Rockbox Sansa c200v2 Series User manual

The Rockbox Manual
for
Sansa c200v2 Series
rockbox.org
March 5, 2013

2
Rockbox
http://www.rockbox.org/
Open Source Jukebox Firmware
Rockbox and this manual is the collaborative effort of the Rockbox team and
its contributors. See the appendix for a complete list of contributors.
c
2003-2013 The Rockbox Team and its contributors, c 2004 Christi Alice
Scarborough, c 2003 José Maria Garcia-Valdecasas Bernal & Peter Schlenker.
Version 3.13. Built using pdfL
A
T
E
X.
Permission is granted to copy, distribute and/or modify this document under
the terms of the GNU Free Documentation License, Version 1.2 or any later
version published by the Free Software Foundation; with no Invariant Sec-
tions, no Front-Cover Texts, and no Back-Cover Texts. A copy of the license
is included in the section entitled “GNU Free Documentation License”.
The Rockbox manual (version 3.13) Sansa c200v2 Series

Contents 3
Contents
1. Introduction 11
1.1. Welcome ..................................... 11
1.2. Getting more help ............................... 11
1.3. Naming conventions and marks ........................ 12
2. Installation 13
2.1. Before Starting ................................. 13
2.2. Installing Rockbox ............................... 13
2.2.1. Automated Installation ........................ 14
2.2.2. Manual Installation .......................... 15
2.2.3. Bootloader installation from Windows ................ 16
2.2.4. Bootloader installation from Mac OS X and Linux ......... 17
2.2.5. Finishing the install .......................... 17
2.2.6. Enabling Speech Support (optional) ................. 17
2.3. Running Rockbox ................................ 17
2.4. Updating Rockbox ............................... 17
2.5. Uninstalling Rockbox ............................. 18
2.5.1. Automatic Uninstallation ....................... 18
2.5.2. Manual Uninstallation ......................... 18
2.6. Troubleshooting ................................. 18
3. Quick Start 19
3.1. Basic Overview ................................. 19
3.1.1. The player’s controls .......................... 19
3.1.2. Turning the player on and off ..................... 20
3.1.3. Starting the original firmware ..................... 20
3.1.4. Putting music on your player ..................... 20
3.1.5. The first contact ............................ 20
3.1.6. Basic controls .............................. 21
3.1.7. Basic concepts ............................. 21
3.2. Customising Rockbox ............................. 22
3.3. USB Charging ................................. 22
4. Browsing and playing 23
4.1. File Browser ................................... 23
4.1.1. File Browser Controls ......................... 24
4.1.2. Context Menu ............................. 24
The Rockbox manual (version 3.13) Sansa c200v2 Series

Contents 4
4.1.3. Virtual Keyboard ............................ 26
4.2. Database .................................... 27
4.2.1. Introduction .............................. 27
4.2.2. Initializing the Database ........................ 27
4.2.3. The Database Menu .......................... 27
4.2.4. Using the Database .......................... 28
4.3. While Playing Screen .............................. 29
4.3.1. WPS Key Controls ........................... 31
4.3.2. Peak Meter ............................... 31
4.3.3. The WPS Context Menu ....................... 32
4.4. Working with Playlists ............................. 35
4.4.1. Playlist terminology .......................... 35
4.4.2. Creating playlists ............................ 35
4.4.3. Adding music to playlists ....................... 36
4.4.4. Modifying playlists ........................... 37
4.4.5. Saving playlists ............................. 38
4.4.6. Loading saved playlists ........................ 38
4.5. Hotkeys ..................................... 38
5. The Main Menu 39
5.1. Introducing the Main Menu .......................... 39
5.2. Navigating the Main Menu .......................... 39
5.3. Recent Bookmarks ............................... 40
5.4. Files ....................................... 40
5.5. Database .................................... 41
5.6. Now Playing/Resume Playback ........................ 41
5.7. Settings ..................................... 41
5.7.1. Sound Settings ............................. 41
5.7.2. Playback Settings ........................... 41
5.7.3. General Settings ............................ 41
5.7.4. Theme Settings ............................. 41
5.7.5. Recording Settings ........................... 41
5.7.6. Manage Settings ............................ 42
5.8. Recording .................................... 42
5.8.1. While Recording Screen ........................ 42
5.9. FM Radio .................................... 43
5.10. Playlists ..................................... 44
5.11. Plugins ..................................... 45
5.12. System ...................................... 45
5.13. Quick Screen .................................. 46
5.14. Shortcuts .................................... 46
6. Sound Settings 48
6.1. Volume ..................................... 48
The Rockbox manual (version 3.13) Sansa c200v2 Series

