Features and Benefits
Larger Back Lit Display
Makes viewing and setting the temperature
easy and accurate.
Winter and Summer Permanent Setpoint Memory
Allows you to save both heating and cooling
temperature settings.
Automatic Compressor Short Cycle Protection
A system safeguard. Reduces wear and
tear of HVAC equipment.
Worry-Free Memory Storage
Even during power outages, the thermostat maintains
setpoint and programmed parameters.
Adjustable 1st and 2nd Stage Temperature Differential
Maintains optimal customer comfort.
O & B Terminals
Greater system flexibility, zoning compatible.
Zone System Compatible
In zoning applications where temperature is
precisely controlled, the thermostat acts as a sensor
within the system.
Quick Wire Terminal Block
Fast and easy installation. Uses sturdy wire clamps –
no wrap-around of screws.
Toll-Free Assistance
Toll-Free Technical Service number printed right on
the thermostat provides immediate assistance.
2 Heat / 2 Cool
Incredible Digital
When it comes to non-programmable temperature control,
we listened to the experts–YOU! Our 9415 takes comfort to a
new level. The LCD display is clearly one of the largest in the
industry, up to 80% larger than competitive models. Plus, the
display is back lit, making it even easier to read in a dark room.
This model is loaded with enhanced features. The 9415 comes
with permanent winter and summer setpoint memory, allowing
you to save both heating and cooling temperature settings. This
eliminates temperature adjustments when switching systems for
seasonal requirements. And our fully adjustable differential
provides increased comfort control. The 9415 is compatible with
all standard 24 Volt AC multi-stage systems, up to two stage
heat and two stage cool.
When you select a Robertshaw thermostat, you’ve made the
choice of an industry partner that’s been making quality
products for 100 years. Come home to affordable comfort.
Come home to RobertshawSM.
Technical service available:
1-800-445-8299
M-F 7:00 a.m. - 5:30 p.m. CST
W
A
R
R
A
N
T
Y
2
T
W
O
Y
E
A
R
24 VAC POWERED
G
GAS
E
ELECTRIC
O
OIL
®
DIGITAL
NON-PROGRAMMABLE
THERMOSTAT
new series!

2 Heat / 2 Cool
Terminal Designations
THE ROBERTSHAW 9415 REPLACES:
E
G
Shipping Information
Indiv. Ctn. Dim.: 6.75" x 4.375" x 1.625"
Master Ctn. Qty.: 6
Master Ctn. Dim.: 9.25" x 5.625" x 7.625"
Master Ctn. Cu. Ft.: .23
Master Ctn. Wt.: 4.0 lbs.
Max. Pallet Qty.: 1170
Max. Pallet Dim.: 40" x 48" x 48"
Max. Pallet Cu. Ft.: 53.33
Max. Pallet Wt.: 835 lbs.
Other Multi-Stage
Heat / Cool Thermostats
9615: Programmable, 7 Day
9715i: Deluxe Programmable, 7 Day
C
24 VAC
Common
R
24 VAC
Transformer
Y2
Cooling
Relay
(Stage 2)
Y1
Cooling
Relay
(Stage 1)
W1
Heat
Relay
(Stage 1)
W2
Auxiliary
Heat Relay
(Stage 2)
O
Cool Active
Accessory
Terminal
B
Heat Active
Accessory
Terminal
G
Fan
Relay
Specifications
Electrical rating: 24 Volt AC (18-30 VAC)
1 amp maximum load per terminal
3 amp total maximum load
(all terminals combined)
Temperature control range: 45˚- 90˚F (7˚- 32˚C)
Power: 24 VAC
Accuracy: +/-1˚F (+/-.5˚C)
System configurations: Multi-stage gas, oil, or
electric heating/cooling systems
(up to two stage heat, two stage cool)
Terminations: C, R, Y2, Y1, W1, G, W2, O, B
GAS ELECTRIC
®
