RED-RING 3L WM Operator's manual
USER INSTRUCTION MANUAL
Redring Warranty
2 Year Parts
2 Year Labour
083329501 - 05/12/13
HELPLINE
344 879 3588
Contents
My Product (please complete this section) page 3
Introduction page 4
Warranty page 4
Important Information page 5
Installation page 5
Before Connection to the Power Supply page 7
Water Connection page 7
Electrical Connection page 7
Other Safety Considerations page 8
Controls page 11
Operating the appliance page 11
After Use page 12
Cleaning Instructions page 13
page 14
Spareslist page 18
FAQ’s page 16
Contact Information page 17
My Product
Please complete the form below:
place. This will save you time if you need to contact our After Sales team.
IMPORTANT:The serial number can be found on the bottom of your appliance.
Model Number:
Product Code:
Serial Number:
Date of Purchase:
/ /
Purchased from: ..................................................................................................
3
Introduction
•
•
contact our After Sales team on 0344 879 3588
Warranty
Your water boiler comes with a 2 year parts and 2 year labour warranty from the date of purchase.
0344 879 3588
Your warranty is given subject to the appliance being used in accordance with the instructions sup-
-
The products are intended for commercial use as detailed in these instructions. The Company has a
policy of continuous improvement in product quality and design. The Company therefore reserves the
The warranty does not cover damage or defects arising from poor maintenance - incuding build up of
limescale
4
Important Information
The use of an electrical appliance requires the following common sense safety rules. Primarily there is
a danger of personal injury and secondly damage to the appliance and property.
These are indicated in the instructions by the following two conventions:
The installation of the unit must be performed by a compe-
• IEE Regulations
• BS Codes of Practice
• Local and National Building Regulations
• Local and National Water Regulations
This appliance must only be used for heating water.
Installation
It is essential that this appliance is installed correctly. Installation should comply with all local electri-
or other suitably robust surface with
appropriate fittings by a qualified fitter.accept any responsibility for the
safety of any unit not installed this way.
suitable wall plugs.
Remove the outer casing following the instructions as detailed and secure the boiler to the wall using
5mm (10g) screws.
3) Pull entire case forward
5) Re-assemble product by reversing steps 1-3
5
Location:
•Ensure the appliance is on vertical surface and the base of the appliance is horizontal.
•Consideration should be given for serving requirements.
•
•Ensure that safe operational access to the appliance is unrestricted.
•
low ceilings that are susceptible to damage from water vapour.
•
•
•All water boilers should be installed 100mm from any adjacent surfaces.
•
•
the manufacturer.
•Appliances to be operated in ambient temperature 5°C – 30°C.
This appliance is only to be installed in locations where it is overseen by and where clean-
ing and maintenance is restricted to trained personel.
-
Supply Cord:
•
•
•
hazards.
•
when descaling the product.
6
Product Safety:
•The water boiler is only to be installed in locations where it is overseen and where mainte-
nance is restricted to trained personnel.
•
Metal surfaces may become very hot whilst in operation.
Use caution when touching these surfaces.
Before Connection to the Power Supply
•
•
by
calling 0344 879 3588.
•Remove any protective coating from the outer panels.
•
-ance.
Water Connection
•Connection to the cold water supply and the appliance is made via the hose supplied.
•
Electrical Connection
•-
•
•Isolation switches for the appliance must not be obstructed and accessible.
•
in water or any other liquid.
Electrical Requirements:
which must be A.C. (Alternating Current).
7
•
There may be some steam emissions from the vent at the base of the appliance during the initial
Other Safety Considerations
•Isolate the appliance from the mains supply when cleaning or not in use.
•
•
•-
•
repair.
•
invalidate warranty.
•
Only clean with a soft damp cloth.
•
•Scale formation within hot water appliances is problematic and more so in hard water areas.
notes on de-scaling.
•Use only the supplied parts with the appliance. Introducing foreign components not approved
by the Manufacturer may cause tainting of the water and may also invalidate your warranty.
