Rheem CLASSIC 90 RGTJ- SERIES User manual

FORM NO. G11-464 REV. 7
Supersedes Form No. G11-464 Rev. 6
GAS FURNACES
Annual Fuel Utilization Efficiency - AFUE
THIS MODEL
ENER UIDE
97%78%
HIGH
MID
82% 88%
92.0%
RGTJ- SERIES
Models with Input Rates
from 45,000 to 120,000 BTU/HR
[13.19 to 35.17 kW]
(All Models 90% A.F.U.E.† or Above)
CLASSIC®90
HIGH EFFICIENCY
DOWNFLOW/
HORIZONTAL
GAS FURNACES
The Rheem®Classic®90 High Efficiency line of downflow/
horizontal gas furnaces are designed for utility rooms, clos-
ets, alcoves, attics or crawl spaces. The RGTJ is shipped in
the downflow configuration and is easily converted for hori-
zontal left-hand airflow applications.
The design is certified by CSA.
Features
■Low profile “34 inch” design is lighter and easier to handle
and leaves room for optional accessories.
■Top electrical connections, left or right gas and conden-
sate drainage connections on downflow models.
■Condensate drain for horizontal application provided
standard.
■Integrated control board manages all operational functions
and provides hookups for an electronic air cleaner.
■A slow-opening gas valve and a specially designed
inducer system make it one of the quietest furnaces on
the market today.
■Galvanized steel cabinet.
■Optional indoor or outdoor combustion air.
■Control board diagnostics.
A variety of cooling coils and plenums designed to use with
the Classic 90 gas furnaces are available as optional acces-
sories for air conditioning models.
✝A.F.U.E. (Annual Fuel Utilization Efficiency) calculated in accordance with Department
of Energy test procedures.

2 Rheem Manufacturing Company
STANDARD EQUIPMENT
Completely assembled and wired; heat exchanger; primary: 409 stainless steel,
secondary: 29-4C stainless steel; induced draft; pressure switch; redundant
main gas control; blower compartment door safety switch; solid state time
on/off blower control; limit controls; manual shut-off valve; 100% safety lock
out; cool fan off delay; field selectable heat fan off delay; one hour automatic
retry; self-test diagnostics; control diagnostics; electronic air cleaner
connections; pressure regulator for natural and L.P. (propane) gases;
transformer; direct drive, multi-speed blower motor.
(Please note: a thermostat is not included as standard equipment.)
OPTIONAL EQUIPMENT
(See Accessory Page)
All models can be converted by a qualified distributor or local service dealer to
use L.P. (propane) gas without changing burners. Factory approved kits must be
used to convert from natural to L.P. (propane) gas and may be ordered as
optional accessories from a parts distributor.
For L.P. (propane) operation, refer to Conversion Kit Index Form.
WARNING
THIS FURNACE IS NOT APPROVED
OR RECOMMENDED
FOR USE IN MOBILE HOMES
90 HIGH EFFICIENCY
DOWNFLOW/HORIZONTAL
GAS FURNACE
PRIMARY AND SECONDARY
HEAT EXCHANGER
REMOTE
SENSOR
HOT SURFACE IGNITOR
IN-SHOT BURNERS
PRESSURE SWITCH
DRAFT INDUCER
INTEGRATED
FURNACE
CONTROL
GAS VALVE AND
MANIFOLD

Rheem Manufacturing Company 3
GENERAL TERMS OF LIMITED WARRANTY
BEFORE PURCHASING THIS APPLIANCE, READ IMPORTANT ENERGY COST AND EFFICIENCY INFORMATION AVAILABLE
FROM YOUR RETAILER.
PHYSICAL DATA AND SPECIFICATIONS
DOWNFLOW/HORIZONTAL MODELS U.S. and Canadian Models
NOTES: All models are 115V, 60HZ, 1
ø. Gas connection size for all models is 1/2" [13 mm] N.P.T.
➀See Conversion Kit Index Form for high altitude derate.
