Redmond RAG-241-E User manual

Halogen Oven RAG-241-E
User manual

2
A1
1
2
3
4
5
6
7
8 9
10
11
12

3
RAG-241-E GBR
A2
POWER
MIN Off
10
20
30
40
50
60
250
225
200
175
150
125
Defrost
Wash
Off
oC
HEAT
1 4
5
2
6
7
2
3

4
GBR ........................................................................................................................................................................................5
FRA.......................................................................................................................................................................................13
DEU ......................................................................................................................................................................................22
NLD ......................................................................................................................................................................................31
ITA.........................................................................................................................................................................................40
ESP.......................................................................................................................................................................................49
PRT .......................................................................................................................................................................................58
DNK......................................................................................................................................................................................67
NOR......................................................................................................................................................................................75
SWE......................................................................................................................................................................................83
FIN........................................................................................................................................................................................91
LTU .......................................................................................................................................................................................99
LVA..................................................................................................................................................................................... 107
EST ....................................................................................................................................................................................115
ROU ...................................................................................................................................................................................123
HUN...................................................................................................................................................................................132
BGR ...................................................................................................................................................................................141
HRV....................................................................................................................................................................................150
SRB....................................................................................................................................................................................158
SVK....................................................................................................................................................................................166
CZE ....................................................................................................................................................................................174
POL....................................................................................................................................................................................183
RUS ...................................................................................................................................................................................193
GRC....................................................................................................................................................................................203
TUR ...................................................................................................................................................................................213
ARE....................................................................................................................................................................................224

5
RAG-241-E GBR
Carefully read all instructions before operating the unit and save them for future reference. By carefully following these instructions you can considerably prolong the
service life of your appliance.
Important Safeguards
• The manufacturer is not responsible for any failures arising from the use of
this product in a manner inconsistent with the technical or safetystandards.
• This appliance is a versatile device intended for cooking food in household
and similar applications such as: staff kitchen areas in shops,offices,and
other working environments; farm houses; by clients in hotels, motels,
and other residential type environments; bed and breakfast type
environments.Donot use theapplianceforanything other thanits intended
use outlined in this user manual. Failure to follow product instructions
may result in damage that will not be covered by the warranty. The
manufacturer is not responsible for the consequences of improper use.
•
Before installing the appliance,ensure that its voltage corresponds

the appliance rating plate or technical data).

6
• When using an extension cord, ensure that its voltage is the same


• Connect the unit to properly grounded electrical outlets to
avoid the possibility of electric shock. Using the extension
cord, ensure that it is grounded.
CAUTION! The oven, the glass lid, and the cooking pot become very
hot during operation! Use oven mitts when handling the unit.Do not
lean over the open unit to prevent burns from steam.
• Always unplug the unit after use, before cleaning, or moving.
Never handle the plug with wet hands. Do not pull the power
cord to disconnect from the outlet; instead, grasp the plug and
pull to disconnect.
•
Keep the power cord away from hot surfaces or sharp edges.
Do not let the cord hang over the edge of a table or a counter.
Do not bend, twist, stretch, or bind the power cord by force.

7
RAG-241-E GBR

will not be covered by the warranty.If the cable is damaged or requires
replacing, contact an authorized service centre only to avoid all risks!
• Do not operate the unit on soft or unstable surfaces.Do not cover the unit
with cloth or tissue during the use to prevent overheating or malfunction.
•
Keep the oven and the cooking pot at least 10 cm awayfrom combustible
materials (such as curtains, wallpaper,etc.).
• Do not operate the appliance outdoors,to prevent damages that could
be caused by foreign liquids or bodies.
• Always unplug the device from the outlet and let it cool thoroughly
before cleaning. Follow the cleaning procedures as outlined in
the “Cleaning and Maintenance Guidelines” section.
• Avoid damage to the oven.If there are any dents,crack,or other visible
damages discontinue the use.
DO NOT immerse the unit in water or wash it under running
water! Do not let the built-in fan assembly get wet.

8
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning the use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Keep the appliance
and its cord out of reach of children aged less than 8 years.
Cleaning and user maintenance shall not be made by children
without supervision.
• 
of children as they may choke on them.
• 
the repair works should be carried out by an authorized service centre.

CAUTION! Do not use the appliance in case of any malfunctions.

9
RAG-241-E GBR
Technical Specications
Model ..............................................................................................................RAG-241-E
Power...............................................................................................................700-800 W
Voltage..........................................................................................220-240 V, 50/60 Hz
Control ...........................................................................................................mechanical
Heating element................................................................................................halogen
Lid diameter........................................................................................................22.5 cm
Temperature range.........................................................................................
Time range.........................................................................................................5-60 min
Power cord length................................................................................................. 1.5 m
Package Includes
Multi-purpose halogen oven .............................................................................. 1 pc.
Metal racks:
Diameter, mm Height, mm Quantity, pcs
160 20 1
190 20 1
190 60 1
Rack removal tongs................................................................................................. 1 pc.
Metal holder.............................................................................................................. 1 pc.
Cookbook “20 Recipes”........................................................................................... 1 pc.
User manual.............................................................................................................. 1 pc.
Service booklet......................................................................................................... 1 pc.
Silicone expander-type ring................................................................................. 1 pc.
Silicone mat .............................................................................................................. 1 pc.


