Rotel RCX-1500 User manual

Owner’s Manual
Manuel de l’utilisateur
Bedienungsanleitung
Manual de Instrucciones
Gebruiksaanwijzing
Manuale di istruzioni
Instruktionsbok
àÌÒÚÛ͈Ëfl ÔÓθÁÓ‚‡ÚÂÎfl
RCX-1500
Stereo Compact Disc Receiver
Register your product at
http://rotelradio.com
FM
USB
DAB i- R AD IO
CD
AUX 1 AUX 2
NETWORK
RCX- 1500
PHONES
STANDBY
QUEUE SELECT
REP LYBACK NEXT
PREV
EJECT

2RCX-1500 Stereo Compact Disc Receiver
Rotelproductsaredesignedtocomplywithinternational
directives on the Restriction of Hazardous Substances
(RoHS) in electrical and electronic equipment and
the disposal of Waste Electrical and Electronic
Equipment (WEEE). The crossed wheelie bin symbol
indicates compliance and that the products must be
appropriately recycled or processed in accordance
with these directives.
FM
USB
DAB i-RADIO
CD
AUX1 AUX 2
NETWORK
RCX-1500
PHONES
STANDBY
QUEUE SELEC T
REPLYBACK NEXT
PREV
EJECT
DAB
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. DANGER: Visible laser
radiation when open and
interlock failed or bypassed.
Avoid direct exposure to beam.
3. CAUTION: Do not open the top cover. There are no user
serviceable parts inside the player; leave all servicing to
qualified service personnel.
WARNING!
To reduce the risk of electrical shock, fires, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose the unit to rain or moisture.
3. Do not touch the power cord or plug with wet hands.

3
English
WARNING: There are no user serviceable parts inside. Refer all servicing to qualified service
personnel.
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to moisture or water.
Do not expose the unit to dripping or splashing. Do not place objects filled with liquids, such as vases,
on the unit. Do not allow foreign objects to get into the enclosure. If the unit is exposed to moisture,
or a foreign object gets into the enclosure, immediately disconnect the power cord from the wall. Take
the unit to a qualified service person for inspection and necessary repairs.
Read all the instructions before connecting or operating the component.
Keep this manual so you can refer to these safety instructions.
Heed all warnings and safety information in these instructions and on the product itself. Follow all
operating instructions.
Clean the enclosure only with a dry cloth or a vacuum cleaner.
Do not use this unit near water.
You must allow a minimum 10 cm or 4 inches of unobstructed clearance around the
unit.
Do not place the unit on a bed, sofa, rug, or similar surface that could block the ventilation openings.
If the unit is placed in a bookcase or cabinet, there must be ventilation of the cabinet to allow proper
cooling.
Keep the component away from radiators, heat registers, stoves, or any other appliance that
produces heat.
WARNING: The rear panel power cord connector is the mains power disconnect device. The apparatus
must be located in an open area that allows access to the cord connector.
The unit must be connected to a power supply only of the type and voltage specified on the rear panel.
(USA: 120 V/60Hz, EC: 230V/50Hz)
Connect the component to the power outlet only with the supplied power supply cable or an exact
equivalent. Do not modify the supplied cable. A polarized plug has two blades, with one wider than
the other. A grounding plug has two blades plus a third grounding prong. These are provided for
your safety. Do not defeat grounding and/or polarization safety provisions. If the supplied plug does
not fit your outlet, please consult an electrician for replacement of the obsolete outlet. Do not use
extension cords.
The main plug of the power cord set is a disconnect device of the apparatus. In order to completely
disconnect the apparatus from the supply mains, the main plug of the power cord set should be
unplugged from the mains (AC) outlet. The stand-by LED indicator will not be lit up to show the power
cord is unplugged. The disconnect device shall remain readily operable.
Do not route the power cord where it will be crushed, pinched, bent, exposed to heat, or damaged
in any way. Pay particular attention to the power cord at the plug and where the cord exits the back
of the unit.
Main plug is used as the main disconnect device and shall remain ready accessible.
The power cord should be unplugged from the wall outlet during a lightning storm or if the unit is to
be left unused for a long period of time.
This apparatus shall be connected to a main socket outlet with a protective earth connection.
Use only accessories specified by the manufacturer.
Use only with a cart, stand, rack, bracket or shelf system recommended by Rotel. Use caution
when moving the unit in a stand or rack to avoid injury from a tip-over.
Use Class 2 wiring for speaker connections to ensure proper installation and minimize the risk of
electrical shock.
Immediately stop using the component and have it inspected and/or serviced by a qualified service
agency if:
• Thepowersupplycordorplughasbeendamaged
• Objectshavefallenorliquidhasbeenspilledintotheunit
• Theunithasbeenexposedtorain
• Theunitshowssignsofimproperoperation
• Theunithasbeendroppedordamagedinanyway
The batteries in remote control shall not be exposed to excessive heat such as sunshine, fire or the
like.
Important Safety InstructionsNotice
The COMPUTER I/O connection should be handled by authorized persons only.
FCC Information
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
•Reorientorrelocatethereceivingantenna.(TV,radio,etc.)
•Increasetheseparationbetweentheequipmentandreceiver
•Connecttheequipmenttoanoutletoncircuitdifferentfromthattowhichthereceiveris
connected.
•Consultthedealeroranexperiencedradio/TVtechnicianforadditionalhelp.
Caution
This device complies with part 15 of the FCC Rules. Operation is subject to the following to
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE TO CATV SYSTEM INSTALLER: Call the CATV system or antenna installer’s attention to
Article 820-40 of the NEC. This provides guidelines for proper grounding and, in particular , specifies
that the cable ground shall be connected to the grounding system of the building, as close to the
point of cable entry as practical. See installation diagram.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against interference in a residential installation. This equipment generates and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause interference to radio or TV communications. There is no guarantee that interference will
not occur in a particular installation. If this equipment does cause interference to radio or television
reception, which can be determined by turning the equipment off and on, try to correct the
interference by one or more of the following measures:
•Reorientorrelocatethereceivingantenna.
•Increasetheseparationbetweentheunitandthetelevisiontuner.
•ConnecttheunittoanACpoweroutletonadifferentelectricalcircuit.
•ConsultyourauthorizedRotelretailerforassistance.

