Introduction
This User’s Manual is suitable for
HDMI over Giga LAN Extender (NXMU-M220)
DVI over Giga LAN Extender（NXDU-M220）
It is divided into 2 parts:
Part 1: Uni-Cast Configuration
Part 2: Multi-Cast (Multi-to-Multi) Configuration
The Uni-Cast application is Plug-and-Play basis. It’s easy to install in seconds.
The Multi-Cast application can be used as multi-to-multi.
Occasion advantage disadvantage
Uni-Cast one on one
control &
broadcast
Plug-and-play basis
Via existing LAN system
Save bandwidth
Multi-channel can be
transmitted simultaneous
Rotary DIP
switch must be
paired
Only one on one
Multi-Cast multiple to
multiple
control &
broadcast
Single / Multi channels
broadcasting simultaneous
Multi-drop
Need High
Bandwidth
IGMP Hub

3
Package Content
Sender Unit and / or Receiver Unit x 1 set / pc
(see Ordering Information)
CAT5 cable (for testing)
Plastic Screw Driver x 1
CD with User’s Manual
Foot Pad Set
Optional
Mounting Bracket with Screws
RJ11 to RS232 Converter
Power Adapter (see Ordering Information)
Power Adapter is optional for extender with PoE function.
Ordering Information
Model Type Optional Power Adapter
NXDU-M220 Sender Unit and Receiver Unit 2
NXDU-220L Sender Unit 1
NXDU-220R Receiver Unit 1
NXMU-M220 Sender Unit and Receiver Unit 2
NXMU-220L Sender Unit 1
NXMU-220R Receiver Unit 1
Overview
The HDMI over Giga LAN Extender is a perfect solution for audio and video signal
extension via existing LAN (Local Area Network) system. It’s Plug-and-Play basis in
uni-cast application, neither GUI control nor RS232 setup is required. However, you
need to set an identical ID number (Rotary DIP Switch) for each Sender and Receiver
unit.
With multicast technology, one local unit can drive multiple remote units with no extra
network load. Via IGMP Giga Hub, there are 16 channels selectable and up to 4
channels can be transmitted simultaneously. Amazingly, each channel can be shown to
an incredible 65536 displays using a standard IT Ethernet structure on a LAN system.
For each source device a local unit is required, and a remote unit is needed for each
display device.
The HDMI over Giga LAN Extender is Full HD 1080p supported, HDCP compliant and
Blu-ray ready. Moreover, this has been common used in applications that require
greater distance, high speed transmission, real-time high video resolution, security, and
noise immunity. Based on Giga LAN structure, it supports super-high speed
transmission. It is ideal for situations that need live presentation, such as public
broadcasting, education center, boardrooms, etc.

4
Features
●Extend high definition video signal over LAN, depending on performance network
●Extend USB signal transmission by using the existing LAN system without
additional wiring
●Suitable for most of popular USB devices (e.g. USB sticks, USB printers, USB
Scanner, external hard disk drives etc.)
●16 selections on the DIP rotary DIP switch available for pairing
●Up to 4 pairings can be transmitted simultaneously over the Giga LAN System
●Using Giga LAN system for low latency network and well-grouping management
●Automatic EDID configuration
●PoE function supported, no additional power supply for the extender unit
●Well-developed Ethernet technology and TCP/IP communication protocol
●HDCP-compliant and Blu-ray ready
●HDTV compatible; support 1080p, 1080i, 720p, 720i
●Compatible with most of the popular screen resolution to XGA, SXGA, UXGA,
WSXGA….Full HD system
●Optional VESA mounting bracket supported (for VESA mountable display
attachment)
System Requirement
1. HDCP compliant monitors with HDMI interface for the HDCP video source
2. CAT5 / 5e / 6 UTP cable (EIA / TIA 568B industry standard compliant)
3. Ethernet Hub (Giga Ethernet Hub is recommended)
System Requirement for PoE
1. Ensure that a PSE device supports PoE function.
2. Ensure that a PSE device can provide sufficient power on the Ethernet cable.
3. STP and FTP cabling are recommended.
Relative Product
Model Function PoE
NVXM-M110 Uni-Cast N/A (NVXM-110L + NVXM-110R)
NVXM-M130 Multi-Cast,
Video Wall
N/A (NVXM-130L + NVXM-130R)
NVXM-M210 Uni-Cast Yes (NVXM-210L + NVXM-210R)
NVXM-M230 Multi-Cast,
Video Wall
Yes (NVXM-230L + NVXM-230R)
For more information, please check through this manual.

