Remta CEJ 21 User manual

COMMERCIAL GAS COOKER
MODELS: CEJ 21 – CEJ 23 – CEJ 25

PRESENTATION
Dear user,
- Our product is manufactured according to the standard rules and our best thanks to you about
you to choose our product and trust in us.
- Please read this user manual carefully and obey the direcves to use your product at best
performance and the best efficiency. Also be sure the other users read the user manual.
- Before calling the service, please check the details in the user manual against the problems.
- Do not let anyone to fix the product except authorized people and service.
PEPARING BEFORE MONTAGE
- Please read the user manual carefully and be sure the other users read the user manual. If the
device is operated without reading the user manual it will be out of warranty. Please contact with
the authorized service for the quesons.

INGREDIENTS
PAGE
NO
SUBJECTS
1 COVER
2 PRESENTATION
3 INGREDIENTS
4 TECHNICAL PROPERTIES
5 GENERAL DIMENSIONS AND WARNING
MARKS
6 SAFETY DETAILS
7 CARRYING AND MOVING – LIFE TIME
8 MONTAGE
9 MONTAGE DIAGRAMS
10-11 USING THE DEVICE
12 CLEANING AND MAINTENANCE
13 GAS TRANSFORMATIONS – FAULTS AND
FAULT SOLUTIONS
14 PART LIST

TECHNICAL PROPERTIES
MODELS CEJ 21 CEJ 23 CEJ 25
General
dimensions
(mm)
340 X 725
X 865
475 X 725
X 865
475 X 725
X 1390
Heat power
(Kw) ΣQN N
Heat power
(Kw) ΣQN min
Heat power Kcal
Consumpon
G20 m³/h
Consumpon
G30 kg/h
Type A1 A1 A1
Gas entrance
inch
1/2 ” 1/2 ” 1/2 ”
CEJ 20 : Single cooker
CEJ 22 : Double cooker
CEJ 24 : Triple cooker
Technical properes are same for both two types.
NATURAL GAS: G20 LPG GAS: G30
All rights are reserved by Remta Çelik LTD. ŞTİ. To change the technical properes.

GENERAL PROPERTIES AND THE WARNING MARKS
LABELS AND WARNING MARKS
CHARACTERISTIC LABEL
HOT SURFACE

SAFETY DETAILS
ASSEMBLING SAFETY
• The user manual should be read before the gas connecon and assembling the device.
• The gas plant and the area which the device will be connected should be suitable for legal rules.
• If the device is operated with a gas tank, there has to be at least 50 cm between them and that
value should be kept.
• The device should be operated with a well air flowed aspiraon unit.
• There has not to be any flammable materials next to the device while it is operated (wooden and
plasc materials, petrochemical materials, curtain, cloth etc.)
USAGE SAFETY
• The device is produced for commercial purposes that is why it has to be used just by qualified
person who has read and understand the user manual well.
• The oil which falls out while the device is operated may occur greasy surface on the ground, so
should be cleaned on me.
MAINTENANCE AND CLEANING SAFETY
• Do not use pressured water when you clean the device.
• The device should be cleaned when it is out of use. If any flammable cleaners are used on the
surfaces of the device, these surfaces should be cleaned and dried well before first use aer this
cleaning.
• Just the authorized service person should fix the device.
GAS LEAK AND FLAME SAFETY
• If any flame occurs next to the device in the close locaon, please shut down the gas valves
without any panic. Use fire exnguisher. Never use water to exn guish the flame. The water makes
the flame spread quickly.
• When you smell any gas, shut down the gas valves and call the authorized people. Be sure that
you have aired the area very well.

