RiceMaster RM-55N-R User manual

72 Beadel Street Brooklyn, NY 11222
718/ 388-5650 outside New York State 800/ 221-5032 facsimile 718/ 388-5860
www.townfood.com
© Town Food Service Equipment Company, Inc. No part of this booklet or it ’s illustrations may be copied or reproduced without
written authorization from Town Food Service Equipment Co., Inc.
REVISED MAY, 2012
Automatic Gas Rice Cooker Owner’s Manual
RM-55N-R (NATURAL GAS) |RM-55P-R (PROPANE GAS) NSF AND ETL CERTIFIED
RM-50N-R (NATURAL GAS) |RM-50P-R (PROPANE GAS) NOT CERTIFIED
SECTION 1 INSTALLATION INSTRUCTIONS
Warning
Improper installation, adjustment, alteration, service or maintenance can cause property damage,
injury or death.
Read the installation, operating and maintenance instructions thoroughly before installing or servicing
this equipment.
For Your Safety
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
Important
Contact your local gas supplier if you smell gas near this equipment.
FOR COMMERCIAL USE ONLY
Do not DiscarD instructions. this manual must remain with the unit for future reference.
this emergency information must be prominently DisplayeD.

2
Town Food Service Equipment Company, Inc. 718/388-5650 outside New York State 800/221-5032
Congratulations on your purchase of your RiceMaster Automatic Gas Rice Cooker.
With proper installation, care and use, it should provide years of reliable service.
IMPORTANT NOTE
The RM-50N-R or RM-50-P-R is not NSF or ETL certified. However, it’s functionality and most of the
specifications are identical to the RM-55N-R and RM55P-R. Most RM-50N-R and RM-50-P-R parts are
interchangeable with RM-55N-R and RM-55P-R. Except for listings and certification, information in this
manual for the RM-50N-R and RM-50-P-R is the same as the RM-55N-R and RM-55-P-R.
PARTS IDENTIFICATION
____________________________________________________________________________________________
rice pot
outer jacket
BURNER ASSEMBLY
1shut off stem
2burner base cover
3pilot/warmer
4main burner
5data plate
6 no.1 start button/ignition lever
7 no.2 main burner/cook button
8 main gas valve knob
9 pilot ignition button-red
lid
pressure regulator
jacket window
234
5
67
9
8
1

Town Food Service Equipment Company, Inc. 718/388-5650 outside New York State 800/221-5032
RM-55N-R RM-55P-R RM-50N-R RM-50P-R
3
INSTALLATION INSTRUCTIONS
____________________________________________________________________________________________
6”
6”
1) The gas supply line must be of adequate size to ensure maximum efficiency of the unit.
2) The installation must conform with the National Fuel Gas Code, ANSI Z223.1, Natural Gas
Installation Code, CAN/CGA-B149.1 or the Propane Installation Code, CAN/CGA-B149.2,
as applicable including:
a) The appliance and it’s individual shut-off valve must be disconnected from the gas supply
piping system during any pressure testing of that system at test pressure in excess of 1⁄2 psig
(3.45 kPa).
b) The appliance must be isolated from the gas supply piping system by closing it’s individual
manual valve during any pressure testing of the gas supply piping system at test pressures
equal or less than 1⁄2psig (3.45 kPa).
3) Local regulations governing gas appliance installations must be complied with.
4) Equipment should be in an area with adequate ventilation.
5) Minimum spacing of 6” to combustible construction is required along back
and side walls. Clearance for noncombustible construction are the same as
combustible clearances. For use only on noncombustible surfaces.
6) Materials such as wood, compressed paper and plant fibers that will ignite and burn, must not
be exposed near the unit. Local safety codes should be complied with in respect to fire
hazard avoidance.
7) Use of the supplied pressure regulator is mandatory. Note that the use of 2 regulators may cause
insufficient gas flow. Consult with installer but always comply with above codes.
8) Keep the appliance area free and clear from combustible materials, gasoline and other flammable
vapors and liquids.
9) Locate this appliance in a well ventilated area. Do not block or cover the opening between the
shroud and pot. Do not obstruct flow of combustion and ventilation air.
10) The unit must be installed with adequate clearance for servicing and proper operation.
11) If the unit is connected to a flexible gas line, the installation must be made with a connector that
complies with the Standard Connectors for Movable Gas Appliances, ANSIZ21.69 or Connectors
for Movable Gas Appliances, CAN/CGA-06.16, and a Quick Disconnect device that complies with
the standard for Quick Disconnect Devices for Use with Gas Fuel ANSIZ21.41, or Quick Disconnect
Devices for use with Gas Fuel, CAN1-6.9, and adequate means must be provided to limit the
movement of the appliance without depending on connector and the Quick Disconnect device or it’s
associated piping to limit movement of the appliance.
12) Before connecting gas check that gas valve is turned OFF (gas valve handle in the vertical position).
13) Check for leaks using soapy water or other suitable leak detector. Rinse off the soapy water
after testing. Do not use open flame for testing.