5
Part 1: Uni-Cast Confi
g
uration
------------------------ Part 1: Uni-Cast Configuration
I. Installation
1. Device Connection
WARNING!
●Ensure that all devices are powered off before connecting to the Unit.
●Make sure all devices you will connect are properly grounded.
●Place cables away from fluorescent lights, air conditioners, and machines
that are likely to generate electrical noise.
●Please allow adequate space around the unit for air circulation.
1. Connect the video source to the Sender Unit.
2. Connect the monitor to the Receiver Unit.
3. Use CAT5 cables (EIA / TIA 568B industry standard compliant) for connection
between Tx/Rx and LAN Hub.
4. Set an identical ID number on Rotary DIP Switch for both Units.
5. Apply the proper power to all connecting devices.
NOTE:
A). It is highly recommended using Giga Ethernet Hub for optimal transmission quality.
B). If users encounter no screen display in computer connection:
1. Make sure the device cables are correctly and firmly attached.
2. Set your display device’s (TV, monitor, etc.) input source as HDMI.
3. Check the PC BIOS configuration about the video output setting.
4. Connect your computer to the HDMI Display DIRECTLY to check if the video
signal gets through.
5. Set the Rotary DIP Switch to the correct position.
6. Inappropriate EDID data. Apply EDID Copy to your display (see EDID
Configuration section).
7. HDCP issue. The system will disable the video output signal when it detects
non-HDCP compliant display(s) on playing the HDCP video source. All the
connected output displays MUST be HDCP compliant while the video source is
HDCP compliant.

6
Part 1: Uni-Cast Confi
g
uration
2. Connection Pattern
Single Point-to-Point Application
Function as simple video extenders, without Ethernet Hub in between
■Sender’s and Receiver’s rotary DIP switch should be adjusted on the same position.

7
Part 1: Uni-Cast Confi
g
uration
II. Product Description
Ub USB Host connection
Ua USB Connector USB device(s) connection
T1 Connect to the HDMI source
R1 Video Connector Connect to the HDMI monitor
T2 R2 RJ-45 Jack Connect to an Ethernet Hub
T3 R3 Reset Button System reset
T4 R4 Power Supply Apply the proper power to the unit
T5 R5 F2 Push Button
T6 R6 F1 Push Button See Push Button Control section
T7 R7 Rotary DIP Switch Set up ID numbers
T8 R8 Serial Port 1 For system control
T9 R9 Serial Port 2 For data communication
T10 R10 Network Status LED Flashing: Connected to network
Off once: Abnormal
T11
Green: Unlink / Blue: Link OK
Flash Blue + Green: Linked but no video
source input
R11
Power/Link LED Red: Unlink / Blue: Link OK
Flash Blue + Red: Linked but no video
source input

8
Part 1: Uni-Cast Confi
g
uration
III. Operation
The LEDs on the Extender Units show the real-time status indicating the linking and
communication between the Sender Unit and the Receiver Unit. Users can identify the
current status through the LED indicators on the unit.
The quality of the output signal will depend largely upon the quality of video source,
cable and display device used. Low quality cables degrade output signal causing
elevated noise levels. Please use the proper cable and make sure the display device is
capable of handling the resolution and refresh rate selected.
NOTE:
The system will disable the video output signal when it detects non-HDCP compliant
display(s) on playing the HDCP video source. All the connected output displays MUST
be HDCP compliant, when the video source is HDCP compliant.
1. Setting
User needs to do the first thing setting Unicast mode in the browser because factory
default is Multicast Mode.
1.1 How to set Unicast for Sender
A). Domain Name
The first thing users need to do is setting the unit as Uni-cast mode via
browser because the factory default setting is Multi-cast mode. Identical ID
setting on the rotary DIP switch of both Sender and Receiver is essential.
Open web browser and insert the address. Please see the “Network
Configuration” section.
B).IP
Open web browser and insert Sender’s IP address. If you don’t know IP
address, you could find on the corner of Host Selection. Please see the
“Network Configuration” section.
C).Serial Command
1.2 How to set Unicast for Receiver
A).IP
Open web browser and insert Receiver’s IP address. If you don’t know IP
address, you could find on the corner of Host Selection. Please see the
“Network Configuration” section.
B).Serial Command
For more detail, please follow Network Configuration.

