QUICK START GUIDE
EnterpriseProTM Router
CDMA R-3300 or R-1300
UNPACKING INSTRUCTIONS
1Unpack the Red Lion Wireless unit and verify the following
components are enclosed for the EnterpriseProTM Router
(Figure A).
Figure A: Package Contents R-3300 or R-1300:
Not Shown: Antenna included with model R-1300 or R-3300
Non-US power supplies require customer-supplied power cord to connect power to
AC power outlet
2If any items are missing, please contact Red Lion
Wireless at [phone].
3Optional item to use for Out-of-Band (OOB) Management
function of the Red Lion Wireless modem: Cisco DB9 to
RJ45 Console Cable.
CDMA MODELS R-3300 OR R-1300
R-3300-S (SPRINT); R-3300-V (VERIZON), R-3300-US (US
CELLULAR) –UNITS ARE CARRIER SPECIFIC
1 The unit will need to be activated with a cellular carrier. If
not, contact your cellular carrier and provide them with the
ESN number located on the bottom label of the unit.
2Attach the antenna.
3Attach power supply connector to the “barrel” power outlet
on the back of the unit and connect power supply plug to an
AC power outlet. Verify the POWER (green) LED is lit to
indicate that the unit is receiving power.
5Please allow 2-4 minutes for the unit to recognize the
cellular data card and connect to the cellular network. When
this has occurred the Signal Strength LEDs should light up
from 1 to 4 LEDs. Red Lion Wireless recommends 2 bars or
greater for proper functionality of the unit. If signal strength
is showing 1 LED or showing the top and bottom LEDs
flashing (1 and 4 positions), please refer to the User Manual
at www.redlion.net.
6Connect to the Ethernet RJ45 port for network connectivity.
ACCESSSING THE GRAPHICAL USER INTERFACE (GUI)
1Connect PC to EnterpriseProTM Router
The Ethernet Port on the EnterpriseProTM Router is “auto-
sensing”, which means a straight through or cross-over
cable can be used to connect to the Red Lion router.
Connect a CAT-5 Ethernet cable between the local PC and
the unit’s Ethernet port. Verify the link LED is lit.
2Setup PC IP Address
For assistance with configuring your PC, see the appropriate
Microsoft Windows support webpage listed at:
http://support.microsoft.com.
PC to Ethernet Interfaces
Select “Use the following IP address” and fill in the blank
fields with the information below:
Ethernet 0
Ethernet 1
IP address
192.168.0.2
192.168.1.2
Subnet mask
255.255.255.0
255.255.255.0
Default gateway
192.168.0.1
192.168.1.1
Preferred DNS
192.168.0.1
192.168.1.1
3Access Graphical User Interface
Open a web browser & enter the following in the
address bar:
Ethernet 0: http://192.168.0.1:10000/
Ethernet 1: http://192.168.1.1:10000/
LOGIN INSTRUCTIONS
•User Name enter:
admin (lowercase letters)
•For Password enter:
six digit serial number of unit (lowercase)
Upon successfully logging in you will see the following screen.
Figure B:GUI:
You are now connected to the Management GUI. If you should
see anything other than the GUI screen shown, please refer
to the EnterpriseProTM Router User Manual located at:
www.redlion.net.
(Front)
Power Supply
(United States)
Power Supply*
(International)
Ethernet Cable
(6’ CAT 5E 568B)

20 Willow Springs Circle •York, PA 17406 •USA •T [phone] • F [phone] •customer.serv[email protected] www.redlion.net
QUICK START GUIDE
EnterpriseProTM Router
CDMA R-3300 or R-1300
VERIFY CELLULAR CONNECTIVITY
Confirm the following on the GUI (see Figure B) after logged into
the unit:
Activation: “Succeeded” or “Unavailable”
Connection: “Enabled”
IP Address: Populated with a network IP address
Signal Strength has GREEN bars populated If you see any RED
bars represented under Signal Strength, please consult the User
Manual. WAN (Eth0) should show “Up” and show the network
issued IP address.
If you were unable to confirm this status on the Main page, please
refer to the User Manual for troubleshooting steps at
www.redlion.net.
If you are able to confirm this status, then your unit is
successfully connected to the cellular network via WAN (Eth 0).
RED LION WIRELESS TECHNICAL SUPPORT
If you have followed all of the instructions up to this point, have
satisfied yourself that you are not having an authentication problem,
are convinced that you have sufficient reception, and your unit is still
not communicating, then it is time to contact Red Lion Technical
Support at [phone], Monday-Friday from 8:45am to
5:30pm EST. We will be happy to assist you in getting your unit up,
running, and operational.
HARDWARE STATUS LED’S
Power:
Green –Power Connection Status (Power)
ON
Power being received
OFF
Power not being received
Ethernet Ports:
Green –Connection Status (Link)
ON
Connected to a network
device at 100 Mbps
OFF
Connected to a network
device at 10 Mbps
Yellow –Link & Data Transmit/Receive Activity
Status
ON –Steady
Ethernet Port has a link
established with the network
device.
ON-OFF-ON
(flickering)
Transmitting and receiving
data packets
TTYS1 (DTE):
Serial Port
Green –Data Receive Activity Status (RXD)
ON-OFF-ON
(flickering)
Receiving data packets
Green –Data Transmit Activity Status (TXD)
ON-OFF-ON
(flickering)
Transmitting data packets
SOFTWARE LICENSING TERMS & CONDITIONS
Software supplied with each Red Lion Wireless product remains the
exclusive property of Red Lion Wireless. Red Lion Wireless grants with
each unit a perpetual license to use this software with the express
limitation that the software may not be copied or used in any other
product for any purpose. It may not be reverse engineered, or used for
any other purpose other than in and with the computer hardware sold by
Red Lion Wireless.
FCC COMPLIANCE STATEMENT
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates uses and can radiate radio
frequency energy; and if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause
harmful interference to radio communications, in which case the user will
be required to correct the interference at their own expense. Warning:
Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
Information to the user:
If this equipment causes interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures: In order to meet FCC emissions limits, this
equipment must be used only with cables that comply with IEEE 802.3. If
necessary, the user should consult the dealer or an experienced
radio/television technician for additional suggestions. The user may find
the following booklet prepared by the Federal Communications
Commission helpful: “How to Identify and Resolve Radio-TV Interference
Problems”. This booklet is available from: U.S. Government Printing
Office, Washington, DC 20402, Stock No. 004-000-00345-4
WARRANTY
Red Lion Wireless provides a limited hardware warranty for the
EnterpriseProTM Router, which consists of the following: This warranty is
effective for one year from the delivery date of the EnterpriseProTM
Router to the purchaser. The purchaser is responsible for returning the
defective unit to our factory, freight prepaid. If the EnterpriseProTM
Router™is under warranty, Red Lion Wireless will repair it and return it,
freight prepaid, via standard shipping. If the EnterpriseProTM Router is
not covered by the warranty, we will notify you of the repair charges and
not repair the EnterpriseProTM Router without your permission. Repairs
are guaranteed for 90 days or the remainder of the warranty, whichever
is longer. Buyer’s remedies for breach of warranty shall be limited to
repair or replacement subject to adjustment as stated herein, or full or
partial adjustment to purchase price. The Red Lion Wireless
EnterpriseProTM Routers are provided with the following warranty:
Hardware maintenance and repair is available on a return to factory
basis. After this initial period, configuration assistance will continue to be
available on a chargeable basis. Software support does not provide for
custom code. Custom changes are available as a chargeable option.
The warranty only covers items with a serial number. Cables and
adapters are not covered.
For complete and most up-to-date warranty information go to
www.redlion.net
