Requisite Audio Engineering L2M MKIII M/S VERSION User manual

THE L2M MKIII M/S VERSION
Optical Leveling Amplifier
By Requisite Audio Engineering
OPERATOR’S MANUAL
2175 Goodyear Ave., Suite 110, San BuenaVentura, California 93003
telephone: [phone] • www.requisiteAudio.com

TABLE OF CONTENTS
INTRODUCTION!1
RECEIVING YOUR L2M!2
UNPACKING and INSPECTION:!2
GENERAL NOTES!3
WARNING:!3
THIS SHIPMENT SHOULD INCLUDE:!3
SERVICING:!3
ENVIRONMENTAL CONSIDERATIONS:!3
FRONT PANEL CONTROLS (top & bottom rows)!4
IN/BYPASS!4
IN/BYPASS - OPERATIONAL NOTE:!4
OUTPUT LEVEL!4
OUTPUT LEVEL - OPERATIONAL NOTE:!4
OUTPUT LEVEL - CALIBRATION PROCEDURE:!4
FRONT PANEL CONTROLS (continued)!5
LIMITER FEEDBACK!5
LIMITER FEEDBACK - OPERATIONAL NOTE:!5
LIMITER RESPONSE!6
LIMITER RESPONSE - OPERATIONAL NOTE:!6
PEAK REDUCTION!6
PEAK REDUCTION - OPERATIONAL NOTE:!6
THE L2M MKIII M/S VERSION
Requisite Audio Engineering L2M MkIII M/S Version

FRONT PANEL CONTROLS (center row)!7
MID!7
MID - OPERATIONAL NOTE:!7
SIDE!7
STEREO LEVEL RIDE!7
STEREO LEVEL RIDE - OPERATIONAL NOTE:!7
FRONT PANEL CONTROLS (center row- continued)!8
PK REDUCTION (MONO - LINK)!8
PK REDUCTION - OPERATIONAL NOTE:!8
METER SELECT!8
FRONT PANEL CALIBRATION POINTS!9
ZERO ADJ!9
ZERO ADJUST - OPERATIONAL NOTE:!9
GR TRACK!9
GR TRACK - CALIBRATION PROCEDURE:!9
FRONT PANEL CALIBRATION POINTS (continued)!10
VU ADJ!10
VU ADJ - CALIBRATION PROCEDURE:!10
STEREO ADJ!10
FRONT PANEL CALIBRATION POINTS (continued)!11
STEREO ADJ - CALIBRATION PROCEDURE:!11
FRONT PANEL CALIBRATION POINTS (continued)!12
STEREO ADJ - OPERATIONAL NOTE:!12
THE L2M MKIII M/S VERSION
Requisite Audio Engineering L2M MkIII M/S Version

REAR PANEL (LEFT to RIGHT, top and bottom row)!13
GROUND!13
POWER SUPPLY INLET!13
AUDIO OUTPUTS!13
LIMITER LINK!13
TUBE CHANNEL!13
TUBE PLACEMENT and FUNCTION (left to right)!13
AUDIO INPUTS!13
OUTBOARD POWER SUPPLIES!14
POWER SUPPLIES!14
POWER ON!14
POWER CABLE!14
VOLTAGE SELECT!14
FUSE!14
WARRANTY!15
THE L2M MKIII M/S VERSION
Requisite Audio Engineering L2M MkIII M/S Version

