Roadstar CD-200DABMP User manual

Service Manual - CD-200DABMP
R
CD-200DABMP
Service Manual - CD-200DABMP

BOM-E1246 DAB-CDDF1628YR/X3.20.11.4/C.LCD
MODEL STAGE PART DESC ASSEMBLY UNIT
E1246 CASING 34-00101-00 HOOK SHAFT 1
E1246 CASING 34-40201-00 PIPE 2
E1246 CASING 35-00001-00 E-RING ±1.5X4X0.4MM 1
E1246 CASING 35-01838-00 FIBRE SHEET 18X38X0.4 1
E1246 CASING 35-02922-00 O-RING ±1.6X3.5 T=0.25/PC 2
E1246 CASING 35-40005-00 HEXAGON NUT M5 1
E1246 CASING 35-50001-00 SPRING WASHER M5 1
E1246 CASING 35-B0101-00 MAIN FIBER 1
E1246 CASING 36-00102-00 RELEASE SPRING 1
E1246 CASING 36-02922-01 BKT SPRING (II) 1
E1246 CASING 36-04901-02 PANEL BKT SPRING (L) ELECTROPLATE 1
E1246 CASING 36-04902-02 PANEL BKT SPRING (R) ELECTROPLATE 1
E1246 CASING 36-06855-01 RIGHT SPRING 1
E1246 CASING 39-00104-00 RIGHT BRACKET (0.0121KG) 1
E1246 CASING 39-03210-00 IC 7805 BRACKET (0.1082KG) 1
E1246 CASING 39-04907-00 IC BRACKET (IC 7809) (0.1026KG) 1
E1246 CASING 39-04908-00 LEFT BRACKET (CD-049) (0.0068KG) 1
E1246 CASING 39-A1526-00 ANTENNA CLIP 1.0MM G.S.S (0.0023KG) 1
E1246 CASING 39-B0102-00 SPRING SHEET (0.004KG) 1
E1246 CASING 39-B1415-00 WIRE CLIP 1.0MM (0.013KG) 1
E1246 CASING 39-D0507-00 FM COVER (0.012KG) 1
E1246 CASING 39-D5606-00 DECK FRONT BKT FOR DAB1628 1
E1246 CASING 39-D5607-00 DECK REAR BKT FOR DAB1628 1
E1246 CASING 40-02603-01 SCREW ±2.6X3 BH/MS 2
E1246 CASING 40-02604-01 SCREW ±2.6X4 BH/MS 10

E1246 CASING 40-02604-03 SCREW ±2.6X4 PH/TAPTITE 4
E1246 CASING 40-02605-03 SCREW ±2.6X5 BH/TAPTITE 4
E1246 CASING 40-02606-01 SCREW ±2.6X6 BH/MS 3
E1246 CASING 40-02608-01 SCREW ±2.6X8 BH/MS 4
E1246 CASING 40-02610-01 SCREW ±2.6X10 BH/MS 1
E1246 CASING 40-02618-01 SCREW ±2.6X18 BH/MS 2
E1246 CASING 40-05018-04 SCREW ±5X18 HH 1
E1246 CASING 40-12006-20 SCREW ±2X6 PA/ST (BLACK) 6
E1246 CASING 40-60203-20 CAMERA SCREW M2X3 P/H (BLACK) 6
E1246 CASING 43-12603-02 COVER PLATE (73X27X0.38) 1
E1246 CASING 43-A3101-00 CD WINDOWS SHEET 1
E1246 CASING 51-16228-80 RING (+SPY SIL) 1
E1246 CASING 51-H6228-00 BASE W/O RESET DAB-162 1
E1246 CASING 52-04937-00 CD BACK LIGHT (PC) 1
E1246 CASING 52-04938-00 SPRING BKT (PC) 1
E1246 CASING 52-10564-00 OPEN ADAPTOR 1
E1246 CASING 52-40235-00 GIB (POM) 2
E1246 CASING 52-40236-00 HOOK (POM) 1
E1246 CASING 52-40237-00 GEAR 1 (POM) 1
E1246 CASING 52-40238-00 GEAR 2 (POM) 1
E1246 CASING 52-A1235-00 SOCK BKT (18PIN) 1
E1246 CASING 52-A1236-00 SPRING BKT 1
E1246 CASING 61-D5603-00 HEAT SINK (DAB/WIRE) 1
E1246 CASING 61-D5608-00 TOP CAB (DAB156) 1
E1246 CASING 61-D5613-00 BOT CAB FOR DAB 1628 (WIRE) 1
E1246 CASING 61-D5614-00 REAR BKT FOR DAB1628 (WIRE) 1
E1246 CASING 61-H6201-00 PANEL BKT (18PIN) (0.123KG) 1
E1246 CASING 81-02020-00 RUBBER PAD 20X20X4MM (BLACK) 1
E1246 CASING 81-02921-00 BKT SPONGE 2

