REICH TOK F2 Series User manual

TOK
Highly flexible coupling for industrial applications
with flexible mounting
TOK…F2
TOK…D F2
TOK…F2K
TOK…D F2K
TOK…TK
TOK…D TK
TOK…R F2K
TOK…R TK
Translation of the original German operating instructions
09/2020 - en - 15500004020002

Contents
Notes on the supplementary manual and the manufacturer.............. 6
Keeping the instructions available ..............................................................................6
Target group of these operating instructions .............................................................6
Copyright.....................................................................................................................7
Related documents .....................................................................................................7
Structural features of these operating instructions....................................................7
Warranty and liability..................................................................................................8
Manufacturer's address ..............................................................................................8
Documentation officer ................................................................................................8
Safety.................................................................................................... 9
Proper use...................................................................................................................9
Duties of the owner ..................................................................................................10
Duties of the personnel.............................................................................................11
Personnel qualifications............................................................................................11
Prohibition of unauthorised conversions..................................................................11
Personal protective equipment ................................................................................11
Note regarding residual dangers...............................................................................12
Basic safety instructions............................................................................................12
Danger to life due to rupturing of the coupling .................................................12
Danger to life due to improper transportation and handling of the
coupling ..............................................................................................................13
Avoiding risks of injury due to entanglement ....................................................13
Avoiding risks of burns from hot surfaces..........................................................13
Avoiding risks of poisoning.................................................................................13
Structural features of warning notices .....................................................................14
Structural features of notices referring to property damage ...................................14
Warning and instruction labels .................................................................................15
Description ......................................................................................... 16
Overview of type TOK...F2 ........................................................................................16
Overview of type TOK...D F2 .....................................................................................17
Overview of type TOK...F2K ......................................................................................18
Overview of type TOK...D F2K ...................................................................................19
Overview of type TOK...TK ........................................................................................20
Overview of type TOK...D TK .....................................................................................22
Overview of type TOK...R F2K ...................................................................................24
Overview of type TOK...R TK .....................................................................................26
Components..............................................................................................................27
Flange .................................................................................................................27
Adapter flange....................................................................................................27
Coupling element ...............................................................................................28

Coupling hub ......................................................................................................28
Union flange .......................................................................................................28
Splited spacer ring..............................................................................................29
Operating conditions..........................................................................................29
Nameplate.................................................................................................................30
Unpacking and checking the scope of delivery .................................. 31
Unpacking .................................................................................................................31
Checking the supply ..................................................................................................31
Reporting and documenting transport damage .......................................................31
Disposing of packaging material ...............................................................................31
Transporting the coupling .................................................................. 32
Transporting the coupling hub with coupling element.............................................33
Transporting the flange.............................................................................................34
Transporting the coupling element...........................................................................34
Transportation of coupling hub ................................................................................35
Storing the coupling ........................................................................... 36
Mounting the coupling ....................................................................... 37
Lifting loads during assembly....................................................................................37
Basic instructions for the types TOK…F2K, TOK…D F2K, TOK…TK, TOK…D TK,
TOK…R F2K and TOK…R TK........................................................................................38
Preparing for assembly .............................................................................................40
Basic notes regarding the condition of delivery........................................................41
Basic notes regarding the coupling hubs ..................................................................43
Mounting the coupling hub on the shaft ..................................................................45
Assembly notes for a hub bore with press fit or transition fit ..................................46
Aligning the coupling.................................................................................................47
Mounting the flange .................................................................................................50
Mounting the adapter flange....................................................................................51
Mounting the union flange .......................................................................................52
Mounting a splited spacer ring .................................................................................53
Mounting the coupling element ...............................................................................54
Type TOK...F2 .....................................................................................................54
Type TOK...D F2 ..................................................................................................56
Type TOK...F2K ...................................................................................................58
Types TOK...D F2K...............................................................................................60
Type TOK...TK .....................................................................................................62
Type TOK...D TK ..................................................................................................64
Types TOK...R F2K...............................................................................................66
Type TOK...R TK ..................................................................................................68
Torques for tightening bolted connections...............................................................69

