1: Introduction
The RS9110-N-11-02 evaluation board provides a complete IEEE 02.11bgn
Wireless LAN evaluation platform. This basically has the RS9110-N-02
02.11bgn WLAN module mounted on it along with few other supporting
components such as 40 Mhz reference oscillator and few other passives. The
RS9110-N-11-02 is a high-performance, low-power WLAN module.
The board connects to a host processor through SDIO or SPI interfaces. It
also provides the connectivity for the WLAN module to the Vector Signal
Generator (VSG) and Vector Signal Analyzer (VSA) through a microwave
coaxial connector switch.
The RS9110-N-11-02 evaluation board facilitates you in carrying out following
tests.
•Evaluation of the end–to-end throughput performance.
•Evaluation of the Transmit and Receive performance of the radio.
Figure 1 shows the block diagram of this evaluation board.
802.11bgn
WLAN Module
RS9110-N-11-02
GPIO HDR JTAG
SPI Interface
SD Memory CONN
Microwave Coaxial
Connector with
Switch
Power Probe
SDIO Edge
Connector
Antenna
40MHz
Osc
Figure 1: RS9110-N-11-02 Evaluation Board Block Diagram
The following picture illustrates various connectors on the RS9110-N-11-02
evaluation board

Redpine Signals, Inc. Proprietary and confidential Page 6
RS9110
-
N
-
11
-
02
Evaluation
Board
User Guide
Version 1.5
Figure 2: RS9110-N-11-02 Evaluation Board and Connectors
A probe point (Jumper PB9) is provided in order to measure the total power
consumed by the RS9110-N-11-02 WLAN Module during transmit, receive,
and standby modes.
On board resistors are provided for the Mode Select, which helps the user to
switch from the SDIO host interface to SPI host interface.
A SMD-based Microwave switch connector is provided to detach the onboard
antenna, and attach external RF input/output of any signal generator/signal
analyzer through a Microwave Cable Adapter (Murata Part
Number::MXHS 3QH3000).
The following diagram illustrates how the user can connect an adapter with
Microwave coaxial cable to the switch connector.

Redpine Signals, Inc. Proprietary and confidential Page 7
RS9110
-
N
-
11
-
02
Evaluation
Board
User Guide
Version 1.5
Figure 3: RF Cable Connected to the RS9110-N-11-02 Evaluation Board
1.1: LED Functionality
The LED on the EVB provides a visual indication of association and on air traffic to
the user. If a user connects an external power amplifier in the rsi_config_vals
structure in the driver, the LED will not function as described in this section.
1) LED will remain off while driver is loaded and active
2) LED will blink to indicate any Tx/Rx traffic activity on air
3) The LED blinking/toggle timing is set to within 40ms. This enables for the naked
eye to recognize LED blinking.

Redpine Signals, Inc. Proprietary and confidential Page
RS9110
-
N
-
11
-
02
Evaluation
Board
User Guide
Version 1.5
2: Wi-Fi Data Transfer Tests
The evaluation kit allows you to carry out WLAN data transfer tests, where in
RS9110-N-11-02 EVB can be connected to any 02.11bgn Access Points and
user can run any network applications to verify the WLAN connection. You can
also evaluate the application level throughputs using this EVB.
In order to perform these tests, a Windows XP, or Linux, or Window CE based
WLAN driver is provided along with the evaluation kit.
2.1: Test Setup
If you want to evaluate the system, you need to have following test setup.
The EVB is inserted into the Laptop that has SDIO slot, and it is wirelessly
connected to an 02.11n Access Point. Data transfer tests can be performed
using any other systems in the LAN, which is connected to AP. The test setup
is shown in the figure below. The sub-net mask of the wireless interface on
the Laptop and AP should be same as that of the LAN, for which AP is
connected via Ethernet.
Please note that, in order to evaluate the Lite-Fi™ on a Windows CE or a
Windows Mobile platform, you need to replace the Laptop in the following
setup, with any of the Windows CE or Windows Mobile based SDIO platform.
Laptop
with SDIO slot
802.11n
Access Point
RS9110-N-11-02
EVB
SDIO
Ethernet
LAN
Figure : Test Setup for Throughput Measurement
The following is the list of the test setup requirements:
•Laptop with SDIO slot and Windows XP or Linux operating system, or a
Windows CE or Windows Mobile based SDIO platform.
•RS9110-N-11-02 EVB
•02.11n Access Point

Redpine Signals, Inc. Proprietary and confidential Page 9
RS9110
-
N
-
11
-
02
Evaluation
Board
User Guide
Version 1.5
2.2: Evaluation Software – Windows XP
The following table provides the description of the software package and
installation guides to be used for carrying out the WLAN data transfer tests
using an Access Point, on a Windows XP platform.
Deliverable Description
LiteFi_X_Y_Z.exe
This is an installation setup file based
on Windows XP, which will install the
Wi-Fi driver files into “C:\Program
Files\Lite-Fi”. <X_Y_Z> indicates the
driver version. For example,
LiteFi_2_1_3.exe, means 2.1.3 version
of the Windows XP driver.
LiteFi_Driver_Installation_Guide_W
indowsXP.pdf
This is a user guide which provides
instructions on following topics:
•Installation of the setup file
•Host requirements to install the Wi-
Fi driver
•Installation of the Wi-Fi driver
LiteFi_WLAN_ est_Procedure_Win
dowsXP.pdf
This is a user guide on the usage of the
driver and wireless configuration utility
to do data transfer tests under
following categories:
•11g connection with WPA/WPA2
•11n connection with WPA2
•11n connection with
Aggregation
2.3: Evaluation Process on Windows XP
You can start the evaluation process as follows:
Step 1: - Follow the instructions mentioned in the
LiteFi_Driver_Installation_Guide_WindowsXP.pdf.
Step 2: - Follow the instructions mentioned in the
LiteFi_WLAN_ est_Procedure_WindowsXP.pdf.