9
Part 1: Uni-Cast Confi
g
uration
2. Push Button Control
VIDEO Extender over Giga LAN
Press once (click within 0.3 sec.) - Link/ Unlink video (also functions for
all Tx & Rx in the same channel)
F1 Factory Default Setting for Tx: Power off the unit →Press and hold the
button →Power on the unit →Release the button after 17 sec. right
after the Power/Link LED flashes green & blue) →Re-power the unit
Press for 1 sec. - Select Graphic Mode or Video Mode (also functions for
all Tx & Rx in the same channel)
(Factory default: Graphic Mode)
F2 Press for 3 sec. – Enter Anti-Dither Adjustment Mode: Level 1 /Level 2 /
Off (also functions for all Tx & Rx in the same channel)
(Factory Default: Off)
Tx
Reset Reboot the system
Press once (click within 0.3 sec.) - Link/ Unlink video (also functions for
all Tx & Rx in the same channel)
Press and hold – USB port function enable/ disable
F1
Factory Default Setting for Rx: Power off the unit →Press and hold the
button →Power on the unit →Release the button after 17 sec. right
after the Power/Link LED flashes red & blue) →Re-power the unit
Press for 1 sec. - Select Graphic Mode or Video Mode (also functions for
all Tx & Rx in the same channel)
(Factory default: Graphic Mode)
Press for 3 sec. – Enter Anti-Dither Adjustment Mode: Level 1 /Level 2 /
Off (also functions for all Tx & Rx in the same channel)
(Factory Default: Off)
F2
*EDID Copy: Power off the unit →Press and hold the button →Power
on the unit →Release the button after 12 sec. (the Network Status LED
flashes yellow)
Rx
Reset Reboot the system

10
Part 1: Uni-Cast Confi
g
uration
3. EDID Configuration
EDID (Extended Display Identification Data) is greatly important which contains
information about manufacturer name and serial number, product type, maximum
image size, color characteristics, factory pre-set timings, frequency range limits, etc. In
some cases display problems may occur due to incorrect EDID communication
between the display monitor and the unit or inappropriate EDID data programmed by
display manufactures. Therefore, by adopting “EDID COPY” function, it will allow the
system to copy EDID information from EDID compliant displays in order to assure
accurate display performance.
●EDID Copy (on Receiver Unit only)
Step 1. Power off the unit
Step 2. Press and hold the button F2
Step 3. Power on the unit
Step 4. Release the button after 12 sec. (the Network Status LED flashes yellow)
NOTE:
1. Using HDMI or DVI for all monitors; do not mix them up in one system.
2. It is suggested using monitors with identical brand and type.

11
Part 1: Uni-Cast Confi
g
uration
4. Network Configuration
User may want to exchange casting mode between unicast and multicast, set up IP and
use EDID Copy function. There are two way to reach, browser and serial command.
2.1. To complete users' goal, configuration via browser is divided into two ways,
a. Typing Domain Name in the address bar
b. Typing IP in the address bar
Before starting take notice of differentiation between Domain Name and IP.
2.1.1. System configuration via Domain Name
aDomain Name is for Sender only.
b. It is suggested using “Safari” web browser or other web browsers like Google
Chrome, Firefox or IE…, etc. If you use other web browser which is not Safari you’ll
need to install “bonjour SDK”: Go to the website
http://developer.apple.com/opensource/ and look for “bonjour SDK download” for
installation.
c. The same pair of Sender and Receiver should have identical ID (Rotary DIP
Switch number)
d. Open web browser and insert the address: http://videolan-gateway0000.local
The four digits after the word “videolan-gateway” depends on the position of the Rotary
DIP Switch you’ve set. Please refer to the form below. For example, if the position is
set up as 7, then the address should be http://videolan-gateway1110.local

