Riff TL MLV 2 User manual

RiFF TL MLV 2 Diving Light
PRODUCT SPECIFICATIONS
◆Model: TL MLV 2 multi unction underwater photographing Light
◆Bulb: White CREE XM-L2 U2 LED *4 (max 2600 Lumens); Red CREE XP-E N3 LED*2;
Purple 6565 LED*2; UV LED*2
◆Switch 1: White high> White low> Strobe> O
Switch 2: Red> Purple> UV> o
◆Runtime: White high: 72 min, Red/Purple/UV: 300 min
◆Re lector: no hotspot design, no re lector
◆Lens: 4mm Polycarbonate Board
◆Body material: Durable aircra t-grade aluminum
◆Angle o light beam: ca. 120°
◆Sur ace treatment: Premium Type III hard-anodizing
◆Color: Black
◆Battery: 32650 Li- ion Battery *1
◆With battery over-discharging protection, polarity reversing protection
◆Operation voltage: 2.8V to 4.5V.
◆Waterproo : 100 meters underwater
◆Dimensions: ca. 145 mm (length) *50mm (dia. o head).
◆Impact resistance: 1.5 M
◆Weight: ca. 332 g (without Battery); ca. 470 g (with Battery)
◆Underwater Weight: ca. 250 g (with Battery)
LOW BATTERY WARNING:
Flash 3 times i the battery voltage is less than 10%; that will repeat a ter 5 seconds, and then
switch to lower brightness; it will switch o when the voltage is less than 5%.

BATTERY INSTALLATION
1. Remove the tail by turning counter-clockwise.
2. Remove used battery and replace with resh battery as shown by the polarity stickers.
3. Mount the tail by turning clockwise.
BATTERY CHARGING
1. Plug the charger in the wall power socket. The indicator light is green in the ree-load status.
2. Put the battery in the slot o the charger.
3. The indicator light is red i the battery is not ully charged; it will turn green a ter battery ully
charged.
4. Take out the ully charged battery and use them in the diving light.
ON/OFF
Push switch to turn it on or o .
MODES CHANGING
1. Successively push the switch 1 ON-OFF within two seconds to cycle through High, Low,
Strobe (white light), O ;
2. Successively push the switch 2 ON-OFF within two seconds to cycle through Red, Purple, UV
Light, O .
SCUBA DIVING APPLICATION
Check closely or cuts, scratches, or an otherwise damaged o-ring or lens sur ace, as this can
cause lood under pressure. Remove any salt deposits, sand, dirt, or other oreign matter rom
the o-ring sealing sur aces.
KEEP THE THREADS, O-RING GROOVE LUBRICATED WITH SILICONE GREASE.
CAUTION
I the light is not to be used or some time, remove the battery to prevent possible leakage or
corrosion. Please remove the battery during transportation to prevent it rom mis-operation.
I the switch gets stuck, please put some washing-up liquid in the slot o the switch and push the
switch back and orward several times till it move smoothly again, then clean the light with resh
water.
WARRANTY RETURN POLICY
Please contact your local distributor or retailer or in ormation on how to handle your warranty
items.