➁ Canadian installations only.
➂In accordance with D.O.E. test procedures.
MODEL IDENTIFICATION
Rheem will furnish a replacement for any part of this product
which fails in normal use and service within the applicable
period stated, in accordance with the terms of the limited
warranty.
For Complete Details of the Limited Warranty, Including Applicable Terms
and Conditions, See Your Local Installer or Contact the Manufacturer for
a Copy.
Primary and Secondary Heat Exchanger ...Twenty (20) Years
*Any Other Part.............................................Five (5) Years
*This five year limited warranty is applicable only to single-phase prod-
ucts installed in residential applications on or after January 1, 2001.
MODEL NUMBERS
RGTJ- SERIES 04EMAES 06EMAES 07EMAES 07EYBES 07EYBGS 09EZAGS 10EZAGS 10EZAJS 12ERAGS
INPUT-BTU/HR [kW] ➀45,000
[13.19]
60,000
[17.58]
75,000
[21.98]
75,000
[21.98]
75,000
[21.98]
90,000
[26.37]
105,000
[30.77]
105,000
[30.77]
120,000
[35.17]
HEATING CAPACITY
BTU/HR [kW]
42,000
[12.31]
56,000
[16.41]
70,000
[20.51]
70,000
[20.51]
70,000
[20.51]
84,000
[24.61]
97,000
[28.43]
97,000
[28.43]
113,000
[33.12]
HIGH ALTITUDE INPUT
[kW] ➁
40,500
[11.87]
54,000
[15.83]
67,500
[19.78]
67,500
[19.78]
67,500
[19.78]
81,000
[23.73]
94,500
[27.70]
94,500
[27.70]
108,000
[31.65]
HIGH ALTITUDE OUTPUT
CAPACITY [kW] ➁
37,800
[11.07]
50,400
[14.77]
63,000
[18.46]
63,000
[18.46]
63,000
[18.46]
76,000
[22.27]
87,500
[25.64]
87,500
[25.64]
100,000
[29.31]
BLOWER (D x W)
[mm]
11 x 7
[279 x 178]
11 x 7
[279 x 178]
11 x 7
[279 x 178]
12 x 7
[305 x 178]
12 x 7
[305 x 178]
12 x 11
[305 x 279]
12 x 11
[305 x 279]
12 x 11
[305 x 279]
11 x 10
[279 x 254]
MOTOR H.P. [W]
SPEEDS-TYPE
1/2 [373]
4-PSC
1/2 [373]
3-PSC
1/2 [373]
3-PSC
1/2 [373]
3-PSC
3/4 [559]
3-PSC
1/2 [373]
3-PSC
1/2 [373]
3-PSC
3/4 [559]
3-PSC
1/2 [373]
3-PSC
MOTOR FULL LOAD AMPS 6.8 6.8 6.8 8.0 9.5 8.0 8.0 9.5 8.0
HEATING SPEED Med-Low Low Med Med Low Med Med Low Med
COOLING SPEED High High High High High High High High High
09EZAJS
90,000
[26.37]
84,000
[24.61]
81,000
[23.73]
76,000
[22.27]
12 x 11
[305 x 279]
3/4 [559]
3-PSC
92.1%
160 [72.6]
50-80
[27.8-44.4]
HEAT EXT. STATIC PRESSURE
(IN. W.C.) [kPA] .10 [.025] .12 [.029] .12 [.029] .12 [.029] .12 [.029] .15 [.037] .20 [.049] .20 [.049] .20 [.049]
RATED EXT. STATIC PRESSURE
(IN. W.C.) [kPA] .50 [.12] .50 [.12] .50 [.12] .50 [.12] .50 [.12] .50 [.12] .50 [.12] .50 [.12] .50 [.12]