INTRODUCTION
THANK YOU
Thank you for selecting the L2M Mastering Limiter and thereby making it a part of your
art. The L2M MkIII M/S Version is the third generation of our L2M platform, now in
it’s 12th year of production (2011).
We classify the L2M as a mastering limiter because it was designed with the specialized
requirements of the mastering engineer in mind. Features such as a choice of outboard
power supplies (all tube or solid-state), true bypass, 1dB 24-step attenuator, 1dB 10-step
Limiter Feedback, Limiter Response, Mid/Side function, and multiple calibration points
all contribute to its effectiveness in the demanding application of mastering. Further-
more, the L2M is equally at home in tracking and mixing situations.
The L2M is an optical limiter based on classic designs of the early 1960s, however, the
L2M is the beneficiary of many significant improvements and represents what a truly
refined optical limiter can be.
Among the more notable performance features of the L2M are it's sonic excellence, ver-
satility and stable frequency response while limiting program material. Corrective EQ,
following the L2M, is simply not required as with many limiters. Your work stays intact,
just as you need it to. While providing unobtrusive compression/limiting action, there
is no undulating bottom or loss of openness, even in the heaviest of limiting situations.
For over a decade, the L2M has been installed in some of the finest mastering and re-
cording studios throughout the U.S., Europe and Canada and has been the primary dy-
namics processor on many major record and film releases.
Please read this manual carefully as it contains information essential to the proper op-
eration of the unit. We welcome your comments and encourage you to write or call.
Thank you again, and please enjoy!
Danny “Sage” McKinney (Founder/President)
Requisite Audio Engineering
[email protected]
818.437.0779
THE L2M MKIII M/S VERSION
Requisite Audio Engineering!L2M MkIII
1

RECEIVING YOUR L2M
UNPACKING and INSPECTION:
Your shipment has been carefully inspected, checked and packaged at our company be-
fore being turned over to the carrier.
We fully expect your L2M to arrive in your hands without having been harmed. How-
ever, at the point at which you do receive the product, it becomes your property. There-
fore it is important that you carefully inspect the carton and it’s contents for any sign of
physical damage which could have occurred in transit. Record and report any damages
to the transportation company within 24-hours of the original shipment.
Here’s what to do if the shipment has been damaged:
Leave the product, its packing materials and box “as is.” Notify the carrier’s local office
and request an immediate inspection of the shipment.
After said inspection has been made and you have received written notification thereof,
please contact our shop at 818.437.0779 for a return authorization number.
We will repair or replace any damaged merchandise as necessary.
Remember, it is your responsibility to follow the above procedures. Otherwise, the car-
rier will not honor your damage claim. If you have any questions regarding this notice
or the shipment itself, please notify us immediately.
Thank you,
Requisite Audio Engineering
818.437.0779
THE L2M MKIII M/S VERSION
Requisite Audio Engineering!L2M MkIII
2

GENERAL NOTES
WARNING:
DO NOT OPEN THE CABINET - RISK OF SEVERE ELECTRICAL SHOCK
THIS SHIPMENT SHOULD INCLUDE:
Model L2M MkIII M/S Version Mastering Limiter
Model OPS-2D Solid-State Power Supply or RTS-2A Tube Power Supply
L2M Operator’s Manual (this book)
A.C. Cable
SERVICING:
The user should not attempt to service this unit beyond that described in this manual.
Internal voltage can exceed 350 VOLTS D.C. !!! Refer all servicing, other than tube and
opto replacement to:
REQUISITE AUDIO ENGINEERING
2175 Goodyear Ave., Suite 110
Ventura, CA 93003
•telephone: [phone]
•email: [email protected]
ENVIRONMENTAL CONSIDERATIONS:
This and all electronic equipment require adequate ventilation and a dry environment
for safe operation and long component life. If proper ventilation from behind the unit is
provided, the L2M mainframe will require 4 rack spaces for mounting. If the RTS-2A
tube supply is also used, it will require an additional 4 rack spaces (8 total). If using the
OPS-2D (solid-state supply) it can be placed at the bottom of the rack, assuming reason-
able ventilation.
Do not allow either unit to become overheated.
Also, while circuitry susceptible to hum pick-up is sufficiently shielded from moderate
electromagnetic fields, installation should be planned to avoid mounting the system ad-
jacent to power transformers, motors, etc.
THE L2M MKIII M/S VERSION
Requisite Audio Engineering!L2M MkIII
3