4RCX-1500 Stereo Compact Disc Receiver
Figure 1: Controls and Connections
Commandes et Branchements
Bedienelemente und Anschlüsse
Controlli e connessioni
Controles y Conexiones
De bedieningsorganen en aansluitingen
Funktioner och anslutningar
é„‡Ì˚ ÛÔ‡‚ÎÂÌËfl Ë ‡Á˙ÂÏ˚
FM
USB
DAB i - R AD IO
CD
AU X 1 AU X 2
NETWORK
PHONES
QUEUE SELECT
RE PLYBACK NEXT
PREV
EJECT
RC X- 1500
STANDBY
 
A B
    

CI
D E F G H J


5
English
RR-CX91
123
456
789
0>10 MEM
FM DAB i-RADIO CD
NETWORK USB AUX 1 AUX 2
QUEUE
DIM
BACK REPLY
SETUP
EXIT
SEL
ON
OFF
-
+
VOLUME
REPT SCAN RANDOM
TIME CLEAR REV PROG
MUTE











Button Series Function Explanation
1,2: STANDBY mode button, are used to switch the STANDBY mode on or off.
3: Source selection buttons, are used to switch your desire source.
4: Back to upper level menu
5: Call out preset/memorized list of tracks, songs, stations, etc against specified mode.
6: To call out special Internet Radio menu on Internet Radio mode.
7,8: Navigation keys and confirm buttons, are used to navigate and enter menus.
9: Playback buttons,are used mainly control the playback under USB and CD mode. It has
specified functions against specified modes.
0: Numeric buttons , offer alternated numeric related selection.
-: Extra functionality buttons, are used to set individual machine’s configuration and make
it more convenience for your using.
=: Volume control buttons.
Front & Rear Interfaces
A: USB socket, is used to connect with USB music storage devices, such as MP3, USB
stick Mobile,iPod/iPhone etc , can be connected directly or through USB adaptor.
B: PHONE jack, is used to connect with 3.5mm headphone.
C: Antenna connector, is used to connect with supplied DAB/FM antenna
D: Analog AUX input jacks, are used to connect with other device’s analog signal output
E: PRE OUT jacks, are used to connect with other amplifier’s input and send
analog signal to the amplifier.
F: Ethernet sockets, is used to connect with supplied Wi-Fi dongle or USB LAN adaptor.
G: Digital AUX input jacks, are used to connect with other device’s digital signal output
H: Computer I/O sockets, is used to connect with computer to upgrade this device firmware
I: Speaker connectors, are used to directly connect with speakers.
J: Power connector, is used to connect with AC mains and outlet.

6RCX-1500 Stereo Compact Disc Receiver
Figure 2: Hook-up Illustration
Branchements principaux
Diagrama de Conexiones
Schema di collegamento
Anschlussdiagramm
De in- en uitgangsaansluitingen
Inkoppling
Подключение
DIGITAL AUDIO DEVICE
WI-FI DONGLE
FM
USB
DAB i- R AD IO
CD
AUX 1 A UX 2
NETWORK
RCX- 1500
PHONES
STANDB Y
QUEUE SELECT
REP LYBACK N EXT
PREV
EJECT
PRE AMPLIFIER

7
Important Notes
When making connections be sure to:
4Turn off all the components in the system before hooking up any components, including loudspeakers.
4Turn off all components in the system before changing any of the connections to the system.
It is also recommended that you:
4Turn the volume control of the amplifier all the way down before the amplifier is turned on or off.
Remarques importantes
Pendant les branchements, assurez-vous que :
4Tous les maillons sont éteints avant leur branchement, quels qu’ils soient, y compris les enceintes acoustiques.
4Éteignez tous les maillons avant de modifier quoi que ce soit au niveau de leurs branchements, quels qu’ils soient.
Il est également recommandé de :
4Toujours baissez le niveau sonore via le contrôle de volume, avant d’allumer ou d’éteindre l’amplificateur.
Wichtige Hinweise
Achten Sie beim Herstellen der Verbindungen auf Folgendes:
4Schalten Sie alle Komponenten im System ab, bevor Sie Geräte (einschließlich Lautsprecher) anschließen.
4Schalten Sie alle Komponenten im System ab, bevor Sie Anschlüsse im System verändern.
Ferner empfehlen wir, dass
4Sie die Lautstärke herunterdrehen, bevor Sie den Verstärker ein- oder abschalten.
Notas Importantes:
Cuando realice las conexiones, asegúrese de que:
4Desactiva todos los componentes del equipo, cajas acústicas incluidas, antes de conectar cualquier nuevo componente en el mismo.
4Desactiva todos los componentes del equipo antes de cambiar cualquier conexión del mismo.
También le recomendamos que:
4Reduzca el nivel de volumen de su amplificador a cero antes de activarlo o desactivarlo.
Héél belangrijk:
Bij het maken van de verbindingen:
4Zorg dat niet alleen de RCX-1500, maar de gehele installatie uitstaat, als nog niet alle verbindingen gemaakt zijn.
4Zorg dat niet alleen de RCX-1500, maar de gehele installatie ook uitstaat, als u verbindingen gaat wijzigen.
Wij raden u ook aan om
4de volumeregelaar van de voorversterker geheel dicht te draaien (volkomen naar links) wanneer u uw eindversterker aan- of uitzet.
Note importanti
Quando effettuate i collegamenti assicuratevi di:
4Spegnere tutti i componenti del sistema prima di collegare qualsiasi componente, inclusi i diffusori.
4Spegnere tutti i componenti del sistema prima di modificare qualsiasi connessione nel sistema.
Vi raccomandiamo inoltre di:
4Portare il volume a zero prima di accendere o spegnere l’amplificatore.
Viktigt
Tänk på följande när du gör anslutningar:
4Stäng av alla apparater i anläggningen innan du ansluter nya komponenter eller högtalare.
4Stäng av alla apparater i anläggningen innan du ändrar någon anslutning.
Vi rekommenderar också att du:
4Vrider ner volymen helt och hållet innan förstärkaren slås på eller av.
LJÊÌ˚ Á‡Ï˜‡ÌËfl
èÂ‰ ÔÓ‰ÒÓ‰ËÌÂÌËÂÏ:
4Ç˚Íβ˜ËÚ ‚Ò ÍÓÏÔÓÌÂÌÚ˚, ‚Íβ˜‡fl ÍÓÎÓÌÍË.
4Ç˚Íβ˜ËÚ ‚Ò ÍÓÏÔÓÌÂÌÚ˚ ‚ ‚‡¯ÂÈ ÒËÒÚÂÏÂ, ÔÂʉ ˜ÂÏ ˜ÚÓ-ÚÓ ‚ ÌÂÈ ÏÂÌflÚ¸.
êÂÍÓÏẨÛÂÚÒfl Ú‡ÍÊÂ:
4Ç˚‚ÂÒÚË „ÓÏÍÓÒÚ¸ ÛÒËÎËÚÂÎfl ̇ ÏËÌËÏÛÏ, ÔÂ‰ ÚÂÏ Í‡Í ‚Íβ˜‡Ú¸ ËÎË ‚˚Íβ˜‡Ú¸ „Ó.