4
Town Food Service Equipment Company, Inc. 718/388-5650 outside New York State 800/221-5032
WARM
START
1
Always follow these lighting and shut down instructions when lighting rice cooker. A 5 minute complete
shutoff period is required before lighting or relighting pilot. Check for gas leaks before relighting unit.
Use soapy water or other suitable leak detector. Rinse off the soapy water after testing.
Notice to Installer—the following must be performed to insure proper operation
1) Remove pot, outer jacket, and base cover.
2) Turn gas valve to ON position as shown in figure 2 below.
3) Gently push on the #2 COOK button. It should stop half way down and not engage.
This is a safety feature feature that does not allow accidental start of the main burner unless the pilot
button has already been pushed.
4) Push the left button marked #1 START down until the unit clicks, then release it. This is the ignition lever
and should light the pilot. The red button labeled WARM button controls the pilot and is hidden by
the #1 START button when off. Pushing the #1 START button also engages the WARM button and
exposes it. It will stay down until pushed up to extinguish the pilot. If the pilot has not lit, repeat until
the pilot lights.
5) If pilot fails to remain lit, refer to TROUBLE SHOOTING on page 14.
6) Replace the pot, outer jacket, and base cover in their proper order. With the pilot lit, push the
#2 COOK button down to its position without water in the pot. The unit should shut off within 3
to 4 minutes. If it fails to shut off, push the #2 COOK button up to the OFF position and see
TROUBLE SHOOTING on page 14. If it shuts off normally, add a gallon of water and wait for the
click indicating that the sensor has reset. With the pilot lit, press the #2 COOK button again. The rice
cooker should boil the pot dry and then shut off. If it fails to shut off normally, press the #2 COOK
button up to it’s OFF position and refer to the TROUBLE SHOOTING section on page 14 for
additional causes and remedies.
WARNING
When igniting the pilot, position the jacket window directly over #1 START and #2 COOK buttons.
Use caution when igniting pilot and maintain a safe distance from jacket window (figure 3).
SHUT DOWN
When removing the pot, make sure to push the red WARM button up until it clicks and is hidden by the #1
START button—it is then in the OFF position. A 5 minute complete shut off period is required before
lighting or relighting pilot.
LIGHTING AND SHUT DOWN INSTRUCTIONS
________________________________________________________________________
COOK
2
start button
pilot/warmer button off position
figure 1
main
burner button
jacket window
figure 3
on position
figure 2

5
Town Food Service Equipment Company, Inc. 718/388-5650 outside New York State 800/221-5032
5
RM-50/55N-R RM-50/55P-R
type of gas natural propane
BTU 34,600 27,300
gas connection 3⁄4” NPT 3⁄4” NPT
liquid capacity 24 qts. 24 qts.
unit size 22” (depth) x 17” (height) 22” (depth) x 17” (height)
net weight 43 lbs. 43 lbs.
carton size 21” x 21” x 18” 21” x 21” x 18”
master carton 1 unit (4.4 cu. ft.) 1 unit (4.4 cu. ft.)
shipping weight 46 lbs. 46 lbs.
color RM-50N: red base, RM-50P: red base
RM-55N: gray base RM-55P: gray base
capacity raw rice:18 lbs. (55 6 oz. cups*) raw rice:18 lbs. (55 6 oz. cups*)
cooked rice: 43 lbs. (110 6 oz. cups*) cooked rice: 43 lbs. (110 6 oz. cups*)
*Asian standard measurement of 6 oz., opposed to an 8oz. cup
SPECIFICATIONS, DIMENSIONS, AND GAS INPUT INFORMATION
________________________________________________________________________
PARTS LIST
________________________________________________________________________
for parts breakdown, see page 6