FRONT PANEL CONTROLS (top & bottom rows)
IN/BYPASS
This switch (2 each) is a "true-hardwired" bypass, making a straight connection from input to
output allowing for accurate comparison of source and processed audio. BYPASS will work,
even if the L2M is off or unplugged from the A/C mains.
IN/BYPASS - OPERATIONAL NOTE:
For accurate perception when comparing processed audio to source material, it is essential that
make-up gain be correctly adjusted. The L2M has 2 points to which MAKE-UP GAIN can be
applied: OUTPUT LEVEL and LIMITER FEEDBACK. For more detail, see OPERATIONAL
NOTES - OUTPUT LEVEL and OPERATIONAL NOTES - LIMITER FEEDBACK. For purposes
of A/B listening STEREO LEVEL RIDE should be at it’s UNITY position.
OUTPUT LEVEL
Output level/make-up gain is accomplished using a precision 24-step attenuator (one for each
channel). Range of settings is from -6dB to +17dB in 1dB increments. As an initial setting for the
OUTPUT LEVEL attenuator, be sure the UNITY position is selected (both channels) and all
other controls are in their “OFF or UNITY” position. Verify that switching between IN & BY-
PASS exhibits no change in volume. This can be confirmed by injecting a 1-kHz tone and ob-
serving an outboard DMM or other suitable meter. The L2M is shipped with UNITY calibrated
to within .1dB. Each channel is calibrated by it’s respective UNITY ADJ on the back of the unit.
OUTPUT LEVEL - OPERATIONAL NOTE:
With program material being played, adjust the desired amount of PEAK REDUCTION and
LIMITER RESPONSE. Referring to the loudest peak in the program material, note how much
GAIN REDUCTION is occurring on the GR METER. Typical readings will be in the -3dB to
-7dB range. Adjust the OUTPUT LEVEL attenuator to have the inverse amount of gain. As an
example, if the GR METER is reading -5dB on the highest peaks adjust the OUTPUT ATTENU-
ATOR to +5dB. Go to a quiet passage of the program material. Using the IN/BYPASS switch,
you can now compare source and processed audio.
OUTPUT LEVEL - CALIBRATION PROCEDURE:
•Set PEAK REDUCTION & LIMITER RESPONSE fully-counterclockwise.
•Set OUTPUT LEVEL, LIMITER FEEDBACK & STEREO LEVEL RIDE to UNITY.
•Inject a +10dB 1-kHz tone. Verify using an external DMM or suitable meter.
•Switch between IN and BYPASS. External meter should read the same or within .1dB
•If not, adjust the UNITY trimmer (rear panel) until IN reads the same as BYPASS
THE L2M MKIII M/S VERSION
Requisite Audio Engineering!L2M MkIII
4

FRONT PANEL CONTROLS (continued)
LIMITER FEEDBACK
Left to run freely, vacuum tubes are not linear and exhibit a considerable amount of harmonic
generation and other forms of distortion. For over half a century, negative feedback has been
engineered into circuits to “improve” the linearity of vacuum tubes when used in audio gain
stages. However, best readings on a meter don’t always equate to the ideal sound, whatever
that happens to be. By making LIMITER FEEDBACK an adjustable feature, harmonic content
and texture are put into the hands of the audio engineer and not the guy with the THD meter.
As an initial setting for the LIMITER FEEDBACK control, be sure the UNITY position is selected
(Channel 1 & Channel 2). In order to maintain correct gain structure for accurate IN/BYPASS
review, LIMITER FEEDBACK should be used in tandem with the OUTPUT LEVEL control.
Since both OUTPUT LEVEL and LIMITER FEEDBACK are step attenuated in 1dB increments
this is fairly easy to do.
LIMITER FEEDBACK - OPERATIONAL NOTE:
LIMITER FEEDBACK has a direct effect on the output level of the audio, which is why it is
done in calibrated 1dB increments on the L2M. Because of this, proper setting of make-up gain
is the combined settings for OUTPUT LEVEL and LIMITER FEEDBACK which should be set to
the inverse of the GR METER reading.
For example, a -5dB meter reading of PEAK REDUCTION would allow for a setting of +5dB on
the OUTPUT LEVEL and a 0dB setting on LIMITER FEEDBACK. In this example, you would
maintain UNITY and have the cleanest possible signal.
In the same example, a -5dB meter reading of PEAK REDUCTION would allow for a setting of
0dB on the OUTPUT LEVEL and a +5dB setting on LIMITER FEEDBACK. In this example, you
would maintain UNITY and add additional harmonics. Naturally, you could have +2dB on
OUTPUT LEVEL and +3dB on LIMITER FEEDBACK.
As an extreme example, -5dB of PEAK REDUCTION would allow for a setting of -5dB on the
OUTPUT LEVEL with a +10dB on LIMITER FEEDBACK. With this setting, you would main-
tain UNITY and provide maximum harmonic generation, which can bring added “life” and “in-
terest” to a dull sounding recording or be just the right texture for a lead vocal or guitar to stand
out. Maybe, maybe not, it’s up to you.
THE L2M MKIII M/S VERSION
Requisite Audio Engineering!L2M MkIII
5

