Redarc SRPA-RM User manual

Remote Monitor for
Solar Regulator
SRPA-RM
To suit SRPA0120, SRPA0240 & SRPA0360
Solar Regulators

2
THE SOLAR REGULATOR REMOTE MONITOR
The REDARC Solar Regulator Remote Monitor allows users to monitor how their solar panels are performing
and keep track of the charge state of the battery/s being used.
The unit is simple to setup and control and provides an easy to read graphical interface, which can be
modified to suit the users preferences.
WARNING & SAFETY INSTRUCTIONS
INST126-1
SAVE THESE INSTRUCTIONS — This manual
contains IMPORTANT SAFETY INSTRUCTIONS for
the REDARC Remote Monitor for REDARC Solar
Regulators.
DO NOT OPERATE THE SOLAR REGULATOR UNLESS
YOU HAVE READ AND UNDERSTOOD THIS MANUAL
AND THE SYSTEM IS SETUP AS PER THESE
INSTRUCTIONS. REDARC RECOMMENDS THAT
ANY REGULATOR/CHARGER BE INSTALLED BY A
SUITABLY QUALIFIED PERSON.
WARNING
RISK OF EXPLOSIVE GASES:
Working in the vicinity of a lead-acid battery is
dangerous. Batteries generate explosive gases
during normal operation. For this reason, it is of
utmost importance that you follow the instructions
each time you use the Regulator.
CAUTION
1. Solar Regulators should not be used by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they are
supervised or have been instructed on how to
use the appliance by a person responsible for
their safety. Children should be supervised
to ensure that they do not play with the Solar
Regulator.
2. Do NOT use the Solar Regulator to charge
non-rechargeable batteries. Doing so may
result in harm to the user and/or damage to the
regulator and/or solar blanket. Only use the
Solar Regulator for charging standard lead acid,
calcium content, Gel & AGM type 12V batteries.
3. Check the battery manufacturer’s data for your
battery and ensure that the voltage of the
charging profile you select does not exceed the
manufacturer’s recommended maximum
charging voltage. If the absorption and boost
voltage for your battery type is too high, please
select another charging profile. Do not change
the original settings without confirming the
battery manufacturer’s recommendations or
consulting the battery manufacturer.
4. The Solar Regulator is not intended to supply
power to a low voltage electrical system
other than to charge a battery.
5. NEVER smoke or allow a spark or flame in
vicinity of battery or engine. This may cause
the battery to explode.
6. The remote monitor is not waterproof or
designed for installation under bonnet or
outdoors. Ensure the monitor is installed in a
cool and dry environment.
7. PERSONAL SAFETY PRECAUTIONS
To assist with the safe operation and use of the Solar
Regulator:
a) Wear complete eye protection and clothing
protection. Avoid touching eyes while working
near a battery.
b) If Battery acid contacts your skin or clothing,
remove the affected clothing and wash the
affected area of your skin immediately with
soap and water. If battery acid enters your eye,
immediately flood the eye with running cold
water for at least 10 minutes and seek medical
assistance immediately.

3
WARNING & SAFETY INSTRUCTIONS
c) If Battery acid contacts your skin or clothing, remove the affected clothing and wash the affected area
of your skin immediately with soap and water. If battery acid enters your eye, immediately flood the eye
with running cold water for at least 10 minutes and seek medical assistance immediately.
1. Designed for use with the REDARC SRPA solar regulator only.
2. The screen backlight will increase the current draw. Timing and durations of the backlight can be
adjusted to suit individual needs.
3. The communication data cable is an 8-Pin RJ45 type Ethernet cable. If a cable of different
length is required. REDARC recommend buying a cable of the required length rather than
shortening the supplied cable.
4. Do not forget your password. The factory default password is ‘000000’.
5. This user manual is to be read in conjunction with the REDARC SRPA Solar Regulator user manual.
CONTENTS
THE SOLAR REGULATOR REMOTE MONITOR ............................................................................2
WARNING & SAFETY INSTRUCTIONS ......................................................................................2
1 INTRODUCTION ...............................................................................................................4
1.1 Dimensions ................................................................................................................4
1.2 Mounting ...................................................................................................................4
2 MONITOR OPERATION......................................................................................................5
3 MONITOR INFORMATION ..................................................................................................6
3.1 Monitoring .................................................................................................................6
3.2 Menu ........................................................................................................................7
3.3 Device Information ......................................................................................................8
3.4 Control Parameters......................................................................................................8
3.5 Device Parameters.....................................................................................................11
3.6 Device Password ......................................................................................................11
3.7 Failure Information ....................................................................................................12
3.8 Meter Parameters......................................................................................................12
4 REMOTE MONITOR CABLE (8-PIN RJ45 10 M/32.8 FT) ...................................................13
5 WARRANTY...................................................................................................................14