E1246 CASING 81-69005-02 SHADE 1
E1246 CASING 93-40201-00 DAMPER GEAR-ASS'Y 1
E1246 CASING2 35-A7304-00 LCD FIBER 1
E1246 CASING2 36-00101-00 OPEN KNOB SPRING 1
E1246 CASING2 39-H6201-00 LCD COVER (0.4MM)/BLK (0.016KG) 1
E1246 CASING2 40-12008-21 SCREW ±2X8 BA/ST BLACK 4
E1246 CASING2 43-H6202-00 SOFT PVC SHEET 0.10MM 2
E1246 CASING2 44-A7301-01 LCD FELT SHEET 1
E1246 CASING2 44-G6240-00 WHITE TRANS 0.1MM (I) 1
E1246 CASING2 44-G6241-00 WHITE TRANS 0.1MM (II) 1
E1246 CASING2 44-H6201-00 WHITE TRANS 0.1MM PC 1
E1246 CASING2 51-G6220-852 T.PANEL;X3.15.4-FD;N/RM(S.OP1202/B)W/O BRAND 1
E1246 CASING2 51-G6221-00 BOTTOM CABINET 1
E1246 CASING2 52-G6223-80 VOLUMN KNOB COVER (S.OP1202) 1
E1246 CASING2 52-G6224-81B OPEN KNOB-FD (S.OP1202/BLACK) 1
E1246 CASING2 52-G6225-82 EQ/DISP-O/PWR KNOB (L-UP) (S.OP1202) 1
E1246 CASING2 52-G6226-83 7MOD/AS-PS KNOB (L-UP) (S.OP1202) 1
E1246 CASING2 52-G6227-82 NUMBER 1/PAU-3/BND KNOB (L-UP) (S.OP1202) 1
E1246 CASING2 52-G6228-82B TRK/8-9 KNOB-COVER (S.OP1202/BLACK) 1
E1246 CASING2 52-G6229-83B PTY KNOB (S.OP1202/BLACK) 1
E1246 CASING2 52-G6230-82 NUMBER 4/SHF-6KNOB (L-UP) (S.OP1202) 1
E1246 CASING2 52-G6231-80 IR LENS (S.OP1202) 1
E1246 CASING2 52-G6232-30 VOLUMN KNOB (L-UP) (S.OP0000) 1
E1246 CASING2 52-G6233-00 ENTER KEY BACK LIGHT 1
E1246 CASING2 52-G6234-80 RESET KNOB (S.OP1202) 1
E1246 CASING2 52-G6239-01 ETECT KNOB-F (L-UP)(S.OPC0000) 1
E1246 CASING2 53-G6230-36W LENS;DAB-F1628X3.20.11 (SPY BLK/WHITE) 1
E1246 CHASSIS1 02-04148-00A DIODE 1N-4148 AT. (TAPPING) 6
E1246 CHASSIS1 03-02313-00 I.C.PT2313L 1

E1246 CHASSIS1 03-06244-002 CPU OP6244-001G RDS+CLOCK(MP3+ESP)+TBK DAB 1
E1246 CHASSIS1 03-07384-00 IC TDA7384A (4X40W) "Y" 1
E1246 CHASSIS1 05-63153-01 CHIP 0.015uF ±10% X7R 0603 SMT 2
E1246 CHASSIS1 11-16280-025 PCB D/S DAB162MB X3.22 182.4X152.4X1.6 1
E1246 CHASSIS1 13-D1561-002 (BOM:E1371) DAB1561MB (TBK TUNER)MB PART ASSEMBLY 1
E1246 CHASSIS1 25-16280-00 SMB PLUG(50 OHM)/35MM WIRE 1
E1246 CHASSIS1 25-F0093-18 18PIN SKT WITH FLEXIBLE PCB (CD093) 1
E1246 CHASSIS1 29-02001-01 TBK DAB TUNER BAND-III+L-BAND 1
E1246 CHASSIS1 32-83210-01 ANT SOCKET W/GND ±3MM L=210MM 1
E1371 CHASSIS1 01-00435-00S TR BD435S NPN TO-126 FAIRCHLD 1
E1371 CHASSIS1 01-00436-00 TR. BD436 1
E1371 CHASSIS1 01-00812-00 TR. 2SA812 5
E1371 CHASSIS1 01-03875-07 TRANSISTOR 2SC3875G 12
E1371 CHASSIS1 01-07805-00 IC-REGULATOR 78L05 2
E1371 CHASSIS1 01-08550-03 TR. 8550C TO-92-B 1
E1371 CHASSIS1 02-00062-07 E.S.D. DIODE NNCD6.2G (5PIN) 2
E1371 CHASSIS1 02-04001-00 DIODE 1N4001 3
E1371 CHASSIS1 02-04148-00A DIODE 1N-4148 AT. (TAPPING) 9
E1371 CHASSIS1 02-05401-00 DIODE 1N5401 1
E1371 CHASSIS1 02-50036-00A ZENER DIODE 3.6V 0.5W AT ±2% 1
E1371 CHASSIS1 02-50100-00A ZENER DIODE 10V 0.5W AT. TAPE ±2% 1
E1371 CHASSIS1 03-01117-00 VOLTAQE REGULATOR LD1117S 1
E1371 CHASSIS1 03-03130-00 REGULATOR PQ3RD13 1
E1371 CHASSIS1 03-04558-06 IC KIA-4558F 2
E1371 CHASSIS1 03-07035-00 IC KIA7035P 1
E1371 CHASSIS1 03-07818-00 REGULATOR LC-78L18 1
E1371 CHASSIS1 03-09257-00 IC TC9257F 1
E1371 CHASSIS1 04-00072-01H CRYSTAL 702MHZ HC-49u/S 22PF 1
E1371 CHASSIS1 05-63102-01 CHIP 1000PF ±10% X7R 0603 SMT 7