8RCX-1500 Stereo Compact Disc Receiver
SETTINGS Overview.............................................17
Configure “My Stuff”. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Configure“MyStations”.........................................18
Configure “My Stream” ..........................................18
CDControlButtons .............................................18
PLAY Button 18
Stop Button 18
PAUSE Button 18
TRACK Buttons 18
DIRECT ACCESS Buttons 18
SEARCH Buttons 19
EJECT Buttons 19
AdditionalFeatures .............................................19
PROGRAM Button 19
REVIEW Button 20
CLEAR Button 20
RANDOM Button 20
REPEAT Button 20
SCAN Button 20
TIME Button 20
RemoteUnitAdvancedButtons ....................................21
Trouble Shooting ............................................... 21
Glossary .....................................................22
Specifications .................................................23
Contents
Important Safety Instructions .......................................3
Figure 1: Controls and Connections 4-5
Figure 2: Hook-up Illustration 6
ImportantNotes ................................................7
About Rotel .................................................... 9
GettingStarted.................................................9
Features 9
A Few Precautions 9
Placement 9
Overview – the Rotel internet radio tuners/digital gateway products. . . . . . . . . 10
DAB and FM radio 10
Internet radio 10
Network access 10
The Rotel Radio website - managing your stations 10
Playback from iPods, mp3 players and flash drives 10
Playback from network servers 10
AC Power and Control ...........................................11
AC Power Input J11
Standby Switch and Indicator Light 11
ConnectionOverview ...........................................11
USB connection A11
PHONE connection B11
DAB/FM Broadcasting C11
Analog Input -AUX 2 D11
PRE Out E11
Network Connection F11
Digital Input -AUX 1 G11
Computer I/O H11
Speaker Connections I11
Speaker Selection 11
Speaker Wire Selection 11
Polarity and Phasing 12
Speaker Wire Connections 12
Internet Radio Quick Start ........................................12
What You need before using 12
First time Connect To The Network 12
Choosing A Radio Station 13
Internet Radio Station Playing13
Store a radio in a preset13
Play a preset radio station13
MediaPlayerQuickStart.........................................14
UPnP Servers
Setting up UPnP Service in PC 14
Playing media files using UPnP service 14
Clear Queue 14
Playback Mode 15
iPod/USBConnectionQuickStart...................................15
USB Storage Device Connection 15
iPod/iPhone Connection 15
PlayBack Control Buttons 15
FM Radio Quick Start ............................................ 16
FM Radio Station Playing 16
Storing a radio station in a preset 16
Playing a preset radio station 16
DABRadioQuickStart...........................................16
DAB Radio Station Playing 16
Storing a DAB station in a preset 16
Playing a preset radio station 16
Radio Station Presets 16

9
English
About Rotel
Our story began nearly 50 years ago. Over the decades, we have received
hundreds of awards for our products and satisfied hundreds of thousands
of people who take their entertainment seriously- like you!
Rotel was founded by a family whose passionate interest in music led
them to manufacture high-fidelity components of uncompromising quality.
Through the years, that passion has remained undiminished and the family
goal of providing exceptional value for audiophiles and music lovers,
regardless of their budget, is shared by all Rotel employees.
Rotel’s engineers work as a close team, listening to, and fine tuning,
each new product until it reaches their exacting musical standards. They
are free to choose components from around the world in order to make
that product the best they can. You are likely to find capacitors from
the United Kingdom and Germany, semiconductors from Japan or the
United States, while toroidal power transformers are manufactured in
Rotel’s own factory.
We all have concerns about our environment. And, as more and more
electronics are produced and later discarded, it is especially important
for a manufacturer to do all it can to engineer products that have a
minimum negative impact on landfill sites and water tables.
At Rotel, we are proud to do our part. We have reduced the lead content
in our electronics by using special RoHS solder, while our new Class D
(not digital) amplifiers are up to five times more efficient than our legacy
designs and still deliver power and performance. These products run
cool, give minimum wasted energy, are good for the environment and
give better sound too.
Finally, we have printed this brochure on recycled paper stock.
While we understand that these are small first steps, they are still important
ones. And we continue to pursue new methods and materials for a cleaner
and greener manufacturing process.
All of us at Rotel thank you for buying this product. We are sure it will
bring you many years of enjoyment.
Getting Started
Thank you for purchasing the Rotel RCX-1500 CD Receiver. When used
in a high-quality music or home theater system, your Rotel CD Receiver
will provide years of musical enjoyment.
Features
Wireless or wire connection to access internet radio.•
Access LAN PCs and music with ‘Media Player’ Mode•
Connect with iPod/MP3/media music player for home•
enjoyment.
Listen to DAB, FM broadcasting station.•
Playback of conventional CD, MP3 or WMA encoded disc.•
Two amplifier channels at 100 watts per channel.•
A Few Precautions
Please read this manual carefully. In addition to basic installation and
operating instructions, it provides valuable information on various RCX-
1500 system configurations as well as general information that will help
you get optimum performance from your system. Please contact your
authorized Rotel dealer for answers to any questions you might have. In
addition, all of us at Rotel welcome your questions and comments
Save the RCX-1500 shipping carton and all enclosed packing material
for future use. Shipping or moving the RCX-1500 in anything other than
the original packing material may result in severe damage to your unit.
Fill out and send in the owner’s registration card packed with the RCX-
1500. Also be sure to keep the original sales receipt. It is your best
record of the date of purchase, which you will need in the event warranty
service is ever required.
Placement
Place the RCX-1500 on a solid, level surface away from sunlight, heat,
moisture, or vibration.
Don’t stack other components or objects on top of the RCX-1500. Don’t
let any liquid fall into the unit.
Note the weight and size of the RCX-1500. If placing the unit on a
shelf, cabinet or rack, make sure the full weight of the RCX-1500 can
be supported.
The RCX-1500 generates heat during normal operation. Do not block
ventilation openings. Allow a minimum of 10 cm or 4 inches of unobstructed
space around the unit. If installed in a cabinet, make sure that there is
adequate ventilation.