12
Part 1: Uni-Cast Confi
g
uration
4.1.2. System configuration via IP address
a. Type a specific IP in the address bar and go to the setting page for each extender
unit such as 169.254.xxx.xxx.It is suggested using “Safari” web browser or Google
Chrome, Firefox or IE.
b. If users do not know Senders or Receivers IP address, find on the corner of Host
Selection Page.
Rotary
Switch Four digits Domain Name
0 0000 http://videolan-gateway0000.local
1 1000 http://videolan-gateway1000.local
2 0100 http://videolan-gateway0100.local
3 1100 http://videolan-gateway1100.local
4 0010 http://videolan-gateway0010.local
5 1010 http://videolan-gateway1010.local
6 0110 http://videolan-gateway0110.local
7 1110 http://videolan-gateway1110.local
8 0001 http://videolan-gateway0001.local
9 1001 http://videolan-gateway1001.local
A 0101 http://videolan-gateway0101.local
B 1101 http://videolan-gateway1101.local
C 0011 http://videolan-gateway0011.local
D 1011 http://videolan-gateway1011.local
E 0111 http://videolan-gateway0111.local
F 1111 http://videolan-gateway1111.local

13
Part 1: Uni-Cast Confi
g
uration
4.2. Insert Domain Name / IP address to set up system
If you log in, you may see the following first. On System page, it shows the version
information.
You can also see the Update Firmware having two buttons; choose file and Upload, for
updating.

14
Part 1: Uni-Cast Confi
g
uration
Utilities provide system rebooting and factory default setting.
Status shows information of the Host unit such as ID, IP Address, default gateway, etc.

15
Part 1: Uni-Cast Confi
g
uration
The LAN Extender can either has its IP address assigned dynamically (DHCP) or it can
be given a fixed IP address.

16
Part 1: Uni-Cast Confi
g
uration
If there is no DHCP you must assign a static IP for the unit. You can get it from the
networking administrator.

17
Part 1: Uni-Cast Confi
g
uration
On Function Page, it is divided into three sections, Video over IP, USB over IP and
serial over IP.

18
Part 1: Uni-Cast Confi
g
uration
IV. Touch Screen Application
Connection Pattern
Touch Screen for USB monitor
Touch Screen for Serial monitor

19
------------------------ Part 2: Multi-Cast (Multi-to-Multi)
Configuration
I. Installation
1. Device Connection
WARNING!
●Ensure that all devices are powered off before connecting to the Unit.
●Make sure all devices you will connect are properly grounded.
●Place cables away from fluorescent lights, air conditioners, and machines
that are likely to generate electrical noise.
●Please allow adequate space around the unit for air circulation.
1. Connect the video source to the Sender Unit.
2. Connect the monitor to the Receiver Unit.
3. Use CAT5 cables (EIA / TIA 568B industry standard compliant) for connection
between Tx/Rx and Giga Hub.
4. Set different ID number for each Sender, Receivers are not limited.
5. Apply the proper power to all connecting devices.
NOTE:
A).It is suggested using the proper Giga Ethernet Hub (IGMP) to ensure optimal
transmission quality. (see System Requirement section)
B).If users encounter no screen display in computer connection:
1. Make sure the device cables are correctly and firmly attached.
2. Set your display device’s (TV, monitor, etc.) input source as HDMI.
3. Check the PC BIOS configuration about the video output setting.
4. Connect your computer to the HDMI Display DIRECTLY to check if the video
signal gets through.
5. Set the Rotary DIP Switch to the correct position.
6. Inappropriate EDID data. Apply EDID Copy to your display (see EDID
Configuration section).
7. HDCP issue. The system will disable the video output signal when it detects
non-HDCP compliant display(s) on playing the HDCP video source. All the
connected output displays MUST be HDCP compliant while the video source is
HDCP compliant.
Pa r t 2 : Mu l t
i
-
Cas
t
(
Mult
i
-
t
o
-
Mult
i
)
Confi
g
uratio
n

20
2. Connection Pattern
Multi-To-Multi Application
■Each Sender’s ID must be different.
Pa r t 2 : Mu l t
i
-
Cas
t
(
Mult
i
-
t
o
-
Mult
i
)
Confi
g
ura
t
io
n