4
1 INTRODUCTION
1.1 Dimensions
114 mm / 4.5"
114 mm / 4.5"
98 mm / 3.9"
98 mm / 3.9"
84 mm / 3.3"
84 mm / 3.3"
1.2 Mounting
CAUTION
The remote monitor is not waterproof or designed for installation under bonnet or outdoors. Ensure
the monitor is installed in a cool and dry environment.

5
2 MONITOR OPERATION
System Status
Volts S-Pnl
Amps Charge
Volts Batt
16.2
0.9
14.6
09:39:54
01 01 2013
Charging Logs
Month:
Total:
Day:
0.0kWh
0.0kWh
0.0kWh
Battery Info 1/3
Status: Normal
Fault: No
Mode: Absorb Battery Info 2/3
Max Volts:
Min Volts:
15.0
12.0
Battery Info 3/3
Current:
S.O.Charge:
Voltage:
0.9A
92%
14.6V
S-Panel Info 1/2
Amps:
Power:
Volts:
0.9
16.8W
16.2 S-Panel Info 2/2
Status: Normal
Regulator Info
Temp :
Status:
26.2°C
OK
3.Control Para.
4.Device Para.
2.Device Info.
1.Monitoring
7.Meter Para.
6.Failure Info.
5.Device PSW.

6
3 MONITOR INFORMATION
3.1 Monitoring
System Status
This screen shows the essential voltage and charging status of your
system:
Volts Batt The voltage level of the battery
System Status
Volts S-Pnl
Amps Charge
Volts Batt
16.2
0.9
14.6
Volts S-Pnl The input voltage from the solar panel
Amps Charge The real time charging performance in amps
Date and Time
This screen shows the date and time:
Date MM–DD–YYYY format
09:39:54
01 01 2013
Time 24hrHH:MM:SS format
Note: The date and clock can be set in the Device Parameter menu
Charging Logs
This screen shows the charging performance of the system since it was
connected:
Day Power supplied in the last 24 hours
Charging Logs
Month:
Total:
Day:
0.0kWh
0.0kWh
0.0kWh
Month Power supplied in the last 30 days
Total Total power supplied since connection
Battery Information (3 screens)
These screens show detailed battery information:
Mode The current charging stage/mode:
No charge, Boost, Absorb or Float
Battery Info 1/3
Status: Normal
Fault: No
Mode: Absorb
Status The battery status: Normal etc.
Fault Fault diagnostics, if a fault has occurred
Max Volts The maximum voltage the battery has reached
Min Volts The minimum voltage the battery has reached
Voltage The battery real time voltage
Current The Charging current into the battery
S.O.Charge The State of Charge of the battery in percentage

7
3 MONITOR INFORMATION
Solar Panel Information (2 Screens)
These screens show detailed solar panel information:
Volts Solar panel real time voltage
S-Panel Info 1/2
Amps:
Power:
Volts:
0.9
16.8W
16.2
Amps Solar panel real time amperage from the panel
Power The calculated power (watts) the panel is producing
Status The solar panels charging status (Normal, No Charge)
Normal — Charging without error or fault
No Charge — No solar panel or battery connected,
check wiring or system
Regulator Information
This screen shows you detailed regulator information:
Temp The regulators internal temperature (displayed in °C)
Regulator Info
Temp :
Status:
26.2°C
OK
Status The regulators status
Pressing the ‘ESC’ from any screen will take you to the ‘MENU’ list.
3.2 Menu
These screens show detailed battery information:
1. Monitoring Performance indicators, scroll during normal
operation
3.Control Para.
4.Device Para.
2.Device Info.
1.Monitoring
2. Device Info Information about the manufacture of the unit
3. Control
Parameters
Installation settings including battery type and size
4. Device
Parameters
Allows backlight and date/time changes
5. Device
Password
Set the device password, needed to change battery
type
7.Meter Para.
6.Failure Info.
5.Device PSW.
6. Failure
Information
If faults occur they will be logged here
7. Meter
parameters
Information on the unit