Oven Parts A1
1. “Power” indicator
2. Timer control knob
3. 22.5 cm diameter tempered glass lid
4. Carrying handle
5. ”Heat” indicator
6. Temperature control knob
7. Housing
8. Set of racks
9. Rack removal tongs
10. Holder
11. Silicone expander-type ring
12. Silicone mat
Control Panel A2
1. “Power” indicator
2. Temperature control knob “Off” position
3. Timer dial
4. “Heat” indicator
5. Temperature dial
6. Temperature control knob “Defrost“ position
7. Temperature control knob “Wash” position (self-clean mode)
Introducing the oven
The appliance is intended for use with heat-resistant cookware compatible with
a 22.5 cm diameter lid.
The oven cooks food by heating the air inside the cooking vessel. The halogen
heating element creates intense heat and the fan, mounted in the lid, gently
circulates the air.
Super-heated air circulates throughout the cooking vessel. The fan constantly
moves the air down and then back up, ensuring quick and even cooking.

selected cooking mode, reaching 250°C. A built-in thermostat monitors and
controls the oven temperature switching the heating element on and off when
necessary.
I. PRIOR TO THE FIRST USE
Carefully remove the unit and its accessories from the package. Dispose all
packing materials properly.

label located on the housing. The absence of the serial number will deprive

Wipe the housing with a damp cloth and let dry. To eliminate any odour during

use is not considered a defect.
After transportation or storage at low temperatures allow the appliance to stay
at room temperature for at least 2 hours before using.

10
II. OPERATING THE OVEN
Before Operating
Examine inner and outer parts of the oven for cracks,dents, or any other visible
damages.
Prepare a cooking vessel (not provided). The vessel must be made of heat-re-
sistant material and be compatible with the oven glass lid (22.5 cm in diameter)
or outer edge of silicone expander-type ring (27 cm).
Operation
1. Place a rack (low or high) into the vessel and place food on the rack.Keep
food at least 1.5-2 cm away from the lid and the sides of the vessel to
allow maximum hot air circulation.
2. 

damaged by high temperatures, and put the lid on the vessel.Ensure that

openings for steam to escape. For the supplementary surface protection
from high temperature use the silicone mat included in set.Fix the silicone


3. Plug in the oven.
4. Firmly put the carrying handle down (when the carrying handle is lifted
during the cooking cycle the oven automatically turns off).
5. Turn the timer control knob clockwise to select the cooking time, the red
indicator light will illuminate, and the fan will start its operation. The

6. Turn the temperature control knob to select the temperature according
to the recipe directions or to the “Suggested Cooking Time and Tem-
perature” section.
CAUTION! When using the oven with a multicooker do not exceed the tem-

7. The heating indicator will illuminate and the oven will start cooking. The
heating indicator can go out before the selected cooking time expires indi-
cating that the oven has reached the selected temperature. When the tem-
perature inside the vessel drops below the desired level,the heating indica-
tor will automatically illuminate indicating that the oven is heating up again.
8. After the selected time expires give the oven 10 minutes to cool down.
Take the lid off the vessel and place it on a heat resistant surface to cool
down completely.
ATTENTION! DO NOT put the hot air grill onto the silicone mat.
III. SUGGESTED COOKING TIME AND
TEMPERATURE
Food Weight, g Time, hour:min Temperature, °С
Chicken 1200 1:30 200
Beef (cut into steaks) 400 0:20 240
Pork 800 1:00 200
Tiger prawns 200 0:10 180
Potatoes (cut into wedges) 400 0:30 190
Actual cooking times will vary from suggested depending on the quality and
freshness of food, as well as your personal preferences.
IV. SUGGESTED DEFROST TIMES
Food Weight, g Time, hour:min
Chicken 500 2:00
Beef 500 2:30
Pork 500 2:30
Tiger prawns 200 0:50
V. COOKING TIPS
• Thaw frozen foods before cooking or add 10-15 minutes per 400 g of
frozen food to the suggested cooking time. To ensure thorough cooking
and crispy crust turn the food periodically during cooking.
• Place the food on the rack to allow hot air to circulate freely and to reduce
the cooking time.
• Use both racks to cook a complete meal.Keep in mind,that different foods
require different cooking times. Place the food that takes longer time to
cook on the bottom rack. Later on during the cooking cycle add the
second rack.