10 RCX-1500 Stereo Compact Disc Receiver
Overview – the Rotel internet radio tuners/
digital gateway products.
This product does not operate without the Wi-Fi or Wired dongle being
connected. We recommend that you read this introduction first.
This Rotel product brings together conventional radio reception facilities
for FM and DAB, plus from the world of computers the ability to access
literally thousands of radio stations available on the internet. In addition
to this, this new range of Rotel tuners/digital gateways offers the facility
to interface with personal audio players (iPods and mp3 players) and
your music files stored on a network server.
These notes expand on the ‘quick start’ notes later in this manual.
Firstly, it does not matter if a wired or Wi-Fi network is not available to
use – however it is essential that the Wi-Fi or wired dongle is inserted into
it’s socket on the rear panel of the product for it to work. Use an extension
cable to relocate the dongle if space is limited at the rear of the tuner.
Each time that the product is turned on, it will be locked into search mode
for about 15/20 seconds. Once this has being accomplished other radio
modes can be used.
The USB input is active from turn on.
DAB and FM radio
This is the most conventional part of the product and if you have previous
experience of tuning, memorizing and selecting radio stations from the
present DAB and FM radio services you will be familiar with the way
the tuner is operated to receive these services. All of this is explained
under relevant quick start sections. Keep in mind to select the antenna
(aerial) input socket to use, find this option in the set-up menu. This does
not obviate the need to install correctly designed antenna (aerials) to
maximise reception on FM and DAB services.
Internet radio
Using internet radio requires the use of two additional services – access
to the internet via a computer network and once this works a feed via
one of the internet-based services which allows access to internet radio
stations. This latter requirement is built into the tuner; we will deal with
access to your network first.
Network access
The installation of computer networks are beyond the scope of these notes,
so we assume that you have a working Wi-Fi network in your home. If
you are using a wired network please refer to Network Config. under
“Settings Overview” section. (Wired networks will provide the most reliable
Ethernet streaming. Ethernet over powerline adaptors are available from
3rd parties if running an Ethernet cable is otherwise impractical.)
At start-up, the unit looks for Wi-Fi networks, and once the search has been
completed you will find one or more listed networks listed in the display to
choose from. You need to select the network name which applies to your
installation. This will have been assigned when your network was installed
and is often pre-allocated by the router central to your network.
The next requirement is to enable your tuner to ‘log-on’ to your network
and you allow this by entering the wireless ‘WEP key’ (or WPA, WPA2
key) appropriate to your network. It is likely that you will have used the
key code when setting up a computer to log onto your network and it
is often contained in the instructions for your router. This is a first-time
only setting, so just carefully scroll though the alpha-numeric characters
selecting the correct upper or lower case characters to create your WEP
key. When completed, scroll through to and select END or simply press
the REPLY button to complete the process.
You can use the Previous and Next keys of the handset to help you enter
this information. Do not confuse the letter ‘O’ with the numeral ‘0’.
When successfully logged on to your network, the tuner will automatically
log in to the website where you to be able to select the area of the world that
interests you and choose radio stations by country, genre and name.
Registering the radio at www.rotelradio.com will allow you to search
for and save internet radio stations, as well as set up other music
services when available for your region.
The Rotelradio website – managing your stations
Managing the thousands of radio stations available via the internet would
be impossible without being able to organise and manage stations to suit
your particular needs. Rotel have provided an easy way to accomplish this
by means of a dedicated website where you can pre-select stations.
The URL for this site is http://rotelradio.com.
Like many websites you will need to register a user name and password
in order to create an account on the site. Before you can do so, you will
need to register the product on the site and there is a special registration
key in the Rotel which you will need to copy to the website registration
form. This registration key will be found under the settings>register
menu. You need to be connected to the internet to access this one time
only key.
After registration, the website will show the radio serial number of your
Rotel unit. This is different from the serial number of your Rotel unit. The
radio serial number can be found in the menu of the Rotel unit under
Settings --> Version.
Note that to update the display of the Rotel to indicate your choices, you
will need to power-cycle and re-select ‘internet radio’. Your new list of
‘My Stuff’ will be updated automatically.
Playback from iPods, mp3 players and flash drives
Most iPod and mp3 players can be plugged into the USB socket on the
front panel to replay the music files stored within. The display will update
to show the file structure and will list the files which can be played. Files
copied to a standard flash drive will also behave in the same way.
Playback from network servers
Music playback from computers configured as music servers provides
another opportunity to link replay via the Rotel unit and thus make use of
the audiophile decoding stages designed into these products.
As with internet radio, a prerequisite is a working network, plus the music
server connected to it. Please follow the instructions shown under ‘Media
Player Quick Start’ later in the manual.

11
English
NOTE: You must insert the Wi-Fi dongle (or wire adaptor) to the
ETHERNET port on the rear panel. The unit will first search for available
networks before allowing access to DAB and FM functions. If networks
are not available, the unit will display “Network Error”. FM and DAB
functions will operate normally after the initial network search.
ANALOG INPUT-AUX 2 D
The RCX-1500 can receive analog music signals from other sources, such
as your CD players analog outputs. Connect the LEFT and RIGHT outputs
of the source to the LEFT and RIGHT input of the AUX 2 Input.
PRE OUT E
The RCX-1500 can send analog signals to a second amplifier through
the connectors labeled PRE OUT. Use this connection if you wish to use
another power amplifier to drive your speakers.
Network Connection F
Connect the Rotel supplied USB Wi-Fi dongle to the USB port on the RCX-
1500 rear panel labeled ETHERNET. The RCX-1500 has been configured
to work with the supplied USB Wi-Fi dongle. No additional software/
setup is required. The RCX-1500 is now ready to connect to your wireless
LAN. Refer to Internet Radio section for detailed setup.
NOTE: Not all USB Wi-Fi/Wired dongles will operate with the RCX-1500.
Please use the one supplied by Rotel.
DIGITAL INPUT-AUX 1 G
The RCX-1500 can play digital music signal from other sources, such as
your CD player’s digital output. There are two connectors on the AUX
1 Digital Input area on the rear panel, labeled with coaxial and optical.
Connect the coaxial or optical output of your source to the coaxial or
optical input of the RCX-1500.
Computer I/O H
This RCX-1500 can be operated from a computer with audio system
control software from third-party developers. This control is accomplished
by sending operating codes from the computer via a hard-wired RS-232
serial connection. In addition, RCX-1500 can be updated using special
software from Rotel.
For additional information on the connections, cabling, software, and
operating codes for computer control or updating of the unit, contact
your authorized Rotel dealer.
Speaker Connections I
Speaker Selection
The nominal impedance of the loudspeakers connected to each channel
of the RCX-1500 should be no lower than 4 ohms.
Speaker Wire Selection
Use insulated two-conductor stranded wire to connect the unit to the
speakers. The size and quality of the wire can have an audible effect
on the performance of the system. Standard speaker wire will work,
but can result in lower output or diminished bass response, particularly
over longer distances. In general, heavier wire will improve the sound.
For best performance, you may want to consider special high-quality
speaker cables. Your authorized Rotel dealer can help in selection of
appropriate cables for your system.
AC Power and Control
AC Power Input J
Your RCX-1500 is configured at the factory for the proper AC line voltage
in the country where you purchased it (USA: 120 volts/60 Hz, Europe:
230 volts/50 Hz). The AC line configuration is noted on a label on the
back panel.
The RCX-1500 is supplied with the proper AC power cord. Use only this
cord or an exact equivalent. Do not modify the supplied cord. Do not
use an extension cord.
Be sure the power switch on the front panel of the RCX-1500 is turned
off. Then, plug one end of the cord into the AC power connector on
the back panel of the amplifier. Plug the other end into an appropriate
AC outlet.
If you are going to be away from home for an extended period of time,
it is a sensible precaution to unplug your receiver.
Standby Switch and Indicator Light 12
The Standby Switch is located on the left side of the front panel. The
Standby Indicator ring will illuminate when the AC mains are connected.
This indicates the unit is in Standby mode.
To turn the unit ON, push the Standby switch once, the front display
will illuminate, indicating the unit is out of Standby mode and ready
for operation.
Connection Overview
Before continuing further to other sections in the manual, please make
sure all the cable connections are made properly. Refer to figure 2.
USB Connection A
The socket on the front panel below the STANDBY switch is for USB
connection. Music storage devices can be accessed by the RCX-1500
through this input. Music storage devices such as MP3 players, iPod, USB
memory sticks or any other form of memory devices with USB interface
can be connected to the RCX-1500 through the front USB socket. RCX-
1500 will automatically search music files from the connected storage
device.
NOTE: RCX-1500 use USB 2.0 standard to access music files. The unit
can playback music files stored on storage devices that are compliant
with USB 2.0 standard. However, it will not operate with devices that
require additional drivers.
PHONES Connection B
The socket on the front panel below the USB socket is for headphones.
Plug a 3.5mm headphone jack into the socket to listen to music through
headphones. Connecting headphones will automatically turn off the
output to the loudspeakers.
DAB/FM Broadcasting C
Please use supplied indoor antenna to connect the DAB and FM connector
on the rear panel. To receive the best FM signal, make sure there is enough
room for the T-shaped indoor antenna to fully extend. Eyelets at both
ends of the T allow tacking the antenna to a wall if desired. Experiment
with different positions to maximize reception.

