Rokit G3 POWERED SERIES User manual


ROKIT G3 POWERED SERIES
NEAR FIELD STUDIO MONITORS
USER GUIDE ∙ GUIDE DE L'UTILISATEUR ∙ GUÍA DEL USUARIO

1

SAFETY INSTRUCTIONS
1. Read instructions - All the safety and operating instructions should be
read before the product is operated.
2. Retain instructions - The safety and operating instructions should be
retained for future reference.
3. Heed Warnings - All warnings on the product and in the operating
instructions should be adhered to.
4. Follow Instructions - All operating and use instructions should be
followed.
5. Cleaning - Unplug this product from the wall outlet before cleaning. Do
not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
6. Attachments - Do not use attachments not recommended by the
product manufacturer as they may cause hazards.
7. Water and Moisture - Do not use this product near water-for example,
near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement;
or near a swimming pool; and the like.
8. Accessories - Do not place this product on an unstable cart, stand,
tripod, bracket, or table. The product may fall, causing serious injury to a
child or adult and serious damage to the product. Use only with a cart,
stand, tripod, bracket, or table recommended by the manufacturer, or sold
with the product. Any mounting of the product should follow the
manufacturer’s instructions, and should use a mounting accessory
recommended by the manufacturer.
9. Cart - A product and cart combination should be
moved with care. Quick stops, excessive force, and
uneven surfaces may cause the product and cart
combination to overturn.
10. Ventilation - Slots and openings in the cabinet
are provided for ventilation to ensure reliable
operation of the product and to protect it from overheating. These
openings must not be blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in installation such as a
bookcase or rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
11. Power Sources - This product should be operated only from the type of
power source indicated on the marking label and connected to a MAINS
socket outlet with a protective earthing connection. If you are not sure of
the type of power supply to your home, consult your product dealer or local
power company.
12. Power-Cord Protection - Power-supply cords should be routed so that
they are not likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the product.
13. Mains Plug - Where the mains plug or an appliance coupler is used as
the disconnect device, the disconnect device shall remain readily operable.
14. Lightning - For added protection for this product during a lightning
storm, or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna or cable system.
This will prevent damage to the product due to lightning and power-line
surges.
15. Overloading - Do not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of fire or electric shock.
16. Flame Sources - No naked flame sources, such as lighted candles,
should be placed on the product.
17. Object and Liquid Entry - Never push objects of any kind into this
product through openings as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock. Never spill liquid
of any kind on the product.
18. Loudspeakers - Excessive sound pressure from loudspeakers can cause
hearing loss.
19. Damage Requiring Service - Unplug this product from the wall outlet
and refer servicing to qualified service personnel under the following
conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to
restore the product to its normal operation.
e. If the product has been dropped or damaged in any way.
f. When the product exhibits a distinct change in performance-this
indicates a need for service.
20. Replacement Parts - When replacement parts are required, be sure the
service technician has used replacement parts specified by the
manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other
hazards.
21. Safety Check - Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to determine
that the product is in proper operating condition.
WARNING
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
THE EQUIPMENT MUST BE CONNECTED TO AN EARTHED MAINS SOCKET-
OUTLET.
CAUTION REGARDING PLACEMENT
To maintain proper ventilation, be sure to leave a space around the unit
(from the largest outer dimensions including projections) than is equal to,
or greater than shown below.
Top,Bottom, Front, Rear, Left, Right Sides: 10 cm
CAUTION
Changes or modifications to this equipment not expressly approved by KRK
SYSTEMS for compliance could void the user’s authority to operate this
equipment.
CAUTION
To prevent electric shock, match wide blade of plug to wide slot, fully insert.
CAUTION
Marking and rating plate can be found at the rear panel of the apparatus.
WARNING
To reduce the risk of fire or electric shock, do not expose this apparatus to
rain or moisture.
The apparatus shall not be exposed to dripping or splashing and that no
objects filled with liquids, such as vases, shall be placed on apparatus.
Mains plug is used as disconnect device and it should remain readily
operable during intended use. In order to disconnect the apparatus from
the mains completely, the mains plug should be disconnected from the
mains socket outlet completely.
Battery shall not be exposed to excessive heat such as sunshine, fire or the
like.
CAUTION
An appliance with a protective earth terminal should be connected to a
mains outlet with a protective earth connection.
IF IN DOUBT CONSULT A COMPETENT ELECTRICIAN.
NOTES ON ENVIRONMENTAL PROTECTION
At the end of its useful life, this product must not be disposed of with
regular household waste but must be returned to a collection point for the
recycling of electrical and electronic equipment. The symbol on the
product, user’s manual and packaging point this out.
The materials can be reused in accordance with their markings. Through re-
use, recycling of raw materials, or other forms of recycling of old products,
you are making an important contribution to the protection of our
environment.
Your local administrative office can advise you of the responsible waste
disposalpoint.

