880 Performance™ Series
Adapter Panel Installation
If mounting the 880 Performance Series Indicator in a panel previously used for a different indicator, the hole in the
panel may be too large/small to mount the 880 indicator.
The following instructions will assist in the mounting of the adapter plate to be used in these situations.
Note
For more information on the 880 Performance Indicator, see the Installation/Service manual (PN 158387) or the
Operator’s manual (PN 152240).
Manuals can be viewed or downloaded from the Rice Lake Weighing Systems website at
www.ricelake.com.
Nut, Kep 8-32NC Hex
PN 14626
Gasket, 880 Panel Mount
PN 159135
Washer, Bonded Sealing SST
PN 75062
Adapter Plate, 880 Panel
PN 159134
Screw, Mach 8-32NC x 5/8
PN 159438
Figure 1. Parts for the Panel Retrofit Option
If the existing hole in the panel is too small to accommodate the DIN Rail mounting plate, the hole will need to be
enlarged to the correct size.
Existing Panel 1/4" Gap minimum is
required around DIN
Rail Mounting Plate.
DIN Rail 
Mounting Plate.
Note
If the panel this indicator is being mounted to is 16ga (.06) or thinner, there is no need to enlarge the hole. The
mounting studs will go through the panel, adapter plate and the DIN Rail mounting plate far enough to secure
the display. Skip to Step 2.
1. Using the DIN Rail mounting plate as a guide, mark the panel for cutting the opening to the size required.
There should be at least 1/4" gap between the mounting plate and the opening in the panel. See Figure 2.
Figure 2. Enlarge Opening (If Required)

2Adapter Panel Installation
2. Use the adapter plate as a template to mark the holes to be drilled for the screws. Ensure the plate is
centered over the opening and the larger hole is on the right side.
Existing Panel
Mark holes to be drilled
Adapter Plate
Figure 3. Adapter Plate as Template
3. Drill the holes.
4. Align adapter plate (gasket side toward panel) to the holes drilled in the panel and secure with screws,
sealing washers and nuts. Torque to 8 in-lb.
Adapter Plate
Gasket
Screws and Washers
Nuts
Existing Panel
Figure 4. Install Adapter Plate

Adapter Panel Installation 3
5. Install the gasket on the display assembly. It must be seated correctly on the display before mounting to
ensure tight seal.
6. Secure the display and mounting plate to the panel using the four 6-32 Kep nuts (PN 14621) provided.
DIN Rail Mounting Plate
Display Assembly
6-32 Kep Nuts
Ensure gasket is
seated properly on
display assembly
before mounting.
Important
Adapter Plate mounted to
existing panel.
Figure 5. Install Display
7. Connect the cable assembly to the controller assembly.
8. Place the controller assembly on the DIN rail as shown in Figure 6.
9. Secure to DIN rail by rotating the left and right hooks up, connecting with the bottom rail.
Connect cable assembly to
controller assembly
Controller
Assembly
Rotate hooks to secure
to bottom DIN rail
A slot is provided for a
screwdriver to lift the
positioning dimple from
the locating hole prior to
rotating the lever.
Figure 6. Install Controller Assembly
10. Connect all connectors to the backplate. See the Installation/Service manual (PN 158387) for connector
locations.
