Redback EP20 User manual

RedBack_EP20-EP40-EP60_ 2016 10:37 10
EP20 / EP40 / EP60

RedBack_ EP20-EP40-EP60_. 2016 10:37 10
Symbols used in this manual
CAUTION!
Denotes a potentially dangerous situation. Non-observance of this warning may result in injury or
damage to property.
NOTE
Denotes application tips and important information.
Symbols on the power tool
Safety instructions for Li-ion batteries
Read all safety warnings and all instructions. Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injuries. Save all warnings and instructions for future
reference.
Do not open the battery.
There is a risk of a short-circuit.
Protect the battery from heat, e.g. from continuous exposure to sunlight, fire, water, and humidity.
There is a risk of explosion.
In case of damage and improper use of the battery, vapors may be emitted. Ventilate the area and
seek medical help in case of complaints. The vapors can irritate the respiratory system.
Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
Use only original batteries with the voltage indicated on the rating plate of your electric power tool. If
other batteries are used, e.g. imitations reconditioned batteries or third-party products, there is a risk
of injuries as well as damage caused by exploding batteries.
The battery voltage must match the battery charging voltage of the battery charger. Otherwise, there
is a risk of fire and explosion.
Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with another battery pack.
Pointed objects, such as nails or screwdrivers, or external forces may damage the battery. This may
cause an internal short-circuit and the battery to burn, smoke, explode or overheat.
NOTE
The batteries EP20, EP40, EP60 are certified according to IEC62133 (see page11).
Disposal information
7)!
(
See page
Direct current (DC)
WARNING!

RedBack_EP20-EP40-EP60_ 2016 10:37 10
Overview
Different batteries are described in these instructions.
1 Battery
2 Contacts
3 Release button
4 LED for battery state of charge indicator
5 Button for battery state of charge indicator
Technical specifications
replaced. Illustrated battery may differ in detail from the one which you purchased.
The indicator goes out after 5 seconds. If the LED flashes, the battery must be recharged.
If the LED not lights up after the button is pressed, the battery is faulty and must be
Li-ion battery
Battery type
Nominal voltage
V
40
Capacity
Ah
2
4
6
Operating
temperature
°C
0...40
Weight
kg
0.9
1.3
1.7

RedBack_ EP20-EP40-EP60_. 2016 10:37 10
Battery state of charge
 Press the button to check the state of charge at the state of charge indicator LED.
Information to ensure a long battery service life
–Never charge batteries at temperatures below 0°C or above 40°C.
–Do not charge batteries in an environment that has high air humidity or at a high ambient
temperature.
–Do not cover batteries and/or the battery charger during the charging process. Battery and
charger heat up during the charging process. This is perfectly normal! Lithium-ion batteries do not
exhibit the well-known “memory effect”. Nevertheless, before a battery is recharged, it should be
fully discharged and the charging process always runs to the end.
NOTE
–Follow the instructions for charging the battery in the operating instructions for the electric
power tool and the battery charger.
–Reduced operating times after recharging indicates that the battery is worn out. The battery
must be replaced. If the batteries are not used for a prolonged period, store batteries partially
charged and in a cool location (10–25 °C).
Transport
The equivalent lithium content of the batteries included in the product package is below the appropriate
limit values. Therefore, the battery as an individual component as well as the power tool and its product
package are not subject to national or international dangerous goods regulations.
If several machines with lithium-ion batteries are transported, these regulations may become relevant
and special safety measures may be required (e.g. for the packaging).
In this case, find out about the currently valid regulations for the country of use.
CAUTION!
Do not install batteries that have a damaged casing into the product.
CAUTION!

RedBack_EP20-EP40-EP60_ 2016 10:37 10
Disposal information
Recycling raw materials instead of waste disposal.
Devices, accessories, and packaging should be recycled in an environmentally friendly manner.
Plastic parts are identified for recycling according to material type.
WARNING!
Do not throw accumulators/batteries into the household waste, fire or water. Do not open disused
batteries.
Accumulators/batteries should be collected, recycled or disposed of in an environmentally friendly
manner.
EU countries only:
In accordance with Directive 2006/66/EC defective or used batteries must be recycled.
NOTE
Please ask your dealer about disposal options!
Guarantee
This product has been manufactured to the highest quality standards. When a new product is
purchased, it is guaranteed a 24-month manufacturer’s warranty which comes into force on the date
the product was purchased. The guarantee covers only defects which can be attributed to a material
and/or production fault as well as nonperformance of warranted characteristics. When making a claim
under the guarantee, enclose the original sales receipt with the purchase date. Repairs under the
guarantee may be carried out only by workshops or service centers authorized by the manufacturer.
A claim may be made under the guarantee only if the power tool has been used as intended.
This warranty is invalid where defects are caused by or result from:
–misuse, abuse or neglect;
–commercial use (industry, craft, rental)
–repairs attempted by unauthorized repair centers
–damage caused by external effects, foreign objects, substances or accidents.

RedBack_ EP20-EP40-EP60_. 2016 10:37 10
TEST REPORT
IEC 62133
Secondary cells and batteries containing alkaline or other non-acid
electrolytes – Safety requirements for portable sealed secondary
cells, and for batteries made from them, for use in portable
applications
Report Number. ..............................: 140701525SHA-001
Date of issue ...................................: 2014-10-16
Total number of pages .................... 7
Applicant’s name ............................: Ningbo NGP Industry Co., Ltd.
Address ...........................................: No. 88, Lane 666, Jinshan Road, Investment Center, Ningbo,
Zhejiang, P. R. China
Test specification:
Standard ..........................................: IEC 62133: 2012 (Second Edition)
Test procedure ...............................: CB Scheme
Non-standard test method.............: N/A
Test Report Form No. .....................: IEC62133B
Test Report Form(s) Originator .... : UL(Demko)
Master TRF ......................................: Dated 2013-03
Copyright © 2013 Worldwide System for Conformity Testing and Certification of
Electrotechnical Equipment and Components (IECEE), Geneva, Switzerland. All rights
reserved.
This publication may be reproduced in whole or in part for non-commercial purposes as long as the IECEE is acknowledged as
copyright owner and source of the material. IECEE takes no responsibility for and will not assume liability for damages resulting from
the reader's interpretation of the reproduced material due to its placement and context.
If this Test Report Form is used by non-IECEE members, the IECEE/IEC logo and the reference
to the CB Scheme procedure shall be removed.
This report is not valid as a CB Test Report unless signed by an approved CB Testing
Laboratory and appended to a CB Test Certificate issued by an NCB in accordance with
IECEE 02.

RedBack_EP20-EP40-EP60_ 2016 10:37 10
Test Report issued under the responsibility of:
This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client.
Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any
party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this
report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the
Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved
in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by
itself does not imply that the material, product, or service is or has ever been under an Intertek certification program.
EP20
EP40
EP60
Test item description .....................: Lithium battery pack
Trade Mark ......................................: REDBACK
Manufacturer ...................................: Same as applicant
Model/Type reference ....................: EP20, EP40, EP60
Ratings............................................: DC 40V, EP20: 2,0Ah, EP40: 4,0Ah, EP60: 6,0Ah