Contents 5
6.2. Bass ....................................... 48
6.3. Treble ...................................... 48
6.4. Balance ..................................... 49
6.5. Channels .................................... 49
6.6. Stereo Width .................................. 49
6.7. Crossfeed .................................... 49
6.8. Equalizer .................................... 51
6.9. Dithering .................................... 53
6.10. Timestretch ................................... 53
6.11. Compressor ................................... 53
7. Playback Settings 55
7.1. Shuffle ...................................... 55
7.2. Repeat ...................................... 55
7.3. Play Selected First ............................... 56
7.4. Fast-Forward/Rewind ............................. 56
7.5. Fade on Stop/Pause .............................. 56
7.6. Party Mode ................................... 56
7.7. Replaygain ................................... 56
7.8. Track Skip Beep ................................ 57
7.9. Auto-Change Directory ............................ 57
7.10. Constrain Auto-Change ............................ 57
7.11. Last.fm Log ................................... 58
7.12. Cuesheet Support ................................ 58
7.13. Skip Length ................................... 58
7.14. Prevent Track Skipping ............................ 58
7.15. Rewind Before Resume ............................. 58
7.16. Rewind on Pause ................................ 59
8. General Settings 60
8.1. Playlist ..................................... 60
8.2. File View .................................... 60
8.3. Database .................................... 62
8.4. Display ..................................... 62
8.5. System ...................................... 65
8.5.1. Limits .................................. 65
8.5.2. Use Shortcuts Menu Instead of Quick Screen ............ 65
8.5.3. Car Adapter Mode ........................... 65
8.5.4. Button Light Timeout ......................... 66
8.5.5. Keyclick ................................. 66
8.5.6. USB HID ................................ 66
8.5.7. USB Keypad Mode ........................... 66
8.5.8. USB Hide Internal Drive ........................ 68
The Rockbox manual (version 3.13) Sansa c200v2 Series

Contents 6
8.6. Startup/Shutdown ............................... 68
8.6.1. Start Screen ............................... 69
8.6.2. Idle Poweroff .............................. 69
8.6.3. Sleep Timer ............................... 69
8.7. Bookmarking .................................. 70
8.8. Automatic resume ............................... 72
8.9. Language .................................... 72
8.10. Voice ....................................... 73
8.11. Hotkey ...................................... 74
9. Theme Settings 75
10.Recording Settings 77
10.1. Format ...................................... 77
10.2. Encoder Settings (MP3 only) ......................... 77
10.3. Frequency .................................... 77
10.4. Source ...................................... 77
10.5. Channels .................................... 78
10.6. Mono Mode ................................... 78
10.7. File Split Options ................................ 78
10.8. Prerecord Time ................................. 78
10.9. Clear Recording Directory ........................... 78
10.10.Clipping Light ................................. 79
10.11.Trigger ...................................... 79
11.Time and Date 81
12.Plugins 82
12.1. Games ...................................... 82
12.1.1. Blackjack ................................ 82
12.1.2. BrickMania ............................... 83
12.1.3. Bubbles ................................. 84
12.1.4. Chessbox ................................ 85
12.1.5. Clix ................................... 86
12.1.6. Chopper ................................. 86
12.1.7. Codebuster ............................... 87
12.1.8. Dice ................................... 87
12.1.9. Flipit .................................. 88
12.1.10.Goban .................................. 88
12.1.11.Jackpot ................................. 93
12.1.12.Jewels .................................. 93
12.1.13.MazezaM ................................ 94
12.1.14.Minesweeper .............................. 95
12.1.15.Pegbox ................................. 95
The Rockbox manual (version 3.13) Sansa c200v2 Series

