Rosewill RNX-N400LX User manual

Quick Installation Guide
Wireless Router RNX-N400LX
Default IP Address: 192.168.1.254
Default Login Name: admin
Default Password: guest
(Please change Default Login Name and Password once you entered into the Management Page, and keep a record of your new Login
Name and Password)

Quick Installation Guide
Wireless Router RNX-N400LX
1
Connect the supplied power-adapter to the power inlet port and connect it to a wall outlet. Then,
the router automatically enters the self-test phase. During self-test phase, RNX-N400LX’s Power
LED will blink briefly, and then will be lit continuously to indicate that this product is in normal
operation.
CHECK BEFORE YOU PROCESS:
A standard CD-ROM drive
Internet connection should be setup & ready to use (ADSL or cable modem ready to
connect).
Modem must provide RJ45 port to connect with RNX-N400LX.
Microsoft Windows compatible PC/Notebook with UPnP enabled network adapter
CAT 5 network cable(s), RJ45 port on PC/Notebook.
STEP 1
Place the RNX-N400LX to the best optimum transmission location. The best transmission
location for your RNX-N400LX is usually at the geographic center of your wireless network,
with line of sign to all of your mobile stations.
STEP 2
Connect RNX-N400LX to your wired network. Connect the Ethernet WAN interface of
RNX-N400LX by category 5 Ethernet cable to your switch/ hub/ xDSL modem or cable
modem. A straight-through Ethernet cable with appropriate cable length is needed.
RNX-N400LX and Modem Rear View
(WAN Port and LAN port Connection diagram between Wireless Router, and Modem)
STEP 3
Plug the DC power to the RNX-N400LX. Use only the AC/DC power adapter supplied with
the RNX-N400LX; it may cause damage by using a different voltage power adapter.

Quick Installation Guide
Wireless Router RNX-N400LX
2
RNX-N400LX Rear View
STEP 4
Connect Ethernet cable between your PC/Notebook LAN port & one of the 4
available LAN ports on RNX-N400LX.
RNX-N400LX, PC, and Modem Rear View
(WAN Port and LAN port Connection diagram between PC. Wireless Router and Modem)
STEP 5
Connect to your Web browser (please make sure your web browser can support
Java), and type in http://192.168.1.254 in the URL. You will be prompt to enter
login name and password. Please use the default login and password for your first
enter. (Login: admin; password: guest)
STEP 6

Quick Installation Guide
Wireless Router RNX-N400LX
3
When Login to Web Management page, please click Setup Wizard, and follow the
steps.
Once complete, you should be ready to surf!
Thank you for supporting Rosewill.
Note:
1. Please update the Wireless Adapter’s Firmware of your Notebook and PC to the latest version
to ensure the best connection.
2. If all setup steps are complete, Please follow the steps below to make sure the RNX-N400LX
is connected with the modem.
Configure your settings correctly i.e. DHCP, SSID, Password.
Save your settings.
Reboot your Rosewill Router and your ADSL/Cable modem.
If rebooting your ADSL/Cable modem doesn’t work, please call your ADSL/Cable
provider and ask them to reset and restart your ADSL/Cable Modem. (This is due to
some newer ADSL/Cable modems are now equipped with a battery for when power is
lost, i.e. Time Warner Cable Modems, will keep the modem on and connected. Due to
the ADSL/Cable modem not assigning the correct DHCP information, the Rosewill
Routers can not work correctly and assign a DHCP to the client computers.)