Redpine Signals, Inc. Proprietary and confidential Page 10
RS9110
-
N
-
11
-
02
Evaluation
Board
User Guide
Version 1.5
2. : Evaluation Software – Linux
The following table provides the description of the software package and
installation guides to be used for carrying out the WLAN data transfer tests
using an Access Point, on a Linux platform.
Deliverable Description
RS.GENR.LNX.SD.X.Y.Z.tgz
This is an installation setup file based
on Linux platform, which will install the
Wi-Fi driver files into appropriate user
directory. <X.Y.Z> indicates the driver
version. For example,
RS.GENR.LNX.SD.3.2. .tgz, means
3.2. version of the Linux SDIO driver.
LiteFi_Driver_Installation_Guide_Li
nux.pdf
This is a user guide which provides
instructions on following topics:
•Installation of the setup file
•Host requirements to install the Wi-
Fi driver
•Installation and un-installation of
the Wi-Fi driver
LiteFi_WLAN_ est_Procedure_Linu
x.pdf
This is a user guide on the usage of the
driver and wireless configuration utility
to do data transfer tests under
following categories in Linux platform:
•11g connection with WPA/WPA2
•11n connection with WPA2
•11n connection with
Aggregation
2.5: Evaluation Process on Linux
You can start the evaluation process as follows:
Step 1: - Follow the instructions mentioned in the
LiteFi_Driver_Installation_Guide_Linux_2_6_18.pdf
Step 2: - Follow the instructions mentioned in the
LiteFi_WLAN_ est_Procedure_Linux.pdf
2.6: Evaluation Software – Windows CE
The following table provides the description of the software package and
installation guides to be used for carrying out the WLAN data transfer tests
using an Access Point, on a Windows CE platform.

Redpine Signals, Inc. Proprietary and confidential Page 11
RS9110
-
N
-
11
-
02
Ev
aluation
Board
User Guide
Version 1.5
Deliverable Description
RWLPSDIO_arm_X_Y_Z.cab
This is an installation setup file for a
Windows CE or Windows Mobile based
ARM platform. <X_Y_Z> indicates the
driver version. For example,
RWLPSDIO_arm_2_1_3.cab, means
2.1.3 version of the Windows CE driver.
LiteFi_Driver_Installation_Guide_W
indowsCE.pdf
This is a user guide which provides
instructions on following topics:
•Copying the setup file
•Host requirements to install the Wi-
Fi driver
•Installation of the Wi-Fi driver
RS9110_N_11_02_WLAN_ est_Pro
cedure_WindowsCE.pdf
This is a user guide on the usage of the
driver and wireless configuration utility
to do data transfer tests under
following categories in Windows CE
platform such as HP-iPAQ PDA:
•11g connection – Open System
•11g connection with WPA
•11n connection with WPA
2.7: Evaluation Process on CE
You can start the evaluation process as follows:
Step 1: - Follow the instructions mentioned in the
LiteFi_Driver_Installation_Guide_WindowsCE.pdf
Step 2: - Follow the instructions mentioned in the
RS9110_N_11_02_WLAN_ est_Procedure_WindowsCE.pdf

Redpine Signals, Inc. Proprietary and confidential Page 12
RS9110
-
N
-
11
-
02
Evaluation
Board
User Guide
Version 1.5
3: Connector Details
This section covers the connector details of various headers.
3.1: SPI/SDIO connector
The following table provides the interface details for SPI/SDIO connector.
You should not install R12, for operating the evaluation board in SDIO Mode.
Conversely, you need to install R12 to put the board into SPI mode.
S. NO SDIO Signal Names
SPI Signal Names Connector Pin No.
1) Sdio_data2 Spi_Intrerrupt J2.1
2) Sdio_data3 -- J2.2
3) Sdio_cmd Spi_cs J2.3
4) Gnd Gnd J2.4 & 7
5) Supply Supply J2.5
6) Sdio_clk Spi_clk J2.6
7) Sdio_data0 Spi_data in J2.
) Sdio_data1 Spi_data out J2.9
3.2: GPIO Interface Header Details
S. No Signal Names Connector Pin No.
1) Supply J .1&2
2) BT-Active J .3
3) Uart_out1 J .4
4) BT_Future0 J .5
5) Uart_in1 J .6
6) WLAN_Active J .7
7) Uart_out2 J .
) BT_ Priority J .9
9) I2C_SDA J .10
10) BT_ Future1 J .11
11) I2C_SCL J .12
12) Uart_rts J .13

Redpine Signals, Inc. Proprietary and confidential Page 13
RS9110
-
N
-
11
-
02
Evaluation
Board
User Guide
Version 1.5
S. No Signal Names Connector Pin No.
13) RF_LDO_en J .14
14) Uart_cts J .15
15) Xtal_ip_en J .16
16) Power_gate_en J .1
17) Gnd J .17,19&20
3.3: SD Memory Interface
S.No. Signal Names Connector Pin No.
4) CS J9.1
5) DI J9.2
6) Supply J9.3
7) SCLK J9.4
) GND J9.5
9) DO J9.6
10) CD J9.6
Other manuals for RS9110-N-11-02
1
Table of contents
Other Redpine Signals Motherboard manuals