Contents 7
12.1.16.Pong ................................... 96
12.1.17.Reversi ................................. 97
12.1.18.Robotfindskitten ............................ 97
12.1.19.Rockblox ................................ 97
12.1.20.Rockblox1d ............................... 98
12.1.21.Sliding Puzzle .............................. 98
12.1.22.Snake .................................. 99
12.1.23.Snake 2 .................................100
12.1.24.Sokoban .................................100
12.1.25.Solitaire .................................101
12.1.26.Spacerocks ...............................102
12.1.27.Star ...................................103
12.1.28.Sudoku .................................103
12.1.29.Wormlet .................................105
12.1.30.Xobox ..................................107
12.2. Demos ......................................108
12.2.1. Bounce .................................108
12.2.2. Credits .................................108
12.2.3. Cube ...................................109
12.2.4. Demystify ................................109
12.2.5. Fire ...................................110
12.2.6. Fractals .................................110
12.2.7. Logo ...................................111
12.2.8. Mosaique ................................111
12.2.9. Oscilloscope ...............................112
12.2.10.PictureFlow ...............................113
12.2.11.Plasma .................................114
12.2.12.Rocklife .................................115
12.2.13.Snow ...................................115
12.2.14.Starfield .................................116
12.2.15.VU meter ................................116
12.3. Viewers .....................................117
12.3.1. Shortcuts ................................117
12.3.2. Chip-8 Emulator ............................118
12.3.3. Frotz ...................................119
12.3.4. Image Viewer ..............................120
12.3.5. MP3 Encoder ..............................121
12.3.6. Rockboy .................................122
12.3.7. Search ..................................123
12.3.8. Shopper .................................123
12.3.9. Sort ...................................123
12.3.10.Text Viewer ...............................124
12.3.11.Theme Remove .............................127
12.3.12.VBRfix .................................128
The Rockbox manual (version 3.13) Sansa c200v2 Series

Contents 8
12.3.13.ZXBox ..................................129
12.4. Applications ...................................130
12.4.1. Alarm Clock ..............................130
12.4.2. Battery Benchmark ..........................131
12.4.3. Calculator ................................133
12.4.4. Calendar ................................133
12.4.5. Chess Clock ...............................134
12.4.6. Clock ..................................135
12.4.7. Disk Tidy ................................137
12.4.8. Keybox .................................138
12.4.9. Lamp ..................................138
12.4.10.Lrcplayer ................................139
12.4.11.md5sum .................................141
12.4.12.Metronome ...............................141
12.4.13.Pitch Detector .............................142
12.4.14.Random Folder Advance Configuration ...............142
12.4.15.Resistor Calculator ...........................143
12.4.16.Rockpaint ................................144
12.4.17.Stats ...................................146
12.4.18.Stopwatch ................................147
12.4.19.Text Editor ...............................147
13.Advanced Topics 149
13.1. Customising the User Interface ........................149
13.1.1. Customising The Main Menu .....................149
13.1.2. Getting Extras .............................149
13.1.3. Loading Fonts .............................149
13.1.4. Loading Languages ...........................150
13.1.5. Changing Filetype Colours ......................150
13.1.6. Loading Backdrops ...........................151
13.1.7. UI Viewport ..............................152
13.2. Configuring the Theme .............................152
13.2.1. Themeing – General Info .......................152
13.2.2. Themes – Create Your Own ......................152
13.2.3. Info Viewport (SBS only) .......................155
13.2.4. Additional Fonts ............................156
13.3. Managing Rockbox Settings ..........................158
13.3.1. Introduction to .cfg Files .......................158
13.3.2. Specifications for .cfg Files ......................159
13.3.3. The Manage Settings menu ....................160
13.4. Firmware Loading ...............................160
13.4.1. Using ROLO (Rockbox Loader) ....................160
13.5. Optimising battery runtime ..........................160
13.5.1. Display backlight ............................161
The Rockbox manual (version 3.13) Sansa c200v2 Series