FRONT PANEL CONTROLS (continued)
RATIO 10:1 / 3:1
The purpose of this switch (Channel 1 & Channel 2) is to allow selection of either compressor
(3:1) or limiter (10:1). Compression (3:1) occurs from the breakaway point (-30dB input). In the
10:1 position, the L2M operates as a compressor until it reaches the -20dB point then rolls-over
into limiting action. Thus, combining the characteristics of a compressor and a limiter in the 10:1
mode.
LIMITER RESPONSE
With LIMITER RESPONSE (both channels) set fully counter-clockwise, the L2M will provide
equal compression/limiting at all frequencies by responding to the entire spectrum of the pro-
gram material. When LIMITER RESPONSE is set fully clockwise, frequencies below 1-kHz
gradually require more energy to initiate gain reduction. For frequencies below 100Hz, gain re-
duction initiation is down approximately 10dB. This arrangement is ideal for general program
material & especially material with a great deal of bass energy and/or broad bass dynamics.
The result is a marked smoothing of mid and high frequencies (above 1-kHz) and a tight and
punchy bass response.
LIMITER RESPONSE - OPERATIONAL NOTE:
For uniform limiter initiation and response in MONO or LINK mode, both channels require
LIMITER RESPONSE to be at the same setting. This is also applies to PEAK REDUCTION.
PEAK REDUCTION
Set fully counter-clockwise, the L2M exhibits no gain reduction and acts as a line amplifier.
Turning PEAK REDUCTION (Channel 1 & Channel 2) clockwise will gradually increase gain
reduction. PEAK REDUCTION should be set for the desired amount of gain reduction as indi-
cated on the VU meter while in the GR (GAIN REDUCTION) mode. A reading of -3dB to -7dB
during the highest peaks of the program material is a reasonable range to work within, how-
ever, you are encouraged to experiment.
PEAK REDUCTION - OPERATIONAL NOTE:
Additional PEAK REDUCTION may be needed to offset the reduction in limiting action that
occurs as you increase the setting of the LIMITER RESPONSE.
For uniform limiter initiation and response in MONO or LINK mode, both channels require
PEAK REDUCTION to be at the same setting. This is also applies to LIMITER RESPONSE.
THE L2M MKIII M/S VERSION
Requisite Audio Engineering!L2M MkIII
6