6
Town Food Service Equipment Company, Inc. 718/388-5650 outside New York State 800/221-5032
NUMBER PART NUMBER DESCRIPTON
1____________ 56881_______________cover handle, heat resistant
2____________ 56882_______________stainless steel rice pot cover with handle
3____________ 56881-S _____________cover handle screw
4____________ 56853_______________cast iron aluminum rice pot
5____________ 56855_______________encased sensing element, bimetalic
6____________ 56856_______________sensing element retaining spring
5/6 __________ 56854_______________sensing element kit
7____________ 56884_______________outer jacket for RM-50
7____________ 56884A _____________outer jacket for RM-55
8____________ 56885A _____________RM-55 stainless steel base cover (56885 for RM-50)
9____________ 56852-1 _____________lower body for RM-50 (red)
9____________ 56852-1A____________lower body for RM-55 (grey)
10 ___________ 56866_______________control panel frame
11 ___________ 56863_______________non-mar feet
12 ___________ 56852-2 _____________cast iron burner
13 ___________ 56878_______________pilot with retaining plate
14 ___________ 56857_______________shut off stem assembly
15 ___________ 56852-3 _____________burner assembly base
16 ___________ 56857-1 _____________burner ignition arm release
17 ___________ 56867_______________burner ignition arm
18 ___________ 56864-1 _____________pilot ignition arm
19 ___________ 56864-2 _____________ignition arm shaft
20 ___________ 56862-2 _____________burner ignition arm limiter
21 ___________ 56870_______________piezo ignition assembly
22 ___________ 56870-1 _____________ignition lever assembly
23 ___________ 56865_______________no.1 start button
24 ___________ 56864_______________red pilot warmer button
25 ___________ 56862_______________no.2 main burner button
26 ___________ 56852-4 _____________air shutter
27 ___________ 56852-4S ____________air shutter spring
28 ___________ 56868_______________main burner orifice, natural gas (.475mm/#77 drill)
28 ___________ 56869_______________main burner orifice, propane gas (.343mm/#80 drill)
29 ___________ 56860_______________on/off gas valve
30 ___________ 56861_______________gas valve knob
31 ___________ 56879_______________pilot orifice, natural gas
31 ___________ 56880_______________pilot orifice, propane gas
32 ___________ 56874-1 _____________ignition line retaining plate
33 ___________ 56872_______________pilot orifice retaining plate
34 ___________ 56874_______________pilot ignition line, natural gas
34 ___________ 56873_______________pilot ignition line, propane gas
35 ___________ 56871-1 _____________ceramic electrode clamp
36 ___________ 56870-2 _____________ceramic electrode holder
37 ___________ 56871_______________ceramic electrode
38 ___________ 56875_______________manifold assembly, natural gas
38 ___________ 56876_______________manifold assembly, propane gas
RM-55N-REG _________¾” pressure regulator, natural gas
RM-55P-REG __________¾” pressure regulator, propane gas
39 ___________ 56861-B _____________brass connecting fitting (older models)
PARTS LIST
________________________________________________________________________

7
Town Food Service Equipment Company, Inc. 718/388-5650 outside New York State 800/221-5032
72 Beadel Street Brooklyn, NY 11222
718/ 388-5650 outside New York State 800/ 221-5032 facsimile 718/ 388-5860
www.townfood.com
Automatic Gas Rice Cooker Owner’s Manual
RM-55N-R (NATURAL GAS) |RM-55P-R (PROPANE GAS) NSF AND ETL CERTIFIED
RM-50N-R (NATURAL GAS) |RM-50P-R (PROPANE GAS) NOT CERTIFIED
SECTION 2 OPERATING AND MAINTENANCE INSTRUCTIONS
Warning
Improper installation, adjustment, alteration, service or maintenance can cause property damage,
injury or death.
Read the installation, operating and maintenance instructions thoroughly before installing or servicing
this equipment.
For Your Safety
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
Important
Contact your local gas supplier if you smell gas near this equipment.
FOR COMMERCIAL USE ONLY
Do not DiscarD instructions. this manual must remain with the unit for future reference.
this emergency information must be prominently DisplayeD.