Contents 9
13.5.2. Replaygain ...............................161
13.5.3. Peak Meter ...............................161
13.5.4. Audio format and bitrate .......................161
13.5.5. Sound settings .............................161
A. File formats 162
A.1. Supported file formats .............................163
B. Audio and metadata formats 164
B.1. Supported audio formats ............................164
B.1.1. Lossy Codecs ..............................164
B.1.2. Lossless Codecs .............................165
B.1.3. Other Codecs ..............................166
B.1.4. Codec featureset ............................167
B.2. Supported metadata tags ...........................168
B.2.1. Featureset for generic metadata tags .................168
B.2.2. Featureset for codec specific metadata ................169
B.2.3. Limitations of metadata handling ...................169
C. Album Art 170
C.1. Limitations ...................................170
C.2. Where to put album art ............................170
D. Theme Tags 172
D.1. Status Bar ....................................172
D.2. Hardware Capabilities .............................172
D.3. Information from the track tags ........................173
D.4. Viewports ....................................173
D.5. Additional Fonts ................................174
D.6. Misc Coloring Tags ...............................174
D.7. Power Related Information ..........................174
D.8. Information about the file ...........................175
D.9. Playlist/Song Info ...............................176
D.10.Playlist Viewer .................................176
D.11.Runtime Database ...............................177
D.12.Sound (DSP) settings .............................177
D.13.Hold .......................................177
D.14.Virtual LED ..................................178
D.15.Repeat Mode ..................................178
D.16.Playback Mode .................................178
D.17.Current Screen .................................178
D.18.List Title (.sbs only) .............................179
D.19.Changing Volume ................................180
D.20.Settings .....................................180
The Rockbox manual (version 3.13) Sansa c200v2 Series

Contents 10
D.21.Images ......................................181
D.21.1.How to display the album art .....................182
D.22.FM Radio ....................................183
D.23.Alignment and language direction .......................184
D.24.Conditional Tags ................................184
D.25.Subline Tags ..................................185
D.26.Time and Date .................................185
D.27.Text Translation ................................186
D.28.Bar Tags .....................................186
D.28.1.Options .................................186
D.29.Other Tags ...................................187
E. Config file options 189
F. Menu Overview 195
G. User feedback 196
G.1. Bug reports ...................................196
G.1.1. Rules for submitting new bug reports ................196
G.2. Feature ideas ..................................196
G.2.1. Rules for submitting a new feature idea ...............196
G.2.2. Features we will not implement ....................197
H. Credits 198
I. Licenses 202
I.1. GNU Free Documentation License ......................202
I.2. The GNU General Public License .......................210
The Rockbox manual (version 3.13) Sansa c200v2 Series

Chapter 1. Introduction 11
1. Introduction
1.1. Welcome
This is the manual for Rockbox. Rockbox is an open source firmware replacement
for a growing number of digital audio players. Rockbox aims to be considerably more
functional and efficient than your device’s stock firmware while remaining easy to use
and customisable. Rockbox is written by users, for users. Not only is it free to use, it
is also released under the GNU General Public License (GPL), which means that it will
always remain free both to use and to change.
Rockbox has been in development since 2001, and receives new features, tweaks and
fixes each day to provide you with the best possible experience on your digital audio
player. A major goal of Rockbox is to be simple and easy to use, yet remain very
customisable and configurable. We believe that you should never need to go through a
series of menus for an action you perform frequently. We also believe that you should
be able to configure almost anything about Rockbox you could want, pertaining to
functionality. Another top priority of Rockbox is audio playback quality – Rockbox,
for most models, includes a wider range of sound settings than the device’s original
firmware. A lot of work has been put into making Rockbox sound the best it can, and
improvements are constantly being made. All models have access to a large number
of plugins, including many games, applications, and graphical “demos”. You can load
different configurations quickly for different purposes (e.g. a large font for in your car,
different sound settings for at home). Rockbox features a very wide range of languages,
and all supported models also have the ability to talk to you – menus can be voiced and
filenames spelled out or spoken.
1.2. Getting more help
This manual is intended to be a comprehensive introduction to the Rockbox firmware.
There is, however, more help available. The Rockbox website at http://www.rockbox.org/
contains very extensive documentation and guides written by members of the Rockbox
community and this should be your first port of call when looking for further help.
If you cannot find the information you are searching for on the Rockbox website there
are a number of support channels you should have a look at. You can try the Rockbox
forums located at http://forums.rockbox.org/. The mailing lists are another option, and
can be found at http://www.rockbox.org/mail/. From that page you can subscribe to
the lists and browse the archives. To search the list archives simply use the search field
that is located on the left side of the website. Furthermore, you can ask on IRC. The
The Rockbox manual (version 3.13) Sansa c200v2 Series