Torques for the bolted connection of the coupling element, flange and
the coupling hub ................................................................................................70
Torques for the flywheel bolts ...........................................................................71
Mounting the protection device ...............................................................................72
Putting the coupling into operation................................................... 73
Operation............................................................................................ 74
Eliminating malfunctions.................................................................... 75
Detecting malfunctions.............................................................................................75
Table of malfunctions ...............................................................................................76
Procedure for eliminating malfunctions ...................................................................76
Maintaining the coupling ................................................................... 77
Preparing for maintenance work ..............................................................................77
Performing inspections .............................................................................................78
Replacing the coupling elements ..............................................................................79
Types TOK…F2 and TOK…D F2............................................................................79
Types TOK…F2K, TOK…R F2K and TOK…D F2K ...................................................79
Types TOK…TK, TOK…R TK and TOK…D TK .........................................................80
Completing maintenance work.................................................................................80
Cleaning the coupling ......................................................................... 81
Dismantling the coupling.................................................................... 82
Disposing of the coupling ................................................................... 83

Notes on the supplementary manual and the manufacturer
6
Notes on the supplementary manual and the
manufacturer
These operating instructions help you use the coupling properly and safely.
Keeping the instructions available
These operating instructions are an integral part of the coupling. Make sure that these
operating instructions are constantly available at the place of use and in legible condition
for the user. Add these operating instructions each time you sell this type of coupling or
make it otherwise available to any third party.
Target group of these operating instructions
These instructions are addressed to the owner and to all persons who perform the
following activities with and on the coupling:
Transportation
Storage
Assembly
Putting into operation
Operating
Servicing
Maintenance work
Decommissioning
Disposal.
These operating instructions are intended for trained specialist personnel and for qualified
and authorised operating personnel.
Each of these persons must have read and understood the contents of these operating
instructions. Following the instructions contained in this manual helps avoid dangers and
increases the reliability and the service life of the coupling.
In addition to the instructions in this manual, always observe the legal and other
regulations applicable at the installation site, such as:
Accident prevention regulations
Regulations for safe and proper work.

Notes on the supplementary manual and the manufacturer
7
Copyright
These operating instructions and all their appendices contain information which is subject
to copyright. They must only be used for the operation of the coupling.
These operating instructions must not be copied, printed or reproduced, processed,
duplicated or distributed in any way or in any form – either in whole or in part – without
the prior written approval of Dipl.-Ing. Herwarth Reich GmbH, hereinafter referred to as
REICH.
© Dipl.-Ing. Herwarth Reich GmbH
Vierhausstr. 53
D-44807 Bochum
Germany
Related documents
Related documents are deemed integral parts of these operating instructions. Retain
these documents together with these operating instructions. Add these documents each
time you sell this type of coupling or make it otherwise available to any third party.
The following types of document are regarded as being applicable documents:
Dimensioned drawing
Technical product description
All documents contained in the scope of supply
Structural features of these operating instructions
Defined structural features are assigned to the various elements within these operating
instructions. A distinction can therefore be easily made between the following elements:
Normal text
Cross references
Lists
Action steps
Tips. These provide additional information such as special notes regarding the use
of the coupling.

