Acrosser Technology ANR-C62-N1 Series User manual

ANR-C62xN1 Series
User Manual
Acrosser Technology Co., Ltd.
www.acrosser.com
ANR-C62xN1Series
Networking 2U Rackmount Server
• Intel® Xeon®+ C627/C622 PCH
• 8x Acrosser®Swappable Expansion NIM
(for 1G/10G/25G/40G, Fiber/Copper/LAN Bypass)
• 2x SFP+ (10G Fiber)
• 1x Management Port

ANR-C62xN1 Series
2Acrosser Technology Co., Ltd.
Disclaimer
For the purpose of improving reliability, design and function, the information in
this document is subject to change without prior notice and does not represent a
commitment on the part of Acrosser Technology Co., Ltd.
In no event will Acrosser Technology Co., Ltd. be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or inability to use the
product or documentation, even if advised of the possibility of such damages.
Copyright
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic,
or other means in any form without prior written permission of Acrosser Technology
Co., Ltd.
Trademarks
The product names appear in this manual are for identication purpose only. The
trademarks and product names or brand names appear in this manual are the
property of their respective owners.
PurposeThis document is intended to provide the information about the features and use of
the product.
Audience
The intended audiences are technical personnel, not for general audiences.
WARNING
Danger of explosion if batteries are incorrectly replaced. Always replace the
battery with the same specications. Dispose of used batteries according to the
manufacturer's instructions.
Before running the system, make sure the power cord is rmly plugged into the
socket.
CAUTION
IEC 60417-6042 (2010-11) IEC 60417-6172 (2012-09)
All power cords must be disconnected during product repair.
To read this User Manual on your smart phone, you will have to install an
APP that can read PDF le format rst. Please nd the APP you prefer from
the APP Market.
Ver: 100-003
Date: Jul. 6, 2021

ANR-C62xN1 Series
3
www.acrosser.com
Table of Contents
1. Introduction ...................................................................5
1.1. Models........................................................................................................................ 5
1.2. Specications ............................................................................................................. 6
1.3. Packing List................................................................................................................ 7
1.4. Layout & Dimension ................................................................................................... 8
1.5. Front Panel................................................................................................................. 9
1.5.1. Module A: Network expansion module connector........................................... 9
1.5.2. HDD Trays..................................................................................................... 13
1.5.3. SFP+ 10GbE LAN Ports ............................................................................... 13
1.5.4. LAN / Console / 2x USB 3.0 / Reset ............................................................. 14
1.5.5. LCM Display / Navigation Joystick / Indicators ............................................. 15
1.6. Rear Panel................................................................................................................ 16
2. Installation...................................................................17
2.1. Package List............................................................................................................. 17
2.1.1. Screw List...................................................................................................... 18
2.2. Slide-rail Assembly................................................................................................... 21
2.3. PCIe Card Installation............................................................................................... 25
3. BIOS Settings...............................................................30
3.1. Main Setup ............................................................................................................... 30
3.2. Advanced Setup....................................................................................................... 31
3.2.1. Trusted Computing........................................................................................ 32
3.2.2. OnBoard Bypass Controller .......................................................................... 32
3.2.3. W83627DHG Super IO Conguration ........................................................... 33
3.2.4. W83627DHG HW Monitor............................................................................. 34
3.2.5. Serial Port Console Redirection.................................................................... 35
3.2.6. USB Conguration ........................................................................................ 36
3.2.7. Network Stack Conguration ........................................................................ 37
3.2.8. CSM Conguration........................................................................................ 38
3.3. IntelRCSetup............................................................................................................ 39
3.3.1. PCH SATA Conguration............................................................................... 39
3.4. Processor Setup....................................................................................................... 40
3.4.1. Processor Conguration................................................................................ 40
3.4.2. Intel VT for Directed I/O (VT-d) ..................................................................... 41
3.5. Security Setup.......................................................................................................... 42

ANR-C62xN1 Series
4Acrosser Technology Co., Ltd.
3.6. Boot Setup................................................................................................................ 42
3.7. Save & Exit Setup..................................................................................................... 43
4. Software Installation and Programming Guide...........44
4.1. Introduction............................................................................................................... 44
4.1.1. Environment.................................................................................................. 44
4.1.2. GPIO............................................................................................................. 44
4.1.3. Watchdog...................................................................................................... 44
4.1.4. LCD Control Module ..................................................................................... 44
4.1.5. Power Supply Unit ........................................................................................ 45
4.1.6. Chassis Opened............................................................................................ 45
4.2. File Descriptions....................................................................................................... 45
4.2.1. GPIO/Watchdog/LCD Control Module........................................................... 45
4.3. API List and Descriptions ......................................................................................... 46
4.3.1. GPIO............................................................................................................. 46
4.3.2. Watchdog...................................................................................................... 46
4.3.3. LCD Control Module...................................................................................... 47
4.3.4. Power Supply Unit (PMBUS) ........................................................................ 48
4.3.5. Pmbus Command Code Summary ............................................................... 49
4.3.6. Chassis Opened............................................................................................ 53
4.3.7. Notes............................................................................................................. 53
5. FAQ...............................................................................55
Q 1. Where can I nd the serial number of this product?................................................. 55