2

QUICK SETUP
Determine the audio input signal
that will be used with the studio monitors
and connect the audio cable (not included) to
the appropriate input. Typical connections
direct to a computer or DJ gear will use the
unbalanced RCA input. Connection to an
audio interface or mixer will use either a
balanced ¼” TRS or XLR input.
Set the volume on the input device (mixer,
audio interface or computer) to minimum
level.
The HF and LF LEVEL ADJUST are set at “0dB”
(factory setting). The VOLUME is set at “+6dB”
(factory setting).
Set the POWER switch to ‘ON’ position. Play
an audio track and slowly bring up the volume on
the input device (mixer, audio interface or
computer) to an acceptable listening level.
Set the POWER switch to ‘OFF’. Connect the AC power cord
(provided) to the AC inlet socket on the studio monitor and power outlet.
Warning: Incorrect AC voltage may damage the studio
monitor. Make sure the AC power outlet matches the studio
monitor (should state 100V~, 110-120V~ or 220-240V~.
STEP 1
STEP 2
STEP 3

3

INTRODUCTION
Welcome to the new KRK Systems Generation 3 ROKIT studio monitor, the world’s most
respected manufacturer of studio reference monitors. In our state of the art design facility,
we create products that deliver a natural and balanced spectral response with low
distortion and superior imaging. With KRK Systems studio monitors, recording engineers
and artists hear every nuance of the audio being reproduced.
SYSTEM CONTROLS
VOLUME - Volume knob sets the input system gain. The usual scenario
is to set the knob at the maximum setting (+6dB as shipped from the
factory) and adjust the input level from your audio source. Use the
volume knob to match the left and right studio monitors.
HF ADJUSTMENT - The High Frequency adjustment may be used to
tailor a listening style preference. The factory setting is flat (knob is in
the 0dB position).
LF ADJUSTMENT – The Low Frequency adjustment may be used to
adjust for the room acoustics and personal preference. Room acoustics
may dictate which type of adjustment you need to make to retain the
proper frequency response from the studio monitor. For example,
placement near a wall or corner will boost the low frequencies.
Location LF Setting Technical Term
Large Room +2dB Open Space
Normal 0dB (flat) Full-Room
Against the Wall -1dB Half-Room
Corner of a Room -2dB Quarter-Room
Note that results may vary. The factory setting is flat (knob is in the 0dB position).
BALANCED INPUT - The XLR & TRS input jack is connected to
your audio equipment outputs, such as a mixing console or
audio interface. Only connect one input source at a time.
UNBALANCED INPUT - The RCA input jack is connected to your audio
equipment outputs, such as an audio interface, computer, DJ gear and
mobile device. Only connect one input source at a time.
AC INPUT INLET SOCKET & FUSE HOLDER - A standard IEC-type AC
Inlet Socket is used to provide power to the studio monitor. Below the
socket is a fuse holder that contains two fuses (one spare).
NOTE - The studio monitors will take break-in time to achieve optimum sonic
performance. Under moderate use, play a favorite album between 15 to 25 hours.