8
3 MONITOR INFORMATION
3.3 Device Information
Device Information (2 Screens)
These screens show the regulators default ratings and serial number:
Rate. Vol The regulators rated voltage 12V or 24V
Char.cur:
Rate.Vol:
20A
24V
Char. cur The regulators rated charging current
SN Internal serial number (REDARC use only)
3.4 Control Parameters
To change settings, press the ‘OK’ button, enter the device password and press ‘OK’ again.
Change the setting to the desired value and press ‘OK’ once more to save the setting.
CAUTION
Check the manufacturer’s data for your battery and ensure that the ‘Absorption’ voltage of the
profile selected does not exceed the manufacturer’s recommended maximum charging voltage. If
the ‘Absorption’ voltage for your battery type is too high, please select another charging profile. Do
not change the original settings without confirming the battery manufacturer’s recommendations or
consulting the battery manufacturer.
Batt. Type
This screen shows and allows changes to the
Battery Type & Battery size setting:
Batt. Type
Batt. AH
100AH
AGM
The Battery type can be selected from AGM, Standard and Calcium types:
AGM Is the low setting, with a maximum charge rate of 14.4V, AGM batteries are a sealed
deep cycle battery, similar to a Gel battery.
Standard Is the medium setting, with a maximum charge rate of 14.6V, Standard batteries are not
sealed and have vents/caps to allow maintenance of the water levels in the cells
Calcium Is the High setting, with a maximum charge rate of 14.8V, Calcium batteries can be
sealed or vented, they are constructed of a calcium/lead mix to improve its strength, heat
and corrosion resistance, generally used for marine or 4wd starting batteries.
OK

9
3 MONITOR INFORMATION
Batt AH The Battery amp hours can be set to offer a state of charge percentage, the range is from
1–9999Ah.
Note 1: This is a calculated guide based on the Battery Information on page 6.
Note 2: This setting is a guide only, the battery size does not need to be set for correct
function/charging.
Temp Comp. Coeff:
This screen shows and allows changes to the Temperature compensation coefficient and systems rated
voltage:
Temp Comp. The temperature coefficient is the reduction in voltage
(millivolt) per degree Celsius rise in temperature.
(displayed in °C)
Temp Comp. Coeff
Rated Voltage
Auto
−30mV/°C/12V
Rated Voltage The battery nominal voltage (12V, 24V or Auto)
Over Volt Disc.
This screen shows the Over Voltage Disconnect and Charge voltage limit setting:
Over Volt. Disc The battery voltage level that will disconnect the solar
panel and stop charging the battery
Over Volt. Disc.
Charge Limit
16.0V
16.5V
Charge limit The highest charging voltage allowed to be set.
Over Volt Rec.
This screen shows the Over Voltage Reconnect voltage setting and the Equalisation charge state:
Over Volt. Rec The battery voltage level that will reconnect the solar
panel to the battery and resume charging after a previous
high voltage disconnection
Over Volt. Rec.
Equal. Charge
----V
15.8V
Charge limit The Equalisation charging stage voltage setting.
Note: this will be zero for AGM battery setting and two 2 hours for Calcium and Standard battery types)
Absorb. Charge
This screen shows the Absorb & Float charging stage voltage levels:
Absorb.
Change
The battery voltage limit for the Absorb Stage of charging,
Absorb stage is when the battery is approaching full and
the regulator is maintaining a constant output voltage.
Absorb. Charge
Float Charge
13.6V
14.4V
Charge limit The battery voltage limit for the Float stage of charging,
Float stage is when the battery is full and will be trickle
charged from the solar panel.

10
3 MONITOR INFORMATION
Absorb. Rec.
This screen shows the Absorption Recover voltage setting and the Low Voltage Reconnect setting:
Absorb. Rec The voltage level that will re-trigger the charger
back into the Absorption stage of charge.
Absorb. Rec.
Low Volt. Rect.
11.5V
13.2V
Low Volt. Rect. Not applicable.
Under Volt. Rect
This screen shows the Under Voltage Reconnect and Under Voltage Warning voltage levels:
Under Volt. Rect The battery voltage level that will reconnect the
solar panel to the battery and resume charging
after a previous low voltage disconnection
Under Volt. Rect
Under Volt. Warn
11.5V
11.8V
Under Volt. Warn The voltage level that will trigger the LED to turn
yellow, warning you that the battery voltage is
low. At this point you should manage your loads
and disconnect or turn off non-essential loads
to save battery power.
Low Volt. Disc
This screen shows the Low Voltage Disconnect and Discharge voltage limit for the battery:
Low Volt. Disc Not applicable.
Low Volt. Disc
Discharge Limit
10.1V
10.5V
Discharge Limit Not applicable.
Equalize Time
This screen shows the Equalize and Absorption charging stage time limits:
Low Volt. Disc The time duration for the equalization charging
stage, this stage is required for battery
maintenance of permanent installations and will
trigger every 28 days
Equalize Time
Absorb Time
10min
---min
Discharge Limit This is the Absorb charging stage time duration,
this setting is defaulted to 180 minutes, and can
be adjusted from 10–180 minutes.
Note: REDARC does not recommend changing this or any of the default settings.

