REMKO 248108 User manual

Operating and
installation instructions
Read the instructions prior to performing any task!
REMKO Ethernet adapter
0210-2019-02 Edition 1, en_GB
Quick guide

Translation of the original
Read these operating instructions carefully before commis-
sioning / using this device!
These instructions are an integral part of the system and must
always be kept near or on the device.
Subject to modifications; No liability accepted for errors or mis-
prints!

Table of contents
1 Safety and usage instructions............................................................................................................. 4
1.1 General safety notes....................................................................................................................... 4
1.2 Identification of notes...................................................................................................................... 4
1.3 Personnel qualifications.................................................................................................................. 4
1.4 Dangers of failure to observe the safety notes................................................................................ 4
1.5 Safety-conscious working............................................................................................................... 4
1.6 Safety notes for the operator........................................................................................................... 5
1.7 Safety notes for installation, maintenance and inspection.............................................................. 5
1.8 Unauthorised modification and changes......................................................................................... 5
1.9 Intended use................................................................................................................................... 5
1.10 Warranty........................................................................................................................................ 5
1.11 Transport and packaging............................................................................................................... 6
1.12 Environmental protection and recycling........................................................................................ 6
2 Product description and technical data.............................................................................................. 7
3Mounting the adapter............................................................................................................................ 8
3.1 Connection to the REMKO Smart-Control Touch controller............................................................ 8
3.2 Mounting the adapter...................................................................................................................... 9
3.3 LAN function.................................................................................................................................. 10
4 Index..................................................................................................................................................... 15
3

1 Safety and
usage instructions
1.1 General safety notes
Carefully read the operating manual before com-
missioning the units for the first time. It contains
useful tips and notes such as hazard warnings to
prevent personal injury and material damage.
Failure to follow the directions in this manual not
only presents a danger to people, the environment
and the system itself, but will void any claims for
liability.
Keep this operating manual and the refrigerant
data sheet near to the units.
1.2 Identification of notes
This section provides an overview of all important
safety aspects for proper protection of people and
safe and fault-free operation.The instructions and
safety notes contained within this manual must be
observed in order to prevent accidents, personal
injury and material damage.
Notes attached directly to the units must be
observed in their entirety and be kept in a fully
legible condition.
Safety notes in this manual are indicated by sym-
bols. Safety notes are introduced with signal words
which help to highlight the magnitude of the danger
in question.
DANGER!
Contact with live parts poses an immediate
danger of death due to electric shock. Damage
to the insulation or individual components may
pose a danger of death.
DANGER!
This combination of symbol and signal word
warns of a situation in which there is immediate
danger, which if not avoided may be fatal or
cause serious injury.
WARNING!
This combination of symbol and signal word
warns of a potentially hazardous situation,
which if not avoided may be fatal or cause
serious injury.
CAUTION!
This combination of symbol and signal word
warns of a potentially hazardous situation,
which if not avoided may cause injury or mate-
rial and environmental damage.
NOTICE!
This combination of symbol and signal word
warns of a potentially hazardous situation,
which if not avoided may cause material and
environmental damage.
This symbol highlights useful tips and recom-
mendations as well as information for efficient
and fault-free operation.
1.3 Personnel qualifications
Personnel responsible for commissioning, opera-
tion, maintenance, inspection and installation must
be able to demonstrate that they hold a qualifica-
tion which proves their ability to undertake the
work.
1.4 Dangers of failure to observe
the safety notes
Failure to observe the safety notes may pose a risk
to people, the environment and the units. Failure to
observe the safety notes may void any claims for
damages.
In particular, failure to observe the safety notes
may pose the following risks:
nThe failure of important unit functions.
nThe failure of prescribed methods of mainte-
nance and repair.
nDanger to people on account of electrical and
mechanical effects.
1.5 Safety-conscious working
The safety notes contained in this manual, the
existing national regulations concerning accident
prevention as well as any internal company
working, operating and safety regulations must be
observed.
REMKO Ethernet adapter
4