4

SYSTEM SETUP
Overall system setup is crucial to avoid unnecessary room acoustic interaction. A
room’s natural acoustics may alter the sound level at various frequencies due to
abnormal dampening or reflections. Follow the checklist below for more details.
9 The system setup (studio monitors and work table) should be placed within the
front 1/3 of the room. Doing so will reduce reflection buildup of peak frequencies.
9 The left and right sides of the system setup should be centered an equal distance
from the left and right walls. This will produce even mid and low frequency
response and preserve stereo imaging.
9 Avoid a listening position (your ears) that is closer than 1 meter (3 feet) from any
wall. Also avoid large objects (such as lamps or decorations) near the studio
monitor and listening position.
9 Diffusers and absorption material in the corners and back of a room will help
remove room interaction by preventing reflections.
9 Carpeting will help prevent reflections from hard floor surfaces.
9 Studio monitor isolators (foam or rubber pads) will help remove low frequency
coupling between the stands and desk. Low frequency coupling will cause the
stand or desk to vibrate causing unwanted sounds.
9 A low noise floor (no outside interference from refrigerators or fans) is important
to prevent the masking of low frequency detail. Rattles due to studio monitor
playback should be removed as well.
W
ithin the system setup, the studio monitors and listening placement should be
positioned in a near field configuration as follows:
The left and right studio monitors should be
approximately 1 to 1.5 meters (3 to 5 feet) apart and
directed at a 60 degree angle towards the listening
location. Measure the distance between the left and
right studio monitors and note the listening position is
equal distance to both sides. This will form an
equilateral triangle. It is important that both left and
right studio monitors are level matched.
The ROKIT is a two-way studio monitor with a tweeter
(producing high frequencies) and a woofer (producing
mid and low frequencies) in one enclosure. In between
the tweeter and woofer is the acoustic axis point
where the full frequency range comes together. The
ideal location for the acoustic axis point is located at
ear level in the listening position. It is acceptable to
angle the studio monitors so the acoustic axis is in the
correct direction.

5

Check another input on the ROKIT. This will require a different cable. For example, if you
have a mixer connected to a ROKIT with a XLR or ¼” TRS cable, try another route and
connect the mixer to the ROKIT with an RCA cable. If there is still no sound, please contact
customer service.
Check that the cable used between the audio source and ROKIT is being used in the correct
application and that it is fully inserted into the socket. For additional information on signal
cables and connections, visit www.krksys.com. Inspect the cable for any frays or visible
damage. Often a bend near the plug end will cause damage to the cable and has to be
replaced. The ROKIT’s XLR and TRS will accept a balanced signal. If you are connected with a
unbalanced signal to the ROKIT through the XLR and TRS, be sure that PIN2 is the signal and
PIN1 & 3 are tied together at the source end.
Check that the audio source is indeed playing an audio signal to both left and right channels
and the sound is not bad. For example, verify audio is heard on the built-in speakers of a
laptop. Or connect headphones to the headphone jack of the mixer or audio interface. If
there is still no sound, than the audio source is the problem. Consult the audio source’s
literature for more information.
Check the audio source. The audio source can range from a laptop computer to a mixer or
audio interface. On all audio source devices, verify if there is a mute feature and confirm it is
not active. Also check if there is a balance control and that it is set to middle. Play a
continuous audio signal, such as a loop or song, and slowly increase the volume on the
audio source. If the ROKIT still has no sound or bad sound, follow the checklist:
A ROKIT pair contains a left and right side. Confirm which ROKIT produces no sound. Verify
that both left and right ROKIT’s have identical knob settings. Then simply move the audio
signal cable from the working ROKIT to the non-working ROKIT. If the non-working ROKIT
now produces sound, the previously used cable is the problem and needs to be replaced. If
there is still no sound, proceed with the next step.
Verify there is power to the ROKIT. The power switch needs to be in the ‘on’ position. The
power cord should be firmly placed into the IEC socket on the rear of the ROKIT and into the
AC outlet. The KRK logo on the front of the ROKIT will illuminate when the power switch is
‘on’. The ROKIT can be in an auto-mute condition. The auto-mute engages after 30 minutes
of no activity. To take the ROKIT out of the mute condition, simply play audio to the input of
the ROKIT. If the KRK logo does not illuminate, see box on the right. Or proceed with the
box below.
Basic Trouble Shooting – If you have a problem and are using a pair of ROKITs, check
whether both ROKITs have the problem. If both ROKITs have the problem it is likely not the
speakers. Focus on your setup.