11
3 MONITOR INFORMATION
3.5 Device Parameters
Device Parameter (Version)
This screen shows the Remote Monitors software version and ID number:
Ver. The internal software version, this information is
for REDARC use only.
Device Parameter
ID: 001
Ver: V02.32+V7.18
ID The internal software ID number, this
information is for REDARC use only
Device Parameter (Backlight)
This screen shows and allows you to set the backlight illumination timing and date/time settings:
The screen backlight will increase the current draw. Timing and durations of the backlight can be adjusted to
suit individual needs.
Bklight The led backlight illumination time duration,
adjustable from 1–999 seconds.
Device Parameter
Bklight: 100S
01 - 01 - 2013
19:10:50
Date MM–DD–YYYY format
Time 24hrHH:MM:SS format
3.6 Device Password
This screen shows and allows you to set the password for Parameter changes:
OriPsw This is the device password before setting.
Device PSW
NewPsw:
OriPsw:
xxxxxx
xxxxxx
NewPsw This is the new device password.
Do not forget your password. The factory default password is ‘000000’.
If changed, REDARC recommend recording your new password in the box provided.
Password

12
3 MONITOR INFORMATION
3.7 Failure Information
Failure Info
This screen shows any fault information that has occurred with
the solar panel or battery connection and voltage limits:
Failure Info.
3.8 Meter Parameters
Meter Parameters (Screen 1)
This screen shows the SRPA remote monitors model number, software version and serial number:
Type The remote monitors part number (SRPA-RM)
Meter Para.
Ver:
SN:
Type:
H02.02+S02.02
201510160000001
SRPA-RM
Ver The software version, for REDARC use only.
SN The units serial number, for REDARC use only.
Meter Parameters (Screen 2)
This screen shows and allows changes to the time duration of the display default screen switching and
backlight time:
Sw—Pages Timeout / time delay in seconds before the screen
defaults back to the monitoring default page.
Meter Para.
Bklight:
Sw-Pages:
020S
000S
Bklight The led backlight illumination time duration,
adjustable from 1–999 seconds.
ICES Declaration: CAN ICES-003 (B)/NMB-003(B)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment intro an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by (the party responsible for compliance) could void the user’s authority to operate the
equipment

13
4 REMOTE MONITOR CABLE (8-PIN RJ45 10 M/32.8 FT)
The Remote monitor cable is equipped with 2 different styles of plug (as shown above). In order to fit within
the remote monitor’s mounting bracket — Plug A should be connected to the remote monitor and Plug B to
the regulator.
The communication data cable is an 8-Pin RJ45 type Ethernet cable. If a cable of different length is required,
REDARC recommend buying a cable of the required length rather than shortening the supplied cable.
Plug A
Plug B
Plug B

14
5 WARRANTY
Limited Warranty
For full warranty terms and conditions, visit the link below or refer to the contact details applicable to
your region.
Australia and New Zealand
www.redarc.com.au/warranty
REDARC Electronics Pty Ltd
23 Brodie Road (North),
Lonsdale SA 5160
Australia
North America
www.redarcelectronics.com/warranty
REDARC Corporation
c/o Shallco, Inc.
308 Component Dr.
Smithfield, NC 27577
USA
Australia [phone]
New Zealand [phone]
UK/Europe [phone]
USA [phone]
Canada [phone]
Mexico [phone]
Design and specifications are subject to change without notice. | Copyright © 2021 REDARC Electronics Pty Ltd. All rights reserved.
REDARC® and THEPOWEROFREDARC® are trademarks of REDARC Electronics Pty Ltd.

15
NOTES

Australia
[e-mail]
www.redarc.com.au
[phone]
New Zealand
[email protected].nz
www.redarcelectronics.co.nz
[phone]
North America
[email protected]
www.redarcelectronics.com
United States
[phone]
Canada
[phone]
Mexico
[phone]
UK/Europe
[email protected]
www.redarcelectronics.eu
[phone]
www.redarc.com.au
INST126-1