1.6 Safety notes for the operator
The operational safety of the units and compo-
nents is only assured providing they are used as
intended and in a fully assembled state.
nThe units and components may only be set up,
installed and maintained by qualified per-
sonnel.
nProtective covers (grille) over moving parts
must not be removed from units that are in
operation.
nDo not operate units or components with
obvious defects or signs of damage.
nContact with certain unit parts or components
may lead to burns or injury.
nThe units and components must not be
exposed to any mechanical load, extreme
levels of humidity or extreme temperature.
nSpaces in which refrigerant can leak sufficient
to load and vent. Otherwise there is danger of
suffocation.
nAll housing parts and device openings, e.g. air
inlets and outlets, must be free from foreign
objects, fluids or gases.
nThe units must be inspected by a service tech-
nician at least once annually. Visual inspec-
tions and cleaning may be performed by the
operator when the units are disconnected from
the mains.
1.7 Safety notes for installation,
maintenance and inspection
nAppropriate hazard prevention measures must
be taken to prevent risks to people when per-
forming installation, repair, maintenance or
cleaning work on the units.
nThe setup, connection and operation of the
units and its components must be undertaken
in accordance with the usage and operating
conditions stipulated in this manual and comply
with all applicable regional regulations.
nLocal regulations and laws such as Water
Ecology Act must be observed.
nThe power supply should be adapted to the
requirements of the units.
nUnits may only be mounted at the points pro-
vided for this purpose at the factory. The units
may only be secured or mounted on stable
structures, walls or floors.
nMobile units must be set up securely on suit-
able surfaces and in an upright position. Sta-
tionary units must be permanently installed for
operation.
nThe units and components should not be oper-
ated in areas where there is a heightened risk
of damage. Observe the minimum clearances.
nThe units and components must be kept at an
adequate distance from flammable, explosive,
combustible, abrasive and dirty areas or
atmospheres.
nSafety devices must not be altered or
bypassed.
1.8 Unauthorised modification
and changes
Modifications or changes to units and components
are not permitted and may cause malfunctions.
Safety devices may not be modified or bypassed.
Original replacement parts and accessories
authorised by the manufactured ensure safety. The
use of other parts may invalidate liability for
resulting consequences.
1.9 Intended use
The Ethernet adapter as the connection between
the touch display and the LAN cable.
Any different or additional use is a non-intended
use. The manufacturer/supplier assumes no lia-
bility for damages arising from non-intended use.
The user bears the sole risk in such cases.
Intended use also includes working in accordance
with the operating and installation instructions and
complying with the maintenance requirements.
The threshold values specified in the technical
data must not be exceeded.
1.10 Warranty
For warranty claims to be considered, it is essential
that the ordering party or its representative com-
plete and return the "certificate of warranty" to
REMKO GmbH & Co. KG at the time when the
units are purchased and commissioned.
The warranty conditions are detailed in the "Gen-
eral business and delivery conditions". Further-
more, only the parties to a contract can conclude
special agreements beyond these conditions. In
this case, contact your contractual partner in the
first instance.
5

1.11 Transport and packaging
The devices are supplied in a sturdy shipping con-
tainer or inside the heat pump casing. Please
check the equipment immediately upon delivery
and note any damage or missing parts on the
delivery and inform the shipper and your contrac-
tual partner. For later complaints can not be guar-
anteed.
WARNING!
Plastic films and bags etc. are dangerous
toys for children!
Why:
- Leave packaging material are not around.
- Packaging material may not be accessible to
children!
1.12 Environmental protection
and recycling
Disposal of packaging
All products are packed for transport in environ-
mentally friendly materials. Make a valuable contri-
bution to reducing waste and sustaining raw mate-
rials. Only dispose of packaging at approved
collection points.
Disposal of equipment and components
Only recyclable materials are used in the manufac-
ture of the devices and components. Help protect
the environment by ensuring that the devices or
components (for example batteries) are not dis-
posed in household waste, but only in accordance
with local regulations and in an environmentally
safe manner, e.g. using certified firms and recy-
cling specialists or at collection points.
REMKO Ethernet adapter
6

2 Product description and technical data
Features of the REMKO Ethernet adapter
Technical data designation: USB 2.0 Ethernet adapter
nFulfils IEEE standards 802.3/802.3u
nFulfils USB 2.0/1.1 specifications
nSupports 10/100 Mbps auto-negotiation
nLow power consumption in idle mode and with little traffic
nNo external power supply required
nChip set: Asix IC AX88772B USB 2.0 for full 10/100 Mbps Ethernet performance USB 2.0 can transfer
data at 480 Mbps, ensuring full 10/100 Mbps Ethernet performance
nLow energy consumption: The REMKO adapter is designed for effective use of energy and to prevent
unnecessary waste of energy. It can dynamically reduce its power supply in order to reduce energy con-
sumption during idle operation and low traffic
Technical data
Product Ethernet adapter
Connections/Interfaces
Interface(s) USB2.0
LAN 10/100
Connection 1 x RJ 45
Dimensions
Height mm 225
Width mm 143
Depth mm 190
EDP no. 248108
We reserve the right to make technical changes for the purpose of technical advancement.
7

