Robe RMS DT Series User manual

Version 1.
4

RMS-Robe Media Server
2
Table of contents
1. Safety instructions ...................................................................................................................................................... 4
2. Unpacking ................................................................................................................................................................... 5
3. ntroduction ................................................................................................................................................................ 5
4. Fixture exterior view ................................................................................................................................................... 6
5. Video inputs/outputs .................................................................................................................................................. 7
6. Connection to the mains ............................................................................................................................................ 8
6.1 Powering on the ROBE Media Server ................................................................................................................... 8
6.2 Shutting down the ROBE Media Server ................................................................................................................ 8
7. DMX 512 connection .................................................................................................................................................. 8
8. Ethernet connection ................................................................................................................................................... 9
9. Folder organization ................................................................................................................................................... 10
10. Control menu map .................................................................................................................................................. 12
11. Operating modes .................................................................................................................................................... 17
12. Control menu .......................................................................................................................................................... 17
12.1 Fixture Address ................................................................................................................................................. 17
12.2 Fixture information ........................................................................................................................................... 18
12.3 Personality ........................................................................................................................................................ 18
12.4 Manual control ................................................................................................................................................. 19
12.5 Stand-alone setting ........................................................................................................................................... 19
12.6 Preview mode. .................................................................................................................................................. 21
12.7 Reset functions ................................................................................................................................................. 21
12.8 Service menu .................................................................................................................................................... 21
12.9 Special functions ............................................................................................................................................... 21
12.10 Pixel mapping ................................................................................................................................................. 23
12.11 Fixture Off ....................................................................................................................................................... 23
13. Keystones ................................................................................................................................................................ 23
13.1 Global keystone parameters............................................................................................................................. 23
13.2 Layer keystone parameters .............................................................................................................................. 24
14. n Frame and Out Frame parameters ..................................................................................................................... 28
15. Video Control .......................................................................................................................................................... 28
16. Playback speed ...................................................................................................................................................... 29
17. Graphic effects ........................................................................................................................................................ 30
17.1 Kaleidoscopic effect .......................................................................................................................................... 30
17.2 Circular effect (Fish eye) ................................................................................................................................... 32
17.3 RGB (CMY) effects ............................................................................................................................................. 32

RMS-Robe Media Server
3
17.4 ris effect on layer ............................................................................................................................................. 37
17.5 Auto iris effect on layer .................................................................................................................................... 40
17.6 Zoom effects on layer ....................................................................................................................................... 40
17.7 Another graphic effects on layers..................................................................................................................... 41
18. Media content management .................................................................................................................................. 43
18.1 Moving files between the fixture and PC ......................................................................................................... 43
18.2 Moving files between networked fixtures ........................................................................................................ 47
19. Remote control of the fixture via WWW browser ................................................................................................. 48
20. Picture merging....................................................................................................................................................... 52
20.1 Picture merging control channels ..................................................................................................................... 52
20.2 Picture merging example .................................................................................................................................. 60
21. Pre-cut content mode for Picture Merging ........................................................................................................... 61
22. Effect video synchronization .................................................................................................................................. 63
23. Projection onto angular, cylindric or spheric surfaces ........................................................................................... 64
23.1 Curved surface support channels ..................................................................................................................... 64
23.2 Rectangle onto circle (sphere) mapping with picture merging ........................................................................ 66
24. Video processing on gobo layers from a streaming video server .......................................................................... 67
25. RDM ........................................................................................................................................................................ 74
25.1 C TP/MSEX protocol ......................................................................................................................................... 74
26. Pixel mapping.......................................................................................................................................................... 76
27. Technical specifications .......................................................................................................................................... 83
28. Maintenance ........................................................................................................................................................... 85
28.1 nstalling the DV /VGA (SD /AS ) capture card ................................................................................................ 85
28.2 Cleaning the air filter ........................................................................................................................................ 85
28.3 System restore .................................................................................................................................................. 86
28.4 Cleaning ............................................................................................................................................................ 86