HEATING C.F.M. @ .2"
W.C. E.S.P. [L/s] 890 [420] 885 [418] 1060 [500] 1275 [602] 1275 [602] 1400 [661] 1425 [673] 1425 [673] 1565 [739]
2040 [963]
1565 [739]
.50 [.12]
.20 [.049]
High
Low
9.5
3/4 [559]
3-PSC
11 x 10
[279 x 254]
100,000
[29.31]
COOLING C.F.M. @ .5"
W.C. E.S.P. [L/s] 1220 [576] 1180 [557] 1150 [543] 1370 [647] 1625 [767] 1570 [740] 1560 [736] 1820 [859] 1700 [802]
TEMPERATURE RISE
RANGE °F [°C]
30-60
[16.7-33.3]
40-70
[22.2-38.9]
45-75
[25-41.7]
35-65
[19.4-36.1]
35-65
[19.4-36.1]
35-65
[19.4-36.1]
50-80
[27.8-44.4]
50-80
[27.8-44.4]
50-80
[27.8-44.4]
APPROX. SHIPPING WEIGHT
(LBS.) [kG] 111 [50.3] 117 [53.1] 123 [55.8] 123 [55.8] 123 [55.8] 148 [67.1] 152 [68.9] 152 [68.9] 160 [72.6]
AFUE ➂92.0% 92.4% 92.0% 92.3% 92.3% 92.4% 92.0% 92.0% 92.1%
9.5
Low
High
.15 [.037]
.50 [.12]
1400 [661]
108,000
[31.65]
1850 [873]
35-65
[19.4-36.1]
148 [67.1]
92.4%
113,000
[33.12]
120,000
[35.17]
12ERAJS
(2) 14" x 20"
[609 x 508]
STANDARD FILTER [mm] (2) 12" x 20"
[305 x 508]
(2) 12" x 20"
[305 x 508]
(2) 12" x 20"
[305 x 508]
(2) 12" x 20"
[305 x 508]
(2) 12" x 20"
[305 x 508]
(2) 12" x 20"
[305 x 508]
(2) 12" x 20"
[305 x 508]
(2) 12" x 20"
[305 x 508]
(2) 14" x 20"
[609 x 508]
(2) 12" x 20"
[305 x 508]
87.37%
CALIFORNIA SEASONAL
EFFICIENCY ➂84.35% 86.46% 89.96% 85.00% 85.00% 86.40% 87.02% 87.02% 87.37%86.40%
RG T J
—07E AMES
Rheem Gas
Furnace
Downflow/
Horizontal
Condensing
Gas Furnace
Design
Series
Heating Input
Designation
Variations
A= Std.
B= Wide
Cabinet
Blower Size
M= 11 x 7
[279 x 178 mm]
R= 11 x 10
[279 x 254 mm]
Z= 12 x 11
[305 x 279 mm]
Y= 12 x 7
[305 x 178 mm]
Heat/Cool
Designation
E= 1100-1300 CFM
[519-613.5 L/s]
G= 1500-1700 CFM
[707.9-802.3 L/s]
J= 1900-2100 CFM
[896.7-991.1 L/s]
Fuel Code
S= U.S. and
Canadian
Natural Gas
Hot Surface
Ignition
04E
06E
07E
09E
10E
12E
Input
BTU/HR
45,000 [13 kW]
60,000 [17.6 kW]
75,000 [20.5 kW]
90,000 [26.4 kW]
105,000 [30.7 kW]
120,000 [35.2 kW]
[ ] Designates Metric Conversions

4 Rheem Manufacturing Company
DOWNFLOW MODELS
[ ] Designates Metric Conversions
IMPORTANT NOTE: Horizontal furnace maybe installed for horizontal left hand air supply ONLY. The condensate trap provided for horizontal application must be
installed in the field beneath the unit as directed in the furnace Installation & Operating Instructions.
MODEL
RGTJ- A B C D E F LEFT SIDE
MINIMUM CLEARANCE (IN.) [mm] SHIP
WGTS.
