Reel planTEc K70EPR User manual

Planar Combination Antenna K70EPR
GSM 900 / 1800 MHz + GPS passive Roof Mount
•Waterproof TÜV passed IP69K mounted
•Antenna available in black, white and blue other colours on demand
•Our products are RoHS- and REACH-conform
Antennas from 200 MHz to 6 GHz
01.08.2011
Reel Reinheimer Elektronik GmbH
proprietary Information. Product and
Information contained herein are
subject to change without notice.
REEL Reinheimer Elektronik GmbH
Felsweg 6a, 35435 Wettenberg, Germany
www.reel-gmbh.de Phone: [phone]
[email protected] Fax: [phone]
Site 1 of 4

GSM
GPS
Frequency Range
900/1800 MHz
Frequency
1575.42 MHz
VSWR*
< 2.0
VSWR
1.5 typ.
Peak Gain*
+2 dBi typ. (900 MHz)
Peak Gain
0 dBi typ.
-1 dBi typ. (1800 MHz)
Power max.
10 W
Technical Data
* Measured with 0.6m cable on 30x30cm ground plane
Mechanical Data
Dimensions (ØxH)
ca. 76 mm x 21 mm
Temperature Range
-40°C to +85°C (operating temperature)
Connection (Standard)
ca. 3m connecting cable RG174 with GSM/FME(f); GPS/SMA(m)
Other cablelengths and connectors see ordering example and connector list in
Internet
Antennas from 200 MHz to 6 GHz
01.08.2011
Reel Reinheimer Elektronik GmbH
proprietary Information. Product and
Information contained herein are
subject to change without notice.
REEL Reinheimer Elektronik GmbH
Felsweg 6a, 35435 Wettenberg, Germany
www.reel-gmbh.de Phone: [phone]
[email protected] Fax: [phone]
Site 2 of 4

Radiation diagram (typ.)*
* Measured with 0.6m cable on 30x30cm ground plane
GSM 900 MHz
Peak Gain: +2 dBi
GSM 1800 MHz
Peak Gain: -1 dBi
Antennas from 200 MHz to 6 GHz
01.08.2011
Reel Reinheimer Elektronik GmbH
proprietary Information. Product and
Information contained herein are
subject to change without notice.
REEL Reinheimer Elektronik GmbH
Felsweg 6a, 35435 Wettenberg, Germany
www.reel-gmbh.de Phone: [phone]
[email protected] Fax: [phone]
Site 3 of 4

Accrediation
Mounting Instructions
Ordering example
Warranty
E-Code 02 1510 high gain (A)
e 13
E-Code 02 1509 low gain (L)
e 13
E-Code 03 6371 low current (V)
e 13
The lawful warranty conditions apply.
K70 E P R _ 0300 _00 03 XX_ _
Combination antenna
Housing diameter
GSM-Frequency
GPS passive
Roof mount
3m RG 174
GSM FME(f)
GPS SMA(m)
Special assembly
•No extra ground planes are necessary for this antenna (ground plane inside).
•Mountable on all clean, smooth and rust free surfaces.
•Tightening torque on M16 nut is min. 4Nm to max. 6Nm
•Mountening bore hole is Ø 16mm (+2mm/-0mm)
•Alternatively the bottom is available as aluminum diecast with tightening torque 12 Nm to ax. 15 Nm (AL).
•Mounting on a separate support possible, if the cable entrance is watertide.
•Antenna available with waterproof cable entrance (PW or AW).