E1371 CHASSIS1 05-63103-01 CHIP 0.01uF ±10% X7R 0603 SMT 1
E1371 CHASSIS1 05-63104-01 CHIP 0.1uF ±10% X7R 0603 SMT 17
E1371 CHASSIS1 05-63105-00 CHIP CAP 105PF/25V Y5V ±20% 0603 SMT 1
E1371 CHASSIS1 05-63220-00 CHIP CAP 22PF ±5% NPO 0603 SMT 2
E1371 CHASSIS1 05-63223-01 CHIP 0.022uF ±10% X7R 0603 SMT 9
E1371 CHASSIS1 05-63224-01 CHIP 0.22uF ±10% X7R 0603 SMT 4
E1371 CHASSIS1 05-63270-00 CHIP CAP 27PF ±5% NPO 0603 SMT 1
E1371 CHASSIS1 05-63272-01 CHIP 2700PF ±10% X7R 0603 SMT 2
E1371 CHASSIS1 05-63300-00 CHIP CAP 30P ±5% NPO 0603 SMT 1
E1371 CHASSIS1 05-63474-02 CHIP CAP 0.47u ±20% X7R 063SMT 1
E1371 CHASSIS1 06-10107-01 E. CAP 100uF 10V (±5X7MM MINI) 3
E1371 CHASSIS1 06-10107-02 E.CAP.100uF 10V(6X5)SUPER MINI 7
E1371 CHASSIS1 06-10227-01 E. CAP 220uF 10V (±6MM MINI) 2
E1371 CHASSIS1 06-10476-03 E. CAP. 47uF 10V (6X5) 5
E1371 CHASSIS1 06-16106-02E E.CAP 10uF/16V (4X5MM RC3) 5
E1371 CHASSIS1 06-16107-04 E.CAP 100uF 16V (±6X5MM) 1
E1371 CHASSIS1 06-16226-02 E. CAP 22uF 16V (±5X5MM) 2
E1371 CHASSIS1 06-16338-00S E.CAP 3300uF 16V 105C1
E1371 CHASSIS1 06-16476-03 E. CAP. 47uF 16V (6X5) 2
E1371 CHASSIS1 06-50105-03 E. CAP 1uF 50V (±4X5MM) 10
E1371 CHASSIS1 06-50225-02 E. CAP. 2.2uF 50V (4X5) 11
E1371 CHASSIS1 06-50334-03 E.CAP 0.33uF 50V (±4X5MM) 2
E1371 CHASSIS1 06-50335-01 E. CAP 3.3uF 50V (±4X7MM) 1
E1371 CHASSIS1 06-50474-02E E.CAP 0.47uF/50V (4X5MM RC03) 1
E1371 CHASSIS1 06-50475-02E E.CAP 4.7uF/50V(±5X5)±20% ELNA 1
E1371 CHASSIS1 07-05010-00 RES. 1Ω(1/4)W 1
E1371 CHASSIS1 07-05022-10 RES 2.2Ω(1/2)W 1
E1371 CHASSIS1 07-05100-00 RES. 10Ω(1/4)W 2
E1371 CHASSIS1 07-63010-00 CHIP RES 1Ω±5% 0603 SMT 1

E1371 CHASSIS1 07-63022-00 CHIP RES 2.2Ω±5% 0603 1
E1371 CHASSIS1 07-63047-00 CHIP RES 4.7Ω±5% 0603 SMT 1
E1371 CHASSIS1 07-63100-00 CHIP RES 10Ω±5% 0603 SMT 3
E1371 CHASSIS1 07-63101-00 CHIP RES 100Ω±5% 0603 SMT 3
E1371 CHASSIS1 07-63102-00 CHIP RES 1KΩ±5% 0603 SMT 8
E1371 CHASSIS1 07-63103-00 CHIP RES 10KΩ±5% 0603 SMT 26
E1371 CHASSIS1 07-63104-00 CHIP RES 100KΩ±5% 0603 SMT 2
E1371 CHASSIS1 07-63105-00 CHIP RES 1MΩ±5% 0603 SMT 5
E1371 CHASSIS1 07-63152-00 CHIP RES 1.5KΩ±5% 0603 SMT 4
E1371 CHASSIS1 07-63153-00 CHIP RES 15KΩ±5% 0603 SMT 5
E1371 CHASSIS1 07-63182-00 CHIP RES 1.8K ±5% 0603 SMT 1
E1371 CHASSIS1 07-63184-00 CHIP RES 180K ±5% 0603 SMT 4
E1371 CHASSIS1 07-63220-00 CHIP RES 22Ω±5% 0603 SMT 2
E1371 CHASSIS1 07-63221-00 CHIP RES 220Ω±5% 0603 SMT 1
E1371 CHASSIS1 07-63222-00 CHIP RES 2.2KΩ±5% 0603 SMT 4
E1371 CHASSIS1 07-63223-00 CHIP RES 22KΩ±5% 0603 SMT 8
E1371 CHASSIS1 07-63224-00 CHIP RES 220KΩ±5% 0603 SMT 2
E1371 CHASSIS1 07-63330-00 CHIP RES 33Ω±5% 0603 SMT 1
E1371 CHASSIS1 07-63331-00 CHIP RES 330Ω±5% 0603 SMT 1
E1371 CHASSIS1 07-63332-00 CHIP RES 3.3KΩ±5% 0603 SMT 5
E1371 CHASSIS1 07-63334-00 CHIP RES 330KΩ0603 ±5% SMT 1
E1371 CHASSIS1 07-63393-00 CHIP RES 39K ±5% 0603 SMT 1
E1371 CHASSIS1 07-63394-00 CHIP RES 390KΩ±5% 0603 SMT 2
E1371 CHASSIS1 07-63472-00 CHIP RES 4.7KΩ±5% 0603 SMT 9
E1371 CHASSIS1 07-63473-00 CHIP RES 47KΩ±5% 0603 SMT 15
E1371 CHASSIS1 07-63512-00 CHIP RES 5.1K 1
E1371 CHASSIS1 07-63561-00 CHIP RES 560Ω±5% 0603 SMT 4
E1371 CHASSIS1 07-63563-00 CHIP RES 56KΩ±5% 0603 SMT 1
E1371 CHASSIS1 07-63622-00 CHIP RES 6.2K ±5% 0603 1