Notes on the supplementary manual and the manufacturer
8
Warranty and liability
Our general commercial terms and conditions apply in general. These can be seen in the
Internet at http://www.reich-kupplungen.com. Warranty and liability claims for personal
injury and property damage are denied in all cases in which these are attributable to one
or more of the following causes:
Improper use of the coupling.
Improper assembly, commissioning and maintenance of the coupling.
Operation of the coupling with defective protection guards or improperly mounted or
non-functional safety and protection devices.
Failure to observe the notes in the operating instructions regarding transportation,
storage, assembly, commissioning, operation, maintenance, cleaning and disassembly
of the coupling.
Unauthorised modifications to the design of the coupling without consulting REICH.
Inadequate monitoring of parts of the machine which are subject to wear.
Improperly performed repairs.
Major disasters caused by external influences and force majeure.
Manufacturer's address
Dipl.-Ing. Herwarth Reich GmbH
Vierhausstr. 53
D-44807 Bochum
Germany
Telephone: [phone]
Fax: [phone]
E-mail: [e-mail]
Internet: www.reich-kupplungen.com
Documentation officer
Dipl.-Ing. Herwarth Reich GmbH
Michael Marxmeier
Vierhausstr. 53
D-44807 Bochum
Germany

Safety
9
Safety
Proper use
The highly flexible Reich TOK coupling has been specially designed for applications
requiring extremely low torsional stiffness. Furthermore, it is particularly well suited to the
compensation of axial and radial displacements of resiliently mounted drives. The wide
range of flexible coupling elements and adaptive designs provides standard solutions for a
wide variety of different tasks. These can be complemented by specific customised
designs on request. The flexible element is designed to combine high torque transmission
capacity and high displacement capacity with high speed capability. Its stiffness can be
adapted to requirements by selecting different rubber qualities. The adaptive designs are
based on the standard flywheel adapter dimensions according to SAE J 620.
Proper use also includes the observance of and compliance with all details contained in
these operating instructions and the related documents. This applies, in particular, to both
the safety instructions and the warning notices, and to the adherence to the cleaning and
maintenance intervals.
Any other use or any use beyond the limits of proper use is deemed improper use and can
lead to property damage or personal injury.
The following types of use, in particular, are deemed improper use:
Operating the coupling outside its operating limits, and especially at too high
rotational speeds and/or torques or continuous fatigue torques.
Operating the coupling in a substandard condition.
Having the coupling operated by inadequately trained personnel.
Operating the coupling with deactivated and/or modified protective guards.
Operating the coupling with modified add-on parts.
Improper cleaning with cleaners containing solvents, alkalis or acids.
Improper operation of the coupling results in forfeiture of the liability for material defects
and warranty.

Safety
10
Duties of the owner
The owner of the coupling is bound by laws and regulations to issue instructions which
ensure safe operation.
The owner must define a “responsible person”. Only this person is authorised to issue
a work clearance permit for working on and with the coupling. Work on the coupling
described herein must not be executed unless the written work clearance permit for
the execution of that work is available from the responsible person.
The owner of the coupling must ensure that only qualified and authorised personnel
performs the following activities on and with the coupling:
−Transportation
−Storage
−Assembly
−Putting into operation
−Operating
−Decommissioning
−Cleaning
−Servicing
−Disposal.
Persons whose ability to react is affected, for example, by the use of alcohol,
medicines, drugs, etc., must not work on or with the coupling.
The owner of the coupling must regularly train the personnel working on the coupling
in the following areas:
−Use of the personal protective equipment
−Safe working practices
−Applicable accident prevention regulations
−Hazards arising from the coupling whilst in operation
−Behaviour in an emergency
−First aid measures.
The owner must ensure that the applicable country-specific laws and guidelines
including the health protection regulations, the occupational health and safety
regulations and the fire prevention regulations, are adhered to.
The owner must ensure that personnel receiving training, hands-on training, briefings
or making an apprenticeship exclusively works on and with the coupling under the
constant supervision of an experienced specialist.
The operator must ensure that the coupling is enclosed by an adequately dimensioned
separating protective guard which can withstand a coupling rupturing. It must allow
sufficient ventilation of the coupling; see page 72.
Before commissioning the coupling, the owner or a person authorised by the owner
must ensure that the following requirements are met:
−Proper use of the coupling must be ensured.
−All protection devices must be properly mounted and functional.
−All safety regulations must be adhered to.