12 RCX-1500 Stereo Compact Disc Receiver
Polarity and Phasing
The polarity - the positive/negative orientation of the connections - for
every speaker and amplifier connection must be consistent so all the
speakers will be in phase. If the polarity of one connection is mistakenly
reversed, bass output will be very weak and stereo imaging degraded.
All wire is marked so you can identify the two conductors. There may be
ribs or a stripe on the insulation with different color conductors (copper
and silver). There may be polarity indications printed on the insulation.
Identify the positive and negative conductors and be consistent with every
speaker and amplifier connection.
Speaker Wire Connections
NOTE: The following text describes both binding post and banana plug
connections. DO NOT use both connection methods in combination to
connect multiple speakers.
The amplifier has two sets of color coded terminals for each amplifier
channel. The speaker terminals accept bare wire, connector lugs, or
“banana” type connectors (except in European Community countries
where their use is not permitted).
Route the wires from the RCX-1500 to the speakers. Give yourself
enough slack so you can move the components to allow access to the
speaker connectors
NOTE: Be sure to note the location of the LEFT and RIGHT speaker
terminals and connect your LEFT and RIGHT speakers to the correct
outputs.
If you are using banana plugs, connect them to the wires and then plug
into the backs of the speaker connectors. When using banana plugs,
the collars of the binding post terminals should be screwed in all the
way (clockwise).
If you are using terminal lugs, connect them to the wires. If you are
attaching bare wires directly to the speaker connectors, separate the wire
conductors and strip back the insulation from the end of each conductor.
Be careful not to cut into the wire strands. Unscrew (turn counterclockwise)
the binding post collar. Place the connector lug around the shaft, or insert
the bundled wire into the hole in the shaft. Turn the collars clockwise to
clamp the connector lug or wire firmly in place.
NOTE: Make sure there are no loose wire strands that could touch
adjacent wires or connectors.
Internet Radio Quick Start
What you need before starting
Before you can use your Internet radio, you need the following:
A broadband Internet connection.•
Access point to internet through wireless LAN. (wired LAN connection•
is also possible with a Rotel supplied USB Ethernet adaptor)
With wireless LAN connection, internet radio should work within 100
metres of the wireless access point, subject to the router/Wi-Fi gateway
being placed in the optimum area for your location. The user can confirm
the WiFi Strength under the settings menu. (Network--->Settings-->WiFi
Strength)
Make sure that your LAN is connected properly and is able to access
the internet. To access internet radio stations an internet connection is
required.
First Time Connection To The Network
Plug in the USB Wi-Fi dongle to the rear USB port Aand push the
STANDBY button to power up this unit. The display on the front will light
up and display:
Starting ... ... SCANNING NETWORK.. ...
After a few seconds, it will start to scan for network.
If it can not find one the display will say:
NO NETWORK FOUND
When the radio finds your network, it displays the ESSID for the access
point on the screen - this is a name that is allocated to the access point
by the person who set up the network - for example:
< MY NETWORK >
It is possible, and in some locations highly likely, that your unit will find
more than one wireless access point if using wireless connection, in which
case you can choose which one you want to connect to. Turn the knob on
the panel to see the ESSID for each access point the radio has found.
If the screen displays “Enter WEP key” or “Enter WPA key” then the
network is using one of the encryption systems, Wired Equivalent Privacy
(WEP) or Wi-Fi Protected Access (WPA) Please obtain the access code
from the person who set up this wireless network, or check the user
manual of your router for this information. Input the code into the unit to
access the wireless LAN.
Note: If you would like to use a static IP address, or if the unit can not
automatically get an IP address, then please see the ‘Network config’
section under the ‘Settings’ section at the end of the manual.

13
English
Choosing A Radio Station
Once a network is found and the network connections made, The top-
level menu will be displayed, please select “Internet Radio”, the display
will shows as
< Internet Radio >
Media Player
FM
DAB
< Location >
Genre
Search
Now you can select internet radio stations to listen to through one of
the options below.
<LOCATION> enables you to choose radio stations provided in the
specific area and countries:
Africa
< America >
Asia
Caribbean
< XXX1 LIVE RADIO >
XXX2 LIVE RADIO
XXX3 LIVE RADIO
XXX4 LIVE RADIO
1. Push the PREV, NEXT keys until the display shows the area and country
you want, then press on the SELECT key.
2. Push the PREV, NEXT keys until the display highlights the desired
station. Push SELECT key to select..
3. Wait until the unit connects to that station.
<GENRE> enables you to choose radio stations according to their
content, for example Classic, Rock, Sport, News, etc.
80S
< 90S >
Adult
Adult contemporary
XXX1 LIVE RADIO
< XXX2 LIVE RADIO >
XXX3 LIVE RADIO
XXX4 LIVE RADIO
1. Push PREV, NEXT keys until the display highlights the type of content
desired, then press SELECT key to select.
2. Push PREV, NEXT keys to highlight the station desired, then press
knob to select.
3. Wait until the radio connects to that station.
<SEARCH> enables you to search for a specified type of radio with a
short keyword.
Station Name
END <> A BCDEFGHIJKLNO
ART
xxx ART xx Radio1
x ARTxx xx Radio2
ARTxxxx xx Radio3
1. Push PREV, NEXT keys until the display moves to the character to input,
then press the SELECT key to select.
2. Repeat step 1 to input the complete keyword. Select “END” or push
REPLY key to confirm the keyword.
3. The display will show stations which match the keyword.
4. Push PREV,NEXT keys to highlight the desired station, press SELECT
key to select and connect to that station.
Note: Internet Radio stations and other music services can be easily set
up at www.rotelradio.com
Internet Radio Station Playing
After connecting to a station, the display will show station name, type
of audio file and bit rate.
BBC RADIO
BUFFERING xx%
BBC RADIO
xxx kbPs WMA
XX:XX
Storing a radio station in a preset
(remote only)
While a radio station is playing, hold down the MEM button on the remote
control , then press a number 0to assign, the display will show
BBC RADIO
xxx kbit WMA
M Preset #
Assign to Preset
#
Store this current radio station into the preset number, and you can store
up to 30 preset radio stations for FM/DAB/Internet Radio.
Playing a preset radio station
While a radio station is playing, you can switch to other preset stations
as below:
1. From the remote control, press number button 0of the preset number
for desired station. Example, push “0”, then “3” for preset number 3,
push “1” then “3” for preset number 13.
2. Press QUEUE 5button to call out preset number and corresponding
station. Push PREV, NEXT keys to choose the station. The display will
show as
01 preset radio 1
02 preset radio 2
> 03 preset radio 3
04 preset radio 4
Press QUEUE button again to exit the queue menu and back to playing
status.
Note: You can review stored radio stations by using the Queue
feature. This will help you avoid accidently overwriting a preset.