•
•Maintenance other than cleaning and descaling should be carried out by the manufacturer
while this product is within guarantee.(Contact our service helpline on 0344 879 3588).
•Warranty is only valid in the UK.
8
This appliance is not intended for use by persons (including
or instruction concerning use of the application by a person responsible
for their safety.
Turn off the power supply cleaning or before replacing any
parts.
Model 3L WM 5L WM 7.5L WM
Height (mm) 347 497
Width (mm) 344
279
Capacity (Litres) 3 5 7.5
Weight (Kg) empty
Weight (Kg) full
4.8
7.8
6.2
11.2
6.2
13.7
Ambient Temp 5°C – 30°C
Water Inlet Pressure 0.1 – 0.8(Mpa)
Voltage 240V (50/60Hz)
Power Rating
9
for the purpose of maintenance or emergency.
warranty.
lid for descaling
(inside unit)
On/Off
switch
Neon
Indicator
Hose for connection to
10
11
– Appliance is on
– Appliance requires descaling or maintenace
– Turn appliance on/off
Appliance
12
Connection to a water supply:
Remove the outer casing (see installation). Push Blue pipe
Connection to mains water supply:
your main water supply.
activates. Ensure boiler is connected to the mains water supply.
Tap function:
position and you will receive water from the tap until the tap
Push Blue pipe
into this tting
Hold to
receive hot
water
13
We recommend cleaning your water boiler on a regular basis. Failure to do this may result in the appli-
ance not operating to its full potential and could invalidate your warranty.
Isolate from the electrical supply before cleaning and allow water boiler to
cool.
away from the mains lead and connections.
THERE ARE 2 WAYS WHICH YOU WILL NEED TO CLEAN YOUR AUTO FILL WATER BOILER:
EXTERNALLY; TO DO THIS, FOLLOW THE EXTERNAL CLEANING GUIDELINES.
INTERNALLY; TO DO THIS, FOLLOW THE DESCALING PROCEDURE.
IMPORTANT: DO NOT USE ANY ABRASIVE CLEANING FLUIDS OR MATERIALS.
EXTERNAL CLEANING GUIDELINES:
TO CLEAN, WIPE OUTSIDE OF YOUR WATER BOILER WITH A DAMP CLOTH. IT IS RECOMMENDED
THAT THIS IS DONE DAILY. STUBBORN STAINS MAY BE REMOVED USING A GOOD STAINLESS STEEL
CLEANER OR NON-ABRASIVE CLEANING.
FAILURE TO CLEAN ON A REGULAR BASIS WILL INVALIDATE YOUR WARRANTY
This appliance shall be operated in ambient temperatures between 5-30°C.
manufacturer.
14
The descaling procedure must be performed by trained personnel as it requires the removal of pan-
els from the boiler and access to live electrical components. Always use a descaling agent suitable for
stainless steel.
1. Isolate the boiler from electrical supply.
2. oC
3.
4.
2)and pull the entire outer case assembly forward (image 3). This will give access to the water
5.
6. Add descaling agent in accordance with manufacturers instructions.
7.
8.
9. Isolate the boiler and allow to cool down.
10.
11.
12.
13.
14.
15.
16.
image 1 image 2 image 3 image 4
15
Installation Dimensions
300mm
404mm (5/7.5L)
255mm (3L)
16
FAQ’s
1. Are there any restrictions as to where I should locate my water boiler?
a.
the weight of the appliance when full of water. Consideration must also be given to serv-
ing requirements and safe operational access to the appliance must also be ensured. For
2.
a. -
3.
a.
4. The water from the tap is cold?
a.
5.
a. All new appliances must be heated and drained to sanitise.
6.
a. Your appliance comes with a 2 year parts and 2 year labour warranty. Please see the
‘Warranty’ section on page 4 for details.
7. Can I purchase any replacement parts?
a.
Please do not hesitate to contact our Spares department on
0344 879 3588 and they will be happy to assist.
17
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
......................................................................................................................................................................................