[kg]
RIGHT
SIDE BACK TOP FRONT VENT
04 171/2[445] 1611/32 [415] 155/8[397] 2 [51] 165/8[422] 137/8[352] 0 0 0 1 [25] 2 [51] 0111 [50]
06 171/2[445] 1611/32 [415] 155/8[397] 2 [51] 165/8[422] 137/8[352] 0 0 0 1 [25] 2 [51] 0117 [53]
07EM 171/2[445] 1611/32 [415] 155/8[397] 2 [51] 165/8[422] 137/8[352] 0 0 0 1 [25] 2 [51] 0123 [56]
07EY 21 [533] 1927/32 [504] 193/16 [486] 2 [51] 201/8[511] 173/8[441] 0 0 0 1 [25] 2 [51] 0123 [56]
09 21 [533] 1927/32 [504] 193/16 [486] 2 [51] 201/8[511] 173/8[441] 0 0 0 1 [25] 2 [51] 0148 [67]
10 21 [533] 1927/32 [504] 193/16 [486] 2 [51] 201/8[511] 173/8[441] 0 0 0 1 [25] 2 [51] 0152 [69]
12 241/2[622] 2311/32 [593] 225/8 [575] 2 [51] 235/8 [600] 207/8[530] 0 0 0 1 [25] 2 [51] 0160 [73]

Rheem Manufacturing Company 5
HORIZONTAL MODELS
IMPORTANT NOTE: Horizontal furnace may be installed for horizontal left hand air supply ONLY. The condensate trap provided for horizontal application must be
installed in the field beneath the unit as directed in the furnace Installation & Operating Instructions.
[ ] Designates Metric Conversions

6 Rheem Manufacturing Company
BLOWER PERFORMANCE DATA—RGTJ MODELS
MODEL
RGTJ-
BLOWER
SIZE
IN. [mm]
MOTOR
H.P.
[W]
BLOWER
SPEED
CFM [L/s] AIR DELIVERY
EXTERNAL STATIC PRESSURE INCHES WATER COLUMN [kPa]
09EZAGS 12 x 11
[305 x 279]
1/2
[373]
LOW
MED
HIGH
1155 [545]
1420 [670]
1605 [757]
1125 [531]
1400 [661]
1575 [743]
1100 [519]
1380 [651]
1550 [732]
1080 [510]
1365 [644]
1560 [736]
1060 [500]
1350 [637]
1570 [740]
1000 [472]
1260 [594]
1480 [698]
0.1 [.02] 0.2 [.05] 0.3 [.07] 0.4 [.10] 0.5 [.12] 0.6 [.15] 0.7 [.17]
04EMAES 11 x 7
[279 x 178]
1/2
[373]
LOW
MED-LO
MED-HI
HIGH
820 [387]
930 [439]
1150 [543]
1414 [667]
790 [373]
890 [420]
1120 [528]
1365 [644]
760 [359]
850 [401]
1090 [514]
1320 [622]
725 [342]
815 [384]
1045 [493]
1270 [599]
690 [326]
785 [370]
1002 [473]
1220 [576]
650 [306]
750 [354]
950 [448]
1165 [550]
610 [288]
720 [340]
900 [425]
1115 [526]
06EMAES 11 x 7
[279 x 178]
1/2
[373]
LOW
MED
HIGH
910 [429]
1115 [526]
1365 [644]
885 [418]
1080 [510]
1315 [620]
860 [406]
1045 [493]
1270 [600]
815 [384]
1005 [474]
1225 [578]
770 [363]
965 [455]
1180 [557]
725 [342]
920 [434]
1125 [491]
680 [321]
875 [413]
1070 [505]
07EMAES 11 x 7
[279 x 178]
1/2
[373]
LOW
MED
HIGH
890 [420]
1100 [519]
1340 [632]
860 [406]
1060 [500]
1295 [611]
835 [394]
1025 [484]
1250 [590]
790 [373]
