Rheinstrom M 60 Owner's manual

Diaphragm Pump M 60
Installation – Operation – Maintenance
10/2002

Installation - Operation - Maintenance
01/2001
Diaphragm Pump M60
General Information
Bybuyingthe diaphragm pump M 60 you have purchased a Rheinstrom high-qualityproduct.
We onlyuse well-chosen high-qualitycomponents to ensure a trouble-free operation for many
years to come.
This type of pump has been especiallydesigned to be used as a sewage or bilge pump for
private yachts or professionallyused ships. The pump is sewage and seawater resistant due to
the use of red brass and stainless steel. The diaphragm and all rubber parts are oil-resistant.
Powerful direct current(DC) motors or 3-phase- (AC) motors make the pump suitable for
continuous operation (naturallyaspirated when dry).
Each pump is checked thoroughlybefore leavingour house. Rheinstrom gives a 1 year
warrantyfor each pump and guarantees a trouble-free functioningif the unit is installed
professionallyand treated properly.
Technical Data
Pump performance (output) 50 l /min
Suction height 6 m
Discharge height (vertical rise) 15 m
Connections 1 ½ ‘’
Weight 40 kg
Motor rating0,75 kw
OperatingVoltage 12 V- 400 V
Installation
There are manypossibilities for positioningand mountingwith footand rear mounting, for
this pump. With the above and the movable connections the installation can be chosen in
accordance with the conditions on board. The pump’s housingcan be rotated bylooseningthe
sixfixingscrews (60 degree steps) if necessary.
If you do not want to installthe pump in the horizontalpositioningplease make sure that the
sealing-casing(suction and delivery) is turned into the right position. The lughas to be on top
(see drawingNo. 3260103).
If the pump is to be installed belowwater-line and the outboard connection is also below
water-line the gooseneck pressure pipe has to be at least 500 mm above water-line. Please
make sure that the pipe cross-section must never be smaller than 1 ½ ‘’ or 38 mm at anyplace.
Otherwise the pump willnot be able to work efficientlycausingthe diaphragm and the valves
to fail prematurely.
E.Th.

RheinstromM60
Attention
The diaphragmpump M 60 is a displacement pump. It may never be run when the
delivery valve is closed because this can harmthe motor, the gear transmission and the
pump. The max. pressure may not exceed 1.5 bar = 21.345 psi.
The installation of the pump into the power supply systemshould be carried out by
trained personnel and according to the instructions of the VDE.
---- Please make sure that the voltage on board and the information on the pump’s data plate
are corresponding.
---- Please connect polarity !
Reversed wires maydestroythe motor of the pump.
(red=positive, black=negative)
You must not change the polarityof the pump’s connectors.
---- Use connection cables with a bigenough cross-section. We recommend a cross-section of
10mm2for 12V/24V.
---- The motor of the pump should be protected byan overload relay. We recommend the
installation of an automatic fuse. In case a fuse is used an ON/OFF switch should be
installed in the positive wire.
Maintenance
The sewage pump M60 is practicallymaintenance free. In case of a possible cloggingthe
check.-valves can be reached easilyafter removingboth connection tubes . If frostis expected
you should let the pump run empty. Small quantities of remainingwater willnotharmthe
pump even in verycold weather.
Spareparts
We can supplyyou with anypart the pump contains of. Furthermore we have repair kits
containingall seals and wear parts in store. You can find allpart numbers and descriptions in
our part list or on the enclosed drawing. For more information about our product range we
would be pleased to send you our catalogue.
Illustrations are noncommittal
Construction and design can be subject to change without notice
Rheinstrom - Pumpenfabrik GmbH
Wallersheimer Weg 13-19 Postfach 1725
56070 Koblenz - Germany 56070 Koblenz - Gemany
Telefon [phone] , Telefax 0049 261 82029
E-Mail= [e-mail]
E.Th.

RheinstromM60
E.Th.

RheinstromM60
DiaphramPump M 60 - 400 V
Type-No. Discription Each
3260133 Gearmotor 400V 1
3260134 Gear 1
3260100 Housing, lower part, RG 1
3260101 Housing, upper part, RG1
3260102 Threaded connection, RG 2
3260103 Sealing-casing2
3260104 Double flange 2
3260105 Valve weight 2
3260106 Valve rupperseal 2
3260107 Rupper seal 4
3260108 Diaphragm 1
3260109 Diaphragm pressure plate 1
3260110 Connectingrod1
3260111 Crank shaft1
3260112Ball bearing2202 2RS 1
3260113 Snap ring Ø351
3260114 Bolt M12x 25DIN 933A2 1
0510027 Bolt for Gear M8 x20 DIN 6912A2 4
0811066 Bolt M10x 35DIN 912A2 6
3260117 Washerd=8,4DIN 9021 A2 2
3260118 Fitting key8x 8 x30 Stahl 1
3260119 PulleyØ40 x 10 1
3260120 Bolt M8 x16 DIN 933 A22
3260121 Cap1
3260122 Bolt M6 x15 DIN 933 A24
0104004 Hexagonal nut M 6 DIN 934 A2 2
0104033 Washerd=8,4DIN 125A237
0350019 Hexagonal nut M 8 DIN 934 A2 16
0480020 Bolt M8 x40 DIN 933 A28
0580073 Hexagonal nut M 10DIN 934A26
0809075 Bolt M8 x30 DIN 933 A28
0811068 Bolt M6 x16 DIN 963 A22
0101045 Washerd=6,4DIN 125A24
0889030 Washerd=10,5 DIN 125 A2 12
0911048 Washerd=12,5 DIN 125 A2 1
E.Th.

Pumpenfabrik GmbH
CE-Directionsfor Machinery Equipment
Manufacturer’s Statement
We Rheinstrom-Pumpenfabrik GmbH
Wallersheimer Weg13 - 19
D - 56070Koblenz, Germany
declare, being completelyresponsible, that this product :
Rheinstrom – Diaphragm Pump M60
to whichthisstatement refers tois in accordance with the Directions of
MachineryEquipment correspondingtoappendixNo. IV (Art. 8(2) a).
It isnot allowed totake the above mentioned product into use before the
unit intowhich the product isto be installed or connected tois declaredto
be in accordance with theDirectoryof MachineryEquipment.
Koblenz - Germany, 17.02.2003
Rheinstrom-Pumpenfabrik GmbH
W. Theisen