RMS-Robe Media Server
4
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE POWERING OR INSTALLING YOUR ROBE MEDIA SERVER !
Save it fo futu e efe ence.
This device has left our premises in absolutely perfect condition. n order to maintain this condition and to ensure a
safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes written in
this manual.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual
or any unauthorized modification to the device.
Please consider that damages caused by manual modifications to the device are not subject to warranty.
The ROBE Media Se ve was designed fo indoo use and it is intended fo p ofessional application only.It is not
fo household use.
1. Safety instructions
DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT!
Make sure that the available voltage is not higher than stated on the rear panel of the fixture.
This fixture should be operated only from the type of power source indicated on the marking label. f you are not
sure of the type of power supplied, consult your authorized distributor or local power company.
Always disconnect the fixture from AC power before cleaning, removing or installing the fuses, or any part.
Make sure that the power switch is set to off-position before you connect the fixture to the mains. The power plug
has to be accessible after installing the fixture. Do not overload wall outlets and extension cords as this can
result in fire or electric shock.
Do not allow anything to rest on the power cord. Do not locate this fixture where the cord may be damaged by
persons walking on it.
Make sure that the power cord is never crimped or damaged by sharp edges. Check the fixture and the power cord
from time to time.
Refer servicing to qualified service personnel.
This fixture falls under protection class . Therefore this fixture has to be connected to a mains socket outlet with a
protective earthing connection.
f the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not switch it on
immediately. The arising condensation water might damage your device. Leave the device switched off until it has
reached room temperature.
Do not shake the device. Avoid brute force when installing or operating the device.
This fixture was designed for indoor use only, Do not expose this unit to rain or use near water.
When choosing the installation spot, please make sure that the device is not exposed to extreme heat, moisture or
dust.

RMS-Robe Media Server
5
Air vents and slots in the fixture are provided for ventilation, to ensure reliable operation of the device and to
protect it from overheating.
The openings should never be covered with cloth or other materials, and never must be blocked.
This fixture should not be placed in a built-in installation unless proper ventilation is provided.
Only operate the fixture after having checked that the housing is firmly closed and all screws are tightly fastened.
Operate the fixture only after having familiarized with its functions. Do not permit operation by persons not
qualified for operating the fixture. Most damages are the result of unprofessional operation!
Please use the original packaging if the fixture is to be transported.
Please consider that unauthorized modifications on the fixture are forbidden due to safety reasons!
f this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock etc.
To switch the ROBE Media Se ve off, always use eithe option "Fixtu e Off" in the main menu of the cont ol boa d
o set a DMX value of the channel 1 (Powe /Special Functions) between 240-249.
Neve switch the fixtu e off by pulling out the powe plug f om the socket othe wise the fixtu e may be damaged
(ope ating system)!
2. Unpacking
The ROBE Media Server is packaged in either a cardboard box or one-unit flight case to protect the product during
transportation.
The following items are included:
- 1 x ROBE Media Server
- 1 x USB flash drive with a System recovery utility
- 1 x user manual
3. Introduction
The ROBE Media Server features a DMX controllable digital media server installed in a 19” rackmount case. The
built-in 32-bit Graphics Engine utilizes Linux and DirectX application programming interface to provide extensive
image control of graphic objects.
The ROBE Media Server uses DMX512 protocol to control media fixture capabilities including loading images and
movies. The graphics engine allows you manipulate position, scale, rotation, apply visual effects and colour mix
each image.

RMS-Robe Media Server
6
4. Fixture exterior vie
Front panel of the fixture
Rear panel of the fixture
1
- Handle
2 - Covering
3- Front doors
1
-
5" TFT Display
2 - Escape button
3 - RNS control wheel
4 - Enter button
5 - Reset button
6 - 2xUSB
7 - System indicator
8 - Fan fail indicator
9 - HDD indicator
10 - Power indicator
11 - ATX power switch
1-
Power input
2- Power switch
3- 2 x USB
4- 2 x USB
5- Ethernet input
6- Video input - S-video
7- VGA outputs 1-4
8- Video input - Composite
9- 3-pin DMX input/output- DMX 1
10 - 5-pin DMX input/output- DMX 2