980 [462]
1200 [566]
750 [354]
940 [443]
1150 [543]
705 [332]
890 [420]
1090 [514]
660 [311]
845 [399]
1025 [484]
07EYBES 12 x 7
[305 x 178]
1/2
[373]
LOW
MED
HIGH
1105 [522]
1290 [609]
1480 [698]
1095 [517]
1275 [602]
1435 [677]
1080 [510]
1260 [595]
1415 [668]
1050 [496]
1220 [576]
1390 [656]
1030 [486]
1195 [564]
1370 [647]
1010 [477]
1170 [552]
1300 [614]
990 [467]
1140 [538]
1255 [592]
940 [443]
1175 [554]
1395 [656]
12ERAJS 11 x 10
[279 x 245]
3/4
[559]
LOW
MED
HIGH
1590 [750]
1840 [868]
2315 [1093]
1565 [738]
1820 [860]
2250 [1062]
1540 [727]
1800 [850]
2185 [1031]
1505 [710]
1750 [826]
2110 [996]
1475 [696]
1700 [802]
2040 [963]
1425 [672]
1645 [776]
1965 [927]
07EYBGS 12 x 7
[305 x 178]
3/4
[559]
LOW
MED
HIGH
1290 [609]
1480 [698]
1705 [805]
1275 [602]
1435 [677]
1665 [786]
1260 [595]
1415 [668]
1615 [762]
1220 [576]
1390 [656]
1570 [741]
1195 [564]
1370 [647]
1540 [727]
1170 [552]
1300 [614]
1475 [696]
1140 [538]
1255 [592]
1400 [661]
1375 [649]
1590 [750]
1890 [892]
09EZAJS 12 x 11
[305 x 279]
3/4
[559]
LOW
MED
HIGH
1420 [670]
1605 [757]
2005 [946]
1400 [661]
1575 [743]
1965 [927]
1380 [651]
1550 [732]
1930 [910]
1365 [644]
1560 [736]
1890 [892]
1350 [637]
1570 [740]
1850 [873]
1260 [594]
1480 [698]
1765 [833]
1175 [554]
1395 [656]
1680 [793]
10EZAGS 12 x 11
[305 x 279]
1/2
[373]
LOW
MED
HIGH
1180 [557]
1460 [689]
1680 [793]
1150 [543]
1425 [672]
1645 [776]
1120 [528]
1390 [656]
1615 [762]
1100 [519]
1375 [649]
1585 [748]
1080 [510]
1360 [642]
1560 [736]
1025 [484]
1280 [604]
1490 [703]
970 [458]
1200 [566]
1420 [670]
10EZAJS 12 x 11
[305 x 279]
3/4
[559]
LOW
MED
HIGH
1460 [689]
1680 [793]
2055 [970]
1425 [672]
1645 [776]
2000 [944]
1390 [656]
1615 [762]
1940 [915]
1375 [649]
1585 [748]
1880 [887]
1360 [642]
1560 [736]
1820 [859]
1280 [604]
1490 [703]
1745 [823]
1200 [566]
1420 [670]
1675 [790]
12ERAGS 11 x 10
[279 x 245]
1/2
[373]
LOW
MED
HIGH
1285 [606]
1590 [750]
1840 [868]
1250 [590]
1565 [738]
1820 [860]
1215 [573]
1540 [727]
1800 [850]
1235 [582]
1505 [710]
1750 [826]
1260 [595]
1475 [696]
1700 [802]
1230 [580]
1425 [672]
1645 [776]
1200 [566]
1375 [649]
1590 [750]
NOTE: Recommended blower speeds are in bold.
[ ] Designates Metric Conversions

Rheem Manufacturing Company 7
ACCESSORIES—DOWNFLOW
PLENUM DATA FOR “A” COILS
Plenum adapters are required in some applications when plenum and
furnace size do not match.
