Risco RVCM52E User manual

Bullet Outdoor IP Camera
Model: RVCM52E
Installation Guide

Safety Precautions
These instructions are intended to ensure that the user can use the product correctly to
avoid danger or property loss.
WARNINGS:
Installation or usage of this product that is not in accordance with the intended
use as defined by the supplier and as described in the instructional materials
can result in damage, injury, or death.
Make sure this product is not accessible by children and those for whom
operation of the system is not intended.
All installation and operation should conform to your local electrical safety
codes. The power shall conform to the re uirement in the SELV (Safety Extra
Low Voltage) and the Limited power source is rated 12V DC in the IEC60950-1.
If the device is permanently connected to an electrical power supply, then the
connection should include an easily-accessible disconnection device, such as a
circuit breaker. Do not connect the two power supplying sources to the device
at the same time; it may result in device damage!
Do not ever attempt to repair your device by yourself, as doing so could result
in damage, injury or death – always contact your installer / supplier agent for
service.
CAUTIONS:
Make sure the power supply voltage is correct before using the camera.
Do not drop the camera or subject it to physical shock.
Do not touch sensor modules with fingers. If cleaning is necessary, use a clean
cloth with a bit of ethanol and wipe it gently.
Do not aim the camera lens at the strong light such as sun or incandescent
lamp. The strong light can cause fatal damage to the camera.
The sensor may be burned out by a laser beam, so when any laser e uipment is
being used, make sure that the surface of the sensor not be exposed to the laser
beam.
Do not place the camera in extremely hot, cold temperatures (the operating
temperature should be between -10°C ~ +50°C).
To avoid heat accumulation, good ventilation is re uired for a proper operating
environment.
While shipping, the camera should be packed in its original packing.
NOTE:
We assume no liability or responsibility for all the fires or electrical shock caused by
improper handling or installation. We are not liable for any problems caused by
unauthorized modification or attempted repair.

1
Contents
Safety Precautions ......................................................................................................... 2
Introduction..................................................................................................................... 2
Features...................................................................................................................... 2
Components and Accessories .................................................................................... 2
IP Camera Components and Dimensions..................................................................... 3
IP Camera Mounting and Installation............................................................................ 4
Mounting the IP Camera ............................................................................................. 4
Powering-up the IP Camera........................................................................................ 6
Connecting the IP Camera to the Network.................................................................. 6
Connecting to a LAN Network ................................................................................. 6
IP Cameras and the RISCO Cloud Installer Application.............................................. 7
Defining IP Camera Settings....................................................................................... 7
Defining Camera Trigger Settings............................................................................. 10
Troubleshooting ........................................................................................................... 13
Internet Configuration/UPnP Client Error .................................................................. 13
Product Specification................................................................................................... 17
Performance ............................................................................................................. 17
NOTES ........................................................................................................................... 19
RISCO Group Limited Warranty .................................................................................. 20
Contacting your Installer / Supplier-Agent................................................................. 21
Contacting RISCO Group............................................................................................. 22

2
Introduction
RISCO Group presents VUpoint, a revolutionary live video verification solution
which seamlessly integrates I Cameras within RISCO’s professional security
systems. owered by the RISCO Cloud (RISCO Application Server), VUpoint
provides an unprecedented level of security and live video monitoring
capabilities to monitoring stations and end-users alike. The RISCO bullet outdoor
I Camera is an important part of this solution and
is easily controlled through
RISCO’s intuitive Web and Smartphone applications.
Features
•lug & lay installation
•1.3” Megapixel
•Color HD
•Day/Night
•IR LED Length 10m
Components and Accessories
RISCO I camera and
mounting bracket:
Electrical power adapter and
installation accessories bag:
Installation guide:

3
IP Camera Components and Dimensions
Figure 1 IP Camera Components
Label Port Name Function Connector Description
1 LAN Network port Ethernet
port
Connects to standard Ethernet
cable
2 DC12V rt Power input port Power
port
Input DC 12V power
Figure 2 IP Camera Dimensions