E1371 CHASSIS1 07-63752-00 CHIP RES 7.5KΩ±5% 0603 SMT 2
E1371 CHASSIS1 07-63821-00 CHIP RES 820Ω±5% 0603 SMT 4
E1371 CHASSIS1 07-63822-00 CHIP RES 8.2KΩ±5% 0603 SMT 5
E1371 CHASSIS1 07-63823-00 CHIP RES 82KΩ±5% 0603 SMT 1
E1371 CHASSIS1 09-70100-01 MICRO INDUCTOR 10UH AXIAL TYPE 1
E1371 CHASSIS1 15-27012-11J RING COIL ±27X12MM V-TYPE (JCI-1066-110uH) 1
E1371 CHASSIS1 39-01561-00 DAB RF CONNECTOR 21.0X11.0MM 1
E0403 CHASSIS2 01-03875-07 TRANSISTOR 2SC3875G 3
E0403 CHASSIS2 02-04148-00A DIODE 1N-4148 AT. (TAPPING) 1
E0403 CHASSIS2 03-06579-00 IC SAA-6579T 1
E0403 CHASSIS2 04-00433-00M C. 4.332MHZ HC-49U 30PPM 22PF 1
E0403 CHASSIS2 05-63103-01 CHIP 0.01uF ±10% X7R 0603 SMT 3
E0403 CHASSIS2 05-63223-01 CHIP 0.022uF ±10% X7R 0603 SMT 2
E0403 CHASSIS2 05-63330-00 CHIP CAP 33PF ±5% NPO 0603 SMT 2
E0403 CHASSIS2 05-63681-00 CHIP 680PF ±5% NPO 0603 SMT 1
E0403 CHASSIS2 06-16476-03 E. CAP. 47uF 16V (6X5) 1
E0403 CHASSIS2 06-50224-02 E. CAP 0.22uF 50V (±3X5MM) 1
E0403 CHASSIS2 06-50225-02 E. CAP. 2.2uF 50V (4X5) 1
E0403 CHASSIS2 07-63100-00 CHIP RES 10Ω±5% 0603 SMT 2
E0403 CHASSIS2 07-63101-00 CHIP RES 100Ω±5% 0603 SMT 2
E0403 CHASSIS2 07-63102-00 CHIP RES 1KΩ±5% 0603 SMT 2
E0403 CHASSIS2 07-63151-00 CHIP RES 150Ω±5% 0603 SMT 1
E0403 CHASSIS2 07-63331-00 CHIP RES 330Ω±5% 0603 SMT 1
E0403 CHASSIS2 07-63471-00 CHIP RES 470Ω±5% 0603 SMT 1
E1246 CHASSIS2 05-63682-01 CHIP 6800PF ±10% X7R 0603 SMT 2
E1246 CHASSIS2 07-63222-00 CHIP RES 2.2KΩ±5% 0603 SMT 1
E1246 CHASSIS2 07-63562-00 CHIP RES 5.6KΩ±5% 0603 SMT 2
E1246 CHASSIS2 22-D1561-001 (BOM:E0403) DAB-F1561X3.20 RDS PART ASSEMBLY 1
E1246 CHASSIS2 29-00347-02 MITSVMI TUNER FAE-347-A29 1

E0412 CHASSIS3 01-00812-00 TR. 2SA812 1
E0412 CHASSIS3 01-03875-07 TRANSISTOR 2SC3875G 2
E0412 CHASSIS3 02-04148-00A DIODE 1N-4148 AT. (TAPPING) 2
E0412 CHASSIS3 05-16225-00 TAN CAP 2.2uF 16V 1
E0412 CHASSIS3 05-63103-01 CHIP 0.01uF ±10% X7R 0603 SMT 1
E0412 CHASSIS3 05-63223-01 CHIP 0.022uF ±10% X7R 0603 SMT 4
E0412 CHASSIS3 06-16106-02E E.CAP 10uF/16V (4X5MM RC3) 1
E0412 CHASSIS3 07-63100-00 CHIP RES 10Ω±5% 0603 SMT 1
E0412 CHASSIS3 07-63102-00 CHIP RES 1KΩ±5% 0603 SMT 3
E0412 CHASSIS3 07-63103-00 CHIP RES 10KΩ±5% 0603 SMT 2
E0412 CHASSIS3 07-63331-00 CHIP RES 330Ω±5% 0603 SMT 1
E0412 CHASSIS3 07-63822-00 CHIP RES 8.2KΩ±5% 0603 SMT 1
E0412 CHASSIS3 09-70100-01 MICRO INDUCTOR 10UH AXIAL TYPE 1
E1246 CHASSIS3 01-03875-07 TRANSISTOR 2SC3875G 1
E1246 CHASSIS3 02-04148-00A DIODE 1N-4148 AT. (TAPPING) 1
E1246 CHASSIS3 07-63473-00 CHIP RES 47KΩ±5% 0603 SMT 1
E1246 CHASSIS3 22-D1561-002 (BOM:E0412) DAB-F1561X3.20 AM PART ASSEMBLY 1
E1114 CHASSIS4 03-75823-00 IC LC75823ED 1
E1114 CHASSIS4 05-03223-10 CHIP CAP CM21X7R223K25AT 1
E1114 CHASSIS4 05-63681-00 CHIP 680PF ±5% NPO 0603 SMT 1
E1114 CHASSIS4 07-63102-00 CHIP RES 1KΩ±5% 0603 SMT 2
E1114 CHASSIS4 07-63103-00 CHIP RES 10KΩ±5% 0603 SMT 1
E1114 CHASSIS4 07-63121-00 CHIP RES 120Ω±5% 0603 SMT 7
E1114 CHASSIS4 07-63152-00 CHIP RES 1.5KΩ±5% 0603 SMT 1
E1114 CHASSIS4 07-63153-00 CHIP RES 15KΩ±5% 0603 SMT 1
E1114 CHASSIS4 07-63181-00 CHIP RES 180Ω±5% 0603 SMT 3
E1114 CHASSIS4 07-63182-00 CHIP RES 1.8K ±5% 0603 SMT 1
E1114 CHASSIS4 07-63183-00 CHIP RES 18K ±5% 0603 SMT 1
E1114 CHASSIS4 07-63221-00 CHIP RES 220Ω±5% 0603 SMT 3