VENT TERMINATION KITS CONCENTRIC: Horizontal/Vertical = RXGY-E03
HORIZONTAL TWO PIPE: RXGY-D02, RXGY-D03, RXGY-D04
CONDENSATE PUMP KIT: RXGY-B01
NEUTRALIZER KIT: RXGY-A01
FOSSIL FUEL KIT: RXPF-F01, RXPF-F02 (TVA)
FOR HIGH ALTITUDES:
*Filter racks are shipped without filters.
RXGP-F03
TWINNING KIT—is for use with Rheem Classic 90 Gas Furnaces for
parallel operation requirements (not needed with RGTA downflow/
horizontal gas furnaces).
Note: See Form Number C11-206 for MultiFlex®coil data.
COMBUSTIBLE FLOOR BASE: RXGC-B17, RXGC-B21, RXGC-B24
EXTERNAL TOP MOUNT FILTER RACK: RXGF-CC
INTERNAL FILTER RACK FOR AIR RETURN DUCT: RXGF-DB*
Each order contains (1) one box of 10 filter racks supplied without filters.
*Filters available through PROSTOCK®.
FURNACE
WIDTH
IN. [mm]
PLENUM
WIDTH
IN. [mm]
PLENUM ADAPTER
DOWNFLOW
COIL
PLENUM
171/2[445] 161/4[413] RXAA-C186 RXAL-B16BU
171/2[445] 201/4[514] RXAA-C173 RXAL-B20BU
171/2[445] 215/8[549] RXAA-C187 RXAL-B21BU
171/2[445] 251/4[641] RXAA-C174 RXAL-B25BU
211/2[533] 251/4[641] RXAA-C175 RXAL-B25BU
211/2[533] 221/4[565] RXAA-C176 RXAL-B22BU
241/2[622] 251/4[641] RXAA-C177 RXAL-B25BU
241/2[622] 215/8[549] RXAA-C187 RXAL-B21BU
211/2[533] 215/8[549] RXAA-C188 RXAL-B21BU
*HIGH ALTITUDE KIT:
F04-105 KBTU/H
F06-45/60/90 KBTU/H
F05-120 KBTU/H
F07-75 KBTU/H
FILTER RACK FILTER SIZES®INCHES [mm]
MODEL RGTJ- RXGF-CC
04 (2) 12 x 20 [305 x 508]
06 (2) 12 x 20 [305 x 508]
07 (2) 12 x 20 [305 x 508]
09 (2) 12 x 20 [305 x 508]
10 (2) 12 x 20 [305 x 508]
12 (2) 14 x 20 [305 x 508]
*For installations over 5000 ft.
OPTION CODE FOR HIGH ALTITUDE: U.S. & Canada – 278
NOTE: High altitude kits and options do NOT include additional burner
orifices. If a burner orifice change is necessary, they must be
ordered through PROSTOCK®. See Installation Instructions for
more information.
Option – 278 furnaces are shipped with #51 DMS orifices installed. This is
one drill size smaller than standard furnaces to account for expected
average elevations and heating values typically seen in these areas.
CAUTION: Always follow National Fuel Gas Code (NFGC) guidelines when
converting furnaces for high altitudes.
For all installations above 2000 ft. (including all option – 278 models), the
burner orifice size needs to be recalculated and verified. A burner orifice
change may still be required. See Installation Instructions for more
information.
NOTE: For Canadian installations only, an optional derate (manifold gas
pressure reduction) method may be used to adjust the furnace for
altitude. See Installation Instructions for more information. This
optional method may NOT be used for U.S. installations.
[ ] Designates Metric Conversions

Before proceeding with installation, refer
to installation instructions packaged
with each model, as well as complying
with all Federal, State, Provincial, and
Local codes, regulations, and practices.
RHEEM
AIR CONDITIONING
DIVISION
5600 Old Greenwood Road, Fort Smith, Arkansas 72908
“In keeping with its policy of continuous progress and product improvement, Rheem reserves the right to make changes without notice.”
PRINTED IN U.S.A. 2-06 DC FORM NO. G11-464 REV. 7
Supersedes Form No. G11-464 Rev. 6