Chapter 1. Introduction 12
main channel for Rockbox is #rockbox on irc://irc.freenode.net. Many helpful developers
and users are usually around. Just join and ask your question (don’t ask to ask!) – if
someone knows the answer you’ll usually get an answer pretty quickly. More information
including IRC logs can be found at http://www.rockbox.org/irc/. We also have a web
client so that you can join the Rockbox IRC channel without needing to install additional
software onto your computer.
If you think you have found a bug please make sure it actually is a bug and is still
present in the most recent version of Rockbox. You should try to confirm that by using
the above mentioned support channels first. After that you can submit that issue to our
tracker. Refer to section G(page 196) for details on how to use the tracker.
1.3. Naming conventions and marks
We have some conventions (especially for naming) that are intended to be consistent
throughout this manual.
Manufacturer and product names are formatted in accordance with the standard rules
of English grammar, e.g. “Sansa playback is currently unsupported”. Manufacturer and
model names are proper nouns, and thus are written beginning with a capital letter.
This manual has some parts that are marked with icons on the margin to help you
finding important parts or parts you could skip. The following icons are used:
Note: This indicates a note. A note starts always with the text “Note”. In order to b
make finding notes easier each one is accompanied by an icon in the margin as here.
Notes are used to mark useful information that may help you to get the most out of
Rockbox.
Warning: This is a warning. In contrast to notes mentioned above, a warning should !
be taken more seriously. Whereas ignoring notes will not cause any serious damage,
ignoring warnings could cause serious damage to your player. You really should read the
warnings, especially if you are new to Rockbox.
This icon marks a section that is intended especially for the blind and visually im- ¸
paired. As they cannot read the manual in the same way sighted people do we have
added some additional descriptions. If you are not blind or visually impaired you can
probably completely skip these blocks. To make this easier, there is an icon shown in
the margin on the right.
Links to the wiki are abbreviated by the name of the wiki page. Those names are still
linked so you can simply follow them like any other link in this manual. If you want to
access a wiki page manually go to Zhttp://www.rockbox.org/wiki/ and type the page
name in the “Go” box at the top of the page. Links to wiki pages are also indicated by
the symbol Zin front of the page name.
The Rockbox manual (version 3.13) Sansa c200v2 Series

Chapter 2. Installation 13
2. Installation
Installing Rockbox is generally a quick and easy procedure. However before beginning
there are a few important things to know.
2.1. Before Starting
Supported hardware versions. The c200v2 Series is available in multiple versions, and
you need to make sure which you have by checking the Sandisk firmware version
number under Settings →Info. The v1 firmware is named 01.xx.xx, while the v2
firmware begins with 03. Make sure that you are following the instructions from
the correct manual.
DRM capability. It is possible that installation of the bootloader may lead to you per-
manently losing the ability to playback files with DRM.
USB connection. To transfer Rockbox to your player you need to connect it to your
computer. For manual installation/uninstallation, or should autodetection fail
during automatic installation, you need to know where to access the player. On
Windows this means you need to know the drive letter associated with the player.
On Linux you need to know the mount point of your player. On Mac OS X you
need to know the volume name of your player.
Note: The following steps require you to change the setting in Settings →USB b
Mode to MSC from within the original firmware.
2.2. Installing Rockbox
There are two ways to install Rockbox: automated and manual. The automated way is
the preferred method of installing Rockbox for the majority of people. Rockbox Utility
is a graphical application that does almost everything for you. However, should you
encounter a problem, then the manual way is still available to you.
There are two separate components which need to be installed in order to run Rockbox:
The Rockbox bootloader. The bootloader is the program that tells your player how
to load and start other components of Rockbox and for providing the dual boot
function. This is the component of Rockbox that is installed to the flash memory
of your Sansa.
The Rockbox manual (version 3.13) Sansa c200v2 Series