E1114 CHASSIS4 07-63222-00 CHIP RES 2.2KΩ±5% 0603 SMT 2
E1114 CHASSIS4 07-63331-00 CHIP RES 330Ω±5% 0603 SMT 1
E1114 CHASSIS4 07-63393-00 CHIP RES 39K ±5% 0603 SMT 1
E1114 CHASSIS4 07-63470-00 CHIP RES 47Ω±5% 0603 SMT 1
E1114 CHASSIS4 07-63471-00 CHIP RES 470Ω±5% 0603 SMT 2
E1114 CHASSIS4 07-63472-00 CHIP RES 4.7KΩ±5% 0603 SMT 2
E1114 CHASSIS4 07-63473-00 CHIP RES 47KΩ±5% 0603 SMT 1
E1114 CHASSIS4 07-63513-00 CHIP RES 51K ±5% 0603 SMT 1
E1114 CHASSIS4 07-63561-00 CHIP RES 560Ω±5% 0603 SMT 4
E1114 CHASSIS4 07-63681-00 CHIP RES 680Ω±5% 0603 SMT 2
E1114 CHASSIS4 07-63820-00 CHIP RES 82Ω±5% 0603 SMT 1
E1114 CHASSIS4 07-63822-00 CHIP RES 8.2KΩ±5% 0603 SMT 1
E1114 CHASSIS4 07-63823-00 CHIP RES 82KΩ±5% 0603 SMT 1
E1114 CHASSIS4 11-16280-309 CD-F1628 KB D/S 1.2X168X41.7MM 1
E1114 CHASSIS4 16-00903-00 JOG SWITCH KQU-903 L=10MM 1
E1114 CHASSIS4 16-01107-00K TACT SW.DCT/1101 4.3MM 2 PIN 13
E1114 CHASSIS4 16-01140-04A TACT SW KPS-1107SW TAPPING 1
E1114 CHASSIS4 18-00115-00 CD115 ROTRAY ENCODER VOL 1
E1114 CHASSIS4 25-M0156-18 18PIN PLUG (CD156) 1
E1246 CHASSIS4 02-01112-02F SMD LED BR1112H RED "STANLEY" 20
E1246 CHASSIS4 02-01730-09 LED B.L WHITE 109X20.5 1
E1246 CHASSIS4 22-F1628-001 (BOM:E1114) CD-F1628(X3.14~22) KB ASSEMBLY 1
E1246 CHASSIS4 27-01731-01Y CD173 LCD TN NEG COLOR PIN TYPE 1
D0400 CHASSIS8 01-00103-00 TR. KEC103S 6
D0400 CHASSIS8 01-00812-00 TR. 2SA812 1
D0400 CHASSIS8 01-01225-13 TRANSISTOR 2SD1225M 1
D0400 CHASSIS8 02-00144-00 IR LED MIE 144A1MC 2
D0400 CHASSIS8 02-04148-02 DIO CHIP RLS4148 1206 ROHM 2
D0400 CHASSIS8 02-50036-00 ZENER DIODE 3.6V ±5% 0.5W 1

D0400 CHASSIS8 02-50051-00 ZENER DIODE 5.1V ±5% 0.5W 1
D0400 CHASSIS8 02-50151-00 5.1V ZENER DIODE (SMD 1206) 1
D0400 CHASSIS8 03-09226-00 IC S1L 9226 1
D0400 CHASSIS8 03-09259-00 IC KA9259ED 1
D0400 CHASSIS8 03-09276-00 IC S5L9276X01-EORN 1
D0400 CHASSIS8 03-09291-00 IC S5L9291X01-EORO 1
D0400 CHASSIS8 03-M0404-05 IC 4X4 ORAM (MEC) M5117405B-60 1
D0400 CHASSIS8 04-00169-00 CRYSTAL HC-49/US 16.9344MHZ 1
D0400 CHASSIS8 05-16106-10 TAN CAP 10UF 16V ±10% 1206 SMD 7
D0400 CHASSIS8 05-63020-00 CHIP CAP 2PF ±5% NPO 0603 SMT 1
D0400 CHASSIS8 05-63102-01 CHIP 1000PF ±10% X7R 0603 SMT 2
D0400 CHASSIS8 05-63103-01 CHIP 0.01uF ±10% X7R 0603 SMT 9
D0400 CHASSIS8 05-63104-01 CHIP 0.1uF ±10% X7R 0603 SMT 44
D0400 CHASSIS8 05-63152-01 CHIP 1500PF ±10% X7R 0603 SMT 2
D0400 CHASSIS8 05-63153-01 CHIP 0.015uF ±10% X7R 0603 SMT 1
D0400 CHASSIS8 05-63220-00 CHIP CAP 22PF ±5% NPO 0603 SMT 1
D0400 CHASSIS8 05-63222-01 CHIP 2200PF ±10% X7R 0603 SMT 2
D0400 CHASSIS8 05-63223-01 CHIP 0.022uF ±10% X7R 0603 SMT 1
D0400 CHASSIS8 05-63330-00 CHIP CAP 33PF ±5% NPO 0603 SMT 2
D0400 CHASSIS8 05-63333-01 CHIP 0.033uF ±10% 0603 SMT 1
D0400 CHASSIS8 05-63391-00 CHIP 390PF ±5% NPO 0603 SMT 2
D0400 CHASSIS8 05-63472-01 CHIP 4700PF ±10% X7R 0603 SMT 1
D0400 CHASSIS8 05-63474-00 CHIP CAP 0.47uF Y5V +80% 3
D0400 CHASSIS8 05-63683-01 CHIP 0.068uF ±10% 0603 SMT 1
D0400 CHASSIS8 05-63821-00 CHIP 820PF ±5% 0603 SMT 1
D0400 CHASSIS8 06-16107-54 E.CAP CHIP 100u/16V ±6.3X5.5 8
D0400 CHASSIS8 06-16476-54 E.CAP CHIP 47uF/16V ±5X5.5 2
D0400 CHASSIS8 07-05047-00 RES. 4.7Ω1/4W 1
D0400 CHASSIS8 07-63000-00 CHIP RES 0Ω±5% 0603 SMT 14