Web :
Telephone:
General : 0344 879 3588
Post:
Glen Dimplex Heating & Ventilation
Millbrook House
Grange Drive
Hedge End
Southampton
SO30 2DF
Spare Parts Lists
18
3.0l white 22672801
No. Spare No. Key Part No. Description Qty
1 95719683 142 563259003 CASE outer WM 3L 1
2 95719787 599 703257505 PANEL front WM 1
3 95719667 952 083246600 CASE lid front 2
4 95719654 701 082569400 PLUG hole blanking 14.7mm 2
5 95719661 275 083212000 ELBOW 3/8-1/4 JG P1211208S 1
6 95719659 286 083211700 ELEMENT 3Kw submersible 1
7 95719676 374 083336000 GASKET level sensor 1
8 95719665 509 083213501 INSULATION lid WM 1
9 95719677 551 503257900 LID tank WM 1
10 95719652 556 11294 Gas Catering Tap (Locknut) 1
11 95719664 5770 083213100 SENSOR eyelet NTC 1
12 95719674 637 083317400 PIPE steam stat 1
13 95719668 730 083256000 SEAL tank WM 1
14 95719670 739 083256204 SENSOR level WM 3L 1
15 95719657 786 083211301 VALVE solenoid 3/4”m-m rest 1
16 95719666 803 083213900 SPRING xing 1
17 95719681 895 533259701 TANK assy weld AF WM 3L 1
18 95719653 911 62695 135 Deg (10amp) DISC STAT 1
19 95719658 974 083211500 VALVE isolation 15mm BES10406 1
20 95719651 977 9408 HARD RED FIBRE WASHER 1
21 95719673 977 083256400 WASHER bre dia 12 ID 2
22 95719672 196 083256304 CONTROLLER 3KW STD (90250070) 1
23 95719656 637 083210901 PIPE tube tap WM 1
24 95719663 894 083212700 TAP tomlinson 1/2” MSBRH 1
25 95719655 037 083210300 SURROUND tap 1
26 95719675 436 083321000 HARNESS 3KW AF WM 1
27 95719660 003 083211800 APAPTOR 3/4-1/4 JG C1320816S 3
28 95719662 637 083212300 TUBE 1/4LLDPE PE-08-BI-0500F-B 2M
19
3.0l stainless 22672805
No. Spare No. Key Part No. Description Qty
1 95719679 142 503259001 CASE outer WM 3L 1
2 95719685 599 703257503 PANEL front WM 1
3 95719667 952 083246600 CASE lid front 2
4 95719654 701 082569400 PLUG hole blanking 14.7mm 2
5 95719661 275 083212000 ELBOW 3/8-1/4 JG P1211208S 1
6 95719659 286 083211700 ELEMENT 3Kw submersible 1
7 95719676 374 083336000 GASKET level sensor 1
8 95719665 509 083213501 INSULATION lid WM 1
9 95719677 551 503257900 LID tank WM 1
10 95719652 556 11294 Gas Catering Tap (Locknut) 1
11 95719664 5770 083213100 SENSOR eyelet NTC 1
12 95719674 637 083317400 PIPE steam stat 1
13 95719668 730 083256000 SEAL tank WM 1
14 95719670 739 083256204 SENSOR level WM 3L 1
15 95719657 786 083211301 VALVE solenoid 3/4”m-m rest 1
16 95719666 803 083213900 SPRING xing 1
17 95719681 895 533259701 TANK assy weld AF WM 3L 1
18 95719653 911 62695 135 Deg (10amp) DISC STAT 1
19 95719658 974 083211500 VALVE isolation 15mm BES10406 1
20 95719651 977 9408 HARD RED FIBRE WASHER 1
21 95719673 977 083256400 WASHER bre dia 12 ID 2
22 95719672 196 083256304 CONTROLLER 3KW STD (90250070) 1
23 95719656 637 083210901 PIPE tube tap WM 1
24 95719663 894 083212700 TAP tomlinson 1/2” MSBRH 1
25 95719655 037 083210300 SURROUND tap 1
26 95719675 436 083321000 HARNESS 3KW AF WM 1