Chapter 2. Installation 14
The Rockbox firmware. Unlike the Sansa firmware, which runs entirely from flash mem-
ory, most of the Rockbox code is contained in a “build” that resides on your
player’s drive. This makes it easy to update Rockbox. The build consists of a
directory called .rockbox which contains all of the Rockbox files, and is located
in the root of your player’s drive.
Apart from the required parts there are some addons you might be interested in
installing.
Fonts. Rockbox can load custom fonts. The fonts are distributed as a separate package
and thus need to be installed separately. They are not required to run Rockbox
itself but a lot of themes require the fonts package to be installed.
Themes. The appearance of Rockbox can be customised by themes. Depending on your
taste you might want to install additional themes to change the look of Rockbox.
2.2.1. Automated Installation
To automatically install Rockbox, download the official installer and housekeeping tool
Rockbox Utility. It allows you to:
•Automatically install all needed components for using Rockbox (“Minimal Instal-
lation”).
•Automatically install all suggested components (“Complete Installation”).
•Selectively install optional components.
•Install additional fonts and themes.
•Install voice files and generate talk clips.
•Uninstall all components you installed using Rockbox Utility.
Prebuilt binaries for Windows, Linux and Mac OS X are available at the ZRockboxUtility
wiki page.
When first starting Rockbox Utility run “Autodetect”, found in the configuration
dialog (File →Configure). Autodetection can detect most player types. If autodetection
fails or is unable to detect the mountpoint, make sure to enter the correct values. The
mountpoint indicates the location of the player in your filesystem. On Windows, this is
the drive letter the player gets assigned, on other systems this is a path in the filesystem.
The Rockbox manual (version 3.13) Sansa c200v2 Series

Chapter 2. Installation 15
Choosing a Rockbox version
There are three different versions of Rockbox available from the Rockbox website: Re-
lease version, current build and archived daily build. You need to decide which one you
want to install and get the appropriate version for your player. If you select either “Min-
imal Installation” or “Complete Installation” from the “Quick Start” tab, then Rockbox
Utility will automatically install the release version of Rockbox. Using the “Installation”
tab will allow you to select which version you wish to install.
Release. The release version is the latest stable release, free of known critical bugs.
For a manual install, the current stable release of Rockbox is available at http:
//www.rockbox.org/download/.
Development Build. The development build is built at each change to the Rockbox
source code repository and represents the current state of Rockbox development.
This means that the build could contain bugs but most of the time is safe to use.
For a manual install, you can download the current build from http://build.rockbox.
org/.
Archived Build. In addition to the release version and the current build, there is also
an archive of daily builds available for download. These are built once a day from
the latest source code in the repository. For a manual install, you can download
archived builds from http://www.rockbox.org/daily.shtml.
Note: Because current and archived builds are development versions that change fre- b
quently, they may behave differently than described in this manual, or they may in-
troduce new (and potentially annoying) bugs. Unless you wish to try the latest and
greatest features at the price of possibly greater instability, or you wish to help with
development, you should stick with the release.
Please now go to section 2.2.5 (page 17) to complete the installation procedure.
2.2.2. Manual Installation
The manual installation method is still available to you, should you need or desire it by
following the instructions below. If you have used Rockbox Utility to install Rockbox,
then you do not need to follow the next section and can skip straight to section 2.2.5
(page 17)
Installing the firmware
1. Download your chosen version of Rockbox from the links in the previous section.
2. Connect your player to the computer via USB in MSC mode as described in the
manual that came with your player.
The Rockbox manual (version 3.13) Sansa c200v2 Series