FRONT PANEL CONTROLS (center row)
MID
With the MID control pulled out and in the fully-clockwise position, center is normal. Fully-
counterclockwise Mid disappears. At the 12 o’clock position 3-4dB of make-up gain will be re-
quired to compensate for loss.
MID - OPERATIONAL NOTE:
MID-SIDE on the L2M is musically effective for tracks containing material recorded using stereo
microphones. As an example, stereo drum overheads, stereo background vocals, room mics.
The stereo output of a chorus pedal or stereo keyboard are not going to be effected in the same
manner.
For initiating Mid/Side functions the MID control must be in the OUT or PULLED position.
With the MID control pushed “IN” MID-SIDE is fully disengaged.
SIDE
When the SIDE control is at it’s fully-counterclockwise position, left is left and right is right (L/
R). At the 12 o’clock position, both left and right are in center (mono). At it’s fully-clockwise
position the image is “flipped”, left is on the right and right is on the left (R/L). The side con-
trol is continuously variable and adjusted in conjunction with the MID control.
STEREO LEVEL RIDE
Manual fine adjustment of level is a useful holdover from the old-school of mastering and is a
good way to go when wanting to avoid level changes in the digital domain. Having a total
range of 6dB, STEREO LEVEL RIDE is ideal for manual adjustment of level transitions from
various sections of the program material. Stereo tracking of this dual-ganged pot is extremely
accurate and holds a tolerance within 0.2dB throughout it’s entire range.
STEREO LEVEL RIDE - OPERATIONAL NOTE:
If needing to adjust track level both up and down, use the -3dB point as your average level, this
will allow for increase or decrease of level as needed.
THE L2M MKIII M/S VERSION
Requisite Audio Engineering!L2M MkIII
7

FRONT PANEL CONTROLS (center row- continued)
PK REDUCTION (MONO - LINK)
When operating in stereo or multi-channel mode, there is the option to LINK the triggering ac-
tion of each channel. The PK REDUCTION mode switch can be used for MONO or LINK op-
eration. It is also connected to the LINK jacks (found on the real panel) for interconnection of
additional L2M units (5.1) or external triggering of limiting action.
PK REDUCTION - OPERATIONAL NOTE:
Though it is customary to LINK when processing stereo material, keep in mind that the forgiv-
ing nature of the optical attenuators found in the L2M allows for mono operation when process-
ing most stereo material. We encourage experimentation in this regard.
LINK allows each channel to “see” what the other channel “sees”. LINK does not link parame-
ters. In other words, when processing stereo material, be sure to adjust the controls of both
channels to identical settings. In link mode, a single PEAK REDUCTION knob can initiate gain
reduction in both channels, however, you will not be able to get balanced LIMITER RESPONSE
or RATIO without both channel’s controls adjusted to the same settings.
METER SELECT
GR/+4/+10 Meter Mode Select - When METER SELECT is placed in the GR position, the meter
will indicate the amount of gain reduction and/or peak limiting in -dB. The meter is calibrated
(see ZERO ADJ CALIBRATION) to read 100% or 0dB during periods of no gain reduction.
When the selector switch is placed in the +4 position, the VU meter will indicate the balanced
output level (post gain reduction) as 0 = +4dBu (0.775v).
When the selector switch is placed in the +10 position, the VU meter will indicate the balanced
output level (post gain reduction) as 0 = +10dBu (2.45V).
THE L2M MKIII M/S VERSION
Requisite Audio Engineering!L2M MkIII
8

FRONT PANEL CALIBRATION POINTS
ZERO ADJ
The ZERO ADJ trimmer (2 each) is used to adjust the meter while in the GR (Gain Reduction)
mode. When METER SELECT is placed in the GR position, the meter should read 100% or 0dB
during periods of no gain reduction, indicating no PEAK REDUCTION is occurring.
ZERO ADJUST - OPERATIONAL NOTE:
Before determining that adjustments are necessary, be sure to allow 10 minutes of system warm-
up time and at least 5 minutes rest from any peak reduction activity. Also, be sure the METER
SELECT is in the GR position.
GR TRACK
The GR TRACK trimmer (2 each) is used to adjust the tracking accuracy of the GR
METER relative to the amount of GAIN REDUCTION that is occurring in the audio.
GR TRACK - CALIBRATION PROCEDURE:
•Allow 10 minutes of system warm-up time and 1 minute rest from peak reduction activity.
•Set PEAK REDUCTION & LIMITER RESPONSE fully-counterclockwise.
•Set OUTPUT LEVEL, LIMITER FEEDBACK & STEREO LEVEL RIDE to UNITY.
•Set RATIO to 3:1 and IN/BYPASS to IN
•Determine that ZERO ADJUST has been made (see above).
•Inject a +10dB 1-kHz tone (2.45V). Verify level using an external DMM or suitable meter.
•Select +10 on the METER SELECT and observe that the VU METER reads 0dB.
•If VU METER does not show 0dB in the +10 setting refer to VU ADJUST (see below).
•Increase PEAK REDUCTION until the VU METER drops to -4dB.
•Using METER SELECT, set to GR
•The GR METER should show -5dB. The additional 1dB is to compensate for meter ballistics of
300 milliseconds.
•After adjusting GR TRACKING, turn off the 1-kHz tone and allow a few moments of rest to
verify that the needle returns to 100% or 0dB.
•Since ZERO ADJ and GR TRACK are interactive it may be necessary to repeat this process
(from step 5) a few times, readjusting ZERO ADJ and GR TRACK.
THE L2M MKIII M/S VERSION
Requisite Audio Engineering!L2M MkIII
9