27 95719660 003 083211800 APAPTOR 3/4-1/4 JG C1320816S 3
28 95719662 637 083212300 TUBE 1/4LLDPE PE-08-BI-0500F-B 2M
20
5.0l white 22673801
No. Spare No. Key Part No. Description Qty
1 95719682 142 563259002 CASE outer WM Whi 1
2 95719686 599 703257504 PANEL front WM 1
3 95719667 952 083246600 CASE lid front 2
4 95719654 701 082569400 PLUG hole blanking 14.7mm 2
5 95719661 275 083212000 ELBOW 3/8-1/4 JG P1211208S 1
6 95719659 286 083211700 ELEMENT 3Kw submersible 1
7 95719676 374 083336000 GASKET level sensor 1
8 95719665 509 083213501 INSULATION lid WM 1
9 95719677 551 503257900 LID tank WM 1
10 95719652 556 11294 Gas Catering Tap (Locknut) 1
11 95719664 5770 083213100 SENSOR eyelet NTC 1
12 95719674 637 083317400 PIPE steam stat 1
13 95719668 730 083256000 SEAL tank WM 1
14 95719671 739 083256205 SENSOR level WM 5L 1
15 95719657 786 083211301 VALVE solenoid 3/4”m-m rest 1
16 95719666 803 083213900 SPRING xing 1
17 95719680 895 533259700 TANK assy weld AF WM 5/7.5L 1
18 95719653 911 62695 135 Deg (10amp) DISC STAT 1
19 95719658 974 083211500 VALVE isolation 15mm BES10406 1
20 95719651 977 9408 HARD RED FIBRE WASHER 1
21 95719673 977 083256400 WASHER bre dia 12 ID 2
22 95719672 196 083256304 CONTROLLER 3KW STD (90250070) 1
23 95719656 637 083210901 PIPE tube tap WM 1
24 95719663 894 083212700 TAP tomlinson 1/2” MSBRH 1
25 95719655 037 083210300 SURROUND tap 1
26 95719675 436 083321000 HARNESS 3KW AF WM 1
27 95719660 003 083211800 APAPTOR 3/4-1/4 JG C1320816S 3
28 95719662 637 083212300 TUBE 1/4LLDPE PE-08-BI-0500F-B 2M
This manual suits for next models
2
Table of contents
Other RED-RING Boiler manuals
Popular Boiler manuals by other brands
ENERGY KING
ENERGY KING 35EKB Installation, operation & maintenance manual
Ariston
Ariston GENUS user manual
Buderus
Buderus GB142 Technical service bulletin
Ferroli
Ferroli ECONCEPT 35 C Instructions for use, installation and maintenance
Myson
Myson Apollo 30Si Installation & service instructions
REMEHA
REMEHA Gas 220 Ace 220 Installation, user and service manual
Maktek
Maktek 25 MKB-S INSTALLATION USE AND MAINTAINENCE GUIDE
AHRI
AHRI BWBBAN000045 Installation, operation & maintenance manual
Slant/Fin
Slant/Fin CARAVAN GGT-600E Application guide
Riello
Riello TAU N OIL PRO Series INSTALLATION, TECHNICAL ASSISTANCE SERVICE AND SYSTEM MANAGEMENT MANUAL
Ferroli
Ferroli ECONCEPT TECH 25 C Instructions for use, installation and maintenance
Raytherm
Raytherm 133-4001 Installation & operating instructions
Radiant
Radiant R2K 34 RAIN Installation, use and maintenance manual
Immergas
Immergas INOXSTOR 200 V2 Instruction and recomendation booklet
C&M
C&M Britony System II Plus 80 Maintenance and service guide
Riello
Riello KIS Series installer and user manual
Bosch
Bosch GREENSTAR HEATSLAVE II EXTERNAL 12/18 Users instructions and customer care guide
geminox
geminox THI 2-17 B 120 Technical instructions