RMS-Robe Media Server
7
5. Video inputs/outputs
Two video inputs S-Video (6) and Co posite (8) allow to process data in a graphics engine, you can use all
spectrum of effects that the graphic engine of the Robe Media Server offers.
One parallel video output is splitted with 4 Full HD layers available via 4 VGA outputs (7).
One of the four VGA output marked as Master- VGA 1 utilizes ED D data passed from the monitor connected to
this output.
ED D ( Extended Display dentification Data) is a data-structure, provided by a display, to describe its capabilities to
a graphics card (that is connected to the display’s source). The ED D enables the Robe Media Server to “know”
what kind of monitor is connected to the output. The ED D includes the manufacturer’s name, the product type,
the timing data supported by the display, the display size and luminance data.
For correct function of the ED D you should keep the following rules:
-The Master-VGA 1 output has to be always connected to the monitor
-f more monitors are connected to the Robe Media Server, all monitors has to be the same type
-Switch on monitors before powering on the Robe Media Server

RMS-Robe Media Server
8
6. Connection to the mains
Fixtu es must be installed by a Qualified elect ician in acco dance with all national and local elect ical
and const uction codes and egulation.
nstall a suitable plug on the power cord, note that the cores in the power cord are colored according to the
following table.
C
ore
(Eu)
C
ore
(US)
Pin
Sy bol
Brown
Black
Live
L
Light blue
White
Neutral
N
Yellow/Green Green Earth
The earth has to be connected!
6.1 Po ering on the ROBE Media Server
When the fixture is connected to the AC mains supply and the power switch is on, press the ATX power switch, it
automatically begins a setup procedure to verify that all functions of the fixture in good order.
f the fixture is in a stand- by mode, you can use option “ Wake On DMX” on the Pove /Special Functions channel
(control channel 1 ) - see DMX chart.
6.2 Shutting do n the ROBE Media Server
There are two recommended ways how to shutdown the fixture:
1. A DMX controller can shut down the fixture with the " Fixture Off" option on the Pove /Special Functions
channel (control channel 1 ) - see DMX chart.
2. The option "Fixture Off" in main menu of ROBE Media Server shuts down the fixture.
After shutting down the fixture switch the power switch on the rear side of the fixture base to the off position in
order to save energy.
Removing powe di ectly without the shutdown p ocedu e
can educe fixtu e eliability!
7. DMX 512 connection
The fixture is equipped with both 3-pin and 5-pin XLR sockets for DMX input and output. Only use a shielded
twisted-pair cable designed for RS-485 and 3-pin/5-pin XLR- connectors in order to connect the controller with the
fixture or one fixture with another.
Wiring of the XLR connectors:
DMX output DMX input
XLR mounting sockets (rear view): XLR mounting plugs (rear view):
1– Shield 2 - Signal (-) 3- Signal (+) 4– Not connected 5– Not connected
To build a DMX chain
1. Connect the DMX output of the first fixture in the DMX chain with the DMX input of the next fixture. Always
connect one output with the input of the next fixture until all fixtures are connected.
2. Use menu "DMX Settings " to set the DMX start address on all fixtures (see the "Fixture address" menu).
3. The option Activate DMX mode has to be confirmed in the “DMX Settings" menu on all fixtures.

RMS-Robe Media Server
9
Do not overload the link. Max. 32 fixtures may be connected on a DMX link.
Example:
Caution: Terminate the link by installing a termination plug in the DMX output of the last fixture. The termination
plug is a male 3-pin XLR plug with a 120 Ohm resistor soldered between Signal (–) and Signal (+).
8. Ethernet connection
The fixtures on a data link are connected to the Ethernet network with an Art-Net communication protocol. The
control software from PC (or lighting console) has to support the Art-Net protocol.
The Art-Net communication protocol is a 10 Base T Ethernet protocol based on the TCP/ P. ts purpose is to allow
transfer of large amounts of DMX 512 data over a wide area using standard network technology.
P address is the nternet protocol address. The P uniquely identifies any node (fixture) on a network.
The Universe is a single DMX 512 frame of 512 channels.
The the ROBE Media Server is equipped with 8-pin RJ- 45 socket for Ethernet input. Use a network cable category 5
(with four “twisted” wire pairs) and standard RJ-45 plugs in order to connect the fixture to the network.
RJ-45 socket (front view): RJ-45 plug (front view):
1- TD+ 5- Not connected
2- TD- 6- RX-
3- RX+ 7- Not connected
4- Not connected 8- Not connected
Patch cables that connect fixtures to the hubs or LAN sockets are wired 1:1, that is, pins with the same numbers
are connected together:
1-1 2-2 3-3 4-4 5-5 6-6 7-7 8-8
f only the fixture and the computer are to be interconnected, no hubs or other active components are needed. A
cross-cable has to be used:
1-3 2-6 3-1 4-8 5-7 6-2 7-5 8-4
Ethernet operation.
Connect the Ethernet inputs of all fixtures in the fixture chain with the network.
Use the menu "Artnet Settings " to set an P address , artnet universe and artnet subnet on all fixtures (see the
"Fixture address" menu).
The option “Activate Artnet mode" has to be confirmed in “Artnet Settings ” menu on all fixtures.
Example:

RMS-Robe Media Server
10
9. Folder organization
The library structure is reflected on the hard drive where all files for the library are stored. The whole library is
contained within a special folder called ‘Media’.
nside the Media folder is a collection of folders (000,001...240) each named with a 3-digit number. Each folder
following this convention represents a library folder and the 3-digit number represents the name of the folder.
Because of this, you can’t have folders without the 3 digit number scheme. You can’t neither have two folders with
the same digits.
nside each folder is a collection of media files that the library folder holds. The media files also should follow the
3-digit conventions where a 3-digit number is followed by an underscore and a name e.g.: 001_testfile1.png.
Note that for media files the digit starts at 001_ since visual 0 is always considered as being empty.
The media files assigned to the DMX values can be sorted either in an alphabetical or nu erical order. Default
assigning is the alphabetical order. f you need to change this sorting, go to the menu ”Personality“ and select
“Gobo selection mode“ option.
The numerical order is suitable in the case that you need to exactly assign certain media files to specified DMX
addresses.
The table below show differences in fileDMX assignment between the alphabetical and numerical sorting.
The table also includes file names without a correct 3-digit convention to illustrate their behaviour in
the numerical sorting.
Media file
na e
DMX
value
at Alphabetical Sorting
DMX
value
at Nu erical Sorting
1
1
2
20
3
19
4
3
5
Not Assigned
*
6
Not Assigned
**
* The 3-digit number has to be in range of 001-255. f there is more than 255 media files in the folder, files above
255 are ignored.
** The media file name does not contain any digit.
Subfolders 000-020 are reserved for default gobos and videos (fro factory) and their content cannot be
changed.
The images and video clips can be in one of the following formats: bmp, jpg, tga; .png, gif, pcx, pnm, xpm and lbm
for images and mpeg1, mpeg2 for videos.
The folder "Progra s" serves for saving recorded DMX programs (dprg_01.csv,......dprg_10.csv).
The folder named "Update" contains subfolders with the update files.The subfolders are created automatically
during software updating and their names matching to date when software update has been executed.

RMS-Robe Media Server
11
The folder a "Log" serves for saving log files generate by the option "Generate Log File" in a menu "Special
Functions" of the control panel.Log file names are deducated from the date when the file has been logged out.
Top level folder
Media
000
001
002
:
240
Programs
Update
13-08-06_09:15:33
:
01-03-06_14:23:50
Log

RMS-Robe Media Server
12
10. Control menu map
Default settings=Bold print
Menu Level 1 Menu Level 2
Menu Level 3
Menu Level 4
Menu Level 5
Menu Level 6
Menu Level 7
Menu Level 8
Fixture
Address DMX Settings Set DMX Address 001-512
Activate DMX
Mode
Ethernet
Settings Set P Address Default IP Address
Custom P
Address
Set ArtNet
Universe 0-15
Set ArtNet
Subnet 0-15
Activate
Artnet Mode
Fixture
Infor ation DMX Values Power 0-255
:
Synchro to L4 0-255
Media Disk
Space Usage
Free Disk
Space
Used Disk
Space
Software
Version
Graphic
Engine
GPU nfo: GPU:
Video Bios:
Driver
Version:
Disp:
Product Ds Mac Addr.
RDM U D
Personality
Display
Adjusting
Display
Permanent On
Display Off After
5 min
Per anent On
Display
Orientation
Nor al
Orientation
Rotated
Orientation