4
IP Camera Mounting and Installation
After reading the installation instructions and before installing your IP camera,
prepare a plan for mounting the IP camera at your protected site. Correct
placement of your IP camera is crucial for optimal security-monitoring
performance. First, determine which areas need to be protected and then map
out the most optimal areas for installing your IP camera.
IMPORTANT! – Please make a record of the AC
address located on the box or on the back cover of
the IP camera before installation. You may need it
during the network connection stage.
Mounting the IP Camera
The IP camera support two mounting options; ceiling and wall mount (see Figure
3, below).
Figure 3 Ceiling / Wall Mount
IMPORTANT- Please make sure the installation surface can support at least 3
times the weight of the camera and the bracket.
MAC address

5
Step Description
1 Place the installation positioning template on the installation surface such as
ceiling or wall.
2 Make holes in the installation surface according to the installation positioning
template.
3 Insert the expansion bolts from the accessories bag into the holes you just made.
4 Position the IP camera base over the holes
5 Use the screws from the accessories bag to secure the IP camera firmly.
6 Loosen the adjusting screw and rotate the IP camera to the correct surveillance
position according to your actual re uirements.
7 Secure the adjusting screw to fix the IP camera.
Figure 4 IP Camera Adjustment

6
Powering-up the IP Camera
Connect the camera power adapter to an electrical outlet.
Connecting the IP Camera to the Network
The IP camera supports a LAN network connection.
Connecting to a LAN Network
Connecting the IP camera to a network using the LAN (Local Area Network)
enables easy connection and setup with compatible APs (Access Points), e.g.
gateway or router.
1. Connect the incoming network cable to the Network port on the IP camera.
2. Wait just a few minutes while the IP camera automatically connects to the
RISCO Cloud.
3. Define the IP camera settings (Refer to Defining IP Camera Settings).

7
IP Cameras and the RISCO Cloud Installer Application
The RISCO Cloud Installer Application provides an interface to your control
panel from a local or remote PC via the Web. This enables you to add IP cameras
and define camera and event alarm trigger settings.
IMPORTANT – A control panel must first be defined in RISCO Cloud in order
to accept IP cameras and define camera settings (Refer to the RISCO Cloud
Installer Application anual)
Defining IP Camera Settings
Once you have connected the IP camera to the network (refer to, Connecting the
IP Camera to the Network) you can define the camera settings.
To define IP camera se ings:
1. Log into the Installer Application using the Web page address supplied by
your service provider and enter your user name and password.
NOTE – It is recommended to use Google Chrome or ozilla Firefox to log into
the Installer Administration application.
2. Select the Control Panels List link. The Control Panels List page is displayed.
Figure 5 Control Panels List Page
3. From the Control Panels List page, select the Control Panel you wish to view.
The Control Panels Update page is displayed.

8
Figure 6 Control Panel Update Page
4. Click the Network Cameras link in the left-hand column; the IP Camera List
page is displayed.
Figure 7 IP Cameras List
5. Click Add Camera; the Add Camera dialog box is displayed.
Figure 8 Add Camera
6. Define the following fields in the Add Camera dialog box.
Field Description
Label Enter a name for the camera
Partitions Select the partition(s) from the list of defined partitions
ype Choose the RISCO camera type (for ONVIF or Generic camera type
settings, refer to the RISCO Cloud Installer Application Manual)
MAC Address Enter the MAC address into this field. The MAC address (media access
control address) is the uni ue identifier assigned to the IP camera for
communications on the physical network.
NO E: The MAC address is case sensitive and should be entered
exactly as it is shown on the box or on the back cover of the IP camera,
e.g. AA:BB:CC:DD:EE:FF

9
7. Click Add.
If an “unable to configure Internet Access”, “UPnP Client Error” or similar
message is displayed, refer to the Troubleshooting section.
8. Once the “camera is ready for use” message is displayed, click OK. The
defined IP camera is displayed in the IP Cameras page.
Figure 9 IP Camera List
NO E – You also have the option to edit or delete the selected IP camera.

