Reel planTEc M35ZXO User manual

Planar Mobile Communications Antenna M35ZXO
GSM 850 / 900 / 1800 / 1900 MHz + UMTS Without Housing
•Our products are RoHS- and REACH-conform
•Including 868 MHz –services and DECT
01.08.2011
Reel Reinheimer Elektronik GmbH
proprietary Information. Product and
Information contained herein are
subject to change without notice.
REEL Reinheimer Elektronik GmbH
Felsweg 6a, 35435 Wettenberg, Germany
www.reel-gmbh.de Phone: [phone]
[email protected] Fax: [phone]
Site 1 of 4
Antennas from 200 MHz to 6 GHz

GSM
Frequency Range
850/900/1800/1900 + 2100 MHz
VSWR*
< 2.0 typ.
Peak Gain*
-2.5 dBi typ. (900 MHZ)
+3.5 dBi typ. (1800 MHz)
Power max.
10 W
Technical Data
* Measured with 0.6m cable on 10x10cm ground plane
Mechanical Data
Dimensions (LxBxH)
ca. 46 mm x 7 mm x 2.5 mm
Temperature Range
-40°C to +85°C (operating temperature)
Connection (Standard)
ca. 3m connecting cable RG178 with GSM/U.FL
Other cablelengths and connectors see ordering example and connector list in
Internet
01.08.2011
Reel Reinheimer Elektronik GmbH
proprietary Information. Product and
Information contained herein are
subject to change without notice.
REEL Reinheimer Elektronik GmbH
Felsweg 6a, 35435 Wettenberg, Germany
www.reel-gmbh.de Phone: [phone]
[email protected] Fax: [phone]
Site 2 of 4
Antennas from 200 MHz to 6 GHz

Radiation diagram (typ.)*
* Measured with 0.6m cable on 30x30cm ground plane
GSM 900 MHz
Peak Gain: -2.5 dBi
GSM 1800 MHz
Peak Gain: +3.5 dBi
01.08.2011
Reel Reinheimer Elektronik GmbH
proprietary Information. Product and
Information contained herein are
subject to change without notice.
REEL Reinheimer Elektronik GmbH
Felsweg 6a, 35435 Wettenberg, Germany
www.reel-gmbh.de Phone: [phone]
[email protected] Fax: [phone]
Site 3 of 4
Antennas from 200 MHz to 6 GHz

Mounting Instructions
Ordering example
Warranty
•To avoid mechanical stress the antenna should not be attached on doors or flaps.
•No extra ground planes are necessary for this antenna (ground plane inside).
•Mountable on all clean, smooth and stainless surfaces.
•Mountable on glass and non-metallic materials.
The lawful warranty conditions apply.
M35 Z X O _ 0300 _03 XX XX_ _
Mobile Communications antenna
Housing diameter
GSM-Frequency
GPS
Without housing
3m RG 178
GSM U.FL
GPS
Special assembly