D0400 CHASSIS8 07-63015-00 CHIP RES 1.5Ω±5% 0603 SMT 4
D0400 CHASSIS8 07-63100-00 CHIP RES 10Ω±5% 0603 SMT 1
D0400 CHASSIS8 07-63102-00 CHIP RES 1KΩ±5% 0603 SMT 3
D0400 CHASSIS8 07-63103-00 CHIP RES 10KΩ±5% 0603 SMT 6
D0400 CHASSIS8 07-63104-00 CHIP RES 100KΩ±5% 0603 SMT 4
D0400 CHASSIS8 07-63105-00 CHIP RES 1MΩ±5% 0603 SMT 2
D0400 CHASSIS8 07-63153-00 CHIP RES 15KΩ±5% 0603 SMT 6
D0400 CHASSIS8 07-63181-00 CHIP RES 180Ω±5% 0603 SMT 1
D0400 CHASSIS8 07-63203-00 CHIP RES 20KΩ±5% 0603 SMT 1
D0400 CHASSIS8 07-63221-00 CHIP RES 220Ω±5% 0603 SMT 1
D0400 CHASSIS8 07-63224-00 CHIP RES 220KΩ±5% 0603 SMT 4
D0400 CHASSIS8 07-63272-00 CHIP RES 2.7KΩ±5% 0603 SMT 1
D0400 CHASSIS8 07-63274-00 CHIP RES 270KΩ±5% 0603 SMT 1
D0400 CHASSIS8 07-63333-00 CHIP RES 33KΩ±5% 0603 SMT 1
D0400 CHASSIS8 07-63334-00 CHIP RES 330KΩ0603 ±5% SMT 1
D0400 CHASSIS8 07-63393-00 CHIP RES 39K ±5% 0603 SMT 2
D0400 CHASSIS8 07-63471-00 CHIP RES 470Ω±5% 0603 SMT 2
D0400 CHASSIS8 07-63472-00 CHIP RES 4.7KΩ±5% 0603 SMT 15
D0400 CHASSIS8 07-63473-00 CHIP RES 47KΩ±5% 0603 SMT 4
D0400 CHASSIS8 07-63683-00 CHIP RES 68KΩ±5% 0603 SMT 1
D0400 CHASSIS8 07-63822-00 CHIP RES 8.2KΩ±5% 0603 SMT 8
D0400 CHASSIS8 07-63823-00 CHIP RES 82KΩ±5% 0603 SMT 2
D0400 CHASSIS8 07-63913-00 CHIP RES 91KΩ±5% 0603 SMT 1
D0400 CHASSIS8 12-14311-120 PCB CDX3.20.11.4 SERVO D/S 116X79X1.2MM 1
D0400 CHASSIS8 16-00033-01 MICRO SWITCH MPU10371MLBO(MIC) 1
D0400 CHASSIS8 25-00090-03 RAINBOW WIRE 30# 3PIN 90MM 1
D0400 CHASSIS8 25-14300-16 16PIN FPC GF106-165-LS 1
D0400 CHASSIS8 25-53015-20E CD DECK 4PIN SOCKET 1
D0400 CHASSIS8 40-02004-03 SCREW ±2X4 BH TAPTITE 3

D0400 CHASSIS8 81-10006-00 DECK CABLE PAD (36X10X0.5) 2
D0400 CHASSIS8 87-00690-07 LASER CAUTION LABEL 1
D0400 CHASSIS8 87-08168-03 LASER BEAM LABEL 1
D0400 CHASSIS8 94-01683-11 CD MECHANISM CDM-1683EUK W/O BKT(143A ±1CK-U 1
E1246 CHASSIS8 01-00435-00S TR BD435S NPN TO-126 FAIRCHLD 1
E1246 CHASSIS8 01-00812-00 TR. 2SA812 2
E1246 CHASSIS8 01-03875-07 TRANSISTOR 2SC3875G 2
E1246 CHASSIS8 02-50033-00A ZENER DIODE 3.3V 0.5W AT ±2% 1
E1246 CHASSIS8 02-50091-00A ZENER DIODE 9.1V 0.5W AT ±2% 1
E1246 CHASSIS8 06-10107-01 E. CAP 100uF 10V (±5X7MM MINI) 2
E1246 CHASSIS8 06-50225-02 E. CAP. 2.2uF 50V (4X5) 2
E1246 CHASSIS8 07-63103-00 CHIP RES 10KΩ±5% 0603 SMT 4
E1246 CHASSIS8 07-63221-00 CHIP RES 220Ω±5% 0603 SMT 2
E1246 CHASSIS8 07-63222-00 CHIP RES 2.2KΩ±5% 0603 SMT 3
E1246 CHASSIS8 07-63334-00 CHIP RES 330KΩ0603 ±5% SMT 1
E1246 CHASSIS8 07-63392-00 CHIP RES 3.9KΩ±5% 0603 SMT 3
E1246 CHASSIS8 07-63472-00 CHIP RES 4.7KΩ±5% 0603 SMT 9
E1246 CHASSIS8 07-63473-00 CHIP RES 47KΩ±5% 0603 SMT 2
E1246 CHASSIS8 25-09286-21 21PIN FFC-E 1.25MM L=130MM 1
E1246 CHASSIS8 25-11101-21 21PIN FPC-H1.25 TOP CON.(NEGATIVE-NEEDLE) 1
E1246 CHASSIS8 94-14311-00 (BOM:D0400) CDX3.20.11.4 CD ASS'Y ASSEMBLY 1
E1246 CHASSISE 06-50105-03 E. CAP 1uF 50V (±4X5MM) 2
E1246 CHASSISE 07-63000-00 CHIP RES 0Ω±5% 0603 SMT 2
E1246 CHASSISE 20-20360-08 RCA CABLE WIRE 360MM GREY 1
E1246 CHASSISL 01-08050-03 TR. 8050C TO-92-B 1
E1246 CHASSISL 02-30000-02 LED ±3MM RED 1
E1246 CHASSISL 02-30553-60T P.LAMP AA 3V 60MA ±3X5.5 K.T. 1
E1246 CHASSISL 05-63104-01 CHIP 0.1uF ±10% X7R 0603 SMT 1
E1246 CHASSISL 07-05103-16 RES. 10KΩ1/16W 1