10
Defining Camera Trigger Settings
Any event from the following list can be defined to trigger an alarm.
Partition Events
Fire Alarm Panic Alarm Medical Alarm Alarm
Full Arm Part Arm Disarmed Duress
Tamper 24 HR-X Alarm Water Alarm Gas Alarm
Environ. Alarm No Motion Alarm Exit Alarm Low Temperature
Detector Events
Alarm Zone Bypassed Zone Un-bypassed Zone Tamper
To define camera rigger se ings:
1. From the Control Panel Cameras page, click the Triggers tab, the Camera
Triggers List page is displayed.
Figure 10 Camera Triggers List
2. Click Add Trigger; the Add Triggers dialog box appears.
Figure 11 Add Trigger

11
3. Define the following fields in the Add Trigger dialog box:
Field Description Event ype
Label Enter a name for the camera trigger Partition and Detector events
Camera Choose a camera from the list Partition and Detector events
Event ype Choose an event type from the list Partition and Detector events
Event Choose the event from the list, e.g.
alarm, duress, etc.
Partition and Detector events
Additional fields are displayed in the Add Trigger dialog box according to the
event type that you selected (see examples below for Partition and Detector event
types).
Figure 12 Add Partition Event Trigger Figure 13 Add Detector Event Trigger
4. Define the following fields in the Add Trigger dialog box according to the
event type that you selected.
Field Description Event ype
Partition(s) Select the partition(s) from the list.
NO E – Only partitions associated with
the camera are displayed.
Partition events only
Detectors Select the detector from the list Detector events only

12
5. Define the following image (still) and clip (video) definitions:
Field Description
Images
(still)
Pre-event starting time (sec) – time, before the actual event occurred, to
start displaying still images.
Number of images – number of still images to display.
Interval between images (sec) – time re uired between each still image.
Clips
(video)
Pre-event starting time (sec) – time, before the actual event occurred, to
start displaying video clip.
Duration (sec) – total duration of the video clip
NO E – These fields are currently locked and the default parameters
cannot be changed.
6. Once finished, click Done. The defined camera trigger is displayed in the
Camera Triggers List page.
Figure 14 Camera Triggers List
NOTE – You also have the options to edit , create a duplicate , or to delete
the selected camera trigger.
IMPORTANT – No two camera triggers can be defined as identical. If a camera
trigger is duplicated, the event, camera or both definitions must be changed.

13
Troubleshooting
Internet Configuration/UPnP Client Error
Not all routers support UPnP and in some routers UPnP is disabled by default. If
you have tried configuring internet access automatically and get the message
“unable to configure Internet Access”, “UPnP Client Error” or similar, it should
possible to set your IP cameras and router up manually.
S ep1: Login in o your rou er
Use the router interface to identify the camera’s IP address. The Router Interface
can be opened using any standard web browser.
1. Enter the local IP address of the router into the web browser’s address
field. The Router Interface Login page is displayed.
2. Enter you username and password in the Login box that appears and
click OK/Login.
NOTE: For more information on how to navigate your specific router please
check the router’s User manual.
3. Navigate to the DHCP Client Table. The DHCP Client Table page is
displayed.
Figure 15 DHCP Client Table page
4. ake a note of the IP Address of the camera that you want to setup
manually.
S ep 2: Camera Se ings
Use the Camera Interface to setup the camera. The Camera Interface can also be
opened using any standard web browser.
1. Enter the IP address and the web port of the camera, for example
192.168.010.168:37080 (default web port is 37080).
NOTE – When using more than one camera the default web port shouldn’t be
the same.

14
2. Once the Camera Interface Login page is displayed, enter the User and
Password into the relevant fields and click Login.
NOTE: By Default the User and Password for camera login is “admin” and
“_AdmiN_+ camera AC address” (e.g. _AdmiN_AABBCCDDEEFF).
1. Once the Camera Interface page is displayed, select Setup > Network >
UPnP. The UPnP Parameters page is displayed.
Figure 16 UPnP Parameters
2. Uncheck the UPnP Enable option and click Save.
3. Select TCP/IP. The TCP/IP Parameters page is displayed.
Figure 17 TCP/IP Parameters
4. Select the Static ode option and enter the static IP address you want to
set for the camera (in our example 192.168.1.122). Also set the subnet
mask and Default gateway address (in our example 255.255.255.0 and
192.168.1.1).