8
Town Food Service Equipment Company, Inc. 718/388-5650 outside New York State 800/221-5032
1) Make sure the unit is properly assembled with burner base, cover, outer jacket, rice pot and cover in
the proper positions. The rice in the pot should be prepared by the methods described on page 10.
If the components are not properly positioned, the unit will not operate normally.
2) Turn gas valve to ON position (figure 2). Position the jacket window directly over #1 START and
#2 COOK buttons.
3) Push the left button marked #1 START down and wait for a click, then release it. This is the ignition
lever and the pilot should light. The red button marked WARM controls the pilot and is hidden by the
#1 START button when off. Pushing the #1 START button engages and exposes the WARM button. It will
stay down until pushed up to extinguish the pilot. If the pilot does not lit, repeat. If the pilot continues
to light, see TROUBLE SHOOTING on page 14.
4) After the pilot has lit, push the #2 COOK main burner control button to ignite the main burner and start
cooking. The cook cycle takes approximately 22 minutes. When the cook button turns to the OFF
position, allow the rice to remain undisturbed for an additional 10 minutes to cure. The curing time
allows the rice to become fluffy and improves taste.
WARNING
When igniting the pilot, position the jacket window directly over #1 START and #2 COOK buttons.
Use caution when igniting pilot and maintain a safe distance from the jacket window (figure 3).
OPERATING INSTRUCTIONS
_______________________________________________________________________
COOK
START 2
1
WARM
start button
pilot/warmer button
off position
on position
figure 1
figure 2
figure 3
main burner button
jacket window

Town Food Service Equipment Company, Inc. 718/388-5650 outside New York State 800/221-5032
RM-55N-R RM-55P-R RM-50N-R RM-50P-R
9
HOW TO USE YOUR RICE COOKER
________________________________________________________________________
ASSEMBLY AND COOKING
Step 1
Place the rice pot with rice and water in the outer jacket. The rice pot must be level and sit evenly in the jacket.
Step 2
Place the lid on the rice pot and light the burner. To light the burner, refer to OPERATING INSTRUCTIONS
on page 8. Do not open the lid while cooking. When cooking is finished, the #COOK 2 button will pop
up and the main burner will automatically shut off. Do not serve the rice yet– refer to RICE COOKING TIPS
on page 10, for information on curing rice. The pilot keeps cooked rice hot (about 160˚F/71˚C) for 2 hours.
Step 3
Shut pilot off by pushing up the red KEEP WARM button. Refer to the LIGHTING AND SHUT DOWN
INSTRUCTIONS on page 4 for additional information
See the SHUT DOWN portion of the OPERATING INSTRUCTIONS on page 4.
SEASONING THE RICE POT
A new rice pot should be carefully seasoned once before use. Wash rice in the rice pot with tap water.
Remove the rice, from milky liquid and replace with fresh water and light the pilot to begin the cooking
process. Using tap water to season the pot may cause discoloration but will effect neither the unit nor the
cooked rice.
VISUAL BURNER CHECK
When operating, burner flame should be light blue in color and should have no yellow tips or lifting from
the burner. The air/gas mixture can be adjusted by moving the air shutter arm under the unit below the
main gas valve.
stainless steel base cover
base with components
outer jacket
rice pot
The misalignment or improper setting as pictured below will
cause the main burner to shut off prematurely.