CARRYING AND MOVING
CARRYING;
• It can be carried by two people holding it from opposite sides.
• Do not bump or drop the device while you carry it.
MOVING;
The device’s operang place can not be changed or the connecon parts can not be fixed and
extended or shortened except authorized services and technicians.
If the device’s operang place is changed by authorized services and technicians, the all gas valves
should be cut of and should wait for the device to be cool down if it is hot. Aer re assembling,
check for the gas leakage, and check the device is working or not.
If the device’s operang place is changed by non-authorized people, the device will be out of
warranty.
LIFE OF THE DEVICE
The life of the device is about 10 years if it is used according to the recommendaons in the user
manual.
MONTAGE
PREPARINGS BY THE USER BEFORE THE MONTAGE
• The non-flammable compartments should be at least 5 cm close to the device otherwise distance
should be 20 cm for the flammable parts.
• Care about the rules against the fire.
• The gas connecon system should be ready before you call the authorized service to connect the
device to the gas system.
MONTAGE (by Technic Service)
• The under set desk should be parallel with the ground and have adjustable legs when the device is
use on it. The device should be located on a non-flammable surface.
• Safety details and the condion of the connecon should be checked before assembling the
device.
• The installaon should be suitable to the required gas values and type wrien on the label on the
device. Do not assembly the device with different requirements wrien on the label on the device.

• If the device will be used with a different gas type, the injector should be changed and the result
values should be declared on the label.
• The entrance properes are given in the “Technical Properes” page.
• Check the fire aer the device is connected to gas system. The air seng can be changed, against
the fire with smoke and to make the best fire.
• Test the device with gas leak detector aer the gas connecon.
• It is not permied to make any changes on the injectors and the valves of the device to change
the real values.
• The device becomes out of warranty if any unoriginal part is used.
MONTAGE DIAGRAMS
There has to be at least 500 mm between the LPG tank and the device.

USING THE DEVICE
PURPOSE OF THE PRODUCT;
The device is produced to cook the food on the cooking places of the device to serve food which is
used in the industrial kitchen services (collecve food services, restaurants, tourisc places, buffets
and etc.)
NOTE: Do not use the device out of its main purpose. The device should be used by the person who
knows the security and the technical condions and read the user manual.
USAGE:
PLACING THE COOKING FOOD
There has to be suitable pot or pan on the cooking cast supporters.
OPERATING:
Push the gas valve and turn it to the full fire direcon and then fire it with a lighter. Hold the gas
valve pushed for 20-25 seconds. Release the gas valve aer the burners are burnt.
You can turn the gas valve to counter clock wise direcon to have the energy safety with minimum
fire posion.
These operaons should be made for each burner. The unused burners should be turned off.
Off
On/Fre
Maxmum Flame
Mnmum
Flame
Off
On/Fre
Maxmum Flame
Mnmum
Flame

USING THE DEVICE
TURNING OF THE DEVICE
TURNING OF THE BURNING BURNERS
Turn the gas valve of the burner to the counter clock wise direcon and cut the gas of the burner.
It is recommended to turn off the gas tank valve or the gas system valve for your safety.
FLAME CONTROL
The security system will cut of the gas circulaon of the device within maximum 60 seconds with
any kind of reason of the flame on the burner is exnguished.
Hold the gas valve as pushed to turn on the valve and fire the gas for checking the gas. The valve
has to be hold as pushed for 15-20 seconds because of the security system. Otherwise the flame
gets exnguished.
SERVICE AND EXPART POINT
REMTA MAKİNA İTH. İHR. SAN. ve TİC. LTD. ŞTİ.
Adres: Akçaburgaz Mah. 4. Cad. 153. Sok. No:23 Esenyurt / İstanbul
Tel: [phone]
[email protected]om.tr • www.remta.com.tr
You can find all communicaon informaon about our services in the link below.
www.remta.com.tr/yetkili -servisler