RMS-Robe Media Server
13
Menu Level 1 Menu Level 2
Menu Level 3
Menu Level 4
Menu Level 5
Menu Level 6
Menu Level 7
Menu Level 8
Display Modes CRT- : CRT- Screen
Resolution
1024x768
Projection
Presetting
Ceiling
Projection On, Off
Rear
Projection On, Off
Dmx Protocol Set DMX
Mode
2 Layers
3 Layers
4 Layers
Protocol
Version Version 1.1
Gobo Selection
Mode
Alphabetical
Order
Y;
Numerical
Order
Microphone
Sensitivity 1..10..20
Verbose Mode
Verbose Mode 0
Verbose Mode 1
DMX Verbose
Mode
Synchro
Verbose Mode
Default
Settings
Set Default
Values
Remove User
Media Content
Manual
Control
Manual DMX
Control Power 0-255
:
Synchro to L4 0-255
Stand-alone
Setting Play Program Program 1 in Loop
:
Program 10 in
Loop
Edit Program Program 1
: Edit Steps Step 1
Powe
Program 10 :
:
Step 99
Synchro To L4
Step Time
0.1 - 25.5 sec.

RMS-Robe Media Server
14
Menu Level 1 Menu Level 2
Menu Level 3
Menu Level 4
Menu Level 5
Menu Level 6
Menu Level 7
Menu Level 8
Fade Time
0.1-25.5 sec.
Snap DMX
Save
Start Step 1-99
Save and Copy
End Step 1-99
Play DMX
Program
Test DMX
program
DMX Program
1
:
DMX Program
10 in Loop
Record DMX
Program
DMX Program
1
:
DMX Program
10
Preset
Playback Deactivated
:
DMX Program
10 in Loop
Fixture Off
Timer
Timer
Deactivated
Timer
Activated
Set Timer
Hours
Set Timer
Minutes
Actual Time to
Off
Preview Mode
Reset
Functions
Reset Graphics
Engine
Service Menu Power On
Time Total Hours
Resetable
Hours
Special
Functions
Regenerate
Thumbnails
Set Thumbnail
size 50..96...300
Regenerate
Thumbnails
FTP Server Set Account

RMS-Robe Media Server
15
Menu Level 1 Menu Level 2
Menu Level 3
Menu Level 4
Menu Level 5
Menu Level 6
Menu Level 7
Menu Level 8
Allow
Anonymous Yes/No
HTTP Access Set Account
Allow
Anonymous Yes/No
USB Data
Synchronization
USB1 Open Media Open 000 Open
USB2 : Synchronize to
Fixture
240 Synchronize
from Fixture
Synchronize to
Fixture
Synchronize
from Fixture
Update Open
Synchronize to
Fixture
Synchronize
from Fixture
nit Flash Disc
Software
Update
Update
Graphical
Software
Update HW
processors
Software
Update Media
Content
Generate Log
File
Remote Servis Set Service P
Address
Remote P
Address 077.048.000.224
Remote Port 08283
Service Port 08290
Set Default
Gateway
Gateway
Address 002.001.001.001
Start Remote
Service
Pixel Mapping Actual Mode Not Active
Artnet Config 1
:
Artnet Config 5
DMX Config 1
:

RMS-Robe Media Server
16
Menu Level 1 Menu Level 2
Menu Level 3
Menu Level 4
Menu Level 5
Menu Level 6
Menu Level 7
Menu Level 8
DMX Config 5
Pixel Mapper
Type Nearest
Linear
Prewiew LED
Mapping
Config Mode Not Active
Artnet Config 1 Set Grid Width
: Set Grid Height
Artnet Config 5 Config Dots
Address Test Picture 1
DMX Config 1 :
: Test Picture 10
DMX Config 5 Config PM
Outputs
Artnet PM
Output Enabled,Disabled
DMX 1 PM
Output Enabled,Disabled
DMX 2 PM
Output Enabled,Disabled
Num. Dots On
DMX 1
Num. Dots On
DMX 2
Fixture Off