ANR-C62xN1 Series
5
www.acrosser.com
1. Introduction
Acrosser’s brand new 2U rack mount server, ANR-C627/622N1 series, are designed
with X86 processor and positioned for Intel®Xeon-based 2U network appliances
which require high-performance computing (HPC) and multi-core (up to 28 cores)
with hyper-threading (HT) functionality for a wide range of workloads with high
memory bandwidth (DDR4-2666) and capacity.
ANR-C627/622N1 equipped with the latest generation Intel®Xeon®Scalable
processors are perfect for IoT Gateway, Edge Computing (EC), Cloud, Next
Generation Firewall (NGFW), IPS/IDS, Security Gateway (Se-GW), Unied Threat
Management (UTM) and Network Functions Virtualization (NFV).As excellence
network appliances, ANR-C627/622N1 series support dual-socket Intel®Xeon®
Scalable processors, 24* RDIMM/LRDIMM DDR4-2666, dual on-board SFP+
(10G ber) and 8* Expandable Network Interface Modules (NIMs) for 1G/10G/40G
(ber/Copper/Bypass) various options. Strong networking ability can meet most of
enterprise-class customers’ needs.
In addition, ANR-C627/622N supports 1+1 Redundant Platinum PSU, dual U.2
Non-volatile Memory Express (NVMe, PCIe Gen3 x4) SSDs or optional 4*2.5” hot-
swappable SATA-III HDDs and smart cooling fans enabling 24/7 operation and long-
term deployment.
1.1. Models
This manual is applied to the following models:
1. ANR-C627N1
2. ANR-C622N1
3. ANR-C627N1U
4. ANR-C622N1U

ANR-C62xN1 Series
6Acrosser Technology Co., Ltd.
1.2. Specifications
System
Thermal Solution • Hot-swappable PWM Smart Cooling Fans
CPU • Intel®Xeon®8280 (Platinum)
• Intel®Xeon®6265N (Gold)
• Intel®Xeon®5218N (Gold)
• Intel®Xeon®4216 (Silver)
• Intel®Xeon®3204 (Bronze)
System Memory • 24x RDIMM/LRDIMM DDR4
BIOS • Support Console Re-direction
• Support PXE Boot
System Chipset • Intel®PCH C627/C622
VGA Chipset • ASPEED®AST2510
Network Interface
Ethernet (on-board) • 2x 10G Fiber, SFP+[1:2] (via Intel®PCH C62x series)
• 1x RJ-45 Copper: LAN port
Storage
HDD Bay • ANR-C62xN1:
4x 2.5” SATA3 Hot-swappable (RAID 0/1/5/10)
• ANR-C62xN1U:
2x U.2 NVMe Hot-swappable (RAID 1)
mSATA • 1x mSATA Socket (Support full-size module)
CFast • 1x CFast Socket
Others
Watchdog Timer • Software Programmable 0 ~ 255 Secs.
Battery • Lithium Battery, 3V 220mAH (CR2032)
Hardware Monitoring • CPU Voltage
• CPU & SYS Temperature
• SYS FAN Speed
Security & Mgmt. • On-board TPM 2.0
• Chassis Intrusion Detection (default: Disable)
OS support • Linux Kernel 4.4 or above, (64-bit)
• DPDK for ANR-C62xN1(U) series
• QAT for ANR-C627N1(U) series

ANR-C62xN1 Series
7
www.acrosser.com
Mechanical & Environment
Chassis Dimension • 440 (W) x 88.5 (H) x 670 (D) mm
Operating Temperature • 0 ~ 40°C (32 ~ 104°F)
Storage Temperature • -20 ~ 80°C (-4 ~ 176°F)
Relative Humidity • 0 ~ 90% @40°C, non-condensing
Power Supply Unit • 1+1 CRPS 2U Redundant ATX PSU (800W)
Power Requirements • ATX Circuit as AT Mode with Power Switch
EMC & Safety
Certication • CE, FCC Class A, RoHS 2, cULus
Vibration Test • IEC 60068-2-64, 5~500Hz, 3GRMS
Drop Test • ISTA-2A 2006
1.3. Packing List
Check if the following items are included in the package.
Item Q’ty
�ANR-C62xN1 Series System 1
�CD Utility 1
�RJ45-console cable (RJ45 <-> DB9) 1
�USB-console cable (Micro-B <-> Type A) 1
�Power Cord 2
�Rack Bracket 2
�Box Packing 1
�Screw Pack 1
�Slide Rail 1

ANR-C62xN1 Series
8Acrosser Technology Co., Ltd.
1.4. Layout & Dimension
(Illustration model: ANR-C62xN1 with 8x optional LAN modules)
440.00
88.50
670.00

ANR-C62xN1 Series
9
www.acrosser.com
1.5. Front Panel
1.5.1. Module A: Network expansion module connector
Available LAN Modules:
Note: The model name, type number, or layout design of these options might change due
to product revision.
1. ACC-NM1Z1-01C8B: 1G Copper x8 (RJ-45 w/ 4-pair Bypass)
2. ACC-NM1Z1-01C8: 1G Copper x8 (RJ-45)