FRONT PANEL CALIBRATION POINTS (continued)
VU ADJ
VU ADJUST is for calibration of VU only. It does not affect GAIN REDUCTION readings.
VU ADJ - CALIBRATION PROCEDURE:
•Set PEAK REDUCTION & LIMITER RESPONSE fully-counterclockwise.
•Set OUTPUT LEVEL, LIMITER FEEDBACK & STEREO LEVEL RIDE to UNITY.
•Set IN/BYPASS to BYPASS
•Allow 10 minutes system warm-up time and 1 minute rest from any peak reduction activity.
•Inject a +10dBu (2.45V) 1-kHz tone (both channels). Verify level using an external DMM or
suitable meter. If your DMM has a dB function, select that. If not, set to A/C and read
2.45VAC across pins 2&3 of the OUTPUT XLR.
•Set IN/BYPASS to IN
•Select +10 on the METER SELECT and observe if the VU METER reads 0dB.
•Adjust as necessary.
•+4dBu is factory set to follow the +10dBu calibration. After the above calibration is com-
pleted, the VU METER should read 0dBu when METER SELECT is set to +4 and a 1-kHz tone
of .775v is applied to the input.
STEREO ADJ
STEREO ADJUST (2 each) - In order to achieve proper stereo or multi-channel gain re-
duction action, each channel should be adjusted to be equal. Carefully read the STE-
REO ADJUST calibration procedure to be sure you have a thorough understanding be-
fore attempting calibration. The L2M is fully calibrated for stereo operation before leav-
ing our shop.
THE L2M MKIII M/S VERSION
Requisite Audio Engineering!L2M MkIII
10

FRONT PANEL CALIBRATION POINTS (continued)
STEREO ADJ - CALIBRATION PROCEDURE:
•Verify that ZERO ADJ, GR TRACK and VU ADJ are all calibrated. If not, follow the above in-
structions for getting them to read accurately.
•Set PEAK REDUCTION & LIMITER RESPONSE fully-counterclockwise.
•Set OUTPUT LEVEL, LIMITER FEEDBACK & STEREO LEVEL RIDE to UNITY.
•Set RATIO to 3:1 and IN/BYPASS to BYPASS.
•Determine that ZERO ADJUST has been made (see above).
•Inject a +10dB 1-kHz tone (both channels). Verify level using an external DMM or suitable me-
ter. If your DMM has a dB function, select that. If not, set to A/C and read 2.45VAC across
pins 2&3 of the OUTPUT XLR.
•Select +10 on the METER SELECT and observe that the VU METER reads 0dB.
•Select LINK on PK REDUCTION.
•Increase PEAK REDUCTION (both channels) until the VU METER drops to -4dB on both
channels
•Using METER SELECT, set to GR to see if both meters read -5dBu. The additional 1dB is to
compensate for meter ballistics.
•If one meter reads higher than the other, lower it using the STEREO ADJUST trimmer, on the
front panel. As you bring it down, the other meter may start to come up. So stop at the point
where both channels show equal gain reduction.
ONCE THEPREVIOUS STEPS HAVEBEEN TAKEN, YOU CAN “FINE TUNE” YOUR AD-
JUSTMENT WITH PROGRAM SPECIFIC CALIBRATION IN THE FOLLOWING WAY:
•Find the portion of program material with the highest peaks and create a 5 to 10 second loop.
•If your using LIMITER RESPONSE leave that set to the way you want to hear it.
•Observe which channel is exhibiting the most gain reduction and slowly bring it down. It
won’t take much.
THE L2M MKIII M/S VERSION
Requisite Audio Engineering!L2M MkIII
11