Chapter 2. Installation 16
3. Take the .zip file that you downloaded and use the “Extract all” command of
your unzip program to extract the files onto your player.
Note: The entire contents of the .zip file should be extracted directly to the root of b
your player’s drive. Do not try to create a separate directory on your player for the
Rockbox files! The .zip file already contains the internal structure that Rockbox needs.
If the contents of the .zip file are extracted correctly, you will have a directory called
.rockbox, which contains all the files needed by Rockbox, in the main directory of your
player’s drive.
Installing the bootloader
In order to install the bootloader, you will need to download the following files:
•An original firmware (OF) from http://forums.sandisk.com/t5/User-guides-Firmware-
Software/c200-version2-Latest-Firmware-Installation-Instructions-03-02-05/td-p/34097
•The bootloader: http://download.rockbox.org/bootloader/sandisk-sansa/c200v2/
bootloader-c200v2.sansa
•The version of mkamsboot for your operating system from http://download.rockbox.
org/bootloader/sandisk-sansa/mkamsboot/
2.2.3. Bootloader installation from Windows
1. Create a folder called “rbinstall” on your desktop, and then extract the OF, the
bootloader and mkamsboot into it.
2. Open a new command prompt, and navigate to the “rbinstall” folder.
3. Run mkamsboot.exe, passing the name of the OF and bootloader files that you
downloaded, in addition to a name for the output file.
Code
mkamsboot.exe c200pa.bin bootloader-c200v2.sansa patched.bin
If mkamsboot.exe does not report success, then retry or abort.
4. Copy the output file (“patched.bin” in the example given above) to the root of
the device and rename it to the same name as the OF file you downloaded earlier
(“c200pa.bin” above).
The Rockbox manual (version 3.13) Sansa c200v2 Series

Chapter 2. Installation 17
2.2.4. Bootloader installation from Mac OS X and Linux
1. Create a folder called “rbinstall” in your home directory, and then extract the OF,
the bootloader and mkamsboot into it.
2. Open a new terminal, and navigate to the “rbinstall” folder.
3. Run mkamsboot, passing the name of the OF and bootloader files that you down-
loaded, in addition to a name for the output file.
Code
./mkamsboot c200pa.bin bootloader-c200v2.sansa patched.bin
If mkamsboot does not report success, then retry or abort.
4. Copy the output file (“patched.bin” in the example given above) to the root of
the device and rename it to the same name as the OF file you downloaded earlier
(“c200pa.bin” above).
2.2.5. Finishing the install
Safely eject the device, unplug USB and wait for the firmware update to finish. Don’t
try to power off the device, it will shutdown by itself after a minute.
2.2.6. Enabling Speech Support (optional)
If you wish to use speech support you will also need a voice file. Voice files allow Rockbox
to speak the user interface to you. Rockbox Utility can install an English voice file, or
you can download it from http://www.rockbox.org/daily.shtml and unzip it to the root
of your player. Rockbox Utility can also aid you in the creation of voice files with
different voices or in other languages if you have a suitable speech engine installed on
your computer. Voice menus are enabled by default and will come into effect after a
reboot. See section 8.10 (page 73) for details on voice settings. Rockbox Utility can also
aid in the production of talk files, which allow Rockbox to speak file and folder names.
2.3. Running Rockbox
When you turn the unit on, Rockbox should load.
2.4. Updating Rockbox
Rockbox can be easily updated with Rockbox Utility. You can also update Rockbox
manually – download a Rockbox build as detailed above, and unzip the build to the root
directory of your player as in the manual installation stage. If your unzip program asks
you whether to overwrite files, choose the “Yes to all” option. The new build will be
The Rockbox manual (version 3.13) Sansa c200v2 Series

