact surfaces using a clean cotton swab.
4. Visually and physically check O-Ring by running it through finger tips, feeling for cuts,
cracks or any other defects that may cause leakage. Such defects will cause water
leakage, so be sure to replace the O-Ring. Be careful not to stretch or pull the O-Ring too
much.
5. Squeeze a rice grain sized bead of silicone grease on your thumb and forefinger. Taking
care not to pull or stretch the O-Rings too much, uniformly spread grease on O-Ring. Too
little grease may cause the O-Ring to twist in the groove, possibly causing water leakage.
6. Place O-Ring in O-Ring grooves, making sure that it is uniform, not twisted or bulging out,
possibly causing water leakage. When closing back cover, visually check O-Ring surface,
tracing a finger over it making sure no hair, lint or other contaminants are attached.
Important Notes:
※ When Housing is not used for long periods, remove O-Ring, place in a plastic bag to keep
them free of dust and other contaminants and store in a place out of direct sunlight.
Please also be careful of prolonged exposure to direct sunlight during use. The O-Rings
and Housing may become deformed, causing water leakage.
※ After extended periods of non-use, soak empty Housing, with Lens Port attached, in
lukewarm for half a day. Manipulate all buttons and dials several times. Using a soft, dry
cloth wipe away water.

CAUTION!
※ The O-Rings are an essential part of waterproofing for this housing. Not properly greasing
the O-Rings as direct may cause the O-Rings to twist in the O-Ring grooves, possibly
causing water leakage.
※ Always perform the above O-Ring, O-Ring groove and O-Ring surface maintenance and
greasing every time you open/close the housing.
※ Please pay close attention and make sure the O-Rings are not twisted or bulging, free of
any contaminants (dirt, hair, etc.), and that foreign objects do not obstruct proper closing
of the Housing back cover or attachment of the Lens Port.
※ DO NOT clean the Housing with volatile organic solvents or chemical cleaning agents
such as thinner, gasoline, and benzine, etc.
※ Housing Monitor is manufactured using hard coat acrylic. When cleaning use a clean soft
cloth taking care not to scratch it.
SPECIFICATIONS
Compatible Camera Canon PowerShot G12
Maximum Depth 60 meters (200 feet)
Material Main Body: Corrosion-resistant aluminum alloy,
anodized
Levers, Buttons, Dials:
POM, PC
Monitor: Hard Coat Acrylic
Screws, Springs: Stainless Steel, Galvanized
Size (Housing) Dimensions: W145mm x D122mm x H116mm
Weight (Land): Approx. 790g
Accessories Diffuser, External Strobe Connection Mount, Lens Cover,
Hand Strap, Reserve O-Rings (1 each for Back Cover and
Port), O-Ring Removal Pick, O-Ring Grease
INSURANCE INFORMATION
※ We strongly recommend insuring your camera. For more information please contact your
dealer.
CONSUMABLE PARTS
※ For replacement of consumable parts such as O-Rings please contact your dealer or
Recsea.
LIGHT/STROBE INSTALLATION
The Accessory Shoe on top of the housing can be used for installation of a target light.
Please be mindful of the weight of the light(s) you intend to use. For heavy lights and strobes
please use optional Tray Grip.
Please refrain from using lights attached to the Accessory Shoe as a carrying handle.
CAUTION! Damage is irreparable.
AFTER-SALE SERVICE
Warranty period is one (1) year from purchase for general users, ninety days for commercial

or industrial users. Recsea will repair manufacturing defects free of charge during the
warranty period when product is used in accordance with this manual. This warranty is only
valid in Japan. Damage due to customer used, and for any consumable parts, the repairs will
be charged at normal rates. Shipping costs to and from Japan shall be born by the customer
for warranty and all other cases. This warranty does not cover any damage to digital camera
for any reason, including damage caused by water intrusion. Please obtain insurance for all
your equipment. Any repairs due to the following will be charged at normal rates:
1) Repaired, modified or dissembled by person or company other than Recsea;
2) If damaged in fire, natural disaster such as earthquake, flood, lightning, etc.;
3) Damage caused by dropping, impact, vibration;
4) When returned for warranty service not accompanied with Warranty Information copy, or if
Warranty Information is altered.
※ Warranty does not cover any losses resulting from inoperability of this product, including
those related to lost profits or any related expenses.
※ Recsea will stock parts necessary for repair for five (5) years from stop of production.
※ This product uses some degradable parts, such as buttons and O-Rings. Recsea
recommends overhauling the housing once per year, more frequently if used often.
Overhaul service is charged at normal rates.

MEMO

WARRANTY INFORMATION
Warranty Period One year from purchase
Purchase Date Year Month Day
Product Name Canon PowerShot G12 Underwater Housing
Product Number WHC-G12
Dealer Name
Serial Number
※ Dealer: Stamp your company name and contact information, purchase date, model and serial
number.
Seatool/Recsea Manufacturing & Sales
NTF CORPORATION UH Division
390-1 Mii, Midori-Ku, Sagamihara-Shi
Kanagawa 252-0151, Japan
T: [phone] F: [phone]
http://www.seatool.net E-mail: [email protected]