14 RCX-1500 Stereo Compact Disc Receiver
3. Go into ‘Media Player’ menu, and select ‘UPnP Servers’ sub menu
by using the PREV, NEXT and hitting SELECT. The unit will scan for all
available UPnP servers. It will display ‘[Empty]’ if no UPnP servers are
found.
Internet Radio
< Media Player >
FM
DAB
< UPnP Servers >
Playback Mode
Queue
Play media files using UPnP Server.
1. After a successful scan, all available UPnP servers will be displayed.
Select your UPnP server with the PREV, NEXT keys, then press SELECT.
2. RCX-1500 will list the options or folders available. This varies
depending on the setup of your music server, and version of software
you are using. It will typically show the following menus
< All Music >
All Artists
Albums
Music Playlists
Folders
[Search]
You can search for songs by scrolling through the All Music option or
search for specific Artists using All Artists or specific albums using Albums.
In each case, you can drill down to the song level Or you can use the
[Search] function.
Enter the [Search] function and the following menu will be displayed
< Artists >
Album
Music
Then enter either Artists, Album or Music sub menus. You can enter a
letter or letters the Artist/Album/Music starts with. Example, enter “M” in
Artists, then press REPLY key to start searching. All artists in your library
starting with the letter “M” will be returned.
3. Once the desired track is found, push to select. The selected track will
be displayed on the menu as the unit attempts to connect to the music
server. Before play starts, the track title, type of file, bit rate will be shown.
When play starts, elapsed time will be displayed instead of file type.
“Track Title”
317kbps WMA
07:49
“Track Title”
01:12 317kpbs
07:49
Media Player Quick Start
The Media Player feature allows you to play audio files (AAC, AIFF,
AU, FLAC, MP3,WAV and WMA (except lossless)) and playlists (M3U)
created by your computer’s Media Player, such as Window Media Player
11. It has been verified to work on Windows 2000, Windows XP and
Windows Vista.
Note: File sharing may need to be enabled on your computer, and not
all Media Players will allow sharing of music files. Please refer to your
computer’s manual for instructions.
UPnP Servers
Setting up UPnP Server in PC
1. Use Windows Media Player 11(or 12 if you use Windows 7)to setup
the PC as an UPnP Sever, click the ‘Library’ tab from Windows Media
Player 11 and select ‘Media Sharing’ to open the ‘Media Sharing’
window to set the option.
2. Your PC will now prompt you that a device has attempted to connect
to your UPnP server. Please click Allow button.
Note: As of this writing, Windows Media Player 11 does not support
AAC decoding used by Apple as the default selection in iTunes. We
recommend that you change the default import setting to WAV, AIFF, or
MP3 formats for maximum compatibility across many devices. You can
set Windows Media Player to mirror your iTunes folders. (In Windows
Media Player, see Tools>Options>Libray tab>Monitor Folders) Windows
Media Player 12 (for Windows 7) does support AAC.

15
English
Note: Using QUEUE feature: A short press on SELECT for any song or
album will start that selection playing. You can also create a custom
QUEUE to create a song mix by holding the SELECT button for 5 seconds.
The selected track(s) will be added to the QUEUE and will be played
in the order selected. Push QUEUE button to call up tracks waiting to
be played. A 5 second push on the STOP button will remove specific
songs from the QUEUE.
Clear Queue
You can clear QUEUE by pressing the QUEUE button and selecting
[Clear Queue] or by going into QUEUE menu from the Media Player
submenu.
UPnP Server
Playback Mode
< Queue >
< [Clear Queue] >
You can also delete individual tracks in QUEUE by selecting the track
and press STOP for 5 seconds.
Playback Mode
UPnP Server
< Playback Mode >
Queue
< Repeat *>
Shuffle
Use NEXT, PREV, keys to select ‘Media Player’ -->‘Playback Mode’, there
are 2 sub-menu, “Repeat” and “Shuffle”. Select either Repeat, Shuffle or
both. A mark will indicate the selection made.
REPEAT: Tracks are played one after another and will start from the first
track again when the last track is finished.
SHUFFLE:Play tracks in random.
Note: If both REPEAT and SHUFFLE are on, The unit will first play the
list in random, after all tracks are played one time, it will continue to
play the list in random until STOP is pressed.
Note: Using shuffle feature with large music libraries may not be
possible or may take an excessively long time. We recommend that
you create shorter playlists in Windows Media Player and then shuffle
these.
iPod/USB Connection Quick Start
<< iPod/USB >>
001/009
00:01:41
123.MP3
> 01_Folder
music-files-002. wav
music-files-003. mp3
music-files-004. aac
USB Storage Device Connection
1. Plug your USB storage device containing music files, or through a
USB adaptor into the front panel’s USB socket A.
2. Press USB button on the front panel to enter iPod/USB mode. The
unit will automatically search music file from root directory. Once the
directory is found, the unit will start playing. The display shows song’s
information, such as name, time, tracks.:
3. If your music files are in sub directories, turn the knob to display all
directories. Turn and press the knob to enter the desired directory. Then
look for the desired music files turning and pressing the knob.
4. Press BACK button to return to the previous menu and select another
directory.
iPod/iPhone Connection
1. Apple’s iPod/iPhone can be connected via the iPod’s USB cable to
the USB front socket.
2. The iPod/iPhone will send a digital music signal to the unit. All
operations can be made from the iPod/iPhone. Only simple commands
can be made through the Rotel unit as explained below.
3. The iPod/iPhone screen will remain active while connected to the
unit. If no operations are made from the iPod/iPhone for an extended
period, the screen will turn to “charging”.
PlayBack Control Buttons 9
1. Use the PLAY /button to start playback.
2. Use the STOP .button to stop playback.
3. Use the PLAY //PAUSE ,button to either pause a currently playing
track or to restart a currently paused track or to restart a stopped track.
4. Use the BACK TRACK buttons {to start playback of the previous
track in the queue.
4. Use the FORWARD TRACK button }to start playback of the next
track in the queue.
5. Push and hold the STOP .button for 5 seconds to safely remove
the USB device from the unit.
Note: The Rotel unit will operate with iPhone 3GS, iPhone 3G, iPod
Classic, iPod touch 2G, iPod Nano 2G, iPod Nano 3G, iPod Nano
4G, and iPod Nano 5G.

16 RCX-1500 Stereo Compact Disc Receiver
FM RADIO Quick Start
Before listening to FM radio, make sure that the FM antenna Chave
been properly connected, and the correct FM format has been selected.
Go into ‘Settings’ menu and select FM tuner region.
FM Radio Station Playing
1. Select FM Button from the front panel. or keep pressing BACK button to
return to top-level menu to enter the FM menu. The display will show as
Internet Radio
Media Player
< FM >
DAB
87.50MHz FM
2. Use the scan buttons ] and [ on the remote unit to auto search for
FM stations.
3. Use track buttons } and { on the front panel or remote to manually
search for FM stations.
Storing a radio station in a preset
(remote only)
While a FM station is playing, push the MEM button , then press the
preset number to assign from the numeric pad 0. The following will
be displayed.
BBC RADIO
xxx kbit WMA
M Preset #
Assign to Preset
#
Store this FM radio station into the preset number. Up to 30 preset FM
radio stations may be stored.
Playing a preset radio station
When a radio station is playing, you can switch to other preset station
in one of the following two ways.
1. From the remote control, press the preset number of the desired
station.
2. Press QUEUE button to call out preset numbers and corresponding
station ,select the desired station with the navigation keys 8. The
display will shows as
01 preset radio 1
02 preset radio 2
> 03 preset radio 3
04 preset radio 4
Press QUEUE button again to exit the queue menu and back to playing
status.
DAB RADIO Quick Start
Make sure that your local area can receive Digital Audio Broadcast
(DAB) broadcasting signal. Before using this feature, please go to Settings
Quickstart section for DAB setting to select your DAB REGION and scan
available DAB stations.
After setting up, press the DAB button on the front panel, or select DAB
menu from top-level menu to enter this feature.
DAB channels are categorized into ensembles, which are also known
as multiplexes. Each multiplex provides a number of stations and each
service contains a primary service that can contain secondary services.
DAB technology allow broadcasters to transmit additional data along
with the audio, which can include other audio channels, text and even
images and computer data in the future.
DAB Radio Station Playing
1. Select DAB Button from the front panel. Or keep pressing BACK
button to return to the top-level menu, navigate to select DAB menu. The
display will show as
Internet Radio
Media Player
FM
< DAB >
The unit will scan for available DAB stations. Select the desired
station.
Storing a DAB station in a preset
(remote only)
While a DAB station is playing, hold down the MEM button, then press
the preset number to be assigned from numeric pad 0. it will store this
DAB radio station into the preset number. Up to 30 preset DAB radio
stations may be stored.
Playing a preset DAB station
When a radio station is playing, you can switch to other preset station
in one of the following two ways.
1. From the remote control, press the preset number of the desired
station.
2. Press QUEUE button to call out preset numbers and corresponding
station ,select the desired station with the navigation keys. Press QUEUE
button again to exit the queue menu and back to playing status.
Radio Station Presets
FM,DAB and the Internet have 30 Pre-set Stations a total of 90 stations
can be logged in the unit.
Note: For easier sorting, only the stations that are log in as Pre-sets will
be visible. Each station will be marked with an F for FM, D for DAB and
I for Internet Radio presets.