FRONT PANEL CALIBRATION POINTS (continued)
STEREO ADJ - OPERATIONAL NOTE:
Overtime, (perhaps many years) it will become evident that STEREO ADJ will need to be reset
to a higher overall level. The sysmptom will be that PEAK REDUCTION needs to be set to it’s
fully-clockwise position to initiate suficient gain reduction for source material that has a good
deal of level.
RESET STEREO ADJ FOR HIGHER SENSITIVITY:
•Inject a +10dB 1-kHz tone (both channels). Verify level using an external DMM or suitable me-
ter. If your DMM has a dB function, select that. If not, set to A/C and read 2.45VAC across
pins 2&3 of the OUTPUT XLR.
•Select GR on the METER SELECT and observe that both VU METERs read 0dB.
•Select MONO on PK REDUCTION (meter mode select).
•Set PEAK REDUCTION (both channels) to the 12 o’clock position.
•Raise the STEREO ADJ trimmer on each channel until the pointer on the VU meter stops
dropping. This will indicate the level is back to it’s highest setting.
•Once this is done, refer to the STEREO ADJUST - CALIBRATION PROCEDURE (see above)
and re-calibrate STEREO ADJ.
If the above procedure was ineffective in recovering sufficient sensitivity, this could be an indi-
cation that the 12AX7 (2ea) and 6AQ5 (2ea) tubes (rear panel, left of optos) have exceeded their
useful lives and replacement is required. This could be the case for only one channel, however,
it would be good practice to change the tubes for both channels, at this time.
THE L2M MKIII M/S VERSION
Requisite Audio Engineering!L2M MkIII
12

REAR PANEL (LEFT to RIGHT, top and bottom row)
GROUND
Banana Plug connection to CHASSIS Ground and/or CIRCUIT Ground is provided. Need for
connection is unlikely, but can be useful in eliminating or finding source of hum, should hum
exist.
POWER SUPPLY INLET
For connect to either of the REQUISITE OUTBOARD POWER SUPPLIES, models OPS-2 (Solid-
State Supply) or RTS-4 (All Tube Supply). When not connected to a power supply, be sure to
use the screw on cover. The cover will protect the pins from accidental damage. Also, avoid
contact with the pins, as power supply caps can store voltage and possibly discharge when
touched.
AUDIO OUTPUTS
Transformer balanced outputs. Channel-1 top, Channel-2 bottom.
Pin-1 no connection, Pin 2 positive going phase, Pin-3 negative going phase.
LIMITER LINK
Top for Channel-1, Bottom for Channel-2. Both become linked to each other when PK REDUC-
TION mode switch is set to LINK.
TUBE CHANNEL
Protective housing for tubes and opto attenuator. When installing your L2M, be sure sufficient
air space is provided to prevent excessive heat build-up from the tubes.
TUBE PLACEMENT and FUNCTION (left to right)
•6AQ5A or 6005 (2ea) - Supplies voltage to the Electro-Luminescent Panel (T4C) Ch-1 & Ch-2
•12AX7 (2ea) - Control Voltage Amplifier (Limiter)
•T4C (2ea) - Optolux Electro-Optical Attenuator
•12BH7A or 12AU7 (2ea) - AUDIO Cathode Follower for M/S circuit
•12BH7A or 12AU7 (2ea) - AUDIO Cathode Follower/output driver
•12AX7 (2ea) - AUDIO Input gain stage
AUDIO INPUTS
Transformer balanced inputs. Channel-1 top, Channel-2 bottom.
Pin-1 no connection, Pin 2 positive going phase, Pin-3 negative going phase.
THE L2M MKIII M/S VERSION
Requisite Audio Engineering!L2M MkIII
13