6

Verify the ROKIT is the correct model for
the AC power outlet. The ROKIT is
available in different models for regions
that have 100VAC, 110-120VAC, and
220-240VAC power outlets. A mismatch
can cause damage to the ROKIT and
should be replaced with the correct
model.
A ROKIT pair contains a left and right
side. Confirm which ROKIT has no
power. Move the power cable from the
working ROKIT to the ROKIT with no
power. If the no power ROKIT is now
‘on’, the previously used power cable is
the problem and needs to be replaced.
If there is still no power, follow the
checklist.
Check to see if the AC outlet is
operating. Remove the power cord and
replace with a known functional
electronic device such as a lamp or
charger for a mobile device.
Check that the rear panel of the ROKIT is
not hot. Usage in direct sunlight, a hot
room with poor airflow or excessive use
at maximum levels may cause the unit
to overheat and go into thermal
protection. Turn off the power and
allow the ROKIT to cool down. If this is
not the problem, contact customer
service.
Check that the fuse has not blown.
Remove all power cords and signal
cables from the ROKIT. With a flat-head
screwdriver, remove the fuse cover and
inspect the fuse (the filament wire
should not be broken). If the fuse is
blown, replace it with the spare fuse
located in the fuse holder. If the fuse
blows again, contact customer service.
…there is sound and it is bad (excessive
hum and terrible hiss).
A ROKIT pair contains a left and right side.
Confirm which ROKIT has the bad sound.
Verify that both left and right ROKIT’s have
identical knob settings. Then simply move
the audio signal cable from the working
ROKIT to the bad sound ROKIT. If the bad
sound ROKIT produces good sound, the
previously used cable is the problem and
needs to be replaced. If there is still bad
sound, proceed with the next step.
Disconnect the audio signal cable from the
rear panel of the ROKIT. With the ROKIT
powered on, listen for the bad sound (i.e. a
slight hiss or hum). If the bad sound is no
longer there, the problem is not the ROKIT
and the audio source should be checked.
Signal cables should not be mixed with
power cables. If the ROKIT still has bad
sound, follow the checklist below and
review the “Check the audio source” box.:
Check that all audio equipment is
connected to the same ground point. This
means both studio monitors and audio
source (laptop, mixer, audio interface) are
connected to the same AC outlet ground
point.
Check that the AC outlet is not connected
to any electronics that can induce noise
into the power line (such as light dimmers,
neon signs, motors or climate control
devices such as heaters, air conditioners or
humidifiers). These devices should not be
using the same AC circuit as the audio
equipment. If the problem persists, look
into adding AC conditioning equipment to
clean the noise from the AC outlet or
contact customer service.