17
English
SETTINGS OVERVIEW
Media Player
FM
DAB
< Settings >
< Network Config >
Version
Upgrade Firmware
Register
Set Time/Date
FM Tuner
DAB Settings
UPnP
WiFi Strength
Keep pressing BACK button to back to top-level menu, select Settings
menu. It contains 9 settings sub-menus.Press PREV, NEXT keys to find
hidden menus.
Network Config
1.Scan for networks ( only for wireless connection)
Use the PREV, NEXT keys to select this menu. After entering this menu,
the display will show “Scanning”, which will take a few seconds.
Once the network is found, the display will show the network ID. Turn
the knob to select, push to confirm.
< Scan for networks >
Enter network name
View Config
Edit Config
2. Enter network name ( only for wireless connection)
If the unit can not find any networks , the network ESSID can be entered
manually.
Use PREV, NEXT keys to select the letters of the device name then select
“END” to confirm the name or hit the REPLY key on the remote or front
panel.
Network Name
< END <> A BCDEFGHIJK >
NAME1
3. View Config
Show current network configuration details. Use navigation keys to
see next/previous page of “Mode”-->”ESSID”-->”MAC Address”-->
“IP Address”-->”Netmask”-->”Gateway”-->”DNS Servers”. Display as
below:
< Mode >
Auto DHCP
< ESSID >
XXXXXX
4. Edit Config
This menu can be used to edit the current network configuration. This
menu is useful for entering a static IP address. Select this function with
the navigation keys and enter the static IP address, MAC address, DNS
of the selected network.
To enter the value press SELECT then press PREV, NEXT keys. Press
SELECT again to enter the value and move on to the next field. Continue
until all information has been entered.
5. Signal Warning ( only for wireless connection)
Select YES or NO to enable or disable warning of low Wi-Fi signal.
Version
This menu displays software and hardware information of the unit
Upgrade Firmware
Use this option to download new firmware for the internet radio from
the Reciva portal on the Internet. If new firmware is available, there will
be a prompt to download.
Note: At this stage, you can press the BACK button to cancel the firmware
upgrade. A firmware upgrade may take several minutes, do not switch
off the power to the unit or put it into standby until the operation is
complete, otherwise, the unit may become permanently damaged.
Upgrading can take 15 to 60 mins, depending on the speed of your
internet connection.
Register
This will display a key that can be used to register the unit on the Rotel
Radio Customer portal: www.rotelradio.com
Set Time/Date
Set you local time and date. Push SELECT key to start entering value,
push PREV, NEXT keys to change value. Press again to confirm value
entered and move on to the next field..
FM Tuner
Select the FM Tuner region with this function.
DAB Setting
There are 3 sub menus: Scan, Clear List, DAB Region. Please select the
menu by turning and pressing the knob.
“Scan” will scan for all available DAB service, it will display list of service
name when successful, or say “no services found “ if DAB broadcasting
is not available.
“Clear List” will clear available service list found by “Scan”.
“DAB Region” will show regions that provide DAB service, you can select
the desired region with the navigation keys.
UPnP
Use this setting if you wish to change the UPnP device name. This is
the name that your music server will pickup in Media Player mode.
Default name is ROTEL GATEWAY.
Use the navigation keys to select letters of the device name then select
“END” or hit REPLY button to confirm the name.
DEVICE NAME
< END <> A BCDEFGHIJ >
DEVICE
WiFi Strength
Shows a percentage to indicate the WiFi strength.

18 RCX-1500 Stereo Compact Disc Receiver
CD Control Buttons
These buttons provide basic control functions for the disc transport
mechanism. Except where noted, all functions are available on the RCX-
1500 front panel and the IR remote control.
PLAY Button
After the disc is loaded, press the PLAY /button to start playing the disc.
The number of the track being played and the elapsed time will be shown
in the display, along with the PLAY indicator. Normally, the disc will start
playing with the first track. However, you can select a different track using
the TRACK buttons or the DIRECT ACCESS buttons (see below) before
pressing the PLAY button to start playing a different selection.
STOP Button
Press the STOP .button once to stop disc play. Press the PLAY /button to
resume disc play where it was stopped. If the STOP .button is press twice,
disc play stops, the display shows STOP and programmed selections are
deleted (see below). When the PLAY /button is press after pressing the
STOP .button twice, the disc begins playing from the first track.
PAUSE Button
The PAUSE ,button is used to temporarily suspend play. The disc continues
to spin and play will be resumed from the current position. The PAUSE
indicator will light in the Display. To resume playing the disc, press the
PLAY button.
TRACK Buttons
These buttons are used to select tracks on the disc. When a disc is playing,
pressing the }TRACK button advances to the beginning of the next track.
Pressing the { TRACK button returns to the beginning of the current track.
Pressing {TRACK twice quickly in succession returns to the beginning of
the previous track. The new track number appears in the Display. These
buttons are also used to select a track before pressing the PLAY button
or when memorizing tracks for the PROGRAM play mode (see below).
These selections are made by continuously pressing the TRACK buttons
until the desired track is reached. In PROGRAM mode, the TRACK buttons
advance or reverse to the next track in the memorized selection list.
DIRECT ACCESS Buttons 0(remote only)
These eleven numeric buttons (labeled 1 through 0 and >10) are used to
directly access a track from instead of stepping through the tracks using the
TRACK Buttons. The first ten tracks on a disc can be selected by pressing
the corresponding button. For example, to play the third track, press the 3
button on the remote control. To play track 10 press the 0 button. To select
track numbers greater than 10 use the >10 button. For example, to select
track 14, press the >10 button followed by the 4 button. To select track
23, press the >10 button twice followed by the 3 button. The number of
the selected track will appear in the main numeric area at the center of
the Display.The DIRECT ACCESS buttons may also be used to memorize
tracks in PROGRAM mode (see PROGRAM Button section).
Configure “My Stuff”
Register an account on Rotel Radio website
A personalized menu “My Stuff” can be setup in the top level menu.
Open the website, www.rotelradio.com, from your internet browser.
Please enter the registration key, this can be found in ‘Settings > Register’
menu. Enter this registration key into the website and follow the instructions
to setup an user name and password. Remember the user name and
password, you will need this to access the site.
After logging into your account, you will be able to edit your information
for ‘My Stations’, ‘My Streams’, ‘My Podcast’ and ‘My Radios’.
Follow the instructions on the website to personalize your RCX-1500
menu.
Configure “My Stations”
There are an enormous choice of stations that are available in the
database from the website. Please follow instructions on the website to
search for stations. When search results are displayed, there will be a
link to ‘Add to my stations’, Click on this and the station selected will be
added to My Stations. A new top level menu ‘My Stuff’ will appear on
the display, with a sub-menu ‘My Stations’.
After the initial registration, you can add to ‘My stations’ while connected
to a radio station by pressing the REPLY key. The display will ask if you
want to add selection to ‘My stations’ press the push select knob to add
selection.
Note: You may further organize your stations into FOLDERS (for
instance JAZZ, ROCK, OPERA etc.) These FOLDERS will be displayed
on your Rotel unit.
Configure “My Streams”
While logged into your website account, you can add your own internet
radio streams to the ‘My Streams’ section which will be listed under ‘My
Account’.
Click on ‘My Streams’, a prompt will appear to enter the station’s name
and its media stream URL. The media stream URL should be a link to the
website’s actual audio stream.
Note: ‘My Stuff’ menu and stations under ‘My Stations’,’My Streams’
will appear after the unit has updated the stations list. Please power
OFF then ON and enter ‘Internet Radio’ from the top level menu for the
unit to update the stations list.