RMS-Robe Media Server
17
11. Operating modes
Before operating the ROBE Media Server from a DMX 512 controller, you need to define the source of DMX data,
which may be:
DMX 512 - data is transmitted over standard DMX cables. Set a valid DMX start address, which is defined as the
first channel from which the ROBE Media Server will respond to the controller.
Please, be sure that you don’t have any overlapping channels in order to control each ROBE Media Server correctly
and independently from any other fixture on the DMX data link.
For DMX start address setting, please refer to the instructions under "Fixture Address".
ArtNet - data is transmitted over Ethernet network using Artnet protocol. Set an P address, Artnet Universe and
Artnet Subnet.
For Artnet setting, please refer to the instructions under article "Fixture Address".
12. Control menu
The control panel situated on the front panel of the base offers several features. You can simply set the fixture
addresses, configure the fixture, run test, make a reset and also use many functions for setting fixture
behaviour.
Control ele ents on the control board:
[RNS] encoder wheel-moves between menu items on the same level, scrolls between values.
[ESC] button-leaves menu without saving changes
[ENTER] button-enters menu, confirms adjusted values and leaves menu
After switching the fixture on, than press [ENTER] and
the display shows the initial screen: the display shows address:
The main menu of the control panel is accessed by pressing the [ENTER] button. To browse through the menu,
rotate the [RNS] wheel. To select a function or submenu, press the [ENTER] button.
12.1 Fixture Address
Use this menu to set the DMX address.
DMX Setting --- Select this submenu to set the DMX start address.
Set DMX Address - sets DMX address. After selecting desired DMX address confirm setting
by using the function "Activate DMX Mode":
Activate DMX Mode - Data is received from DMX input.
Artnet Setting --- Select this submenu to set the fixture for Ethernet operating.
Set IP Address - Select this submenu to set an P address and NetMask.
The P address is the nternet protocol address and uniquely identifies any node (fixture) on
a network. There can't be 2 fixtures with the same P address on the network!
Default IP Address -Preset P address.
Custo IP Address - The option enables edit all numbers of the P address.
To set the custom P address:
1. Select „Custom P Address” and press the [ENTER].
2. Use RNS wheel to set the first number of the P address

RMS-Robe Media Server
18
3. Press the [ENTER] to move on the second number of the P address
4. Repeat steps 2 and 3 for the third and fourth number of the P address.
f you want to return back on the previously edited number, press [ESC].
The same way you can set the Netmask Address.
Set ArtNet Universe - Select this submenu to set a Universe (0-15).
The Universe is a single DMX 512 frame of 512 channels.
Set ArtNet Subnet - Select the option to set Ethernet subnetworks to which the fixture
belongs (0-15)
After setting all Artnet parameters confirm setting by using the function
"Activate Artnet Mode":
Activate Artnet Mode - Data is received from the Ethernet input.
12.2 Fixture information
DMX Values --- Select this item to read DMX values of each channel received by the fixture.
Media Disk Space Usage --- Select the item to read information about the hard disk space.
Free Disk Space --- Select the item to show a size of free hard disk space (MB).
Used Disk Space --- Select the item to show a size of used hard disk space (MB).
Software Version --- Select this function to read the software version of the fixture´s Graphic Engine.
GPU Info --- Select the item to read information about graphics processing unit, drivers and display device.
Product IDs --- Select the function to read the MAC address and the RDM U D code.
12.3 Personality
Use this menu to modify ROBE Media Server operating behaviour.
Display Adjusting --- This function allows you to change the display settings:
Display Per anent On - This function allows you to keep the display permanent on or
to turn it off after 5 minutes of inactivity of control buttons (wheel)
Display Orientation - Select this function to adjust the display orientation:
Nor al orientation - A standard display orientation.
Rotated Orientation - nverts the display by 180°.
Display Mode --- Use this menu to set suitable resolution for connected monitor (monitors):
CRT-I: CRT-I --- On this line is displayed the name of connected monitor (e.g. CRT- : Philips 170C)
Screen Resolution - the menu item includes the standard list of resolutions, if the monitor
is connected to the “ Master- VGA1” output, this list is extended with another resolutions
supported by the monitor. Default resolution is 1024x768.
Projection Presetting --- Use this menu depending on the installation location of the fixture:
Ceiling Projection --- When this function is "On", a picture is top (bottom and left) right
reversed.This function enables to project the image from a ceiling mounting of
the ROBE Media Server.
Rear projection --- When this function is "On", picture is left (right) reversed.
This function enables to project the image to a rear projection screen.
DMX protocol --- Use this menu to set desired number of gobo/video layers and DMX channels.
Set DMX ode --- the item allow you to select a desired number of control channels
2 Layers - 92 control channels