10
Town Food Service Equipment Company, Inc. 718/388-5650 outside New York State 800/221-5032
• Measurericewiththemeasuringcup*.Theunitwillcookaminimumof2-3fullmeasuringcups*
of dry rice. Uncooked rice volume doubles after cooking.
• Determinethequantityofricetobecooked.Theamountofriceshouldbeenoughtocompletelycover
the bottom of the pot. The maximum is 10 full measuring cups*. Place the rice in the pot and wash
4 or 5 times with fresh water. When water is almost clear and drain rice.
• Coverthericewith1”ofwater.Analternatemethodistogentlyplaceone’s hand on the rice.
Add enough water to reach the center of the knuckles where the fingers join the hand.
• Coverricepotwithstainlesssteelcover*.Checktobesurethatthepotisproperlypositionedon
the cooker and that the water level is of uniform depth covering the rice. For tender rice, let it soak
in pot for about 10 minutes before igniting main burner.
*supplied with unit
RICE COOKING TIPS
• Whencookingahalfpotofrice,turngasvalvetothefullON position, taking note of flame on burner.
Turn gas valve slightly towards OFF position until flame is reduced by half.
• Lengthofcookingtimewillvaryaccordingtotypeofgasused,gaspressuretoburner,andquantityof
rice being cooked.
• Whenmainburnerautomaticallyshutsoff,thericeshouldbebrokenuporturnedusingautensilthat
will not damage the pot. Cover the rice and wait 10 to15 minutes allowing the rice to cure before
serving. Rice will remain hot (about 160˚F/71˚C) for 2 hours.
• ThericepotisdesignedforuseintheRM-55N-R,RM55P-R,RM-50N-RandRM-50-P-Ronly.Donotput
the pot on any other heat source— it will damage the thermostatic element and will not operate properly.
• KeepthePiezoelectricignitioncleananddrybywipingwithadrycloth.Donotpresstheignitionwhile
touching electrode—electric shock will result. If lighter fails to spark, check that it is clean, dry, and that
the black neoprene line from the ignition assembly is connected. Call your dealer or gas service for
assistance if the unit continues to malfunction.
• Cookerbaseconnectedtogassupplymaybecleanedwithadampclothandmildsoapordetergent.
Never immerse the unit into water. Be careful to not strain gas connection as this will damage the
manifold and could be very dangerous, resulting in a gas leak.
• Ricepot,cover,andenamelbodymayberemovedforcleaning.Thesepartsshouldbecleaned
and carefully reassembled to prevent damage to the unprotected cooking sensor. Do not force these
parts to fit—they assemble easily if properly positioned. Refer to the illustrations on page 9 of the
ASSEMBLY AND COOKING section.
• Afterunitiscleanedandassembled,leaveallgasvalvesinOFF position, rice pot centered and resting
evenly on enamel outer body of unit.
RICE PREPARATION
___________________________________________________________________________
CARE AND MAINTENANCE
__________________________________________________________________________

Town Food Service Equipment Company, Inc. 718/388-5650 outside New York State 800/221-5032
RM-55N-R RM-55P-R RM-50N-R RM-50P-R
11
Vicente’s Mexican Rice
___________________________________________________________________________________________
30 servings
INGREDIENTS
4 ounces peanut oil
6 cups long grain rice
6 cups water
3 cups beef stock
salt and freshly ground pepper to taste
crushed chilies to taste
generous pinch of saffron
3 large tomatoes, peeled, seeded and chopped
4 garlic cloves
1 red bell pepper, diced
1 onion, peeled and chopped
DIRECTIONS
Place peanut oil and rice into rice pot.
Press the ON button and then the #1 COOK button.
Stir rice in peanut oil approximately every minute until COOK light goes off.
Pour the 6 cups of water and remaining ingredients into the rice.
Stir thoroughly and cover with lid.
Set timer for 30 minutes to soak the rice.
After 30 minutes stir thoroughly. Push the #1 COOK button.
When the COOK light goes off the HOLD light will come on. Allow the seasoned rice to cure for 10
to15 additional minutes.
Rice is now ready to serve.
Buen provecho!

12
Town Food Service Equipment Company, Inc. 718/388-5650 outside New York State 800/221-5032
*Recipe compliments of Maria Asuncion Aquirre de King,
Dim Sum King, Veracruz, Mexico.
Maria’s Mexican Rice*
_____________________________________________________________________________________________
30 servings
DIRECTIONS
Push the #1 START button to light the pilot. Verify ignition of the pilot through the jacket window.
Push the #2 COOK button and light the main burner. Verify ignition of the main burner through the jacket
window. Add a sufficient amount of oil to cover the bottom of the rice pot. Allow the oil to heat.
The sensor in the bottom of the pot is designed to turn the rice cooker off when it senses there is no water
remaining in the pot. The oil in the bottom of the pot is being heated by the burner and will exceed the
temperature of boiling water. At this point the sensor will make a click sound and pop into its expanded
position as the temperature of boiling water has been exceeded. This causes the #2 COOK button to jump
to the OFF position and the burner will shut off.
Mexican Rice is fried before liquids are added. The oil must be at frying temperature, about 375ºF. To
do this, push the COOK-2 button once again to continue heating the oil. BEWARE the automatic shut off
feature of the sensor is now disabled and the unit will not shut off automatically. To turn off the main burner
lift the #2 COOK button.
Heat the oil to frying temperature. Add grains of rice to test the temperature of the oil. When the test
grains of rice sizzle and turn white, add the remaining rice. Fry the rice by allowing it to cook for 30
seconds, and mix thoroughly. Let it fry for an additional 30 seconds and mix again. Repeat this process
until the rice begins to ‘cashew’or have a light brown color, about 7-10 minutes.
After the rice has started to change color, add the garlic and stir for 1 more minute. At this point wearing
a heat resistant mitt is imperative as the pot is very hot and the liquids about to be added will vaporize
quickly and can scald the skin. Stir in crushed tomatoes and fry for one more minute. Turn off the burner
by raising the #2 COOK button to its OFF position. Add the remaining of the ingredients and mix.
About 4-5 minutes after turning off the main burner, listen for a click indicating that the sensor has reset to
its original state restoring the automatic capabilities.
Relight the main burner by pushing down the #2 COOK button. Verify ignition through the jacket window.
The unit will now cook the rice and automatically shut off when the rice is done—about 15 minutes.
When the unit shuts off, allow the rice to cure undisturbed in the rice cooker for 10 minutes.
Mix and serve.
NOTES
Consistency of rice will vary depending on amount of chicken stock used. For very spicy rice add
additional jalapeños to taste. Be creative– try adding peas, corn, or finely chopped bell peppers.
Use the rice cooker to braise the chicken.
The braised chicken adds flavor to the rice when fried in the same pot. Buen provecho!
INGREDIENTS
8 oz. vegetable or peanut oil
4 quarts cooled chicken stock
3 lbs. washed rice
juice of one lemon
2-3 sprigs finely chopped cilantro
3 boneless chicken breasts, precooked and cubed
2 cloves garlic, smashed, finely chopped
3 tablespoons salt
1 28 oz. can crushed tomatoes
2 finely chopped jalapeños

