Relish TOUCH CONTROL User manual

TOUCH CONTROL MANUAL
With Relish Guitars Switzerland ‘s patented Touch Pad your tone options
go beyond the toggle realm. Choose from up to 17 positions from neck to
bridge - both in humbucker and split coil mode – to find your sweet spot.
For Relish Touch Control Pad, versions 2018-2019, Platine Version PSW1840, Software Version FW0116
THE RELISH
FUNCTIONALITIES
Control pickups
with sleek touch
pad
Neck to bridge:
17 positions
Coil split func-
tion by two-
finger tap
True Bypass &
Analog output
signal
Battery level
indication by
RGB LED
Battery saving
sleep mode
after 3 min not
in use
TECHNICAL SUPPORT
If you have any questions or face any technical issues, please do not hesitate
to contact us at
[email protected]
Page 1/5

Page 2/5

BATTERY RGB LED INDICATION
When plugging in jack cable, the touch pad will automatically indicate the
battery level by blinking blue or red LED lights on both ends of the pad three
times.
Blue blinking means “ready to play”
Red blinking indicates low battery status below 10%
TRUE BYPASS MODE
When battery is too low to power the
Touch Control System, the guitar will
automatically switch to bypass mode.
With the bypass pickup selector on the
circuit board on the inside of the guitar, you
can select which pickup is active during by-
pass mode. Left activates bridge, right
activates neck pickup. During bypass mode,
only one pickup can be active.
SLEEP MODE
Battery is only used when a jack wire is plugged into the guitar. In order
to save battery power when plugged in, a motion detector activates sleep
mode after three minutes of complete non-movement.
As soon as the guitar is being picked up again, the Touch Pad System
awakes immediately.
Page 3/5

Neck Pickup
coil split mode
activated
Bridge Pickup
coil split mode
activated
Bridge Pickup
activated only
Neck & Bridge
Pickups both
activated,
50/50 mix
Neck Pickup
activated only
PICKUP POSITIONS RGB LED INDICATION
When Touch Control System is active, RGB LED lights will indicate the posi-
tion or mix of the pickups in use.
Blue light indicates coils of respective pickup are split.
Red light indicates battery is low (below 10%).
Neck & Bridge
Pickups both
activated,
20/80 mix
Neck & Bridge
Pickups both
activated,
80/20 mix
Neck & bridge
pickup in coil
split mode,
50/50 mix
White light indicates position of neck-bridge mix.
PICKUP POSITION INDICATION EXAMPLES
TECHNICAL SUPPORT
If you have any questions or face any technical issues, please do not hesitate
to contact us at
[email protected]
Page 4/5

SWAPPING BATTERIES
The Relish Touch Control System is powered by a 9V alkaline battery and is compatible with
most common 9V batteries. All Relish guitars newer than 2018 that feature both a Touch
Control System and a Graph Tech Ghost Piezo System have one 9V battery that powers both
systems. The 9V battery has an expected lifetime of approximately 10-12h active playing time.
HOW TO ACCESS THE BATTERY
SAFETY NOTE:
For your own saftey, we recommend unplugging the guitar before removing
the battery and/or inserting a new battery.
The 9V battery can be accessed by removing the back lid of your Relish
guitar.
Remove the backlid by pulling the edge
behind the upper strap pin away from the
guitar.
Remove the backlid by inserting index
finger into the whole at lower strap pin
position and pulling the backlid away
from guitar.
Battery is located next to middle bar of
alu frame at lower strap pin position.
Remove empty battery from battery
holder.
Insert new 9V battery into battery
holder until clicking sound appears.
MARY & MARY ONE GUITARS JANE GUITARS
Page 5/5