OUTBOARD POWER SUPPLIES
POWER SUPPLIES
For the L2M MkIII M/S Version, and all Requisite mainframe audio processors, there is a choice
of two different power supplies:
•OPS-2D solid-state supply (1 to 2 channels)
•RTS-4A all-tube supply (1 to 4 channels)
Each supply is configured for the number of channels required for use a specific mainframe(s).
Depending on the configuration, there will be a cable(s) with a single, multi-pin connector for
B+, Heaters, Meter Lights and phantom power, which brings power to the mainframe unit(s).
POWER ON
This switch is located at the outboard power supply. When first connecting the power supply to
an L2M mainframe, please be sure your main power switch is turned off. Once the connector is
seated, carefully thread the ring lock of the cable to the jack on the L2M mainframe. If powering
only one L2M unit, with a supply having extra cables, be sure the unused cable(s) is rolled-up
and fastened to the supply with a cover over the unused end.
POWER CABLE
Each supply has an IEC connector for mains A/C. In the U.S. and Canada, the supply is
shipped with a North America power cable. For other countries a power cable is not supplied
and must be purchased locally.
VOLTAGE SELECT
Each power supply has a VOLTAGE SELECT to allow operation with A/C mains of 120V or
240V.
FUSE
Each power supply has a replaceable FUSE for overcurrent protection. Be sure to use the Slo-
Blo type (1.25”/32mm long) at the rating indicated on the supply for the mains voltage being
used. When going from 120V to 240V be sure to reduce the fuse to 1/2 the AMP value of the
120V fuse. Otherwise, the fuse will be overrated and not offer the same level of protection.
THE L2M MKIII M/S VERSION
Requisite Audio Engineering!L2M MkIII
14

WARRANTY
For a period of 2 years after original purchase, Requisite Audio Engineering will, free of
charge, repair this product if it fails due to defective materials or workmanship. This
limited warranty is subject to the following limitations:
•Units that are discovered to have been opened or tampered with will not be covered
by this warranty. We strongly discourage opening the chassis due to the risk of severe
electrical shock!
•Defects that are, in the sole judgement of Requisite Audio Engineering, the result of
accident, misuse, abuse, neglect, mishandling, misapplication, faulty installation, un-
authorized repair, modification, or act of God will not be covered by this warranty.
•In the absence of receipt of original purchase, this warranty is valid for 2 years from
date of manufacture as determined from the units serial number and the records of
Requisite Audio Engineering.
•There are no expressed warranties except as listed above.
•TUBES, OPTOS and LIGHT BULBS are not covered by this warranty, but receive a 90-
day warranty.
•REQUISITE AUDIO SHALL NOT BE LIABLE FOR PROPERTY DAMAGE OR ANY
OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGE WHATSOEVER WHICH
MAY RESULT FROM THE FAILURE OF THIS PRODUCT OR ARISING OUT OF THE
BREACH OF THIS WARRANTY. Any and all warranties of merchantability and fit-
ness implied by law are limited to the duration of the expressed warranty.
If a problem develops with this product DO NOT OPEN THE UNIT or attempt repair-
ing it yourself. Opening this unit invalidates your warranty and will expose you to risk
of very severe electrical shock!
REFER ALL REPAIR TO REQUISITE AUDIO. Do not return the unit without authoriza-
tion and instructions from us. Units must be shipped PRE-PAID both directions.
REQUISITE AUDIO cannot be responsible for damage due to shipping or improper
packaging. Save the original packaging.
This warranty gives you specific legal rights and you may also have other rights which
vary from state to state.
THE L2M MKIII M/S VERSION
Requisite Audio Engineering!L2M MkIII
15