15
NOTE: By default the TCP/IP settings should already be defined.
5. Click Save to save the changes.
6. Select Connection. The Connection Parameters page is displayed.
Figure 18 Connection Parameters
7. Set the following port connection parameters of the camera:
TCP Por Set the TCP port you want to define for the camera (in our
example 47777).
UDP Por Set the UDP port (in our example 47778)
HTTP Por The default port number is 80, and can be changed to any
port range 1024 to 65535 (in our example 10080).
RTSP Por : The default port number is 554 (in our example 47554).
HTTPS Por The default port number is 443, and can be changed to any
port range 1024 to 65535 (in our example 47443).
8. Click Save to save the changes.
9. Repeat the above steps for each camera using the relevant IP address and
alternative port number for each.
S ep 3: Rou er Por Forwarding Se ings
By default, the security features on many routers prevent access to the devices on
your home/business network from the Internet. To open a port, you need to
enable “port forwarding” on your router. Router administration screens can
vary, but typically, you would do the following to open a port:
1. Return to the Router Interface page.
NOTE: For more information on how to navigate your specific router please
check the routers User manual.

16
2. Navigate to the Advanced Setup > Port Forwarding/Port Triggering. The
Port Forwarding page is displayed.
Figure 19 Port Forwarding page (empty)
NOTE: This is the section in the router where we will specify which local IP
address belongs to which external port number. ake sure that “Port
forwarding” is enabled for each IP address.
3. For the first camera enter the settings as shown in the screenshot below.
Remember to use the same local IP address and external port numbers as
was set in the camera settings in Step 2.
Figure 20 Port Forwarding page (populated)
NOTE: For HTTP, RTSP and HTTPs Port settings use the TCP Protocol option.
4. Click Apply/Save Settings to save the changes.
5. Reboot the camera by unplugging and reconnecting the camera to the
power supply.
6. Repeat the above steps for each camera using the same local IP address
and external port numbers as was set in the camera settings.

17
Product Specification
Performance
Please refer to the following table for product performance specification.
Parameter
System
Main Processor TI Davinci high performance DSP
OS Embedded LINUX
System Resources Support real-time network monitor, local record, and remote operation at the
same time.
User Interface Remote operation interface such as WEB, DSS, PSS.
System Status Bit stream statistics, log, and software version.
Video Parameter
Image Sensor 1/3-inch CMOS
Pixel 1280(H)*960(V)
Gain Control Fixed/Auto
White Balance Manual/Auto
BLC On/Off
Exposure Mode Auto/Low noise/Low motion blur/Manual
It ranges from 1/3 to 1/100000
Video Compression
Standard H264/H.264H/MJPEG
Video Frame Rate
PAL:
Main stream(1280*960@25fps)
extra stream 1 (704*576@25fps)
extra stream 2 (1280*720@8fps)
NTSC:
Main stream(1280*960@30fps)
extra stream 1 (704*480@30fps)
extra stream 2 (1280*720@1fps)
Note: Extra stream 2 actual frame depends on device max capacity set and is
adjustable within capacity set.
Video Bit Rate
H.264H: 40Kbps-8192Kbps adjustable
MJPEG: 40Kbps-16384Kbps adjustable and bit rate is adjustable.
Support customized setup.
Video Flip Support mirror.
Support flip function.
Snapshot Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask Supports max 4 privacy mask zones
ROI Support 4 ROI
Video Setup Support parameter setup such as bright, contrast.
Video Information Channel title, time title, motion detect, camera masking.
Lens 3.6mm. Fixed focus. Angle of view: 70°(H）*51.5°(V)
Lens Interface M12. Lens is the default accessories
Record and Backup
Record Priority Manual > Video detect > Schedule
Storage
Management Support NAS storage
Network
Wire Network 1-channel wire Ethernet port, 10/100 Base-T Ethernet
Network Protocol Standard HTTP, TCP/IP, ARP, IGMP, ICMP, RTSP, RTP,UDP, RTCP, SMTP,
FTP, DHCP, DNS, DDNS, UPNP, NTP, Bonjour, SNMP, QoS, 802.1x.
Remote Operation Monitor, system setup, file download, log information, maintenance , upgrade
and etc.
IR light IR light 20-30M.

18
Parameter
General Parameter
Power
DC 12V
Warning！
Do not connect these two power supplying sources to the device at the same
time; it may result in device damage!
Power
Consumption
DC 12V
5 W MAX
Working
Temperature -20℃~+60℃
Working Humidify ≤95%
Dimensions(mm) 70*66*160
Weight 500g（Excluding box）
Installation Bracket installation