13
Town Food Service Equipment Company, Inc. 718/388-5650 outside New York State 800/221-5032
If rice cooker is not working properly, perform the following diagnostic tests:
1) With the pilot lit and an empty rice pot in the cooker, start the main burner. Expect to hear a click after
3 minutes and 15 seconds. The click is the sound of the sensor reaching shut off temperature. If the
main burner does not shut off, refer to difficulty item below: main burner does not shut off automatically.
2) If the main burner shuts off, the sensor is working. Pour a gallon of water into the rice pot and listen for
the click of the sensor returning to its cooking position. After the pilot is lit, start the main burner
and cover the rice pot. If the cooker shuts off within 20 minutes, remove the cover and allow the water
to evaporate. If the cooker shuts off after the water has evaporated, the unit is working normally.
Contact Town Food with any questions about the operation of the unit.
If the cooker shuts off too soon, never press the cook button a second time. The rice will burn.
The sensor has activated and must cool to be reset.
DIFFICULTY CAUSE REMEDY
main burner shuts off insufficient water to cook rice cook with proper amounts of water
before rice is done,
pilot remains lit base cover and rice pot position base cover, rice pot an outer
and/or outer jacket are not jacket correctly according to diagram
correctly positioned on page 9
rice cooker shuts off too soon overall height of shut off stem replace shut off stem assembly or remove
assembly is too tall any washers from existing shut off stem
assembly (see figure 1, page 13)
main burner does not shut off stem tip is worn replace tip according to figure 1, page 13
shut off automatically
sensing element fails replace sensing element according to
figure 2, page 13
pilot will not light spillage on pilot clean or replace main pilot burner
ceramic electrode disconnected reconnect Piezo ignition to ceramic
from Piezo ignition assembly electrode
pilot ignition line will not ignite be sure orifice is clean and positioned
properly in ceramic electrode holder
insufficient pilot insufficient gas pressure check gas pressure
burner flame
ensure all gas valves are open
contact gas supplier if problem persists
main pilot orifice is blocked clean or replace main orifice
TROUBLE SHOOTING
____________________________________________________________________________