Safety
11
Duties of the personnel
The personnel working on and with the coupling must:
have read and understood all operating instructions,
be familiar with all safety devices and regulations,
observe and comply with all safety instructions and warning notices applicable to the
place of use,
be familiar with and adhere to the basic occupational health and safety regulations
and accident prevention regulations.
Personnel qualifications
The specialist personnel must have knowledge and experience in the following areas:
All notes in these operating instructions and the related documents
Legal regulations and occupational health and safety regulations applicable to the
place of use
Explosion protection and fire prevention regulations applicable to the place of use
Safe lifting and transportation of loads
Assembly and disassembly of couplings
Alignment of couplings
Joining of bolted connections and their tightening to the specified torque
Maintenance and cleaning work on couplings.
Prohibition of unauthorised conversions
Conversions or modifications are permissible only with the manufacturer’s approval.
Exclusively use accessories which are approved by REICH for use with the coupling.
Exclusively use genuine OEM spare parts. There is no warranty for third-party spare
parts that these parts have been designed and manufactured to meet the stress and
safety requirements.
Personal protective equipment
Adherence to the following safety measures is required to enable you to work safely on
and with the coupling:
Do not wear clothing or jewellery which may become entangled with moving parts such
as ties, neckerchiefs, rings or chains.
Comply with the owner's safety instructions.
Wear a hair net or other head covering if you have long hair.
Wear safety shoes to avoid injuries to your feet.
Wear protective gloves to avoid injuries to your hands.
Wear a hard hat to avoid injuries to your head.
Wear protective clothing to protect your body against injuries.
Wear protective goggles during work when your eyes are at risk.

Safety
12
Wear ear protectors in areas in which your hearing may be damaged.
Wear a respiratory protector during work when your respiratory system may be
damaged.
Make sure that the work areas and escape routes are not blocked at the place of use.
The owner must issue instructions for the wearing of personal protective equipment in
accordance with the risks existing at the place of use.
Note regarding residual dangers
The coupling has been constructed according to the state-of-the-art and the recognised
safety rules and relevant standards. Wherever possible, sources of danger have been
eliminated in the design or ruled out through suitable devices. Residual dangers may
nevertheless arise when using the coupling.
Dangers to persons or impairment of the coupling and other property can especially occur
if the coupling:
is improperly transported, mounted, commissioned and maintained by non-qualified
or untrained personnel,
is operated improperly,
is not used properly,
is not serviced properly,
is not cleaned properly,
is not decommissioned properly,
is not stored properly.
Basic safety instructions
Danger to life due to rupturing of the coupling
A damaged or improperly mounted coupling can rupture during operation. Parts flying
around can cause life-threatening injuries.
The coupling must be mounted exclusively by specialist personnel qualified for this
task.
The coupling must be operated exclusively in flawless condition.
The maintenance intervals must be adhered to.
The owner must mount a protection device which is capable of withstanding rupturing
of the coupling.

Safety
13
Danger to life due to improper transportation and handling of the coupling
If the coupling or its components are inadequately supported during transport, assembly
or disassembly, there is a risk of crushing injuries in the event of the coupling or its
components falling down.
Exclusively use undamaged lifting and lashing gear which is suitable for the load.
Secure the coupling and its components during transport, assembly or disassembly to
prevent them from falling down.
Do not stand under suspended loads.
Wear the personal protective equipment specified by the owner.
Avoiding risks of injury due to entanglement
Perform all work required on the coupling only when the coupling is stationary.
Switch off the prime mover prior to all work on the coupling.
Secure the prime mover to prevent reactivation.
Exclusively operate the coupling with a mounted and functional protective guard.
Affix a label warning of the hazard of entanglement on the protective guard.
Avoiding risks of burns from hot surfaces
The surface of the coupling can become hot during operation.
Do not touch hot surfaces.
Allow the coupling to cool to hand temperature prior to maintenance work.
If necessary, check the surface temperature with an infrared thermometer.
Wear the personal protective equipment specified by the owner.
Avoiding risks of poisoning
There is a risk of poisoning when working with solvents or preservatives.
Wear the personal protective equipment specified by the owner.
Observe and follow the instructions contained in the safety data sheet for the solvent
or preservative being used.
Make sure that the workplace is adequately ventilated.