Chapter 2. Installation 18
installed over your current build.
The bootloader only changes rarely, and should not normally need to be updated.
Note: If you use Rockbox Utility be aware that it cannot detect manually installed b
components.
2.5. Uninstalling Rockbox
Note: The Rockbox bootloader allows you to choose between Rockbox and the original b
firmware. (See section 3.1.3 (page 20) for more information.)
2.5.1. Automatic Uninstallation
You can uninstall Rockbox automatically by using Rockbox Utility. If you installed
Rockbox manually you can still use Rockbox Utility for uninstallation but will not be
able to do this selectively.
2.5.2. Manual Uninstallation
Copy an unmodified original firmware to your player, and then reboot into the Sandisk
firmware. See section 3.1.3 (page 20) for more information.
If you wish to clean up your disk, you may also wish to delete the .rockbox directory
and its contents. Turn the Sansa off. Turn the player back on and the original Sansa
software will load.
2.6. Troubleshooting
“File Not Found” If you receive a “File Not Found” from the bootloader, then the
bootloader cannot find the Rockbox firmware. This is usually a result of not
extracting the contents of the .zip file to the proper location, and should not
happen when Rockbox has been installed with Rockbox Utility.
To fix this, either install Rockbox with the Rockbox Utility which will take care
of this for you, or recheck the Manual Install section to see where the files need to
be located.
The Rockbox manual (version 3.13) Sansa c200v2 Series

Chapter 3. Quick Start 19
3. Quick Start
3.1. Basic Overview
3.1.1. The player’s controls
Throughout this manual, the buttons on the player are labelled according to the
picture above. Whenever a button name is prefixed by “Long”, a long press of approx-
imately one second should be performed on that button. The buttons are described in
detail in the following paragraph. Additional information for blind users is available on ¸
the Rockbox website at ZBlindFAQ.
Hold the player with the buttons on the right and the screen on the left. On the right
side of the unit, there is a series of four connected buttons that form a square. The
four sides of the square are the Play,Submenu,Left and Right buttons, respectively.
Inside the square formed by these four buttons is the Select button. At the bottom
right corner of the square is a small separate button, the Power button.
Moving clockwise around the outside of the unit, on the top are the Volume Up and
Volume Down buttons, which control the volume of playback. The buttons can be
distinguished by a sunken triangle on the Volume Down button, and a raised triangle
on the Volume Up button. To the right of the volume buttons on the top of the unit is
the slot for inserting flash memory cards. On the right side of the unit is the connector
for the USB cable. At center of the bottom of the player is the Rec button. To the left
of the Rec button is the Hold switch. Moving this switch to the right activates hold
mode, in which none of the other buttons have any effect. On the lower left side of the
unit is the headphone socket. Immediately above the headphone socket is a lanyard loop
and the microphone.
The Rockbox manual (version 3.13) Sansa c200v2 Series

Chapter 3. Quick Start 20
3.1.2. Turning the player on and off
To turn on and off your Rockbox enabled player use the following keys:
Key Action
Power Start Rockbox
Long Power Shutdown Rockbox
On shutdown, Rockbox automatically saves its settings.
If you have problems with your settings, such as accidentally having set the colours to
black on black, they can be reset at boot time. See the Reset Settings in section 13.3.3
(page 160) for details.
In the unlikely event of a software failure, hardware poweroff or reset can be performed
by holding down Power until the player shuts off or reboots.
3.1.3. Starting the original firmware
Rockbox has a dual-boot feature. To boot into the original firmware, press and hold the
Left button while turning on the player.
3.1.4. Putting music on your player
Note: Due to a bug in some OS X versions, the player can not be mounted, unless the b
USB HID feature is disabled. See section 8.5.6 (page 66) for more information.
With the player connected to the computer as an MSC/UMS device (like a USB
Drive), music files can be put on the player via any standard file transfer method that
you would use to copy files between drives (e.g. Drag-and-Drop). Files may be placed
wherever you like on the player, but it is strongly suggested NOT to put them in the
/.rockbox folder and instead put them in any other folder, e.g. /,/music or /audio.
The default directory structure that is assumed by some parts of Rockbox (album art
searching, and missing-tag fallback in some WPSes) uses the parent directory of a song
as the Album name, and the parent directory of that folder as the Artist name. WPSes
may display information incorrectly if your files are not properly tagged, and you have
your music organized in a way different than they assume when attempting to guess the
Artist and Album names from your filetree. See section C(page 170) for the requirements
for Album Art to work properly. See section B.1 (page 164) for a list of supported
audio formats.
3.1.5. The first contact
After you have first started the player, you’ll be presented by the Main Menu. From
this menu you can reach every function of Rockbox, for more information (see section 5.1
The Rockbox manual (version 3.13) Sansa c200v2 Series