Town Food Service Equipment Company, Inc. 718/388-5650 outside New York State 800/221-5032
RM-55N-R RM-55P-R RM-50N-R RM-50P-R
14
tip
circular
metal disc
washers
DIFFICULTY CAUSE REMEDY
yellow main burner flame unit connected to incorrect check rating plate to confirm unit
type of gas is connected to the correct type of gas
black soot collects on air shutter is closed adjust/open air shutter
bottom of rice pot
flame lifts off main burner spillage on main burner or clean or replace main burner
blockage inside main burner
spillage on main burner clean or replace main burner
excessive air adjust/close air shutter
boiling over too much water cook with proper amount of water, and
refer to RICE PREPARATION on page 10
pot interior turns gray rice pot hasn’t been cleaned thoroughly wash and dry pot
for an extended period of time
pot is discolored by boiling water discoloration will not harm rice pot or
rice but may turn gray
Units requiring warranty service must be returned to Town Food Service Equipment Co., Inc. for repair.
See GAS COOKER LIMITED WARRANTY on page 15. Call Town at 718/388-5650 with model and serial
number and request authorization to return for warranty repair number (RGA #). Non warranty parts are
also available by contacting Town.
TROUBLE SHOOTING
____________________________________________________________________________
1. Remove rice pot.
2. Locate shut off stem in center of burner.
3. Unscrew stem tip.
4. Remove lightweight washers (about 1⁄8” thick) under tip.
5. Reinstall tip.
6. Ensure spring returns to the top of its travel.
figure 1
shut off stem assembly
figure 2
replacing sensing element
1. Remove and invert rice pot. 3. Replace sensing element. 4. Reinstall retaining ring.
2. Remove retaining ring. IMPORTANT concave
side of sensing element
must be exposed
sensing element retaining ring
retaining ring
sensing element
sensing element
If rice cooker shuts off too soon, remove any washers above or below perforated circular metal disc below.
If main burner does not shut off automatically the encased sensor may have to be replaced as pictured below.

Town Food Service Equipment Company, Inc. 718/388-5650 outside New York State 800/221-5032
RM-55N-R RM-55P-R RM-50N-R RM-50P-R
15
GAS RICE COOKER LIMITED WARRANTY
Town Food Service Equipment Co., Inc. (Town) warrants its rice cookers to be free of defects in
materials and workmanship, subject to the terms specified below. This warranty is limited to parts replace-
ment and does not include any labor allowance. Any service charges or charges for parts replacement is
the customer’s responsibility.
Town warrants gas RiceMasters to be free of defects in materials or workmanship for a period of 6
months. The warranty period for all electric and gas rice cookers shall commence at the the time of
shipment from Town. The warranty period may be extended, at Town’s discretion, if proof of installation
(specifying model and serial number) was at a later date, but in no case shall warranty be extended
beyond 9 months after date of shipment from Town.
Parts and labor are covered for the warranty period for properly packaged units returned to Town
prepaid. Town cannot be responsible for shipping damages to any unit returned with improper
packaging. Parts that have failed due to defective materials or workmanship will be replaced at no
charge. Units repaired under warranty will be returned freight prepaid. Warranty for the new parts will
be for the remainder of the original warranty period. Freight will be added to the invoice for non-warranty
repairs. There will be no credit for defective units returned.
Customers are requested to clean units before returning them for service. Units returned in abused or
unsanitary condition will not be serviced without the customer’s consent to pay an appropriate labor
charge for labor to clean and repair the rice cooker. If the customer does not agree, the unit will be
returned without cleaning or repair. This warranty does not cover any failures or operating difficulties due
to accident, abuse, misuse, alteration, misapplication, improper installation or improper maintenance or
service. Town does not authorize any person or company to assume on it’s behalf any obligation or
liability in connection with this unit in any manner whatsoever. If warranty service becomes necessary,
bring the unit to the dealer where the rice cooker was purchased. Request that it be carefully packed.
Be sure to insulate the enamel jacket from the rice pot. If the pot is allowed to contact the enamel jacket
during shipment it will become chipped. If the base is not properly packed it may become dented. Town
will charge for repairs to units returned and damaged due to abuse for any reason. The returning agency
is entitled to request from the purchaser the costs of shipping and handling charges to return the unit. Be-
fore any unit is returned, call Town at 718/388-5650 and request a Return Goods Authorization (RGA).
Be advised this RGA is only authorization to return the unit for evaluation. No credit of any kind may be
taken arising from an RGA. Unit will be inspected to verify the difficulty for which it was returned. Once
the difficulty is verified, it will be repaired and the unit returned at no charge if due to faulty materials
and/or workmanship. If defective for any other reason, the unit will be repaired and the customer will be
charged for the cost of the labor and materials for the repair plus return delivery costs.
If unit must be returned to Town, carefully pack (preferably in the original carton), send prepaid,
adequately insured, and with the RGA clearly marked on the outside of the package.

RECORD OF OWNERSHIP
For your records, please record the following information. It will be required in the event service is required.
Date of purchase___________Model __________Serial Number_________Gas Type____________
Dealer ___________________________________________ Dealer Phone Number ________________
72 Beadel Street Brooklyn, NY 11222
718/ 388-5650 outside New York State 800/ 221-5032 facsimile 718/ 388-5860
www.townfood.com