RMS-Robe Media Server
19
3 Layers - 120 control channels
4 Layers - 148 control channels
Protocol Version --- the item allow you to select a desired protocol version.
Gobo Selection Mode --- Use this menu to select desired sorting of media files in media subfolders.
Alphabetical Order --- The media files are assigned to DMX values in an alphabetical order.
Nu erical projection --- The media files are assigned to DMX values in a numerical order.
Verbose Mode --- Use this menu to hide messages displayed on the screen when you are changing some setting
on the Powe /Special functions channel (e.g. Rear projection on, Rear projection off.....) .
Verbose Mode 0 --- Generated messages are hidden.
Verbose Mode I --- Generated messages are visible on the projection screen.
DMX Verbose Mode --- t displayes information regards picture at the bottom left corner of
the image (channel, name, DMX value):
Synchro Verbose Mode --- used for debugging of video synchronization.
Default Settings --- Select this option to set default values or to remove user´s content in the fixture.
Set Default Values --- Select this option to reset all fixture personalities to the default values.
Re ove User Media Content --- The item deletes all user media contents except the factory media
content.
12.4 Manual control
Manual DMX control ---Select this menu to control all channels by the control elements on the control board.
12.5 Stand-alone setting
Use this menu to set options for a stand-alone mode as a selection of the program, programming and modifying
user programs.
Play Progra --- Select this menu to run a built-in program or 10 freely-programmable programs
in a loop.
Progra 1 In Loop
: These options start user defined programs
Progra 10 In Loop
Running program can be paused by pressing the [ENTER] button.
Edit Progra --- Select this menu to edit or create a program. The ROBE Media Server has 10 freely-programmable
programs, each up to 99 steps. Each program step has a step time, during which effects last in a current step.

RMS-Robe Media Server
20
Procedure:
1. Select the program you want to edit (“Program 1” - “Program 10”) and press the [ENTER] button.
2. Select “Edit Steps” menu and press [ENTER] button.
3. Select the desired program step (“Step 01” - “Step 99”) and press [ENTER] button.
4. Select the desired item and press the [ENTER] button. Now you can edit a DMX value of selected item by the
[RNS] encoder wheel
5. Press the [ENTER] to save adjusted value.
6. Select another effects (channels) and repeat steps 4 an 5.
7. Select “Save” or “Save and Copy” and press the [Enter] to confirm all adjusted values in a current step:
“Save” - saves the current prog. step
“Save and Copy” - saves and copies the current prog. step to the next prog. step.
Option “Snap DMX”- inserts current values from DMX to all effects (channels). t is very useful function, you don
not have to adjust all effects to desired positions, all values are loaded from DMX.
8. Go to the next prog. step ,press the [ENTER] and repeat this procedure (steps 4 and 7).
After creation of the program, you can simply reduced its length (by changing the start/end step) using either the
“Start Step” item or the “End Step” item.
Play DMX Progra --- Select this menu to run one of 10 programs which have been recorded via the menu
“Record DMX progra ”. By pressing the [ENTER] you can switch the running program into the 3 following modes:
Pause, Playing, Playing in Loop. The current program step is shown on the fixture display:
Record DMX Progra --- The menu allows to record DMX data that receives the fixture and then replay them again
via the menu “Play DMX progra ”. There is a list of 10 programs for recording with unlimited steps each.
Select desired program number and press the [ENTER] to enter the recording screen.
The data record starts after changing any receiving DMX value. To stop recording, press [ENTER] or [ESC].
Recorded DMX program has the name dprg_xx.csv where the xx means the number of the program (e.g.
dpr_01.csv, dprg_02.csv....) and is stored in the folder “Programs” accessible by means of FTP. The format of this
file is a plain text that allows additional user editing. The first line of the file includes all DMX channels with their
starting DMX values and the next lines display changes of DMX values of channel effect and a relevant time of the
changes.
Note: If you select the progra which contains previously recorded data, the data will be overwritten without
warning.
Preset playback --- The menu allows to select a program (or a DMX program), which will be played automatically in
a loop after switching the fixture on.
Fixture Off Ti er --- The menu offers to control the time during which the fixture is on and, for example, plays the
recorded program. The adjusted time period is counted from starting the fixture.
Deactivated Ti er --- The item disables the “Fixture Off Timer” option.
Set Ti er Hours --- The item enables to set hours for the “Fixture Off Timer”.