ANR-C62xN1 Series
10 Acrosser Technology Co., Ltd.
3. ACC-NM1Z1-01F8: 1G Fiber x8 (SFP)
4. ACC-NM1Z1-01H8B: 1G Hybrid x8 (SFP + RJ-45 w/ 2-pair Bypass)
5. ACC-NM1Z1-01H8: 1G Hybrid x8 (SFP + RJ-45)
6. ACC-NM1Z1-10F2: 10G Fiber x2 (SFP+)

ANR-C62xN1 Series
11
www.acrosser.com
7. ACC-NM1Z1-10F4: 10G Fiber x4 (SFP+)
8. ACC-NM1Z1-40F1: 40G Fiber x1 (QSFP+)
9. ACC-NM1Z1-40F2: 40G Fiber x2 (QSFP+)
10.ACC-NM1Z1-01C4B: 1G Copper x4 (RJ-45 w/ 2-pair Bypass)

ANR-C62xN1 Series
12 Acrosser Technology Co., Ltd.
11. ACC-NM1Z1-01C4: 1G Copper x4 (RJ-45)
12.ACC-NM1Z1-01F4: 1G Fiber x4 (SFP)

ANR-C62xN1 Series
13
www.acrosser.com
1.5.2. HDD Trays
4x 2.5” SATA3 Hot-swappable HDD trays (for ANR-C62xN1).
or
2x U.2 NVMe|SATA3 Hot-swappable HDD trays (for or ANR-C62xN1U).
1.5.3. SFP+ 10GbE LAN Ports
LED Light Status
Blue Blue On 10Gbps
Off 1Gbps or below
If this LAN port funtion fail after connected a 1GbE module, you may
try the following steps:
Step 1: Remove the 1GbE module from the LAN port.
Step 2: Disable the LAN port function.
Step 3: Enable the LAN port function.
Or you may remove the 1GbE module from the LAN port and then
restart the system.

ANR-C62xN1 Series
14 Acrosser Technology Co., Ltd.
1.5.4. LAN / Console / 2x USB 3.0 / Reset
Console LAN
Reset
Console USB
• Console (M.USB)
Micro USB For Console Function
Note: Either M.USB or RJ45 console can only be used only one at a time.
• Reset
System Reset Button
• Console (RJ45)
Pin # Signal Pin # Signal
1RTS 5 GND
2 DTR 6 SIN
3 SOUT 7 DSR
4 GND 8 CTS
• LAN
LED Light Status
LED2 Off 10Mbps Orange 100Mbps
Green 1000Mbps
LED1 Yellow Link/Active
Off LAN Off

ANR-C62xN1 Series
15
www.acrosser.com
• USB
Standard USB 3.0 Type-A connector
1.5.5. LCM Display / Navigation Joystick / Indicators
IPMIHDD
Navi. Joystick
PWRLCM
• LCM Display
128 * 32 Pixels Graphic mode only
• Navigation Joystick
LCM menu control buttons (Up/Down/Left/Right/Center)
• IPMI
IPMI indicator (Green)
• HDD
HDD activity indicator (Yellow)
• PWR
Power indicator (Green)

ANR-C62xN1 Series
16 Acrosser Technology Co., Ltd.
1.6. Rear Panel
AC Inlets
Power Switch VGAUSB
Expansion Card Slot
SYSFAN5SYSFAN2SYSFAN1 SYSFAN6 SYSFAN3 SYSFAN4
• Expansion Card Slot
1x PCI express card insert slot
• AC Inlets
1+1 CRPS 2U Redundant ATX PSU
• System Fan
4x Hot-swappable Smart Cooling Fans
with 2-color LED (Green->Normal, Orange->Warning)
• USB
2x USB 2.0 ports
• VGA
VGA connector
• Power Switch
Power on/off switch

ANR-C62xN1 Series
17
www.acrosser.com
2. Installation
To mount this server into a rack, you will need to do some preparation.
2.1. Package List
Check the following items.
Item Description Q’ty
RJ45-console cable RJ45 <-> DB9 1
USB-console cable Micro-B <-> Type A 1
Ear Bracket 2
Screw Pack 1

ANR-C62xN1 Series
18 Acrosser Technology Co., Ltd.
2.1.1. Screw List
This is a bag of screws and sponges.
# Item Description Q’ty
1 M4x6 (black) For ear bracket 8
2 M3 Screw For 2.5” HDD with sponge (yellow) 8
3 6#32 Screw For 3.5” HDD with sponge (yellow) 8
4 Sponge (yellow) For 2.5” & 3.5” HDD 8
5 M3x4 (sliver) For HDD bay (2.5”-7mmx4) 16

ANR-C62xN1 Series
19
www.acrosser.com
#1: Ear brackets
#2: 2.5” HDD with sponge

ANR-C62xN1 Series
20 Acrosser Technology Co., Ltd.
#3: 3.5” HDD with sponge
#5: 7mm-HDD bay with screws