Safety
14
Structural features of warning notices
DANGER
Notices containing the word DANGER warn of a dangerous
situation which causes death or
severe injuries.
WARNING
Notices containing the word WARNING warn of a dangerous
situation which
can cause death or severe injuries.
CAUTION
Notices containing the word CAUTION warn of a situation that
may lead to minor or moderate injury
.
The following specific danger symbols can also be used in the warning notices in lieu of the
general danger symbol:
Risk of explosion
Risk of burns, risk of scalding
Danger due to heavy loads falling down
Danger due to rupturing compon
ents
Structural features of notices referring to property damage
CAUTION!
These notices warn of a
situation which can cause property
damage.

Safety
15
Warning and instruction labels
Observe and comply with the warning and instruction labels which are affixed at the
place of use of the coupling.
Make sure that none of the warning and instruction signs installed at the coupling's
operating location are covered over and that they are all clearly legible at all times.
Immediately replace any damaged warning and instruction labels.

Description
16
Description
The couplings in the TOK series, types TOK…F2, TOK…D F2, TOK…F2K, TOK…D F2K,
TOK…TK, TOK…D TK, TOK…R F2K and TOK R TK are used to transmit torques and speeds
between a drive unit and the driven machine in horizontal position. They reduce torsional
vibrations and shock loads and are able to compensate for displacements.
Depending on the type, they consist of the flange, the coupling hub, the actual flexible
coupling element, adapter flange and an optionally supplied spacer ring. After assembly, a
torsionally flexible connection is established between the drive unit and the driven
machine.
Overview of type TOK...F2
With this type, two different mounting lengths can be achieved depending on the
configuration of the coupling element.
No. Designation
1
Coupling hub
2
Flexible coupling element (with use of through holes)
3 Bolts

Description
17
Overview of type TOK...D F2
This type uses two coupling elements acting in parallel instead of one. It is
therefore designed for the transmission of higher torques.
No. Designation
1
Coupling hub
2a
Flexible coupling element (with use of through holes)
2b Flexible coupling element (with use of through holes and reversed inner sleeve)
3
Bolts

Description
18
Overview of type TOK...F2K
This type enables the flexible coupling element to be replaced without moving the
coupled machines. Follow the instructions given on pages 38 and 79.
No. Designation
1 Coupling hub
2
Flexible coupling element (with use of threaded bores)
3 Splited spacer ring
4 Bolts
5
Washers (for aluminium flanges or where necessary)

Description
19
Overview of type TOK...D F2K
This type uses two coupling elements acting in parallel instead of one. It is
therefore designed for the transmission of higher torques.
This type enables the flexible coupling elements to be replaced without moving the
coupled machines. Follow the instructions given on pages 38 and 79.
No.
Designation
1 Coupling hub
2a Flexible coupling element (with use of threaded bores)
2b
Flexible coupling element (with use of through holes)
3 Splited spacer ring
4, 5,
6
Bolts

Description
20
Overview of type TOK...TK
This type enables the flexible coupling element to be replaced without moving the
coupled machines. Follow the instructions gi
ven on pages 38 and 79
. Depending on
the installation situation, it can be designed either with
a splited spacer ring (figure
A) or with a union flange (figure B).
No. Designation
1
Coupling hub (drive side)
2 Flexible coupling element (with use of threaded bores)
3 Coupling hub (driven side)
4
Flange
5
Splited spacer ring
6, 7,
8
Bolts
9
Washers (for aluminium flanges or where necessary)