3 Mounting the adapter
3.1 Connection to the REMKO
Smart-Control Touch controller
NOTICE!
Only use the unit in dry areas and protect it
from electromagnetic radiation.
use
The REMKO adapter must be used if it is not pos-
sible to connect the REMKO Smart-Control Touch
controller to the W-LAN network of the in-house
router.
To do this, install the adapter directly on the panel
of the Touch Display.
The adapter can now be connected with a patch
cable (LAN cable).
The cable must be connected directly to the router.
NOTICE!
The router must be set up by a specialist
Fig. 1: USB Ethernet adapter
1
42 3
1: Router (example)
2: Patch cable
3: LAN adapter
4: Heat pump
REMKO Ethernet adapter
8

3.2 Mounting the adapter
The LAN cable may only be connected to the USB
port using the REMKO adapter. (see Fig. 2, Pos. 3)
2
13
Fig. 2: Remote control connections
1: 12 V/GND connection (occupied)
2: Patch cable connection (LAN cable) occupied
3: LAN adapter connection
1. To install the adapter, remove the existing
USB W-LAN stick [1].
1
2. After the W-LAN stick has been removed,
connect the Ethernet adapter to the now free
port.
Connect the adapter [2] with the LAN (patch)
cable and the router.
2
9

3.3 LAN function
Installation and setup of the LAN function
System requirements
The following system requirements are necessary
to complete the LAN function installation success-
fully:
nREMKO Smart Control Touch controller with
software version 4.24 or higher
nJavaScript/HTML5-capable web browser
(version not more than two years old)
nBroadband internet connection of at least
10 mbit/s
nThe WLAN router must support WPA 2 encryp-
tion/security standard
Installation in house
The central controller for the REMKO heat pump
via a smart phone or other mobile devices can be
installed virtually anywhere in the building.
The connection requires a router which is con-
nected directly to the control unit of the heat pump
via LAN.
NOTICE!
The router must be set up by a specialist
The LAN function is limited to the in-house LAN
network of the operator only. Outside the net-
work, access to the heat pump parameters is
not possible.
1
WLAN
2
Fig. 3: External access
1: Router (example)
2: REMKO Smart Control Touch
REMKO Ethernet adapter
10

Installation on mobile devices
To be able to use the LAN function of the REMKO
heat pump, a connection must be established with
the in-house router. This is only possible at the
expert level. To do this, select the "Expert" level on
the basic display.
After activating the expert level by touching the
corresponding icon, a password is required. To
enter the password at this level, touch the icon
again to confirm.
11

After confirming, four bar controllers are enabled
below the "Expert" icon. To enter the password
here, move the grey sliders to the appropriate posi-
tion by touching them.
The REMKO default password for the expert level
is "0321". If this password has not already been
changed, the expert level is enabled after entering
this password.
After the expert level has been enabled, various
parameter levels are visible.
Select the "Settings" level by touching the "Set-
tings" icon.
REMKO Ethernet adapter
12

After selecting the "Settings" level, select the
"Basic settings" parameter.
The "Interfaces" parameter appears in the "Basic
settings" level. Select this icon by touching it.
13

In the "Interfaces" parameter level you will find the
"Network” parameter. Touch to select this param-
eter.
The parameters available for the W-LAN function
are listed here. If the REMKO heat pump is con-
nected to the router via a LAN cable, only the IP
address displayed under "Status" is required.
********
********
e.g.
Enter the IP address displayed in the address field
of your smartphone or tablet Internet browser and
connect to the heat pump. As long as you are in
the W-LAN network of your router, you now have
the possibility to control your REMKO Smart-Con-
trol Touch controller via your mobile device.
REMKO Ethernet adapter
14

4 Index
C
Connection to the controller ................ 8
Connection to the Smart-Control controller ..... 8
D
Disposal of equipment .....................6
E
Environmental protection ...................6
External access .........................10
I
Intended use ............................ 5
P
Product description ....................... 7
S
Safety
Dangers of failure to observe the safety
notes ............................... 4
General ............................. 4
Identification of notes ................... 4
Notes for inspection .................... 5
Notes for installation ....................5
Notes for maintenance .................. 5
Personnel qualifications ................. 4
Safety notes for the operator ............. 5
Safety-conscious working ................4
Unauthorised modification ...............5
Unauthorised replacement part manufacture . 5
Set up the LAN function .................. 10
Setting up the LAN function ................10
System requirements .................... 10
T
Technical data ........................... 7
W
Warranty ............................... 5
15

REMKO QUALITY WITH SYSTEMS
Air-Conditioning | Heating | New Energies
Telephone +49 (0) 5232 606-0
Telefax +49 (0) 5232 606-260
E-mail [email protected]
URL www.remko.de
REMKO GmbH & Co. KG
Klima- und Wärmetechnik
Im Seelenkamp 12
32791 Lage
Hotline within Germany
+49 (0) 5232 6 06-0
Hotline International
+49 (0) 5232 606-130
We reserve the right to make technical changes, and provide no guarantee as to the accuracy of this data!
Table of contents