7

WARRANTY
Thank you for choosing one of KRK Systems (a Gibson family of brands) product.
Your satisfaction is extremely important to us. We proudly stand behind the quality of our work and appreciate that you put your trust in us.
Registering your merchandise will help us guarantee that you are kept up to date on our latest advances.
FOR MERCHANDISE PURCHASED FROM AN AUTHORIZED GIBSON PRO AUDIO DISTRIBUTOR OUTSIDE OF THE US, PLEASE CONTACT THE
DISTRIBUTOR FROM WHOM YOU PURCHASED YOUR MERCHANDISE FOR TO REGISTER YOUR WARRANTY AND FOR HANDLING AND
RESOLUTION OF ALL WARRANTY-RELATED ISSUES.
Gibson Pro Audio Warranty - If at any time your Gibson Pro Audio product malfunctions as a result of faulty materials or workmanship, Gibson
Pro Audio or one of Gibson Pro Audio’s Authorized Service Centers in the US will repair the defect(s) or replace the merchandise, as it deems
appropriate at its sole discretion.
Warranty Period (from date of Purchase as listed on the Bill of Sale):
Three (3) years from all studio monitors. One (1) year all headphones, computer audio devices, including room correction devices.
Gibson will warrant all replacement parts and repairs for ninety (90) days from the date of original shipment. In the unlikely event that your
merchandise is destroyed, lost or damaged beyond repair while in the possession of Gibson or one of Gibson Pro Audio’s Authorized Service
Centers for repair, Gibson will replace that merchandise with one of the same or most similar style of a value not in excess of the original
purchase price of your merchandise. Any insurance covering the merchandise, including but not limited to collector's value insurance, must be
carried by owner at owner's expense. For the fastest and safest merchandise return, please use the original shipping carton and packaging
materials. Gibson cannot be responsible for any damages incurred during the shipping process due to poor or inadequate packing.
THIS WARRANTY IS EXTENDED TO THE ORIGINAL RETAIL PURCHASER ONLY AND MAY NOT BE TRANSFERRED OR ASSIGNED TO SUBSEQUENT
OWNERS. IN ORDER TO VALIDATE YOUR WARRANTY, AND AS A CONDITION PRECEDENT TO WARRANTY COVERAGE HEREUNDER, YOU MUST
REGISTER YOUR WARRANTY WITHIN FIFTEEN (15) DAYS FOLLOWING THE ORIGINAL DATE OF PURCHASE.YOUR PROOF OF PURCHASE OR SALES
RECEIPT MUST ACCOMPANY ALL REQUESTS FOR WARRANTY COVERAGE.
This warranty is subject to the following limitations: THIS WARRANTY DOES NOT COVER: 1. Any merchandise that has been altered or modified
in any way or upon which the serial number has been tampered with or altered. 2. Any merchandise whose warranty card has been altered or
upon which false information has been given. 3. Any merchandise that has been damaged due to misuse, negligence, or improper operation.
4. Any merchandise that has been damaged by accident, flood, fire, lightening, or other acts of God. 5. Shipping damage of any kind.
6. Any merchandise that has been subjected to extremes of humidity or temperature.7. Any merchandise that has been purchased from an
unauthorized dealer, or upon which unauthorized repair or service has been performed.
GIBSON MAKES NO OTHER EXPRESS WARRANTY OF ANY KIND WHATSOEVER. ALL IMPLIED WARRANTIES, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, EXCEEDING THE SPECIFIC PROVISIONS OF THIS WARRANTY ARE HEREBY
DISCLAIMED AND EXCLUDED FROM THIS WARRANTY. SOME STATES AND/OR COUNTRIES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
IMPLIED WARRANTIES SO THAT THE ABOVE MAY NOT APPLY TO YOU.
GIBSON SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT CONSEQUENTIAL, INCIDENTAL OR OTHER SIMILAR DAMAGES SUFFERED BY THE
PURCHASER OR ANY THIRD PARTY, INCLUDING WITHOUT LIMITATION, DAMAGES FOR LOSS OF PROFITS OR BUSINESS OR DAMAGES RESULTING
FROM USE OR PERFORMANCE OF THE MERCHANDISE, WHETHER IN CONTRACT OR IN TORT, EVEN IF GIBSON OR ITS AUTHORIZED
REPRESENTATIVE HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, AND GIBSON SHALL NOT BE LIABLE FOR ANY EXPENSES, CLAIMS,
OR SUITS ARISING OUT OF OR RELATING TO ANY OF THE FOREGOING.
FOR MERCHANDISE PURCHASED FROM AN AUTHORIZED GIBSON PRO AUDIO DISTRIBUTOR OUTSIDE OF THE US, PLEASE CONTACT THE
DISTRIBUTOR FROM WHOM YOU PURCHASED YOUR MERCHANDISE FOR THE HANDLING AND RESOLUTION OF ALL WARRANTY ISSUES. FOR
THESE PURCHASES, THE ABOVE-DESCRIBED WARRANTY IS NOT APPLICABLE.
Warranty Service outside the United States: To initiate a warranty repair, please contact the Authorized Gibson Pro Audio distributor from whom
you purchased your merchandise, and follow the distributor’s return/warranty policy.
Warranty Service for Merchandise Purchased from an Authorized Gibson Pro Audio Dealer in the U.S: In the event of malfunction of your Gibson
Pro Audio merchandise, the Dealer or Owner must call Customer Service @ 1-800-4GIBSON (1-800-444-2766) and obtain a Return Authorization
number from the customer service agent. No merchandise may be returned to Gibson without such prior Return Authorization, and the Return
Authorization number must be written on the outside of the shipping package. The Customer Service agent will provide the address and
additional shipping instructions. Owner must ship the merchandise, freight, and insurance pre-paid to the address provided by the customer
service representative. Only Authorized Gibson Pro Audio Service Centers may perform warranty service and any service performed by
unauthorized persons will void this warranty. Gibson disclaims liability for defects or damage caused by services performed by unauthorized
persons or non-warranty service not performed by Gibson or an Authorized Gibson Pro Audio Service Center.
When contacting Gibson, you must include a complete written description of the malfunction of the merchandise. Following its inspection of
merchandise upon its arrival, Gibson or the Authorized Gibson Pro Audio Service Center will advise you or your dealer of the approximate date
of completion. The repaired merchandise or part will be returned to you or your dealer, freight collect insured. No representative or other
person is authorized to assume for Gibson any liability except as stated in this warranty. This warranty gives you specific rights which vary from
state to state or from country to country.
For further information, write: Customer Service Dept., Gibson Customer Service 309 Plus Park Blvd. Nashville, TN 37217
Or call: 1-800-4GIBSON (1-800-444-2766), e-mail: [email protected]

22

This document is copyright protected. No part of this manual may be copied or reproduced in
any form without prior written consent from GIBSON BRANDS, INC.. GIBSON BRANDS, INC. shall
not be liable for operational, technical, or editorial errors/omissions made in this document.
ROKIT G3 SERIES USER GUIDE REV B © 2013 GIBSON BRANDS, INC.

23

®