19
English
SEARCH Buttons (remote only)
The ]and [buttons fast forward or fast reverse through the disc that
is playing. One press of the ]or [ button will fast forward or fast
reverse at 2X normal speed. Pressing the ]or [button repeatedly
will fast forward or fast reverse at 4X, then 8X, 16X and 32X normal
speed. One more press of the ] or [button, or pressing the Play /
button, returns the RCX-1500 to normal speed play. While the buttons
are pressed, you will hear high-speed audio.
EJECT Button
When a disc is inserted into the front panel Disc Slot it is pulled into
the disc transport. To eject the disc press the EJECT button on the front
panel or the remote control ^.
If you accidentally press either of these buttons, press the button again
to re-load the disc.
Additional Features
These convenience features add extra functionality to the RCX-1500,
including the ability to memorize a group of tracks to be played, to repeat
a disc, a program, or a track over and over, to play the tracks on a disc
in random order, to automatically play the first 10 seconds of each track,
and to select from several available time displays.
PROGRAM Button (remote only)
This button, labeled PROG, allows you to memorize more than 20
tracks on the current disc for playback in a specific order. For example,
you could instruct the RCX-1500 to play track 5, followed by track 3,
followed by track 8.
Note: Programmed play lists cannot be set up with MP3 and WMA
discs.
To begin a program:
1. Insert a disc in the front panel slot. The RCX-1500 will read the contents
of the disc. You may press the PLAY /button if you would like to listen
to the tracks while you program them.
2. Press the PROGRAM button the remote control. The PROGRAM indicator
will light up in the Display, along with “P:00” indicating that the unit is
waiting for the first track to be memorized.
3. To program tracks from the handheld remote control, enter the first
track number using the DIRECT ACCESS buttons. Your selection will be
memorized automatically and the Display indicator will change to “P:01”,
indicating that one track has been memorized. Continue entering the rest
of your selections using the DIRECT ACCESS buttons. Note that there is
no need to press the PROGRAM button as each selection is memorized
as it is entered.
Once you have memorized a play list, the RCX-1500 remains in PROGRAM
mode until you eject the disc or press the STOP button twice in succession.
If you press the PLAY button, the memorized program will play instead of
the entire disc, starting with the first selection in the memorized list.
When a PROGRAM has been memorized, most functions that would
normally affect the entire disc operate on just the memorized program. For
example, the TRACK buttons advance to the next track in the memorized
program, not the next track on the disc. Likewise, the REPEAT button (see
below) continuously plays the memorized program, not the entire disc.
Note: The Random Play feature cannot be used when using the
Programmed Play feature.

20 RCX-1500 Stereo Compact Disc Receiver
REVIEW Button (remote only)
This button is used to review the memorized tracks in Program Play mode.
Press the button and the first memorized track number and “Prog Review”
will appear in the Display. Pressing the REVIEW button again while the
track number is displayed will continue the review sequence, showing
the next memorized track. Continue pressing the REVIEW button to see
the complete memorized track list.
If the REVIEW button is not press again, after 5 seconds the review
process is terminated and the unit resumes whatever mode it was in
before you started the review process or resumes Program Play with the
current track.
You may remove a selection from the Program Play list during the review
procedure using the CLEAR button, as described below.
CLEAR Button (remote only)
This button allows you to remove a track selection from the memorized
program play list during the review procedure described above. Follow
the review procedure until the desired track number appears. Then,
instead of pressing the REVIEW button to continue, remove the track by
pressing the CLEAR button while the track number is displayed. You may
then continue the review procedure.
RANDOM Button (remote only)
This instructs the CD player to play tracks from the entire disc in random
order. Once all of the selections have been played once, the disc will
stop playing, unless the REPEAT Button (see below) has been engaged,
in which case the random play will continue until the STOP button is
pressed. When the RANDOM button is engaged, the icon appears
in the Display.
REPEAT Button (remote only)
This button allows you to repeat the current track or the entire disc
continuously until the feature is cancelled by disengaging the REPEAT
button or pressing STOP. The REPEAT button steps sequentially through
the available options. Press the button once and the RCX-1500 will repeat
just the current track. The icon appears in the Display. Press the button
a second time and the RCX-1500 will repeat the entire disc. A second
icon appears in the Display. Press the button a third time to cancel the
REPEAT function. As noted above, REPEAT can be used in conjunction with
the RANDOM play feature. The REPEAT and RANDOM play combination
can also be used when playing CD-DA discs.
Note: The REPEAT function is automatically cancelled when the disc is
ejected.
SCAN Button (remote only)
This feature automatically plays the first ten seconds of each track on
the disc (or the memorized program). To activate the feature, press the
SCAN button. The icon appears in the Display. To stop scanning and
resume normal operation at the current track, press the SCAN button
again or press the PLAY /button.
The RANDOM and INTRO play combination can also be used when
playing CD-DA discs.
TIME Button (remote only)
Normally, the RCX-1500 displays the elapsed time of the currently
playing track. The TIME button allows you to see alternative time displays.
Pressing the button once displays the time remaining in the current track,
which counts down as the track continues playing. Pressing the button a
second time displays the time remaining on the entire disc (or memorized
program). When the alternative time displays are selected an “R” icon
appears in the display. Pressing the button a third time reverts to the
standard elapsed time display.
Note: When playing MP3 and WMA discs, only the regular elapsed
time and the time remaining in the current track can be displayed.