E1246 CHASSISL 07-05151-00 RES. 150Ω1/4W 1
E1246 CHASSISL 12-03201-755 PCB CD-032X2 LB 1.0MM 41X18 1
E1246 CHASSISL 16-51377-00K PUSH SW.SPPB51377A(DS-20)KONEX 1
E1246 CHASSISL 25-03060-04 RIBBON CABLE #30 4PIN 60MM 1
E1246 CHASSISL 81-10308-06 LAMP COVER ±3X8MM BLUE 1
B0492 CHASSISW 31-19360-05 19X0.14X2MM WIRE 360MM GRN 1
B0492 CHASSISW 31-19360-06 19X0.14X2MM WIRE 360MM BLUE 1
B0492 CHASSISW 31-19360-07 19X0.14X2MM WIRE 360MM PURPLE 1
B0492 CHASSISW 31-19360-08 19X0.14X2MM WIRE 360MM GREY 1
B0492 CHASSISW 31-19360-09 19X0.14X2MM WIRE 360MM WHITE 1
B0492 CHASSISW 31-19360-50 19X0.14X2MM 360MM GREEN/BLACK 1
B0492 CHASSISW 31-19360-70 19X0.14X2MM 360MM WIRE PUR/BLK 1
B0492 CHASSISW 31-19360-80 19X0.14X2MM 360MM GRY/BLACK 1
B0492 CHASSISW 31-19360-90 19X0.14X2MM 360MM WHT/BLK 1
E1246 CHASSISW 31-16360-10 16# UL 1007WIRE 360MM BLACK 1
E1246 CHASSISW 31-C1002-001 (BOM:B0492) CD1002 V.Y.Z EIA WIRE ASSEMBLY 1
E1246 CHASSISW 54-36005-02 150MM+30MM 0.5A FUSE+150MM RED 1
E1246 CHASSISW 54-36150-04 15A FUSE W/150+150MM 16# YELLO 1
B0494 PACKING 87-59305-01 '12 PLUS' SILVER/BLK 1
B0494 PACKING 87-59307-01 'GROUND' SILVER/BLK 1
B0494 PACKING 87-59308-01 'MEMORY 12V +' SILVER/BLK 1
B0494 PACKING 87-59309-01 'FRONT-R SPEAKER(+)'SILVER/BLK 1
B0494 PACKING 87-59314-01 'POWER ANTENNA' SILVER/BLK 1
B0494 PACKING 87-59317-01 'REAR-R SPEAKER(+)'SILVER/BLK 1
B0494 PACKING 87-59325-01 'FRONT-R SPEAKER(-)'SILVER/BLK 1
B0494 PACKING 87-59326-01 'REAR-R SPEAKER(-)'SILVER/BLK 1
B0494 PACKING 87-59327-01 'REAR-L SPEAKER(+)'SLIVER/BLK 1
B0494 PACKING 87-59328-01 'REAR-L SPEAKER(-)'SLIVER/BLK 1
B0494 PACKING 87-59329-01 'FRONT-L SPEAKER(+)'SLIVER/BLK 1