CLEANING
• Clean the out surface with a sponge via using dish detergent and dry it out aer every end of
service beginning the first use.
• Aer every use, the food residual parts and burnt oil should be cleaned very well. Otherwise
these parts make bad smelling.
• Do not use nitric acid or any kind of CHEMICAL MATERIALS to clean the device.
MAINTENANCE
• The periodical maintenance should be done by a technical person
• We recommend to maintenance for about per every 6 months according to the using frequency.
• It will be charged to user for maintenance even the device is warranty.
The following details should be cared!
• Injectors : The hole of the injector should be cleaned well.
• Air adjustment ring : Air adjustment ring should be cleaned and not be blocked. The adjustment
of the air mixer should be made by an authorized service person.
EFFICIENCY USE
• Turn off the device when it is out of use.
• Always keep the device clean.
• The device works in a closed area with best performance.
• At 24 °C, you can have the best performance from the device. The device can work between -10
and +50 °C.
GAS TRANSFORMATIONS
It is declared on the label on the device that the device works with which gas type. The device
should be operated according to this kind of system that the technical service connected the
device.
The device is design to work with LPG Gas or Natural Gas.
The device can not be transformed to the other gas types from its main form.
If the device is transformed to the other gas types by an unauthorized person, the device will be out
of warranty and our company does not have responsibility about the malfuncons and the
problems.

FAULTS AND FAULT SOLUTIONS
FAULT POSITION FAULT REASON SOLUTION
The valve is on
posion but the
burner is not
burning!
Valve can not be
pushed Change the valve
There is no gas
Turn on the valve
For the first me take out the air in the spiral pipe.
Hold pushed the valve for 3 minutes. Take out the air
in the pipe.
The injector of the burner is blocked. Change it.
Check the gas type.
Flame is
exnguished in a
short me
Flame control probe is far from the flame. Make it
closer. If it is cracked change it.
Valve is on burning
posion but burner
is not burning!
There is no gas The burner nozzle is blocked, change it.
Burner air
adjustment is
wrong
Check
the air sengs.
Burner nozzle is
wrong
Check the nozzle diameter.
Valve is on burning
posion, burner is
burning but when
the valve is
released the
burner is
exnguished!
Flame control
probe is not geng
magnec.
Fasten the probe screw
Probe is cracked change it
Valve is on
minimum posion
but the flame is not
going on!
Flame is not going
on Change the burner.
Bypass injector of
the valve is not
adjusted
Check the bypass injector

DÖKÜM DESTEK
HAVUZ
BEK KAPAĞI
BEK
GAZ RAMPASI
SAC BEK DESTEĞİ
ÜST TABLA
DEMİR ŞASE
ISI ELEMANI
GAZ
MUSLUK KAPAĞI
GAZ
MUSLUĞU
PART LIST
Cast supporter
Pool
Burner cover
Burner
Gas distrubuter
Burner support sheet
Top table
Gas valve cover
Gas valve
Heang element Iron chassis

NOTLAR

GARANTİ ŞARTLARI
ÜRÜNLERİMİZ EEE YÖNETMELİĞİNE UYGUNDUR.

Bu belgenin kullanılmasına; 6502 sayılı Tüketicinin Korunması Hakkında Kanun uyarınca,
T.C. Gümrük ve Ticaret Bakanlığı Tüketicinin Korunması ve Piyasa Gözetimi Genel Müdürlüğü
tarafından izin verilmiştir.
ÜRETİCİ FİRMA
ÜNVAN
ADRES
TEL-FAKS
E-POSTA
WEB SAYFASI
ÜRÜNÜN CİNSİ
MARKASI
MODELİ
TESLİM TARİHİ VE YERİ
GARANTİ SÜRESİ
AZAMİ TAMİR SÜRESİ,
SERİ NO
SATICI FİRMA
ÜNVAN
ADRES
TEL-FAKS
E-POSTA
FATURA TARİH VE NO
TESLİM TARİHİ VE YERİ
TARİH, İMZA VE KAŞE
REMTA MAKİNA
REMTA MAKİNA İTH. İHR. SAN. TİC. LTD. ŞTİ.
Akçaburgaz Mh. 4. Cd. 153. Sk. No:23 34522 Esenyurt / İstanbul
[phone]
[email protected]
www.remta.com.tr
DOĞALGAZLI LOKANTA OCAĞI
REMTA
CEJ21-CEJ23-CEJ25
2 YIL
20 İŞ GÜNÜ
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
GARANTİ BELGESİ
Warranty Document