B0494 PACKING 87-59330-01 'FRONT-L SPEAKER(-)'SLIVER/BLK 1
E1246 PACKING 35-40005-00 HEXAGON NUT M5 1
E1246 PACKING 35-50001-00 SPRING WASHER M5 1
E1246 PACKING 35-51210-00 PLAIN WASHER M5 1
E1246 PACKING 39-00128-00 METAL BAR (197MM) (0.028KG) 1
E1246 PACKING 39-B0112-00 KEY (0.0232KG) 2
E1246 PACKING 40-05005-07 SCREW ±5X5 RH/MS 4
E1246 PACKING 40-15025-11 SCREW ±5X25 TA/ST 1
E1246 PACKING 52-32825-00 CARRYING CASE 1
E1246 PACKING 61-07211-03 MOUNTING BOX (072) 0.6MM (0.1456KG) 1
E1246 PACKING 81-06854-00 CASE SPONGE 20X30X15(BLK) W/D 2
E1246 PACKING 81-32802-00 CASE SPONGE (BLACK) 4
E1246 PACKING 83-03228-00 3228 G/B 9-1/16X3-7/8X11-1/8" 1
E1246 PACKING 84-00004-00 COLOUR TIE 4" 'BLACK' 1
E1246 PACKING 85-10065-01 POLYBAG 6.5X10" W/PE(O4) MARK 1
E1246 PACKING 85-12125-03 12X12.5 PE(O4)&LETTERING, HOLE 1
E1246 PACKING 85-32512-01 POLY BAG 3(1/4) X 12 W/PE(04)MARK 1
E1246 PACKING 85-35045-01 POLY BAG 3(1/2)X4(1/2) W/"PE(04) MARK 1
E1246 PACKING 86-03228-03 POLYFOAM (NEW) 1X2 1
E1246 PACKING 87-00410-07 0.5A FUSE LABEL WHT/BLK 1
E1246 PACKING 87-00422-10 15A FUSE LABEL WHT/BLK 1
E1246 PACKING 87-00588-04 SILVER LABEL ±23MM 1
E1246 PACKING 87-00690-05 CLASS 1 LABEL 1
E1246 PACKING 87-17300-00 QC PASSED LABEL 1
E1246 PACKING 87-59334-01 REAR RCA LABEL 1
E1246 PACKING 87-69001-00 CD DECK LOCKER CAUTION LAB (E 2
E1246 PACKING 87-R1020-02 RDS-10268V COMP LAB EIA (STD) 1
E1246 PACKING 88-C1628-20 DAB-F1628X3.(15,18~20) I/M (COMMON) 1
E1246 PACKING 89-03228-04 B=B CTN 20 X 9-3/4 X 12" 0,2

E1246 PACKING 92-C1002-002 (BOM:B0494) CD1002 VYZ WIRE LABEL ASSEMBLY 1
E1246 PACKING 99-00001-00 DESICCANT 1

EXPLODED VIEW
PANEL

EXPLODED VIEW PARTS LIST
PANEL
Ref. No. Description RS Part No. Mfr’s Part No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Lens: DAB-F1628X3.20.11 (SPY BLK/White)
T. Panel X3.15.4-FD N/RM (S. OP1202/B) W/O Brand
Bottom Cabinet
Open Knob For FD (S. OP1202/Black)
Open Knob Spring
Volume Knob Cover (S. OPC1202)
Volume Knob (L-Up) (S. OP0000)
Soft PVC Sheet 0.10MM
IR Lens (S. OP1202)
Number 1/PAU-3/BND Knob (L-Up) (S.OP1202)
Number 4/SHF-6 Knob (L-Up) (S.OP1202)
7MOD/AS-PS Knob (L-Up) (S. OP1202)
EQ/DISP-0/PWR Knob (L-Up) (S. OP1202)
Reset Knob (S. OP1202)
PTY Knob (S. OP1202/Black)
TRK/8-9 Knob Cover (S. OP1202/Black)
Enter Key Back Light +SPY White
Key Board
CD115 Rotary Encoder VOL
LCD Cover 90.4MM/BLK
CD173 LCD TN NEG Color PIN Type
LCD Felt Sheet
LED B.L White 109X20.5
Eject Knob-F (L-Up) (S. OPC0000)
Screw Ø2X8 BA/ST Black
53-G6230-36W
51-G6220-852
51-G6221-00
52-G6224-81B
36-11852-00
52-G6223-80
52-G6232-30
43-H6202-00
52-G6231-80
52-G6227-82
52-G6230-82
52-G6226-83
52-G6225-82
52-G6234-80
52-G6229-83B
52-G6228-82B
52-G6233-01
12-16280-309
18-00115-00
39-H6201-00
27-01731-01Y
44-A7301-00
02-01730-09
52-G6239-01
40-12008-21

EXPLODED VIEW
CABINET

EXPLODED VIEW PARTS LIST
CABINET
Ref. No. Description RS Part No. Mfr’s Part No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Panel
Ring (+SPY SIL)
Base W/O Reset DAB-162
Rear Bracket For DAB1628 (ISO)
CD MECH. CDM-1683EUK W/O Bracket (143A)
Heat Sink (DAB/ISO)
Top Cabinet (DAB1628)
Bottom Cabinet For DAB1628 (ISO)
Main Fiber
Main Board
Mounting Box (072)
CD Windows Sheet
Shade
Panel Bracket (18PIN)
Pipe
Bracket Spring
Gear 1 (POM)
Panel Bracket Spring (Left) Electroplate
Panel Bracket Spring (Right) Electroplate
GIB (POM)
Open Adaptor
Right Bracket
Gear 2 (POM)
Left Bracket (CD-049)
CD Back Light (PC)
Hook (POM)
Release Spring
Hook Shaft
Lamp Board
Right Spring
Spring Bracket
18PIN SKT With Flexible PCB (CD093)
Socked Bracket (18PIN)
Front Deck Bracket For DAB1628
Rear Deck Bracket For DAB1628
TBK DAB Tuner BAND-III+L –BAND
MITSVMI Tuner FAE-347-A29
FM Cover
IC 7805 Bracket
36PIN ISO Socket SW/RCA/CDC/AUX In
51-16228-80
51-H6228-00
61-D5618-00
94-01683-11
61-D5605-00
61-D5617-00
61-D5619-00
35-B0101-00
11-16280-025
61-07211-03
43-A3101-00
81-69005-02
61-H6201-00
34-40201-00
36-02922-01
52-40237-00
36-04901-02
36-04902-02
52-40235-00
52-10564-00
39-00104-00
52-40238-00
39-04908-00
52-04937-00
52-40236-00
36-00102-00
34-00101-00
12-03201-755
36-06855-01
52-A1236-00
25-F0093-18
52-A1235-00
39-D5606-00
39-D5607-00
29-02001-01
29-00347-02
39-D0507-00
39-03210-00
25-12245-36
